Sony Ke-42xs920 User manual

FLAT PANEL COLOR TELEVISION

SERVICE MANUAL

MR-2

CHASSIS

MODEL NAME REMOTE COMMANDER DESTINATION

9-965-966-01

KE-42XS910

RM-Y1001 BRAZIL

HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

ORIGINAL MANUAL ISSUE DATE: 6/2004

REVISION DATE REVISION TYPE SUBJECT

6/2004 No revisions or updates are applicable at this time.

FLAT PANEL COLOR TELEVISION

SERVICE MANUAL

MR-2

CHASSIS

MODEL NAME REMOTE COMMANDER DESTINATION

9-965-966-01

KE-42XS910

RM-Y1001 BRAZIL

KE-42XS910

3

KE-42XS910

TABLE OF CONTENTS

Speciﬁcations ................................................................................. 4

Warnings and Cautions .................................................................. 5

Safety Check-Out ........................................................................... 6

SECTION 1: DISASSEMBLY................................................................. 7

1-1. Rear Cover Removal.............................................................. 7

1-2. A Board Removal ................................................................... 8

1-3. DE2, DIC2, J1 and MS2A Board Removal............................. 9

1-4. K Board Removal ................................................................... 9

1-5. H2 Board Removal............................................................... 10

1-6. HM and H1 Board Removal ................................................. 10

1-7. Speaker Box Removal ..........................................................11

1-8. Switching Regulator Removal ...............................................11

1-9. Shield Assembly Removal.................................................... 12

1-10.Plasma Display Panel Removal ........................................... 12

1-11. H3 and H4 Board Removal .................................................. 13

SECTION 2: DIAGRAMS..................................................................... 14

2-1. Circuit Boards Location ........................................................ 14

2-2. Printed Wiring Boards and

Schematic Diagrams Information ......................................... 14

2-3. Frame Diagrams .................................................................. 16

2-4. Block Diagrams .................................................................... 17

2-5. Schematics and Supporting Information .............................. 18

DE2 Board Schematic Diagram (1 of 6)............................... 18

DE2 Board Schematic Diagram (2 of 6)............................... 19

DE2 Board Schematic Diagram (3 of 6)............................... 20

DE2 Board Schematic Diagram (4 of 6)............................... 20

DE2 Board Schematic Diagram (5 of 6)............................... 21

DE2 Board Schematic Diagram (6 of 6)............................... 22

MS2A Board Schematic Diagram (1 of 3) ............................ 23

MS2A Board Schematic Diagram (2 of 3) ............................ 24

MS2A Board Schematic Diagram (3 of 3) ............................ 25

DIC2 Board Schematic Diagram (1 of 6).............................. 26

DIC2 Board Schematic Diagram (2 of 6).............................. 26

DIC2 Board Schematic Diagram (3 of 6).............................. 27

DIC2 Board Schematic Diagram (4 of 6).............................. 27

DIC2 Board Schematic Diagram (5 of 6).............................. 28

DIC2 Board Schematic Diagram (6 of 6).............................. 29

J1 Board Schematic Diagram .............................................. 30

A Board Schematic Diagram (1 of 4).................................... 31

A Board Schematic Diagram (2 of 4).................................... 32

A Board Schematic Diagram (3 of 4).................................... 33

A Board Schematic Diagram (4 of 4).................................... 33

H1 Board Schematic Diagram.............................................. 34

H2 Board Schematic Diagram.............................................. 35

H3 Board Schematic Diagram.............................................. 36

H4 Board Schematic Diagram.............................................. 37

HM Board Schematic Diagram............................................. 38

K Board Schematic Diagram................................................ 39

2-6. Semiconductors ................................................................... 40

SECTION 3: EXPLODED VIEWS........................................................ 41

3-1. Cover and Stand .................................................................. 41

3-2. Speaker................................................................................ 42

3-3. Chassis - 1 ........................................................................... 43

3-4. Chassis - 2 ........................................................................... 44

3-5. Packing Material................................................................... 45

SECTION 4: ELECTRICAL PARTS LIST........................................... 46

SECTION TITLE PAGE SECTION TITLE PAGE

4

KE-42XS910

SPECIFICATIONS

Design and speciﬁcations are subject to change without notice.

110-220V, 50Hz

410 W

3.3 W

Video (IN)

3 total (1 on side panel)

1Vp-p, 75ohms unbalanced, sync negative

S Video (IN)

3 total (1 on side panel)

Y: 1Vp-p, 75ohms unbalanced, sync negative

C: 0.286Vp-p (Burst signal), 75ohms

Audio (IN)

6 total (1 on side panel)

500 mVrms (100% modulation)

Impedance:47 kilo ohms

Audio (VAR/FIX)

1 total

408mVrms at the maximum volume setting (Variable)

408mVrms (Fixed)

Impedance (Output):2 kilo ohm

Power Requirements

Power Consumption (W)

In Use (Max)

In Standby

Inputs/Outputs

Control S (IN/OUT)

1 total

Component Video Input

2 (Y, PB, PR)

Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative

PB: 0.7 Vp-p, 75 ohms;

PR: 0.7 Vp-p, 75 ohms

Sub woofer (OUT)

1 total (phono jack)

RF Inputs

2 total

Television system

NTSC, PAL-M

Channel coverage

VHF: 2-13/ UHF: 14-69/ CATV: 1-125

Antenna

75-ohm external antenna terminal for VHF/UHF

Panel System

Plasma Display panel

Resolution

1024 pixels (horizontal) x 1024 pixels (vertical)

Screen size

42 inches measured diagonally

Supplied Accessories

Remote Commander RM-Y1001

Two Size AA (R6) Batteries

AC power cord

Antenna cable

Cable clamp

Four Clamp rivets

Two Clamp screws

Cleaning cloth

KE-42XS910

S

p

eaker Out

p

ut

(

W

)

15W x 2

Dimensions (W x H x D)

mm 1,229 x 753 x 286 mm

in 48 3/8 x 29 3/4 x 11 3/8 in

Mass

kg 44.5 kg

lbs 98 lbs 2 oz

5

KE-42XS910

WARNINGS AND CAUTIONS

CAUTION

Short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield, or carbon painted on the CRT, after

removing the anode.

WARNING!!

An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of

this receiver is directly connected to the AC power line.

!SAFETY-RELATED COMPONENT WARNING!!

Components identiﬁed by shading and

!

mark on the schematic diagrams, exploded views, and in the parts list are critical for safe

operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements

published by Sony. Circuit adjustments that are critical for safe operation are identiﬁed in this manual. Follow these procedures

whenever critical components are replaced or improper operation is suspected.

6

KE-42XS910

SAFETY CHECK-OUT

After correcting the original service problem, perform the following

safety checks before releasing the set to the customer:

1. Check the area of your repair for unsoldered or poorly soldered

connections. Check the entire board surface for solder splashes and

bridges.

2. Check the interboard wiring to ensure that no wires are “pinched” or

touching high-wattage resistors.

3. Check that all control knobs, shields, covers, ground straps, and

mounting hardware have been replaced. Be absolutely certain that

you have replaced all the insulators.

4. Look for unauthorized replacement parts, particularly transistors,

that were installed during a previous repair. Point them out to the

customer and recommend their replacement.

5. Look for parts which, though functioning, show obvious signs of

deterioration. Point them out to the customer and recommend their

replacement.

6. Check the line cords for cracks and abrasion. Recommend the

replacement of any such line cord to the customer.

7. Check the B+ and HV to see if they are speciﬁed values. Make sure

your instruments are accurate; be suspicious of your HV meter if sets

always have low HV.

8. Check the antenna terminals, metal trim, “metallized” knobs, screws,

and all other exposed metal parts for AC leakage. Check leakage as

described below.

Leakage Test

The AC leakage from any exposed metal part to earth ground and

from all exposed metal parts to any exposed metal part having a

return to chassis, must not exceed 0.5 mA (500 microamperes).

Leakage current can be measured by any one of three methods.

1. A commercial leakage tester, such as the Simpson 229 or RCA

WT-540A. Follow the manufacturers’ instructions to use these

instructions.

2. A battery-operated AC milliampmeter. The Data Precision 245

digital multimeter is suitable for this job.

3. Measuring the voltage drop across a resistor by means of a VOM

or battery-operated AC voltmeter. The “limit” indication is 0.75

V, so analog meters must have an accurate low voltage scale.

The Simpson’s 250 and Sanwa SH-63TRD are examples of

passive VOMs that are suitable. Nearly all battery-operated digital

multimeters that have a 2 VAC range are suitable (see Figure A).

How to Find a Good Earth Ground

A cold-water pipe is a guaranteed earth ground; the cover-plate

retaining screw on most AC outlet boxes is also at earth ground. If the

retaining screw is to be used as your earth ground, verify that it is at

ground by measuring the resistance between it and a cold-water pipe

with an ohmmeter. The reading should be zero ohms.

If a cold-water pipe is not accessible, connect a 60- to 100-watt

trouble- light (not a neon lamp) between the hot side of the receptacle

and the retaining screw. Try both slots, if necessary, to locate the hot

side on the line; the lamp should light at normal brilliance if the screw

is at ground potential (see Figure B).

