Sony PVM-2541 PVM-1741 PVM-740 LMD-2451W LMD-1751W LMD-4251TD LMD-2451TD LMD-2341W LMD-2041W LMD-1541W LMD-940W LMD-1530W LMD-2110W... User manual

LCD Monitor
Operating Instructions
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
LMD-4251TD
LMD-2451TD
4-198-688-13(1)
© 2010 Sony Corporation

2
Owner’s Record
The model and serial numbers are located at the rear.
Record these numbers in the spaces provided below.
Refer to these numbers whenever you call upon your
Sony dealer regarding this product.
Model No. ____________________
Serial No. ____________________
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the manufacturer's
instructions.
• Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete
outlet.
• Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
• Only use attachments/accessories specified by the
manufacturer.
• Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
• Unplug this apparatus during lightning storms or
when unused for long periods of time.
• Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
WARNING
To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel
only.
WARNING
THIS APPARATUS MUST BE EARTHED.
This apparatus is provided with a main switch on the
rear panel.
Install this apparatus so that user can access the main
switch easily.
WARNING
Make sure the surface is wide enough so that this
apparatus’s width and depth don’t exceed the surface’s
edges.
If not, this apparatus may lean or fall over and cause an
injury.
WARNING (For LMD-2451TD)
When installing the unit, incorporate a readily
accessible disconnect device in the fixed wiring, or
connect the power plug to an easily accessible socket-
outlet near the unit. If a fault should occur during
operation of the unit, operate the disconnect device to
switch the power supply off, or disconnect the power
plug.
CAUTION
The apparatus shall not be exposed to dripping or
splashing. No objects filled with liquids, such as vases,
shall be placed on the apparatus.
Important Safety Instructions
This symbol is intended to alert the user to
the presence of uninsulated “dangerous
voltage” within the product’s enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the
appliance.

3
Do not install the appliance in a confined space, such as
book case or built-in cabinet.
CAUTION
The unit is not disconnected from the AC power source
(mains) as long as it is connected to the wall outlet, even
if the unit itself has been turned off.
For kundene i Norge
Dette utstyret kan kobles til et IT-
strømfordelingssystem.
Apparatet må tilkoples jordet stikkontakt
Suomessa asuville asiakkaille
Laite on liitettävä suojamaadoituskoskettimilla
varustettuun pistorasiaan
För kunderna i Sverige
Apparaten skall anslutas till jordat uttag
For the customers in the U.S.A.
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference in
which case the user will be required to correct the
interference at his own expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital
device pursuant to Subpart B of Part 15 of FCC Rules.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
WARNING:
Using this unit at a voltage other than 120 V may require
the use of a different line cord or attachment plug, or
both. To reduce the risk of fire or electric shock, refer
servicing to qualified service personnel.
When installing the installation space must be secured in
consideration of the ventilation and service operation.
• Do not block the ventilation holes at the top side and
bottom side.
• Leave a space around the unit for ventilation.
• Leave more than 15 cm of space in the rear of the unit
to secure the operation area.
When the unit is installed on the desk or the like, leave
at least 10 cm (for LMD-4251TD)/4.4 cm (for LMD-
2451TD) of space in the top and bottom sides. Leaving
15 cm or more of space in the rear of the unit is
recommended for service operation.
For the customers in Canada
This Class A digital apparatus complies with Canadian
ICES-003.
For the customers in Europe
This product with the CE marking complies with the
EMC Directive issued by the Commission of the
European Community.
Compliance with this directive implies conformity to the
following European standards:
• EN55103-1 : Electromagnetic Interference
(Emission)
• EN55103-2 : Electromagnetic Susceptibility
(Immunity)
This product is intended for use in the following
Electromagnetic Environments:
E1 (residential), E2 (commercial and light industrial),
E3 (urban outdoors), E4 (controlled EMC environment,
ex. TV studio).
For the customers in Europe
The manufacturer of this product is Sony Corporation,
1-7-1 Konan, Minato-ku, Tokyo, 108-0075 Japan.
The Authorized Representative for EMC and product
safety is Sony Deutschland GmbH, Hedelfinger Strasse
61, 70327 Stuttgart, Germany.
For the customers in the USA
Lamp in this product contains mercury. Disposal of
these materials may be regulated due to environmental
considerations. For disposal or recycling information,
please contact your local authorities or the
Telecommunications Industry Association
(www.eiae.org).

Table of Contents
4
Table of Contents
Precaution .............................................................. 5
On Safety ............................................................ 5
On Installation .................................................... 5
Handling the LCD Screen .................................. 5
On Burn-in ......................................................... 5
On a Long Period of Use .................................... 5
Handling the 3D Glasses .................................... 6
About the Fluorescent Tube ............................... 6
On Cleaning ....................................................... 6
On Moisture Condensation ................................ 6
On Repacking ..................................................... 6
On Fan Error (For LMD-2451TD) ..................... 7
Features .................................................................. 7
Location and Function of Parts and
Controls ................................................................ 10
Front Panel ....................................................... 10
Input Signals and Adjustable/Setting Items ..... 13
3D Input Signals and Adjustable/
Setting Items .................................................. 14
Side Panel (LMD-4251TD)
Rear Panel (LMD-2451TD) ........................... 15
Adjusting the Height of the Stand
(LMD-2451TD) .................................................... 17
Connecting the AC Power Cord ......................... 18
Installing the Input Adaptor .............................. 19
Attaching the Provided L/R Labels .................. 19
Selecting the Default Settings ............................. 20
Selecting the Menu Language ............................ 21
Using the Menu .................................................... 22
Adjustment Using the Menus ............................. 24
Items ................................................................. 24
Adjusting and Changing the Settings ............... 25
STATUS menu............................................. 25
COLOR TEMP/SPACE menu..................... 25
USER CONTROL menu.............................. 26
USER CONFIG menu.................................. 28
REMOTE menu ........................................... 37
KEY INHIBIT menu.................................... 38
Troubleshooting ................................................... 39
Specifications ....................................................... 39
Dimensions ........................................................... 44
3D Viewing Angle (vertical) ................................ 45

