HT/HS Series Highlights
- DRC™ Multi-Function
- CineMotion™ Reverse 3-2 Pulldown
- Hi-Scan 1080i™ Display
- 16:9 Enhanced Mode
- High Contrast Protective Screen
- Flexible Twin-View™ Two Tuner Picture-and-Picture
- MID™D (Multi-Image Driver X) Circuitry
WS Series Highlights
- 16:9 Aspect Ratio
- HD Detailer™Wideband Video Amplifier
- HD Microfocus™CRTs
- HD Microfocus™Lens System
- DVI-HDTV Interface
- TruSurround®Sound
- DAC Speaker System
- Scrolling Channel Index™System
WV Series Highlights
- DRC™Multi-Function V1
- 720p displayed as 1080i
- Clear Edge VM™Wideband Velocity Modulation Circuitry
- Memory Stick®Media Still Image Playback1
- High Contrast Screen with AR (Anti-Reflection) Coating
2002
Projection
Televisions
Sony Electronics Inc.
One Sony Drive
Park Ridge, NJ 07656
www.sony.com CA 4491
©2002 Sony Electronics Inc. Reproduction in whole or in part without written
permission is prohibited. All rights reserved. Features and specifications
subject to change without notice. Non-metric weights and measures are
approximate. Sony, ClearEdge VM, CineMotion, Digital Reality Creation,
DRC, HD Detailer, Hi-Scan, Hi-Scan 1080i, Memory Stick, MID, SteadySound,
Scrolling Channel Index and Twin View are trademarks of Sony. BBE and the
BBE symbol are trademarks of BBE Sound, Inc. DIRECTV is a registered
trademark of DIRECTV, Inc. a unit of Hughes Electronics Corporation. WOW,
TruSurround and the (•)®symbol are trademarks of SRS Labs, Inc.
1. All Sony digital still cameras and camcorders, except models DSC-D700,
DSC-D770, DSCR-TRV900, and DSR-PD100A, store images on a Memory
Stick media in the DCF file format, which is required for playback on these
televisions. If the image file is re-named or manipulated the DCF file format
must be restored before playback is possible. Images captured on all other
digital still cameras and camcorders will need to be formatted on a PC to
the DCF file format (with third party software not supplied with the television)
before they can be viewed.
2. Hi-Scan 1080i Display: Works through analog component video (Y/PB/PR)
connections and DVI-HDTV interface. Not compatible with such digital
connections that may become available in the future.
3. High-Definition reception: Free over-the-air broadcasts where available
(check with your cable operator for compatability) and/or DIRECTV®high-
definition subscription services through a DIRECTV HDTV Satellite Receiver.
4. Power output: All channels driven into 8 ohms, 50 Hz – 20,000 Hz at no
more than 10% THD, measured from auxiliary input to load.

At Sony, projection television isn’t just about being
big. It’s about being better. Each one of Sony’s new
digital projection television models brings you the latest
technology… and the greatest entertainment impact
available today. From a 43-inch model that’s surprisingly
friendly for even compact homes…to a 65-inch model
that’s the ideal centerpiece of any home theater, these
are just some of the qualities you’ll find in the exceptional
entertainment experience that is Sony projection television…