To Exposed Metal

Parts on Set

0.15 F

Earth Ground

AC

Voltmeter

(0.75V)

Trouble Light

AC Outlet Box Ohmmeter

Cold-water Pipe

Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

7

KE-42XS910

1-1. REAR COVER REMOVAL

SECTION 1: DISASSEMBLY

Six screws

(+BVTP 4x16)

Four screws

(+BVTP 4x16)

Four screws

(+BVTP 4x16)

Six screws

(+PSW 3x6)

Two screws

(+PSW 3x6)

Stand Assy

Speaker cover (R) Ass

y

Six screws

(+PSW 4x10)

Two screws

(+PSW 5M) (Stand)

Two screws

(+PSW 5M) (Stand)

Speaker cover (L) Assy

Three screws

(+PSW 5x10)

Three screws

(+PSW 5x10)

Four screws

(+PSW 3x6)

Four screws

(+PSW 3x6)

Rear cover

1

2

3

9

566

6

5

8

7

5

6

4

8

KE-42XS910

1-2. A BOARD REMOVAL

DM Block Assy

Four screws

(+PSW 3x6) Four screws

(+PSW 3x6)

A board

Two screws

(+PSW 3x6)

2

1

3

4

9

KE-42XS910

Four screws

(+PSW 3x6)

Frame DM (L)

Top shield

Six screws

(+PSW 3x6)

DEC2 board

DE2 board

Shield cover DM

Shield DM (Main)

Four screws

(+PSW 3x6)

Four screws

(+PSW 3x6)

Two screws

(+PSW 3x6)

Two screws

(+PSW 3x6)

Four screws

(+PSW 3x6)

Two screws

(+PSW 3x6)

Four screws

(+PSW 3x6)

MS2A board

J1 board

Frame DE (Top)

Lead with

connector (LVDS)

LVDS Cover

Frame DE (Buttom)

Frame DM (R)

6

4

5

1

2

1

8

7

9

3

1-3. DE2, DIC2, J1 AND MS2A BOARD REMOVAL

1-4. K BOARD REMOVAL

RF Shield

Four screws

(+PSW 3x6)

K board Two screws

(+PSW 3x6)

1

2

10

KE-42XS910

1-6. HM AND H1 BOARD REMOVAL

Two screws

(+BVTP 4x16)

Six screws

(+BVTP 4x16) Speaker box (L) Assy

Two screws

(+BVTP 3x12)

Connector panel cover

Two screws

(+BVTP 3x12)

H2 board

1

2

3

1

Three screws

(+BVTP 3x12)

HM board H1 board

Two screws

(+BVTP 3x12)

Multi button

Control panel cove

r

Four screws

(+BVTP 3x12)

Six screws

(+BVTP 4x16)

Two screws

(+BVTP 4x16)

Speaker box (L) Assy

1

2

5

43

1-5. H2 BOARD REMOVAL

11

KE-42XS910

1-8. SWITCHING REGULATOR REMOVAL

Speaker box (R)

Thirteen screws

(+BVTP 4x16)

Thirteen screws

(+BVTP 4x16)

Speaker box (L)

2

1

Switching regulator

Seven screws

(+PSW 3x6)

Four screws

(+PSW 3x6)

Fan bracket

2

1

1-7. SPEAKER BOX REMOVAL

12

KE-42XS910

Four screws

(+PSW 4x8)

Plasma display panel

1

Two screws

(+BVTP 3x6)

Four screws

(+BVTP 3x12)

SUS shield (R) Assy

Three screws

(+PSW 3x6)

Two screws

(+BVTP 3x12)

A shield (bottom) Assy

Two screws

(+PSW 3x6)

Four screws

(+BVTP 3x12)

SUS shield (L) Assy

6

5

4

3

2

1

1-9. SHIELD ASSEMBLY REMOVAL

1-10.PLASMA DISPLAY PANEL REMOVAL

13

KE-42XS910

Two screws

(+BVTP 3x12)

Two screws

(+BVTP 3x12)

H4 board

Two screws

(+BVTP 3x12)

H3 board

Filter bracket (bottom) Assy

3

2

1-11.H3 AND H4 BOARD REMOVAL

14

KE-42XS910

SECTION 2: DIAGRAMS

2-1. CIRCUIT BOARDS LOCATION

2-2. PRINTED WIRING BOARDS AND

SCHEMATIC DIAGRAMS INFORMATION

All capacitors are in µF unless otherwise noted. pF : µµF 50WV or

less are not indicated except for electrolytics and tantalums.

All electrolytics are in 50V unless otherwise speciﬁed.

All resistors are in ohms. kΩ=1000Ω, MΩ=1000kΩ

Indication of resistance, which does not have one for rating

electrical power, is as follows: Pitch : 5mm

Rating electrical power :

1/4 W

1/4 W in resistance, 1/10 W and 1/16 W in chip resistance.

: nonﬂammable resistor

: fusible resistor

: internal component

: panel designation and adjustment for repair

: earth ground

: earth-chassis

All variable and adjustable resistors have characteristic curve B,

unless otherwise noted.

Readings are taken with a color-bar signal input.

Readings are taken with a 10MΩdigital multimeter.

Voltages are DC with respect to ground unless otherwise noted.

Voltage variations may be noted due to normal production

tolerances.

All voltages are in V.

S : Measurement impossibility.

: B+line.

: B-line. (Actual measured value may be different).

: signal path. (RF)

Circled numbers are waveform references.

Divided schematic diagram:

Some schematic diagrams are divided into several pieces.

Information to where the line is to be connected is printed at the end

of each line.

For example: [TO A1/3, A2/3_1] means theline is connected to Ref.

No. 1 of A (1 of 3) and A (2 of 3) schematic diagrams.

TO A1/3,A2/3_1

Ref. No.

Name of divided schematic diagram

H1 Board

HM Board H3 Board

K Board A Board

H4 Board

DM Block Assy

(Includes DE2 and

DICC2 Boards)

H2 Board

Switching Regulator

MS2A Board

15

KE-42XS910

REFERENCE INFORMATION

RESISTOR

: RN METAL FILM

: RC SOLID

: FPRD NONFLAMMABLE CARBON

: FUSE NONFLAMMABLE FUSIBLE

: RW NONFLAMMABLE WIREWOUND

: RS NONFLAMMABLE METAL OXIDE

: RB NONFLAMMABLE CEMENT

: ADJUSTMENT RESISTOR

COIL

: LF-8L MICRO INDUCTOR

CAPACITOR

: TA TANTALUM

: PS STYROL

: PP POLYPROPYLENE

: PT MYLAR

: MPS METALIZED POLYESTER

: MPP METALIZED POLYPROPYLENE

: ALB BIPOLAR

: ALT HIGH TEMPERATURE

: ALR HIGH RIPPLE

The components identiﬁed by

X

in this basic schematic diagram

have been carefully factory-selected for each set in order to satisfy

regulations regarding X-ray radiation. Should replacement be

necessary, replace only with the value originally used.

When replacing components identiﬁed by

Y

, make the necessary

adjustments as indicated. If the results do not meet the speciﬁed

value, change the component identiﬁed by

X

and repeat the

adjustment until the speciﬁed value is achieved.

When replacing the parts listed in the table below, it is important to

perform the related adjustments.

The components identiﬁed by shading and

!

symbol are critical for safety. Replace

only with part number speciﬁed.

The symbol indicates a fast operating fuse and is displayed on the component

side of the board. Replace only with fuse of the same rating as marked.

G

D

S

B1 E1

C2

B2 C1

E2

2

3

4

5

6

7

8

9

10

11

12

14

16

17

18

1

G

D

S

B2 E2

C1

B1 C2

E1

B2 E2

C1

B1 C2

E1

B2 E2

C1

B1 C2

E1

19

B1 E1

E2

C1(B2)

C2

20

B1

E2

C1

C2

22

23 -

(B2)

E1

(B2)

E1

E2

B1

C2

C1

21

B1

E1

C2

B2

C1

E2

G

SS

D

G

D

B1

E1

C2

B2

C1

E2

B1

E2

C2C1(B2)

E2

B1

C1

C2E1(B2)

C2

B1

C1

E2E1(B2)

C2

B1

C1

E2

B2

E1

C2

Ver.1.6

Transistor

(FET)

Transistor

Discrete semiconductor

(Chip semiconductors that are not actually used are included.)

Diode

Source

Anode Anode

(NC)

Cathode

Anode

Cathode

Common

Cathode Cathode

Common

Cathode Cathode

Common

Cathode

Anode

Base Emitter

Collector

Base Emitter

Collector

Drain

Gate

Drain

Device Printed symbol Terminal name Circuit

Terminal name of semiconductors in silk screen

printed circuit ( )

Anode

Anode Cathode

Anode Anode

Cathode

13

Transistor

(FET)

Transistor

(FET)

15

Emitter

Collector

Base

Transistor

Source

Gate

Drain

Cathode

Anode

Anode Cathode

Anode

*

_

KE-42XS910

16

KE-42XS910

2-3. FRAME DIAGRAMS

WHT

14P

WHT

6P

5P

CN1810 CN1809

CN1811

14

13

12

11

10

9

8

7

6

5

4

3

2

1

6

5

4

3

2

1

5

4

3

2

1

MS3.3V

GND

9V

AC DET1

GND

POWER

ILINK STBY

TH1

GND

3.3V

GND

5V

14V

STBY5V

GND

2.5V

GND

3.3V

GND

A8

FAN_ERR

ANT_MS

B1

GND

A1

GND

FAN

GND

B2

A2

A3

B3

SET 2.5V

SET 3.3V

14V

GND

A4

B4

A5

B5

GND

A6

B6

A7

B7

MAIN_AFT

MAIN_HSYNC

SET 1.8V

GND

B8

A9

B9

A10

O-SAP

AGC

B10

A11

B11

A12

SET 5V

7V

B14

GND

FMONO

I-SAP

GND

B13

B12

A13

A14

GND

10V

GND

A15

B15

A16

B16

GND

B25

STBY 5V

MAIN_CB/C_OUT

MAIN_YV_OUT

GND

A19

9V

GND

A17

B17

A18

B18

GND

A20

B19

B20

A21

SUB_CR_OUT

SUB_CB/C_OUT

SUB_YV_OUT

MAIN_CR_OUT

GND

B21

A22

B22

A23

GND

B23

A24

B24

A25

MS_R_IN

MS_L_IN

MAIN_SLICER

SUB_SLICER

GND

A26

B26

A27

B27

GND

A28

B28

A29

B29

ATSC_R_IN

ATSC_L_IN

ATSC_PR_IN

ATSC_PB_IN

ATSC_Y_IN

CN1804

100P

A32

GND

A31

A30

B30

B31

GND

B32

A33

B33

A34

GND

A43

SP_DC_PROT

SDA_MAIN

SCL_MAIN

DVI_VGA

DVI_MUTE

DVI_RST

B36

GND

B34

A35

B35

A36

GND

B37

A37

A38

B38

SP_MUTE

WOOFER_MUTE

LINE_MUTE

UD_SDA

UD_SCL

UD_BINT

GND

A39

B39

A40

B40

GND

A41

B41

A42

B42

CLAMP_GATE

CV_COMP_SW

SIRCS

GND

B43

A44

B44

A45

NC

B45

A46

B46

A47

KEY_WAKE

P-SW(-)

