Sorelle Berkley 4 Drawer Chest User manual

Made in AY, Vietnam
Important Information:
Berkley 4 Drawer Chest
Assembly Instruction
Read all instructions BEFORE assembling crib.
KEEP INSTRUTIONS FOR FUTURE USE.
Website: www.sorellefurniture.com

Page 2
(A) Left Side Panel (x1) (B) Right Side Panel (x1) (C) Front - Top Rail(x1)
(D) Front-Middle Rail (x3) ( F ) Rear - Top Rail (x1)
( G) Rear - Middle Rail (x1) ( H) Rear - Bottom Rail
( J ) Back Panel (x1）
(x1) ( I ) Top Panel (x1)
SORELLE
(R4) Drawer Bottom (x4)(R3) Drawer Back (x4)
(R1) Drawer Left (x4)
(R2) Drawer Right (x4)
( R ) Drawer Front (x4)
Assembly Parts
(R5) Drawer Support (x4)
(E) Front- Bottom Rail (x1)

Page 3
Hardware list
SORELLE
( e ) Knob (x8)
Assembly Parts
(l) Allen Key (1 pc)
(m) Wall Strap Kit (1 pc) ( n ) Screwdriver (1 pc)
( d ) Plastic Connector (8 pcs) ( f ) 5/32 x 1”mm Allen bolt (8pcs)
(g)
8*25 Drawer Screw
(32 pcs)
(a) 1/4” x 1-3/8”mm Allen bolt (10 pcs) (b). Spring Washer ( 16 pcs)
( i ) Metal Connector A (4pcs)
( h ) Metal Connector B (4 pcs)
( j ) 7*12 Drawer Screw (12 pcs)
(c) Falt Washer (16 pc)
( k ) 8*15 Back Panel Screw (24 pcs)
(o) 1/4” x 1-1/8”mm Allen bolt (6 pcs)

A
Page 4
SORELLE
Berkley Double Dresser Assembly
Attach left side panel (A) to Rails as Fig.2
Attach Rails to Right Panel (B) as Figure 1.
1
2
Figure 2
Figure 1
b+c
a
X5
b+c
C
D
D
D
E
H
G
F
o
b+c
a
X5
B
b+c
o
X3
X3

Page 5
SORELLE
Berkley Double Dresser Assembly
Attach Top Panel ( J ) to Send panel as Figure 3.
3
Attach Top Panel ( I ) to Side panels by using 8 Plastic Connector ( d )
as Figure 4.
4
I
I
B
A
B
d
d
d
X 8
Figure 4
Figure 3

Page 6
SORELLE
Drawer Assembly
(j)
(j)
(h)
(i) (j)
g
g
g
g
5
4
3
2
1
3. Secure both sides of
Drawer Front (R) to drawer
assembly with four (4)
Screws (g). Figure 3.
Check all screws for
tightness.
5. Using Drawer Knob
Screw ( f ) , install one (1)
Knob ( e ) on Drawer.
Figure 5.
Repeat for all drawers.
Set drawers aside for
later use.
( e )
( f )
( n )
1.Working on a padded
flat surface,attach Drawer
Sides (R1&R2) to Drawer
Back (R3) with Philips Head
Screw(g). Figure 1
2. Slide Drawer Bottom (R4) and into drawer Bottom
Support (R5) assembly. Figure 2
4. Attach Matel Connector A ( i )and
Matel Connector B (h). Figure 4
(R3)
(R2)
(R4)
(R)
(R5)
(R1)

J
I
A
Page 7
Figure 7
Figure 6
SORELLE
Berkley Double Dresser Assembly
Assembly the drawer as Figure 6.
6
Use 24 pcs Wood Screws (d) to attach the Back Panel (K) to the dresser
As shown in Figure 7..
7
k (24x)