Precaution 5
Precaution
On Safety
• Operate the unit only with a power source as specified
in the “Specifications” section.
• A nameplate indicating operating voltage, etc., is
located on the rear panel.
• Should any solid object or liquid fall into the cabinet,
unplug the unit and have it checked by qualified
personnel before operating it any further.
• Do not drop or place heavy objects on the power cord.
If the power cord is damaged, turn off the power
immediately. It is dangerous to use the unit with a
damaged power cord.
• Unplug the unit from the wall outlet if it is not to be
used for several days or more.
• Disconnect the power cord from the AC outlet by
grasping the plug, not by pulling the cord.
• The socket-outlet shall be installed near the equipment
and shall be easily accessible.
• Do not use the 3D glasses as sunglasses.
• Do not use the 3D glasses as eye protection.
• Do not use the 3D glasses as welding glasses.
• Do not drive while wearing the 3D glasses.
• Take regular breaks between watching 3D video
images.
• Be careful not to pinch your fingers in the hinges of
the 3D glasses when moving the temple frames.
On Installation
• Allow adequate air circulation to prevent internal heat
build-up.
Do not place the unit on surfaces (rugs, blankets, etc.)
or near materials (curtains, draperies) that may block
the ventilation holes.
• Do not install the unit in a location near heat sources
such as radiators or air ducts, or in a place subject to
direct sunlight, excessive dust, mechanical vibration
or shock.
For LMD-4251TD
• To prevent injuries or accidents that might occur as a
result of the monitor falling over, be sure to use a
dedicated monitor stand when placing it on the table or
the floor. For details on the stand, please contact your
Sony dealer.
• Consult with Sony qualified personnel for installation.
Handling the LCD Screen
• The LCD panel fitted to this unit is manufactured with
high precision technology, giving a functioning pixel
ratio of at least 99.99%. Thus a very small proportion
of pixels may be “stuck”, either always off (black),
always on (red, green, or blue), or flashing. In
addition, over a long period of use, because of the
physical characteristics of the liquid crystal display,
such “stuck” pixels may appear spontaneously. These
problems are not a malfunction.
• Do not leave the LCD screen facing the sun as it can
damage the LCD screen. Take care when you place
the unit by a window.
• Do not push or scratch the LCD monitor’s screen. Do
not place a heavy object on the LCD monitor’s screen.
This may cause the screen to lose uniformity.
• If the unit is used in a cold place, horizontal lines or a
residual image may appear on the screen. This is not
a malfunction. When the monitor becomes warm, the
screen returns to normal.
• The screen and the cabinet become warm during
operation. This is not a malfunction.
On Burn-in
For LCD panel, permanent burn-in may occur if still
images are displayed in the same position on the screen
continuously, or repeatedly over extended periods.
Images that may cause burn-in
• Masked images with aspect ratios other than 16:9
(LMD-4251TD)
• Masked images with aspect ratios other than 16:10
(LMD-2451TD)
• Color bars or images that remain static for a long time
• Character or message displays that indicate settings or
the operating state
To reduce the risk of burn-in
• Turn off the character displays
Press the MENU button to turn off the character
displays. To turn off the character displays of the
connected equipment, operate the connected
equipment accordingly. For details, refer to the
operation manual of the connected equipment.
• Turn off the power when not in use
Turn off the power if the viewfinder is not to be used
for a prolonged period of time.
On a Long Period of Use
Due to the characteristics of LCD panel, displaying
static images for extended periods, or using the unit
repeatedly in a high temperature/high humidity