B49

KEY

NC

GND

B48

B47

A48

A49

P-ON

A50

B50

GND

B41

1.8V

B6

A2

A1

B1

CN1802

100P

GND

B2

A3

B3

A4

B4

A5

B5

A6

O_DIS_Y

5V

GND

O_DIS_CB

GND

5V

GND

A24

O_MID_BUSY

A7

B7

A8

B8

A9

B9

A10

B10

O_DIS_CR

GND

1.8V

GND

O_DIS_HS

GND

1.8V

GND

A11

B11

A12

B12

A13

B13

A14

B14

A15

O_DIS_YS

O_DIS_VS

I_BINT

GND

I_MICOM_VP

GND

B_MS/CNM_USB_D+

B_MS/CNM_USB_D-

I_MS/CNM_AC_DET

I_MS/CNM_RESET

B15

A16

B16

A17

B17

A18

B18

A19

B19

MS3.3V

O_DRC_VP

GND

MS3.3V

GND

A20

B20

A21

B21

A22

B22

A23

B23

3.3V

GND

3.3V

GND

O_CNM_UART_UX

I_MS_AU_L_IN

B_I2C_SCL_5V

I_MS_AU_R_IN

B_I2C_SDA_5V

O_MS_AU_L_OUT

O_CNM_UART_TX

O_MS_AU_R_OUT

O_ATHENA3_M_BLOCK

B24

A25

B25

A26

B26

A27

B27

A28

GND

B28

A29

B29

A30

B30

A31

B31

A32

B32

GND

CHECK_A2.5V

O_PAL_FILM_MOD

O_ATHENA3_S_BLOCK

I_MS_MAIN_CV_IN

I_MS_SUB_CV_IN

SYS RST(I_BOARD_RESET)

I_SUB_C/CB

A33

B33

A34

B34

A35

B35

A36

B36

A37

GND

B37

A38

B38

A39

B39

A40

B40

A41

I_SUB_CR

GND

2.5V

GND

I_SUB_Y/CV

I_MAIN_C/CB

I_MAIN_Y/CV

A42

B42

A43

B43

A44

B44

A45

B45

2.5V

GND

I_MAIN_CR

2.5V

GND

A46

B46

A47

B47

A48

B48

A49

B49

A50

GND

9V

GND

9V

GND

B50

GND

B6

SUB_SLIDER_Y

MAIN_SLIDER_Y

GND

A1

B1

A2

DVI_VGA

DVI_RST

DVI_MUTE

SYSTEM_RST

MS_AC_DET

GND

USB-N

USB-P

B2

A3

B3

A4

B4

A5

B5

A6

CV_COMP_SW

SP_DC_PROT

SP_MUTE

WOOFER_MUTE

LINE_MUTE

GND

SIRCS

A7

B7

A8

B8

GND

A9

B9

A10

B10

MAIN_AFT

MAIN_HSYNC

AGC

A13

GND

ANT

A12

A11

B11

B12

I_SAP

O_SAP

GND

FMONO

B13

A14

B14

A15

GND

A24

KEY_WAKE

LOGO_LED

PICOFF_LED

TIMER_LED

ILINK_LED

STBY_LED

B17

P_LED

B15

A16

B16

A17

GND

KEY

B18

A18

A19

B19

S-BLOCK

M-BLOCK

DRC_VP

MID_BUSY

GND

P-ON

VP

A20

B20

A21

B21

RESET

A22

B22

A23

B23

/AC_INT

/BOX_RST

TV_RXD

TV_TXD

CN1805

100P

GRANT

B24

A25

B25

A26

GND

SDA

BINT

B26

A27

B27

A28

UD_SDA

UD_SCL

UD_BINT

B30

GND

SCL

B29

B28

A29

A30

GND

A31

B31

A32

B32

AC_RLY_ILINK

B41

NC

A35

GND

A33

B33

A34

B34

NC

GND

A36

B35

B36

A37

AC_RLY_STBY

AC_DET

FAN-ERR

FAN

TEMP2

TEMP1

B37

A38

B38

A39

GND

TEMP3

B39

A40

B40

A41

STBY5V

ATSC-OVP

D-OVP

VPR2

GND

A42

B42

A43

B43

GND

2.5V

GND

A44

B44

A45

B45

GND

A48

GND

2.5V

GND

3.3V

A47

A46

B46

B47

GND

3.3V

GND

5V

B48

A49

B49

A50

1.8V

B50

WHT

CN1806

13P

STBY 5V

LOGO_LED

1

GND 4

5V 2

3

CN1813

4P

STBY_LED

ILINK_LED

TIMER_LED

PICOFF_LED

STBY 5V

GND

9

10

6

P_LED

7

8

GND 4

5

SIRCS

2

3

5V

CN1814

10P

1

2GND

TH2

3

4GND

TH3

CN1801

4P

DIC2.5V 9

DIC2.5V

13

12

GND

10

11GND

3.3V

DIC2.5V

7

8

GND

6

5

7V

5V

2GND

4

3

GND

9V

1

J1

DIC2

P-ON

A20

STBY5V

B44

SET1.8V

B50

CN4100

100P

SET3.3V

B47

SET5V

SET3.3V

GND

A49

GND

B49

A50

GND

A48

B48

SET2.5V

GND

A46

GND

B46

A47

GND

A45

B45

ATSC-OVP

D-OVP

AC_RLY_LINK

GND

VPR2

A43

B43

A44

B41

A42

B42

TEMP1

AC_RLY_STBY

AC_DET

TEMP2

TEMP0

GND

A40

B40

A41

B38

A39

B39

FAN-ERR

FAN

GND

A37

B37

A38

NC

B35

A36

B36

NC

GND

A34

B34

A35

GND

B32

A33

B33

GRANT

A26

UD_SDL

UD_SCL

UD_BINT

GND

A31

B31

A32

B29

A30

B30

/AC_INT

BINT

GND

SCL

SDA

A28

B28

A29

GND

B26

A27

B27

M-BLOCK

A23

/BOX-RST

TV_RXD

TV_TXD

S-BLOCK

B24

A25

B25

GND

B23

A24

DRC_VP

RESET

MID_BUSY

VP

B21

A22

B22

GND

B20

A21

KEY-WAKE

LOGO_LED

PICOFF_LED

TIMER_LED

KEY

GND

B18

A19

B19

A17

B17

A18

ILINK_LED

STBY_LED

P_LED

FMONO

I_SAP

B15

A16

B16

GND

A14

B14

A15

O_SAP

MAIN_AFT

MAIN_HSYNC

AGC

B12

A13

B13

GND

ANT

A11

B11

A12

CV_COMP_SW

SP_DC_PROT

SP_MUTE

WOOFER_MUTE

LIME_MUTE

GND

B9

A10

B10

A8

B8

A9

MAIN_SLIDER_Y

B1

SYSTEM_RST

DVI_MUTE

DVI_RST

SIRCS

DVI_VGA

GND

B6

A7

B7

A5

B5

A6

SUB_SLIDER_Y

MS_AC_DET

USB-N

USB-P

A3

B3

A4

B4

GND

A2

B2

GND

A1

RXD-JIG

TXD-JIG

RESET

CNVSS

JIG

SW-1

19

20

SCLK 12

16

17

18

GND

EPM

BUSY 13

14

15

CE 9

RXD

TXD 10

11

SDA

SCL

6

7

8

UD_BINT

UD_SCL

UD_SDL

B-INT

20P

GND

3

4

5

1

2

CN4401

DE2

DRAIN

6

RXIN3+

RXIN3-

RXCLK+

RXCLK-

RXIN2+

RXIN2-

DRAIN

12

13

14

9

10

11

7

8

RXIN1+

RXIN1-

DRAIN

RXIN0+

RXIN0-

CN3801

14P

3

4

5

1

2

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

CN2402

CN2401 20P

20P

UD_SCL

UD_BINT

GND

BINT

UD_SDA

CE

SCL

SDA

CNVSS

RXD

TXD

SCLK

GND

EPM

BUSY

JIG

RESET

TXD-JIG

RXD-JIG

SW_1

TXD-JIG

RXD-JIG

UD_BINT

UD_SCL

BINT

GND

UD_SDA

CE

CNVSS

SCL

SDA

SCLK

RXD

TXD

RESET

GND

EPM

BUSY

JIG

SW_1

J2

H1

KEY1

P-ON

P-SW(-)

STBY5V

KEY-WAKE

GND

1

2

3

4

5

6

7

CN9501

7P

GND

S_SW2

S2-2

Y2

C2

V2

L2

R2

1

2

3

4

5

6

7

8

9

10

11

12

CN9601

12P

12

34

V

L

R

J9601

J9602

H2

RLVIDEO

AUDIO

S VIDEO

LOGO

GND

SET 5V

STBY 5V

1

2

3

4

CN9801

4P

H4

STBY5V

POWER_LED

5V

IR

GND

PICOFF_LED

TIMER_LED

STBY_LED

GND

ILINK_LED

1

2

3

4

5

6

7

8

9

10

CN9701

10P-L

H3

R-

R+

GND

L-

L+

GND

SP MUTE

SP-DC-PORT

1

2

3

4

5

6

7

8

CN3001

8P

AUDIO_-14V

AUDIO_+14V

AUDIO_GND

1

2

3

4

5

6

7

CN3061

7P

WHT

L

R

L OUT

R OUT

AUDIO_GND

1

2

3

4

CN3062

4P

WHT

K

SPEAKER

RXC-

RXC+

RXO+

RXO-

HPD

RX1+

RX1-

5V

SDA

SCL

RX2+

RX2- 1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

CN7001

24P

5V

DVI-RST

MUTE

VGA

GND

D-PR

GND

D-PB

GND

D-Y

GND

1

2

3

4

5

6

7

8

9

10

11

CN7004

11P

SDA

SCL

UD_BINT

GND

1

2

3

4

CN7002

4P

UD

4

1

2

3

11

9

6

7

5

8

10

4

1

2

3

4

3

2

1

7

6

5

1

9

8

7

6

4

3

2

5

12

11

10

D-Y

GND

D-PB

VGA

5V

D-PR

GND

MUTE

DVI-RST

SCL

GND

SDA

UD_BINT

P-ON

GND

P-SW(-)

