Sony VAIO VGN-CS220J/R User manual

VGN-CS220J/R
VAIO® CS Notebook PC
Color inside and out
MAKE A POWERFUL STATEMENT
Enjoy mobile computing with Intel ® Centrino ® processor technology and
an Intel ® Core™2 Duo T6400 processor (2GHz ) with 4GB of pre - installed
system memory.
The VAIO ® CS notebook comes pre - installed with Genuine Microsoft ®
Windows Vista ® Home Premium 64 - bit .
A perfect mix of power and style, the VAIO ® CS notebook is a slim,
lightweight PC weighing only 5.7lbs (with standard battery).
The CS notebook’s eye - catching Sangria Red color graces its exterior as
well as interior to ensure that this PC makes a head - to - toe color
coordinated impression.
Offering a massive boost in wireless connection speed and range, work
and play quicker virtually anywhere within your office or home using
802.11n integrated wireless LAN technology .
RICH MULTIMEDIA
Watch all your favorite movies and shows in stunning clarity on the 14.1”
widescreen display using XBRITE - ECO™technology so you can see deeper
blacks, brighter whites, true - to - life color and razor - sharp detail from almost
any angle.
Control your music and movies with a slide of your finger using the touch
sensor A/V slide control.
Enjoy your personal musical light shows on a CS notebook. A 12 - tone
music analyzer translates your music into a colorful LED light show that
plays out beneath the trim of the CS notebook.
Store your important documents, family videos and pictures on the roomy
320GB (5400RPM) Serial ATA hard disk drive.
EASY COMMUNICATION
Stay connected to colleagues, friends and family at home or on - the - go
with real - time video conferencing using the integrated MOTION EYE ®
camera and microphone.
Step out and be seen with the VAIO ® CS notebook, a gorgeous 14.1 ”
notebook adorned by fashionable high - gloss colors inside and out. This
thin - and - light PC slips easily in and out of hand bags and features an array
of entertainment extras, including light effects and an intuitive AV “ slide ”
control that lets you control your media with the slide of a finger.
1
5
7
3
6
2
4
6
ECO
-

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 12/21/2008
VGN-CS220J/R
VAIO® CS Notebook PC
Specifications
General
ComputerType: Notebook
TypeofUse: Portable
ActionButtons: Play/Pause/ Stop, AV Mode, Mute, Volume - /+, Capture,
WLAN/Bluetooth® on / off
PointingDevice: Electro - static touch pad
Hardware
Keyboard: QWERTY,82keyswith2mm stroke and 18.05mm pitch
Camera: Built - in1.3 megapixel MOTION EYE ® camera and microphone
Processor
Type: Intel®Core™2DuoProcessorT6400
Speed: 2.0GHz
FrontSideBusSpeed: 800MHz
L2Cache: 2MB
Technology: Intel®Centrino® processortechnology
Memory
Type: DDR2
Installed: 4GBPC2 - 6400(2GBx2)
Maximum:4GB
Speed: 800MHz
Hard Drive
Capacity: 320GB
Speed: 5400rpm
Interface: SerialATA
Optical Drive #1
CDSupport: Read/Write(CD/ - R/ - RW)
DVDSupport: Read/Write(DVD±R/±RW/±RDL/ - RAM)
Expansion Slots
MultimediaCard Reader: OneMemoryStickPRO™ mediaslot
(Standard/Duo)with MagicGate ® functionality
One ExpressCard ®/ 34media slot
OneSecureDigital(SDmemory card) media slot
Audio
SoundSystem: Intel® High Definition Audio
Display
ScreenSize: 14.1"
Resolution: 1280x800
XBRITE - ECO™ Technology: Yes
Technology: WXGA
Graphics
Processor: MobileIntel ®GraphicsMediaAccelerator 4500MHDwith
Intel® ClearVideoTechnologywithTotalAvailableGraphicsMemory
of1750MB (max.)
