COLOR REAR VIDEO PROJECTION
SERVICE MANUAL AX1 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO.
9-965-947-02
KDP-51WS550 RM-Y192 US/CND SCC-M11CA
KDP-57WS550 RM-Y192 US/CND SCC-M11AA
KDP-65WS550 RM-Y192 US/CND SCC-M11BA
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
ORIGINAL MANUAL ISSUE DATE: 7/2003
REVISION DATE REVISION TYPE SUBJECT
7/2003 No revisions or updates are applicable at this time.
7/25/2003 Updated Table of Contents (Page 3)
Updated 2-4. Focus Lens Adjustment step #11 (Page 17),
Exchanged order of procedures for 2-6. & 2-7. (2-Pole Magnet Adjustment &
Centering Magnet Adjustment), Added step #7 to 2-6. Centering Magnet Adjustment,
Updated 2-9. Defocus Adjustment (Blue) step #5 (Page 18)
Corrected instructions for 3-2. HV Hold Down Circuit Operation Check (Page 38)
Corrected procedure for 3-4. +B OVP Conrmation (Page 39)

COLOR REAR VIDEO PROJECTION
SERVICE MANUAL AX1 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO.
9-965-947-02
KDP-51WS550 RM-Y192 US/CND SCC-M11CA
KDP-57WS550 RM-Y192 US/CND SCC-M11AA
KDP-65WS550 RM-Y192 US/CND SCC-M11BA
Self Diagnosis
Supported model
KDP-65WS550 RM-Y192

