Sony STR-KSL50 User manual

STR-KSL50
AEP Model
UK Model
E Model
SERVICE MANUAL
HOME THEATER SYSTEM
Sony Corporation
Home Audio Company
Published by Sony Engineering Corporation
9-877-413-01
2003F16-1
© 2003.06
SPECIFICATIONS
Ver 1.0 2003. 06
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are
trademarks of Dolby Laboratories.
•STR-KSL50 is the receiver section in HT-SL50.
Amplifier section
POWER OUTPUT
Models of area code AEP, UK
Rated Power Output at Stereo Mode
(8 ohms 1 kHz, THD 0.7 %)
25 W + 25 W2)
Reference Power Output2)
(8 ohms 1 kHz, THD 10 %)FRONT1): 35 W/ch
CENTER1): 35 W
SURR1): 35 W/ch
Models of other area code
Rated Power Output at Stereo Mode
(8 ohms 1 kHz, THD 0.7 %)
20 W + 20 W2)
Reference Power Output2)
(8 ohms 1 kHz, THD 10 %)FRONT1): 30 W/ch
CENTER1): 30 W
SURR1): 30 W/ch
1) Depending on the sound field settings and the
source, there may be no sound output.
2) Measured under the following conditions:
Area code Power requirements
MY, SP, AEP, UK 230 V AC, 50 Hz
Frequency response
TV/SAT, DVD, VIDEO: 10 Hz – 50 kHz
+0.5/–3 dB (with sound
field and tone by passed)
Inputs (Analog)
TV/SAT, DVD, VIDEO: Sensitivity: 250 mV
Impedance: 50 kilohms
S/N3): 96 dB
(A, 250 mV4))
3) INPUT SHORT (with sound field and tone by
passed).
4) Weighted network, input level.
Inputs (Digital)
DVD (Coaxial) Sensitivity: –
Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
DVD, TV/SAT (Optical) Sensitivity: –
Impedance: –
S/N: 100 dB
(A, 20 kHz LPF)
Outputs
SUB WOOFER Voltage: 2 V
Impedance: 1 kilohms
Tone
Gain levels: ±6 dB, 1 dB step
Video section
Inputs
Video: 1 Vp-p, 75 ohms
Outputs
Video: 1 Vp-p, 75 ohms
FM tuner section
Tuning range 87.5 – 108.0 MHz
Antenna terminals 75 ohms, unbalanced
Intermediate frequency10.7 MHz
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75
ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz
+0.5/–2 dB
Selectivity 60 dB at 400 kHz
AM tuner section
Tuning range
Models of area code AEP, UK, MY, SP
With 9-kHz tuning scale: 531 – 1602 kHz
Antenna Loop antenna
Intermediate frequency450 kHz
Usable sensitivity 50 dB/m (at 999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5% (50 mV/m, 400 Hz)
Selectivity At 9 kHz: 35 dB
— Continued on next page —
•Abbreviation
MY : Malaysia model.
SP : Singapore model.

2
STR-KSL50
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
1. GENERAL ·········································································· 3
2. TEST MODE······································································ 4
3. DIAGRAMS········································································ 7
3-1. Block Diagrams
– Main Section – ···························································8
– Display/Power Section – ············································ 9
3-2. Printed Wiring Board – Digital Section – ··················· 10
3-3. Schematic Diagram – Digital (1/2) Section – ·············11
3-4. Schematic Diagram – Digital (2/2) Section – ·············12
3-5. Printed Wiring Board – Main/Standby Section – ········ 13
3-6. Schematic Diagram – Main (1/2) Section – ················ 14
3-7. Schematic Diagram – Main (2/2)/Standby Section – ··15
3-8. Printed Wiring Board – Display Section – ·················· 16
3-9. Schematic Diagram – Display Section – ·····················17
3-10. IC Block Diagram ······················································· 18
3-19. IC Pin Function Descriptions······································ 19
4. EXPLODEDVIEWS
4-1. Front Panel Section ·····················································23
4-2. Chassis Section ···························································· 24
5. ELECTRICAL PARTS LIST ······································· 25
Unleaded solder
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Noticethat the minus side ofa tantalumcapacitor may be damaged
by heat.
TABLE OF CONTENTS
General
Power requirements
Area code Power requirements
AEP, UK 230 V AC, 50/60 Hz
MY, SP 220 – 230 V AC, 50/60 Hz
Power consumption
Area code Power consumption
AEP, UK 130 W
MY, SP 105 W
Power consumption (during standby mode)
0.3 W
Dimensions (w/h/d)
STR-KSL50: 430 ×56 ×290 mm
including projecting parts
and controls
Mass (Approx.) 4.5 kg
Parts No.
MODEL IDENTIFICATION
— BACK PANEL —
PARTS No.
4-246-465-0s
4-246-465-1s
4-246-465-2s
MODEL
AEP model
UK model
Malaysia, Singapore model

3
STR-KSL50
SECTION 1
GENERAL This section is extracted
from instruction manual.
List of Button Locations and Reference Pages
Main unit
How to use this page
Use this page to find the location of buttons that are
mentioned in the text.
Illustration number
r
MUTING qs (14, 19, 37)
R R
Name of button/part Reference page
Display 6(28)
DVD (indicator) 3(19)
INPUT SELECTOR 8(19, 26)
IR (receptor) 7(32)
MASTER VOLUME 9(18, 36)
MUTING qs (14, 19, 37)
PRESET TUNING +/– qd (28)
SOUND FIELD qa (21, 25, 38)
TUNER (indicator) 5(19)
TV/SAT (indicator) 4(19)
VIDEO (indicator) 2(19)
ALPHABETICAL ORDER NUMBERS AND SYMBOLS
@/1 (power) 1(13, 18, 19, 25,
26)
;PLII q; (20)
?/1
12 3 4 5 6 78 9 0
qs
qd
qa

