Sony PSP-1006 K User manual

PSP-1006 K
PSP-1007 K
2-549-103-62(1)
GB
CT

2WARNINGS
Photosensitivity
A very small percentage of individuals may experience epileptic seizures when
exposed to certain light patterns or flashing lights. Exposure to certain patterns
or backgrounds on a television screen or while playing video games, including
games played on the PSP™ system, may trigger an epileptic seizure in these
individuals. Certain conditions may trigger previously undetected epileptic
symptoms even in persons who have no history of prior seizures or epilepsy. If
you, or anyone in your family, has an epileptic condition, consult your
physician prior to playing. If you experience any of the following symptoms
while playing a video game - dizziness, altered vision, eye or muscle twitches,
loss of awareness, disorientation, any involuntary movement or convulsions -
IMMEDIATELY discontinue use and consult your physician before resuming
play.
Radio waves
Radio waves may affect electronic equipment or medical devices (for example,
pacemakers), which may cause malfunctions and possible injuries.
• If you use a pacemaker or other medical device, consult your physician or the
manufacturer of your medical device before using the wireless networking
feature.
• Keep the PSP™ system at least 23 cm (9 inches) away from a pacemaker or
other medical devices when using the wireless networking feature.
• Do not use the wireless networking feature in the following locations:
– Areas where its use is prohibited, such as in airplanes or hospitals. Abide by
medical institution regulations when using the PSP™ system on their
premises. Additionally, you may be violating air safety regulations
punishable by fines by using the wireless networking feature in an airplane
or by using the PSP™ system during takeoff or landing.
– Crowded areas.
– Areas near fire alarms, automatic doors and other types of automated
equipment.
• Use caution when using the wireless networking feature in a vehicle, as radio
waves may affect electronic equipment in some vehicles.
WARNINGS

3
GB
WARNINGS

4
GAME page 39
• Playing games
• Managing saved data
VIDEO page 43
• Playing UMD™Video
• Playing videos (MPEG-4) saved on a Memory
Stick Duo™
MUSIC page 55
• Playing UMD™Audio
• Playing music (ATRAC3plus™ or MP3) saved on
a Memory Stick Duo™
PHOTO page 68
• Displaying images (JPEG) saved on a Memory
Stick Duo™
• Playing slideshows
SETTINGS page 80
• Adjusting PSP™ system settings
• Creating video, photo or network settings
• Connecting to devices using the USB connector
TM

5
GB
Basic button operations
Select a category
Select an item
Using the home menu
The basic operation of the PSP™ system starts from the home menu. Press the
home button to display the home menu and use the directional buttons to
navigate the horizontal and vertical icon bars.
POWER
HOLD
SELECT
HOME VOL START
Directional buttons:
Home button:
button:
Used to select on-screen items
Displays the options
menu for selected items
button: Confirms selected items
button: Cancels selected
operations
Displays the home menu

6Table of contents
WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Battery pack precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 15
xPreparation
Checking the package contents . . . . . . . . . . . . . . . . . . . . . 16
Part names and functions . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Preparing the PSP™ system for use . . . . . . . . . . . . . . . . . 23
Connecting the headphones with remote control . . . . . . . . 26
xBasic operations
Turning the PSP™ system on and off . . . . . . . . . . . . . . . . 27
Putting into sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Inserting a UMD™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Inserting a Memory Stick Duo™ . . . . . . . . . . . . . . . . . . . . . 31
Avoiding unintended operation of the PSP™ system . . . . . 32
Using the sound button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Using the display button . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
xGame
Playing a game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Game options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Copying and deleting saved data . . . . . . . . . . . . . . . . . . . . 42
xVideo
Watching a video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Operating with PSP™ system buttons
or the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Video options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Saving videos on a Memory Stick Duo™ . . . . . . . . . . . . . . 53
Table of contents

7
GB
Table of contents
xMusic
Listening to music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Operating with PSP™ system buttons
or the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Music options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Transferring and saving music
on a Memory Stick Duo™ . . . . . . . . . . . . . . . . . . . . . . 65
xPhoto
Viewing images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Operating with PSP™ system buttons
or the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Photo options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Playing slideshows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Saving images on a Memory Stick Duo™ . . . . . . . . . . . . . 78
xSettings
Settings for the PSP™ system . . . . . . . . . . . . . . . . . . . . . . 80
Video Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Photo Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Date & Time Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Power Save Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Security Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
USB Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Network Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
How to use the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . 105

