Sony VGN-TT160N - VAIO TT Series User manual

VGN-TT160N/B
VAIO® TT Series Notebook
A new grade in mobility
MOBILE PC PERFORMANCE
Enjoy the performance of an Intel ® Core ™2 Duo SU9300 processor
(1.20GHz ) with Intel ® Centrino ® 2 technology and 3GB of pre-
installed system memory.
The VAIO® TT series notebook comes pre- installed with Genuine
Microsoft ® Windows Vista® Business 32-bit.
Store virtually all your business presentations, team projects and
important documents on the roomy 160GB Serial ATA hard disk drive.
ENDLESS FEATURES
Enjoy an 11.1" LED backlit, widescreen display with XBRITE-DuraView™
LCD technology for a brighter, crisper, tougher display that helps resist
scratches.
An HDMI ™ output provides single - cable connectivity (audio and video)
to a compatible HDTV (cable sold separately) or compatible external
monitor.
A built - in microphone and MOTION EYE ® camera with face- tracking
technology allows for easy communication with friends and family .
A built - in biometric fingerprint scanner makes authentication and
secure access quick and easy – you only need your fingerprint.
WIRELESS FREEDOM
Offering a massive boost in wireless connection speed and range,
work and play quicker virtually anywhere within your office or caf é
hotspot using next -generation 802.11n integrated wireless LAN
technology .
Integrated Stereo A2DP Bluetooth ® technology allows you to wirelessly
connect to useful peripherals and stream CD- quality audio to
compatible devices .
The ultraportable VAIO® TT notebook establishes a new grade in
mobility with its thin -and- light design available in an array of stylish
colors. What’s more, this PC with a stunning 11.1”LCD offers industry-
leading mobile performance, balancing the power of Intel ®
Centrino ® 2 processor technology with a host of energy- conserving
features that deliver maximum battery life.
1
2
8
18
3
4
17
8

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 10/23/2008
VGN-TT160N/B
VAIO® TT Series Notebook
Specifications
General
Computer Type: Notebook
Type of Use: Ultra Portable
Action Buttons: Mute, Volume -/ +, S1, Eject, WLAN /
Bluetooth® on / off
Pointing Device: Electro-static touch pad
Security: Biometric Fingerprint Sensor
Trusted Platform Module (TPM) TCG Ver.1.2 compliant
Hardware
Keyboard: QWERTY, 17.0 mm pitch, 1.7 mm stroke
Camera: Built -in MOTION EYE® camera and microphone
Processor
Type: Intel® Core™2 Duo Processor SU9300
Speed: 1.20 GHz
Front Side Bus Speed: 800MHz
L2 Cache: 3MB
Technology: Intel® Centrino® 2 processor technology
Memory
Type: DDR3
Installed: 3GB PC3 - 6400 (2GBx1 + 1GBx1)
Maximum: 4GB
Speed: 800MHz
Hard Drive
Capacity: 160GB
Speed: 5400rpm
Interface: Serial ATA
Impact Protection: G -Sensor™Shock Protection -Hard
Disk Drive Protection
Optical Drive #1
DVD+R DL Write: 4x max
DVD+R Write: 8x max
DVD+RW Write: 8x max
DVD -R Write: 8x max
DVD -RW Write: 6x max
CD -R Write: 24x max
CD -RW Write: 16x max
DVD ±RW: Yes (DVD ±R DL/ DVD±RW/ RAM)
CD Read: 24x max
DVD Read: 8x max
DVD -RAM Write: 5x max
DVD -R DL Write: 4x max
DVD -RAM Read: 5x max
Expansion Slots
Multimedia Card Reader: One Memory Stick PRO™
(Standard/Duo) media slot with MagicGate®
functionality
One ExpressCard® / 34 slot
One Secure Digital (SD memory card) media slot
Audio
Sound System: Intel® High Definition Audio
Display
Screen or Display Technology: WXGA
Screen Size: 11.1"
Resolution: 1366 x 768
XBRITE- DuraView ™Technology: Yes
Back Light Technology: LED
Graphics
Processor: Mobile Intel® Graphics Media Accelerator
4500MHD with Intel ® Clear Video Technology
Total Available Graphics Memory: 1300MB (max.)