4
STR-KSL50 SECTION 2
TEST MODE
FACTORY PRESET MODE
*All preset contents are reset to the default setting.
*Procedure:
While depressing the PLII and the PRESETTUNING + buttons
simultaneously, press the power ?/1 button to turn on the main
power. The message “FACTORY” appears and the present
contents are reset to the default values.
RDS AUTOBETICAL MODE
*This mode is installed in the Europe models only. When this mode
is used, the receiver scans the broadcasts that can be received by
the tuner, and sets up the broadcasts. Be sure to start scanning
after connecting the antenna.
*Procedure :
1. Check that the antenna is connected.
2. While depressing the INPUT SELECTOR button, press the
?/1 button to turn on the main power.
3. The message “AUTO-BETICAL SELECT” appears and the
receiver starts scanning.
MICRO/NORMAL SPEAKER SELECTION MODE
*Either the micro speaker mode or normal speaker mode can be
selected.
*Procedure
While depressing the MUTING button, press the power ?/1
button to turn on the main power. Either the message “MICRO
SP.” or “NORM. SP.” appears. Select the desired mode.
SOUND FIELD CLEAR MODE
*The preset sound field is cleared when this mode is activated.
Use this mode before returning the product to clients upon
completion of repair.
*Procedure:
While depressing the SOUND FIELD button, press the power
?/1 button to turn on the main power. The message
“SF. CLR” appears and initialization is performed.
ALL CLEAR MODE
*The all preset value is cleared when this mode is activated.
*Procedure :
While depressing the PLII and the PRESET TUNING - buttons
simultaneously, press the power ?/1 button to turn on the main
power. The message “CLEARED” appears and clear all preset
value.
SOFTWARE VERSION DISPLAY MODE
*The software version is displayed.
*Procedure:
Whiledepressing the SOUNDFIELD and the PRESETTUNING
- buttons simultaneously, press the power ?/1 button to turn on
the main power. The model name, destination and the software
version are displayed.
KEY CHECK MODE
*Button check
*Procedure:
While depressing the MUTING and the INPUT SELECTOR
buttons simultaneously, press the power ?/1 button to turn on
the main power.
“REST 06” appears.
Every pressing of any button other than ?/1 counts down the
buttons. The buttons which are already counted once are not
counted again. When all buttons are pressed “REST 00” appears.
FLUORESCENT INDICATORTUBETEST MODE
*All fluorescent segments are tested. When this test is activated,
all segments turn on at the same time, then each segment turns on
one after another.
*Procedure:
While depressing the MUTING and the PRESET TUNING -
buttons simultaneously, press the power ?/1 button to turn on
the main power.
1. All segments turn on.
VIDEO , DVD , TV/SAT and TUNER LED turn on.
2. Press the INPUT SELECTOR button, confirm display
VIDEO , and TUNER LED turn on.
3. Press the INPUT SELECTOR button, confirm display
DVD and TV/SAT LED turn on.
4. Press the INPUT SELECTOR button, all segments and LEDs
turn off.
5. Every pressing of the INPUT SELECTOR button turns on
each segment and LED one after another in the same order.
TUNER CHECK MODE
*Tuner check
*Procedure :
While depressing the SOUND FIELD and the INPUT
SELECTOR buttons simultaneously, press the power ?/1
button to turn on the main power. “TUN CHK” appears and the
tuner checking is performed.
DSPTEST MODE
*DSP tests are performed.
*Procedure :
There are two different methods to enter the test mode.
(1) While depressing the INPUT SELECTOR and PRESET
TUNING- buttonssimultaneously, pressthe power ?/1 button
to turn on the main power.
(2) When the set is turned on, by using the remote controller, press
the ENTER button three times, then press the MAIN MENU
button one time and thenpress the MUTING button one time.
•Select the item by pressing Cursor button ( Vor v).
•Select the function by pressing Cursor button ( Bor b).
LSW
SL SRSSB
C R
L F E
OPT COAX
RDS
MONO
ST
D.RANGE
dB
kHz
mft.
MHz
DIGITAL
PRO LOGIC II
DTS
MPEG-2 AAC
D
D
D D
MEMORY
LSW
SRS
CR
L F E
COAX
RDS
MONO
ST
k
m
MHz
DIGITAL
PRO LOGIC
MPEG
D
D
D D
SL S B
OPT
D.RANGE
dB
Hz
ft.
II
DTS
-2 AAC
MEMORY

5
STR-KSL50
•DSPTest Mode Items
Items
SWAP
DSP Version
DSP communication
Bass Management
Main Speaker cut off Freq.
LFE cut off Freq.
Co-ef. Read Address
Co-ef. Read Data
Co-ef. Write Address
Co-ef. Write Data
SRAM
Total operation time
Longest Power ON time
Output time less than
–50dB volume
Output time less than
–40dB volume
Output time less than
–30dB volume
Output time less than
–20dB volume
Output time less than
–10dB volume
Output time less than
0dB volume
Protector count value
Fuse open count value
EEPROM CONDITION
Remark
Selection of setting
output channels
Checking communication
between DSP and microcom
Checking communication
between DSP and SRAM
Four large charactors are
hour. Two small charactors
are minutes.
0 to 255
Description
Normal channel output
Left input tFront Left, Surround Left, Center channel output
Right input t Front Right, Surround Right, Sub Woofer channel output
Left input tCenter channel output
Right input t Sub Woofer channel output
Left input tSurround Left channel output
Right input t Surround Right channel output
“DSPV XXX” is displayed. Three large charactors are the DSP version
that is being used.
When this item is selected the message will be displayed “ OK ” if the
checking is correct. “ ERROR ” will be displayed in a case of an error.
“SUR-NORM” is displayed.
“EQ-NORM” is displayed.
“DLY-NORM” is displayed.
“BM-NORM” is displayed.
Not used for service “BM. AUTO” is displayed.
Not used for service “MAIN 120 Hz” is displayed.
Not used for service “LFE 120 Hz” is displayed.
Not used for service “RA. XXXXX” is displayed.
Not used for service “RD. XXXXXX xx” is displayed.
Not used for service “WA. XXXXX” is displayed.
Not used for service “WD. XXXXXX xx” is displayed.
“ RAMC. OFF ” will be displayed in a case of no checking.
By pressing Cursor button the checking starts.
“ RAMC. PASS ” will be displayed if the checking is good.
“ RAMC. NG ” will be displayed if an error occurs.
“TTL-XXXX xx” is displayed.
“LNG-XXXX xx” is displayed.
“V50-XXXX xx” is displayed.
“V40-XXXX xx” is displayed.
“V30-XXXX xx” is displayed.
“V20-XXXX xx” is displayed.
“V10-XXXX xx” is displayed.
“V00-XXXX xx” is displayed.
“PROT XXX” is displayed.
“FUSE XXX” is displayed.
“E- XXXX” is displayed.
S RST tSuper Reset : first time use EEPROM or test pattern
corrupted
FAIL tEEPROM read / write with microcom has problem
V CHG tSoftware version change
D CHG tDestination / model change
CLEAR tBack up data initialize
NORM tNormal AC on
Function
NORM
ALL
C SW
SLSR
–
–
–
–
–
–
–
–
–
–
–
–
–
OFF
ON
–
–
–
–
–
–
–
–
–
–
–

6
STR-KSL50
Items
EEPROM READ
EEPROM Super Reset
DSP HALT MODE
RemarkDescription
“E- XXX-XX” is displayed.
First four hex code is EEPROM address (controlled by +/– button).
Last two hex code is EEPROM data.
“S.RST- XXX” is displayed.
WhenYES is selected, press Cursor button to clear all EEPROM data
“HALT NO” or “HALTYES” is displayed.
Function
–
–
–