— 3 —
KDP-51WS550/57WS550/65WS550
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specications ................................................................................. 4
Warnings and Cautions .................................................................. 5
Safety Check-Out ........................................................................... 6
Self-Diagnostic Function................................................................. 7
SECTION 1: DISASSEMBLY............................................................... 10
1-1. Rear Board Removal............................................................ 10
1-2. Terminal Board and UD Board Removal .............................. 10
1-3. Chassis Assembly Removal..................................................11
1-4. Service Position ....................................................................11
1-5. MA Board, BM Board, G2 Board, AD board,
Q Box Assembly, and UA Board Removal ........................... 12
1-6. D Board, A Board, and DS Board Removal.......................... 12
1-7. High-Voltage Cable Installation and Removal...................... 13
1-8. Picture Tube Removal.......................................................... 13
1-9. Grille, HA Board, QH Board, and HB Board Removal.......... 14
1-10. Beznet Assembly Removal .................................................. 14
1-11. SR Board Removal .............................................................. 15
1-12. Mirror Cover Removal (KDP-51WS550/57WS550 Only) ..... 15
SECTION 2: SET-UP ADJUSTMENTS................................................ 16
2-1. Screen Voltage Adjustment (G2) (Coarse Adjustment) ........ 16
2-2. Screen (G2) Adjustment (Fine Adjustment).......................... 16
2-3. Deection Yoke Tilt Adjustment............................................ 16
2-4. Focus Lens Adjustment........................................................ 17
2-5. Focus VR Adjustment........................................................... 17
2-6. Centering Magnet Adjustment.............................................. 18
2-7. 2-Pole Magnet Adjustment .................................................. 18
2-8. 4-Pole Magnet Adjustment .................................................. 18
2-9. Defocus Adjustment (Blue)................................................... 18
2-10. Electrical Adjustments by Remote Commander................... 19
2-10-1. Method of Entering the Service Adjustment Mode .. 19
2-10-2. Memory Write Conrmation Method ........................ 19
2-10-3. Adjusting Buttons and Indicator ............................... 19
2-11. Adjustable Service Data Lists .............................................. 20
2-11-1. ID Map Table............................................................ 29
2-12. Registration Adjustment (PJE Mode Only)........................... 30
2-12-1. Setup for Adjustment ............................................... 30
2-12-2. Main Deection Adjustment ..................................... 30
2-12-3. Operation Method for Projector Engine Mode ......... 31
2-13. PJE Adjustment (Sub Deection Adjustment) ...................... 32
2-13-1. Adjustment for NTSC Full Mode .............................. 33
2-13-2. Copying All Registration Data to Other Modes ........ 35
2-14. Auto Registration Offsets ..................................................... 35
2-15. Auto Registration Error Codes ............................................. 36
2-16. Auto Registration Diagnostics .............................................. 37
SECTION 3: SAFETY-RELATED ADJUSTMENTS............................. 38
D BOARD ..................................................................................... 38
3-1. HV Regulation Circuit Check and Adjustment...................... 38
3-2. HV Hold Down Circuit Operation Check .............................. 38
G BOARD ..................................................................................... 39
3-3. +B Max Voltage Conrmation .............................................. 39
3-4. +B OVP Conrmation........................................................... 39
SECTION 4: CIRCUIT ADJUSTMENTS.............................................. 40
4-1. P & P Sub Contrast Adjustment (Video) (SCON)................. 40
4-2. P & P Sub Contrast Adjustment (RF) (SCON) ..................... 40
4-3. P & P Sub-Hue and Sub-Color Adjustment Video
(SHUE, SCOL) ..................................................................... 40
4-4. P & P Sub-Hue and Sub-Color Adjustment (RF)
(SHUE, SCOL) ..................................................................... 40
4-5. Blue Offset Adjustment......................................................... 41
SECTION 5: DIAGRAMS..................................................................... 42
5-1. Circuit Boards Location ........................................................ 42
5-2. Printed Wiring Boards and
Schematic Diagrams Information ......................................... 42
5-3. Block Diagrams .................................................................... 44
5-4. Schematics and Supporting Information ............................. 48
CR Board Schematic Diagram ............................................ 48
CB Board Schematic Diagram ............................................ 49
CG Board Schematic Diagram ............................................ 50
VM Board Schematic Diagram ............................................ 51
MA Board Schematic Diagram (1 of 3)................................. 52
MA Board Schematic Diagram (2 of 3)................................. 53
MA Board Schematic Diagram (3 of 3)................................. 54
A Board Schematic Diagram (1 of 2).................................... 56
A Board Schematic Diagram (2 of 2).................................... 57
UA Board Schematic Diagram (1 of 2)................................ 60
UA Board Schematic Diagram (2 of 2)................................ 61
AD Board Schematic Diagram ............................................ 64
D Board Schematic Diagram (1 of 3) ................................... 66
D Board Schematic Diagram (2 of 3) ................................... 67
D Board Schematic Diagram (3 of 3) ................................... 68
UD Board Schematic Diagram ............................................ 71
BM Board Schematic Diagram (1 of 3) ................................ 73
BM Board Schematic Diagram (2 of 3) ................................ 74
BM Board Schematic Diagram (3 of 3) ................................ 75
DS Board Schematic Diagram ............................................. 77
G2 Board Schematic Diagram ............................................. 78
QI Board Schematic Diagram (1 of 3) .................................. 80
QI Board Schematic Diagram (2 of 3) .................................. 81
QI Board Schematic Diagram (3 of 3) .................................. 82
QM Board Schematic Diagram (1 of 5) ................................ 84
QM Board Schematic Diagram (2 of 5) ................................ 85
QM Board Schematic Diagram (3 of 5) ................................ 86
QM Board Schematic Diagram (4 of 5) ................................ 87
QM Board Schematic Diagram (5 of 5) ................................ 88
QT Board Schematic Diagram ............................................. 91
HA Board Schematic Diagram ............................................ 93
QH Board Schematic Diagram ............................................ 95
SR Board Schematic Diagram ............................................ 96
HB Board Schematic Diagram ............................................ 97
5-5. Semiconductors ................................................................... 98
SECTION 6: EXPLODED VIEWS ........................................................ 99
6-1. Cover (KDP-51WS550/57WS550 Only).............................. 99
6-2. Cover (KDP-65WS550 0nly) .............................................. 100
6-3. Chassis .............................................................................. 101
6-4. Picture Tube....................................................................... 102
SECTION 7: ELECTRICAL PARTS LIST .......................................... 103