Chipset: Mobile Intel® GS45 Express Chipset
Interface: HDMI™ and VGA out with Smart Display Sensor
Inputs and Outputs
Microphone Input: 1
Port Replicator Connector(s): 1 (Bottom)
USB Port(s): 2 (2.0 compliant)
VGA Output(s): 1
DC -In: 1
1
7
2
8
12
i.LINK® Connection: 1 (4pin) i.LINK® connector (IEEE
1394)
Headphone Output(s): 1
Ethernet Connection (s): 1
HDMI™Output: 1
Networking/Modem
Ethernet Protocol: 10Base - T/100Base - TX/1000Base -T
(Gigabit)
Ethernet Speed: Fast Ethernet (RJ- 45)
Wireless LAN: Intel® WiFi Link 5100AGN(802.11a/b/g/n)
Bluetooth® Technology: Integrated Stereo A2DP
Bluetooth® Technology (2.1 + EDR)
Power
Battery Type: Standard Capacity Lithium-ion Battery
(VGP- BPS14/B)
Estimated Battery Life: 4.5 to 7.5 hours Standard
Capacity Battery
6.5 to 12.0 hours Large Capacity Battery
Power Requirements: 68W + 10%
Input Voltage: 100 - 240V
Software
Operating System: Genuine Microsoft® Windows Vista®
Business 32-bit / XP Pro downgrade
Internet Services: AOL® 90 -Day Risk Free Trial -For new
users only
Anti -Virus and Recovery Software: Microsoft® Windows
Live™OneCare™Trial Version
Supplied Software: Microsoft® Works SE 9.0 w/ 60 - Day
Trial Version of Microsoft® Office Small Business 2007
The VAIO® Software Experience: VAIO ® Startup Assistant
Click to Disc Editor -Import, Edit, Burn
VAIO ® Movie Story -Simple Movie Creation
VAIO ® MusicBox -Music by Mood
VAIO ® Media plus -Multimedia Streaming Software
*Please access VAIO® Help and Support from your
PC for a complete list of software applications and
trials.
Service and Warranty Information
Telephone Support: 1 year toll -free technical telephone
assistance, available 24/7 .
Online and Email Support: Support available from
http://www.esupport.sony.com/EN/VAIO
Limited Warranty Term: 1 year limited warranty with
International Repair Service Program . See actual
warranty for details.
Environmental Information
RoHS®: Compliant
For more information: www.sony.com/vaioeco
Regulation and Standard Compliance
Energy Star® Compliant: 4.0
Dimensions
Weight: 2.92 lbs.
Measurements: 10.99"(W) x 0.93"(H) x 7.87"(D)
Supplied Accessories
Power Cord
AC Adapter (VGP- AC16V13)
Standard Capacity Lithium-ion Battery (VGP- BPS14/B)
Optional Accessories
Large Capacity Battery (VGP- BPL14/B)
Stick AC Adapter (VGP- AC16V10)
Port Replicator (VGP-PRTT1)
Carrying Case (VGP-CKTT1)
Carrying Pouch (VGP- CP11)
Bluetooth® Laser Mouse (VGP- BMS33/B)
Bluetooth® Presentation Controller (VGP-BRMP10)
USB Portable Speaker (VGP- USP1)
100GB Portable Hard Drive with Wireless Keys (VGP-
UHDM10/B)
Privacy Filter (VGP-FL13)
Color: Black
UPC Code: 27242754638
11
4
17
6
6
16
15
14
13
9
9,10
17
17
2
1.GHzdenotesmicroprocessorinternalclockspeed;otherfactorsmay
affectapplication performance. CPU speed will be reduced under
certain operating conditions.
2.GBmeansonebillion bytes when referring to hard drive capacity. TB
meansonetrillionbyteswhenreferringtoharddrivecapacity.
Accessiblecapacitymayvary.Aportionofharddisk space is
reservedasarecoverypartition.
3.BroadbandInternetservicerequiredalongwiththirdpartyservices
whichmay require a subscription or other service fee.
4.Requires802.11ncompatibleaccesspoint.Somefunctionalitymay
requireInternetservices.
5.Certaincircumstancesmaylimit/preventBlu - rayDisc™ media
playback.Foroptimal performance, download all updates from
http://esupport.sony.com/EN/DRIVERS.
