Sony M-950 User manual

3-858-734-11(1)
Operating Instructions
MicrocassetteTM-
Corder
Sony Corporation 1996 Printed in Japan
M-950
English
As you read, refer to the illustrations in the Japanese corresponding text
(labeled with A, B, etc.)
zGetting Started
Inserting the Supplied Batteries
Into the main unit A
1Slide OPEN on the battery compartment in the direction of the arrow
to open the battery compartment lid.
2Insert one R03 (size AAA) battery (supplied) with correct polarity.
Note
Make sure that the battery is inserted with correct polarity. You may not be able to
distinguish between ‘and ’with some batteries.
3Close the lid until it clicks.
Into the speaker unit B
1Push and slide OPEN on the speaker unit in the direction of the arrow
as illustrated to open the battery compartment lid.
2Insert two R03 (size AAA) batteries (supplied) with correct polarity.
3Close the lid until it clicks.
To remove the batteries C
Remove them as illustrated.
Note
Do not mix a new battery with an old one nor use different types of batteries.
If the battery compartment lid is accidentally detached D
Attach it as illustrated.
Recording with the supplied Microphone M
Connect the supplied microphone to EAR/MIC. The built-in microphone
will be disconnected and the sound through the external microphone will
be recorded.
To start recording, insert a cassette and press rREC.
Recording with the connected equipment N
Notes (Before recording)
• When connecting cords, be sure you connect plugs firmly.
• Make a trial recording to make sure that you made connections correctly and
adjusted the volume properly.
• The following examples use Sony products. If you have any problem when using
other products, read the instruction manual of those products.
1Insert a cassette.
2Adjust the sound of the connected equipment.
3Press rREC.
To check the direction of the tape in the display window P
9FWD appears when recording on the upper side.
REV (appears when recording on the reverse side.
The indication will disappear about one minute after the tape starts
running. To display the indication, press pSTOP.
TAPE SPEED selector
2.4 cm: For optimum sound (recommended for normal use). A 60-minute
recording can be made using both sides of the MC60 microcassette.
1.2 cm: For longer recording time. A 120-minute recording can be made
using both sides of the MC60 microcassette.
Tape counter
While the upper side of the tape is running (9FWD appears in the display
window), the numbers in the tape counter increase. While the reverse side
is running (REV (appears in the display window), they decrease. Press
COUNTER RESET to return to 000.
To return the tape to the position of 000
Press COUNTER RESET for more than 2 seconds until ZERO STOP appears
in the display window. During rewind or REVIEW, the tape stops at 000.
Press COUNTER RESET to make the ZERO STOP indicator disappear.
Power Sources
Batteries
Battery life (Approx. hours)
Batteries Recording Recording Playback
without (when speaker (when speaker
speaker unit unit is installed*) unit is installed*)
Sony alkaline 5.5 22 24
LR03(SG)
Sony R03(SB) 1.5 10 11.5
* When one battery is installed in the main unit and two batteries are installed in the
speaker unit
We recommend to use long-life alkaline batteries.
When to replace the batteries Q
The battery indicator in the display window shows the remaining battery
power.
When the battery is used up, iappears in the display window. Replace all
the batteries (one battery in the main unit if the speaker is not installed)
with new ones.
Notes
• When you operate the unit after you have changed the batteries, idisappears and
appears in the display window.
• While the tape runs rapidly (fast forward or rewind), imay appear. Replace the
batteries only when the tape does not run properly.
• During playback, the battery indicator may temporarily flicker when you turn up the
volume.
• The tape will run for a while after iappears; however, a big noise may be heard
from the speaker or recording may not be made. When iappears, replace all the
batteries at once.
• At the beginning or end of the tape imay momentarily appear. If the indicator
disappears, you do not need to replace the batteries.
House current
1Connect the AC-E15L AC power adaptor (not supplied) to DC IN 1.5V of
the speaker.
2Connect the other end of the AC power adaptor to a wall outlet.
Note
Use the AC-E15L AC power adaptor.
Do not use any other AC power adaptor.
How to use the supplied carrying case R
Put the M-950 and the supplied accessories into the carrying case as
illustrated.
Releasing HOLD E
Unlock the unit before operating.
HOLD function O
This function locks the unit to prevent it from operating when you
accidentally press a button except VOR, COUNTER RESET, rREC and P
PAUSE. To lock the unit, slide HOLD Hin the direction of the arrow. The
Hindicator appears in the display window.
To prevent rREC and PPAUSE from pressing, slide the RECORD
PROTECT cover so that the buttons cannot be seen.
Installing the Speaker Unit F
1Attach the speaker unit to the main unit.
2Slide the speaker unit as illustrated until it clicks.
To remove the speaker unit G
1Keep holding both the main unit and the speaker unit with your both
hands, release the speaker lock.
2With the speaker locked released, remove the speaker unit straight out
from the main unit.
