Sound Projections SM-4neo User manual

User Guide
Sound Machine SM-4neo
Warranty statement.
Sound Projections Six Year Limited Warranty.
The Sound Machine SM-4neo is warranted to be free of defects in materials and
workmanship for a period of 6 years from the date of original purchase, subject to
the following conditions:
• This warranty excludes defects caused by normal wear, abuse, shipping
damage or failure to use product in accordance with instructions. All
warranty service must be performed or authorized by Sound Projections.
Any service or modifications performed without authorization from Sound
Projections may void this warranty.
• The Ni-MH rechargeable battery in SM-4neo models is warranted for a
period of 3 years.
• Wireless microphone and CD/MP3 player options are warranted for a
period of two years.
• Prior to returning your system for repair and/or warranty service, please
contact our customer service department at the address below for a
Return Authorization (RA) number.
Sound Projections
22130 South Vermont Avenue, unit E
Torrance, California 90502
[phone]
www.soundprojections.com 560-21 Rev A, SM-4neo, 07/07

15
Replacing the fuse.
Warning! Replace fuse with same type and
rating as indicated on panel.
1. Remove power cord plug from panel
mounted AC receptacle
2. Pry fuse carrier away from receptacle
with small screwdriver
3. Remove fuse to be replaced.
4. Install new fuse
5. Insert fuse carrier with new fuse back into receptacle
6. Plug power cord back into AC receptacle
Specifications for SM-4neo.
Rated power output.................................................200 watts dynamic
Max SPL .................................................................127 dB ‘loud’ mode
................................................................................120 dB ‘normal’ mode
Frequency response ...............................................65 Hz - 16 kHz
Wireless system (optional)......................................Shure 90 channel auto-scan
Battery life ...............................................................4-8 hours typical
Power requirements................................................110/240 VAC - 50/60 Hz, 200 watts max
Dimensions (HWD) .................................................23 x 15 x 13” (58 x 38 x 33cm)
Weight.....................................................................33 pounds (15 kg)
Inputs ......................................................................(2) mic level, balanced, XLR
................................................................................(1) line level, balanced, XLR
................................................................................(1) line level, 1/4" phone
................................................................................(1) tape/CD level, dual RCA
Outputs....................................................................(1) line level, balanced, XLR
................................................................................(1) line level, 1/4" phone
................................................................................(1) tape/CD level, dual RCA
................................................................................(1) speaker output
Specifications and models subject to change without notice
install
fuse
2
Welcome
Congratulations on purchasing a portable sound system from Sound Projections.
Our products combine superior design with quality components and rugged
construction. We’re proud of the products we manufacture, and appreciate the
confidence you’ve shown by choosing us.
Please take a few of minutes to read this user guide. Our products incorporate
many unique features, and your knowledge of them will enhance the performance
of your system.
John Munroe, President
and the entire staff at Sound Projections
Unpacking
System inspection and inventory.
Check the unit carefully for damage which may have occurred during transit, and
contact the freight carrier immediately should you find damage.
Save the shipping carton and packing materials.
The shipping box was designed to ship your unit safely.
Contents
Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Charging the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Choosing an input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Wireless microphone operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Wireless system set-up (channel frequencies) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using talkover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CD operation (see separate instructions)
Setting the EQ controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Changing the fuse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Warranty Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

