BLU-RAY DISC / DVD PLAYER
Ver. 1.5 2012.08
BDP-BX38/S280/S380/S383
RMT-B109A/B109P/B109C/B110A/B110P
SPECIFICATIONS
System
Laser: Semiconductor laser
Inputs and outputs
(Jack name:
Jack type/Output level/Load impedance)
HDMI OUT:
HDMI 19-pin standard connector
COMPONENT VIDEO OUT
(Y, P B, P R
Phono jack/Y: 1.0 Vp-p/
PB,PR: 0.7 Vp-p/75 ohms
LINE OUT VIDEO:
Phono jack/1.0 Vp-p/75 ohms
LAN (100):
100BASE-TX Terminal
USB:
USB jack Type A (For connecting a USB memory,
General
Power requirements:
120V AC, 60Hz (US, CND)
220 – 240V AC, 50/60Hz (AEP,UK, AUS,RUS,CN)
Power consumption:
18 W (BDP-S380/S383/BX38)
Dimensions (approx.):
430mm×199mm×36mm
(17 in. × 7
4/5in. × 17/16 in.)
(width/depth/height) incl. projecting parts
Mass (approx.):
1..6 kg
Operating temperature:
5 ºC to 35 ºC(41 F to 95 F)
Operating humidity:
25 % to 80 %
Supplied accessories
Specifications and design are subject to change
without notice.
Audio/video cable (phono plug ×3) (1)
Remote commander (remote) (1)
Size AA (R6) batteries (2)
Photo: BDP-S280
Remote : RMT-B109A
HDMI cable (1) (Except AEP,UK,AUS,US,CND,PX,RUS)
(BDP-S280:US/S380:US/BX38:US)
ENERGY STAR and the ENERGY STAR mark
are registered U.S. marks. ENERGY STAR is a
registered mark owned by the U.S. government.
US Model
Canadian Model Saudi Arabia Model
E Model
PX Model
Australian /
New Zealand Model
Chinese Model
Indian Model
Russian Model
Taiwan Model
Thailand Model
AEP Model
UK Model
Singapore Model
Argentina Model
Middle East Model
memory card reader,digital stil camera and digital
video camera)
All model (REAR USB)
BDP-BX38/S380/S383 (FRONT USB)
(1) (BDP-S380 : TW only)
LAN cable
(Except AEP,UK,E,AR,SP,TH,CN,IN,TW)
16 W (BDP-S280)
110 – 240V AC, 50/60Hz (PX,E,AR,BR,SP,TH,EA,KS,IN)
110V AC, 60Hz (TW)
) :
LINE OUT R-AUDIO-L::
Phone jack/2 Vrms/10 kilohms
DIGITAL OUT (COAXIAL):
Phono jack/0.5 Vp-p/75 ohms
BDP-S380
BDP-S280/S380/BX38
BDP-S280/S380/S383
ºº
TM
UK Model
BDP-S280/S380/S383
Brazilian Model
BDP-S280/S380
Mexican Model
BDP-S380/S383

– 2 –
BDP-BX38/S280/S380/S383
SAFETY CHECK-OUT
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers' instructions to use these
instruments.
2. A battery-operated AC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit” indication
is 0.75V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples of a
passive VOM that is suitable. Nearly all battery operated digital
multimeters that have a 2V AC range are suitable. (See Fig. A)
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to
the customer and recommend their replacement.
4. Look for parts which, though functioning, show obvious signs
of deterioration. Point them out to the customer and recommend
their replacement.
5. Check the line cord for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
6. Check the B+ voltage to see it is at the values specified.
7. Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts forAC leakage. Check
leakage as described below.
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
Ω
μ
Fig. A. Using an AC voltmeter to check AC leakage.
Unleaded solder
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
CAUTION:
The use of optical instrument with this product will increase eye
hazard.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radia-
tion exposure.
This label is located on the laser
protective housing inside the
enclosure.
WARNING!!
WHEN SERVICING, DO NOT APPROACH THE LASER
EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS
NECESSARY TO CONFIRM LASER BEAM EMISSION,
BE SURE TO OBSERVE FROM A DISTANCE OF MORE
THAN 25 cm FROM THE SURFACE OF THE OBJEC-
TIVE LENS ON THE OPTICAL PICK-UP BLOCK.
For customers in European countries
product. The CLASS 1 LASER PRODUCT
MARKING is located on the rear exterior.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK OR DOTTED LINE WITH
MARK ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLE-
MENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
For customers in Taiwan