KEY1

GND

STBY5V

KEY-WAKE

C2

GND

S2-2

Y2

S_SW2

GND

V2

L2

GND

R2

12P

CN8230

7P

CN8005

4P

CN8004

CN8403

11P

B4

A1

A3

A2

B2

B1

A4

B3

A6

B5

A5

B7

A7

B6

A9

B8

A8

B10

A10

B9

A17

A12

B11

A11

A13

B12

B13

B15

A15

A14

B14

B16

A16

B18

A18

B17

B19

A20

A19

B21

A21

B20

A23

B22

A22

B29

B24

A24

B23

A26

A25

B25

A28

B27

A27

B26

A29

B28

A31

B30

A30

B32

B31

A32

A34

B33

A33

B35

A35

B34

A42

A37

A36

B36

B38

A38

B37

B40

A40

B39

A39

B41

A41

B43

B42

A43

A45

B44

A44

B46

A46

B45

A48

B47

A47

A49

B48

B49

B50

A50

100P

CN8001

14V

GND

FAN_ERR

ANT_MS

GND

FAN

GND

SET 3.3V

GND

SET 2.5V

GND

SET 1.8V

GND

SET 1.8V

GND

MAIN_HSYNC

GND

MAIN_AFT

O-SAP

AGC

GND

FMONO

I-SAP

SET 5V

7V

GND

10V

GND

STBY 5V

9V

GND

MAIN_YV_OUT

GND

MAIN_CB/C_OUT

GND

SUB_YV_OUT

MAIN_CR_OUT

GND

SUB_CR_OUT

SUB_CB/C_OUT

GND

MAIN_SLICER

MS_L_IN

GND

SUB_SLICER

MS_R_IN

GND

ATSC_Y_IN

ATSC_PB_IN

ATSC_L_IN

GND

ATSC_PR_IN

ATSC_R_IN

GND

DVI_RST

GND

UD_SCL

DVI_VGA

DVI_MUTE

GND

SDA_MAIN

SCL_MAIN

SP_DC_PROT

SP_MUTE

LINE_MUTE

GND

WOOFER_MUTE

UD_BINT

GND

CV_COMP_SW

GND

UD_SDA

SIRCS

GND

CLAMP_GATE

NC

KEY_WAKE

KEY

GND

P-SW(-)

P-ON

6

2

3

4

5

1

7

8

GND

R-

L+

L-

GND

R+

SP-DC-PORT

SP MUTE

CN8601

8P

WHT

GND

FAN4

GND

DRV3

FAN3

DRV4

DRV2

FAN2

6

5

11

10

9

8

7

12

12P

CN8002

WHT

GND

FAN1

DRV1

4

3

1

2

AUDIO

L

R

J8236

J8235

IN

DV1-HDTV

AUDIO

OUT

R

L

WOOFER OUT

J8237

IN

OUT

J8238

CONTROLS

R

J8230

P

R

B

P

Y

IN 4

HD/DVD

AUDIO

R

L

J8231

R

AUDIO

L

IN 5

HD/DVD

Y

J8233

B

P

R

P

R

J8232

R1

L1

V1

3 4

1 2

J8234

SW1

AUDIO

R

L

S VIDEO

VIDEO

L

AUDIO

R

VIDEO

S VIDEO

R2

V2

L2

4

SW2

1

3

2

VIDEO IN

A

MS1

MS2

GND

9V

1

2

3

4

WHT

CN8003

4P

TO ANT SW

TO PDP UNIT

:B-TO-B:B-TO-B

WHT

2P

3P

2P

3P

2P

UD Board

for US Models Only

J2 Board

for US Models Only

KE-42XS910

17

KE-42XS910

A

K

DIC2 (w/o CCD)

HM

DE2

Panel

MS2 F

H3

IR Rcv.

GP1UM27SRK

Memory Stick

Component

Input -1

S Vi deo

Input -3

S Vi deo

Input -1

Audio L/R

Out (Fix/Val)

Woofer

Output

Ctrl-S

Input

Ctrl-S

Output

RF Input -1

RF Output

RF

SW

H2

S Vi deo

Input -2 Analo g CVBS

Analog L / R

Analog

Tu ner

BTF-WA421

Analog CVBS, Y/C

Analog L / R

Analog CVBS, Y/C

Analog L / R

H4

Logo LEDs

Front 5 Keys/

Power SW

LEDs

CCP2

<Sub>

CXD3802

3D-Comb

(2D)

SDRAM

16MB

CCP2

<Main>

CXD3802

3D-Comb

DRC-MFV1

CXD2097AQ

S D RAM

16MB

S D RAM

64MB*2

M I D-uC

MB94P918

NVM

8KB

I2 C

MS-IF LVDS Tx/Rx

SN65LVDT14PWR

COMP

MB93943

M S -uC

MB93403

FLASH

32MB

NVM

1KB

Local Bu s

LVDS Tx/Rx

SN65LVDT41PWR

S D RAM

128MB*2

DAC

AK4352

Analog

CVBS, Y / C

or Y/Cb/Cr

(Main )

LV D S T rans.

THC63LVDM83C

LVDS Receiver

THC63LVDF84B-T

LV D S T rans.

THC63LVD103

I2 C

Y/Cb/ C r

4:2:2

DCP

CXD9690Q

Y/Cb/ C r

4:2:2

LVDS Receiver

THC63LVD104

Analog

L/R

GBR

4:4:4

(LVDS)

UA R T

AV SW ( 2 )

CXA2069Q

ComponentI/F

CXA2171AQ

Video SW

M52055FP

LPF

30MHz

LPF

30MHz

MID-XU

CXD9707CGP

I2 C

Analog L / R

(Main )

TV-uC

M306V 7FH

Pan el-uC

MB91307A

OSD GBR

8bit each

NVM

16KB

Buton/LED C ontrol

I2 C

Buton/LED C o ntrol

SIRCS Input

MS

Memory Stick

Analog Y /Cb/

Cr

Analog Y /Cb/

Cr

Analog L / R

(Fix/Valuable)

Digital Part

Analog Part

uC

Memory

Analog Video

Analog Audio

Digital Video

Digital Audio

RF

Memory StickI/F

O t h ers

Original

Module

O t h ers

I2C

U ART

O t h ers

Others

Boards / Modules Functional Blocks Main Signals Control Si gnals

Analog

CVBS, Y / C

(Sub)

Analog

Y/Cb/ C r

4:2:2

(16bi t )

Y/Cb/ C r

4:2:2

(16bi t )

LVDS Receiver

THC63LVD104

Y/Cb/Cr 4:2:2 (16bit)

NVM

8KB

I2 C

DDR

16MB

Panel Driver

CXD9762GF

Local Bu s

(Log i c

)

Component

Input -2

Control

Signals

Buffe r

I2 C

SIRCS ( I R )

SIRCS Output

Speakers

Panel

IR

I2 C

Analog L / R

Tru

Surround

NJW1149

Buffer

NJM4558 x2

H1

GBR

4:4:4

AV SW ( 1 )

CXA2069Q

Analog L / R

Analog CVBS, Y/C

Analog L / R

Analog CVBS, Y/C (Sub)

Analog L/R (Sub)

Analog CVBS, Y/ C (Main)

Analog L/R (M a i n )

Analog CVBS, Y/ C (Main)

I2 C

Analog L + R

FHP: 32", 37", 42"

RF Input -2

< AUX>

Y/Cb/ C r

4:2:2

(16bi t )

LVDS Receiver

THC63LVD104

Delay

Contr o l

NJU26103

ADC

AK5380

DAC

AK4351

Buffer

NJM4558

Down Mix

NJM4558 x2

Buffer

NJM4560 x3

MS-IF

Buffer

NJM4560 x3

Audio

Amp.

TDA3490L

SIRCS ( I R )

Flash

1MB

I2 C

DAC

M B 8 8 141

Bus SW

LV4066

I2 C

Logo LED Control

Balanced Analog

L/R

Buton/LED Control

SIRCS (IR)

Logo LED Control

Y/Cb/Cr 4:2:2

(16bi t )

CCD

CXP964032

CCD

CXP964032

2-4. BLOCK DIAGRAMS

KE-42XS910

18

KE-42XS910

DE2 BOARD SCHEMATIC DIAGRAM (1 OF 6)

1

A

B

C

D

E

F

G

H

I

212 13

11

10

98765

43 14 15

STBY 5V

STBY 3.3V

STBY 5V

SW 3.3V

STBY 5V

STBY 3.3V

STBY 5V

STBY 3.3V

TO(2/6)

JL4407

TO(3/6)

TO(2/6)

TO(3/6)

CN2401

TO J2 BOARD

B-SS11646<UC.>-DE2-P1

(MAIN CPU)

DE2(1/6)

CN1805

TO J1P BOARD

TO(3/6)

ORD4413 DAN202K

AC DET SW

AC DET

INV.

RESET

BUFF

TO(2/6)

CPU

TO(3/6)

TO(2/6)

BUS BUFFER

OR GATE

TO(3/6)

SW

R4421

:1005

10k

:1005

0

R4424

:1005

Q4401

F.F

INV.