14
Using the outputs.
output
L
R
twoone
tape
line output
Connect RCA outputs
to a tape player’s
input to record the
sound system.
The tape output is a line-
level, summed and compos-
ite signal of the sound sys-
tem inputs.
Connect line output
one to the balanced
input of another sys-
tem for daisy-chain
applications.
Line output one is a bal-
anced, low-impedance and
composite signal of the
sound system inputs.
Connect line output
two to a tape player’s
input to record the
sound system.
Line output two is an unbal-
anced, line-level and com-
posite signal of the sound
system inputs.
3
Important safeguards
CAUTION: To reduce the risk of electric shock, do not remove the cover. No user-
serviceable parts inside. Refer servicing to qualified personnel.
ATTENTION: Pour eviter les risques de choc électrique, ne pas enlever le
couvercle. Aucun entretien de pièces intérieures par l'usager. Confier l'entretien
au personnel qualifié.
WARNING: To prevent fire or electric shock, do not expose this equipment to rain
or moisture.
AVIS: Pour eviter les risques d'incendie ou d’électrocution, n'exposez pas cet
article à la pluie ou a l'humidité.
Explanation of graphical symbols.
The lightning flash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magni-
tude to constitute a risk of electric shock to humans.
The exclamation point, within an equilateral triangle, is intended to alert
the user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Explication des symboles graphiques.
Le symbole éclair avec point de flèche à l'intérieur d'un triangle
équilatéral est utilisé pour alerter l'utilisateur de la presence à l'intérieur
du coffret de “voltage dangereux” non isolé d'ampleur suffisante pour
constituer un risque d'elétrocution.
Le point d'exclamation à l'intérieur d'un triangle équilatéral est employé
pour alerter les utilisateurs de la présence d'instructions importantes
pour la fonctionnement et l'entretien (service) dans le livret d'instruction
accompagnant l'appareil.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
CAUTION AVIS

13
Using talkover.
Press the red button to use the “talkover” feature, which auto-
matically lowers the volume of all other inputs (including optional
CD) when speaking on the microphone.
When to use talkover.
Use talkover when making voice announcements over music or other program
material being played through the sound system (without having to manually
adjust the other volume controls). When you stop speaking into the micro-
phone, the volume on other inputs smoothly returns to normal in 3 seconds.
Note: The talkover feature is assigned to optional wireless mic 1 if installed;
otherwise, it is assigned to the mic 1 XLR input.)
CD/MP3 player operation.
See separate instructions for operation and features of the CD/MP3 player.
Setting the EQ controls.
Use the 3 equalizer tone controls to adjust for best sound quality and clarity. The
top-center mark indicates a ‘flat’ response.
For outdoor / voice applications:
Set the voice switch to “loud” for outdoor and other applications where powerful
voice projection is needed.
Turn the “low” control to the 9 o’clock position for maximum voice clarity
(reducing the bass level will also increase battery life).
For indoor and/or music playback:
Set the controls to the flat (12 o’clock) position, then adjust for desired sound
quality (be sure the voice switch is in the “normal” position).
Set the voice switch to the “normal” position when playing music and for most
indoor applications.
low highmid
voice
loud
norm
equalizer
4
Getting started.
Whether you’re a first-time user or an experienced presentation professional, the Sound
Machine SM-4neo was designed with you in mind. Easy to use and loaded with features,
you’ll need only a few minutes to set up and begin operation. This user guide is full of
valuable information — please read it!
!! Charge the battery!
Your SM-4neo is shipped with the battery fully charged. If stored for more than
two weeks before use, plug it in to top off the battery. See “Charging the battery”
on page 5.
1. Set up the sound system in front of your audience.
Proper set-up is important. For best sound distribution, put the unit on a
speaker stand or table so the sound projects over the audience.
Connecting an SM-4C Companion Speaker.
For expanded crowd coverage, connect unpowered
companion speaker SM-4C to the speaker output
jack on the lower panel of the Sound Machine.
Note: The speaker output is designed
specifically for use with the Sound Machine SM-4C companion
speaker and SC50-4W or SC100-4W cable — DO NOT use other
type external speakers or damage may result!
2. Plug a microphone or audio source into an input jack.
Connect a microphone, tape player or other source to the matching input jack;
turn down the corresponding volume knob
before turning on the SM-4neo.
(See “Choosing an Input” on pages 6-7
for more information on input selection.)
If using the optional wireless microphone
system, use the corresponding knob to
control the input volume.
Note: See separate instructions for operation of the CD/MP3 player.
one two one two
input
L
R
tape/cd
line inputmic input
talkover
on off

