Sony SNC-M1 User manual

3-857-706-12 (1)
Network Camera
© 2004 Sony Corporation
SNC-M1/M1W
User’s Guide
Software Version 1.1

2
Owner's Record
The model and serial numbers are located on the bottom.
Record the serial number in the space provided below.
Refer to these numbers whenever you call upon your
Sony dealer regarding this product.
Model No. ____________________
Serial No. ____________________
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified
personnel only.
AC power adaptor
Model No.: 3A-211DA05
(ENG ELECTRIC CO., LTD.)
CAUTION: This unit is for use only with the supplied
AC power adaptor. Use with other AC
power adaptors may cause hazards such as a
fire.
WARNING
This unit has no power switch. Disconnect device of this
unit is the mains plug of the AC adaptor.
The mains plug on this equipment must be used to
disconnect mains power. Please ensure that the socket
outlet is installed near the equipment and shall be easily
accessible. In the event of abnormal operations,
disconnect the mains plug.
Caution
This installation should be made by a qualified service
personnel and should conform to all local codes.
Caution
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquid, such as vases,
shall be placed on the apparatus.
For customers in the U.S.A.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference wll not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and
receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV
technician for help.
If you have any questions about this product, you may
call:
Sony's Business Information Center (BIC) at
1-800-686-SONY (7669)
or Write to: Sony Customer Information Services
Center
6900-29, Daniels Parkway, PMB 330
Fort Myers, Florida 33912
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
WARNING
Declaration of Conformity (For SNC-M1 only)
Trade Name: SONY
Model No: SNC-M1
Responsible Party: Sony Electronics Inc.
Address: 16450 W. Bernardo Dr., San
Diego, CA 92127 U.S.A.
Telephone No: 858-942-2230

3
You are cautioned that any changes or modifications not
expressly approved in this manual could void your
authority to operate this equipment.
The shielded interface cable recommended in this
manual must be used with this equipment in order to
comply with the limits for a digital device pursuant to
Subpart B of Part 15 of FCC Rules.
For customers in Canada
This Class B digital apparatus complies with Canadian
ICES-003.
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of the
device.
The term “IC:” before the radio certification number
only signifies that industry Canada technical
specifications were met.
For customers in Europe
Hereby, Sony Corporation, declares that
this SNC-M1W is in compliance with
the essential requirements and other
relevant provisions of the Directive 1999/5/EC.
For details, please access the follwing URL:
http://www.compliance.sony.de/
ATTENTION
The electromagnetic fields at specific frequencies may
influence the picture of the unit.
Voor de klanten in Nederland
• Dit apparaat bevat een vast ingebouwde batterij die
niet vervangen hoeft te worden tijdens de levensduur
van het apparaat.
• Raadpleeg uw leverancier indien de batterij toch
vervangen moet worden. De batterij mag alleen
vervangen worden door vakbekwaam
servicepersoneel.
• Gooi de batterij miet weg maar lever deze in als klein
chemisch afval (KCA).
• Lever het apparaat aan het einde van de levensduur in
voor recycling, de batterij zal dan op correcte wijze
verwerket worden.
For Customers in Taiwan only
• You should keep in mind that the images or audio
you are monitoring may be protected by privacy
and other legal rights, and the responsibility for
making sure you are complying with applicable
laws is yours alone.
• Access to the images and audio is protected only
by a user name and the password you set up. No
further authentication is provided nor should you
presume that any other protective filtering is done
by the service. Since the service is Internet-based,
there is a risk that the image or audio you are
monitoring can be viewed or used by a third-party
via the network.