— 4 —
KDP-51WS550/57WS550/65WS550
120V AC, 60Hz
295W
Under 1 W
Under 17 W
DVI-HDTV
1 terminal, 3.3V T.M.D.S., 50 ohms
The DVI-HDTV input terminal is compliant with the EIA-861
standard and is not intended for use with personal computers.
Video (IN)
4 total (1 on front panel)
1Vp-p, 75ohms unbalanced, sync negative
S Video (IN)
3 total (1 on front panel)
Y: 1Vp-p, 75ohms unbalanced, sync negative
C: 0.286Vp-p (Burst signal), 75ohms
Control S (IN/OUT)
1 total
Projection System
3 picture tubes, 3 lenses, horizontal in-line system
Picture Tube
7-inch high-brightness monochrome tubes (6.3 raster size), with
optical coupling and liquid cooling system.
Projection Lenses
High performance, large diameter hybrid lens F1.1
Antenna
75 ohm external terminal for VHF/UHF
Television System
NTSC, American TV Standard
Channel Coverage
VHF: 2-13/UHF: 14-69/DTV: 1-999/CATV: 1-125
SPECIFICATIONS
Design and specications are subject to change without notice.
Power Requirements
Power Consumption (W)
In Use (Max)
In Standby
In i.LINK Standby
Inputs/Outputs
Screen Size (measured diagonally)
51 inches (KDP-51WS550)
57 inches (KDP-57WS550)
65 inches (KDP-65WS550)
Supplied Accessories
Remote Control RM-Y192
Batteries (2) size AA (R6)
Optional Accessories
A/V Cable (VMC-810/820/830 HG)
Audio Cable (RKC-515HG)
Component Video Cable (VMC-10/30 HG)
Control S Cable (RK-G69HG)
i.LINK cables: VMC-IL4415 (4-pin to 4 pin, 1.5 meters);
VMC-IL4435 (4-pin, 3.5 meters)
Audio (IN)
7 total (1 on front panel)
500 mVrms (100% modulation)
Impedance:47 kilohm
Component Video Input
2 ( Y,PB,PR)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative;
PB: 0.7 Vp-p, 75 ohms;
PR: 0.7 Vp-p, 75 ohms
Digital Audio Optical Output PCM/Dolby Digital
1 total Optical Rectangular
i.LINK
3 total (1 on front panel)
4-pin S400 i.LINK terminal
Variable/Fixed Audio (OUT)
More than 408 m Vrms at the maximum volume setting (Variable)
More than 408 m Vrms (Fixed) Impedance (output):2 kilohms
KDP-51WS550 KDP-57WS550 KDP-65WS550
20W x 2
1194 x 1350 x 650 mm 1362 x 1377 x 690 mm 1542 x 1507 x 735 mm
47 x 53
1/8
x 25
5/8
in 52
1/4
x 54
3/16
x 27
1/8
in 60
3/4
x 59
1/4
x 28
15/16
in
79.3 kg 87 kg 139.5 kg
174.5 lbs 191.5 lbs 307 lbs
Speaker Output (W)
Dimensions (W x H x D)
mm
in
Mass kg
lbs

— 5 —
KDP-51WS550/57WS550/65WS550
WARNINGS AND CAUTIONS
CAUTION
Short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT shield, or carbon painted on the CRT, after
removing the anode.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of
this receiver is directly connected to the ac power line.
! SAFETY-RELATED COMPONENT WARNING!!
Components identied by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe
operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements
published by Sony. Circuit adjustments that are critical for safe operation are identied in this manual. Follow these procedures
whenever critical components are replaced or improper operation is suspected.
ATTENTION!!
Apres avoir deconnecte le cap de l’anode, court-circuiter l’anode du tube cathodique et celui de l’anode du cap au chassis metallique
de l’appareil, ou la couche de carbone peinte sur le tube cathodique ou au blindage du tube cathodique.
An d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout
dépannage. Le chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
! ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identies par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces
sont d’une importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero
de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance
est critique pour la securite du fonctionnement sont identies dans le present manuel. Suivre ces procedures lors de chaque
remplacement de composants critiques, ou lorsqu’un mauvais fonctionnement suspecte.

