VGN-FW140D
VAIO® FW Series Notebook PC
Inspired by theater screens. Born from Sony ® HD technology.
POWERFUL PC PERFORMANCE
Intel
® Core™ 2 Duo P8400 processor (2.26GHz ) — the latest chipset from
Intel
® .
The VAIO
® FW notebook comes pre - installed with Genuine Microsoft ®
Windows Vista ® Home Premium.
Built
- in Wireless - N technology offers a boost in wireless connection speed
and range .
INSPIRED BY THEATER SCREENS. BORN FROM SONY
® HD TECHNOLOGY.
Fall in love with your favorite movies all over again with an extra
- wide,
theater inspired 16.4” display (1600x900 resolution) using the energy
-
efficient XBRITE™ LCD technology.
The 16:9 aspect ratio ensures that you won’t miss an inch of the original
picture from your favorite movie while also providing valuable extra
workspace. Compare two documents or websites side
- by - side without the
hassle of having to tab back and forth.
An HDMI ™ output delivers video and audio to external sources via a single
cable so you can enjoy HD entertainment on your compatible big screen
TV without a myriad of extra cables (HDMI™ cable sold separately) .
ENDLESS FEATURES
Store you favorite multimedia, important documents, and cherished family
photos on the roomy 250GB Serial ATA hard drive.
The VAIO
® FW notebook, designed with dedicated AV Controls, makes
navigating through your favorite multimedia quick and easy.
Whether it’s for YouTube™ , a class project or for sharing with friends and
family, editing digital video captured by your Sony
® Handycam ® is quick
and easy with VAIO
® Movie Story software. You choose the supplied
template and professional
- looking cutaways, cross - fades and soundtrack
syncing are automatically done for you.
Stay connected to colleagues, friends and family with real
- time video
conferencing using the integrated MOTION EYE
® camera and
microphone.
Broaden you entertainment horizons with the VAIO
® FW notebook
featuring an extra
- wide 16.4 ” XBRITE ™ LCD display. Great for watching
widescreen movies or viewing two websites side
- by - side, this entertainment
powerhouse is inspired by theater screens, born from Sony
® HD expertise
and powered by Intel
® processor technology.
1
3
6
15
2
4
6

Sony of Canada Ltd. • 115 Gordon Baker Rd. • Toronto, ON • M2H 3R6 • www.sonystyle.ca
VGN-FW140D
VAIO® FW Series Notebook PC
Specifications
G
eneral
C
omputer Type: Notebook
T
ype of Use: Portable
A
ction Buttons: S1, DVD Play, A/V Mode, Volum
e
-/+, Play/Pause/Stop, WLAN/Bluetooth® on/
off
P
ointing Device: Electro-Static touch pad
H
ardware
Keyboard: QWERTY, 86 keys with 2.0mm stroke
and 19.05mm pitch- Bilingual
Camera: Built-in 1.3 megapixel MOTION EYE®
camera and microphone
P
rocessor
T
ype: Intel® Core™ 2 Duo Processor P8400
S
peed: 2.26GHz
F
ront Side Bus Speed: 1066MHz
L
2 Cache: 3MB
M
emory
Type: DDR2 SDRAM
Installed: 3GB PC2-6400 (2GBx1 + 1GBx1)
Maximum: 4GB
S
peed: 800MHz
H
ard Drive
C
apacity: 250GB
S
peed: 5400rpm
In
terface: Serial ATA
O
ptical Drive #1
D
VD+R DL Write: 6x max
D
VD+R Write: 8x max
D
VD+RW Write: 8x max
D
VD- R Write: 8x max
D
VD-RW Write: 6x max
C
D- R Write: 24x max
C
D-RW Write: 24x max
D
VD ± RW: Yes (DVD ± R DL/DVD ± RW/RAM)
C
D Read: 24x max
D
VD Read: 8x max
D
VD- RAM Write: 5x max
D
VD- R DL Write: 6x max
D
VD- RAM Read: 5x max
E
xpansion Slots
M
ultimedia Card Reader: One Memory Stick
Duo™ media slot with MagicGate®
functionality
One ExpressCard ® /34 slot
One Secure Digital (SD™ memory card) med
ia
slot
A
udio
S
ound System: Dolby Sound Room® Audio
D
isplay
S
creen Size: 16.4"
Resolution: 1600 x 900
XBRITE™ Technology:
Yes
G
raphics
P
rocessor: ATI Mobility Radeon™ HD 3470 with
Total Available Graphics Memory of 1530MB
(max.)