77
STR-KSL50
SECTION 3
DIAGRAMS
• Circuit Boards Location
DIGITAL board
MAIN board
DISPLAY board
POWER SW board
STANDBY board
For schematic diagrams.
Note:
•All capacitors are in µF unless otherwise noted.p : pF. 50
WV or less are not indicated except for electrolytics and
tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise
specified.
•%: indicates tolerance.
•f: internal component.
•2: nonflammable resistor.
•5: fusible resistor.
•C: panel designation.
•A: B+ Line.
•B: B– Line.
•Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
No mark : FM
•Voltages are taken with aVOM(Inputimpedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
•Waveforms are taken with a oscilloscope.
•Circled numbers refer to waveforms.
•Signal path.
F: ANALOG
J: DIGITAL
c: DVD
•Abbrevation
MY : Malaysia model.
SP : Singapore model.
THIS NOTE IS COMMON FOR PRINTEDWIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this necessary note is printed in each block.)
C
B
These are omitted.
E
Q
B
These are omitted.
CE
For printed wiring boards.
Note:
•X: parts extracted from the component side.
•a: Through hole.
•: Pattern from the side which enables seeing.
Caution:
Pattern face side: Partsonthepattern faceside seen from
(Side A) the pattern face are indicated.
Parts face side: Parts on the parts face side seen from
(Side B) theparts face are indicated.
• Waveforms
– DIGITAL Board –
1IC1201 qs (MCLK2) 2IC1101 wa (XOUT) 3IC1601 id (X1)
1V/DIV, 40ns/DIV 1V/DIV, 40ns/DIV 1V/DIV, 40ns/DIV
4.1 Vp-p
74 ns 3.4 Vp-p
62.4 ns
81.3 ns 4.3 Vp-p
Note: The components identified by mark 0or dotted line
with mark 0are critical for safety.
Replace only with part number specified.

88
STR-KSL50
3-1. Block Diagrams – Main Section –
• Signal Path
: ANALOG
: DIGITAL
: DVD
9MCLK1
12MCLK2
69
28
29
22
30
20
19
23
24
25
18
GP8
5DIN2
LRCKI2
BCKI2
KFSIO
SDI2
BCKO
29 VIDEO-MUTE
26 VIDEO-SW2
22 VIDEO-SW1
LRCKO
SDO1
SDO2
SDO3
SDI1
4
5
6
7
8
9
BCLK
43
CDT1
LRCK
SDTI1
SDTI2
SDTI3
27
28
23
25
26
LOUT1
ROUT1
LOUT3
LOUT2
ROUT2
24 ROUT3 SDTO
14 SCKOUT
6CS
59 2 32 33 34 35 36 56
39
MCLK1
AUDIO
INTERFACE
OUTPUT
CIRCUIT
MUTE
Q361-366
VOLUME
SELECTOR
AMP
ATT
AMP
INPUT
CIRCUIT
PROTECT DET
Q730-732
FUNCTION
MUTE SW
Q1601, 1602
MUTE
DRIVE
Q379
42
CCLK
41
CS
13
CS
12
SCL
10
CDT1
14
DATA
15
CLK
16
LATCH
EXLOCK XRST HACN HDIN HCLK HDOUT HCS BST
68
GP9
113
PM
6 5 19 20 18 4 3
XRST
HACN
3 17
S.MUTE PD
9 8
SMUTE
PD
24 21
ANA/DIG
F.MUTE
HDIN
HCLK
HDOUT
HCS
BST
2
GP9
7
PM
67
PROTECTOR
72
FRONT RELAY
71
CENTER RELAY
70
REAR RELAY
64
FAN_ON
17
WOOFER RELAY
44CS0
24AUDIO 15LRCK 14BCK
17 WE
45WE0
X1201
13.5MHz
A0-A15
21 XOUT
4
OUT
1IN
22 XIN
X1101
12.288MHz
D0-D15
20
21
24
23
22
25
LIN2
RIN2
CIN2
SLIN2
SRIN2
SWIN2
28
27
29
DATA
CLK
LATCH
54
47
36
41
42
35
74
75
78
79
LOUT
ROUT
COUT
SLOUT
SROUT
SWOUT
INL6
INR6
INL4
INR4
L-CH
R-CH
C-CH
SL-CH
SR-CH
SW-CH
L-CH
R-CH
C-CH
SL-CH
SR-CH
30 LIN+
29 LIN-
32 RIN+
31 RIN-
14
17
111312
4
10
5231
BAL L+ BAL R+
30
DVDD
+3.3V
REG
Q401
OPTICAL
RECEIVER
+7V
D1601
D1101
L
J401
R
DVD
IN
DIGITAL
L
R
70
71
INL8
INR8
L
R
J251
TV/SAT
IN
VIDEO
IN
6
57
IC1502
2
31
IC1502
6
57
IC1552
BIAS 2
31
IC1552
MONITOR
OUT
VIDEO
IN
J301
DVD
COAXIAL IN
J403 SUB
WOOFER
OUT
DVD
OPT IN
DVD
IN
IC1601 (1/2)
SYSTEM CONTROL
IC201
VIDEO SWITCH
IC401
INPUT SELECT, VOLUME CONT
IC1101
DIGITAL AUDIO
I/F RECEIVER IC701 FL AMP
4
OUT
1IN
IC751 FR AMP
4
OUT
1IN
IC501 C AMP
4
OUT
1IN
IC601 SL AMP
4
OUT
1IN
IC651 SR AMP
IC1501
CODEC
IC1201
AUDIO DSP
IC1202
SDRAM
IC303
IC302
11 10
3DIN0
OPTICAL
RECEIVER
TV/SAT
OPT IN
IC301
4DIN1
IC303
98
13
CKOUT
AUDIO
LRCK
BCK
CKOUT
AUDIO
LRCK
BCK
CKOUT
16DATAO 17XSATE 34ERROR 35
DO 36
DI 37CE 38CLK 47CKSEL1 48
XMODE
SW-CH
7OUT
5IN
IC402 SW AMP
FAN ON/OFF DET
Q550, 551
RELAY SW
Q402
RELAY DRIVE
Q520, 620, 720
RY701
RY501
RY601
D721
D521
D621
RY401
74
STEREO
73
TUNED
76
DO
75
MUTE
78
SLATCH
STEREO
TUNED
DI
SCLK
DO
53
RDS DATA RDS_DATA
52
RDS CLK RDS_CLK
43
RDS SIGNAL SIGNAL
MUTE
LATCH
L CH
2
3
INL2
INR2
L CH
R CH
TU901
TUNER UNIT
R CH MUTE STEREO TUNED CE ST-DI ST-DO CLK
L CH R CH MUTE STEREO TUNED LATCH DI DO SCLK
DATAO
SIGNAL
94
CKSEL1
93
XMODE
96
CE
95
CLK
98
DO
97
DI
100
XSTATE
1
DATAO
99
ERROR
RDS_CLK RDS_DATA
L
TM601
FRONT
CENTER
SURR
SPEAKERS
RDS-DATA RDS-INT FM SIG OUT 3.3V+3.3V
AUDIO
VIDEO
AEP, UK
AEP, UK
L
R
R

