SoundPeak SP-1500.2 dbPRO User manual

OWNER'S MANUAL
Super Natural Sound
High Performance Technology
SP-1500.2 dbPRO
SP-2000.2 dbPRO
SP-2300.2 dbPRO

FEATURES
-2-
[SP-1500.2 dbPRO]
2/1 Channel Bridgeable Class A/B Amplifier
MOSFET PWM Power Supply
Stable into 1 Ohm Load Workable
24dB Octave Crossover Slope
Variable Low Pass Filter (LPF)
Variable High Pass Filter (HPF)
HPF/FULL/LPF Selectable Switch
Variable Bass Boost
On/Off Switch
RCA Line Input and Output
Multi-Way Protection circuitry (Thermal/Over Current/Speaker Short /Speaker DC protection)
Tested Voltage & THD:14.4V & Less than 0.05% THD
Operating Voltage : DC10V~15.5V Power Input
Wired Remote Controller
Subsonic
[SP-2000.2 dbPRO]
2/1 Channel Bridgeable Class A/B Amplifier
MOSFET PWM Power Supply
Stable into 1 Ohm Load Workable
24dB Octave Crossover Slope
Variable Low Pass Filter (LPF)
Variable High Pass Filter (HPF)
HPF/FULL/LPF Selectable Switch
Variable Bass Boost
On/Off Switch
RCA Line Input and Output
Multi-Way Protection circuitry (Thermal/Over Current/Speaker Short /Speaker DC protection)
Tested Voltage & THD:14.4V & Less than 0.05% THD
Operating Voltage : DC10V~15.5V Power Input
Wired Remote Controller
Subsonic
[SP-2300.2 dbPRO]
2/1 Channel Bridgeable Class A/B Amplifier
MOSFET PWM Power Supply
Stable into 1 Ohm Load Workable
24dB Octave Crossover Slope
Variable Low Pass Filter (LPF)
Variable High Pass Filter (HPF)
HPF/FULL/LPF Selectable Switch
Variable Bass Boost
On/Off Subsonic Switch
RCA Line Input and Output
Multi-Way Protection circuitry (Thermal/Over Current/Speaker Short /Speaker DC protection)
Tested Voltage & THD:14.4V & Less than 0.05% THD
Operating Voltage : DC10V~15.5V Power Input
Wired Remote Controller

MaxMin 30Hz 500Hz50Hz 18dB0dB
ONOFF
INPUT OUTPUT
LPF
CH1/L
CH2/R
CH1/L
CH2/R
250Hz
FULL
LPF HPF
HPFSENSITIVITY
REMOTE
SUB
SONIC
BASS
BOOST
Prot.
Power
-3-
RCA CONNECTION
HEAD UNIT
to INPUT of ADDITIONAL
AMPLIFIERS
Wired Remote
Control
[SP-1500.2 dbPRO / SP-2000.2 dbPRO / SP-2300.2 dbPRO]
The amplifier is equipped with RCA type signal input for low level input.
To adjust input levels and to balance both channels, use both channels' gain controls.

Caution
SPEAKER OUTPUT
CH1 CH2
BRIDGE
POWER
GND REM B+
POWER CONNECTION
BATTERY
HEAD UNIT
to REMOTE Turn-on
from HEAD UNIT
GROUND
[SP-1500.2 dbPRO / SP-2000.2 dbPRO / SP-2300.2 dbPRO]
Recommended Ampere
SP-1500.2 dbPRO:150A (External Type Fuse)
SP-2000.2 dbPRO:250A (External Type Fuse)
SP-2300.2 dbPRO:300A (External Type Fuse)
First make the ground connection, then +12V wire connection, and finally the remote
connection. Furthermore, the +12V wire must always be fused at the battery to
protect the amplifier from possible damage. If you need to replace the power fuse,
replace it with a fuse of the same value. It may cause serious damage to your amplifier
and/or your vehicle if you use fuses with different type or rating.
+12V Power
Connect B+ terminal of the amplifier to the + terminal of the battery using the wire that
has the same diameter of the ground cable.
Make sure you install in-line fuse holder approximately 300 to 400 mm away from
the + terminal of the battery. Please ensure
that there is no fuse in the battery holder.
GROUND
Disconnect the battery and connect the GND (ground) terminal to the cars chassis.
Keep this cable as short as possible (no longer than 500 mm).
Making sure that the connection with the chassis is rust free and clear of paint or grime.
REMOTE
Connect the REM terminal of the amplifier to the power antenna terminal in the car
ignition switch using 12 or 16 ga. electrical wire.
-4-

-5-
SPEAKER OUTPUT
CH1 CH2
BRIDGE
SPEAKER OUTPUT
CH1 CH2
BRIDGE
SPEAKER OUTPUT
CH1 CH2
BRIDGE
SPEAKER CONNECTION
[SP-1500.2 dbPRO / SP-2000.2 dbPRO / SP-2300.2 dbPRO ] 1 Channel Bridged
3 Channel Tri Mode
CH2
Speaker Impedance
2~8 ohms
2 Channel Stereo
CH1
Speaker Impedance
1~8 ohms
CH3-MONO
SUBWOOFER
CH1-MONO
SUBWOOFER
CH2
CH1
Speaker Impedance
4~8 ohms

