Sony Vaio PCG-C1XD Mounting instructions

nN
About the Software on
your Sony Notebook
Computer
PCG-C1XD
© 2000 by Sony Corporation.

About the Software on your Notebook Computer
2
nN
NOTICE
This product contains software owned by Sony and licensed by third parties. Use of
such software is subject to the terms and conditions of license agreements enclosed
with this product. Software specifications are subject to change without notice and
may not necessarily be identical to current retail versions.
Updates and additions to software may require an additional charge. Subscriptions to
online service providers may require a fee and credit card information. Financial
services may require prior arrangements with participating financial institutions.
© 2000 Sony Corporation All rights reserved.
Reproduction in whole or in part without permission is prohibited.
End User Software License Agreement
This End User Software License Agreement (the "EULA") is a legal agreement
between you and Sony Corporation (hereinafter referred to as "SONY"), a corporation
organized under Japanese Law, the manufacturer of your SONY computer system
(the "SONY HARDWARE"). Please read this EULA carefully before installing or using
the software distributed together with this EULA (the "SONY SOFTWARE"). By
installing or using the SONY SOFTWARE, you agree to be bound by the terms of this
EULA. You may use the SONY SOFTWARE only in connection with the use of the
SONY HARDWARE. SONY SOFTWARE is licensed not sold.
Notwithstanding the foregoing, software distributed together with separate End User
Software License Agreement (the "Third Party EULA"), including but not limited to
Windows®operating system provided by Microsoft Corporation, shall be covered by
the Third Party EULA.
If you do not agree to the terms of this EULA, please return the SONY SOFTWARE
together with the SONY HARDWARE to the place where you obtained it.

About the Software on your Notebook Computer
3
nN
1License. This SONY SOFTWARE and the related documentation are licensed to
you by SONY. This EULA allows you to use the SONY SOFTWARE for your
personal use for a single SONY HARDWARE outside a network and only to make
one copy of the SONY SOFTWARE in machine-readable form for back-up
purposes only.
2Restrictions. The SONY SOFTWARE contains copyrighted material and other
proprietary material. In order to protect them, and except as permitted by
applicable law, you may not decompile, reverse engineer or disassemble the
SONY SOFTWARE in whole or in part. Except for the transfer of the SONY
SOFTWARE together with the SONY HARDWARE and prior agreement of the
recipient to be bound by the terms and conditions of this EULA, you may not sell
or rent the SONY SOFTWARE and its copy to any third party.
3Limited Warranty. SONY warrants the media on which the SONY SOFTWARE is
recorded to be free from physical defects for a period of ninety (90) days from the
date of purchase as evidenced by a copy of the receipt. During the applicable
warranty period, SONY will replace free of charge such media that proved to be
defective; provided they are returned properly packaged to the place where you
obtained it, together with your name, address, and proof of date of purchase.
SONY will have no responsibility to replace media damaged by accident, abuse,
or misapplication.
The above limited warranty replaces all other representations, conditions and
warranties, whether express or implied, by statute or otherwise and SONY
expressly disclaims all other warranties and all conditions including, but not
limited to, the implied warranties and/or conditions of satisfactory quality and
fitness for a particular purpose. The terms of this limited warranty do not affect or
prejudice your statutory rights as an ultimate consumer, neither do they limit or
exclude any liability for death or personal injury caused by the negligence of
SONY.

About the Software on your Notebook Computer
4
nN
4Termination. This EULA is effective until terminated. You may terminate this
EULA at any time by destroying the SONY SOFTWARE, related documentation,
and all copies thereof. This EULA will terminate immediately without notice
from SONY, if you fail to comply with any provision of this EULA. Upon
termination you must destroy the SONY SOFTWARE, related documentation,
and all copies thereof.
5Governing Law. This EULA shall be governed by and construed in accordance
with the laws of Japan.
Should you have any questions concerning this EULA or this limited warranty, please
refer to the Customer Service Guide on how to contact VAIO-Link.
Sony, DVgate, i.LINKTM, Mavica, PictureGear, Memory Stick and the Memory Stick
logo, VAIO and the VAIO logo are trademarks of Sony Corporation. Windows and the
Windows 98 logo are registered trademarks of Microsoft Corporation.
Intel, MMX, Celeron and Pentium are trademarks of Intel Corporation.
All other trademarks are trademarks of their respective owners.
Specifications are subject to change without notice.