99
STR-KSL50
– Display/Power Section –
60
59
VOL(A)
VOL(B)
5
6
SDA
SCL
41 A/D3
1
3
VOL
ENCODER
IC1601(2/2)
SYSTEM CONTROL
RV101
54
28
27
13 REMOTE
CONTROL
RECEIVER
+3.3V
(STBY)
+5V
+3.3V
(STBY)
IC102
21 RESET
IC1602
IC1604
EEPROM
FUKCTION
KEY
S114, 115
FL101
FLUORESCENT
INDICATOR TUBE
39 A/D1
FUKCTION
KEY
S113, 116
S123
FLASH
PROGRAMMING
CNS3
40 A/D2
FUKCTION
KEY
S111, 112
56 POWER KEY
82 X0
SIRCS
83 X1
FLASH1
FLASH2
AEP, UK
X1601
16MHz
49
51
MD0
MD2
69F_CTRL1 68F_CTRL2 65FAN_CLK
66POWER RELAY
48STOP
55FUSE DETECT
33SCL 34SDA
2
4
1B
2A
IC1651
BUFFER
IC152
FL/LED DRIVE
61DIN
63FL_STB
62CLK 62Y 83Y 31Y 3DVD LED 2TV/SAT LED 1TUNER LED 4VIDEO LED
SEG1-16
11A
9
10
3A
3B
52B
8
7
CLK
DIN
9STB
77
RSTX
23 -5V
REG
IC406
GRID1-12
F2
F2
F1
F1
F2
F1
14-29 42-31 D151-154
FAN901
FAN
CONTOROL
Q861-865
FAN
CLK
Q866
D801-804
+,-RECT
D805-808
+RECT
-5V (VIDEO)
23 -7V
REG
IC404
-7V
13 +7V
REG
IC403
+7V
13 +10V
REG
IC1902
+10V (TUNER)
13 +3.3V
REG
IC1905
+3.3V (TUNER)
13 +3.3V
REG
IC1904
RELAY
DRIVE
Q951
STOP
DET
Q901
+3.3V (STBY)
13 +5V
REG
IC1503
4
2
5
+3.3V/+2.5V
REG
IC1901
+5V
+3.3V
+2.5V
AUDIO+
-27V
13 +5V
REG
IC1903
+5V
13 +5V
REG
IC405
+5V (VIDEO)
D814-817
+,-RECT
D809
+,-RECT
AMP+V
AMP-V
D952-955
STBY
+REC
D810, 811
-RECT
D956, 957
+RECT
AC
IN
F901
T901
T902
RY901
?/1
g

1010
STR-KSL50
3-2. PrintedWiring Board – Digital Section –
IC1501
IC1201
IC1101
IC1902
IC1905
IC1202
IC1502
IC1552
IC1601
IC1602
IC1604
IC1651
IC1904
IC1903
IC1503
IC1901
AEP,UK
AEP,UK
31
TUNER
UNIT
*CN7
15P:AEP,UK
11P:MY,SP
TM301
1
1
1
5
3
3
3
2
7
1
3
1
1
3
AEP,UK
12
A
B
C
D
E
F
34567891011
16
• See page 7 for Circuit Boards Location. • : Uses unleaded solder.
Ref. No. Location
•Semiconductor Location
Ref. No. Location Ref. No. Location
D1101 B-3
D1501 B-8
D1502 B-8
D1601 E-2
IC1101 B-4
IC1201 C-3
IC1202 C-4
IC1501 B-3
IC1502 B-2
IC1503 C-9
IC1552 C-2
IC1601 D-2
IC1602 E-2
IC1604 E-2
IC1651 E-3
IC1901 E-6
IC1902 B-6
IC1903 E-6
IC1904 E-7
IC1905 C-6
Q1601 D-2
Q1602 E-2

1111
STR-KSL50
3-3. Schematic Diagram – Digital (1/2) Section – • See page 7 forWavefoms. • See page 18 for IC Block Diagrams. • See page 19 for IC Pin Function Description.
C1102
C1103
C1107
C1109
C1110
C1112
C1129
C1131
C1201
C1202
C1204
C1206
C1210
C1211
C1212
C1218
C1220
C1227
C1501
C1503
C1505
C1506
C1507
C1513
C1514
C1551
C1552
D1101
D1501
D1502
G1101
IC1101
R1100
R1101
R1102
R1103
R1104
R1105
R1106
R1108
R1111
R1114
R1124
R1202
R1203
R1205
R1209
R1213
R1214
R1215
R1216
R1217 R1218
R1219
R1220
R1221
R1222
R1224
R1225
R1226
R1227
R1228
R1230
R1231
R1232
R1233
R1234
R1235
R1236
R1237
R1238
R1239
R1240
R1241
R1242
R1243
R1244
R1503
R1504
R1505
R1507
R1508
R1516
R1517
R1518
R1519
R1520
R1521
R1552
R1554 R1555 R1556
R1557
X1101
X1201
C1512
C1511
R1509
C1516
C1517
C1518
C1519
C1520
C1521
C1523
FB1203
FB1204
IC1501
FB1104
FB1105
FB1202
FB1501
FB1502
C1914
C1311
C1310
C1309
C1913
R1110
C1640
C1641
C1209
R1208
R1207
R1206
C1205
R1204
C1213
C1214
FB1201
R1115
R1113
C1113
FB1102
C1106
R1107
C1101
C1104
C1111
R1112
C1105
C1108
C1515
R1553
R1229
C1216
C1508
C1509
C1502
R1506
C1504
R1502
R1212
C1208 R1210
C1219
R1314
R1364
C1916
C1915
C1230 C1231
IC1202
C1207
CN9
CNS1
C1221
C1510
IC1902
IC1905
TM301
CN7
R1705
R1710
R1711
TP1214
TP1215
TP1216
TP1217
TP1218
TP1219
TP1220
TP1213
TP1212
TP1211
TP1210
TP1209
TP1208
TP1207
TP1206
TP1205
JR1121
TP1204
TP1203
TP1202
TP1201
TP1222
TP1221
IC1552
IC1502
IC1503
IC1201
R1551
R1501
C1203
47 16V
0.1
0.01
18p
18p
0.01
0.001
100p
0.1
0.1
0.1
0.1
0.1
470
10V
470
10V
100p
100p
0.1
0.0015
0.1
0.1
470 10V
10 50V
0.1
0.1
0.0015
22 50V
1SS352
1SS367
1SS367
LC89056W-E
1M
10k
10k
100
100
4.7k
33k
100
1k
100
100
100
10k
100
100
220
220
220
220
220 220
220
220
220 220
220220 220
220 220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
220
10k
330
5.6k
4.7k
100k
220
220
220
220
220
220
10k
330 5.6k 22k
4.7k
12.288MHz
13.5MHz
0.022
0.1
1k
0.0033
0.0033
0.0033
0.0033
0.0033
0.0033
0.001
0UH
0UH
AK4527B
0UH
0UH
0UH
0UH
0UH
47
16V
0.1
0.1
0.1
0.1
1k
0.1
0.0022
0.1
100
100
100
0.1
1k
0.1
0.1
0UH
10k
1k
0.1
0UH
0.1
5.6k
0.1
0.01
0.1
100
47
16V
0.1
470
10V
10k
220
100p
0.1
0.1
22
50V
22k
10
50V
10k
220
0.1 10k
0.1
1k
1k
0.1
47
16V
0.1 0.1
IS61LV6416-10TLT
0.1
7P
23P
0.1
47
16V
NJM7810FA
100
100
100
0
NJM4565M
NJM4565M
KIA7805API
CXD9617R
330
330
0.1
*