V
ideo RAM: 256MB of dedicated video RAM
C
hipset: Mobile Intel® PM45 Express Chipset
Interface: HDMI™ and VGA out with Smart
Display Sensor
I
nputs and Outputs
Ethernet Port: 1
1
13
2
5
6
10
15
HDMI™ Connection Output(s): 1
Headphone Jack: 1
Modem Jack: 1
Microphone Input: 1
USB Port(s): 3 (2.0 compliant)
VGA Output(s): 1
DC-
In: 1
i.LINK ® Connection: 1 (4pin) i.LINK® connector
(IEEE 1394)
Networking/Modem
Ethernet Protocol: 10Base-T/100Base- TX/1000Base -
T
Ethernet Speed: Fast Ethernet (RJ -45)
Modem Type: Integrated V.92/V.90 Modem (RJ-
11)
Wireless LAN: Atheros 802.11b/g/n Wireless
Network Connection(802.11b/g/n)
Bluetooth ® Technology: Integrated Stereo A2DP
Bluetooth® Technology
Power
Battery Type: Standard Capacity Lithium-ion
Battery (VGP-BPS13/S)
Estimated Battery Life: TBD hours Standard
Capacity Battery
TBD hours Large Capacity Battery
Power Requirements: 110W + 10%
Software
Operating System: Genuine Microsoft ® Windows
Vista®Home Premium - Bilingual (English / French)
Supplied Software: Microsoft® Works SE 9.0
The VAIO ® Software Experience: VAIO® Startup
Assistant
Click to Disc Editor - Import, Edit, Burn
VAIO® Movie Story - Simple Movie Creation
VAIO®
MusicBox - Music by Mood
VAIO® Media plus - Multimedia Streaming
Software
Service and Warranty Information
Limited Warranty: 1Year
Telephone Support: 1Year
Environmental Information
EPEAT™ : Meets Silver EPEAT™ Rating
RoHS®
: Compliant
Regulation and Standard Compliance
Energy Star ® Compliant: 4.0
Dimensions
Weight: 6.4 lbs (with standard battery)
Measurements: 15.1"(W) x 1.14-1.46"(H) x
10.3"(D)
Supplied Accessories
Standard Lithium-ion battery (VGP-BPS13/AS)
AC Adapter
15
9
3
14
11
11
12
7
7,8
Power Cable
O
ptional Accessories
Large Capacity Battery (VGP-BPL13)
Standard Capacity Battery (VGP-BPS13A/B)
AC Adapter (VGP-AC19V25)
Stick AC Adapter (VGP-AC19V21)
USB Port Replicator (VGP-
UPR1)
Neoprene Case (VGP-AMC7)
Ladies Leather Tote (VGP-
AML4)
Sport Messenger Bag (VGP- AMB10)
Bluetooth Laser Mouse (VGP-BMS33/W)
Color: Powder White
1.GHzdenotesmicroprocessorinternalclockspeed;otherfactorsmay
affectapplication performance. CPU speed will be reduced under
certain operating conditions.
2.GBmeansonebillionbytes when referring to hard drive capacity.
Accessiblecapacitymayvary.Aportionofharddisk space is
reservedasarecoverypartition.
3.Requires802.11ncompatibleaccesspoint.Somefunctionalitymay
requireInternet services, which may require a fee.
4.BroadbandInternetservicerequiredalongwiththirdpartyservices
whichmay require a subscription or other service fee.
5.DVDMedia/Formatsarenotuniversallycompatible.
6. Viewable area measured diagonally.
7.Non - metricweights and measures are approximate and mayvary.
8.Measuredatthenarrowestpoint
9.i.LINKisatrademark of Sony used only to designate that a product
containsanIEEE 1394 connector. All products with an i.LINK
connectormaynotcommunicatewitheachother.
10.TotalAvailableGraphics Memory refers to the new Windows Vista
classificationofgraphics memory, which varies depending on the
operatingcondition, version of device driver and system memory size.
11.Actualbatterylifemayvarybasedonproductsettings,usage
patternsand environmental conditions. Batterylifewill be shorter with
models equipped with Instant Mode features.
12.Seeactuallimitedwarrantyfordetails.
13.A portion of the systemmemoryover3GB may not be available to
theoperatingsystem.
14.Interoperability and compatibility among Bluetooth ® devicesvaries.
15. Requires high definition - capable display with HDMI ™ connector.
Imagequalitywill vary.
ComputerInterface:For this product,there are a multitude of varying
software packages and add - onhardwareoptions.Thisproductisnot
manufacturedtoworkwith any specific software, and Sony does not and
cannotmake any warranty orrepresentationwith respect to the
performanceofthisproductwithanyparticularsoftwarepackages
and/or non - Sony add - onhardwareoptionsexcept those mentioned here.
Sonyhereby disclaims anyrepresentationsorwarranties that this
product is compatible with any combination of non - Sonyproductsyou
maychoose to connect toit.WhileSony representatives or Sony
authorizeddealersmaybeabletoassist you and may make
recommendations,they are NOT authorizedtovary or waive this
disclaimer.Purchasers must determine for themselves the suitability and
compatibilityofthehardwareandsoftwareineachandeveryparticular
instance.Softwaretitles pre - installedon the Sony computer are subject
tochangewithoutnotice.Preinstalledsoftwaremaynotbeidenticalto
retailversionsorhave all documentation. Features and specifications are
subjecttochangewithout notice. This product meets the standards of the
InternationalEnergyStarProgramforenergyefficiency.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulateddueto environmental considerations. For disposal or
recyclinginformation,please contact your local authorities or the
Electronic Industries Alliance (www.eiae.org).