Table of Contents
4
Table of Contents
Overview
Features .................................................................. 5
How to Use This User’s Guide .............................. 6
Precautions ............................................................. 6
Operating Precautions ........................................ 6
System Requirements ............................................ 7
Preparation
Assigning the IP Address to the Camera ............ 8
Assigning the IP Address Using the Setup
Program ............................................................ 8
Accessing the Camera Using the Web Browser 10
Basic Configuring by the Administrator ........... 11
Operating the Camera
Logging in to Homepage — Welcome Page ...... 12
Logging in as a User ........................................ 12
Displaying the setting window for the
administrator directly ..................................... 12
About Viewers .................................................. 13
Configuration of Main Viewer ........................... 13
Main menu ....................................................... 14
Camera Control Section ................................... 14
Monitor Image .................................................. 14
Controlling the Monitor Image .......................... 15
Monitoring the camera image .......................... 15
Zooming in the monitor image ......................... 15
Capturing a monitor image ................................ 16
Capturing a monitor image .............................. 16
Saving the captured image ............................... 16
Administrating the Camera
Basic Operations of Administrator Menu ......... 17
How to set Administrator menu ....................... 17
Configuration of Administrator Menu ............. 18
Configuring the System — System setting
menu ..................................................................... 19
System Tab ....................................................... 19
Date & time Tab ............................................... 20
Initialize Tab ..................................................... 20
System log Tab ................................................. 21
Access log Tab ................................................. 21
Setting the Camera Image and Audio
— Camera setting Menu ..................................... 22
Common Tab .................................................... 22
MPEG4 Tab ...................................................... 23
JPEG Tab .......................................................... 23
Reset Tab ..........................................................24
Configuring the Network — Network setting
Menu .....................................................................24
Network Tab .....................................................24
Wireless network Tab (SNC-M1W only) .........25
Dynamic IP address notification Tab — Notifying
the IP Address .................................................26
Setting the User — User setting Menu ...............27
Setting the Security — Security setting Menu ..28
Sending a mail — e-Mail (SMTP) setting
Menu .....................................................................29
Setting Tab — Setting the SMTP Function ......29
Send trigger Tab — Setting mail sending
mode ...............................................................30
Sending Images to FTP Server (JPEG mode only)
— FTP Client setting Menu ................................31
Setting Tab — Setting the FTP Client
Function ..........................................................31
Send trigger Tab — Setting the Periodical FTP
sending mode ..................................................31
Setting the Motion Detection Function — Motion
detection setting Menu .........................................32
Setting the Motion Detection Area, Sensitivity and
Threshold level ...............................................33
Using DDNS Service – DDNS Setting Menu .....34
Others
Using the Supplied Setup Program ....................38
Starting the Setup Program ...............................38
Bandwidth Control Tab .....................................38
Date time Tab ....................................................39
Rebooting the Camera ......................................39
Using the SNC audio upload tool — Transmitting
Audio to Camera ..................................................40
Installing the SNC audio upload tool ...............40
Connecting the Camera to the Computer .........40
Using the SNC audio upload tool .....................41
Assigning the IP Address to the Camera Using
ARP Commands ...................................................42
Specifications ........................................................42
Glossary ................................................................43
Index ......................................................................45

Overview
Features 5
Overview
Features
The SNC-M1/M1W is a network camera equipped with
a built-in Web server.
The camera has the following features:
Monitoring using the Web browser
Real-time monitoring of the image and sound from the
camera is possible using the Web browser on the
computer.
MPEG4 video compression
MPEG4 video compression allows smooth streaming of
motion pictures with 30 fps (QVGA size). Motion JPEG
video streaming is also possible by selecting the JPEG
video compression format.
Offering video streaming in VGA size
The 1/4 type VGA CMOS sensor offers high-quality
video streaming in VGA size. (The frame rate in VGA
size is less than 30 fps.)
Built-in microphone
A microphone (monaural) is built in the camera. Also,
the built-in microphone jack (minijack, monaural)
accepts a commercially available plug-in-power
microphone (rated voltage: 2.4 V DC).
External speaker system can be
connected
The line output jack (minijack, monaural) allows
connection of a commercially available speaker system
with built-in amplifier so that the sound transmitted via
the network can be output from the connected speaker
system.
Sending the image and controlling
peripheral devices by synchronizing with
the motion detection function
A mail can be sent to the specified address in MPEG4
mode by synchronizing with the motion detection
function, or can be sent periodically to an FTP server in
JPEG mode.
Wireless network (SNC-M1W only)
No difficult wiring is required when using the wireless
LAN.
Supplied IP Setup Program
The camera is supplied with the IP Setup Program for
easy performance of the network setting.
NOTICE TO USERS
© 2004 Sony Corporation. All rights reserved. This
manual or the software described herein, in whole or in
part, may not be reproduced, translated or reduced to
any machine readable form without prior written
approval from Sony Corporation.
SONY CORPORATION PROVIDES NO
WARRANTY WITH REGARD TO THIS MANUAL,
THE SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN AND HEREBY EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE WITH REGARD TO THIS
MANUAL, THE SOFTWARE OR SUCH OTHER
INFORMATION. IN NO EVENT SHALL SONY
CORPORATION BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL
DAMAGES, WHETHER BASED ON TORT,
CONTRACT, OR OTHERWISE, ARISING OUT OF
OR IN CONNECTION WITH THIS MANUAL, THE
SOFTWARE OR OTHER INFORMATION
CONTAINED HEREIN OR THE USE THEREOF.
Sony Corporation reserves the right to make any
modification to this manual or the information contained
herein at any time without notice.
The software described herein may also be governed by
the terms of a separate user license agreement.
• Microsoft, Windows, Internet Explorer and MS-DOS
are registered trademarks of Microsoft Corporation in
the United States and/or other countries.
• Java is a trademark of Sun Microsystems, Inc. in the
United States and other countries.
• Intel and Pentium are registered trademarks of Intel
Corporation or its subsidiaries in the United States and
other countries.
• Adobe, Acrobat and Adobe Reader are trademarks of
Adobe Systems Incorporated in the United States and/
or other countries.
All other company and product names are trademarks or
registered trademarks of the respective companies or
their respective makers.