1212
STR-KSL50
3-4. Schematic Diagram – Digital (2/2) Section –
• See page 7 for Wavefoms.• See page 21 for IC Pin Function Description.
C1910
C1905
R1304
C1911
R1636
R1635
R1641
R1640
R1639
R1650
R1651
R1658
D1601
Q1602
C1602
R1673
R1674
R1682
R1687
R1688
C1624
C1627
R1699
R1698
R1638
R1631
R1602
R1600
R1308
X1601
C1635
C1617
R1642
R1666
R1662
R1663
R1664
R1665
R1667
C1651
C1650
C1652
C1654
C1312
R1617
R1618
R1619
R1604
R1605
R1606
R1607
R1608
R1609
R1610
R1611
R1612
R1613
R1614
R1615
R1616
R1603
R1601
R1649
R1648
R1647
R1646
R1645
R1644
R1643
CNS3
C1912
L1901
C1605
C1604
C1612
C1603
C1606
C1611
C1610
R1629
R1628
R1627
R1626
Q1601
R1655R1625
R1624
C1626
C1616
R1689
FB1601
R1694
R1707
R1708
C1229
IC1602
R1637
R1659
IC1901
FB1602
C1618
C1619
R1621
R1656
R1620
R1683
R1686
R1685
R1657
R1676
R1677
R1678
R1679
R1680
R1681
C1614
IC1651
C1625
R1690
R1672
R1671
R1654
R1684
R1632
R1660
C1620
R1634
R1630
C1653
R1704 R1703
FB1651
FB1603
C1906
C1908
CN6
CNS4
C1615
R1305
C1909
C1601
IC1903
IC1904
JR1112
JR1113
JR1114
C1633
R1697
C1631
IC1604
IC1601
470 10V
0.1
47k
0.1
10k
10k
100
100
100
10k
10k
100
ISS352
2SC2712
0.1
100
100
100k
10k
0
0.1
10 50V
4.7k
4.7k
4.7k
100
100
4.7k
100
16MHz
0.1
0.01
10k
10k
3.3k
3.3k
100
100
1k
10
50V
0.1
220p
220p
0.1
100
100
100
100
100
1k
1k
1k
1k
1k
1k
1k
1k
1k
1k
4.7k
1k
1k
1k
1k
1k
1k
1k
1k
1k
7P
470 10V
0
0.1
0.1
0.1
0.1
47 16V
0.01
0.01
10k
10k
10k
10k
UN2211
10k10k
10k
0.1
0.022
10k
0UH
1k
10k
10k
0.1
S-80929CNMC-G8ZT2G
10k
10k
SI-3004KWF
0
0.1
0.1
1k
1k
10k
1k
10k
10k
10k
10k
10k
10k
10k
10k
10k
0.022
TC74VHCT08AFT
0.1
10k
10k
10k
10k
10k
0
10k
0.1
47k
10k
220p
10k 10k
0UH
0
470 10V
470 10V
19P
17P
0.022
47k
0.1
0.1
0
0
0
0.1
0.1
BR24C16F-E2
MB90478PF-G-
139-BND
*

1313
STR-KSL50
3-5. PrintedWiring Board – Main/Standby Section –
IC301
IC302
IC303
IC402
IC201
IC406
IC405
IC401
IC404
IC403
IC701
IC651IC601IC501
IC751
TO
DIGITAL
BOARD
CN9
(Page 10)
TO
DIGITAL
BOARD
CNS1
(Page 10)
TO
DIGITAL
BOARD
CN6
(Page 10)
EEEEEE
E
5
E
E
E
E
E
5
5
5
5
1
1
1
1
1
-+-+-+-+-+
SURR R SURR L FRONT LFRONT R
(IMPEADANCE USE 8-16 )
FAN
MONITORVIDEO
VIDEO
DVD
TV/SAT IN
TV/SAT
DIGITAL
DVD
COXIAL IN
OPT INOPT IN
DVD IN
AUDIO
VIDEO IN
(CHASSIS)(CHASSIS)
3131
17
8
14
E
3
1
3
1
3
1
1
3
14
85
E
E
E
E
E
E
EE
1
3
E
1
1
5
5
4
1
12
A
B
C
D
E
F
G
H
I
3456789101112
T901
POWER
TRANSFORMER
NOT REPLACEABLE
BUILT IN TRASFORMER
POWER
TRANSFORMER
6
5
4
3
2
2
1
1
5
4
3
2
1
AC
IN
21
1
2
E
E
41
*
*
Ref. No. Location
D301 C-1
D405 C-5
D520 C-11
D521 F-7
D550 H-7
D620 C-10
D621 F-7
D720 C-7
D721 F-7
D731 E-7
D801 G-10
D802 G-10
D803 H-10
D804 G-10
D805 H-7
D806 H-7
D807 I-7
D808 I-7
D809 F-10
D810 I-9
D811 I-9
D812 I-10
D813 H-11
D814 H-10
D815 H-10
D816 H-10
D817 H-10
D820 B-7
IC201 B-5
IC301 B-1
IC302 B-2
IC303 B-2
IC401 C-3
IC402 C-4
IC403 C-5
IC404 D-5
IC405 C-6
IC406 C-6
IC501 H-9
IC601 E-9
IC651 C-9
IC701 D-8
IC751 F-8
Q361 D-5
Q362 D-5
Q363 D-4
Q364 D-4
Q365 D-5
Q366 D-4
Q379 D-3
Q401 D-2
Q402 C-5
Q520 D-7
Q550 H-7
Q551 H-7
Q620 C-7
Q720 D-6
Q730 E-7
Q731 E-7
Q732 F-7
Q861 C-7
Q862 B-7
Q863 B-7
Q864 C-7
Q865 C-6
Q866 B-7
• Semiconductor
Location
• See page 7 for Circuit Boards Location. • : Uses unleaded solder.