Precaution
6
environments may cause image smearing, burn-in, areas
of which brightness is permanently changed, lines, or a
decrease in overall brightness.
In particular, continued display of an image smaller than
the monitor screen, such as in a different aspect ratio,
may shorten the life of the unit.
Avoid displaying a still image for an extended period, or
using the unit repeatedly in a high temperature/high
humidity environment such an airtight room, or around
the outlet of an air conditioner.
To prevent any of the above issues, we recommend
reducing brightness slightly, and to turn off the power
whenever the unit is not in use.
Handling the 3D Glasses
• Do not touch the lens surface of the 3D glasses.
• Do not leave the 3D glasses in ambient high-
temperature, such as near heating equipment or inside
a car.
• Do not put extra pressure on the 3D glasses to avoid
them becoming misshapen.
• Make sure hard accessories or buckles not to touch the
lens surface of 3D glasses while holding or
transporting.
• Avoid wearing the 3D glasses when they are aging,
breaking or being damaged. Tiny scratches on the lens
surface may interfere with your viewing enjoyment.
Laying down or looking away from the screen will
lessen the 3D effect or shifts image colors.
About the Fluorescent Tube
A specially designed fluorescent tube is installed as the
lighting apparatus for this unit. If the LCD screen
becomes dark, unstable or does not turn on, consult your
Sony dealer.
On Cleaning
Before cleaning
Be sure to disconnect the AC power cord from the AC
outlet.
On cleaning the monitor screen and lens of 3D
glasses
While the monitor screen surface is especially treated to
reduce light reflections, the lenses of the 3D glasses are
also specially finished. As incorrect maintenance may
impair their performance, take care with respect to the
following:
• Wipe the screen and lens gently with a soft cloth such
as a cleaning cloth or glass cleaning cloth.
• Stubborn stains on the screen may be removed with a
soft cloth such as a cleaning cloth or glass cleaning
cloth lightly dampened with water. To remove
stubborn stains on the lens of the 3D glasses, rinse the
lens by hand with water and dry the lens gently with a
soft cloth.
• Never use solvent such as alcohol, benzene or thinner,
or acid, alkaline or abrasive detergent, or chemical
cleaning cloth, as they will damage the surface.
On cleaning the monitor cabinet and 3D
glasses frames
• Clean the cabinet and frames gently with a soft dry
cloth. Stubborn stains may be removed with a cloth
lightly dampened with mild detergent solution,
followed by wiping with a soft dry cloth.
• Use of alcohol, benzene, thinner or insecticide may
damage the finish of the cabinet and frames or remove
the indications on the cabinet. Do not use these
chemicals.
• If you rub on the cabinet and frames with a stained
cloth, they may be scratched.
• If the cabinet and frames are in contact with a rubber
or vinyl resin product for a long period of time, the
finish of them may deteriorate or the coating may
come off.
On Moisture Condensation
If the unit is brought directly from a cold place to a warm
place, or the unit is warm and the ambient temperature
cools suddenly (by air-conditioning, for example),
moisture may condense on the surface or inside of the
unit, or create a mist residue inside the protection plate.
This is called moisture condensation, and is not a
malfunction of the product itself, although it may cause
damage to the unit.
Leave the unit in a condensation free area.
If moisture condensation has occurred, turn off the unit
and do not use it until moisture condensation has
evaporated.
On Repacking
Do not throw away the carton and packing materials.
They make an ideal container which to transport the
unit.

Features 7
On Fan Error (For LMD-2451TD)
The fan for cooling the unit is built in. When the fan
stops and the RETURN button on the front panel blinks
for fan error indication, turn off the power and contact an
authorized Sony dealer.
Features
The LMD-4251TD (42-type) or LMD-2451TD (24-
type) is a multiple format LCD monitor equipped with a
circular micro-polarizer filter for broadcast use,
featuring a precise image and high performance. It
supports various 3D signal formats, including dual-
stream HD-SDI signals, by using an optional input
adaptor (BKM-250TG with a serial number 7400001 or
later) for both 2D and 3D signals. The provided two
pairs of 3D glasses are designed to suit the performance
of the monitor and for comfort over long hours of use.
The monitor has a number of new features for 3D picture
production, as well as various features supporting 2D
picture production.
Circular micro-polarizer filter
Two input signals are separated into even lines and odd
lines on the display and circular polarized before
appearing on the screen. Images on the left of the screen
are viewed through left lens of the 3D glasses and those
on the right are viewed through right lens. With this
feature, you can monitor multiple screens at one time.
Comfortable fitting lightweight 3D glasses
The provided 3D glasses are a lightweight design for
reduced fatigue after extended periods of use. The
glasses provide precise image quality and accurate color
reproduction. The frames are made of flexible material
and the lenses are encased in the top-center part of the
frames. This helps the glasses fit any face shape and
avoids distorting images through the lenses even when
adjusting the temple frames. Additionally, nose pad and
temple tips hold the glasses firmly under sweaty
conditions or physical working environment. Optional
3D glasses are available in two types; BKM-30G for
additional viewers and BKM-31G for eyeglasses users.
BKM-31G is lightweight, and includes flip-up lenses. It
can be directly attached to your eyeglasses.
Supporting various 3D input signal formats
With BKM-250TG (optional), various signals, such as
3G, dual-stream, side-by-side and line-by-line, are
supported. Install BKM-250TG with a serial number
7400001 or later to display HD-SDI signal in 3D. While
multiple signal formats–including 1080P, 1080i,
1080PsF and 720P–are available, line-by-line-type DVI
signals are also supported.
In addition, non-compressed horizontal resolution side-
by-side-type signals are supported. (Software versions
1.1 or later)
Select 720P scan size
NORMAL or NATIVE scan size can be selected when a
720P signal is input. (Software versions 1.1 or later, and
BKM-250TG with a serial number 7400001 or later)
About this manual
The instructions in this manual are for the following
two models:
• LMD-4251TD
• LMD-2451TD
The illustration of LMD-2451TD is used for the
explanations.
Any differences in specifications are clearly indicated
in the text.

