Sony WEGA KDS-R70XBR2 User manual

KDS -R70XBR2
70"SXRDXBRRearProjectionTelevision
Key Features
FullHD1080(1920x1080/0.61”SXRDchip)PictureResolution
WEGAEngine ™HDSystem
DRCMF-V2.5
ContrastRatioupto10000:1withAdvancedIrisfunction
RemovableSpeakers
ATSCIntegratedTunerwithCableCARD™Slot
HDMI™(HighDefinitionMultimediaInterface)x3(1080pvideo)
PCInput(D-Sub15)
CineMotion ® Reverse3:2Pulldown
SRS ® TruSurround ® AudioEffect
Key Technologies
SXRD™Panels SXRD technology is the latest display technology developed by the legendary television
engineers at Sony to meet and exceed the demands of a High Definition image at its full 1080 line resolution.
Digitally transmitted High Definition signals can contain over 2 million individual detail points that need to be
displayed accurately and rapidly. SXRD displays those 2 million detail points per SXRD panel accurately since the
3 SXRD panels actually contain enough pixels to fully display a 1080 line picture without interlacing it.
SXRD has the speed to create a smooth, film like image. The SXRD panels have a blistering 5ms response time
(total rise and fall time), which exceeds the demands of even the most rapidly moving High Definition images. And
SXRD creates highly accurate, natural colors because the 3 - panel design displays all the colors, all the time.
Cinema Black Pro The Advanced Iris function is a special Sony function designed to improve contrast expression
especially in darker scenes. The Advanced Iris function is enabled by using either one of two modes, Auto and
Manual. The Auto Mode has two settings designed to work best with video content such as movies that vary
between bright scenes and dark scenes. Auto 1 is for programs that have a wide range of brightness from scene to
scene. Auto 2 is for programs that have less variation between brightness levels from scene to scene.
WEGA Engine ™HD WEGA Engine™HD Video Processor --- The latest generation of Sony’s exclusive WEGA HD
Engine™fully digital signal - processing path includes video processing functions that are designed to improve
overall picture quality. The WEGA Engine HD has similar functions to the WEGA Engine™ ( Green, blue and white
color enhancer circuit for a vivid image, Digital MPEG Noise Reduction Circuit reduces annoying MPEG artifacts,
and the Digital Contrast Enhancer circuit delivers crisp and vivid images with high contrast. The WEGA Engine HD
adds the following:
> DRC - MFv2.5: Sony’s exclusive video signal processing that improves video signals to a realistic and clean picture
quality according to signal types.
> CCP - XA: Generates high purity, high Signal - To - Noise ratio and enables the generation of wide bandwidth and
stable digital component signals.
> IFP2: Has functions that optimize contrast remove noise in the signal to reproduce video with little noise and blur.
HDMI™and PC Inputs Designed for maximum versatility, Sony’s Grand WEGA™ XBR ®line is equipped with a
comprehensive range of input interfaces. The HDMI (High - Definition Multimedia Interface) is the first industry -
supported, uncompressed, all - digital audio/video interface. HDMI technology supports enhanced or High Definition
video, together with multi - channel digital audio to provide matchless image and sound reproduction. The PC input
(D - Sub 15) offers easy connection to your PC, allowing you to use your high resolution Grand WEGA XBR TV as a
computer monitor.