1414
STR-KSL50
3-6. Schematic Diagram – Main (1/2) Section – • See page 18 for IC Block Diagrams.
Q363
Q364
Q365
Q366
R371
R372
R373
R374
R375
R376
R377
R378
RY401
D405
R473
C471
R499
R477
C498
R381
Q401
R472
R475
C472
R560
D301
Q361
Q362
R361
R362
R380
Q379
C308
R304
J403
R480
R204
C204
CC51 R451
CC01 R401
R452
CC52
CC02
CC53
CC03
R430
R410
R203
R202
R402
R453
R403
C202
C203
C207
C210
C481
C482
C485
C487
C491 C492
C493
C494
C495
IC401
J401
Q402
R471
C371
C372
C373
C375
C376
FB301
FB302
C206
C208
C301
C302
C304
C306
C310
C374
C400
C464
C467
C488
R303
C303
C451
C413 C433
C401
C403
C452
C453
C417
R474
C312
C402
C309
R301
R302
R307
R483
R479
CN403
R482
R368
R367
R360
R363
R369
R370
C418 C419
C311
IC303
CN301
C483 C484
C486
C496
C466
R470
C465
R306
C305
R305
C307
C414
C415
R382
C416
R476
L201
L202
C209
C490
C489
C497
R481
R366
R379
IC302
IC301
J251
IC201
IC402
J301
2SC3576
2SC3576
2SC3576
2SC3576
100k
100k
1k
1k
1k
1k
1k
1k
1SS133
2.2k
4.7
50V
47k
4.7k
33p
10k
2SC3576
1k
2.2k
4.7
50V
10k
1SS133
2SC3576
2SC3576
4.7k
4.7k
100k
BN1F4M
47p
1k
1P
47k
75
47p
100P 1k
100P 1k
1k
100P
100P
100P
100P
47k
47k
75
75
1k
1k
1k
10
50V
10
50V
470 6.3V
2200p
4.7 50V
4.7
50V
4.7
50V
10 50V
4.7
50V 4.7
50V
4.7 50V
4.7 50V
4.7
50V
M61527FP
6P
2SC2785
680
0.022
0.022
0.022
0.022
0.022
0.45UH
0.45UH
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
75
1000p
2.2 50V
2.2
50V 2.2 50V
2.2 50V
2.2 50V
2.2 50V
2.2 50V
2.2 50V
2.2k
470
6.3V
2.2 50V
470
6.3V
100
100
100
100
100
23P
100
47k
100k
100k
100k
4.7k
4.7k
2.2
50V
2.2
50V
10
50V
TC74HCU04AF
7P
4.7 50V 4.7 50V
4.7
50V
4.7
50V
220
10V
47k
220
10V
560k
22
50V 22k
1p
2.2
50V
2.2 50V
100
2.2
50V
1k
470
6.3V
100p
100p
100p
100
10k
4.7k
TORX141PL
TORX141PL
NJM2279D
NJM4565DD

1515
STR-KSL50
3-7. Schematic Diagram – Main (2/2)/Standby Section –
C443 C441
C442
C440
C447
C446 C444
C445
D809
C818
C819
C801
C802
D720
Q720
RY701
C711
L707
C761
L757
Q731 Q730
C730
R708
R758
D721 D731
D520
Q520
RY501
C511
L507
R508
D521
R522
R604
R605
R602
C602
C603
IC601
C611
L607
R608
R640
R540
R740
D620
Q620
R622
R653 R655
R652
C652
C653
IC651
C661
L657
R658
R601
R651
D621
RY601
C702 C703
IC701R701
R752
C752
IC751
R751
R503 R505
C502
C503
IC501
R501
C701
C751
C501
C601
C651
C704
C754
C504
C604
C654
R722
Q732
R730R731
R732C732
C821
D810
D811
C820
D812
C791
C741
C812
C813
C814
C707
C710
C757
C760
C507
C510
C607
C610
C657
C660C658
C656
C758
C756
C708
C706
R705
C709
R755
C759
R750
R710
R760
R510
Q550
C561
C563
D550
R558 R554
R555R557
R552
R556
Q551R553
R704
R654
R703
R754 R753
R504
R603
Q861
R884
C871
R610
R660
D805
D808
D806
D807
C815
C816
C642
C641
C643
R551
C564
R885
R881
CN820
R887
R886
Q865 Q863
R888
Q862
Q866
R883
R882
CN822
C565
R733
CN802
R791
R641
R642
R643
R832
C805
C803
C804
RY901
D951
D952
C922
C921
D953
D954
D955
D956
D957
R956
R955 C923
C924
T902
CNP902
Q951
R951
R954
Q901
R952
CN903
R953
C925
C806C811
C644
C694
C544
D820
R810
R811
R910
D802
D801
D803 D804
C817
Q864
R707
R507
R757
R607
R657
D815 D814
D816 D817
FH901FH902
T901
R702
C753
R502
C509
C609
C659
C744
C794
CN801
CNP901
C506
C508
C606
C608
R509
R759
CN861 FAN
R709
R609
R659
R741
D813
IC405
IC406
IC403
IC404
C562
TM601
R831
PC900
100
10V 0.1
100
10V 0.1
47
25V
10
50V 0.1
0.1
D3SBA20
4700
35V
4700
35V
0.22
50V
0.22
50V
1SS133T
2SC2785
0.022
0.022
2SA988 2SC2785
220 10V
47k
47k
1SS133T 1SS133T
1SS133T
2SC2785
0.022 47k
1SS133T
4.7k
470 22k
22k
100p
100p
SI18752
0.022
47k
47
47
47
1SS133T
2SC2785
4.7k
330 22k
22k
100p
100p
SI18752
0.022
47k
100
100
1SS133T
100p 100p
SI18752100
22k
100p
SI18752
100
330 22k
100p
100p
SI18752
100
4.7
50V
4.7
50V
4.7
50V
4.7
50V
4.7
50V
4.7p
4.7p
4.7p
4.7p
4.7p
4.7k
2SC1841
6.8k10k
33k0.1
100 50V
10EDB40-TA2B5
10EDB40-TA2B5
10EDB40-TA2B5
10EDB40-TA2B5
10EDB40-TA2B5
10EDB40
-TA2B5
10EDB40
-TA2B5
10EDB40
-TA2B5
10EDB40
-TA2B5
10EDB40
-TA2B5 10EDB40 -TA2B5
10EDB40
-TA2B5
10EDB40
-TA2B5
10EDB40 -TA2B5
10EDB40 -TA2B5
10EDB40
-TA2B5
10EDB40
-TA2B5
220
35V
HZS30-1L
0.01
0.01
1000 25V
0.001
50V
0.001
50V
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.11
50V
1
50V
1
50V
1
50V
1
50V
1
50V
22k
100
16V
22k
100
16V
1k
27k
27k
27k
2SC2785
4.7
50V
150V
1SS133T
100k 820
4.7k
220k
3.3k
68k
2SC278510k
470
470
330
470 330
470
330
2SB734
10k
100 16V
27k
27k
0.1
0.1
0.01
0.01
0.01
100k
4.7 50V
100
1.5k
4P
4.7k
10k
BN1F4M BN1F4M
100
BN1F4M
BN1F4M
2.2k
1k
19P
10016V
47k
5P
10
10
10
10
22k
1000 25V
0.001
50V
0.001
50V
1SS133T
0.022
25V
0.022
25V
1SS133T
1SS133T
10k
33k 1000
16V
150V
2P
2SC2785
47k
47k
2SC2785
4.7k
4P
1
0.1
1000 25V 1000 25V
220p
220p
220p
RD5.6
0.47 1/4W
0.47 1/4W
0.47 1/4W
3300
16V
2SD1616
4.7
4.7
4.7
4.7
4.7
22k
100p
22k
100
16V
100
16V
100
16V
220p
220p
5P
2P
1
50V
1
50V
1
50V
1
50V
10
10
3P
10
10
10
10
HZ6.8BP
KIA7805API
NJM79M05FA M5F79M07L
1
50V
100(I)
10EDB40
-TA2B5