About the Software on your Notebook Computer
5
nN
As an ENERGY STAR Partner, Sony has determined that this product meets the ENERGY
STAR guidelines for energy efficiency.
The International ENERGY STAR Office Equipment Program is an international
program that promotes energy saving through the use of computers and their office
equipment. The program backs the development and dissemination of products with
functions that effectively reduce energy consumption. It is an open system in which
business proprietors can participate voluntarily. The targeted products are office
equipment such as computers, displays, printers, facsimiles and copiers. Their
standards and logos are uniform among participating nations.
ENERGY STAR is an U.S. registered mark.

About the Software on your Notebook Computer
6
nN
Contents
About the Software on Your Notebook Computer
Sony software.......................................................................................... 7
Operating System and other pre-installed software ...................... 12
Using Smart Utilities
Using Smart Capture ........................................................................... 14
Customizing Your Notebook Computer
Setting up the Jog Dial ......................................................................... 18
Sony Notebook Setup ......................................................................... 27
PowerPanel........................................................................................... 29
Displaying Battery Information ........................................................ 34
Selecting the Display Mode ............................................................... 37
Using the Dual Display Function...................................................... 40
About the Partitions of your Hard Disk Drive .................43

About the Software on Your Notebook Computer
Sony software
About the Software on your Notebook Computer
7
nN
About the Software on Your
Notebook Computer
Your Sony notebook computer is ready to help you work, play, learn, and
communicate as soon as you turn it on. This section gives you an overview of the
activities you can perform with your software titles.
For general information and technical assistance, please refer to your Customer Service
Guide.
Sony software
PictureGear
Sony Electronics
Create your own environment with the Digital Image Library (photos, backgrounds,
wallpapers, slide shows, etc). PictureGear is your assistant for creating and implementing
personal screen savers... You can even animate your preferred gifs with Gif Animation Tools or
create labels for all your medias with PictureGear Label Maker.
For details, please read the PictureGear Help file.
Jog Dial Setup
Sony Electronics
Jog Dial Setup sets the allocations of the Sony software or others to the Jog Dial. The settings
enable you to start any application you want, to establish a dialup connection or read an e-mail
by simply turning and pressing the Jog Dial. See “Setting up the Jog Dial” on page 18 and the
Jog Dial Setup Help file for details.

About the Software on Your Notebook Computer
Sony software
About the Software on your Notebook Computer
8
nN
DVgate Still
Sony Electronics
Attaching a DV device to the i.LINKTM connector enables you to transfer the images you have
captured to your hard drive. DVgate Still displays digital video images sent from a digital
video cassette recorder or a digital video camera recorder, and captures them as still pictures on
your notebook computer.
For details, please read the DVgate Still Help file.
DVgate Motion
Sony Electronics
DVgate Motion is a kit of 4 complementary applications: DVgate Motion, DVgate Assemble,
DVgate Scan and DVgate Clip.
Edit the rushes you have shot with your digital video camera recorder using this video-capture
application, specially tuned for high-quality numeric movies. When connected to your camera
via i.LINKTM, your computer operates as an editing desk that can preview, cut and assemble
your selection and save the sequences in AVI format. For details, please refer to the Help file of
DVgate Motion.
Media Bar
Sony Electronics
The Media Bar allows you to play audio and video files in various formats on your hard
drive.Video images are displayed in a separate Movie window, which you can move and resize
(to full screen). For details, please read the Media Bar Help file.

About the Software on Your Notebook Computer
Sony software
About the Software on your Notebook Computer
9
nN
CyberCode Finder
Sony Electronics
The CyberCode Finder is Sony’s new interface that provides you with task-relevant
information in a clear and attractive manner.
The CyberCodes, 2D bar codes developed by Sony, act as indexes and allow you to bring up the
corresponding information on your computer, start registered software and documents as well
as print your own CyberCodes.
For furhter details, please refer to the CyberCode Finder Help file.
Smart Capture
Sony Electronics
Your Notebook Computer features a built-in camera to shoot still images and video clips, which
you can view, edit or send by e-mail. The Smart Capture Finder displays images from the
camera and allows you to adjust the settings or create effects.
Smart Capture enables you to capture images via i.LINK compatible devices or create a
panorama picture using the MOTION EYE and the panorama assist function.See “Using Smart
Capture” on page 14 for more details or refer to the on-line help files.
Smart Connect
Sony Electronics
With Smart Connect you can copy, edit or delete files on another VAIO computer (equipped
with Smart Connect) connected to your computer with an i.LINK™cable.
You can also print a document on a printer connected to another VAIO computer.
Smart Label
Sony Electronics
You can record a voice memo and shoot an image, then post the memo and the image on the
desktop. The recorded file will be easily recognized thanks to the label that appears on your
desktop.
For details, please refer to the Smart Label on-line help file.