To give you a dramatically more realistic picture,
Sony's Digital Reality Creation circuitry uses digital
mapping to create up to four times as much data as
a conventional TV image. For you, that means truly
exceptional home theater viewing with images that
rival High-Definition.
On models with Sony’s DRC Multi-Function V1 circuitry,
detail and smoothness levels are customizable–allowing
you to create the most pleasing picture possible.
Digital Reality Creation
™
Multi-Function
Hi-Scan 1080i™Display
It doesn’t get any better than this. Sony’s Hi-Scan
1080i2inputs accept the full 1080i signal from a
High-Definition3receiver, such as Sony’s SAT-HD200,
or satellite and reproduce an image that’s truly
incredible. These inputs also allow you to experience
the full impact of progressive scan (480p) DVD players
for unbelievable home theater viewing.
To let you enjoy movies in their full glory, Sony’s
CineMotion reverse 3-2 pull-down technology
preserves the integrity of movie film frames to
create exceptional, consistent, fine details in 480-line
progressive scan (480p).
CineMotion™Reverse 3-2
Pull-Down Technology
By doubling Velocity Modulation to take advantage
of higher frequency sources like DVD and DSS, this
patented technology creates cleaner edges, greater
picture depth and an unparalleled picture overall.
Simply put, user selectable levels create better separation
between objects and backgrounds.
ClearEdge VM™
Wideband Velocity
Modulation
Wide Band Velocity Modulation™
(WV600 series)
For conventional
480i sources, DRC™
Multi-Function circuitry
creates up to four times
as much data as
a conventional
television picture.
(HT/HS/WS series)
100
100
Clarity
Reality
You can now customize
the level of DRC
depending on the signal
strength and viewing
environment.
(WV600 series)

HD Detailer™Wideband
Video Amplifier
All televisions have a video amplifier, the device that
takes the original video source and “amplifies”it to
deliver a useable signal to your CRT or television
screen. The bandwidth rating of a video amplifier
determines the amount of detail that can be displayed
on a television. Sony’s HD Detailer Wideband Video
Amplifier delivers greater detail on even the finest
images by getting the most out of high-bandwidth
sources, such as the 1080i signal available from some
set-top boxes and satellite feeds.
Available on
WV600 Series models.
Memory Stick®
Media Playback
It’s the fastest way from your camera to your
television. If you’re one of the millions that have
a digital camera, camcorder or computer that
utilizes Memory Stick®media, then you can enjoy
these awesome images on your WV600 series
projection television.1Simply insert the Memory
Stick media into the slot on the front of the
television and choose one of two menu options:
“Slide Show”displays full-screen photos, one
after another. “Set Up”allows you to set Slide
Show interval, repeat option, rotate photos and
display file information.
“Index”displays a “thumbnail”image of all photos,
which can be accessed with the remote control.
3D Digital
Comb Filter
The best picture in the business gets even better.
Sony’s 3D Digital Comb Filter gives you higher
horizontal resolution, higher vertical resolution
and reduces video “noise”at the same time. You’ll
also get exceptional gray-scale gradation, thanks to
a 10-bit signal processing.
The Wideband
Video Amplifier
preserves detail on
High-Definition
1080i sources.
(WS500, WV600)
Resolution is improved
top to bottom and side
to side with Sony’s
3D Digital Comb Filter.

Scrolling Channel
Index™System
Have you ever wanted to see what’s on two, three
or even four of your favorite channels all at once?
No problem. Now you can easily review them with
Scrolling Channel Index™System in one of the
picture-and-picture windows.
TruSurround®
SRS®Sound
Enveloping you with crisp, lifelike sound,
TruSurround sound processing creates the impact
of powerful rear speakers—using only the pair of
stereo speakers built into the television cabinet,
a virtual 3-Dimensional sound stage so you’re
always in the center of the action.
DVI-HDTV Interface
Sony Hi-Scan®televisions employ a DVI (Digital
Visual Interface) input which takes a high-bandwidth,
uncompressed, high-speed signal from a digital video
source, such as Sony’s SAT-HD200 High-Definition
Receiver, and delivers it to the monitor. The overall
result is a fully digital high-definition connection
that’s becoming the industry standard…and one that
lets viewers enjoy the purest HDTV signal possible.
More sophisticated than P-I-P features, Sony’s
advanced circuitry can display two programs side-by-
side, all without an additional source. Even greater
flexibility allows you to adjust sizing and placement.
Made possible by Sony’s Multi-Image Driver X (MID™X)
circuitry, you can even view a High-Definition image
right alongside a conventional picture.
Multi-Image Driver X
(MID™X) Circuitry
Sony's Twin-View system
lets you follow two complete
pictures, side-by-side.
View one main image and four
inset channels simultaneously.
(SAT-HD200)