Overview
How to Use This User’s Guide / Precautions
6
How to Use This User’s
Guide
This User’s Guide explains how to operate the SNC-M1
or SNC-M1W Network Camera from a computer.
The User’s Guide is written to be read on the computer
display.
As this section gives tips on using the User’s Guide, read
it before you operate the camera.
Jumping to the related page
When you read the User’s Guide on the computer
display, click on the sentence to jump to the related page.
Software display examples
Note that the displays shown in the User’s Guide are
explanatory examples. Some displays may be different
from the ones which appear as you operate the
application software.
This User’s Guide instructs on SNC-M1 and SNC-M1W
at the same time. The illustrations of SNC-M1W are
mainly used in the instructions.
Printing the User’s Guide
Depending on your system, certain displays or
illustrations in the User’s Guide, when printed out, may
differ from those as portrayed on your screen.
Installation Manual (printed matter)
The supplied Installation Manual describes the names
and functions of parts and controls of the Network
Camera, connecting examples and how to set up the
camera. Be sure to read the Installation Manual before
operating.
Precautions
This Sony product has been designed with safety in
mind. However, if not used properly electrical products
can cause fires which may lead to serious body injury.
To avoid such accidents, be sure to heed the following.
Heed the safety precautions
Be sure to follow the general safety precautions and the
“Operating Precautions.”
In case of a breakdown
In case of system breakdown, discontinue use and
contact your authorized Sony dealer.
In case of abnormal operation
• If the unit emits smoke or an unusual smell,
• If water or other foreign objects enter the cabinet, or
• If you drop the unit or damage the cabinet:
1 Disconnect the camera cable and the connecting
cables.
2 Contact your authorized Sony dealer or the store
where you purchased the product.
Operating Precautions
Operating or storage location
Avoid operating or storing the camera in the following
locations:
• Extremely hot or cold places
• Exposed to direct sunlight for a long time, or close to
heating equipment (e.g., near heaters)
• Close to sources of strong magnetism
• Close to sources of powerful electromagnetic
radiation, such as radios or TV transmitters
• Locations subject to strong vibration or shock
Ventilation
To prevent heat buildup, do not block air circulation
around the camera.
Treatment of the lens cover
Take care not to stain, strike or press hard on the lens
cover. Such acts may inhibit optimun performance of the
camera and may cause a malfunction.
Transportation
When transporting the camera, repack it as originally
packed at the factory or in materials of equal quality.

Overview
System Requirements 7
Cleaning
• Use a blower to remove dust from the lens or optical
filter.
• Use a soft, dry cloth to clean the external surfaces of
the camera. Stubborn stains can be removed using a
soft cloth dampened with a small quantity of detergent
solution, then wipe dry.
• Do not use volatile solvents such as alcohol, benzene
or thinners as they may damage the surface finishes.
System Requirements
These are the requirements for the computer that
displays the image or controls the camera.
Processor
Pentium III, 1 GHz or higher (Pentium 4, 2 GHz or
higher recommended)
RAM
256 MB or more
OS
Windows 2000/XP
Web browser
Internet Explorer Ver. 5.5 or Ver.6.0