8Table of contents
xAdditional information
Compatible media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

9
GB
Precautions
Before using this product, carefully read this manual and retain it for future
reference.
Safety
This product has been designed with the highest concern for safety. However,
any electrical device, if used improperly, has the potential for causing fire,
electrical shock or personal injury. To help ensure accident-free operation,
follow these guidelines:
• Observe all warnings, precautions and instructions.
• Regularly inspect the AC adaptor and AC power cord for damage and for dust
build-up around the mains power plug or electrical outlet.
• Stop use, unplug the AC power cord from the electrical outlet and disconnect
any other cables immediately if the device functions in an abnormal manner,
produces unusual sounds or smells or becomes too hot to touch.
• Call the PSP™ service line at the number listed on your warranty card if the
device does not operate properly.
Use and handling
• Use in a well-lit area and keep the screen a safe distance from your face.
• Avoid prolonged use of the PSP™ system. To help prevent eyestrain, take a
break of about 15 minutes during every hour of play.
• If you experience any of the following health problems, discontinue use of the
system immediately. If symptoms persist, consult with your physician.
– Dizziness, nausea, fatigue or symptoms similar to motion sickness
– Discomfort or pain in a part of the body, such as eyes, ears, hands or arms
• Keep the system and accessories out of the reach of small children.
Small children may swallow the Memory Stick Duo™ or wrap the cables
around themselves, which may inflict injury or cause an accident or a
malfunction.
• Do not use the system while driving or riding a bicycle. Looking at the screen
or operating the system while driving an automobile or riding a bicycle may
result in a traffic accident.
• Take extra care when using the system while walking.
• Be careful not to pinch your fingers when closing the disc cover.
Precautions

10 Precautions
• Do not use the system or accessories near water.
• Use only attachments/accessories specified by the manufacturer.
• Do not use the headphones if they cause discomfort to your skin.
If the supplied headphones cause discomfort to your skin, discontinue use
immediately. If symptoms do not subside even after discontinuing use, seek
medical attention.
• Do not expose the system or accessories to high temperatures, high humidity,
or direct sunlight.
• Do not leave the system or accessories in a car with the windows closed
(particularly in summer).
• Do not expose the system or accessories to dust, smoke or steam.
• Do not allow liquid or small particles to get into the system or accessories.
• Do not place the system or accessories on surfaces that are tilted, unstable or
subject to vibration.
• Do not throw or drop the system or accessories, or subject the devices to
strong physical shock. Handle the analog stick with care.
• Do not forcibly twist the PSP™ system or expose the system to strong
physical shock during gameplay, as doing so can damage the system or cause
the disc cover to open, ejecting the disc.
• Do not put heavy objects on the system or accessories.
• Do not touch or insert foreign objects into the connectors of the system or
accessories.
• Do not place the system close to items with a magnetic strip, such as credit
cards.
• Do not touch the system or AC adaptor for an extended period of time while
in use. Depending on the conditions of use, the system or AC adaptor may
reach temperatures of 40° C/104° F or more. Extended contact under these
conditions may cause low-temperature burns*.
* Low-temperature burns are burns that occur when the skin is in contact with objects of
relatively low temperatures (40° C or more/104° F or more) for an extended period of
time.
AC adaptor and AC power cord use
• Do not touch the mains power plug of the AC power cord with wet hands.
• Do not touch the AC power cord, AC adaptor or the system, if connected to
an electrical outlet, during an electrical storm.
• Do not use a power source other than the supplied battery pack, AC adaptor
and AC power cord.

