LifeBook®A6230 Notebook PC
Fujitsu has managed to pack quite a bit of advanced technology into the LifeBook®
A6230 notebook yet kept it cost effective.
It features a choice of Colour Lids, a fast E-SATA port, dedicated graphics, and a
built in HDMI port.
OVERVIEW
The 15.4” wide energy saving
Crystal View LP Display
Powerful ATI Mobility™
Radeon®HD 3470 graphics
with HyperMemory support
Archive photos and large files
with fast E-SATA port
(5x faster than USB)
Faster DDR3, 1066 MHz memory
Fast 802.11 draft-N wireless
Removable dust filter
Gesture-enable touchpad
Personalize the look of
your notebook with a
choice of Colour Lids
BENEFITS
Power
The Intel®Centrino®2 processor technology
delivers the kind of high energy efficiency that
delivers the battery life needed for the heavy-
duty computing power the LifeBook A6230
notebook is capable of.
Style
Clean design is reflected throughout the
LifeBook A6230 notebook’s style, ergonomics,
and technology. The energy efficient 15.4” wide
Crystal View display delivers bright images as
well as vibrantly rich colors. You also have your
choice of rich colourful lids to personalize your
notebook.
The Colour Lids not only provide you a way to
individualize your notebook, it adds another
layer of protection which can help keep your
notebook looking as good as it operates.
The full-size keyboard and integrated gesture
enable touchpad, seamlessly connects you to
your computer.
Connect
Working away from the office isn’t so bad if
you can easily access the Web while sitting
on your sofa or connect to a Wi-Fi spot at the
airport, cafe or on a campus. The Intel®Wireless
Wi-Fi Link 5100 Intel®Centrino®2 processor
technology offers Wi-Fi IEEE 802.11a/b/g/
draft-n. The Wi-Fi 5100 WLAN not only improves
connectivity, enables wireless connectivity to
selected Wi-Fi enabled consumer devices,
it also significantly reduces WLAN power
consumption through its optimized power
modes.
You can also connect to other data sources
through a multitude of ports—four USB 2.0
ports, an IEEE 1394 port, as well as a E-SATA
port. The new E-SATA port is five times faster
then a USB 2.0 port so archiving data to an
external E-SATA drive becomes much faster.
You can use the dedicated Memory Stick/SD
card slot as a fast and easy way to download
pictures, music, and data. Going wireless is
easy.
Practical
The graphics technology designed into the
LifeBook A6230 notebook provides outstanding
video playback with sharper image quality,
increased clarity, and customizable color
controls. You will be treated to an enhanced
visual experience as well as exceptional 3D
graphics performance, usually not found on
mobile computers.
Fujitsu intelligent Shock Sensor technology
protects your hard drive from accidental bumps,
vibrations, and drops that could otherwise
destroy your valuable data. The spill resistant
keyboard also helps protect against accidental
spills that could potentially damage your
notebook computer.
The available ExpressCard®TV Tuner works in
conjunction with Genuine Windows Vista®Home
Premium so you can watch television, pause live
TV, and use the free electronic programming
guide to record your favorite TV shows.
Quality and Reliability
Fujitsu has incorporated a removable dust filter
which can be cleaned periodically to keep dust
and lint from blocking the notebook’s cooling
vents. This ensures the notebook will run cooler
and prolong its operational life.
The close interaction between Fujitsu design,
manufacturing, and service engineers creates
some of the highest quality products offered
in the PC market. In a time when most PCs
are assembled by third-party vendors, Fujitsu
takes pride in its own world-class design and
manufacturing capabilities.
Fujitsu recommends Windows Vista®Home Premium.

SOFTWARE
Operating Systems Genuine Windows Vista®Home Premium Service Pack 1 (64-bit, MUI)
Software Microsoft®Works with Microsoft®Office Home and Student 2007 60-Day Trial, Adobe Reader, Norton
Internet Security™ 20081, Roxio Creator, CyberLink®MakeDisc™ software CD, CyberLink®PowerDVD,
CyberLink®PowerDirector DE, ArcSoft WebCam Companion, Fujitsu LifeBook Application Panel
software, Fujitsu Driver Update utility
KEY SPECIFICATIONS (Listed specifications are for the current model only and NOT for earlier models or revisions to this product.)