About the Software on Your Notebook Computer
Sony software
About the Software on your Notebook Computer
10
nN
Smart Publisher
Sony Electronics
With Smart Publisher, you can send memos to the Internet by e-mail and upload files to your
We b p ag e s .
For details, please read the Smart Publisher Help file.
Smart Write
Sony Electronics
As easy to use as a standard word processor, Smart Write accepts hand-written information
(use your Pointing device as a pen).
When sending memos, insert an image created using Smart Capture, or record a voice memo,
and sign it using Smart Write.
For details, please read the Smart Write Help file.
BatteryScope
Sony Electronics
BatteryScope is a flexible battery management system that gathers critical information from the
battery in your notebook computer, processes it, and displays the information on the screen in a
way that is easy to understand. For details, please read the chapter “Displaying Battery
Information” on page 34 or the BatteryScope Help file.
PowerPanel
Sony Electronics
The PowerPanel utility controls the power management of your notebook computer and
provides key information about system activity and battery life. Automatic power management
selects the most appropriate profile, depending on the application you’re working with and the
conditions of use.
See the chapter “PowerPanel” on page 29 for more information. PowerPanel Help also
provides further details.

About the Software on Your Notebook Computer
Sony software
About the Software on your Notebook Computer
11
nN
Sony Notebook Setup
Sony Electronics
Use the Sony Notebook Setup to confirm system information, specify preferences for system
behavior, and change hardware settings for your Sony Notebook computer.
For more information, refer to the chapter “Sony Notebook Setup” on page 27 or click Help
on the Notebook Setup screen to display the help file.
UI Design Selector
Sony Electronics
You can change the window design of the Sony Software compatible with UI Design selector.
Product Recovery CD-ROM
Sony ITE
The Product Recovery CD-ROM allows you to reinstall individual applications and device
drivers if they are corrupted or accidentally erased. It also allows you to restore the software
titles that were shipped with your computer if they become corrupted or are erased
accidentally. Reinstalling an individual device driver or software title may correct a problem
you are experiencing with your computer, and you may not need to recover the entire contents
of your hard drive.
!You can only use this Recovery
CD-ROM on the Sony
notebook you purchased and
not on any other Sony PC or
other manufacturer's PC.

About the Software on your Notebook Computer
About the Software on Your Notebook Computer
Operating System and other pre-installed software
12
nN
Operating System and other pre-installed software
Windows®98 Second Edition
Microsoft Corporation
Microsoft®Windows®98 Second Edition makes your computer work better by integrating
tightly with the Internet and providing better system performance and easier system
diagnostics and maintenance. With Windows®98 Second Edition, your system plays better as
well with support for the latest graphics, sound, and multimedia technologies, easy addition
and removal of peripheral devices, and the convergence of the TV and PC in your home. This
exciting new operating system builds on the groundbreaking features introduced with
Windows®98. At the same time, Windows®98 Second Edition maintains the best support for
older Windows-based applications and technologies. For questions and technical assistance, go
online to:
http://www.microsoft.com/support/
Internet Explorer 5.0
Microsoft Corporation
Internet Explorer is the Internet browser of Microsoft.The Setup Wizard configures your
computer to connect automatically to the service provider of your choice. A full e-mail package
enables you to send and receive mail—including attached files—across the Internet.
NetMeeting, Outlook Express and Microsoft Chat are just some of the components bundled
with Internet Explorer 5.0. A complete online tutorial helps new users become comfortable
using the Internet. For questions and technical assistance, go online to:
http://www.microsoft.com/support/