11
GB
Precautions
• Do not allow dust or foreign matter to build up around the system or accessory
connectors. If there is dust or foreign matter on the system's connectors or the
AC power cord, wipe it off with a dry cloth before connecting. Dust or other
matter on the connectors can result in fire or electrical shock.
• Unplug the AC power cord from the electrical outlet and remove the battery
pack from the system before cleaning or when you do not intend to use the
system for an extended period of time.
• Protect the AC power cord from being walked on or pinched particularly at
plugs, convenience receptacles and the point where they exit from the system.
• When disconnecting the AC power cord, hold it by the plug and pull straight
out from the electrical socket. Never pull by the cord and do not pull at an
angle.
• Do not use the system to play games or video when the system is covered with
any type of fabric. If you want to pause or temporarily store the system while
playing games or video, put the system in sleep mode before placing it in the
pouch. Also do not use the AC adaptor when covered with fabric. This may
help to avoid overheating.
• Do not connect the AC power cord to a voltage transformer or inverter.
Connecting the AC power cord to a voltage transformer for overseas travel or
an inverter for use in an automobile may cause heat to build up in the AC
adaptor and may cause burns or a malfunction.
LCD screen
• Red, blue or green spots (bright spots) or black spots (dark spots) may appear
in certain locations on the LCD screen. The appearance of such spots is a
normal occurrence associated with LCD screens and is not a sign of a
malfunction. LCD screens are made using highly precise technology.
However, a very small number of dark pixels or continuously lit pixels exist
on each screen. Also, a distorted image may remain on the screen for several
seconds after the system has been turned off.
• Direct exposure to sunlight may damage the system's LCD screen. Be careful
when using the system outdoors or near a window.
• When using the system in a cold environment, you may notice shadows on
the graphics or the screen may appear darker than usual. This is not a
malfunction, and the screen will return to normal when the temperature goes
up.
• Do not leave still images displayed on the screen for an extended period of
time. This may cause a faint image to be left permanently on the screen.

12 Precautions
Memory Stick Duo™
For best results, follow these guidelines:
• Do not touch the connector area (A) with your hands or with metal objects.
• Do not press hard when writing on the memo area (B).
• Do not insert a Memory Stick Duo™ into a device designed to accept only
standard-size Memory Stick™ media.
• Do not use or store a Memory Stick Duo™ in the following:
– Places subject to high temperatures, such as in a hot vehicle
– Locations exposed to direct sunlight
– Locations that are very humid or conducive to corrosion
• Use the supplied case to carry or store the Memory Stick Duo™.
xRecorded data
Do not use the Memory Stick Duo™ in the following ways, as doing so may
result in data loss or corruption:
• Removing the Memory Stick Duo™ or turning off the system while it is
loading or saving data or being formatted.
• Using it in a location that is exposed to static electricity or electrical
interference.
If, for any reason, software or data loss or corruption occurs, it is usually
not possible to recover the software or data. It is recommended that you
regularly back up software and data. Sony Computer Entertainment Inc.
and its subsidiaries and affiliates will not be held liable for any damages or
injury in the case of software or data loss or corruption.
In accordance with copyright law, no recorded data may be used for
purposes other than personal enjoyment without permission from the
copyright holder.

13
GB
Precautions
Pouch and hand strap
• If you want to pause or temporarily store the system while playing games or
video, put the system in sleep mode before placing it in the pouch. This may
help to avoid overheating.
• Put both the PSP™ system and the remote control in hold mode to help
prevent unintended operation.
• Keep the pouch and hand strap out of the reach of small children.
Never disassemble the system or supplied accessories
Use the PSP™ system and accessories according to the instructions in this
manual. No authorization for the analysis or modification of the system, or the
analysis and use of its circuit configurations, is provided. Disassembling will
void the system warranty. Additionally, there is a risk of fire, electrical shock
or malfunction. The LCD screen, in particular, contains dangerous, high-
voltage parts, and the laser beam for reading UMD™ may cause visual
impairment if exposed directly to the eyes.
Overseas use
Depending on the country, there are limitations on the use of certain types of radio
waves. In some cases, use of the system may lead to a fine or other penalty.
Moisture condensation
If the PSP™ system or UMD™ is brought directly from a cold location to a
warm one, moisture may condense on the lens inside the system or on the
UMD™. Should this occur, the system may not operate properly. In this case,
remove the UMD™ and turn off and unplug the system. Do not put the UMD™
back in until the moisture evaporates (this may take several hours). If the
system still does not operate properly, contact the PSP™ service line at the
number listed on your warranty card for assistance.
UMD™ handling
• Do not touch the opening on the rear of the disc (recorded surface of the disc)
with your fingers.
• Do not allow dust, sand, foreign objects or other types of dirt to get on the
disc.
• If the UMD™ becomes dirty, gently wipe the exterior and recorded surfaces
of the UMD™ using a soft cloth. Do not use solvents or other chemicals.

