KDS- 55A3000
55" Class (54.5") BRAVIA® SXRD® A Series Microdisplay TV
Key Features
Full HD 1080p Picture Resolution
6
SXRD ™Panels(R/G/B), > 2M Pixels Each
6
BRAVIA Engine ™ EX
MotionFlow technology (120hz/black insertion)
1080p Input, HDMI™x3 (1080/60p, 24p,CEC,
xvYCC)
DMeX compatible -BRAVIA® Internet Video Link
Ready
BRAVIA® Theatre Sync ™
XMB™Xross Media Bar™ interface
3 SXRD Full HD Resolution (1920 x 1080/0.61 ”
SXRD chip)
6
BRAVIA Engine ™ EX
Key Technologies
SXRD ® Chips SXRD technology is the latest display technology developed by the legendary television engineers at Sony to meet
and exceed the demands of a High Definition image at its full 1080 line resolution.
6
Advanced Iris Function The Advanced Iris function is a special Sony function designed to improve contrast expression especially in
darker scenes. The Advanced Iris function is enabled by using either one of two modes -Auto and Manual. The Auto Mode has two
settings designed to work best with video content such as movies that vary between bright scenes and dark scenes. Auto 1 is for
programs that have a wide range of brightness from scene to scene. Auto 2 is for programs that have less variation between brightness
levels from scene to scene.
The Manual mode is used to help deliver optimum contrast levels under different room lighting conditions. The High mode offers
maximum screen brightness and works well when a room is brightly lit. The Medium mode is for average levels of light. And the Low
mode offers the maximum amount of contrast and works best under low light conditions. The key benefits are deep blacks and
improved brightness and overall contrast.
BRAVIA Engine™EX Video Processor The BRAVIA Engine EX full digital video processing system is based on Sony’ s
renowned BRAVIA Engine video processing system. It has all of the same functions of BRAVIA Engine plus the added ability to
upconvert 480i standard defi nition signals via Digital Reality Creation Multi Function v1.0 technology for a picture with more detail
and defi nition.
HDMI™and PC Inputs Designed for maximum versatility, Sony's SXRD A Series line is equipped with a comprehensive range of
input interfaces. The HDMI (High -Definition Multimedia Interface™ ) is the first industry -supported, uncompressed, all-digital audio/video
interface. HDMI technology supports enhanced or High Definition video, together with multi-channel digital audio to provide superb
image and sound reproduction. A D-Sub 15 input also allows connection to your PC , allowing you to use your high resolution
BRAVIA TV as a computer monitor.
5
Motionflow ™120Hz High Frame Rate Technology Takingmotion performance to the next level requires innovation and
expertise. Enter Sony's Motionflow™High Frame Rate technology. Motionflow™detects the incoming video signal and applies the
appropriate processing for optimum motion reproduction. Taking full advantage of film sourced 24fps encoded content available on
DVD and Blu-ray Disc, Motionflow™eliminates the need for 3:2 pulldown and delivers smooth, judder free video, faithfully preserving
the integrity of the original film. When 60fps content is detected, Motionflow™doubles the amount of frames and uses real-time
calculation to create a new level of natural motion reproduction. You'll experience movies and sports with a greater sense of realism
than ever before.
x.v.Color ™ technology BRAVIA HDTV's performance has now advanced to the point that the color range can be defined by
limitations in the original video source, rather than the TV. Thanks to the adoption of a newly approved international color standard
called xvYCC (an option in the HDMI v1.3 spec and which Sony participated in creating), the color space has been greatly expanded.