— 6 —
KDP-51WS550/57WS550/65WS550
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the B+ and HV to see if they are specied values. Make sure
your instruments are accurate; be suspicious of your HV meter if
sets always have low HV.
8. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and from
all exposed metal parts to any exposed metal part having a return to
chassis, must not exceed 0.5 mA (500 microamperes). Leakage current
can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliammeter. The Data Precision 245 digital
multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75 V,
so analog meters must have an accurate low voltage scale. The
Simpson’s 250 and Sanwa SH-63TRD are examples of passive
VOMs that are suitable. Nearly all battery-operated digital multimeters
that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate retaining
screw on most AC outlet boxes is also at earth ground. If the retaining
screw is to be used as your earth ground, verify that it is at ground by
measuring the resistance between it and a cold-water pipe with an
ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt trouble-
light (not a neon lamp) between the hot side of the receptacle and the
retaining screw. Try both slots, if necessary, to locate the hot side on the
line; the lamp should light at normal brilliance if the screw is at ground
potential (see Figure B).
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.
To Exposed Metal
Parts on Set
AC Voltmeter
(0.75 V)
Earth Ground
0.15 µF1.5 kΩ

— 7 —
KDP-51WS550/57WS550/65WS550
SELF-DIAGNOSTIC FUNCTION
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER LED will automatically begin to ash. The number
of times the LED ashes translates to a probable source of the problem. A denition of the STANDBY/TIMER LED ash indicators is listed in the
instruction manual for the user’s knowledge and reference. If an error symptom cannot be reproduced, the Remote Commander can be used to review
the failure occurrence data stored in memory to reveal past problems and how often these problems occur.
Diagnostic Test Indicators
When an error occurs, the STANDBY/TIMER LED will ash a set number of times to indicate the possible cause of the problem. If there is more than
one error, the LED will identify the rst of the problem areas.
Results for all of the following diagnostic items are displayed on screen. If the screen displays a “0”, no error has occurred.






  
   � 
� 
� 
� 
� 
   � 
� 

� 
� 
   �  � 
   � 
� 
� 

� 
� 



  � 

� 

� 
� 
� 



  � 

� 
� 
� 


  � 
� 
� 
   � 

� 

� 
   �  � 
  

� 

� 
� 
 



Self Diagnosis
Supported model

— 8 —
KDP-51WS550/57WS550/65WS550
Display of Standby/Timer LED Flash Count






 



 
 
 
 
 
 
 
 
 
Release of TIMER STAND BY indicator blinking
The TIMER/STANDBY indicator blinking display is released by turning OFF the power switch on the TV main unit or removing the plug from the power.
Self-Diagnosis Screen Displays
In cases of malfunctions where it is not possible to determine the symptom such as when the power goes off occasionally or when the screen
disappears occasionally, there is a screen display on whether the malfunction occurred or not in the past (and whether the detection circuit operated or
not) in order to allow conrmation.
Screen Display Method
Quickly press the remote command button in the following order from the standby state.
Display Channel 5 Sound Volume* _ Power ON
*Note that this differs from entering the service mode (sound volume + )
Numeral “0”
means that no fault was detected.
Numeral “1”
means a fault was detected one
time only.
SELF DIAGNOSIS
2: +B OCP 0
3: +B OVP 0
4: VSTOP 0
5: AKB 1
6: LOWB 0
7: H-STOP 0
8: AUDIO 0
9: ZCD 0
10: HV PROT 0
101: WDT 24
Self-Diagnosis Screen Display
The results display is not automatically cleared. In case of repairs and after repairs, check the self-diagnosis screen and be sure to return the results
display to “ 0 ”.
If the results display is not returned to “ 0 ” it will not be possible to judge a new malfunction after completing repairs.
Method of Clearing Results Display
1. Power off (Set to the stand by mode.)
2. Display Channel 5 Sound Volume + Power ON (Service Mode)
3. Channel 8 ENTER (Test reset = Factory preset condition)
Method of Ending Self Diagnosis Screen
When ending the self-diagnosis screen completely, turn the power switch OFF on the remote commander or the main unit.