Features
8
Luminance difference display
Luminance difference between the left and right signals
is displayed. This function is convenient to check the
disparity. (Software versions 1.1 or later, and BKM-
250TG with a serial number 7400001 or later)
Checkerboard
Left and right HD-SDI input signals are displayed in a
grid pattern. The two signals shown in a grid makes for
easy adjusting of the iris and color settings for the
camera. This function is only available in 2D display
mode.
L/R switch
Left and right dual-stream HD-SDI signals can be
swapped over without being visually disturbed by black
frames. This allows you to easily compare the color and
brightness between left and right signals. This function
is only available in 2D display mode.
The automatic switch of left and right signals function is
supported. The switching interval can be selected from
among SHORT, MEDIUM and LONG. (Software
versions 1.1 or later, and BKM-250TG with a serial
number 7400001 or later)
White balance offset for 3D
You can set to match the white balance for 2D and 3D
images (with glasses). Also you can set to switch the
white balance automatically when selecting 2D or 3D
display. (Software versions 1.1 or later)
Grid display function
A grid (vertical and horizontal lines) can be displayed on
the entire screen. The vertical lines are used when
checking the overall image disparity. Both the vertical
and horizontal lines are used to check the geometrical
mismatch of left and right images. (Software versions
1.1 or later, and BKM-250TG with a serial number
7400001 or later)
Disparity ruler
Two vertical lines can be displayed for measuring the
disparity value of specific subjects. (Software versions
1.1 or later, and BKM-250TG with a serial number
7400001 or later)
Virtual subject marker
Use the virtual subject marker for planning the subject
position. A square marker is displayed as a pseudo-3D
subject marker. The position and screen depth of the
marker can be adjusted for planning the real subject’s
placement. The size of the square marker can also be
adjusted. (Software versions 1.1 or later, and BKM-
250TG with a serial number 7400001 or later)
Disparity simulation
The phase of either or both left and right signal for 3D
image can shift horizontally. The monitor simulates
parallax without the need for 3D rig adjustment. It saves
time and effort in setting and adjusting the 3D rig and
equipment.
Notes
• Going out of the disparity simulation feature
initializes the parallax setting. Adjust 3D rig if
parallax needs to be changed.
• Simulated images cannot be output to any device.
Horopter check
Left/right signals for the 3D image are displayed in
selected single colors. This helps you define if the
subjects are in front of the determined screen position or
behind it. You can carefully adjust the depth of the 3D
effect using this feature. This function is only available
in 3D display mode.
Flip H
If a half mirror type rig is used, left or right signal will
be reversed. With the Flip H feature, signals that are shot
this way are horizontally reversed again for normal
viewing.
Note
A delay between left and right signals occurs as a result
of the signal processing. Because left and right signals
are internally synchronized to offset the delay, display
speed may decrease before the image reaches the screen.
Payload ID
Channel assign information of payload ID data
superimposed on input signals is displayed. You can
monitor which of two channels a left/right input signal
is assigned to.
Dual time code display
The time codes for the both left and right signals are
displayed. When the time codes are out of sync, due to
incorrect VTR settings, etc., and the time code lag is
more than one frame, the time code on the right of the
screen is displayed with the black and white inverted.
(Software versions 1.1 or later, and BKM-250TG with a
serial number 7400001 or later)
High brightness LCD panel
Because of precise image, wide viewing angle
technology and high speed response, real color image
can be reproduced.
Multi-format
The monitor supports the video, Y/C, RGB, component,
SDI (3G/HD/SD, when the optional input adaptor is
used) signals and NTSC/PAL color systems.
SDI supports not only HD-SDI and SD-SDI, but also
3G-SDI, which transmits twice as much data as HD-SDI
with a Single-link.

Features 9
HD15 (analog) and DVI-D (digital) connectors are
equipped for the PC input.
For more information, see “Available signal formats”
on page 41.
Expandable input capability
The input connector configuration can be easily
modified by installing the optional input adaptor into the
optional input port. Up to two adaptors can be installed.
For more information, see “Available signal formats”
on page 41.
External remote function
The input signal is selected or various items are adjusted
by use of the serial (Ethernet) remote function. Up to 32
monitors and control units (max. 4) can be connected by
the Ethernet (10BASE-T/100BASE-TX) connection
and controlled remotely on the network. You can
control individual monitors or monitor groups simply by
entering the monitor ID or group ID number. You can
also execute the same operation on all connected
monitors, or put all connected monitors into the same
setup and adjustment state.
For more information, see SERIAL REMOTE of
REMOTE menu on page 37.
Refer to the Operation Manual of the BKM-15R Monitor
Control Unit.
Monitor stand with tilt function (LMD-2451TD)
The monitor comes equipped with a monitor stand with
tilt function.
You can select the height of the monitor by adjusting the
height.
For more information, see “Adjusting the Height of the
Stand (LMD-2451TD)” on page 17.
Mount function
LMD-4251TD is compatible with the VESA 400 × 400
mounting.
LMD-2451TD supports the VESA (100 × 100)
standard.
Two-display
Two kinds of input signals are put on the monitor.
For more information, see MULTI DISPLAY of MULTI
DISPLAY SETTING on page 30.
Input signal waveform and audio level display
(LMD-2451TD)
The waveform of the input signal or the audio level
(embedded audio only) is displayed as the sub display.
For more information, see SUB INPUT SELECT and
waveform of MULTI DISPLAY SETTING on page 30.
Closed caption
The closed caption conforming to the EIA608 standard
is displayed.
The EIA/CEA-608 and EIA/CEA-708 standard closed
caption signals superimposed on an SDI signal are
displayed by installing the optional input adaptor.
Auto chroma/phase function
The chroma and phase of the decoder are automatically
adjusted with the auto chroma/phase function.
Blue only mode
In the blue only mode, a monochrome display is
obtained with all three of the R/G/B picture elements
driven with a blue signal. This mode is convenient for
chroma and phase adjustments and monitoring of signal
noise.
H/V delay mode
The horizontal and vertical sync signals can be
monitored simultaneously. This mode cannot be
activated when 3D images are displayed on the screen.
Select marker/scan display
Various items for broadcast use can be displayed. The
center marker, safe area marker, aspect marker or
display size (scan), etc are displayed by selecting
according to use.
For more information, see MARKER SETTING on
page 30 and SCAN of SYSTEM SETTING on page 28.
APA (Auto Pixel Alignment) function
For the signal input to the HD15 input connector, you
can adjust the picture to the appropriate size simply by
pressing the button assigned as the APA function.
Select color temperature mode
You can select the color temperature from among two
(9300 K, 6500 K) settings.
Color space function
You can select one from among three color space
settings (SMPTE-C/EBU/ITU-R BT.709).
On-screen menus
You can set the appropriate settings according to the
connected system by using the on-screen menus.
Select language display
You can select from seven display languages, English,
French, German, Spanish, Italian, Japanese and
Chinese.
Key inhibit function
You can inhibit a key function to prevent missing an
operation.