NOR

TO(2/6)

A

CH1

CH0

VSS

VEE

INH

COM

UD_SDL

UD_SCL

UD_BINT

NC

GND

UD_BINT

UD_SCL

UD_SDL

GND

B-INT

SDA

SCL

RXD-JIG

TXD-JIG

JIG

SW-1

GND

MAIN_SLIDER_Y

SUB_SLIDER_Y

DVI_MUTE

DVI_RST

SYSTEM_RST

MS_AC_DET

GND

KEY-WAKE

/BOX-RST

GRANT

SET1.8V

GND

SET5V

GND

SET3.3V

GND

SET3.3V

GND

SET2.5V

GND

SET2.5V

GND

STBY5V

GND

VPR2

GND

ATSC-OVP

D-OVP

AC_RLY_LINK

TEMP1

/AC_INT

P-ON

AC_RLY_STBY

AC_DET

GND

TEMP2

TEMP0

FAN-ERR

FAN

GND

SCL

SDA

BINT

GND

TV_RXD

TV_TXD

GND

S-BLOCK

M-BLOCK

DRC_VP

RESET

VP

MID_BUSY

GND

KEY

GND

LOGO_LED

PICOFF_LED

TIMER_LED

ILINK_LED

STBY_LED

P_LED

GND

FMONO

I_SAP

O_SAP

AGC

MAIN_AFT

MAIN_HSYNC

GND

ANT

CV_COMP_SW

GND

SP_DC_PROT

SP_MUTE

WOOFER_MUTE

LIME_MUTE

GND

SIRCS

DVI_VGA

USB-N

USB-P

GND

MOD

VDD1

VSS1

VSS2

VDD2

900

CS0

CS1

CS2

VCC

AO6

AO5

AO4

AO3

AO2

AO1

AO12

AO11

AO10

AO8

AO9

AO7

SDA

SCL

GND

2OE

3OE

4OE

1OE

2Y

2A

1Y

1A

3Y

3A

4Y

4A

GND

VCC

RST

VCC

MAIN ON/OFF

MAIN_HIN

NC

ATSC_RXD

ATSC-TXD

PIC OFF-LED

FAN-ERR

SP_DC_PORT

NC

DIC_RST

NC

E-POW-WATCH

CPU-RST

E-BUSY

MS-RST

ANT_S

ATSC-GRANT

ATSC-OVP

ILINK-STBY-LED

BOX-RST

S-MODE1

S-MODE2

DVI_MUTE

DVI_VGA

DVI_RST

SUB_HIN

AGC_ATT

TIMER_LED

CV_COMP_SW

ANT_M

O_SAP

I_SAP

FMONO

TMDS-RSTP

POWER LEDP

CABLE_ERRORP

DCP_LVDS_PDN

M_SENSEP

AUDIO_CSN

AUDIO_CLKP

AUDIO_DATP

AUDIO_PDN

LVDS-PDN

TXD-PDP

RXD-PDP

SUB-AFT

MAINAFT

BUS-SW3

BO

GO

RO

RESET

BS-REC

OSDCLK

SUBW-MUTE

B2

G2

R2

B1

G1

R1

MPWRN

EPM

BUSY

SCLK

RXD

TXD

CE

CNVSS

HLF2

HLF1

VHOLD1

CVIN1

VCCE

TVSETB

CVIN2

VHOLD2

POWER-MUTE

B-INT

BUS-SW2

BUS-SW1

LINE-MUTE

OSD-V

OSD-H

OVP

D-OVP

STB-LED

AC-RLY

SP-MUTE

NVM-RST

NVM-WP

OSDOSC

VCCI

XIN

XOUT

CNVSS

SIRCS-IN

KEY1

DAT1

DAT0

CLK0

CLK1

YM

YS

VSS

RESET

BYTE

RST

VCC

$A0

DAT

CLK

WP

1234

5 6 7 8

123

4 5

1234567

891011121314

OUTVCC

GND

123

4 5

123

4 5

CONT VDD

OUT

123456789101112131415161718192021222324252627282930

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

123

4 5

1 2 3 4 5 6 7

891011121314

A1

B1

A2

B2

A3

B3

A4

B4

A5

B5

A6

B6

A7

B7

A8

B8

A9

B9

A10

B10

A11

B11

A12

B12

A13

B13

A14

B14

A15

B15

A16

B16

A17

B17

A18

B18

A19

B19

A20

B20

A21

B21

A22

B22

A23

B23

A24

B24

A25

B25

A26

B26

A27

B27

A28

B28

A29

B29

A30

B30

A31

B31

A32

B32

A33

B33

A34

B34

A35

B35

A36

B36

A37

B37

A38

B38

A39

B39

A40

B40

A41

B41

A42

B42

A43

B43

A44

B44

A45

B45

A46

B46

A47

B47

A48

B48

A49

B49

A50

B50

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

G2

G1S1 D2

D1 S2

12345678910

11 12 13 14 15 16 17 18 19 20

1234567

8 9 10 11 12 13 14

1234567

8

10 91112

13 14 15 16 17 18 19 20 21 22 23 24

123

4 5

1234

5 6 7 8

2PD601AR

Q4403

Q4404

Q4405

Q4406

Q4407

Q4408

Q4409

Q4411

Q4414

Q4415

Q4417

Q4420

Q4422

Q4423

Q4424

Q4425

IC4400

IC4404

IC4405

IC4407

IC4409

D4401

D4402

D4403

D4405

D4410

JL4400

JL4408

JL4409

JL4410

JL4411

C4402

C4407

C4414

C4416

C4418

C4420

C4439

FB4412

L4400

L4401

L4402

JL4412

JL4413

Q4419

Q4421

IC4406

C4434

Q4413

Q4418

JL4425

Q4412

IC4403

Q4426

Q4427

FB4420

JL4403

JL4405

JL4406

JL4401

JL4402

JL4414

JL4415

JL4416

JL4417

JL4418

JL4419

JL4420

JL4421

JL4422

IC4102

C4101

Q4101

IC4100

C4100

RB4100

RB4101

RB4102

JL4114

JL4109

JL4110

JL4112

JL4113

JL4116

JL4117

JL4119

JL4120

JL4108

Q4100

JL4100

JL4101

JL4102

JL4103

JL4104

JL4105

FB4102

FB4103

FB4104

FB4105

FB4106

FB4107

FB4108

FB4109

FB4111

FB4113

FB4114

FB4115

FB4116

FB4117

FB4118

FB4119

FB4120

FB4121

FB4122

FB4123

FB4124

FB4125

FB4126

FB4127

FB4128

FB4129

FB4130

FB4131

R4104

FB4132

FB4133

FB4134

FB4135

FB4140

FB4141

FB4142

FB4143

FB4144

FB4145

FB4146

FB4147

FB4148

FB4149

R4103

JL4106

JL4107

JL4111

JL4115

JL4118

C4400 C4401

C4403 C4404

C4405

C4406

C4409

C4410

C4411

C4412

C4415

C4417

C4419

C4421

C4422

C4423

C4430

C4432

C4433

TP4402

TP4403 TP4406

R4594

R4593

R4444

R4511

R4566

R4567

R4573

R4575

C4103

D4400

D4404

D4407

D4409

D4412

IC4103

R4404

C4428

C4429

C4431

C4440

C4441

FB4110

IC4408

Q4410

Q4416

JL4423

JL4424

IC4411

TP4400

TP4401

C4435 C4436

R4027

R4102

R4116

R4122 R4123

R4400

R4401

R4402

R4403

R4405

R4406

R4411

R4412

R4413

R4414

R4415

R4417

R4418

R4419

R4428

R4429

R4430

R4431

R4433

R4434

R4435

R4436

R4437

R4438

R4439

R4440

R4441

R4442

R4443 R4445

R4446

R4447

R4448

R4449

R4450

R4452

R4453

R4454

R4455

R4456

R4457

R4458

R4459

R4460

R4461

R4462

R4463

R4466

R4467

R4468

R4469

R4470

R4471

R4472

R4473

R4474

R4475

R4476

R4477

R4479

R4480

R4481

R4483

R4484

R4485

R4487

R4489

R4490

R4491

R4492

R4493

R4494

R4495

R4496

R4497

R4498

R4499

R4500

R4501

R4502

R4503

R4504

R4505

R4506

R4507

R4508

R4509

R4512

R4513

R4514

R4515

R4516

R4518

R4521

R4522

R4523

R4524

R4525

R4526

R4527

R4528

R4529

R4530

R4531

R4532

R4533

R4534

R4535

R4537

R4538

R4539

R4540

R4541

R4542

R4543

R4544

R4545

R4546

R4547

R4549

R4550

R4551 R4552

R4553

R4554

R4555

R4559

R4560

R4561

R4563

R4564

R4565

R4568

R4569 R4570

R4572

R4574

R4576

R4577

R4578

R4579

R4580

R4583

R4584

R4585

R4586

R4587

R4588

R4589

R4592

R4597

R4601

R4602

R4603

R4604

R4612

R4124

R4562

R4100

FB4100

FB4101

FB4112

JL4124

JL4125

JL4126

JL4127

Q4428

Q4429

R4598

R4599

CN4100

IC4401

R4600

R4605

R4606

R4607

R4610

C4447

C4448

CN4401

R4488

R4613

R4611

C4449

Q4430

R4595

R4558

R4422

R4408

R4548

R4557

C4450

C4451

C4452

C4453

C4444

C4445

R4464

R4520

R4608

IC4410

X4400

X4401

D4101

R4407

R4409

R4465

C4426

C4427

BD4729GTR

RESET

47

16V

:AL-CP

47

16V

:AL-CP

10

16V

:AL-CP

10

16V

:AL-CP

TC74LCX74FT

NJM2391DL1-33

3.3V-REG

22

16V

:AL-CP 22

16V

:AL-CP

TC7SZ02FU

10µH

:CHIP

10µH

:CHIP

TC74LCX273FT

BK2125HM601

1µH

:CHIP

MA111

47

16V

:AL-CP

DAP202K

PROT

DAP202K

PROT

INV.