1.8 times as many natural colors as existing HDTV signals will now be faithfully reproduced. x.v.Color™ is the name Sony has chosen
to promote video products that include xvYCC capability. x.v.Color enabled products, such as select Sony Handycam® camcorders,
cannow offer more accurate color reproduction and natural colors.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 11/18/2008
KDS- 55A3000
55" Class (54.5") BRAVIA® SXRD® A Series Microdisplay TV
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Closed Captions (CC): Yes
On - ScreenDisplay: XMB ®
DMeX ™support: Yes
Video
VideoProcessing: Yes (BRAVIA Engine™
EX)
ColorTemperature: Cool, Neutral, Warm
NoiseReduction: Yes
BlackCorrector: High, Medium, Low, Off
ClearWhite: On, Off
GammaCompensation: High, Medium,
Low, Off
CineMotion ® Reverse 3:2 Pulldown
Technology: Yes
AdvancedIris: Yes
DRC ® Mode: Mode 1, Mode 2, CineMotion ®
Technology
DRC ® PalettePresets: Custom 1, Custom
2, Custom 3
DirectMode: On, Off
GameMode: On/Off
Auto Adjustment (PC): Yes
Advanced Video Menu: Yes
DetailEnhancer: High, Medium, Low, Off
ColorSystem: ATSC, NTSC
DisplayTechnology: SXRD™Technology
DeepColor: Yes
3D Comb Filter: Yes
Live Color Creation™ Technology: Yes
x.v.Color ™ Technology: Yes
PictureMode: Vivid, Standard, Cinema,
Photo, Custom
Motionflow ™ Technology: Motionflow™
120Hz
DRC ® Version: Yes (DRC MF V1.0)
Audio
ToneControl(s): Treble, Bass
MTS Stereo Decoder: Yes
SpeakerOn/Off: Yes
VoiceZoom: Yes
AutoSAP: Yes
Auto Mute (on no signal): Yes
Steady Sound ® AutomaticVolume
Control: Yes
Sony Original Surround: S - Force ® Front
Dolby ® : Dolby ® Digital (AC3/ATSC only)
AudioMode: Dynamic, Standard, Custom
SoundBooster: Yes
Convenience
ChannelJump: Yes
FavoriteChannel: Yes
Program Guide Access: Yes
Auto Channel Programming: Yes
InfoBanner: Yes
ProgrammableTimer: Yes
SleepTimer: 15, 30, 45, 60, 90, Off
CaptionVision: On, Off, Program
Clock: Yes
Power Save Mode: Standard, Reduced,
Picture Off
Channel Surf: Yes
RemoteControl: Yes
LabelInputs: Yes
ID - 1Detection: Yes
On/OffTimer: Yes
BRAVIA ® Theatre Sync™ : Yes (One - Button
Home Theater Control (HDMI - CEC))
Show/HideChannels: Yes
ParentalControl: Yes
Freeze: Yes
ChannelLabels: Yes
Specifications
General
TelevisionType: Micro Display HDTV
Video
Display Response Time: 2.5ms (rise and
fall)
VerticalSize: Yes
VerticalCenter: Yes
HorizontalCenter: Yes
Audio
Audio Power Output: 24W (12W x2)
Inputs and Outputs
Audio Out (Variable/Fixed): 1 (Side)
Component Video (Y/Pb/Pr ) Input(s): 2
(Side)
Composite Video Input(s): 3 (Side)
Digital Audio Output(s): 1 (Side) Dolby ®
Digital Optical Output
RF Connection Input(s): 1 (Side)
S- VideoInput(s): 1 (Side)
PC Audio Input(s): 1 (side)
PC Video Input(s): 1 (Side)
1080/24p Input Capable: Yes (via HDMI™)
Analog Audio Input(s) (Total): 5 (Side)
HDMI™Connection(s)(Total): 2 (Rear)
HDMI™Connection(s) (w/ Analog Audio
In): 1 with L/R RCA audio connections
Power
Power Consumption (in Operation): 240W
Power Consumption (in Standby): 0.1W
PowerRequirements: AC 120V, 60Hz
PowerManagement: Yes
Regulation and Standard
Compliance
Energy Star ® Compliant: Yes
Service and Warranty Information
Limited Warranty Term: 1 Year Parts / 1
Year Labor
Dimensions
Weight: 81lb 10oz (37kg)
Supplied Accessories
Remote Control (RM - YD016)
Operating Instructions
Quick Start Guide
Batteries (AA x2)
Warranty
Product Registration Card
Linux License
Optional Accessories
SU - RS12X floor stand
DMX - NV1 BRAVIA ® Internet Video Link
XL - 5200 Replacement Lamp
5
5
4
SG - 55A1/S UCM Gun Metal Silver Speaker
Grill
SG - 55A1/R UCM Claret Red Speaker Grill
SG - 55A1/B UCM Satin Black Speaker Grill
SG - 55A1/T UCM Cocoa Brown Speaker Grill
Color: Black
UPC Code: 027242712652
1.WithAdvancedIrisON
2.Dependingon usage, the lamp will require periodic replacement to
maintainoptimumpicturequality.Itisrecommendedthatthelamp
be exchanged after 8,000 hours of use.
3.Screen Size measured diagonally
4.Foradditionalwarrantytermsandinformationpleaserefertothe
LimitedWarrantyCardincludedwiththisproduct or visit
http://esupport.sony.com
5.Limitedtoresolutionssupportedbyboth the PC and the Sony TV. See
SonyTVusersmanualandPC documentation for supported
resolutions
6.Pictureisslightlyover - scannedto prevent video source artifacts at
screen edges.