Preparation
Assigning the IP Address to the Camera
8
Preparation
The Preparation section explains what the administrator
has to prepare for monitoring the images after
installation and connection of the camera.
Assigning the IP
Address to the Camera
To connect the camera to a network, you need to assign
a new IP address to the camera when you install the
camera for the first time.
You can assign an IP address in two ways:
• Using the setup program stored in the supplied CD-
ROM (see page 8)
• Using the ARP (Address Resolution Protocol)
commands (see page 42)
This section explains how to assign an IP address to the
camera using the supplied setup program and how to
configure the network.
Before starting, connect the camera to a local network,
referring to “Connections” in the supplied Installation
Manual.
Use the network cable for connection when you
assign a new IP address to the camera (SNC-
M1W only).
Consult the administrator of the network about the
assigned IP address.
Assigning the IP Address Using the
Setup Program
1 Insert the supplied CD-ROM disc into your CD-
ROM drive.
After a short time a window will open displaying
the files on the CD-ROM.
2 Click the Setup icon of IP Setup Program.
The “File Download” dialog opens.
3 Click Open.
Note
If you click “Save this program to disk” on the “File
Download” dialog, you cannot install correctly.
Delete the downloaded file, and click Setup icon
again.
4 Install the IP Setup Program to your computer
following the wizard displayed.
If the Software License Agreement is displayed,
read it carefully and accept the agreement to
continue the installation.
5 Start the IP Setup Program.
The program detects the SNC-M1 or SNC-M1W
cameras connected to the local network and lists
them on the Network tab window.
6 Click on the camera to which you want to assign a
new IP address in the list.
The network settings for the selected camera are
displayed.
Tip
The factory setting of the camera network is as
follows.
IP address: 192.168.0.100
Subnet mask: 255.0.0.0
Wireless LAN setting (SNC-M1W only)
Type: Adhoc
SSID: snc-mw
Channel: 11 ch
WEP: Nothing

Preparation
Assigning the IP Address to the Camera 9
7 Set the IP address.
To obtain the IP address automatically from a
DHCP server:
Select Obtain an IP address automatically.
The IP address, Subnet mask and Default gateway
are assigned automatically.
To specify the IP address manually:
Select Use the following IP address, and type the
IP address, Subnet mask and Default gateway in the
relevant boxes.
8 Set the DNS server address.
To obtain the DNS server addresses
automatically:
Select Obtain DNS server address automatically.
To specify the DNS server addresses manually:
Select Use the following DNS server address, and
type the Primary DNS server address and
Secondary DNS server address in the relevant
boxes.
Note
The Third DNS server address and Fourth DNS
server address are invalid for this camera.
9 Set the HTTP port No.
Normally select 80 for the HTTP port No. To use
another port number, select the text box and type a
port number between 1024 and 65535.
10 Type the Administrator name and Administrator
password.
The default settings of both items are “admin.”
Note
You cannot change the Administrator name and
Administrator password on this display. To change
these items, See “Setting the User — User setting
Menu” on page 27.
11 Confirm that all items are correctly set, then click
OK.
If “Setting OK” is displayed, the IP address is
correctly assigned.
12 To access the camera directly, double-click the
camera name on the list.
The welcome page of the network camera SNC-M1 or
SNC-M1W is displayed.
Note
If the IP address is not set correctly, the welcome page
does not appear after step 12. In this case, try to set the
IP address again.

Preparation
Accessing the Camera Using the Web Browser
10
Accessing the Camera
Using the Web Browser
When the IP address has been assigned to the camera,
check that you can actually access the camera using the
Web browser installed in your computer.
Use Internet Explorer as the Web browser.
1 Start the Web browser on the computer and type the
IP address of the camera in the URL box.
The welcome page of “Network Camera SNC-M1”
or “Network Camera SNC-M1W” is displayed.
2 Click Enter.
The main viewer is displayed.
When the main viewer is correctly displayed, the IP
address assignment is completed.
When the main viewer of the camera is
displayed for the first time
When you click Enter, “Security warning” is displayed.
When you click OK, the ActiveX control is installed and
the main viewer is displayed.
Notes
• If Automatic configuration is enabled in the Local
Area Network (LAN) Settings on Internet Explorer,
the image may not be displayed. In this case, disable
Automatic configuration and set the Proxy server
manually. For setting the Proxy server, consult your
network administrator.
• When you install ActiveX viewer on Windows 2000
or Windows XP, you should have logged in the
computer as the Administrator.
Tip
Every page of this software is optimized as display
character size Medium for Internet Explorer.
To display the Welcome page correctly
To operate the welcome page correctly, set the security
level of the Internet Explorer to Medium or lower, as
follows:
1 Select Tool from the menu bar for Internet
Explorer, then select Internet Options and
Security tab in sequence.
2 Click the Internet icon (when using the camera via
the Internet) or Local intranet icon (when using
the camera via a local network).
3 Set the slider to Medium or lower. (If the slider is
not displayed, click Default Level.)
When using antivirus software in the
computer
• When you use antivirus software in your computer, the
camera performance may be reduced, for example, the
frame rate for displaying the image may be lower.
• The Web page displayed when you log in the camera
uses Java Script. The display of the Web page may be
affected if you use antivirus software in your
computer.