1

10V

F:1608

DTA143EKA

LATCH

DTC143TKA

INVERTER

TC7SH04FU

DTA114EKA

2PD601AR

BK2125HS601

#

SN74LV125A

0.1

10V

B:1005

DTC114EUA

MB88141A

D/A CONV.

0.01

16V

B:1005

100*4

SSM6N15FU

BK1608HS601

#

BK1608HS601

#

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.01

F:1005

0.1

16V

F:1005

0.01

F:1005

0.1

16V

F:1005

0.01

16V

B:1005

0.0033

16V

B:1005

0.01

F:1005

0.01

16V

B:1005

0.001

B:1005

0.01

F:1005

33k

15k

0

:1005

0

:1005

0

:1005

0

:1005

0

:1005

0

:1005

0.1

10V

B:1005

DAN202K

PROT

DAN202K

PROT

DAN202K OR

TC7SET32FU

SN74LV4066APWR

BUS-SW

0

:1005

0.1

16V

B:1608

0.1

16V

B:1608

0.1

16V

B:1608

680p

B:1608

680p

B:1608

BLM11A601S

M24128-BWMN6T(A)

NVM

2PD601AR

BD4741G-TR

0.01

F:1608

10

:AL-CP

10k

:1005

0

:1005

10k

:1005

100

:1608

100

:1608

22

:1005

22

:1005

22

:1005

22

:1005

1k

:1608

1k

:1608

22

:1005

22

:1608

22

:1608

22

:1005

22

:1005

22

:1005

22

:1005

22

:1005

100

:1005

470k

:1005

22

:1608

2.2k

:1608

470k

:1005

100k

:1005

47k

:1005

22

:1608

2.2k

:1608

10k

:1005

47k

:1005

10k

:1005

2.2k

:1005

2.2k

:1005

100k

:1005

100k

:1005

470

:1005

100 :1005

10k :1005

47

:1005

47

:1005

10k :1005

100 :1005

22 :1005

47 :1005

100 :1005

47k :1005

1k :1005

1M

:1005

47 :1005

22 :1005

3.3k

:1005

100 :1005

1k :1005

10k

:1005

22

:1005

47k :1005

10k :1005

47 :1005

10k :1005

100 :1005

1M

:1608

100 :1005

47 :1005

1k :1005

10k :1005

1k :1005

47 :1005

1k :1005

47 :1005

1k :1005

47 :1005

10k :1005

1k :1005

10k :1005

1k :1005

10k

:1005

1k :1005

1k

:1005

1k

:1005

1k

:1005

10k

:1005

1k :1005

3.3k :1005

33k

:1608

10k :1005

100 :1005

10k :1005

1k :1005

100 :1005

1k

:1005

100 :1005

100

:1005

22k

:1608

1M

:1608

15k

:1005

10k

:1005

10k

:1005

10k

:1005

22k

:1005

22k

:1005

22k

:1005

10k

:1005

47k

:1005

100k

:1005

470

:1608

47k

:1005

47k

:1005

1k :1005

47k

:1005

10k

:1005

47k

:1005

47k

:1005

10k

:1005

10k

:1005

22k

:1005

33k

:1005

10k

:1005

22k

:1005

22k

:1005

0 :1005

4.7k

:RN-1608

2.2k

:1005

100

:1005

47k

:1005

22

:1005

1k

:1005

2PD601AR

BUFFER

2PD601AR

INV

2PB709AR

INV

2PD601AR

INV

2PB709AR

BUS-SW

2PD601AR

INV

2PB709AR

BUS-SW

2PD601AR

NVM-WP

#

NVM-RST

2PD601AR

LATCH

2PD601AR

LATCH

2PD601AR

INV

2PB709AR

2PD601AR

INV

2PD601AR

INVERTER

2PD601AR

BUFF

2SD601AR

0

:1005

4.7k

:1005

#

BK1608HS601

DTA114EKA

2PB709AR

0

:1005

0

:1005

100P

:B-TO-B

TC4W53FU

0

:1005

100

:1005

4.7k

:1005

0

:1005

100

:1005

0.1

10V

B:1005

0.001

B:1005

20P

FFC/FPC

#

1k

:1608

1k

:1608

1k

:1608

1k

:1608

0

:1608

0

:1608

0.001

B:1005

0.001

B:1005

100p

CH:1005

100p

CH:1005

2.2

6.3V

B:2012

2.2

6.3V

B:2012

10k :1005

470

:1608

470

:1608

M306V7FHFP-100

66.1565MHz

16MHz

MA111

0

1/16W

:1608

0

1/16W

:1608

680 :1005

12p

CH:1005

12p

CH:1005

P-MUTE

OSDHS

O1VS

RESET

OSD-M

RXD_PDP

TXD_PDP

I2C-DEV

DCP_LVDS_PD

DVI_RST

DVI_VGA

DVI_MUTE

DVI_RST

DVI_MUTE

DVI_VGA

ATSC-OVP

ILINK-STBY-LED

BOX-RST

ATSC-GRANT

ATSC

WOOFER-MUTE

POWER-LED

STBY-LED

TIMER-LED

P-ON

ILINK_POW_CTL

KEY-WAKE

CV-COMP-SW

SP-MUTE

ATSC-TXD

ATSC-RXD

ATSC-TXD

ATSC-RXD

KEY

SIRCS

STBY_ 3.3V-2

SW_3.3V

SW_ 5V

STBY_ 5V-2

ANT_M

DIC-RST

FAN-ERR

AGC

MAIN_HSYNC

AFT1

FMONO

I_SAP

O_SAP

LINE-MUTE

SP-DC-PROT

O1HS

PICOFF-LED

SW_

LOGO-LED

FAN

3.3V

JIG

RXD_PDP

SW_

STBY_

SW_

AC_DET

DVI_RST1

MUTE

VGA

SIRCS

LINE-MUTE

WOOFER-MUTE

SP-MUTE

SP-DC-PROT

CV-COMP-SW

ANT_M

MAIN_HSYNC

AFT1

AGC

O_SAP

I_SAP

FMONO

POWER-LED

STBY-LED

ILINK-STBY-LED

TIMER-LED

PICOFF-LED

LOGO-LED

KEY

KEY-WAKE

P-ON

O1VS

DIC-RST

BOX-RST

ATSC-GRANT

AC_DET

B-INT

FAN

FAN-ERR

THERMO_G

THERMO_PANEL

THERMO_HIC

AC-RLY

OVP

ILINK_POW_CTL

ATSC-OVP

VPR2

3.3V

3.3V-2

ATSC

5V-2

2.5V

I2C-DEV

SW_ 5V

MAIN_SLICER_Y

SUB_SLICER_Y

MAIN_SLICER_Y

STBY_ 5V-2

SW_ 1.8V

SW_ 5V

UD_JIG

I2C-DEV

RXD-JIG

TXD-JIG

JIG

UD_JIG

SI1

SO1

SW_1

TXD-JIG

RXD-JIG

STBY_ 3.3V-2

SI2

SO2

CORBU-UART

TXD_PDP

DCP-RST

SDA

SCL

R5

B5

G5

YS

YM

R6

G6

B6

G7

B7

R7

CLK

TXD

RXD

TXD

RXD

SDA

SCL

SDA

SCL

SDA

UD_SDL

UD_SCL

UD_BINT

SDA

SCL

UD_BINT

UD_SCL

UD_SDL

SI0

SO0

2-5.SCHEMATICS AND SUPPORTING INFORMATION

KE-42XS910

19

KE-42XS910

DE2 BOARD SCHEMATIC DIAGRAM (2 OF 6)

1

A

B

C

D

E

F

G

H

I

J

212 13

11

10

98765

43 14 15

+3.3V

+2.5V

B-SS11646<UC.>-DE2-P2

TO(4/6)

R3833

47:1005

DCP

TO(1/6)

DE2(2/6)

LEVEL SHIFT

TO(1/6)

RESET

TO(1/6)

TO MSZA BOARD

(DSP,RECEIVER)