1616
STR-KSL50
3-8. PrintedWiring Board – Display Section –
IC102 IC152
12
A
B
C
D
34567891011 12 13
10
Ref. No. Location
•Semiconductor Location
Ref. No. Location
D151 B-12
D152 B-11
D153 B-10
D154 B-9
IC102 B-4
IC152 B-7
• See page 7 for Circuit Boards Location. • : Uses unleaded solder.

1717
STR-KSL50
3-9. Schematic Diagram – Display Section – • See page 18 for IC Block Diagrams.
S111 S112
S113
C142
C158
C159
R178
S114
S115
S116
R192
R153
C141
C143
C155
C156
R191
R194
S123
IC102
C112
R198
D154
D153
D152
R152
CN151
CNP152
CN153
C157
D151
R176
RV101
R199
FL101
IC152
0.1
0.1
0.1
82k
1k
100
10
50V
1000p
220p
220p
1k
1k
NJL74H400A
47
16V
1
SELS5B23C
SELS5B23C
SELS523C
10
17P
3P
3P
10 50V
SELS5B23C
150
1

1818
STR-KSL50
IC1101 LC89056W (DIGITAL Board)
38
37
36
23
24
1 2 3 4 5
44
8 9 10
46
17
22
21
20
30
35 252627282932 3334
16
45 13
14
15
47
40
41
48
CL
39XSEL
CE
DI
EMPHA
AUDIO
DISEL
DOUT
DINO
DINI
DIN2
6
DGND
7
DVDD
11
AVDD
12
AGND
DOSEL0
R
VIN
LPF
CKSEL0
XSTATE
18 DGND
19 DVDD
XIN
XOUT
XMCK
DVDD
31
DGND DO CSFLAG F0/P0/C0 F1/P1/C1 F2/P2/C2 F3/P3/C3 AUTO BPSYNC ERROR
DATAO
DOSEL1 CKOUT
BCK
LRCK
CKSEL1
MODE0
MODE1
42DGND
43DVDD
XMODE
TIMING
MICROCOMPUTER
INTERFACE
SAMPLING
FREQUENCY
C BIT
DETECT
PA/PB
DETECT
LOCK
DETECT
SYSTEM
RESET
MODE
SELECT
INPUT
CIRCUIT
DATA
DEMODULATOR
PLL
CLOCK
VIN3 V-
14
SW2
13
VIN1
12
MUTE1
11
VOUT1
10
NC
9
V+
8
1
SW1
2
AMP
VIN2
3
MUTE2
4
VOUT2
5
GND2
6
GND1
7
AMP
11KEY2
10KEY1
9STB
8CLK
7DIN
6DOUT
5DSC
4VIDEO LED
3DVD LED
2TV/SAT LED
133
TUNER LED GRID10
32 GRID11
31 GRID12
30 VEE
29 SEG16
28 SEG15
27 SEG14
26 SEG13
25 SEG12
24 SEG11
23 SEG10
44 12VSS VSS
13 VDD 14 SEG1 15 SEG2 16 SEG3 17 SEG4 18 SEG5 19 SEG6 20 SEG7 21 SEG8 22 SEG9
43VDD 42GRID1 41GRID2 40GRID3 39GRID4 38GRID5 37GRID6 36GRID7 35GRID8 34GRID9
SERIAL
INTERFACE
24-bit
OUTPUT LATCH
DATA SELECTOR
12-bit
SHIFT REGISTER
4-bit
LATCH
DISPLAY MEMORY
24 bits x 12 words
KEY DATA MEMORY
(2 x 16 bits)
TIMING GENERATOR
KEY SCAN
COMMAND DECODER
GRID DIRVER MULTIPLEXED
DRIVER
DIMMING
CIRCUIT
OSC
OSC
R
SEGMENT DRIVER
1
2
3
4
5
6
7
8
9
10
11
33
32
31
30
29
28
27
26
25
24
23
12 13 14 15 16 17 18 19 20 21 22
44 43 42 41 40 39 38 37 36 35 34
FORMAT
CONVERTER
AUDIO
INTERFACE
INPUT
CIRCUIT
OUTPUT
CIRCUIT
LOOP1 LOOP0/SDA/CDTI DIF1/SCL/CCLK DIF0/CSN P/SN MCLK DZF1 AVSS AVDD VREFH VCOM
DZF2
RIN+
RIN–
LIN+
LIN–
ROUT1
LOUT1
ROUT2
LOUT2
ROUT3
LOUT3
DEM1 DEM0
TVDD
DVDD
DVSS
PDN
ICKS2 ICKS1 ICKS0
CAD1 CAD0
SDOS
I2C
SMUTE
BICK
LRCK
SDTI1
SDTI2
SDTI3
SDTO
DAUX
DFS
IC1501 AK4527B (DIGITAL Board)
INR10/RECR4
AVEE
INL9
INR9
INL8
INR8
INL7
INR7
SLIN2
INL6
INIR6
INL5
INR5
INL4
INR4
INL3
NC RSELOUT
GND NC
SWVIN
LATCH
CLOCK
DGND
SLVIN
SWIN2
CIN2
SWSELOUT
SROUT
LIN1
SRIN2
NC
GND
GND
AVCC
NC
RIN1
SWIN1
DVDD
RIN2
LIN2
GND
BALANCE R/-
BALANCE R/+
SRSELOUT
SRIN1
ROUT LOUT
CIN1
GND
INR1
INL1
INR2
RECR2
INR3
BALANCE L/+
SWOUT
COUT
NC
BALANCE L/-
RVIN
CVIN
CSELOUT
SLSELOUT
GND SLOUT NC SRVIN
SLIN1 LVIN
LSELOUT GND RECL1 RECR1 RECL2 RECL3 RECR3
INL10/RECL4
DATA
INL2
MCU I/F
CLK DATA LATCH
80
78
77
76
75
74
73
72
71
70
69
68
67
66
65
79
64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
12 34 56 7 8 9101112131415161718192021222324
IC201 NJM2279D (MAIN Board)
IC152 µPD16315GB-3BS (DISPLAY Board)
IC401 M61527FP (MAIN Board)
3-10. IC Block Diagram