Preparation
Basic Configuring by the Administrator 11
Basic Configuring by the
Administrator
You can monitor the image of the camera only logging
in with the initial condition of this network camera. You
can also set various functions according to the install
position, network condition or purpose of the camera.
We recommend you configure the following items
before monitoring the image from the camera.
Setting contents Setting menu
Set the format of the image sent from the camera (MPEG 4 or JPEG). Video mode (page 22)
Select the quality of the image sent from the camera. MPEG4 Tab (page 23)
JPEG Tab (page 23)
Select the size of the image sent from the camera. Image size (page 22)
Select weather the audio from the camera microphone is sent or not. Microphone (page 22)
Accord date and time of the camera with those of the computer. Date & time Tab (page 20)
Set to send the monitor image attached to a mail. e-Mail (SMTP) setting Menu (page 29)
Set to send the image to the FTP server FTP Client setting Menu (page 31)
Set the access right of the user for the camera. Security setting Menu (page 28)

Operating the Camera
Logging in to Homepage — Welcome Page
12
Operating the Camera
The Operating the Camera section explains how to
monitor the image from the camera using the Web
browser. Use Internet Explorer as the Web browser.
The functions of the camera should be set by the
Administrator. For setting the camera, see
“Administrating the Camera” on page 17.
Logging in to Homepage
— Welcome Page
Logging in as a User
1 Start the web browser on the computer and type the
IP address of the camera you want to monitor.
The welcome page of Network Camera SNC-M1
or SNC-M1W is displayed.
2 Click Enter.
The main viewer appears.
Control the camera from the main viewer.
Note
If the Welcome page does not activate correctly, the
security level of the Internet Explorer may be set to
Medium or higher. See “To display the Welcome page
correctly” on page 10 and check the security level.
Displaying the setting window for
the administrator directly
When the administrator sets the camera functions, the
setting window can be displayed directly from the
welcome page.
1 Click Setting on the welcome page.
The following dialog appears.
2 Enter the user name and password for
Administrator, then click OK.
The user name “admin” and the password “admin”
are set at the factory for the Administrator. You can
change them on the User setting menu in the
Administrator menu (see page 27).
The Administrator menu appears.

Operating the Camera
Configuration of Main Viewer 13
About Viewers
This viewer can monitor the image in both video modes
MPEG4 and JPEG.
You have to install it when you access to the main viewer
at the first time.
When you are going to display the main viewer
of the camera for the first time
When you log in the network camera for the first time
(clicking Enter to enter the main viewer), the Security
Warning appears. Click Ye s and install ActiveX Control.
You can use all the functions of the viewer by using
ActiveX Control.
Notes
• If Automatic configuration is enabled in the Local
Area Network (LAN) Settings on Internet Explorer,
the image may not be displayed. In this case, disable
Automatic configuration and set the Proxy server
manually. For setting the Proxy server, consult your
network administrator.
• When you install ActiveX control on Windows 2000
or Windows XP, you should have logged in the
computer as the Administrator.
Tip
Every page of this software is optimized as display
character size Medium for Internet Explorer.
Configuration of Main
Viewer
This section explains the functions of the parts and
controls of the main viewer. For a detailed explanation
on each part or control, see the specified pages.
Main viewer
MPEG4 mode*
JPEG mode*
* Refer to the “Camera setting Menu” about the Video mode
(page 22).
Camera control
section
Monitor image
section
Main menu
Camera control
section
Monitor image
section
Main menu

Operating the Camera
Configuration of Main Viewer
14
Main menu
Setting
Click this button to display the setting menu for
Administrator menu. (See “Basic Operations of
Administrator Menu” on page 17.)
You can operate this function only when logging in as
the administrator.
Home
Displays the Welcome page.
Camera Control Section
Frame rate
(Displayed only when the camera Video mode (page 22)
is set to JPEG.)
Selects the frame rate to transmit images.
View size
Selects the view size to be displayed. (page 15)
Digital zoom
Click to change the size of the digital zoom. (page 15)
Capture
Click this button to capture a still image shot by the
camera and to store it in the computer. (See “Capturing
a monitor image” on page 16.)
(Volume)
(Displayed when the Microphone (page 22) is set to
On.)
Drag the bar of icon to adjust the volume.
When you click icon, the icon changes to and
the audio output stops. To output the audio, click
again.
Monitor Image
• The image shot by the camera is shown here. Date and
time is displayed at the top of the window.