Location and Function of Parts and Controls
10
Location and Function of Parts and Controls
Front Panel
COMPOSITE
COMPONENT
Y/C
RGB
A-1
A-2
B-1
B-2
DVI
F1
F2
F3
F4
HD15
–
+
–
+
–
+
–
+
–
+
–
+
5
qa
qs qf
4
6
7
8
9
0
3
2
1
qd
1
CONTROL
VOLUME
CONTRAST
PHASE
CHROMA
BRIGHT
MENU
ENTER
RETURN
Y/C
A-1
A-2
B-1
B-2
F1
F2
F3
F4
RGB
COMPOSITE
COMPONENT
DVI
HD15
5
4
6
7
8
9
3
2
0
qa
q
s
LMD-2451TD
LMD-4251TD

Location and Function of Parts and Controls 11
a1(standby) switch and indicator
Press the switch to turn on the power in standby mode
(the power switch on the rear panel is turned on). The
indicator lights in green. Pressing the switch again sets
the monitor in standby mode and the indicator lights in
red.
b-(key inhibit) indicator
Lights in red when KEY INHIBIT in the KEY INHIBIT
menu is set to ON.
cCONTROL button
Press to display the buttons on the front panel. Press
again to clear the display.
dVOLUME buttons
Press the + button to increase the volume or the – button
to decrease it.
eCONTRAST buttons
Press the + button to make the contrast higher or the –
button to make it lower.
fPHASE buttons
Press the + button to make the skin tones greenish or the
– button to make them purplish.
gCHROMA buttons
Press the + button to increase the color intensity or the –
button to decrease it.
hBRIGHT (brightness) buttons
Press the + button to increase the brightness or the –
button to decrease it.
iMenu operation buttons
Displays or sets the on-screen menu.
MENU button
Press to display the on-screen menu.
Press again to clear the menu.
+/– buttons
Press to select the items and setting values.
ENTER button
Press to confirm a selected item on the menu.
When the menu is not displayed and the button is
pressed, the distinguished signal format is displayed.
RETURN button
When the menu is displayed and the button is pressed,
the value of an item is reset to the previous value.
When the menu is not displayed and the button is
pressed, the function selected in FUNCTION
BUTTON SETTING of the USER CONFIG menu is
displayed on the side of the F1 to F4 button. Also,
when the fan stops (LMD-2451TD), this button
blinks.
jInput select buttons
Press to monitor the signal input to each connector.
A-1, A-2, B-1 and B-2 buttons are used when an
optional input adaptor has been installed in the option
port.
COMPOSITE button: to monitor the signal through
the COMPOSITE IN connector
Y/C button: to monitor the signal through the Y/C IN
connector
RGB button: to monitor the RGB signal through the
connectors for the R/G/B signal input
COMPONENT button: to monitor the component
signal through the connectors for Y/PB/PRsignal input
A-1 button: to monitor the signal from connector 1
(the connectors for the R/G/B signal input in BKM-
229X) of the input adaptor installed to the option port
A
A-2 button: to monitor the signal from connector 2
(the connectors for Y/PB/PRsignal input in BKM-
229X) of the input adaptor installed to the option port
A
B-1 button: to monitor the signal from connector 1
(the connectors for the R/G/B signal input in BKM-
229X) of the input adaptor installed to the option port
B
B-2 button: to monitor the signal from connector 2
(the connectors for Y/PB/PRsignal input in BKM-
229X) of the input adaptor installed to the option port
B
HD15 button: to monitor the signal through the
HD15 input connector
DVI button: to monitor the signal through the DVI-D
input connector
kFunction buttons
You can turn the assigned function on or off.
The factory setting is as follows;
F1 button: EXT SYNC
F2 button: SCAN
F3 button: ASPECT
F4 button: H/V DELAY
You can assign the function from among SCAN,
ASPECT, EXT SYNC, I/P MODE, MULTI DISPLAY,
CLOSED CAPTION, MONO, H/V DELAY,
MARKER, APA, BLUE ONLY, 2D/3D SELECT,
CHECKERBOARD, L/R SWITCH, HOROPTER
CHECK, DISPARITY SIM., GRID, DISPARITY
RULER, AUTO L/R SW, DIFFERENCE and
VIRTUAL SUB. MAR. in FUNCTION BUTTON
SETTING of the USER CONFIG menu (see page 31).
For details of the function assigned to the function
button, see page 31.
lSpeakers
The audio signal which is selected by the input select
button is output.