19
STR-KSL50
3-11. IC Pin Function Descriptions
• IC1201 CXD9617R (AUDIO DSP) (DIGITAL BOARD)
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 to 25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
I/O
—
I
I
I
—
I
O
—
—
—
—
—
I
O
I/O
—
I/O
I
O
O
—
I/O
O
O
O
I
I
I
—
O
I
I
O
I
O
O
O
—
—
O
O
O
O
—
I
—
I
O
—
O
Pin Name
VSS
XRST
EXTIN
FS2
VDD1
FS1
PLOCK
VSS
MCLK1
VDDI
VSS
MCLK2
MS
SCKOUT
LRCKI1
VDDE
BCKI1
SDI1
LRCKO
BCKO
VSS
KFSIO
SDO1 to SDO3
SDO4
SPDIF
LRCKI2
BCKI2
SDI2
VSS
HACN
HDIN
HCLK
HDOUT
HCS
SDCLK
CLKEN
RAS
VDDI
VSS
CAS
DQM/OE0
CS0
WE0
VDDE
WMD1
VSS
WMD0
PAGE2
VSS
PAGE1
Description
Ground terminal
Rest input from the system control
Not used (connected to the ground)
Not used (connected to the ground)
Power supply terminal (+2.5V)
Not used (connected to the ground)
Internal PLL lock signal output Not used (open)
Ground terminal
Resonator terminal (13.5MHz)
Power supply terminal (+2.5V)
Ground terminal
Resonator terminal (13.5MHz)
Master/slave operation selection terminal (L : internal clock) (fixed at “L”)
Internal system clock output to the CODEC (IC1501)
Not used (open)
Power supply terminal (+3.3V)
Bit clock input-output terminal for audio interface serial data Not used (open)
Data input from the CODEC (IC1501)
Sampling clock output to the CODEC (IC1501)
Bit clock output to the CODEC (IC1501)
Ground terminal
Audio clock (384fs/256fs) input from the DIR (IC1101)
Serial data output to the CODEC (IC1501)
Serial data output terminal Not used (open)
SPDIF power output terminal Not used (open)
Sampling clock input to the DIR (IC1101)
Bit clock input from the DIR (IC1101)
Data input from the DIR (IC1101)
Ground terminal
Acknowledge signal output to the system control (IC1601)
Serial data input from the system control (IC1601)
Clock input from the system control (IC1601)
Serial data output to the system control (IC1601)
Chip select signal input from the system control (IC1601)
SDRAM clock Not used (open)
SDRAM clock enable Not used (open)
Row address strobing Not used (open)
Power supply terminal (+2.5V)
Ground terminal
Column address strobing Not used (open)
Data I/O mask Not used (open)
Chip select signal output to the SRAM (IC1202)
Write enable signal output to the SRAM (IC1202)
Power supply terminal (+3.3V)
Setting WAIT mode for external memory (pull up)
Ground terminal
Setting WAIT mode for external memory (pull up)
External memory page switch signal output Not used (open)
Ground terminal
External memory page switch signal output Not used (open)

20
STR-KSL50
Pin No.
53
54
55
56
57
58
59
60
61
62
63
64 to 66
67
68
69
70
71
72 to 75
76
77 to 80
81
82 to 85
86
87
88
89
90
91
92 to 97
98,99
100
101
102 to 105
106
107,108
109,110
111
112
113
114
115
116
117 to 119
120
Pin Name
PAGE0
BOOT
BTACT
BST
MOD1
MOD0
EXLOCK
VDDI
VSS
A17
A16
A15 to A13
GP10
GP9
GP8
VDDI
VSS
D15/GP7 to D12/GP4
VDDE
D11/GP3 to D8/GP0
VSS
A9 toA10
TDO
TMS
XTRST
TCK
TDI
VSS
A8 to A3
D7,D6
VDDI
VSS
D5 to D2
VDDE
D1,D0
A2,A1
VSS
A0
PM
SD13
SD14
SYNC
VSS
VDDI
I/O
O
I
O
I
I
I
I
—
—
O
O
O
O
O
I
—
—
I/O
—
I/O
—
O
O
I
I
I
I
—
O
I/O
—
—
I/O
—
I/O
O
—
O
I
I
I
I
—
—
Description
External memory page switch signal output Not used (open)
Not used (connected to the ground)
Boot mode status display signal Not used (open)
Boot strap signal input from the system control (IC1601)
Setting for 256fs (pllx9) (pull up)
Setting for single chip mode (pull down)
Lock signal input terminal
Power supply terminal (+2.5V)
Ground terminal
External memory address Not used (open)
External memory address Not used (open)
Address signal output to the SRAM (IC1202)
LRCK0 signal output
GP9 (DECODE) signal output to the system control (IC1601)
GP8 (AUDIO) signal input from the DIR (IC1101)
Power supply terminal (+2.5V)
Ground terminal
Data input/output from/to the SRAM (IC1202)
Power supply terminal (+3.3V)
Data input/output from/to the SRAM (IC1202)
Ground terminal
Address signal output to the SRAM (IC1202)
Simple emulation data output Not used (open)
Simple emulation data entry beginning and the end terminal Not used (open)
Asynchronous simple BREAK input terminal of emulation Not used (open)
Simple emulation clock input Not used (open)
Simple emulation data entry Not used (open)
Ground terminal
Address signal output to the SRAM (IC1202)
Data input/output from/to the SRAM (IC1202)
Power supply terminal (+2.5V)
Ground terminal
Data input/output from/to the SRAM (IC1202)
Power supply terminal (+3.3V)
Data input/output from/to the SRAM (IC1202)
Address signal output to the SRAM (IC1202)
Ground terminal
Address signal output to the SRAM (IC1202)
PLL initialization signal input from the system control (IC1601)
Data entry terminal Not used (open)
Data entry terminal Not used (open)
Synchronization / asynchronous selection terminal (L:Sync. H:Async.) (fixed at “H”)
Ground terminal
Power supply terminal (+2.5V)
