Sony VAIO VPCW221AX/L User manual

VPCW221AX/L
VAIO® W Notebook PC
The perfect mate your notebook PC.
THE PERFECT FAMILY ACCESSORY
Handy and sturdy enough for any member of your household the W Series
PC is perfect for surfing the web, e - mailing or updating your Facebook ®
profile .
The VAIO ® W Series notebook comes pre - installed with Genuine Microsoft ®
Windows ® 7 Starter.
An ultra - wide 10.1'' LED backlit display (1366x768) produces vivid and crisp
images while conserving precious battery life.
Keeping in touch has never been easier or more fun. The W features an
integrated camera and microphone so you can video chat with friends
and family no matter how far from home they travel .
Store your cherished digital family photos, school projects and important
documents on the 250GB (5400rpm) Serial ATA hard disk drive.
2 easy - to - access USB ports offer convenient connectivity to compatible
cameras, printers and USB flash memory media.
Providing a kid friendly online environment just got easier with KidZui ® and
Online Family.Norton software. Together they provide kid friendly content,
simple parental controls and weekly reports that offer peace of mind and
helps eliminate the need to constantly watch over your kids' shoulder.
WIRELESS FREEDOM
Built - in Wireless - N technology offers a boost in wireless connection speed
and range .
Extend the reach of your VAIO W Series PC with A2DP Bluetooth ®
technology for streaming uncompromised CD - quality stereo music to your
compatible Bluetooth ® technology enabled speakers or headphones.
Enjoying your photos and home videos has never been simpler with the
uniquely smart and easy - to - use PMB VAIO Edition. Get instantly organized
with smart sorting features, create personal masterpieces with one - click
creative tools and share your favorites in two simple steps. Instantly sort
your photos and home videos by person, place, or date.
And with a PlayStation ® 3 or other DLNA ® compatible device connected to
your compatible HDTV, you can enjoy all the content stored on your
notebook on the big screen –wirelessly!
A good - looking and sturdy 10.1 ” PC with a super - crisp, widescreen perfect
for the whole family. With built - in parental controls, kids can enjoy a safer
on - line experience and surf the web and check e - mails in style . And with
long battery life you can stay connected longer in more places.
3
4
9
2
3
12
4
3

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 12/05/2010
VPCW221AX/L
VAIO® W Notebook PC
Specifications
General
Computer Type: Notebook
Type of Use: Mini Notebook
Action Buttons: Wireless on / off
Pointing Device: Electro-static touchpad
Hardware
Keyboard: QWERTY, 82 keys with 1.2mm stroke
and 16.5mm pitch
Camera: Built-in MOTION EYE® camera and
microphone with face-tracking technology
Processor
Type: Intel® Atom™Processor N470
Speed: 1.83GHz
Front Side Bus Speed: 667MHz
L2 Cache: 512kB
Memory
Installed: 1GB (1GBx1)
Maximum: 2GB
Type/Speed: DDR2/667MHz
Hard Drive
Capacity: 250GB
Speed: 5400rpm
Type: Serial ATA
Expansion Slots
Multimedia Card Reader: One Memory Stick
Duo™media slot with MagicGate®
functionality
One Secure Digital (SD memory card) media
slot
Audio
Sound System: Intel® High Definition Audio
Display
Screen Size: 10.1"
Resolution: 1366 x 768
Back Light Technology: LED
Graphics
Processor: Mobile Intel® Graphics Media
Accelerator 3150
Inputs and Outputs
Headphone Jack: 1
Microphone Input: 1
USB Port(s): 2 (2.0 compliant)
VGA Output(s): 1
DC- In: 1
Ethernet Connection (s): 1
Internal Microphone: 1
Power
Battery Type: Large Capacity Lithium-ion Battery
Default Brightness: Up to 8 hours with Large
Capacity Battery
Maximum Brightness: Up to 7 hours with Large
Capacity Battery
Wireless/Networking
Ethernet Protocol: 10Base-T/100Base- TX
Ethernet Speed: Fast Ethernet (RJ -45)
Wi- Fi: 802.11 b/g/n
Bluetooth ® Technology: Integrated Stereo A2DP
(2.1 + EDR)
1
2
4
6
6
3
12
Software
Operating System: Genuine Microsoft ®
Windows® 7 Starter Edition (32-Bit)
Supplied Software: Microsoft® Works SE 9.0 w/
60-Day Trial Version of Microsoft® Office Home
and Student 2007
Anti -Virus Software: Norton Internet Security ™2010
30-Day Trial Offer
System Maintenance and Support: VAIO Care™-
System diagnostics and maintenance
Sony® Creativity Suite: PMB –VAIO® Edition -
Import, organize, edit and publish in one easy-
to-use program
Kid Zui® -Kid-friendly Web browser, search
engine & online playground
*Please access VAIO® Help and Support from
your PC for a complete list of software
applications and trials.
Service and Warranty Information
Telephone Support: 1 year toll- free technical
assistance available 24/7 at 888-476-6972. For
priority support, please call 239-768-7605 .