Location and Function of Parts and Controls
12
When BKM-220D/243HS/244CC/250TG is not
installed, the audio signal which is selected in INPUT
SELECT of the USER CONFIG menu is output (see
page 34).
When BKM-220D/243HS/244CC/250TG is installed,
the audio signal of the channel which is selected in
OPTION AUDIO SETTING of the USER CONFIG
menu is output (see page 34).
The audio signals from the speakers are output from the
AUDIO L/R OUT connector on the rear (see page 16).
mTally lamp (LMD-2451TD only)
You can check the status of the monitor by the color of
the tally lamp.
The tally lamp lights in red, green or amber according to
the setting of PARALLEL REMOTE in the REMOTE
menu.
nStand (LMD-2451TD only)
LMD-2451TD comes equipped with a stand. You can
adjust the height of the monitor (see page 17).

Location and Function of Parts and Controls 13
Input Signals and Adjustable/Setting Items
a: Adjustable/can be set
×: Not adjustable/cannot be set
Input signal
Item Video*3,
Y/C*3
B & W*3Component*4RGB*4SDI Computer 3D
SD HD SD HD SD*5HD*63G*11 DVI HD15 HD-SDI
*12, *13
DVI*13
CONTRAST*1a a aaaaaaaaaaa
BRIGHT*1a a aaaaaaaaaaa
CHROMA*1a×aa
×× aaaaa a a
PHASE*1a
(NTSC) × × ××× × × × aa ×a
APERTURE a a aaaaaaaaaaa
COLOR TEMP a a aaaaaaaaaaa
COLOR SPACE a a aaaaaaaaaaa
AUTO CHROMA/
PHASE a×aa
××××××× × ×
ACC a× × ××× × × × × × × ×
CTI a×a××× × × × × × × ×
V SHARPNESS aa a
×a×a×××× × ×
MATRIX*2××a××× × × × × × × ×
COMPONENT
LEVEL ××a
(480/60I) ××× × × × × × × ×
NTSC SETUP a
(NTSC)
a
(480/60I) × ××× × × × × × × ×
SCAN a a a aaaaaa
×× × ×
ASPECT aa a
×a×a×××× × ×
MARKER a a a aaaaaa
×× a×
BLUE ONLY a×a aaaaaa
×× a×
MONO a×aa
×× aaa ×× a×
H/V DELAY a a a aaaaaa
×× × ×
APA × × × ××× × × × × a××
SIZE × × × ××× × × × × a××
SHIFT a a a aaaaaa
×a××
PITCH × × × ××× × × × × a××
DOT PHASE × × × ××× × × × × a××
POWER SAVING a a aaaaaaaaaaa
I/P MODE*7aa aaaaaa
××× × ×
MULTI DISPLAY a a a aaaaaa
a*9a*9a*15 a*9
CLOSED CAPTION a*8a*8× ×××a*10 a*10 ××× × ×
3D SETTING × × × ××× × × × × × a*14 ×

Location and Function of Parts and Controls
14
*1 Adjustment of SUB CONTROL is the same.
*2 When a component signal (480/60I or 480/60P) is input and
the COMPONENT LEVEL is set to SMPTE, this can be
switchable.
*3 When a BKM-227W is installed, the number of the input
connector is increased.
*4 When a BKM-229X is installed, the number of the input
connector is increased.
*5 When a BKM-220D, BKM-243HS, BKM-244CC or BKM-
250TG is installed, the signal is input.
*6 When a BKM-243HS, BKM-244CC or BKM-250TG is
installed, the signal is input.
*7 Only the interlace signal is input.
*8 When an NTSC signal is input, closed captions are
displayed. Not displayed when any of the format display,
marker display, or multi display is set to ON (see FORMAT
DISPLAY on page 29, MARKER ENABLE on page 30, and
MULTI DISPLAY ENABLE on page 30).
*9 The signal can only be selected in the main display (see SUB
INPUT SELECT on page 31).
*10 When a BKM-244CC is installed, closed captions are
displayed.
*11 When a BKM-250TG is installed, the signal is input.
*12 When a BKM-250TG that has a serial number 7400001 or
later is installed, the signal is input.
*13 3D display mode is available when selecting 3D in 2D/3D
SELECT.
*14 For details about adjustable items, see “3D Input Signals and
Adjustable/Setting Items”.
*15 Displays in 2D display mode when selecting SIDE BY
SIDE in MULTI DISPLAY.
3D Input Signals and Adjustable/Setting Items
a: Adjustable/can be set
×: Not adjustable/cannot be set
*16 Available when selecting 2D in 2D/3D SELECT.
*17 Not available when NORMAL is selected in 720P SCAN.
*18 GRID and DISPARITY RULER cannot be used
simultaneously.
Item 3D input signal
3G-B Dual-stream Sequential Side-by-side 1 Side-by-side 2 Line-by-line DVI
2D/3D SELECT aaaaaaa
DISPARITY SIM. a*17 a*17 ×a*17 a*17 ××
HOROPTER CHECK a*17 a*17 ×××××
FLIP H aa×××××
CHECKERBOARD a*16 a*16 ×aa××
L/R SWITCH a*16 a*16 ×××××
AUTO L/R SW a*16 a*16 ×××××
PAYLOAD ID ×a×××××
720P SCAN aa×a×××
GRID*18 aaaaaa×
DISPARITY
RULER*18
aaaaaa×
DIFFERENCE a*16 a*16 ×aa××
GRID/RULER
INTENSITY
aaaaaa×
VIRTUAL SUB. MAR. a*17 a*17 ×××××