About the Software on your Notebook Computer
About the Software on Your Notebook Computer
Operating System and other pre-installed software
13
nN
Adobe®Acrobat®Reader 4.0
Adobe Systems Incorporated
Acrobat Reader software allows you to view, navigate, and print electronic documents in
Adobe Portable Document Format (PDF), an open file format that is intended to preserve the
fidelity of documents created on all major computer platforms. Once Acrobat Reader is
installed, you can open and view PDF files from within your Web browser by clicking on a PDF
file embedded in a HTML file. You quickly see the first page while the rest of the document is
being downloaded. For questions and technical assistance, go online at
http://www.adobe.com
QuickTime 4.0
Apple
QuickTime is the Apple technology that makes video, sound, music, 3D and virtual reality
come alive for your Internet browser and Windows.
With QuickTime VR, rotate objects, zoom in or out, look in any direction and navigate from one
scene to another.
For further information, see the web site at:
http://www.apple.com/quicktime/
VirusScan
McAfee (Network Associates)
VirusScan is McAfee's powerful and advanced anti-virus solution.
If a virus is detected, VirusScan can attempt to remove it from the infected file, move the file to
a quarantine location, or delete the infected file.
VirusScan is an important element of a comprehensive security program that includes a variety
of safety measures such as regular backups, meaningful password protection, training, and
awareness. For details, please refer to the on-line help files or for technical support, go to
http://www.mcafee.com

Using Smart Utilities
Using Smart Capture
About the Software on your Notebook Computer
14
nN
Using Smart Utilities
Using Smart Capture
Your computer includes a built-in "MOTION EYE" camera. You can use the camera
software to shoot still images and record video clips.
Capturing a still image
1Press the CAPTURE button. The Smart Capture application starts.
2The finder window appears.Turn the MOTION EYE lens towards the subject.
3Adjust the focus ring.
4Half-press the CAPTURE button on the computer. The image remains still for a
few seconds. To display another image, release the CAPTURE button and press
again.
5Fully press the CAPTURE button. The Still Viewer window will open and the
captured still image appears in the Still Viewer window.
6To end Smart Capture click the button in the top right corner of the window.
✍Do not touch the camera lens.
Do not point the camera
towards the Sun. Doing so
may cause damage to the
camera.
✍See the Smart Capture
software on-line help for more
information on installation and
use.
You can capture the following
still images sizes : 640 x 480,
320 x 240, 160 x 120, 80 x
60, and 40 x 30 pixels.
When capturing a small
resolution image (i.e. 80 x 60
or 40 x 30 pixels) , the
displayed image on the finder
window may appear blurred.
A gap may appear when a
rapid-moving object is
displayed. However this is not
a malfunction.
If you turn the lens inwards,
Smart Capture goes into mirror
mode. You can use the mirror
mode, to take a video clip of
yourself. A mirror-image
appears in the finder window
of the display while shooting,
however, after capturing a
normal image appears.

Using Smart Utilities
Using Smart Capture
About the Software on your Notebook Computer
15
nN
Displaying the captured images in Still Viewer
From the Start menu, select Programs, Smart Capture and click Still Viewer. You can
display, save or delete your images or send them by e-mail.
To end Still Viewer click the button.
To send a still image via e-mail
1Click the Start button on the Windows®98 taskbar.
2Point to Programs and click Smart Capture.
3Click Still Viewer.
4Select the still image you want to send via e-mail, using or .
5Click MAIL. Your e-mail window will appear with the selected file attached to
your message.
Shooting a video clip
You can use the MOTION EYE to shoot (capture) video clips, as well as play them or
send them via e-mail (if you selected MOVIE in the Smart Capture window)
1Press the CAPTURE button.
2The Smart Capture window will appear.
Select MOVIE using the Switch Capture Mode Button.
3Adjust using the focus ring.
✍You can create a panorama
picture by using PictureGear
2.5SE or higher.
See the software on-line help
for information on installation
and use.
You can capture still images
and video clips from a digital
video camera using Smart
Capture.
When you run applications
used by the built-in camera,
set the power management
profile in PowerPanel to AC
Profile or Camera.
You need to set up MAPI when
using the e-mail software. See
the manual supplied with the
e-mail software for more
information on sending e-
mails.