Online and Email Support: Available at
http://www.esupport.sony.com/EN/VAIO
International Service: 1 year international service
plan. Registration required. See
www.sony.com/IRSP for details.
Limited Warranty Term: 1 year limited warranty .
See actual warranty for details.
Environmental Information
EPEAT™ : Gold
RoHS® : Compliant
ENERGY STAR® : 5.0
Dimensions
Weight: 2.93 lbs (with standard battery)
Measurements: 10.54"(W) x 1.08-2.00"(H) x
7.07"(D)
Supplied Accessories
Large Capacity Battery (5200mAh)
AC Adapter
Power Cord
Optional Accessories
Additional Large Capacity Battery (VGP-BPL18)
Additional AC Adapter (VGP-AC19V39)
Slip Case (VGP-CPW1)
USB Optical Mouse (VGP- UMS30)
Wireless Laser Mouse (VGP - WMS30)
VAIO® Carrying Case (VGP-CCB4/B)
Bluetooth® Interchangeable Mouse (VGP -BMS15)
Bluetooth® Interchangeable Mice Covers (VGP-
BMC15)
Color: Blue
UPC Code: 027242802858
1.GHzdenotesmicroprocessorinternalclockspeedandmayvary.
2.GBmeansonebillionbyteswhenreferringtohard drive capacity.
Accessiblecapacity may vary. A portion ofharddisk space is
reservedas arecoverypartition.
3.Requires a compatible 802.11 access point(802.11n recommended)
andinternetconnection.
4. Viewable area measured diagonally.
5.Measured atthenarrowest point
6.Estimates only based upon Sonyengineeringtesting. Actual
performancewill vary based onnotebook settings, environmental
conditions, and usage. Battery capacity decreases over time and use.
7.See actual limited warranty fordetails.For a copy of Sony'swarranty,
pleasevisit www.sony.com/pcsupport, call toll - free888 - 476 - 6972
(888 - 4SONYPC)or writeto SonyElectronics,12451 Gateway
Boulevard,Fort Myers,FL33913.
10
11
13
8
7
5
8.For certain third party softwareapplications, Sony provides first level
phonesupport. Additional telephone support may be available from
theapplicable 3rd party vendor. Availability and scheduleforany
suchsupportis determined by the aplicable software vendor. Long
distance charges may apply.
9.Broadband Internet service requiredalong with third partyservices
whichmayrequirea subscription or other service fee.
10.60 - DayTrialVersionofMicrosoft ® Office2007 - Thistrialsoftwarewill
workonly for 60 days after youfirstuse it. You will not beableto use
thesoftware if you dont activateitas described the first timeyouuse
thesoftware. Youcanactivate thesoftware by Internet:Internet
servicecharges may apply. If you wanttokeep using the software
afterthe 60 - daytrial period,you must convertto theperpetual
version.You can convert online byfollowingthe conversion
instgructions presented during setup and paying the required fees.
11.Norton Internet Security™2010 30 - day subscription is pre - installed
onyour Sony VAIOPC. You needto activate thesoftwarefor the
productto work. After your 30 - daysare finished, buyNorton Internet
Securityto continuetobe protectedfrom viruses, hackersand
identifytheft.
12.Interoperabilityandcompatibility among Bluetooth ®devices vary.
13.Notall features available on notebooks powered by Intel ®Atom™
processors.
ComputerInterface: For this product,thereare a multitude ofvarying
software packages and add - onhardware options. This product is not
manufacturedto work with any specific software, and Sony doesnotand
cannotmake anywarrantyor representationwith respect tothe
performanceof this product with anyparticularsoftware packages
and/or non - Sony add - onhardware options except thosementionedhere.
Sonyhereby disclaimsany representations orwarranties thatthis
product is compatible with any combination of non - Sonyproductsyou
maychoose toconnectto it.WhileSony representativesorSony
authorizeddealers may be able to assist youandmay make
recommendations,they areNOTauthorized tovary or waivethis
disclaimer.Purchasers must determineforthemselves the suitabilityand
compatibilityof the hardware and software ineachand every particular
instance.Softwaretitles pre - installedon the Sonycomputer are subject
tochange without notice. Preinstalled softwaremaynot be identical to
retailversions or have all documentation. Features and specifications are
subjecttochangewithoutnotice. Non - metricweights andmeasures are
approximateandmay vary.
©2010Sony ElectronicsInc.All rightsreserved.Reproduction inwholeor
inpart without written permission isprohibited.Sony, VAIO and the VAIO
logo,VAIO Care, Memory Stick Duo,i.LINK, MagicGate, and MOTION EYE
aretrademarks of Sony in the U.S.andin other countries. Microsoft and
Windowsare trademarks of the MicrosoftCorporationin the U.S. and in
othercountries. Intel isa registered trademark.Intel is atrademark of
IntelCorporation in the US andother countries. Bluetooth is aregistered
trademarkof SIG, Inc. Symantec,the Symantec Logo, andNorton
InternetSecurity aretrademarks or registeredtrademarks ofSymantec
Corporationor its affiliates in theU.S.and other countries. ENERGY STARis
aregistered U.S.trademark.All othertrademarksare trademarksoftheir
respectiveowners.