Location and Function of Parts and Controls 15
Side Panel (LMD-4251TD)
Rear Panel (LMD-2451TD)
PARALLEL
REMOTE
DVI- D
HD15
OPTION B
IN G/Y OUT
IN B/PBOUT
IN R/PROUT
IN EXT
SYNC OUT
IN AUDIO
ROUT
IN Y/C OUT
IN
COMPOSITE
OUT
SERIAL REMOTE
OPTION A
1
2
qa
9
0
6
7
8
4
qd
qs
qf
qg
qh
qj
5
qk
+
–
54 6 7 8 9 0
123
qd
qf qg qh qj qk
qa qs
LMD-4251TD
LMD-2451TD

Location and Function of Parts and Controls
16
aa/?(power) switch (LMD-4251TD)
Power switch (LMD-2451TD)
The power is turned on or off.
The monitor is turned on by pressing side ?.
bAC IN socket
Connect the supplied AC power cord.
c24V connector (LMD-2451TD only)
Plug the DC 24V power supply to this connector to
provide power to the monitor.
Note
Be sure to connect to a power supply of the specified
voltage value.
dAUDIO L/R IN connectors (phono jack)
Connect to the audio outputs of a VCR or to an audio
mixer.
eCOMPOSITE IN connector (BNC)
Input connector for composite signals.
fY/C IN connector (4-pin mini-DIN)
Input connector for Y/C signals.
gG/Y IN connector (BNC)
Input connector for G of RGB signals and component Y
(luminance) signals.
hB/PBIN connector (BNC)
Input connector for B of RGB signals and PB(blue color
difference) of component signals.
iR/PRIN connector (BNC)
Input connector for R of RGB signals and PR(red color
difference) of component signals.
jEXT SYNC IN/OUT (external sync) connectors
(BNC)
To use the external sync signal, press the function button
that EXT SYNC is assigned (F1 button at the factory
setting).
IN connector
When this unit operates on an external sync signal,
connect the reference signal from a sync generator
to this connector.
Note
When inputting a video signal with the jitters, etc.
the picture may be disturbed. We recommend using
the TBC (time base corrector).
OUT connector
Loop-through output of the IN connector. Connect
to the external sync input of video equipment to be
synchronized with this unit.
When the cable is connected to this connector, the
75-ohm termination of the input is automatically
released, and the signal input to the IN connector is
output from this connector.
kAUDIO L/R OUT connectors (phono jack)
Outputs the audio signal which is selected by the input
select button on the front panel.
When BKM-220D/243HS/244CC/250TG is not
installed, output the audio signal which is selected in
INPUT SELECT of the USER CONFIG menu (see
page 34).
When BKM-220D/243HS/244CC/250TG is installed,
output the audio signal of the channel which is selected
in OPTION AUDIO SETTING of the USER CONFIG
menu (see page 34).
The audio signal from this connector is monitored on the
front speakers (see page 11).
lLoop-through output connectors
Outputs the signals input to the input connectors (5to
9). Connect to the analog input (composite, Y/C,
analog component or analog RGB) of equipment,
according to the input signal.
mOptional input port
An optional input adaptor can be installed according to
your system configuration (see page 19).
LMD-4251TD has port A on the upper side and port B
on the lower. LMD-2451TD has port A on the left side
and port B on the right.
Press the A-1, A-2, B-1 or B-2 button to select the
signal.
nPARALLEL REMOTE connector (modular
connector, 8-pin)
Forms a parallel switch and controls the monitor
externally.
For details on the pin assignment and factory setting
function assigned to each pin, see page 41.
CAUTION
For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to this
port. Follow the instructions for this port.
oSERIAL REMOTE connector (RJ-45)
Connect to the network or Sony BKM-15R Monitor
Control Unit by using a 10BASE-T/100BASE-TX LAN
cable (shielded type, optional).
For details, refer to the Interface Manual for
Programmers (saved in the supplied CD-ROM,
Japanese and English only.)