I2C LEVEL CONVERTER

DEN

RXIN3+

RXIN3-

RXCLK+

RXCLK-

RXIN2+

RXIN2-

DRAIN

RXIN1+

RXIN1-

DRAIN

RXIN0+

RXIN0-

PLL_GND

PLL_VCC

GND

RXOUT0

RXCLKOUT

PWR_DWN

PLL_GND

LVDS_GND

RXIN3+

RXIN3-

RXCLKIN+

RXCLKIN-

RXIN2+

RXIN2-

LVDS_GND

LVDS_VCC

RXIN1+

RXIN1-

RXIN0+

RXIN0-

LVDS_GND

RXOUT27

RXOUT26

RXOUT25

GND

RXOUT24

RXOUT23

RXOUT22

RXOUT1

RXOUT2

VCC

RXOUT3

GND

RXOUT4

RXOUT5

RXOUT6

RXOUT7

RXOUT8

RXOUT9

VCC

RXOUT10

RXOUT11

RXOUT12

GND

RXOUT13

RXOUT14

RXOUT15

RXOUT16

RXOUT17

RXOUT18

GND

RXOUT19

RXOUT20

RXOUT21

VCC

BOUT5

NC OSD2BIN1

OSD2GIN0

OSD2GIN1

OSD2BIN0

CBFIN0

CBFIN1

CBFIN2

CBFIN3

CBFIN4

VSS

VDDE

CBFIN5

CBFIN6

CBFIN7

CBFIN8

CBFIN9

YGFIN0

YGFIN1

YGFIN2

YGFIN3

YGFIN4

YGFIN5

VSS

VDDI

YGFIN6

YGFIN7

YGFIN8

YGFIN9

CRIN0

CRIN1

CRIN2

CRIN3

CRIN4

CRIN5

VSS

VDDI

CRIN6

CRIN7

CRIN8

CRIN9

CBIN0

CBIN1

CBIN2

CBIN3

CBIN4

CLK

VSS

VDDI

CBIN5

CBIN6

CBIN7

CBIN8

CBIN9

YGIN0

YGIN1

YGIN2

RST_X

VSS

VDDE

YGIN3

YGIN4

YGIN5

TD0

BOUT4

GBRVOUT

GBRHOUT

BOUT9

BOUT8

VDDE

VSS

GBRCLKO

BOUT7

BOUT6

BOUT3

BOUT2

BOUT1

BOUT0

VDDI

VSS

GOUT9

GOUT8

GOUT7

GOUT6

OVDD

GOUT5

GOUT4

GOUT3

GOUT2

GOUT1

VDDI

VSS

OSD2CLKO

GOUT0

ROUT9

ROUT8

ROUT7

ROUT6

ROUT5

OVDD

ROUT4

ROUT3

VDDI

VSS

ROUT2

ROUT1

ROUT0

OSD1VOUT

OSD1CLKO

OVDD

OSD2VOUT

OSD2HOUT

OSD1HOUT

CLP1OUT

OVSS

VDDE

VSS

OSD1HIN

YS2

YM2

OSD2RIN0

OSD2RIN1

OSD1BIN7

VDDE

VSS

OSD1CLK

OSD1BIN6

OSD1BIN5

OSD1BIN4

OSD1BIN3

OSD1BIN2

OSD1BIN1

OSD1BIN0

OSD1GIN7

OSD1GIN6

VDDE

VSS

OSD1GIN5

OSD1GIN4

OSD1GIN3

OSD1GIN2

OSD1GIN1

VDDI

OSD1GIN0

OSD1RIN7

OSD1RIN6

OSD1RIN5

VSS

OSD1RIN4

OSD1RIN3

OSD1RIN2

OSD1RIN1

OSD1RIN0

VDDI

YS1

YM1

SCL

SDA

SASEL

VDDI

VSS

HIN

VIN

YGIN9

YGIN8

YGIN7

YGIN6

OVDD

IN

BUS

OVSS

VDDE

VSS

VPD0

TCK

TRST

TMS

TDI

VDDE

OVSS

YGOUT6

VOUT

HOUT

CROUT0

CROUT1

CLKO

VSS

VDDE

CROUT2

CROUT3

CROUT4

CROUT5

CROUT6

CROUT7

CROUT8

CROUT9

CBOUT0

CBOUT1

VSS

VDDI

CBOUT2

CBOUT3

CBOUT4

CBOUT5

OVDD

VDDI

CBOUT6

CBOUT7

CBOUT8

CBOUT9

YGOUT0

VSS

YGOUT1

YGOUT2

YGOUT3

YGOUT4

VDDI

YGOUT5

YGOUT7

YGOUT8

YGOUT9

VSS

OVDD

VFIN

HFIN

CRFIN0

CRFIN1

CRFIN2

CRFIN3

CRFIN4

CRFIN5

VSS

VDDE

CLKF

CRFIN6

CRFIN7

CRFIN8

CRFIN9

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121122123124125126127128129130131132133134135136137138139140141142143144145146147148149150151152153154155156157158159160161162163164165166167168169170171172173174175176177178179180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

12345678910111213141516171819202122232425262728

29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56

123

4 5

1

2

3

4

5

6

7

8

9

10

11

12

13

14

12

3 4

12

3 4

12

3 4

CONT VDD

OUT

S

IC3802

IC3803

IC3806

C3806

C3807

C3820

C3850 C3857

L3801

L3802

L3803

L3804

L3805

L3806

L3807

L3808 L3809

FB3803

Q3801

Q3802

D3801

D3802

RB3801

RB3802

RB3803

RB3804

RB3805

JL3301

R3808

R3819

R3824

R3827

TP3301

TP3302

TP3303

TP3304

TP3305

TP3306

C3801

C3804

C3805

C3809

C3810

C3811

C3812

C3813

C3814

C3815

C3816

C3817

C3818 C3819

C3823

C3824

C3827

C3828

C3829

C3830

C3831

C3832

C3833

C3834

C3835

C3836

C3837

C3838

C3839

C3840

C3841

C3842 C3843

C3844

C3845

C3846

C3847

C3848

C3849

C3851

C3852

C3853

C3854

C3855

C3856

R3801

R3802

R3803

R3804

R3805

R3807

R3809 R3810

R3813

R3814

R3815

R3820

R3821

R3822

R3834

R3836

RB3813 RB3814 RB3815 RB3816 RB3817 RB3818 R3840 R3841 R3842

R3806

C3821

C3822

R3818

CN3801

X3801

IC3804

R3811

R3812

R3825

R3826

IC3801

IC3805

10

16V

:AL-CP

10

16V

:AL-CP

THC63LVDF84B

RECEIVER

100*4

:1005

100*4

:1005

100*4

:1005

100*4

:1005

100*4

:1005

TC7SA00FU

INVERTER

1µH

:CHIP

1µH

:CHIP

MIMA152WK

MIMA152WA

2SK2036

BK1608HS601

CXD9690Q

47

6.3V

:AL-CP

47 6.3V :AL-CP

47

6.3V

:AL-CP

10µH

:CHIP

10µH

:CHIP

10µH

:CHIP

10µH

:CHIP

10µH

:CHIP

10µH

:CHIP

10µH

:CHIP

0

:1005

0

:1005

0

:1005

0

:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.001

B:1005

0.1 10V B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.1

10V

B:1005

0.001

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1 10V B:1005

0.01

16V

B:1005

0.001

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.1

10V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

0.01

16V

B:1005

100

:1005

100 :1005

100

:1005

100

:1005

100

:1005

10k

:1608

10k

:1608

10k

:1608

47

:1005

100

:1005

100

:1005

10k

:1005

22

:1005

1k

:1005

47

:1005

47

:1005

47*4

:1005

47*4

:1005

47*4

:1005

47*4

:1005

47*4

:1005

47*4

:1005

47

:1005

47

:1005

47

:1005

0

:1005

0.1

10V

B:1005

0.1

10V

B:1005

10k

:1005

14P

FI-X14S

24MHz

PST3620UL

RESET

0

:1005

0

:1005

47 :1005

PST3627UR

RESET

CORBU-IN

OSD-M

SW_ 3.3V

SW_ 2.5V

O1VS

I2C-DEV

O1HS

DCP-RST

Y6

Y7

Y8

Y9

Y0

Y1

Y2

Y3

Y4

Y5

C1

C2

C3

C4

C5

C6

C7

C8

C9

SDA(3.3V)

SCL(3.3V)

C0

C4

C5

C6

C7

C8

C9

Y0

Y3

Y4

Y5

Y6

Y7

Y8

Y9

C0

C1

HS

Y1

Y2

VS

C2

C3

HS

VS

YM

YS

SDA(3.3V)

SCL(3.3V)

R5

R6

R7

G5

G6

G7

B5

B6

CLK

B7

SDA

SCL

R0

R1

R2

R3

R4

R5

R6

R7

B0

B1

B2

B3

B4

B5

B6

B7

G0

G1

G2

G3

G4

G5

G6

G7

DCK

HS

VS

KE-42XS910

20

KE-42XS910

DE2 BOARD SCHEMATIC DIAGRAM (3 OF 6)

1

A

B

C

D

E

F

G

H

I

K

J

212

11

10

98765

43

+3.3V

TO(1/6)

RESET

B-SS11646<UC.>-DE2-P3

(MCU)

TO(6/6)

VPR2TO(1/6)

TO(6/6)

TO(1/6)

TO(6/6)

TO(4/6)

TO(1/6)

TO(6/6)

TO(1/6)

TO(6/6)

EEPROM

TO(1/6)

SW_2

SW_4

SW_1

VCCI

DE2(3/6)