Processor Intel®Core™ 2 Duo Processor P7450 (2.13 GHz, 3 MB L2 cache, 1066 MHz FSB)
Intel®Core™ 2 Duo Processor P7550 (2.26 GHz, 3 MB L2 cache, 1066 MHz FSB)
Chipset Mobile Intel®PM45 Express Chipset
Memory2Two DIMM slots; max. 8 GB (4 GB x2); DDR3 1066 MHz SDRAM dual channel memory module
Display LCD 15.4” Crystal View LP WXGA ( Standard 200 nits)
Crystal View LP viewing angles
Side to Side = 90 degrees; Up and Down = 45 degrees
Video Controller ATI Mobility™ Radeon®HD 3470 with a maximum 256 MB GDDR3 memory
dedicated VRAM (up to 2.0 GB total available graphics memory using
HyperMemory™ technology with 4 GB system memory, up to 1.5 GB with 3 GB
system memory, and up to 1.0 GB with 2 GB system memory)
Maximum Resolution Internal display: 1280 x 800 pixel, 16M colours
External monitor: 1920 x 1200 pixel, 16M colours
Simultaneous: 1024 x 768 pixel, 16M colours
Hard Drive3500 GB (5400 rpm); ultra-DMA 150, S-ATA; protected by Fujitsu Shock Sensor technology
Webcam Integrated 1.3 mega-pixel webcam
Optical Drive Dual-Layer Multi-Format DVD Writer
(Read: 24x CD-ROM, 24x CD-R, 8x DVD-ROM, 5x DVD-RAM, 8x DVD±R, 4x DVD±RW)
(Write: 24x CD-R, 10x CD-RW, 5x DVD-RAM, 8x DVD±R, 4x DVD±RW, 2.4x DVD+R (DL),
2x DVD-R (DL))
Audio Realtek codec ALC269 with 2-channel High Definition (HD) audio
Stereo headphone and microphone jack; Boxless x 2 internal stereo speakers
Communication Internal wired Gigabit Ethernet LAN
Wireless Communication Integrated Intel®Wireless Wi-Fi Link 5100 (300 Mbps Rx/150 Mbps Tx, 802.11 a/g/n)
User Interface Integrated Gesture-Enable touchpad
Spill-resistant full-size keyboard with 19 mm key pitch and 3 mm key stroke
Ports One 15-pin D-SUB connector for external monitor
Four USB 2.0 connectors
One E-SATA jack
One HDMI jack
One DC In connector
One IEEE 1394 (4-pin type) jack
One LAN (RJ-45) connector
One stereo headphone jack
One stereo microphone jack
Card Slots One ExpressCard®slot
One PC Card slot
One Memory Stick/SD Card slot
Security Security Lock Slot
Battery4High capacity Lithium ion battery, 6-cell, 10.8 V, 5200 mAh (Up to 2 hours 15 minutes)
AC Adapter Autosensing 100-240 V AC; 80 W, supplying 19 V DC, 4.22 A, 80 W
Dimensions/Weight 14.49” x 10.43” x 1.71”
Approximately 6.61 lbs
Operating Temperature 41°F to 95°F / 5°C to 35°C (ambient temperature)
20% to 85% relative humidity, non-condensing
Non-Operating Temperature 5°F to 140°F / -15°C to 60°C
8% to 85% relative humidity; non-condensing
COMPLIANCE AND SERVICE INFORMATION
Compliance FCC Part 15B Class B and FCC Part 15C, 15E
IC ICES-003 Class B and RSS-210 UL-cUL Listed
ExpressCard®ID EC100285
Warranty5One-year International Limited Warranty
24/7 technical support
Fujitsu extended service plans available
LIFEBOOK A6230
1) Pre-installed with a free 90-day trial version of
Symantec’s Norton Internet Security™. The 90-day
trial version is activated upon user’s acceptance of
software license agreement. After 90 days, the user
must purchase a subscription from Symantec to
download latest virus definitions.
2) Note that when 4 GB of memory is installed in a
Windows Vista 64-bit system, virtually all the memory
is addressable.
3) One gigabyte (GB) = one billion bytes; accessible
capacity will be less and actual capacity depends on
the operating environment and formatting.
4) Battery life estimates reflect the results of
BAPCo MobileMark2007 Productivity Workloads
performed upon systems with battery life setting
enabled. Actual battery life will vary based on screen
brightness, applications used, features selected,
power management settings, battery conditioning,
and other customer preferences. Optical drive, LAN,
wireless LAN or hard disk drive usage may also have a
significant impact on battery life.
5) Service and warranty turnaround time may vary by
country and product. International warranty valid only
for products purchased in North, Central, and South
America.