Chipset: MobileIntel ® GM45Express Chipset
Max.ExternalResolutionvia VGA: 2048x1536
Inputs and Outputs
ModemJack: 1
MicrophoneInput: 1
USBPort(s): 3(2.0 compliant)
VGAOutput(s): 1
DC - In: 1
i.LINK ® Connection: 1 (4pin) i.LINK ®connector(IEEE1394)
HeadphoneOutput(s): 1
EthernetConnection(s): 1
Networking/Modem
EthernetProtocol: 10Base - T/100Base - TX
EthernetSpeed: FastEthernet(RJ - 45)
ModemType: IntegratedV.92/V.90 Modem (RJ - 11)
WirelessLAN: Intel®WiFiLink5100AGN(802.11a/b/g/n)
Bluetooth ® Technology: IntegratedStereoA2DPBluetooth®
Technology
Power
BatteryType: StandardCapacity Lithium - ionBattery(VGP - BPS13/S)
EstimatedBatteryLife: 1.5 - 4.0hours StandardCapacityBattery
2.5 - 6.0hours LargeCapacityBattery
PowerRequirements: 86W+10%
Software
OperatingSystem: GenuineMicrosoft ® Windows Vista ®HomePremium
64 - bit
Anti - VirusandRecovery Software: Microsoft® WindowsLive ™
OneCare ™ Trial Version
1
2
6
10
9
3
16
11
11
5
15
SuppliedSoftware: Microsoft®WorksSE9.0w/ 60 - DayTrialVersion of
Microsoft® OfficeHome and Student 2007
VAIO ® MultimediaSuite: VAIO ®StartupAssistant
Clickto DiscEditor - Import,Edit,Burn
VAIO ®MovieStory - SimpleMovieCreation
VAIO ® MusicBox - Musicby Mood
VAIO ® Mediaplus - MultimediaStreamingSoftware
*Please access VAIO ® HelpandSupportfromyourPCforacomplete
list of software applications and trials.
Service and Warranty Information
TelephoneSupport: 1yeartoll - freetechnicaltelephoneassistance,
available24/7
OnlineandEmailSupport: Supportavailable from
http://www.esupport.sony.com/EN/VAIO
LimitedWarrantyTerm: 1yearlimitedwarranty .Seeactualwarranty
for details.
Environmental Information
EPEAT™ : Silver
RoHS ® : Compliant
Formore information: www.sony.com/vaioeco
ENERGYSTAR® : 4.0
Dimensions
Weight: 5.7 lbs (withstandardbattery)
Measurements: 13.2"(W)x1.14 - 1.57 "(H)x 9.6"(D)
Supplied Accessories
StandardCapacity Lithium - ionbattery(VGP - BPS13/R)
ACAdapter
PowerCord
Optional Accessories
LargeCapacityBattery(VGP - BPL13)
AdditionalStandard Lithium - ionBattery(VGP - BPS13A/R)
ACAdapter(VGP - AC19V25)
USBDockingStation(VGP - UPR1)
Bluetooth® Laser Mouse (VGP - BMS55/R)
USBPortableSpeaker(VGP - USP1)
SlipCasewithVAIOSmart Protection® technology in Sangria Red (VGP -
CKC3/R)
NeopreneNotebook and AC Adapter Case(VGP - AMC5)
Color: Sangria Red
UPCCode: 27242761469
1.GHzdenotesmicroprocessor internal clock speed; other factors may
affectapplication performance. CPU speed willbe reduced under
certain operating conditions.
2.GBmeans one billion bytes when referring toharddrivecapacity.
Accessiblecapacitymay vary. A portion of hard disk spaceis
reservedasarecoverypartition.
3.Requires802.11ncompatibleaccess point. Some functionality may
requireInternetservices.
4.BroadbandInternetservicerequiredalongwiththirdpartyservices
whichmay require a subscription orother service fee.
5.Compatibilityandperformancein a 64 bit environment may vary.
Checkwiththemanufacturerof your software or accessory to ensure
youhave the latest updates.
6. Viewable area measured diagonally.
7.Non - metricweights and measures are approximateand may vary.
8.Measuredatthenarrowest point
9.i.LINKis a trademark of Sony used onlytodesignate that a product
containsanIEEE1394connector.Allproductswithani.LINK
connectormaynotcommunicatewith each other.