Adjusting the Height of the Stand (LMD-2451TD) 17
CAUTION
• When you connect the optional LAN cable of the unit
to peripheral device, use a shielded-type cable to
prevent malfunction due to radiation noise.
• For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to this
port. Follow the instructions for this port.
• The connection speed may be affected by the network
system. This unit does not guarantee the
communication speed or quality of 10BASE-T/
100BASE-TX.
pSERIAL REMOTE RS-232C connector (D-sub
9-pin, female)
Connect to the RS-232C control connector on external
equipment connected to the monitor. The monitor can
be operated according to control commands sent from
external equipment connected to it.
For details on the pin assignment and factory setting
function assigned to each pin, see page 41.
For details, refer to the Interface Manual for
Programmers (saved in the supplied CD-ROM,
Japanese and English only.)
qDVI-D input connector (DVI-D)
Inputs DVI Rev.1.0 applicable digital RGB signal.
To view the signals of the SXGA and higher resolution
when the DVI input is selected, use the cable within 3 m
(118 1/8 inches) in length.
rHD15 input connector (D-sub 15-pin, female)
Inputs an analog RGB video signal (0.7 Vp-p, positive
polarity) and sync signal.
The Plug & Play function corresponds to DDC2B.
Adjusting the Height of
the Stand (LMD-2451TD)
LMD-2451TD comes equipped with a stand.
You can adjust the height of the monitor in three levels
by changing the position of the stand attachment bracket
and the arm attachment position. Depending on the
height, you can install the input adaptor with the stand
attached to the monitor.
A and B in the following list indicate the screw holes
shown in the illustrations in steps 2and 4.
Height of the monitor
Unit: mm (inches)
1) You can install the input adaptor with the stand attached to the
monitor.
2) Default setting
3) You cannot attach the stand in combinations of these positions.
1 Remove the stand attachment bracket (see
page 18).
2 Attach the stand attachment bracket to the A or B
screw holes.
The bracket is attached to the B holes at the factory.
3 Attach the stand attachment bracket with four
screws.
Use the screws removed in step 1.
Position of the
stand attachment
bracket
AA B B
Arm attachment
position
BA B A
LMD-2451TD – 3) 430.5
(17)
471.6 1)
(18 5/8)
497.9 1), 2)
(19 5/8)
+
–
A A
AA
BB
BB
AA
A: Screw holes for low position
B: Screw holes for high position

Connecting the AC Power Cord
18
4 Attach the arm.
5 Secure the arm with four screws.
Use the screws removed in step 1.
6 Attach the arm cover.
To remove the stand attachment bracket
1 Put the monitor on a soft cloth with the surface of
the LCD monitor downward.
2 Slide and remove the arm cover of the stand.
3 Remove four screws.
4 Remove the arm.
5 Remove four screws to remove the stand
attachment bracket.
Connecting the AC
Power Cord
1 Plug the AC power cord into the AC IN socket on
the rear panel. Then, attach the AC plug holder
(supplied) to the AC power cord.
2 Slide the AC plug holder over the cord until it locks.
To disconnect the AC power cord
Pull out the AC plug holder while pressing the lock
levers.
+
–
A A
B B
BB
AA
A A
B B
BB
AA
Hang the hook of the bracket for using
the A screw holes.
Hang the hook of
the bracket for
using the B screw
holes.
5
1
4
3
2
+
–
AC power cord
AC IN socket
AC plug holder (Supplied)
+
–

Installing the Input Adaptor 19
Installing the Input
Adaptor
Before installing the input adaptor, disconnect the power
cord.
1 Remove the panel of the optional input port.
2 Insert the input adaptor into the port.
3 Tighten the screws.
Attaching the Provided L/R Labels
Install the L/R labels on the panel around the input
connectors to show channel allocations for inputs.
Examples for attaching
LMD-4251TD
LMD-2451TD
PARALLELREMOTESERIALREMOTE

Selecting the Default Settings
20
Selecting the Default
Settings
When you turn on the unit for the first time after
purchasing it, select the area where you intend to use this
unit from among the options.
The default setting values for each area
1 Turn on the unit with the power switch on the rear
panel.
The SELECT SETTING screen appears.
2 Press the CONTROL button.
3 Press the +or – button to select the area where you
intend to use the unit and press the ENTER button.
If you select either 1, 3or 5
The confirmation screen is displayed. Confirm the
selected area. When the setting is wrong, press the
RETURN button to return to the previous screen.
If you select either 2or 4
One of the following screens appears. Press the +
or – button to narrow the area further and then press
the ENTER button.
The confirmation screen is displayed. Confirm the
selected area. When the setting is wrong, press the
RETURN button to return to the previous screen.
3
3
4
5
3
1
2
COLOR
TEMP
COMPONENT
LEVEL
NTSC
SETUP
COLOR
SPACE
1NORTH
AMERICA D65 BETA7.5 7.5 SMPTE-C
2LATIN
AMERICA
PAL&PAL-N
AREA
ARGENTINA D65 SMPTE 0 EBU
PARAGUAY D65 SMPTE 0 EBU
URUGUAY D65 SMPTE 0 EBU1
NTSC&PAL
-M AREA
OTHER
AREA D65 BETA7.5 7.5 SMPTE-C
3AFRICA AUSTRALASIA
EUROPE MIDDLE-EAST D65 SMPTE 0 EBU
4ASIA EXCEPT
JAPAN
NTSC AREA D65 BETA7.5 7.5 SMPTE-C
PAL AREA D65 SMPTE 0 EBU
5JAPAN D93 SMPTE 0 EBU
–
+
–
+
–
+
–
+
–
+
–
+
–
+
1
3~4
2
S E L E C T S E T T I N G
N O R T H _A M E R I C A
L A T I N A M E R I C A
A F R I C A A U S T R A L A S I A E
A S I A E X C E P T J A P A N
J A P A N
1North America
2Latin America
3Africa,Australia/New
Zealand, Europe,
Middle East, Russia
4Asia Except Japan
5Japan
S E L E C T T H I S A R E A ?
[ E N T E R ] Y E S
[ R E T U R N ] NO
N O R T H A M E R I C A