This power amplifier has protection features to prevent damage from misuse or faulty conditions. If the
unit senses excessive heat, short circuited speakers or overload, protection LED will light up and system
will be turned off. Prior to checking the wiring for any fault, you should turn all level controls down and
turn off power. If the amplifier shuts down due to excessive heat, protection LED will not light up. In this
case, simply allow the amplifier to cool down. Before removing your amplifier, refer to the list below and
follow the troubleshooting instructions. Always test the speakers and their wires first.
PPROTECTION LED LIGHTS UP WHEN AMPLIFIER IS POWERED UP
FUSE BLOWING
OVERHEATING
Check the value of minimum speaker impedance.
Check speakers for short-circuits.
Check if there is good airflow around the amplifier.
Check if a good ground connection is present and check speakers for short-circuits.
Disconnect all RCA inputs from the amplifier. If hissing / engine noise disappears, replace the
RCA connectors and re-check. Then check the component driving the amplifier.
SOUND TOO LOW-DISTORTED SOUND
Check if the input level control has been set to match the output level of the unit.
Check the volume of head unit.
Check speakers for short-circuits.
Check if crossover frequencies have been properly set.
HIGH HISS-ENGINE NOISE IN SPEAKERS
.
Check the value of minimum speaker impedance.
Check for short-circuits on power cable and vehicle chassis.
AMPLIFIER DOES NOT POWER UP
Check if at least +12V DC is available on the battery power terminal.
Check if at least +13.8V DC is available on the remote terminal.
Check if a good ground connection is present. Check all fuses.
Check if protection LED is not lit.
Check if speaker wires are short-circuited.
Remove speaker wires and reset the amplifier.
If protection LED still lights up, then the amplifier is faulty.
-6-
TROUBLE SHOOTING

SPECIFICATIONS
Rated power output
-RMS power, 4 ohm stereo
-RMS power, 2 ohm stereo
-RMS power, 1 ohm stereo
-RMS power, 4 ohm bridged
-RMS power, 2 ohm bridged
Signal to Noise Ratio
Low Pass Crossover
High Pass Crossover
Subsonic Seletable @ on
Bass Boost @ 45Hz
Frequency Response
THD@RMS Watts
Channel Separation
Fuse Rating
Input Sensitivity
Dimensions
280W x 2CH
500W x 2CH
750W x 2CH
950W x 1CH
1500W x 1CH
>98dB
30Hz ~ 250Hz
50Hz ~ 500Hz
30Hz
0~18dB
10Hz ~ 40KHz (+/-1dB)
0.05%
75dB
150A (external type fuse)
200mV~5V (+/- 5%)
256(W) x 61(H) x 434(L)mm
[SP-1500.2 dbPRO]
-7-
Rated power output
-RMS power, 4 ohm stereo
-RMS power, 2 ohm stereo
-RMS power, 1 ohm stereo
-RMS power, 4 ohm bridged
-RMS power, 2 ohm bridged
Signal to Noise Ratio
Low Pass Crossover
High Pass Crossover
Subsonic Seletable @ on
Bass Boost @ 45Hz
Frequency Response
THD@RMS Watts
Channel Separation
Fuse Rating
Input Sensitivity
Dimensions
400W x 2CH
700W x 2CH
1200W x 2CH
1500W x 1CH
2400W x 1CH
>98dB
30Hz ~ 250Hz
50Hz ~ 500Hz
30Hz
0~18dB
10Hz ~ 40KHz (+/-1dB)
0.05%
75dB
250A (external type fuse)
200mV~5V (+/- 5%)
256(W) x 61(H) x 600(L)mm
[SP-2000.2 dbPRO]
[SP-2300.2 dbPRO]
Rated power output
-RMS power, 4 ohm stereo
-RMS power, 2 ohm stereo
-RMS power, 1 ohm stereo
-RMS power, 4 ohm bridged
-RMS power, 2 ohm bridged
Signal to Noise Ratio
Low Pass Crossover
High Pass Crossover
Subsonic Seletable @ on
Bass Boost @ 45Hz
Frequency Response
THD@RMS Watts
Channel Separation
Fuse Rating
Input Sensitivity
Dimensions
600W x 2CH
900W x 2CH
1500W x 2CH
1800W x 1CH
3000W x 1CH
>98dB
30Hz ~ 250Hz
50Hz ~ 500Hz
30Hz
0~18dB
10Hz ~ 40KHz (+/-1dB)
0.05%
75dB
250A (external type fuse)
200mV~5V (+/- 5%)
256(W) x 61(H) x 660(L)mm

Designed and Engineered in USA.
Made in Korea
