SNC-EM601
Network Mini Dome HD Camera – E Series
Vandal-resistant Mini Dome 720p/30fps Camera
Powered by IPELA ENGINE™ EX Technology
nMaximum resolution of 1280 x 1024 pixels with the Exmor®CMOS sensor
nExtremely Wide Dynamic Range to 130dB achieved with
View-DR®technology
nPicture mode to optimize picture quality in various applications
nDEPA™ Advanced Intelligent Video Analytics enhanced by unique
features such as face detection
nH.264 (High/Main/Baseline Profile)/JPEG video codecs
nMinimum illumination of 0.05 lx in Color and
0.04 lx in B/W (50 IRE @ 1/30 sec)
nIK10-rated vandal-resistant feature
nImage Stabilizer to help minimize the effect of camera shake or
vibration to achieve less blurry images
•IPELA ENGINE EX signal processing system developed based on
Sony’s unique signal processing and video analytics
technologies to provide unique features
such as View-DR®, XDNR®, and
DEPA™ Advanced technologies
•View-DR – Sony’s innovative wide dynamic range technology
– to capture objects clearly and adaptively even under very
harsh, severe backlight or highlight conditions
•Visibility Enhancer (VE) to optimize the brightness and color
reproduction of an image dynamically on a pixel-by-pixel basis
while continuously adapting to the scene within the given
dynamic range
•DEPA Advanced Intelligent Video Analytics to
trigger an alarm based on user-defined rules
•XDNR (eXcellent Dynamic Noise Reduction) technology for
clear images with virtually no motion blur under low illumination
•IK10-rated vandal-resistant feature to protect the camera from
destructive behaviors
•Picture mode selectable from a range of camera scenes in the
setting menu to optimize picture quality in various applications
•True D/N (Day/Night) function to switch to Day or Night mode
depending on the light level
•Built-in HTML viewer compatible with most Smartphones
•Easy Focus - allows installer/user to focus the camera remotely
using a PC or locally
•Easy Zoom - allows installer/user to change field of view locally
or remotely using a PC
•Powered by PoE (IEEE 802.3af-compliant) for easy installation
•ONVIF™ (Open Network Video Interface Forum)
Profile S conformance software that ensures
greater interoperability and more flexibility in
building multiple-vendor systems
•VBR (variable bitrate) or CBR (constant bitrate) compression
mode selectable to correspond with various network conditions
•Easy initial network settings with supplied SNC Easy IP Setup
Guide application
•Image Stabilizer to help minimize the effect of camera shake or
vibration to achieve less blurry images
KEY FEATURES
ON
OFF
Actual Images
Actual Images
OFF
ON

©2013 Sony Electronics Inc. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
Weights and measurements are approximate.
Sony, IPELA, IPELA ENGINE EX, Exmor, DEPA, XDNR,View-DR and
the Sony make.believe logo are trademarks of Sony.
Microsoft, Windows, Windows Vista and Internet Explorer are registered
trademarks of Microsoft Corporation in the United States and/or other countries.
Google and Google Chrome are trademarks of Google Inc. Safari is a trademark of Apple Inc
All other trademarks are the trademarks of their respective owners.
SPECIFICATIONS
DIMENSIONS
ø5 7/8 (148)
4 3/8 (108)
Unit: inches (mm)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
sony.com/security
S-IP2167 (MK11052V1) Printed in USA (9/13)
SNC-EM601
Camera
Image Sensor 1/3-type progressive scan Exmor CMOS
Number of Effective Pixels Approx. 1.37 Megapixels
Signal System NTSC
Sync System Internal synchronization
Minimum Illumination (50 IRE) Color: 0.05 lx (F1.2,View-DR OFF, VE OFF, AGC ON, 1/30s, 30 fps)
B/W: 0.04 lx (F1.2, View-DR OFF,VE OFF, AGC ON, 1/30 s, 30 fps)
Minimum Illumination (30 IRE) Color: 0.03 lx (F1.2,View-DR OFF, VE OFF, AGC ON, 1/30s, 30 fps)
B/W: 0.02 lx (F1.2, View-DR OFF,VE OFF, AGC ON, 1/30 s, 30 fps)
Dynamic Range Equivalent to 130 dB with View-DR technology
S/N Ratio More than 50 dB (Gain 0 dB)
Gain Auto
Shutter Speed 1/1 s to 1/10,000 s
Exposure Control Exposure compensation,AGC, Shutter speed,Iris