14 Precautions
Cleaning
For safety reasons, unplug the AC power cord from the electrical outlet and
remove the battery pack from the system before cleaning.
xCleaning the exterior surface
Wipe gently with a damp cloth, and then dry the surface. Do not use solvents or
other chemicals to clean the exterior of the PSP™ system.
xCleaning the LCD screen
Wipe gently with a soft cloth.
xCleaning the connectors
• Do not use when the connectors of the system, AC adaptor or the AC power
cord are not clean. Remove the dirt with a dry cloth or cotton swab. If used
when dirty, the flow of electrical current may be obstructed.
• If the headphones or remote control connectors become dirty, this could cause
noise or interruptions in sound. Wipe the connectors with a dry, soft cloth to
keep in clean condition.

15
GB
Precautions
Battery pack precautions
Do not handle a damaged or leaking battery pack.
Contact with the material can result in injury or burns to the eyes or skin. Even
if foreign substances are not immediately visible, chemical changes in the
material can result in injuries occurring at a later time.
Handle the battery pack with care.
The battery pack may explode or present a fire or chemical burn hazard if it is
not handled carefully.
• Do not allow the battery pack to come into contact with fire or subject it to
extreme temperatures such as in direct sunlight, in a vehicle exposed to the
sun or near a heat source.
• Do not cause the battery pack to short-circuit.
• Do not disassemble or tamper with the battery pack.
• Prevent damage to the battery pack. Do not carry or store the battery pack
with metal items such as coins or keys. If damaged, discontinue use.
• Do not throw or drop the battery pack or subject it to strong physical shock.
• Do not put heavy objects on or apply pressure to the battery pack.
• Do not allow the battery pack to come into contact with liquids. If it becomes
wet, discontinue use until it is completely dry.
• Keep the battery pack out of the reach of small children.
• If the PSP™ system will not be used for an extended period of time, remove
the battery pack and store it in a cool, dry place out of the reach of children.
• Use only the supplied battery pack or a replacement marked for use with the
PSP™ system.
• Use only the designated AC adaptor to charge the battery pack.
Warnings
If you come into contact with material from a leaking battery pack, take the
following actions:
• If the material gets into the eyes, do not rub. Immediately flush the eyes
with clean water and seek medical attention.
• If the material comes into contact with the skin or clothes, immediately
rinse the affected area with clean water. Consult your physician if
inflammation or soreness develops.

16 Checking the package contents
Check that you have all of the following items. If any items are missing, contact
the PSP™ service line at the number listed on your warranty card for assistance.
Preparation
Checking the package contents
sMemory Stick Duo™ (32 MB)
sHand strap
sPouch
sCloth
sPrinted materials
POWER
HOLD
SELECT
HOME
VOL
START
5V
sBattery pack
sPSP™ system
sAC adaptor
sHeadphones with remote control
sAC power cord (with 3-pin
converting adaptor attached)
(supplied with PSP-1006 K)
sAC power cord (supplied with
PSP-1007 K)

17
Preparation
GB
Checking the package contents
Removing the 3-pin converting adaptor (PSP-1006 K only)
Electrical outlet configuration may vary depending on the region of use. If the
plug on the supplied AC power cord does not match the electrical outlet, loosen
the screw and remove the converting adaptor.
Mains power plug
3-pin converting adaptor

18 Part names and functions
System front
Part names and functions
AL button
BDirectional buttons
CMemory Stick Duo™ access
indicator
Lights up when saving and loading
data
DWLAN access indicator
Lights up when using the wireless
networking feature
EAnalog stick
Can be used with games that
support analog operation
FStrap holder
Attach as shown in the diagram.
GLeft speaker
HHome button
Displays the home menu
IVolume - button
Turns the volume down
JVolume + button
Turns the volume up
POWER
HOLD
SELECT
HOME VOL START
HOME VOL

19
Preparation
GB
Part names and functions
System rear
KLCD screen
LDisplay button
Adjusts screen brightness
( page 35)
MSound button
Adjusts the tone ( page 33)
NSelect button
OStart button
PR button
Qbutton
Rbutton
Sbutton
Tbutton
UPower indicator
Lights up, flashes or changes color
to indicate system status
(page27)
VHold indicator
Turns yellow when in hold mode
(page32)
WRight speaker
ABattery cover CDisc cover
BPush button
PUSH
UMD

20 Part names and functions
System top
System bottom
AIR port COpen latch
BUSB connector
AHeadset connector CDC IN 5V connector
BCharging terminals
LR
OPEN
DC IN
5V