5
3. Turn the power switch ON
(plug in power cord for AC operation).
Observe LED indicators to confirm
battery level and power.
Battery Power (upper LED’s): The green light indicates the battery is at or
near full charge and ready to use. The yellow light means 30-60% usage
remains, and red means less than 30% remains and that the battery should
be charged before use (see “Charging the battery.” )
AC Power (lower LED): The SM-4neo automatically runs on AC power when-
ever the unit is plugged in and turned on. The green indicator on the bottom
row will light indicating full AC operation.
4. Adjust the volume level and sound quality.
Increase the volume of the input being used to desired level (be sure the
microphone or input source is turned on!) Adjust equalizer and set voice
switch as necessary (see pages 6, 7 and 9 for more details).
Charging the battery.
!! For maximum operating time, charge the battery after
EVERY use.
While it does not harm the battery if the unit is left in a partially discharged
state, over time the battery's self discharge will result in a low battery.
Optimum charging is achieved when the battery is charged between 0 and 40
degrees Centigrade (32 - 104° F). If the outdoor environment is unusually
warm or cold, bring the system indoors before charging. (The Sound Machine
may be left plugged into an AC outlet during storage for optimum results.)
Charging the battery.
Turn the system “off” and plug the cord into a standard AC outlet
to charge the battery. The unit automatically begins charging,
indicated by the flashing charge LED.
When the charge LED lights steady, the battery is fully charged
and the unit is ready for use or storage.
flash =
charging
12
Dual wireless system set-up.
Follow these steps to set-up a Sound Machine with two wireless systems:
1. Turn the sound system “on”, and turn all transmitters “off”.
2. Perform Automatic Frequency Selection on the first receiver (see page 11).
3. Turn the first transmitter “on.”
4. Perform Automatic Transmitter Setup (see page 11).
Leave the first transmitter on. Repeat for steps 2-4 for the second system.
!! Note: Be sure that only one transmitter’s IR port is exposed when syn-
chronizing a system.
Manual Frequency Selection (receiver only)
To manually select a group or a channel, press and hold the channel button.
The display alternates between the group number and the channel number.
Releasing the channel button while either number is displayed makes that
displayed number flash. Then, press the channel button while the number is
flashing to increase the setting by one.
To activate the newly-selected group or channel, simply wait until the number
stops flashing.
Receiver locking feature.
The wireless receiver has a locking feature which prevents accidental channel
changes.
• To lock the channel: Hold the channel button until both numbers flash
(approximately 10 seconds).
• To unlock the channel: Hold the channel button until both numbers flash
(approximately 5 seconds).
hold channel
button
to change the group
value, release the
channel button while
the first digit displays…
…then press the
channel button to
increase the value.
to change the channel
value, release the
channel button while the
second digit displays…
…then press the
channel button to
increase the value.

116
Wireless system set-up.
Each transmitter and receiver pair must be the same frequency, or channel. The
Shure wireless system uses transmitter setup to synchronize the transmitter and
receiver channels.
Note: transmitting devices such as cellular phones may interfere with wireless
audio transmissions. Keep transmitters and receivers away from these and
other potential sources of interference.
Single wireless system set-up.
1. Automatic Frequency Selection: Press and release the channel button.
This scans for a clear channel and sets the receiver to that channel.
2. Automatic Transmitter Setup: Turn transmitter “on”. Open the transmitter’s
battery compartment to display the infrared (IR) port (see pages 9 and 10).
With the transmitter IR port exposed to the wireless receiver, press and
release the sync button until the red light stops flashing on both receiver
and transmitter.
When the receiver’s ready light glows green, the system is ready for use.
Close the transmitter battery compartment.
LED screen displays
current channel press channel button to scan for a clear channel
system scans for
clearest available
channel
Choosing an input.
one two one two
input
L
R
tape/cd
line inputmic input
Plug a microphone with an
XLR connector into mic input
one or two. The knob above
the jack controls the volume
level.
The mic inputs are balanced and low
impedance, and supply phantom
power (10 volts) for condenser type
microphones.
When using long mic cables, use a
balanced microphone to help prevent
hum and interference.
Plug a balanced, line-level
source with an XLR connector
(such as the output from a
mixer) into line input one. The
knob above the jack controls
the volume level.
Line input one is a balanced line level
input.
Use shielded cable to avoid hum or
interference.
To daisy-chain two sound systems
together for greater crowd coverage,
connect the line output from one
system into line input one.