— 9 —
KDP-51WS550/57WS550/65WS550
Self-Diagnosis Function Operation
+B overcurrent (OCP)
Occurs when excessive current ows through R6812. The increase in voltage across Q6803 causes it to turn on which sends a high signal to the
micro.
+B overvoltage (OVP)
IC6801 detects +B OVP condition and turns on Q6802. This sends a high signal to the micro and also shuts down the AC relay.
V-STOP
Occurs when an absence of the vertical deection pulse is detected by pin 56 of IC0401 (MA Board). Power supply will shut down when waveform
interval exceeds 2 seconds.
White Balance Failure
If the RGB levels* do not balance within 2 seconds after the power is turned on, this error will be detected by IC0401. TV will stay on, but there will be
no picture.
*(Refers to the RGB levels of the AKB detection Ref pulse that detects 1K).
Low B OCP/OVP
Occurs when set 5V is out.
Horizontal Deection Stopped
Occurs when either:
1) a +B overcurrent is detected (Q6803), or
2) IC0401 (MA Board) is damaged.
Self-Diagnosis Block Diagram
3
1
2
R5104 R5105
R5125
Q5018
RY600
Q6102
Q6105
Q6108
D6122
D6803
D6505
D6121
R6812
D6805
R6803
IC6801 Q6802
1K-PROT2
+B OCP
+BVOP
5V
+B OCP
21
34
IC5007
VDY-
CRT
IC0401
Y/C JUNGLE
SCL
SDA
AKB
VPROT
HPROT
IC0001
MAIN MICRO
MA
CLKO
DATO
AC RLY
LOW B ERR
OVP
OCP
STR
STBY-LED
STBY-LED
P_SW(-)
IC6201
5V
+B
+B +B
BM
MA
D
D
A
2 14
57
56
58
53
52
28
31
69
43
44
45
48
O
IO

— 10 —
KDP-51WS550/57WS550/65WS550
1-1. REAR BOARD REMOVAL
SECTION 1: DISASSEMBLY



























1-2. TERMINAL BOARD AND UD BOARD REMOVAL

— 11 —
KDP-51WS550/57WS550/65WS550
1-4. SERVICE POSITION



















1-3. CHASSIS ASSEMBLY REMOVAL

— 12 —
KDP-51WS550/57WS550/65WS550

 














1-6. D BOARD, A BOARD, AND DS BOARD REMOVAL
1-5. MA BOARD, BM BOARD, G2 BOARD, AD BOARD,
Q BOX ASSEMBLY, AND UA BOARD REMOVAL








— 13 —
KDP-51WS550/57WS550/65WS550
CAUTION: Removing the arrow-marked screws is strictly prohibited. If removed, it may cause liquid to spill.



























1-8. PICTURE TUBE REMOVAL




 






1-7. HIGH-VOLTAGE CABLE INSTALLATION AND REMOVAL

— 14 —
KDP-51WS550/57WS550/65WS550












1-10.BEZNET ASSEMBLY REMOVAL
1-9. GRILLE, HA BOARD, QH BOARD, AND HB BOARD REMOVAL






























— 15 —
KDP-51WS550/57WS550/65WS550





1-12.MIRROR COVER REMOVAL (KDP-51WS550/57WS550 ONLY)






















1-11. SR BOARD REMOVAL
The Screen Holder does not need
to be removed in order to remove
the SR boards.

— 16 —
KDP-51WS550/57WS550/65WS550
SECTION 2: SET-UP ADJUSTMENTS
2-1. SCREEN VOLTAGE ADJUSTMENT (G2)
(COARSE ADJUSTMENT)
1. Receive the Monoscope signal.
2. Set BRIGHTNESS to 50% and PICTURE to minimum.
3. Turn the red VR on the focus block all the way to the left and then
gradually turn it to the right until the retrace line is barely visible.
4. Gradually turn the control to the left until the retrace line disappears.
RGB
SCREEN
RGB
FOCUS
FOCUS Block
2-2. SCREEN (G2) ADJUSTMENT (FINE
ADJUSTMENT)
If the jig described below is available, it is recommended that the G2
Fine Mode Adjustment be performed to set the screen controls to their
optimal condition. If desired, you can build the jig illustrated below,
using 3-watt resistors. Please note that if the proper voltage is not
obtained with the listed resistor’s values, then increase or decrease one
of the values in the resistor network to obtain the correct voltage.
1. Select VIDEO-1 mode no signal applied (the screen must be black).
2. Connect the G2 JIG.
3. SW on JIG.
4. Connect an oscilloscope to the TP9101(KR), TP9201(KG) and
TP9301(KB) of CR board, CG board, and CB board.
5. Adjust red, green, and blue screen voltage to 177.5+/-0.5V with
screen VR on the focus block.