FLASH

FAN_ERR

VOUT

VIN

N.B

GND

CONT

VCC

PLLBP

D0

D8

D1

D9

D2

D10

D3

D11

D4

D12

D5

D13

D6

D14

D7

D15/A-1

A16

A0A1

A2

A3

A4

A5

A6

A7

A17

A18

A19

A8

A9

A10

A11

A12

A13

A14

A15

A00

FEAT1

FEAT2

FEAT0

WE

VSS

CE

OE

VCC

VSS

BYTE

NC

RES

BYRY/

NC

BUS_SW

INTVSO

INTVS1

INTVS2

AVSS/AVRL

AVRH

A23

A22

A21

A20

A19

A18

A16

A15

A14

A13

A12

A11

A10

A9

A8

A7

A6

A5

A4

A3

A2

A1

A0

A17

VSS

VCC

VSS

D15

D14

D13

D12

D11

D10

D9

D8

D7

D6

D5

D4

D3

D2

D1

D0

WE

AS

MCLK

SW_3

SYSCLK

RESET

VSS

NMI

WR1

WR0

RD

CLS

FLASH_RST

FEAT3

CS2

CS1

CS0

XO

XI

MOD1

MOD2

MOD0

NVM_WP

BY

RY/

SDA1

SCL1

VSS

P_ALARM

SO2

SI2

SO1

SI1

SO0

SI0

VCC

SDA2_I

SCL2_I

SDA2_O

SCL2_O

WP

SCL

SDA

VCC

NC

GND

TEST

THERMO HIC

THERMO PANEL

CABLE DET

I2C EN

WAKE UP

3.3V DET

THERMO G

FHP PDPGO

FHP CPUGO

400kHzz 100kHzz

VSS

AVCC

ALARM

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

616263646566676869707172737475767778798081828384858687888990

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

123456789101112131415161718192021222324

25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48

12

3 4

1 2 3 4

5678

123

4 5

D3401

D3402

RB3401 RB3402

FB3402

FB3404

RB3409

RB3410

RB3411

RB3412

RB3413

RB3414

RB3415

RB3416

IC3451

S3402

IC4001

R4019

C3401

C3402

C3407

C3408

C3409

C3410

C3415

C3451

C3452

C3453

C4001

R3408

R3409

R3410

R3423

R3442

R3462

R3463

R3403

R3404

R3405

R3406

R3411

R3412

R3413

R3414

R3415

R3416

R3419

R3422 R3425 R3427

R3428

R3429

R3440

R3445

R3446

R3447

R3448

R3455

R3456

R3457

R3458

R3459

R3464

R3465

R3466

R3467

R3468

R3469

R3470

R4002

R4003

R4004

R4005

R4015 R4016

R4021

R4023

R4025

R4026

R4022

R3441

R4028

R4029

R4030

R4031

R4032

R4033

R4035

R4203

R3437

R3460

R3461

R3473

R3471

D4005

X3401

IC3401

FB4001

C3404

R4011 R4012 R4034

R4036 R4037

IC3402

R4039

IC3403

UDZS3.9B

1SS383

10k*4 10k*4

BLM11A601S

0*4

NJM2870F18

0.15A

1.8V REG

M24C64-W

0

:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.01

16V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.1

10V

B:1005

0.047

10V

B:1005

0.1

10V

B:1005

4.7

6.3V

B:2012

0.1

10V

B:1005

10k :RN-1005

0

:1005

0 :1005

10k :1005

100 :1005

10k

:1005

100 :1005

47k :1005

10k

:1005

10k

:1005

10k

:1005

2.2k

:1005

10k

:1005

10k

:1005

2.2k

:1005

4.7k

:1005

2.2k

:1005

4.7k

:1005

10k

:1005

10k

:1005

10k :1005

47 :1005

100

:1005

100

:1005

10k

:1005

10k

:1005

10k

:1005 100 :1005

100 :1005

100

:1005

100

:1005

100

:1005

100

:1005

10k

:1005

10k

:1005

10k

:1005

10k :1608

100

:1005

10k :1005

10k

:1005

10k

:1005

10k

:1005

10k

:1005

10k :1005

1k

:1005

10k

:1005

10k

:1005

10k

:1005

10k

:1005

10k

:1005

MA111

16.5MHz

MB91306RPFV-G-

BND-E1

MCU

BLM11A601S

0.47 10V

B:1608

0

:1005 0

:1005

0

:1005

0

:1005

0

:1005

PST3627UL

0

:1005

MBM29LV800

TA-70PFTN

FLASH ROM

INTVS1

INTVS2

CPU-CORBU

INTVSO

CL_X

PLLBP

SW_ 3.3V

PANEL_CONT

CORBU-UART

SW_ 3.3V

THERMO_G

THERMO_PANEL

THERMO_HIC

FIELD_DET

CORBU-RST

SW_ 1.8V

SW_ 3.3V

SO1

SI1

SW_1

DCP-RST

A2

A3

A4

A5

A6

A7

A8

A9

A10

A11

A12

A13

A14

A15

A16

A18

A19

A20

D6

D7

D8

D9

D10

D11

D12

D13

D14

D15

A1

A2

A3

A4

A5

A6

A7

A8

A9

A10

A11

A12

A13

A14

A15

A16

A17

A18

A19

A20

D15

D7

D14

D6

D13

D5

D12

D4

D11

D3

D10

D2

D9

D1

D8

D0

A1

A17

RD

WR0

CS0

CS1

CS0

RD

WR0

WR1

CLK

AS

D0

D1

D2

D3

D4

D5

SCL

SDA

IRQ

PDPGO

CPUGO

CPUD0

CPUD1

CPUD2

CPUD3

CPUD4

CPUD5

CPUD6

CPUD7

CPUD8

CPUD9

CPUD10

CPUD11

CPUD12

CPUD13

CPUD14

CPUD15

CPUA1

CPUA2

CPUA3

CPUA4

CPUA5

CPUA6

CPUA7

CPUA8

CPUA9

CPUA10

CPUA11

CPUA12

CPUAS_X

CPURD_X

CPUWR0_X

CPUCS_X

CPUCLK

CPUWR1_X

A1

A2

A3

A4

A5

A6

A7

A8

A9

A10

A11

A12

CLK

AS

RD

CS1

WR0

WR1

D0

D1

D2

D3

D4

D5

D6

D7

D8

D9

D10

D11

D12

D13

D14

D15

SI0

SO0

1

A

B

C

D

E

F

G

H

I

J

212 13

11

10

98765

43 14

+1.5V

+3V

GY10

GY11

GY12

GY13

GY14

GY15

GY16

GY17

BU10

BU11

BU12

BU13

BU14

BU15

BU16

BU17

RV10

RV11

RV12

RV13

RV14

RV15

RV16

RV17

CLKI1

B-SS11646<UC.>-DE2-P4

TO(1/6)

(CPU 1.5V REG.)

TO(2/6)

CPU CPUCPUCPU

DE2(4/6)

HSADIN1

HSADOUT1

1.5V

GND

REF

FBSEL

VCC

PGND

LX

PGND

LX

FB

TOFF

COMP

SS

IN

LX

IN

SHDN

CORBU IN11 CORBU IN22 CORBU POWERR

VSS

VDDS_SEP

VDDS

VDD2

VDD

VSS2

VDDC_SEP

VDDC

NC

VDDC

DE1

VSS

VSS2

VSS

INTVS1

COAST1

IFLD1

SOG1

HSCS1

VS1

CLKI1

RV17

RV16

RV15

RV13

RV14

RV12

RV11

RV10

BU17

BU16

BU15

BU14

BU13

BU12

BU11

BU10

GY17

GY16

GY15

GY14

GY13

GY12

GY11

GY10

GYA20

GYA21

GYA22

GYA23

GYA24

GYA25

GYA26

GYA27

BUA20

BUA21

BUA22

BUA23

BUA24

BUA26

BUA25

BUA27

RVA20

RVA21

RVA22

RVA23

RVA24

RVA25

RVA26

RVA27

GYB20

GYB21

GYB22

GYB23

GYB24

GYB25

GYB26

GYB27

BUB20

BUB21

BUB22

BUB23

BUB24

BUB25

BUB26

BUB27

RVB20

RVB21

RVB22

RVB23

RVB24

RVB25

RVB26

RVB27

CLKI2

VS2

HSCS2

SOG2

IFLD2

HSADIN2

HSADOUT2

DE2

COAST2

ECO2

WUENB2

INTVS2

12345678

910 11 12 13 14 15 16

L3501

FB3501

FB3502

FB3503

FB3504

IC3502

RB3503

JL3501

IC3501(1/8) IC3501(2/8) IC3501(3/8) IC3501(4/8)

C3501

C3502

C3503

C3504

C3505

C3506

C3507

C3508

C3509

C3510

C3511

C3512

C3513

C3514

C3515

C3516

C3517

C3518

C3519

C3520

C3521

C3522

C3523

C3524

C3525

C3526

C3527

C3528

C3529

C3530

C3531

C3532

C3533

C3534

C3535

C3536

C3537

C3538

C3539

C3540

C3541

C3542

C3543

C3544

C3545

C3546

C3547

C3548

C3549

C3550

C3551

C3552

C3553

C3554

C3555

C3556

C3557

C3558

C3559

C3560

C3561

C3562

C3563

C3564

C3565

C3566

C3567

C3568

C3569

C3570

C3571

C3572

C3573

C3574

C3575

C3576

C3577

C3578

C3579

C3580

C3581

C3582

C3583

C3584

C3585

C3586

C3587

C3588 C3589

R3512

R3506

R3507

R3505

R3509

R3510

R4101

R3513

R3514

R3511

C3590

R4008

4.7µH

1.6A

:CHIP

BLM11P300S

MAX1644EAE

2.0A

1.5V REG

10k*4

CXD9762GF CXD9762GF CXD9762GF CXD9762GF

4.7 6.3V B:2012

0.01 16V B:1005

4.7 6.3V B:2012

0.01 16V B:1005

2.2

6.3V

B:2012

10

6.3V

B:3216

0.1

10V

B:1005

470p

B:1005

1

6.3V

B:1608

47k

:RN-1005

0

:1005

0

:1005

22

:1005

10

:1005

220k

:1005

0

:1005

0.1

:4532

0.1

:4532

24k

:1005

220

2.5V

:AL-CP

0

:1005

VS1

HSCS1

GY10

GY11

GY12

GY13

GY14

GY15

GY16

GY17

BU10

BU11

BU12

BU13

BU14

BU15

BU16

BU17

RV10

RV11

RV12

RV13

RV14

RV15

RV16

RV17

CLKI1

VS1

HSCS1

TO(3/6)NTVS2

DE1

TO(3/6)INTVS1

CORBU-IN

SW_3.3VSW_ 2.5V

289

278

277

266

265

254

253

242

241

229

232

231

230

217

218

219

220

205

206

207

208

193

194

195

197

181

182

184

53

170

157

171

169

183

243

83

122

124

269

66

84

87

88

93

97

117

118

121

142

149

151

164

334

335

337

345

355

362

365

370

292

301

302

351

352

293

315

377

313

280

291

268

378

327

316

403

353

328

404

429

379

354

455

430

405

380

456

431

457

356

381

406

432

382

407

458

383

408

433

459

384

409

434

460

435

385

410

461

436

462

411

386

437

463

412

438

464

387

413

439

158

304

256

55

65

101

114

123

176

189

212

222

225

261

303

297

317

319

329

339

343

344

357

359

361

363

372

394

112

258

94

135

282

62

257

145

255

82

111

113

143

146

152

175

177

198

210

211

213

221

233

249

267

285

294

305

318

331

332

333

98

150

91

92

95

116

120

140

148

139

85

110

69

61

138

90

96

119

144

86

246

126

163

185

188

196

200

209

224

234

236

248

260

271

283

295

306

307

330

336

358

360

364

366

367

368

369

389

270

187

199

223

235

247

259

272

284

296

308

320

1

2

3

4

7

8

5

6

G0

G1

G2

G3

G4

G5

G6

G7

B0

B1

B2

B3

B4

B5

B6

B7

R0

R1

R2

R3

R4

R5

R6

R7

VS

HS

DCK

DE

DE2 BOARD SCHEMATIC DIAGRAM (4 OF 6)

Sony KE-42XS920 User manual

Popular Flat Panel TV manuals by other brands