710
Operating the body-pack mic/transmitter.
Indicator LED for Power / Infrared (IR) / Mute
On-Off / Mute switch: Press and hold to turn “on” (LED green), press and
hold for 2 seconds to turn “off.” To mute or unmute, press and release.
4-Pin Microphone Input Jack.
IR port: Receives infrared beam to synchronize frequencies.
Note: When using multiple systems, only one transmitter IR port should
be exposed at a time.
Gain adjustment switch (see instructions below)
Changing batteries.
Install 2 new AA alkaline batteries in the transmitter for
best results; expected life is approximately 8 hours.
When the transmitter light glows red, replace the batteries.
Adjusting gain.
Three gain settings are available:
•mic: low-output microphone.
•0: high-output microphone, guitar
•-10: Use only if audio is distorted due to high input level.
1
one two one two
input
L
R
tape/cd
line inputmic input
Plug any line-level source with
a 1/4" phone plug (tape player,
music instrument, etc) into
line input two. The knob
above the jack controls the
volume level.
Line input two is an unbalanced line
level input.
Use shielded cable to avoid hum or
interference.
Plug the outputs from a tape
player or external CD player
with RCA jacks into the
tape/cd input. The knob
above the jack controls the
volume level.
The tape/cd input is a line level input.
This is a summing input, meaning the
left and right channels will combine for
a mono input signal.
1
2
3
4
5
Green Ready
Flashing green Controls locked (see “locking feature” pg 9)
Amber Mute on
Flashing red IR transmission in process
Glowing red Battery power low
Pulsing red on
startup Batteries dead (transmitter cannot be turned on until batteries are charged)
Pulsing red after
synchronization Frequency group incompatible; check transmitter group.

9
Operating the handheld wireless mic/transmitter.
Indicator LED for Power / Infrared (IR) / Mute
On-Off / Mute switch: Press and hold for 2 seconds to turn “on” (
LED green),
press and hold again to turn “off.” To mute or unmute, press and release.
IR port: Receives infrared beam to synchronize frequencies.
Note: When using multiple systems, only one transmitter IR port should
be exposed at a time.
Changing batteries.
Install 2 new AA alkaline batteries in the transmitter for best
results; expected battery life is approximately 8 hours.
When the transmitter light glows red, replace the batteries.
Transmitter locking feature.
The transmitter (handheld and body-pack) has a locking feature which prevents
accidental muting or turning off during performance.
• To lock the controls: With the transmitter “off”, hold the power button
down until the green LED flashes (approximately 5 seconds).
• To unlock the controls: With the transmitter “on”, hold the power button
down until the green
LED flashes (approximately 5 seconds).
1
8
1
2
Green Ready
Flashing green Controls locked (see “locking feature” below)
Amber Mute on
Flashing red IR transmission in process
Glowing red Battery power low
Pulsing red on
startup Batteries dead (transmitter cannot be turned on until batteries are charged)
Pulsing red after
synchronization Frequency group incompatible; check transmitter group.
3
Wireless system operation.
The Sound Machine SM-4neo is available with single or
dual built-in Shure wireless receivers. The instructions on
the following pages describe how to set-up and operate
the receiver units and wireless transmitters.
Operating the optional wireless mic system.
The built-in wireless receiver(s) turn on automatically when the Sound Machine is
turned “on.” Raise the paired left/right antennas up and
out at a slight angle; single wireless options will have
two antennas, dual wireless will have four. Also, note
the location of the wireless mic volume controls on the
Sound Machine’s rear panel.
Features and controls of the built-in wireless receiver.
audio LED: Indicates strength of incoming audio signal:
green for normal, amber for strong, red for peak.
Channel number readout: See “Single System Setup” on page 11.
channel button: See “Single System Setup” on page 11.
ready LED: Green light indicates wireless system is receiving signal.
Infrared (IR) port: Broadcasts IR signal to transmitter.
sync button: Press and release to synchronize transmitter and receiver
frequencies.
audio channel ready
sync
1 2 3 4 5 6
1
2
3
4
5
6
twoone twoone
wireless mic wireless mic