   





2-3. DEFLECTION YOKE TILT ADJUSTMENT
1. Connect the color bar generator monoscope pattern to Video 1 input.
2. Cover the red and blue CRT lenses with lens caps to allow only green
to show (or use the method shown in the note below for turning off
the CRTs individually without using lens caps).
3. Loosen the CRT’s deection yoke set screw and align the tilt of the
deection yoke so that the horizontal bars at the center of the
cross-hatch pattern are parallel to the top and bottom edges of the
screen.
4. After aligning the deection yoke fasten it securely to the
funnel-shaped portion (neck) of the CRT.
5. Cover the green and blue CRT lenses with lens caps to allow only
green to show (or use the method shown in the note below for turning
off the CRTs individually without using lens caps), then repeat steps 3
and 4 for the red CRT.
Cover the green and red CRT lenses with lens caps to allow only
green to show (or use the method shown in the note below for turning
off the CRTs individually without using lens caps), then repeat steps 3
and 4 for the blue CRT.
Note: If lens caps are unavailable, you can cut off the unnecessary color
beams by controlling the service mode MCP-RON, GON, BON.






— 17 —
KDP-51WS550/57WS550/65WS550
2-4. FOCUS LENS ADJUSTMENT
In this adjustment, use the remote commander while in service mode.
For details on the usage of the service mode and the remote commander,
please refer to section
2-10. ELECTRICAL ADJUSTMENTS BY REMOTE COMMANDER.
1. Loosen the lens screw.
2. Cover the red and blue CRT lenses with lens caps to allow only green
to show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps).
3. Turn the green lens to adjust to the optimum focus point with the
crosshatch signal.
4. Tighten the lens screw.
5. Cover the green and blue CRT lenses with the lens caps to allow only
red to show (or use the method shown in the note below for turning off
the CRTs individually without using lens caps).
6. Turn the red lens to adjust to the optimum focus point with the
crosshatch signal.
7. Tighten the lens screw.
8. Cover the green and red CRT lenses with the lens caps to allow only
blue to show (or use the method shown in the note below for turning
off the CRTs individually without using lens caps).
9. Turn the blue lens to adjust to the optimum focus point with the
crosshatch signal.
10. Tighten the lens screw.
11. After adjusting the items:
2-5. FOCUS VR ADJUSTMENT,
2-7. 2-POLE MAGNET ADJUSTMENT,
2-8. 4-POLE MAGNET ADJUSTMENT,
reconrm the optimum focus point and adjust again if necessary.
* In PJE mode, every time 6 is pressed, the test signal changes to:
“crosshatch+video signal” → “crosshatch+borderline (black)” →
”crosshatch (black)” → “dots (black)” → “all white” → off
Test Signal
A
B
Lens
Minimize both A and B.
Center of crosshatch
Scanning line visible.
Note: If lens caps are unavailable, you can cut off the unnecessary color
beams by controlling the service mode MCP-RON, GON, BON.
2-5. FOCUS VR ADJUSTMENT
1. Set generator to crosshatch.
2. Cover the red and blue CRT lenses with lens caps to allow only green
to show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps).
3. Turn the green focus VR on the focus block to adjust to the optimum
focus point with the crosshatch signal.
4. Cover the green and blue picture lenses with lens caps to allow only
red to show (or use the method shown in the note below for turning off
the CRTs individually without using lens caps).
5. Turn the red focus VR on the focus block to adjust to the optimum
focus point with the crosshatch signal.
6. Cover the green and red picture lenses with lens caps to allow only
blue to show (or use the method shown in the note below for turning
off the CRTs individually without using lens caps).
7. Turn the blue focus VR on the focus block to adjust to the optimum
focus point with the crosshatch signal.
8. After adjusting the items:
2-4. FOCUS LENS ADJUSTMENT,
2-7. 2-POLE MAGNET ADJUSTMENT,
2-8. 4-POLE MAGNET ADJUSTMENT,
reconrm the optimum focus point and adjust again if necessary.
Note: If lens caps are unavailable, you can cut off the unnecessary color
beams by controlling the service mode MCP-RON, GON, BON.
RGB
SCREEN
RGB
FOCUS
FOCUS Block