Using Smart Utilities
Capture modes
About the Software on your Notebook Computer
16
nN
4Turn the MOTION EYE lens towards the subject.
5Keep pressing the CAPTURE button to shoot a video clip.
You can shoot up to 60 seconds.
The Movie Player window will open.
6Release the CAPTURE button when finished.
The captured video clip will appear in the Movie Player window.
Click Bto playback the images. Click Xto pause, xto stop playback.
To end Smart Capture, click
Capture modes
Extended Record Mode
Video:Motion JPEG, 640x480, maximum of 15 frames/second or Motion JPEG
320x240, 24 bit, maximum of 30 frames/second.
Audio: PCM, 22.05kHz, 16bit,monophonic.
Video Mail Mode
Video: 160x120,24bit, maximum of 10 frames/second Audio: PCM,11.025kHz, 16bit,
monophonic.
MPEG1 Format
Video: MPEG1, 160x112, maximum of 10 frames/second (equivalent).
Audio: MPEG1, monophonic, 11.025kHz(equivalent)
✍You can adjust the refresh rate
when you select Monitor as
the display mode.
Some displays do not support
using both the computer’s LCD
and an external display
simultaneously.
To use the Monitor and
Monitor/LCD display modes,
an external display must be
connected to the monitor
connector on the port
replicator.

Using Smart Utilities
To send a video clip via e-mail
About the Software on your Notebook Computer
17
nN
To playback captured video clips
1Start the Movie Player software.
2Click Bto playback the images. Click Xto pause, xto stop playback.
3To end Movie Player click .
To send a video clip via e-mail
If you shoot a video clip in a low resolution format, you can send by e-mail.
1Click the Start button on the Windows®98 taskbar.
2Point to Program and then Smart Capture.
3Click Movie Player.
4Click MAIL.
5The Compression Settings window will open.
Choose the compression rate by moving the slider.
6Click Start Compression. When the compression is completed, attach the file to
your e-mail.
7Send the e-mail.
✍See the manual supplied with
the e-mail software for more
information on sending e-
mails.

Customizing Your Notebook Computer
Setting up the Jog Dial
About the Software on your Notebook Computer
18
nN
Customizing Your Notebook
Computer
You can customize the settings of your notebook computer. The following sections
briefly describe how to change your computer’s settings. You can also refer to the
Help files of the software for more detailed information.
In addition, you can select the display modes via NeoMagic® and enjoy the benefits
of displaying your desktop on two screens.
Setting up the Jog Dial
Information on Using the Jog Dial
The following functions are preinstalled in the Jog Dial launcher.
Name Description
VA I O We b Press the Jog Dial to go to the VAIO
home page
VA I O - L i n k Press the Jog Dial to go to the VAIO-
Link home page
Club VAIO Press the Jog Dial to go to the Club
VA I O h o m e p a g e

Customizing Your Notebook Computer
Setting up the Jog Dial
About the Software on your Notebook Computer
19
nN
Idle/Suspend/Hibernation Press the Jog Dial to select a power
saving mode. See "Controlling
Power Management" for more
information.
Monitor Press the Jog Dial to toggle through
the computer display and the LCD.
Only LCD gLCD and external display g
only external Display gonly LCD...
TV output/ LCD Press the Jog Dial to toggle through
the external display connected to
your computer and the LCD.
Only LCD gLCD and external
display gonly LCD...
Brightness Turn the Jog Dial to adjust the
brightness of the LCD screen. Press
the Jog Dial to confirm the
adjustment.
Vo l u m e Turn the Jog Dial to adjust the
volume of the internal speakers.
Mute Press the Jog Dial to mute the
volume of the internal speakers.
Bass Boost Press the Jog Dial to increase the
basses on your headphones.

Customizing Your Notebook Computer
Setting up the Jog Dial
About the Software on your Notebook Computer
20
nN
Using the Sony Software
You can use additional functions using the supplied Sony software. For more
information, see "Using the Jog Dial" on page.
Software Description
DVgate Still Press the Jog Dial to lauch DVgate
Still.
Turn the Jog Dial to play/rewind image
by image
DVgate Motion Press the Jog Dial to lauch DVgate
Motion.
Turn the Jog Dial to play/rewind
image by image while in pause.
DVgate Clip You can move the Play slider.
Turn the Jog Dial to forward /
rewind image by image while in
pause.
DVgate Assemble Turn the Jog Dial to scroll the list.
DVgate Scan Turn the Jog Dial to scroll the list.
PictureGear Press the Jog Dial to launch
PictureGear.
Turn the Jog Dial to change the size
of the windows. Press the Jog Dial to
optimize the size of the windows.
✍When using Sony software, be
sure to activate the window
that supports the Jog Dial. For
software that do not support
the Jog Dial, see "Software
that do not support the Jog
Dial”.