Operating the Camera
Controlling the Monitor Image 15
Controlling the Monitor
You can monitor the camera image on the monitor
window of the main viewer.
Monitoring the camera image
1 Log in to the home page to display the main viewer.
You can see how to log in on page 12, “Logging in
as a User”.
2 Select the frame rate (only when the camera Video
mode is set to JPEG).
Click the Frame rate list box to select the frame
rate for transmitting the image. Selectable frame
rates are 1, 2, 3, 4, 5, 6, 8, 10, 15, 20, 25 and 30 fps.
The number means the frame number transmitted
per 1 second.
If you select 30 fps, the image is sent at the
maximum speed of the connected line (30 fps
maximum).
Note
The frame rate options indicate the maximum
number of frames that can be transmitted.
The number of frames actually transmitted may
vary depending on network environments and
camera settings (image size and image quality
settings).
3 Select the view size.
Click View size box list box to select the view size
from among Auto, 640 × 480, 320 × 240 and 160 ×
120.
Auto is determined by the image size specified with
Image size on the Camera setting page (page 22).
Zooming in the monitor image
1 Click Digital zoom icon.
2 Click the point you want to zoom in.
The image is expanded by about 2 times with the
clicked point at the center.
The digital zoom icon changes to .
3 To cancel zooming in, click icon.

Operating the Camera
Capturing a monitor image
16
Capturing a monitor
You can capture a monitoring image as a still image and
save it in the computer.
Capturing a monitor image
1 Monitor the camera image in the monitor window.
2 Click Capture icon.
The still image of the moment when you click is
captured, and the still image is displayed in the
monitor window.
3 To cancel the still image, click Cancel or Close.
Saving the captured image
1 Capture the monitor image.
2 Click Save.
Save As dialog appears.
3 Select JPEG or Bit map as Save as type.
4 Type on File name and specify Save in, then click
Save.

Administrating the Camera
Basic Operations of Administrator Menu 17
Administrating the Camera
The Administrating the Camera section explains how to
set the functions of the camera by the Administrator.
For monitoring the camera image, see “Operating the
Camera” on page 12.
This section explains the basic operations and each
option of the Administrator menu.
Basic Operations of
Administrator Menu
You can set all functions to suit the user’s condition in
the Advanced mode menu.
Click Setting in the welcome page or main viewer page
to display the Administrator menu.
How to set Administrator menu
1 Log in the home page to display the welcome page.
You can see how to log in on page 12 “Logging in
as a User”.
2 Click Setting in the welcome page.
The authentication dialog appears. Enter the user
name and password for Administrator.
Administrator menu appears.
The user name “admin” and password “admin” are
set at the factory for the Administrator.
The following steps also display the Administrator
menu.
1Click Enter in the welcome page to display the
main viewer.
2Click Setting icon in the main viewer.
3 Click the menu name (example: System) on the left
side of the Administrator menu.
The clicked setting menu appears.
Example: System setting menu
4 Select the tab above the setting menu, and set each
setting option in the tab.
Example: “System” setting menu “Date & time”
tab
See page 18 to 33 for details of setting menu tabs
and setting options.
5 After setting, click OK.
The setting contents become active.
Click Cancel to invalidate the set values and return to
the previous settings.
Buttons common to every setting menu
The following buttons are displayed on the setting
menus where they are necessary. The functions of the
buttons are the same on every setting page.
Click this button to validate the settings.
Click this button to invalidate the set values and return to
the previous settings.