SonyElectronicsInc. • 16530ViaEsprillo • SanDiego,CA92127 • 800.222.7669 • www.sony.com
LastUpdated:11/03/2006
KDS -R70XBR2
70"SXRDXBRRearProjectionTelevision
PleasevisittheDealerNetworkforcurrent
informationatwww.sony.com/dn
Features
General
Auto SAP: Yes
Channel Fix: Yes
ID1 Detection: Yes
Video Label: Yes
Video
Tuner: 8 VSB, ATSC, NTSC, Clear QAM,
CableCARD™ QAM
Video Processing: Yes (WEGA Engine ™HD
System)
Color Temperature: Cool, Neutral, Warm
Noise Reduction: Yes
Black Corrector: High, Medium, Low, Off
Clear White: On, Off
Gamma Compensation: High, Medium, Low,
Off
Live Color: Yes
CineMotion®Reverse 3:2 Pulldown
Technology: Yes
Direct Digital II Circuitry: Yes
Advanced Iris: Yes
Display Mode for PC Input: Video, Text
Comb Filter: 3D Digital Comb Filter
DRC®MultiFunction Circuitry: Yes (DRC MF
V2.5)
DRC®Mode: Mode 1, Mode 2, CineMotion®
Technology
DRC® Palette Presets: Custom 1, Custom 2,
Custom 3
Direct Mode: On, Off
Game Mode: On/Off
Advanced Video Menu: Yes
Picture Modes: Vivid, Standard, Pro
Detail Enhancer: High, Medium, Low, Off
Color System: ATSC, NTSC
Wide Mode: Yes
Display Technology: SXRD™Technology
High Definition: Yes (Full HD 1080)
Audio
Tone Control(s): Treble, Bass
Sound Mode: Dynamic, Clear Voice, Natural
MTS Stereo Decoder: Yes
Audio Mute: Yes
Speaker On/Off: Yes
Simulated Surround: Yes
SRS ®TruSurround®XT Audio Effect:Yes
Dolby® Digital: Yes
Convenience
Channel Label: Yes
Channel Skip/Add: Yes
Channel Jump: Yes
Favorite Channel: Yes
Speed Surf ™ Channel Selection: Yes
Program Guide Access: Yes
Auto Channel Programming: Yes
Info Banner: Yes
Programmable Timer: 2 Event
Sleep Timer: 15, 30, 45, 60, 90, Off
Caption Vision: On, Off, Program
Clock: Yes
Power Save Mode: Standard, Reduced, Picture
Off
Twin - View ™ Technology: Yes
Picture Freeze: Yes
Specifications
General
Aspect Ratio: 16:9
Screen Size: 70"
Television Type: Rear Projection
Video
Native Resolution: 1080p
Display Resolution: 1920 x 1080
Display Response Time: 2.5ms (rise and fall)
Vertical Size: Yes
Vertical Center: Yes
Horizontal Center: Yes
Inputs and Outputs
Analog Audio Input(s): 5 (1 Front/4 Rear)
Audio Out (Variable/Fixed): 1 (Rear)
CableCARD ™ Slot: 1 (Rear)
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)
Composite Video Input(s): 3 (1 Front/2 Rear)
Control-S Input(s): 1 (Rear)
Control- S Output(s): 1 (Rear)
Digital Audio Output(s): 1 (Rear) Dolby® Digital
Optical Output
RF Connection Input(s): 2 (Rear)
S -Video Input(s): 1 (Rear)
PC Audio Input(s): 1 (Rear)
PC Video Input(s): 1 (Rear)
HDMI ™ Connection(s): 3 (1 Side/ 2 Rear)- 1 rear
input has L/R audio inputs
Power
Power Consumption (in Operation): 285W
Power Consumption (in Standby): 0.2W
(without CableCARD)
Power Requirements: AC 120V, 60Hz
Power Management: Yes
Regulation and Standard Compliance
Energy Star ®Compliant: Yes
Service and Warranty Information
Limited Warranty: 1 Year Parts / 1 Year Labor
3
4
Dimensions
Weight: 154.32lbs (70.0kg)
Measurements: 75.4" x 46.2" x 24.5" (1885 x 1154
x 611mm) with speakers, 68.6" x 46.2" x
24.5" (1714 x 1154 x 611mm) without speakers
Supplied Accessories
Remote Control (RM- Y009)
Operating Instructions
Quick Start Guide
Batteries (AA x2)
Warranty
Product Registration Card
XL-5300 (extra lamp included)
Optional Accessories
SU -RS51U (AV Stand)
XL-5300 (180W Replacement Lamp)
UPC Code: 027242697812
1.With Advanced IrisON
2.Depending onusage, thelampwillrequireperiodic replacementto
maintainoptimum picturequality. Itisrecommendedthatthe lampbe
exchangedafter 8,000hours ofuse.
3.Screen Sizemeasured diagonally
4.For additionalwarranty termsandinformationpleaserefer tothe
LimitedWarranty Cardincluded withthis productorvisit
http://esupport.sony.com
©2006Sony ElectronicsInc. Allrightsreserved.
Sony,Grand WEGA,Steady Sound,WEGAEngineHD,Speed Surf,SXRD,
CineMotionand DRCare trademarksofSony. Inthe UnitedStates, TVGuide
andother relatedmarks areregisteredmarks ofGemstar - TVGuide
International,Inc. and/orone ofitsaffiliates.CableCARDis atrademark of
CableTelevision Laboratories,Inc. SRSandtheSRSsymbol, and
TruSurroundare trademarksof SRSLabs,Inc. ThisTV incorporatesHigh -
DefinitionMultimedia Interface(HDMI™ ) technology.HDMI, theHDMI logo
andHigh - DefinitionMultimedia Interfaceare trademarksor registered
trademarksof HDMILicensing LLC.Allothertrademarksare propertyof
theirrespective owners.
Featuresand specificationsare subjecttochange withoutnotice. Non -
metricweights andmeasures areapproximate.