Notes
• When removing the speaker unit, make sure you are holding both the speaker
unit and the main unit firmly; otherwise, the speaker unit may drop out.
• Before removing the speaker unit, make sure the tape has stopped completely;
otherwise, noise may be heard or a tape may stop running.
zOperating the Unit
Recording
You can record right away with the built-in microphone, with or without
the speaker unit.
Inserting the cassette H
1Slide OPEN on the cassette compartment in the direction of the arrow
and open the lid.
2Take out any slack in the tape and insert the cassette with the side to
start recording facing the lid.
3Close the cassette compartment lid until it clicks.
Releasing VOR
Make sure that VOR L or VOR H is not displayed in the display window.
For normal recording, if VOR L or VOR H is displayed, make it disappear.
Refer to “VOR (Voice Operated Recording)”.
Start recording I
If you start recording from the upper side (9FWD appears in the display
window), recording automatically goes on to the reverse side (REV (
appears in the display window) and the unit turns off automatically when
the tape comes to the end of the reverse side. If the tab is removed,
however, you cannot record on that side.
1Slide the RECORD PROTECT cover so that rREC and PPAUSE
buttons appear.
2Press rREC.
While recording, the REC indicator lights and appears in the display
window.
To Press or slide
Stop recording pSTOP
Pause recording PPAUSE
To release pause recording, press rREC.
Take out a cassette Press pSTOP and slide OPEN on the cassette
compartment lid in the direction of arrow.
Notes
• Before taking out the cassette, make sure that the sound of the unit operating has
stopped.
• When earphones or an external microphone is connected to the EAR/MIC jack, the
built-in microphone does not work.
Playing a Tape
Inserting the cassette J
1Slide OPEN on the cassette compartment in the direction of the arrow
and open the lid.
2Take out any slack in the tape and insert the cassette with the side to
start playing facing the lid.
3Close the cassette compartment lid until it clicks.
REC
Start playback K
If the playback starts from the upper side (9FWD appears in the display
window), playback goes on to the reverse side (REV (appears in the
display window) and the unit turns off automatically.
1Press 9( PLAY/DIR.
2Adjust the volume using VOLUME.
To Press or slide
Stop playback pSTOP
Pause playback PPAUSE
To release pause playback, press 9( PLAY/
DIR*.
Fast forward** FF/CUE during stop
Rewind** REW/REVIEW during stop
Fast forward while listening FF/CUE during Playback
to the sound (CUE)
Rewind while listening to REW/REVIEW during playback
the sound (REVIEW)
Play the other side 9( PLAY/DIR
during playback
Play the other side pSTOP for more than 2 seconds
during stop
Take out a cassette Press pSTOP and slide OPEN in the
direction of arrow.
* The PPAUSE button is released automatically when the pSTOP button is pressed
(stop-pause-release function).
**The tape stops at the end of the tape and the power is turned off automatically
(automatic shut-off mechanism).
Note
Before taking out the cassette, make sure that the sound of the unit operating has
stopped.
Using Other Functions L
To select the side to be recorded
To record on both sides continuously
1Insert a cassette with the side to start recording facing the lid.
2Start recording on the upper side (9FWD appears in the display window).
If REV (is displayed, press pSTOP for more than 2 seconds to display
9FWD.
When recording reaches the end of the upper side, it will automatically
continue on the reverse side.
Notes
• Make sure the tabs on both sides are not removed.
• Even if only the tab on the reverse side is removed, recording cannot be made.
To Record on one side only
1Insert a cassette with the side to start recording facing away from the lid
(reverse side).
2Start recording on the reverse side (REV (appears in the display window).
If 9FWD is displayed, press pSTOP for more than 2 seconds to display
REV (.
When recording reaches the end of the reverse side, it will automatically stop.
Note
Make sure the tab on the reverse side is not removed.
VOR (Voice Operated Recording)
The VOR system works only while recording. Press VOR to display VOR L
or VOR H first and then press rREC. The unit automatically starts
recording the sound and pauses when there is no sound (you can save tapes
and batteries).
VOR L: To record for dictation in a noisy place.
VOR H: To record at meetings or in a quiet place.
When you use this system in a noisy place the unit stays in the recording
mode. If the sound is too soft, on the contrary, the unit will not start
recording. Press VOR to display VOR L (low) or VOR H (high) depending
on the conditions. When you do not use this function, press VOR during
recording until VOR L or VOR H disappears in the display window.
Notes
• The VOR system depends on the environment conditions. If you cannot get the
desired results, record without the VOR system.
• When using the VOR system, the unit starts recording only when a sound is
detected, therefore, the beginning of the word may not be recorded. For an
important recording, we recommend to recording without the VOR system.
• The VOR L or VOR H indicator appears during playback too.
Start recording during playback
Press rREC during playback, recording starts immediately. It is useful
when you want to re-record the portion which was just recorded.
Review the portion just recorded
Press REW/REVIEW during recording. Release the button at the point to
start playback.
Polarity of plug