Administrating the Camera
Basic Operations of Administrator Menu
18
General note on setting menus
After changing a setting on a setting menu, wait at least
10 seconds before turning off the power of the camera.
If the power is turned off immediately, the changed
setting may not be stored correctly.
Configuration of Administrator
Menu
System
Displays the System setting menu.
(“Configuring the System — System setting menu” on
page 19).
Camera
Displays Camera setting menu for setting of camera
image and audio. (“Setting the Camera Image and Audio
— Camera setting Menu” on page 22)
Network
Displays the network setting menu for setting of
network connection. (“Configuring the Network —
Network setting Menu” on page 24)
User
Displays the user setting menu for setting the user name
and the password to log in. (“Setting the User — User
setting Menu” on page 27)
Security
Displays the security setting menu for specifying the
computer allowed to connect to the camera. (“Setting the
Security — Security setting Menu” on page 28)
e-Mail (SMTP)
Displays the e-Mail (SMTP) setting menu for sending an
e-Mail. (“Sending a mail — e-Mail (SMTP) setting
Menu” on page 29)
FTP client
Displays the FTP client setting menu for sending an
image file to FTP server. (“Sending Images to FTP
Server (JPEG mode only) — FTP Client setting Menu”
on page 31)
Motion detection
Displays the Motion detection setting menu for the
motion detection function built into the camera.
(“Setting the Motion Detection Function — Motion
detection setting Menu” on page 32)
DDNS
Displays the *DDNS setting menu for registration and
change in DDNS service. (“Using DDNS Service –
DDNS Setting Menu” on page 34)
*DDNS: Dynamic Domain Name Service

Administrating the Camera
Configuring the System — System setting menu 19
Configuring the System
— System setting menu
When you click System on the Administrator menu, the
System setting menu appears.
Use this menu to perform the principal settings of the
software.
The System setting menu is composed of five tabs that
are System, Date & time, Initialize, System Log and
Access Log.
System Tab
Title bar name
Type a name to display on the title bar up to 32
characters. The characters typed here are displayed on
the title bar of the Web browser.
Serial number
Displays the serial number of the camera.
Software version
The software version of this camera is displayed.
Color
You can select the main viewer color from Light blue,
Blue or Metal.
Light blue
Blue
Metal
Notes
• The color of the welcome page and the Administrator
setting page cannot be changed.
• To reflect a selected color to the main viewer, log in
again after returning to the welcome page.
Language (only for CE model)
Set the language of the Administrator setting menu.
You can select from English, French, German, Spanish
or Italian.
Note
The language of Welcome page and Main viewer cannot
be changed.
OK/Cancel
See “Buttons common to every setting menu” on page
17.

Administrating the Camera
Configuring the System — System setting menu
20
Date & time Tab
Current date & time
Displays the date and time set on the camera.
Note
After you have purchased the camera, be sure to check
the date and time of the camera and set them if
necessary.
PC clock
Displays the date and time set on your computer.
Date & time format
Select the format of date and time to be displayed on the
main viewer from the drop-down list.
You can select from among yyyy-mm-dd hh:mm:ss
(year-month-day hour:minute:second), mm-dd-yyyy
hh:mm:ss (month-day-year hour:minute:second), and
dd-mm-yyyy hh:mm:ss (day-month-year
hour:minute:second).
Adjust
Select to set the day and time.
Keep current setting: Select when you do not need to
set the date and time.
Synchronize with PC: Select when synchronizing the
camera's date and time with those of the computer.
Manual setting: Select when you want to set the
camera's date and time manually.
Select the lower 2-digits of year, month, date, hour,
minutes and seconds from each drop-down list.
Synchronize with NTP: Select when synchronizing the
camera's date and time with those of the time sever
called NTP server (Network Time Protocol). Set the
NTP saver name and the Interval.
NTP server name
Type the host name or IP address of the NTP server, up
to 64 characters.
Interval
Select the interval at which you want to adjust the
camera's time referring to the NTP server' time, between
1 and 24 hours. The set interval is a guide, and does not
indicate the exact time.
Note
The setting time may not accord with the exact time
according to the network environment.
Time zone
Set the time difference from Greenwich Mean Time in
the area where the camera is installed.
Select the time zone where the camera is installed from
the drop-down list.
Adjust clock for daylight saving time changes
When you select it, the clock is adjusted according to the
daylight saving time of the selected time zone.
Notes
• If the time zone selected on the Time zone menu is
different from that set on the computer, the time is
adjusted using the time zone difference and set on the
camera.
• The daylight saving time adjustment works only when
Adjust is set to Synchronize with NTP.
OK/Cancel
See “Buttons common to every setting menu” on page
17.
Initialize Tab
Reboot
Reboots the camera.
Click Reboot, and “The SNC-M1 (or SNC-M1W) will
be rebooted. Are you sure?” appears. Click OK to
reboot the camera. It takes about two minutes to start
again.