Product
Specifications
KP-43HT20 KP-53HS30 KP-61HS30 KP-51WS500 KP-57WS500 KP-65WS500 KP-57WV600 KP-65WV600
Screen size, diagonal 43” 53” 61” 51” 57” 65” 57” 65”
Screen Aspect Ratio 4:3 4:3 4:3 16:9 16:9 16:9 16:9 16:9
16:9 Enhanced Mode Yes Yes Yes - - - - -
Hi-Scan 1080i™ Display Yes Yes Yes Yes Yes Yes Yes Yes
Digital Reality Creation™ MultiFunction circuitry Yes Yes Yes Yes Yes Yes V1 V1
CineMotion™ reverse 3-2 pull-down technology Yes Yes Yes Yes Yes Yes Yes Yes
3D Digital Comb Filter Yes Yes Yes Yes Yes Yes Yes Yes
ClearEdge VM™ Wideband Velocity Modulation - - - - - - Yes Yes
HD Detailer™ Wideband Video Amplifier - - - Yes Yes Yes Yes Yes
MICROFOCUS™ picture tubes Yes Yes Yes HD HD HD HD HD
MICROFOCUS™ lenses Yes Yes Yes HD HD HD HD HD
High contrast protective screen Yes Yes Yes Yes Yes Yes Yes Yes
Anti-Reflection (AR) Coating - - - - - - Yes Yes
TruSurround®SRS®Sound processing Yes Yes Yes Yes Yes Yes Yes Yes
SteadySound™ with BBE®- - - Yes Yes Yes Yes Yes
Total audio power440 w 40 w 40 w 40 w 40 w 40 w 40 w 40 w
DAC Speakers - - - Yes Yes Yes Yes Yes
Memory Stick®Media Still Image Playback - - - - - - Yes Yes
MID™ X (Multi-Image Driver X) circuitry Yes Yes Yes Yes Yes Yes Yes Yes
Flexible Twin-View™ P&P Yes Yes Yes Yes Yes Yes Yes Yes
Auto Wide & Widescreen Modes - - - Yes Yes Yes Yes Yes
Scrolling Channel Index™ System - - - Yes Yes Yes Yes
Freeze Memo Yes Yes Yes Yes Yes Yes Yes Yes
Component video inputs (Y/PB/PR) 2 HD capable 2 HD capable 2 HD capable 2 HD capable 2 HD capable 2 HD capable 2 HD capable 2 HD capable
S-Video inputs (rear/front) 2/1 2/1 2/1 2/1 2/1 2/1 2/1 2/1
Composite inputs (rear/front) 3/1 3/1 3/1 3/1 3/1 3/1 3/1 3/1
DVI-HDTV Interface - - - Yes Yes Yes Yes Yes
Dimensions (W x H x D) 38 x 42 1/8 x 22 3/4” 46 1/2 x 55 7/8 x 24 7/8” 54 x 61 7/16 x 26 1/4” 47 x 51 1/2 x 24 3/4” 52 1/4 x 54 1/8 x 27 1/8” 60 3/4 x 57 1/8 x 28 7/8” 53 5/8 x 54 7/8 x 27 1/8” 60 3/4 x 59 5/8 x 28 7/8”
(approx.) 965 x 1069 x 577 mm 1180 x 1417 x 632 mm 1370 x 1560 x 666 mm 1194 x 1308 x 630 mm 1326 x 1375 x 690 mm 1542 x 1452.2 x 735 mm 1361 x 1394 x 689 mm 1542 x 1516 x 735 mm
Weight 144 lbs. (65kg) 157 lbs. (71.2 kg) 211 lbs. (95.4 kg) 168 lbs. (76.2 kg) 210 lbs., 2 oz. (95.3 kg) 275 lbs, 9 oz. (125.0 kg) 216 lbs., 1 oz. (98.0 kg) 299 lbs., 13 oz (136.0 kg)
Energy Star compliant Yes Yes Yes Yes Yes Yes Yes Yes
Optional A/V Cabinet SU-43HT5 and SU-43T4 - - - - - - -
AUDIOOTHER VIDEOCONVENIENCE