10.TotalAvailableGraphicsMemoryrefersto the new Windows Vista
classificationof graphics memory, which varies dependingonthe
operatingcondition, version of device driverand system memory size.
11.Actualbatterylifemay vary based on product settings, usage
patternsand environmental conditions.
12.Seeactuallimitedwarranty for details. For a copy of Sony's warranty,
pleasevisit www.sony.com/pcsupport, call toll - free888 - 476 - 6972
(888 - 4SONYPC)orwriteto Sony Electronics, 12451Gateway
Boulevard,FortMyers,FL33913.
13.Forcertainthirdpartysoftware applications, Sony provides first level
phonesupport.Additional telephone support may be availablefrom
theapplicable3rd party vendor. Availability and schedule for any
suchsupport is determined by the aplicable software vendor.
14.60 - DayTrial Version of Microsoft ® Office2007 - Thistrialsoftware will
workonlyfor 60 days after you first use it. Youwillnotbe able to use
thesoftwareifyoudont activate it as described the first time you use
thesoftware.Youcanactivate the software by Internet: Internet
servicechargesmay apply. If you want to keep usingthesoftware
afterthe60 - daytrialperiod,you must convert to theperpetual
version.Youcanconvertonline by following the conversion
instgructions presented during setup and paying the required fees.
15.Microsoft® WindowsLive ™ OneCare ™ TrialVersion – Thistrial
softwarewillworkforninety(90)daysafteryou first use it. You will not
beable to use the software ifyoudo not activate it as describedthe
firsttimeyouusethesoftware. You can activate the software by
Internet:Internetservicechargesmay apply. If you want to keep
usingthe software after the 90 - daytrialperiod,youmustbuya
subscription.You can subscribe online by followingtheconversion
instructions presented during setup and paying the required fees.
16.Interoperability and compatibility among Bluetooth ®devicesvary.
14
13
12
7
7,8
16
ComputerInterface:Forthisproduct,thereareamultitudeofvarying
software packages and add - onhardwareoptions. This product is not
manufacturedtowork with any specific software, andSonydoesnot and
cannotmakeanywarrantyor representation with respect to the
performanceofthisproduct with any particular software packages
and/or non - Sony add - onhardwareoptionsexceptthosementionedhere.
Sonyherebydisclaimsany representations or warranties thatthis
product is compatible with any combination of non - Sonyproductsyou
maychoosetoconnectto it. While Sony representatives or Sony
authorizeddealersmay be able to assist you and maymake
recommendations,theyareNOTauthorized to vary or waive this
disclaimer.Purchasersmustdetermineforthemselvesthesuitabilityand
compatibilityofthehardware and software in each and every particular
instance.Software titles pre - installedontheSonycomputeraresubject
tochangewithoutnotice. Preinstalled software may not be identical to
retailversionsor have all documentation. Features andspecificationsare
subject to change without notice.
Lampinthisproduct contains mercury. Disposal of these materials may
beregulateddue to environmental considerations. For disposalor
recyclinginformation,pleasecontactyourlocalauthoritiesorthe
Electronic Industries Alliance (www.eiae.org).
©2008SonyElectronicsInc.All rights reserved. Reproduction in whole or
inpartwithoutwrittenpermission is prohibited. Sony, VAIO, the Sony logo,
theVAIO logo, like.no.other, VAIO Smart Protection,XBRITE - ECO,
MemoryStickPRO,MOTIONEYE, MagicGate and i.LINK are trademarks
ofSonyin the U.S. and in other countries.Microsoft,WindowsLive,
OneCareandWindowsVistaaretrademarksofthe Microsoft
Corporationinthe U.S. and in other countries. Intel, CentrinoandCore
aretrademarksofthe Intel Corporation in the U.S. and in other countries.
ENERGYSTARandit'slogo is a registered U.S. mark. Bluetooth and the
BluetoothlogoareregisteredtrademarksofSIG,Inc.Allother
trademarksaretrademarksoftheir respective owners.
PrintedinU.S.A.10/08.
