Sony STR-DH130 User manual

model name1[STR-DH130]
[4-294-472-11(1)]
filename[D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB01COV_STR-DH130-U2.fm] masterpage:Right
4-294-472-11(1)
FM Stereo
FM/AM Receiver
Operating Instructions
STR-DH130

2GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB02REG_STR-DH130-
U2.fm4-294-472-11(1)
masterpage: Left
STR-DH130
4-294-472-11(1)
To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture.
To reduce the risk of fire, do not cover the
ventilation opening of the apparatus with
newspapers, tablecloths, curtains, etc. Do not place
the naked flame sources such as lighted candles on
the apparatus.
Do not install the appliance in a confined space, such
as a bookcase or built-in cabinet.
To reduce the risk of fire or electric shock, do not
expose this apparatus to dripping or splashing, and
do not place objects filled with liquids, such as
vases, on the apparatus.
As the main plug is used to disconnect the unit from
the mains, connect the unit to an easily accessible
AC outlet. Should you notice an abnormality in the
unit, disconnect the main plug from the AC outlet
immediately.
Do not expose batteries or apparatus with battery-
installed to excessive heat such as sunshine, fire or
the like.
The unit is not disconnected from the mains as long
as it is connected to the AC outlet, even if the unit
itself has been turned off.
Excessive sound pressure from earphones and
headphones can cause hearing loss.
This symbol is intended to alert
the user to the presence of the Hot
Surface that may be hot if it is
touched during the normal
operation.
For customers in the United
States
Owner’s Record
The model and serial numbers are located on the rear
of the unit. Record these numbers in the space
provided below. Refer to them whenever you call
upon your Sony dealer regarding this product.
Model No. Serial No.
This symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
This symbol is intended to alert the
user to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9) Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has
two blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10)Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11)Only use attachments/accessories specified by
the manufacturer.
WARNING

3GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB02REG_STR-DH130-
U2.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
12)Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
13)Unplug this apparatus during lightning storms or
when unused for long periods of time.
14)Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
The following FCC statement
applies only to the version of
this model manufactured for
sale in the U.S.A. Other
versions may not comply with
FCC technical regulations.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment
and receiver.
– Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
You are cautioned that any changes or modifications
not expressly approved in this manual could void
your authority to operate this equipment.
To reduce the risk of electric shock, the speaker cord
should be connected to the apparatus and the
speakers in accordance with the following
instructions.
1) Disconnect the AC power cord from the MAINS.
2) Strip 10 to 15 mm of the wire insulation of the
speaker cord.
3) Connect the speaker cord to the apparatus and
the speakers carefully so as not to touch the core
of speaker cord by hand. Also disconnect the AC
power cord from the MAINS before
disconnecting the speaker cord from the
apparatus and the speakers.
For customers in Europe
Disposal of Old Electrical &
Electronic Equipment
(Applicable in the European
Union and other European
countries with separate
collection systems)
This symbol on the product or on its packaging
indicates that this product shall not be treated as
household waste. Instead it shall be handed over to
the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for the
environment and human health, which could
otherwise be caused by inappropriate waste
handling of this product. The recycling of materials
will help to conserve natural resources. For more
detailed information about recycling of this product,
please contact your local Civic Office, your
household waste disposal service or the shop where
you purchased the product.
continued

4GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB02REG_STR-DH130-
U2.fm4-294-472-11(1)
masterpage: Left
STR-DH130
4-294-472-11(1)
Disposal of waste batteries
(applicable in the European
Union and other European
countries with separate
collection systems)
This symbol on the battery or on the packaging
indicates that the battery provided with this product
shall not be treated as household waste.
On certain batteries this symbol might be used in
combination with a chemical symbol. The chemical
symbols for mercury (Hg) or lead (Pb) are added if
the battery contains more than 0.0005% mercury or
0.004% lead.
By ensuring these batteries are disposed of correctly,
you will help prevent potentially negative
consequences for the environment and human health
which could otherwise be caused by inappropriate
waste handling of the battery. The recycling of the
materials will help to conserve natural resources.
In case of products that for safety, performance or
data integrity reasons require a permanent
connection with an incorporated battery, this battery
should be replaced by qualified service staff only.
To ensure that the battery will be treated properly,
hand over the product at end-of-life to the applicable
collection point for the recycling of electrical and
electronic equipment.
For all other batteries, please view the section on
how to remove the battery from the product safely.
Hand the battery over to the applicable collection
point for the recycling of waste batteries.
For more detailed information about recycling of
this product or battery, please contact your local
Civic Office, your household waste disposal service
or the shop where you purchased the product.
Notice for customers: The following
information is only applicable to
equipment sold in countries applying
EU Directives.
The manufacturer of this product is Sony
Corporation, 1-7-1 Konan Minato-ku Tokyo,
108-0075 Japan. The Authorized Representative for
EMC and product safety is Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327 Stuttgart,
Germany. For any service or guarantee matters
please refer to the addresses given in separate
service or guarantee documents.
About This Manual
• The instructions in this manual are for model
STR-DH130. The model number is located at the
lower right corner of the front panel. The
illustrations used in this manual are of Europe
model and they may be different from your model.
Any differences in operation are marked in the
manual as “Europe model only”.
• The instructions in this manual describe the
operation of the receiver with the supplied remote
control. You can also use the buttons or knobs on
the receiver if they have the same or similar names
as those on the remote control.

5GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB01COV_STR-DH130-
U2TOC.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
Table of Contents
About This Manual........................................4
Supplied accessories......................................6
Description and location of parts...................7
Getting started .............................................13
Connections
1: Installing the speakers .............................13
2: Connecting the speakers..........................14
3: Connecting the audio/video equipment...14
4: Connecting the antennas (aerials)............17
5: Connecting the AC power cord
(mains lead) ............................................18
Preparing the Receiver
Initializing the receiver................................18
Selecting the speaker system .......................19
Adjusting the tone........................................19
Basic Operations
Playback ......................................................20
Viewing information on the display
panel .......................................................21
Recording using the receiver .......................22
Tuner Operations
Listening to FM/AM radio ..........................22
Presetting FM/AM radio stations
(Preset Tuning) .......................................24
Receiving RDS broadcasts ..........................26
(Europe model only)
Menu Operations
Using the setting menu ................................26
Using the Remote Control
Reassigning the input button .......................27
Resetting the input buttons ..........................28
Additional Information
Precautions.................................................. 29
Troubleshooting .......................................... 30
Specifications.............................................. 32
Index ........................................................... 34

6GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB01COV_STR-DH130-
U2TOC.fm
masterpage: Left
STR-DH130
4-294-472-11(1)
Supplied accessories
• Operating Instructions (this manual)
• Quick Setup Guide
• FM wire antenna (aerial) (1)
• AM loop antenna (aerial) (1)
• Remote control (RM-AAU130) (1)
• R6 (size AA) batteries (2)
Insert two R6 (size AA) batteries (supplied) by
matching 3and #on the batteries to the
diagram inside the battery compartment of the
remote control.
Notes
• Do not leave the remote control in an extremely hot
or humid place.
• Do not use a new battery with old ones.
• Do not mix manganese batteries and other kinds of
batteries.
• Do not expose the remote control sensor to direct
sunlight or lighting apparatuses. Doing so may
cause a malfunction.
• If you do not intend to use the remote control for an
extended period of time, remove the batteries to
avoid possible damage from battery leakage and
corrosion.
• When you replace or remove the batteries, the
remote control buttons may be reset to their default
settings. If this happens, reassign the input buttons
(page 27).
• When the receiver no longer responds to the
remote control, replace all the batteries with new
ones.
Inserting batteries into the
remote control

7GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB03DES_STR-DH130-
U2.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
Description and location of parts
A?/1(on/standby) (page 18, 24)
BSPEAKERS (OFF/A/B/A+B) (page 14, 19)
CINPUT SELECTOR (page 20, 22 - 25)
DDisplay panel
ERemote control sensor
Receives signals from remote control.
FMASTER VOLUME (page 20)
GMUTING (page 20)
HDIMMER
Adjusts the brightness of the display panel in 3
levels.
IDISPLAY (page 21)
JBASS +/–, TREBLE +/– (page 19)
KTUNING MODE, TUNING +/–, MEMORY/
ENTER (page 23, 25)
LFM MODE (page 23)
MPHONES jack (page 30)
Front panel
Indicators on the display panel
qsqd 0987qa
13
2456
SP A
SP B
MEMORY RDS
MONO SLEEP ST
qf qg
q
h
continued

8GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB03DES_STR-DH130-
U2.fm
masterpage: Left
STR-DH130
4-294-472-11(1)
NSP A/SP B
Lights up according to the speaker system used
(page 19). However, these indicators do not light
up if the speaker output is turned off or if
headphones are connected.
OSLEEP
Lights up when the Sleep Timer is activated
(page 11).
PTuning indicators
Lights up when the receiver tunes to a radio
station.
MEMORY
A memory function, such as Preset Memory
(page 24), etc., is activated.
RDS (Europe model only)
Tuned to a station with RDS services.
MONO
Monaural broadcast
ST
Stereo broadcast
Preset station number (The number will change
according to the preset station you select.)

9GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB03DES_STR-DH130-
U2.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
Rear panel
1 32
AAudio signal section (page 14, 16)
AUDIO IN/OUT jacks
PORTABLE IN jack
BANTENNA section (page 17)
FM ANTENNA jack
AM ANTENNA terminals
CSPEAKERS section (page 14)
White (L)
Red (R)

10GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB03DES_STR-DH130-
U2.fm
masterpage: Left
STR-DH130
4-294-472-11(1)
Use the supplied remote control to operate this
receiver and other equipment. The remote
control is assigned to operate Sony audio/
video equipment. You can reassign the input
button to match the equipment connected to
your receiver (page 27).
RM-AAU130
To control the receiver
Remote control
ws
wd
qh
qj
ql
qk
qg
1
2
5
qa
6
7
8
0
qd
9
3
wa
w;
4
qs
qf
B?/1*(on/standby)
Turns the receiver on or sets it to standby mode.
CInput buttons
Selects the equipment you want to use. When
you press any of the input buttons, the receiver
turns on. The buttons are assigned to control
Sony equipment.
GD.TUNING
Enters direct tuning mode.
HENTER/MEMORY
Stores a station during tuner operation.
IAMP MENU
Displays the menu to operate the receiver.
KMUTING
Turns off the sound temporarily.
Press the button again to restore the sound.
LMASTER VOL +**/–
Adjust the volume level of all speakers at the
same time.
NTUNING +/–
Scans a station.
PRESET +/–
Selects preset stations.
FM MODE
Selects the FM monaural or stereo reception.
PRETURN/EXIT O
Returns to the previous menu.
Q
Press V/v/B/bto select the settings, then press
to enter/confirm the selection.
RDISPLAY
Views information on the display panel.
TNumeric buttons**
Presets or tune to the preset stations.
,V/v/B/b

11GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB03DES_STR-DH130-
U2.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
* If you press AV ?/1(A) and ?/1(B)
simultaneously, the receiver and connected
equipment will turn off (SYSTEM STANDBY).
The function of the AV ?/1(A) changes
automatically each time you press the input
buttons (C).
**The number 5, MASTER VOL +/TV VOL +, and
Nbuttons have tactile dots. Use the tactile dots
as references when operating the receiver.
To control a Sony TV
Hold down TV (O), then press the button
printed in orange to select the function you
want.
Example: Hold down TV (O), then press
TV CH +.
* If you press AV ?/1(A) and ?/1(B)
simultaneously, the receiver and connected
equipment will turn off (SYSTEM STANDBY).
The function of the AV ?/1(A) changes
automatically each time you press the input
buttons (C).
**The number 5, MASTER VOL +/TV VOL +, and
Nbuttons have tactile dots. Use the tactile dots
as references when operating the receiver.
VSLEEP
Sets the receiver to turn off automatically at a
specified time.
Each time you press this button, the display
changes cyclically as follows.
0-30-00 t 1-00-00 t 1-30-00 t 2-00-00 t
OFF
When Sleep Timer is being used, “SLEEP”
indicator lights up in the display panel.
Tip
To check the remaining time before the receiver
turns off, press SLEEP. The remaining time
appears on the display panel. If you press
SLEEP again, the Sleep Timer will be canceled.
ATV ?/1(on/standby)
Turns the TV on or off.
HENTER/MEMORY
Enters the selections.
JTOOLS/OPTIONS
Displays the TV function options.
2
Press
TV CH +
1
Hold
down
TV
KMUTING
Activates the TV’s muting function.
LTV VOL +**/–
Adjusts the TV volume.
MMENU/HOME
Displays the TV menus.
NTV CH +/–
Scans for the preset TV channels.
PRETURN/EXIT O
Returns to the previous TV menu.
RDISPLAY
Displays information related to the current TV
program.
S-/--
Selects TV channel entry mode.
>10/x
Selects the channel numbers of the Digital
CATV terminal.
For example, to select 2.1, press 2, >10/x and 1.
TNumeric buttons**
Selects the TV channels.
WTV INPUT
Selects the input signal.
continued

12GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB03DES_STR-DH130-
U2.fm
masterpage: Left
STR-DH130
4-294-472-11(1)
To control other Sony equipment
a)If you press AV ?/1(A) and ?/1(B)
simultaneously, the receiver and connected
equipment will turn off (SYSTEM STANDBY).
The function of the AV ?/1(A) changes
automatically each time you press the input
buttons (C).
b)The number 5, MASTER VOL +/TV VOL +, and
Nbuttons have tactile dots. Use the tactile dots as
references when operating the receiver.
c)For MD deck only.
d)For example, to select 2.1, press 2, >10/xand 1.
Notes
• The above explanation is intended to serve as
examples.
• Depending on the model of your connected
equipment, some functions explained in this
section may not work with the supplied remote
control.
Name Blu-ray Disc,
DVD player
Satellite tuner,
Cable TV
tuner
VCR CD player MD deck,
Tape deck
AAV ?/1a) Power Power Power Power Powerc)
EPOP UP/MENU Menu––––
FTOP MENU On-screen
guide
––––
HENTER/MEMORY Enter Enter Enter Enter –
JTOOLS/OPTIONS Options menu Options menu – – –
MMENU/HOME Menu Menu Menu – –
N./>Skip track Select channel Search index Skip track Skip track
REPLAY /
ADVANCE Replay, fast forward
– Replay,
fast forward
––
m/MSearch forward,
backward
– Fast forward,
rewind
Fast forward,
rewind
Fast forward,
rewind
Nb) Play – Play Play Play
XPause – Pause Pause Pause
xStop – Stop Stop Stop
PRETURN/EXIT OReturn Return, exit – – –
QEnter Enter Enter Enter Enterc)
V/v/B/bSelect Select Select – –
RDISPLAY Display Display Display Display Displayc)
S-/-- –––––
>10/x–(.)dot
d) Track > 10 Track > 10 –
CLEAR ClearClear–––
TNumeric buttonsb) Track Channel Channel Track Trackc)

13GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB04CON_STR-DH130-
U2.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
Connections
Getting started
You can enjoy your audio/video equipment
connected to the receiver by following the
simple steps below.
1: Installing the speakers
This receiver allows you to use a 2.0 channel
system.
Example of speaker system
configuration
Installing and connecting the
speakers (page 13, 14)
Connecting the audio/video
equipment (page 14, 16)
Preparing the receiver
See “5: Connecting the AC power cord (mains
lead)” (page 18) and “Initializing the receiver”
(page 18).
Selecting the speaker system
(page 19)
Connections
Left
speaker
Right
speaker

14GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB04CON_STR-DH130-
U2.fm
masterpage: Left
STR-DH130
4-294-472-11(1)
2: Connecting the
speakers
Before connecting the cords, be sure to
disconnect the AC power cord (mains lead).
* If you have an additional speaker system, connect
them to the SPEAKERS Bterminals. You can
select the speakers you want to use with the
SPEAKERS (OFF/A/B/A+B) button on the
receiver (page 19).
3: Connecting the audio/
video equipment
Before connecting cords, be sure to disconnect
the AC power cord (mains lead).
* If you want to record, you must make this
connection (page 22).
10 mm
(13/32")
1
24
3
A
ASpeaker cords (not supplied)
A
Left speaker
Right speaker
SPEAKERS
B
terminals*
Connecting the audio equipment
Super Audio
CD player,
CD player
AAudio cord (not supplied)
BPhono cord with stereo headphone
jack (not supplied)
A
Portable
audio
B
MD deck,
Tape deck
A

15GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB04CON_STR-DH130-
U2.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
Connections
Notes
• When listening to a equipment connected to the
PORTABLE IN jack, sound may be distorted or
interrupted. This is not a malfunction and will
depend on the connected equipment.
• If the sound from the equipment connected to the
PORTABLE IN jack is very soft, you may increase
the volume level. However, before you switch to
other input, be sure to reduce the volume level to
avoid damaging your speaker.

16GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB04CON_STR-DH130-
U2.fm
masterpage: Left
STR-DH130
4-294-472-11(1)
Before connecting cords, be sure to disconnect the AC power cord (mains lead).
* If you want to record, you must make this
connection (page 22).
Connecting the video equipment
A
Satellite tuner,
Cable TV tuner
Blu-ray Disc player,
DVD player
AAudio cord (not supplied)
VCR,
DVD recorder
A
Audio signalsVideo
signals
To the VIDEO IN
jack of the TV.
Video
signals
To the VIDEO IN
jack of the TV.
To the VIDEO IN
jack of the TV. Audio
signals
A
Video
signals
Audio
signals

17GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB04CON_STR-DH130-
U2.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
Connections
Notes
• The default setting for the BD/DVD and VIDEO
input buttons on the remote control is as follows:
BD/DVD: Blu-ray Disc player
VIDEO: VCR
Be sure to change the default setting of the
BD/DVD (and VIDEO) input button so that you
can use the button to control your DVD player (and
DVD recorder). For details, see “Reassigning the
input button” (page 27).
• You can also rename the BD/DVD and VIDEO
input so that it can be displayed on the receiver’s
display panel. For details, see “Naming inputs”
(page 20).
4: Connecting the
antennas (aerials)
Before connecting antennas (aerials), be sure
to disconnect the AC power cord (mains lead).
Notes
• To prevent noise pickup, keep the AM loop
antenna (aerial) away from the receiver and other
equipment.
• Be sure to fully extend the FM wire antenna
(aerial).
• After connecting the FM wire antenna (aerial),
keep it as horizontal as possible.
FM wire antenna (aerial)
(supplied)
AM loop antenna (aerial)
(supplied)

18GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB04CON_STR-DH130-
U2.fm
masterpage: Left
STR-DH130
4-294-472-11(1)
5: Connecting the AC
power cord (mains lead)
Connect the AC power cord (mains lead) to a
wall outlet.
Initializing the receiver
Before using the receiver for the first time,
initialize the receiver by performing the
following procedure. This procedure can also
be used to revert back to the factory default
settings.
Be sure to use the buttons on the receiver to
perform this operation.
1Press ?/1to turn off the
receiver.
2Hold down ?/1for 5 seconds.
The “CLEARING” appears on the
display panel for a while, then changes to
“CLEARED”.
Changes or adjustments made to the
settings are now reset to the defaults.
AC power cord (mains lead)
To the wall outlet
Preparing the Receiver
?/1

19GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB04CON_STR-DH130-
U2.fm
masterpage: Right
STR-DH130
4-294-472-11(1)
Preparing the Receiver
Selecting the speaker
system
You can select the speakers you want to drive,
if you have connected the speakers to
SPEAKERS Aand Bterminals.
Be sure to use the buttons on the receiver to
perform this operation.
Press SPEAKERS (OFF/A/B/A+B)
repeatedly to select the speaker
system you want to drive.
To turn off the speaker output
Press SPEAKERS (OFF/A/B/A+B)
repeatedly until the “SP A” and “SP B”
indicators on the display do not light up.
Note
You cannot switch the speaker system by pressing
SPEAKERS (OFF/A/B/A+B) when the headphones
are connected.
Adjusting the tone
You can adjust the tonal quality of the
speakers.
Press TREBLE + or TREBLE –
repeatedly to adjust the treble
level.
Press BASS + or BASS –
repeatedly to adjust the bass level.
You can adjust from –10 dB to +10 dB in 1 dB
step.
The initial setting is 0 dB.
To select Light up
The speakers connected to the
SPEAKERS Aterminals
SP A
The speakers connected to the
SPEAKERS Bterminals
SP B
The speakers connected to both the
SPEAKERS Aand Bterminals
(parallel connection)
SP A
SP B
SPEAKERS (OFF/A/B/A+B)
TREBLE
+/–
BASS
+/–

20GB
D:\NORM'S JOB\SONY HA\SO0173\STR-DH130\4294472111_GB\GB05BAS_STR-DH130-
U2.fm
masterpage: Left
STR-DH130
4-294-472-11(1)
Playback
1Turn on the connected
equipment.
2Turn on the receiver.
3Press the input button which
corresponds to the equipment
you want.
You can also use INPUT SELECTOR on
the receiver.
The selected input appears on the display
panel.
Note
When you press TUNER, “FM TUNER” or
“AM TUNER” appears for a while, and then
frequency appears on the display panel.
4Play back the source.
5Press MASTER VOL +/– to
adjust the volume.
You can also use MASTER VOLUME on
the receiver.
To activate the muting function
Press MUTING.
The muting function will be canceled when
you do the following.
• Press the button again.
• Increase the volume.
• Turn off the receiver.
To avoid damaging your
speakers
Before you turn off the receiver, be sure to turn
down the volume level.
You can enter a name of up to 8 characters for
inputs (except TUNER) to appear on the
display panel.
It is more recognizable having the equipment
named on the display than the jacks.
1Press the corresponding input
button which you want to
create an index name.
You can also use INPUT SELECTOR on
the receiver.
2Press AMP MENU.
3Press V/vrepeatedly to select
“NAME IN”, then press or b.
The cursor flashes and you can enter a
character.
4Press V/vto select a character,
then press B/bto move the
input position backward and
forward.
Tips
• You can select the character type as follows
by pressing V/v.
Alphabet (upper case) tNumbers t
Symbols
• To enter a blank space, press bwithout
selecting a character.
Basic Operations
Input
buttons
,
V/v/B/b
AMP
MENU
MUTING
MASTER
VOL +/–
Naming inputs