White Balance ATW, ATW-PRO, Fluorescent lamp, Mercury lamp, Sodium vapour
lamp, Metal halide lamp,White LED, One push WB, Manual
Lens Built-in varifocal lens
Easy Zoom Yes
Zoom Ratio Optical zoom 3x
Digital zoom 4x
Total zoom 12x
Easy Focus for Setup Yes
Horizontal Viewing Angle 93.0° to 31.6°
Vertical Viewing Angle 50.6° to 17.8°
Viewing Tilt Angle 121.5°
Focal Length f = 3.0 mm to 9.0 mm
F-Number F1.2 (Wide) to F2.1 (Tele)
Minimum Object Distance 300 mm
Pan/Tilt/Rotation Angle
(Manual)
Pan: ±192°
Tilt: -7° to +75°
Rotation: ±99°
Camera Features
Day/Night Yes (True D/N)
e-Flip Yes
Wide-D Yes (View-DR)
Tone Correction Yes (Visibility Enhancer (VE))
Noise Reduction Yes (XDNR)
Image Stabilizer Ye s
Picture Mode Yes
Privacy Masking (number) 20
Privacy Masking (shape) Quadrangle formed by any four corner points
Privacy Masking (color/effect) Opaque: 14 colors (Black, White, Red, Green, Blue, Cyan,Yellow,
Magenta, Gray (6 scales)), Mosaic
Vandal Resistant Yes (IK10)
Superimpose Number 3 independent positions for character (Codec, Date & time,
Event,Text (Max. 64 characters)),1 independent position for logo
mark
Superimpose Language English
Menu Language 15 Languages
(English, Japanese, Chinese (simplified), Chinese (Traditional),
French, Spanish, German, Italian, Korean, Portuguese, Russian,
Arabic, Hindi,Vietnamese, Thai)
Smartphone viewer Yes
Video
Resolution 1280 x 1024, 1280 x 960, 1024 x 768, 1280 x 720, 800 x 600,
720 x 576, 720 x 480, 704 x 576, 640 x 480, 352 x 288,
320 x 240 (H.264, JPEG)
Compression Format H.264 (High/Main/Baseline Profile), JPEG
Maximum Frame Rate H.264: 30 fps (1280 x 1024)
JPEG: 30 fps (1280 x 1024)
Bitrate Compression Mode CBR/VBR (selectable)
Range of Bitrate Setting 64 Kbps to 32 Mbps
Solid PTZ Yes
Adaptive Rate Control Yes (H.264)
Bandwidth Control Yes (JEPG)
Multi Streaming Capability Triple Streaming
Number of Clients 20
Intelligent Video Analytics
Analytics Architecture DEPA Advanced
Intelligent Motion Detection Yes
Face Detection Yes
Tamper Alarm Yes
Scene Analytics Passing,Appearance, Left Object Detection, Removed Object
Detection
SNC-EM601
System Requirements
Operating System Windows®XP™ (32 bit) Professional Edition
Windows®Vista™ (32 bit) Ultimate, Business Edition
Windows®7 (32/64 bit) Ultimate, Professional Edition
Windows®8 Pro (32/64 bit)
Processor Intel Corei7 2.8 GHz or higher
Memory 2 GB or more
Web Browser Microsoft®Internet Explorer®Ver. 7.0,Ver. 8.0,Ver. 9.0
Firefox®Ver. 3.5 (Plug-in free viewer only)
Safari®Ver. 4.0 (Plug-in free viewer only)
Google Chrome™ Ver. 4.0 (Plug-in free viewer only)
Network
Protocols IPv4,TCP, UDP,ARP, ICMP, IGMP*, HTTP, DHCP, DNS, NTP, RTP/RTCP,
RTSP over TCP, RTSP over HTTP, SMTP, IPv6, HTTPS, SNMP (v1, v2c, v3), SSL
Multicast Streaming Support Yes
ONVIF Conformance Yes (Profile S)
Authentication IEEE 802.1X
Interface
Analog Monitor Output for Setup Phono jack x1
Network Port 10BASE-T / 100BASE-TX (RJ-45)
General
Power Requirements PoE system (IEEE 802.3af compliant) Class 2
Power Consumption 5.0 W max.
Operating Temperature 14 °F to 122 °F (-10 °C to +50 °C)
Cold Start Temperature 32 °F to 122 °F (0 °C to 50 °C)
Storage Temperature -4 °F to 140 °F (-20 °C to +60 °C)
Operating Humidity 20% to 80%
Storage Humidity 20% to 95%
Dimensions (W x H x D) ø5 7/8 inches x 4 3/8 inches (148 mm x 108 mm)
Weight Approx. 1 lb 12 oz (800 g)
External Material Top cover: ABS + PC
Dome cover: PC
External Color Top cover: Munsell 4.4BG 8.4/0.2
Fire Retardant UL2044
Safety Regulations JATE Technical Standard (LAN)
UL2044, IEC60950-1 (CB)
VCCI (Class A), FCC (Class A), IC (Class A)
Emission: EN55022 (Class A) + EN50130-4
Immunity: EN55022 (Class A) + EN55024
Emission: AS/NZS CISPR22 (Class A)
KCC
EMC-TR
Supplied Accessories CD-ROM (supplied programs) (1)
Installation Manual (1)
Template (1)
Screw M3 (1)
Wrench (1)
Bracket (1)
Wire rope (1)
Safety regulations (1)
Optional Accessories YT-ICB600 (In-ceiling Bracket)
YT-LD601S (Smoked Dome Cover)
*SSM (Source Specific Multimedia) is supported.
