Sony Hi-Scan KP-51WS500 User guide

DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
KP-51WS500
47" x 51 5/8" x 24 7/8"
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
120V AC
60Hz
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
51" Hi-Scan
Projection TV
168 Lbs (approx.) 260w(max)
1w(stby)
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone] • b2b.sel.sony.com
TOP VIEW
25 3/8"
FRONT VIEW
37 7/8"
51 5/8"
Ir Receiver
under Power
button
44 1/2"
25"
47 "
24 7/8"
34 3/8"
49 1/2"
4 1/8"
22 5/8"
23 7/8"
SIDE VIEW
JACK PACK
R
RM-Y909 REMOTE CONTROL
5
51" 1"
IN
VHF/UHF
IN
AUX
TO
CONVERTER
Video
VIDEO IN
Audio
L
MONO
R
TV
OUT
S Video
IN OUT
CONTROL S
123
AUDIO
OUT
Y
Pb
Pr
DVI IN
COMPONENT / HD IN
RL
AUDIO