— 18 —
KDP-51WS550/57WS550/65WS550
2-6. CENTERING MAGNET ADJUSTMENT
1. Set the mode to PRO.
2. Receive the monoscope signal.
3. Cover the red and blue CRT lenses with lens caps to allow only green
to show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps).
4. Adjust the green CRT’s centering magnet to put the center of the
monoscope signal to the center of the screen.
5. Repeat steps 1 through 4 for the red CRT except now you will cover
the green and blue CRT lenses with lens caps to allow only red to
show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps) and you will adjust the red
centering magnet.
6. Repeat steps 1 through 4 for the blue CRT except now you will cover
the red and green CRT lenses with lens caps to allow only blue to
show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps) and you will adjust the blue
centering magnet.
7. After 2-Pole and 4-Pole adjustment, entering magnet adjustment
needs to be conrmed. If centering magnet is re-adjusted, then 2-Pole
magnet will need to be conrmed.
Note: If lens caps are unavailable, you can cut off the unnecessary color
beams by controlling the service mode MCP-RON, GON, BON.
2-7. 2-POLE MAGNET ADJUSTMENT
1. Set the mode to PRO and picture to MAX.
2. Receive the 100IRE 1080i Dot signal.
3. Cover the red and blue CRT lenses with lens caps to allow only green
to show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps).
4. Turn the focus VR on the focus block to the left (counter clockwise)
and set it to overfocus to enlarge the spot.
5. Adjust the CRT’s 2-pole magnet so that the small bright spot is in the
center.
6. Align the focus VR on the focus block and set it for the best focus.
7. Repeat steps 1 through 6 for the red CRT covering the green and
blue CRT lenses with lens caps to allow only red to show (or use the
method shown in the note below for turning off the CRTs individually
without using lens caps) and you will adjust the red focus control on
the focus block.
8. Repeat steps 1 through 6 for the blue CRT covering the red and green
CRT lenses with lens caps to allow only blue to show (or use the
method shown in the note below for turning off the CRTs individually
without using lens caps) and you will adjust the blue focus control on
the focus block.
Note: If lens caps are unavailable, you can cut off the unnecessary color
beams by controlling the service mode MCP-RON, GON, BON.
2-8. 4-POLE MAGNET ADJUSTMENT
1. Set the mode to VIVID and WIDE mode = Zoom, VM:Off.
2. Receive the 100IRE 1080i Dot signal.
3. Cover the red and blue CRT lenses with lens caps to allow only green
to show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps).
4. Turn the (green) focus VR on the focus block to the right (clockwise)
and set it to under-focus to reduce the spot.
5. Adjust the 4-pole magnet so that the small spot in the center of the
screen becomes round for green and red.
6. Adjust the blue spot to an oval shape X:Y=1:1
7. Repeat steps 1 through 6 for the red CRT except now you will cover
the green and blue CRT lenses with lens caps to allow only red to
show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps) and you will adjust the red
focus control on the focus block.
8. Repeat steps 1 through 6 for the blue CRT except now you will cover
the red and green CRT lenses with lens caps to allow only blue to
show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps) and you will adjust the blue
focus control on the focus block.
Note: If lens caps are unavailable, you can cut off the unnecessary color
beams by controlling the service mode MCP-RON, GON, BON.
x
y
x : y = 1:1 (Green, Red)
Use the center dot
2-9. DEFOCUS ADJUSTMENT (BLUE)
Note: Adjust the blue dot to be slightly larger than red and green dots.
This adjustment provides a more pleasing picture to the customer.
1. Set the mode to PRO, PICTURE : Max, COLOR TEMP : Cool.
2. Receive the 100IRE 1080i Dot signal.
3. Cover the red and green CRT lenses with lens caps to allow only blue
to show (or use the method shown in the note below for turning off the
CRTs individually without using lens caps).
4. Turn the blue focus VR on the focus block to the right (clockwise) until
blue spot is in focus.
5. Change mode to VIVID to conrm Flare level is minimal using cross
hatch signal.
6. Set the generator to an all white signal and check uniformity.
Note: If lens caps are unavailable, you can cut off the unnecessary color
beams by controlling the service mode MCP-RON, GON, BON.