6.Actualbatterylifewillvarybased on product settings, usage patterns,
batteryand environmental conditions.
7.Aportionofthesystemmemoryover3GB may not be availableto
theoperatingsystem.
8. Viewable area measured diagonally.
9.Non - metricweights and measures are approximate and mayvary.
10.Measuredatthe narrowestpoint
11.i.LINKisatrademarkof Sony used only to designate that a product
containsan IEEE 1394 connector. All products with an i.LINK
connectormaynotcommunicate witheach other.
12.Total Available Graphics Memory refers to the new WindowsVista ®
classificationofgraphics memory, which varies depending on the
operatingcondition, version of device driver and system memory size.
13.Seeactuallimited warranty for details. For a copy of Sony's warranty,
please visit www.esupport.sony.com, call toll - free888 - 476 - 6972(888 -
4SONYPC),or write toSonyElectronics, 12451 GatewayBoulevard,
FortMyers,FL33913.
14.Forcertain third party software applications, Sony provides first level
phonesupport.Additionaltelephone support may be available from
theapplicable3rdpartyvendor.Availabilityand schedule for any
such support is determined by the applicable software vendor.
15.60 - DayTrial Version of Microsoft ® Office2007 - Thistrial softwarewill
workonlyfor60daysafteryoufirstuseit. You will not be able to use
thesoftwareifyoudonotactivateitasdescribedthefirsttimeyouuse
thesoftware. You canactivatethesoftware by Internet:Internet
servicechargesmayapply.Ifyouwanttokeepusing the software
afterthe60 - daytrial period, youmustconvert to theperpetual
version.Youcan convert online by following the conversion
instructions presented during setup and paying the required fees.
16.Microsoft® WindowsLive ™ OneCare ™ TrialVersion - Thistrial
softwarewill work for ninety (90)daysafteryou first use it. You willnot
beableto use the software if you do not activate it asdescribedthe
firsttime you use thesoftware.Youcan activate the softwareby
Internet:Internet service charges mayapply.If you want tokeep
usingthesoftware after the 90 - daytrial period, you must buy a
subscription.Youcan subscribe online by following the conversion
instructions presented during setup and paying the required fees.
17.Interoperability and compatibility among Bluetooth ®devicesvary.
18. Requires high definition - capable display with HDMI ™ connector.
Imagequalitywill vary.
ComputerInterface: For this product,there are a multitude of varying
software packages and add - onhardwareoptions.Thisproductisnot
manufacturedtoworkwith any specific software, and Sony does not and
cannotmake any warrantyorrepresentationwith respect tothe
performanceofthisproductwithanyparticular software packages
and/or non - Sony add - onhardware options except those mentioned here.
Sonyhereby disclaims anyrepresentationsor warranties thatthis
product is compatible with any combination of non - Sonyproductsyou
maychoose to connect toit.While Sony representatives orSony
authorizeddealersmaybeabletoassist you and may make
recommendations,they are NOTauthorizedtovary or waivethis
disclaimer.Purchasers must determine for themselves the suitability and
compatibilityofthehardwareandsoftwareineachandeveryparticular
instance.Softwaretitles pre - installedon the Sony computer are subject
tochangewithoutnotice.Preinstalledsoftwaremay not be identical to
retailversionsorhave all documentation. Features and specifications are
subject to change without notice.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulateddueto environmental considerations. For disposal or
recyclinginformation, please contact your local authorities or the
Electronic Industries Alliance (www.eiae.org).
©2008Sony Electronics Inc. Allrightsreserved. Reproduction in wholeor
inpart without written permission is prohibited. Sony, i.LINK, VAIO, XBRITE -
DuraView,Sonylogo, VAIO logo, Memory Stick Duo and MagicGate are
trademarksofSonyintheU.S.andinothercountries.Intel and Core are
trademarksoftheIntelCorporationin the U.S. and in other countries.
Microsoftand Windows Vista are registered trademarks of the Microsoft
Corporationin the U.S. and in other countries. Blu - rayDiscand the
Bluetoothlogo are a regestered trademark of SIG, Inc. All other
trademarksaretrademarksof their respective owners.
Printed08/08.