— 19 —
KDP-51WS550/57WS550/65WS550
2-10.ELECTRICAL ADJUSTMENTS BY
REMOTE COMMANDER
All of the circuit adjustments can be made by using the remote
commander (RM-Y192).
N te: he following test equipment is required:
1. Pattern Generator (with component outputs)
2. Frequency counter
3. Digital multimeter
4. Audio oscillator
2-10-1. METHOD OF ENTERING THE SERVICE
ADJUSTMENT MODE
SERVICE MODE PROCEDURE
1. V must be in Standby mode. (Power off)
2. Press “DISPLAY”, “5”, “VOL +”, then “POWER” on the remote
commander.
(Press each button within 1 second of pressing the previous button.)
SERVICE MODE ADJUSTMENT
Data
WSL : XXX
0 0
3D-COMB
NRMD
F / A FLAG : XXXXXXXX
CBA FLAG : XXXXXXXX
SERVICE
V
Item NO.
Adjustment Item
Category
3. he screen displays the item being adjusted within that category.
4. Press 1 or 4 on the remote commander to select the adjustment item
5. Press 3 or 6 on the remote commander to change the data
6. Press 2 or 5 on the remote commander to select the adjustment
category
Every time you press 2 (Category up), service mode changes in the
order shown below:
7. If you want to go back to the most recently saved value, press “0”
then “EN ER” to read the memory.
8. Press “MU ING” then “EN ER” to write the new adjustment data into
memory.
9. urn power off when you want to exit the service mode.
N te:: Press “8” then “EN ER” on the remote commander to restore the
factory settings for user controls and channel memories (this will also
turn set off and then on to exit the service mode).
2-10-2. MEMORY WRITE CONFIRMATION
METHOD
1. After adjustment, turn the power off with the remote commander.
2. urn the power ON and set to service mode.
3. Cycle through the adjusted items again and confi rm that the
adjustments were saved.
2-10-3. ADJUSTING BUTTONS AND
INDICATOR
N te: When the PJE mode (which displays an internally generated
signal) is activated, several buttons on the remote commander will have
different functions than the ones listed below. herefore, when in the
PJE mode, refer to section 2-12-3 for button functions.
MU ING
Category up
Adjustment
item up
Adjustment
item down
EN ER
Category
down
Data down
Data up
DISPLAY
POWER
est Reset
VOLUME
V/VIDEO
PIC MODE
AN
WIDE MODE
INDEX WIN VIEW
RM-Y192
USER
LUMA
VERSION
COLR
CL Y
MIDE
CCPM
YC S
DEF1
DEF2
DEF4
DEF5
DEF3
PJED AIVP
PJED A1SV
DDEV
MCP
COMB
PJED FDIS
PJED V1CM
PJED O VS
AWID
SNNR
RNR
BNR
OSDP
ASEL
PJED DFHG
PJED CEN
AP
MSMO
PJED VUP
PJED ROGH
PJED PV3P
PJED SF F
OP
A SC
ID
PFOP
PFID
VSEL
DRCV
MID1
MID2
MID3
VSW
CRNR

— 20 —
KDP-51WS550/57WS550/65WS550
2-11. ADJUSTABLE SERVICE DATA LISTS
Only the Adjustable registers are shown in the initial data list.
A complete set of the Initial data, Fixed and Adjustable, can be downloaded at: http://www-ec.sdp.sel.sony.com/padics/Model_Data_List.htm
Initial data can is also available in an Excel format. Please contact Nita Wardlaw at [email protected].com with your request.
    
    
         
        
         
     
        
     
        
     

         
      
        
     
        
     
         
        
         
        
         
     
        
     
         
        
        
        
        
