Southland S-HLT-3017-SBEZ-E User manual

Look inside for:
Page
Safety Definitions 1
Important Safety Information 2-3
Product Specifications 4
Parts & Features 4
Assembly 4-5
Operation 6-9
Routine Maintenance 10
Storage 10
Troubleshooting 11
Technical Service 11
Warranty 12-17
01/13/09 Printed in China A101109
Operator’s Manual
STRAIGHT SHAFT TRIMMER
30cc, 2 Cycle
IMPORTANT:
Thank you for purchasing this Southland™ Trimmer.
This manual provides complete instructions for safely operating, and maintaining your Trimmer. Read and save these
instructions. Refer to this manual each time before using your Trimmer.
Record the following for future reference:
Mfg. Date Code : _________________
Date of Purchase: Attach a copy of your sales receipt.
Consumer Toll Free Number: 1-800-737-2112
KEEP THIS MANUAL FOR FUTURE REFERENCE
MODEL Nos. S-HLT-3017-SBEZ-E
S-HLT-3017-SBEZ
For Occasional Use Only
If you have a question or problem...
CALL TOLL FREE: 1-800-737-2112
This product contains one or more chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
WARNING

Indicates Warning. Keep all by-standers at least 50 ft.
(15 m) away.
Read these instructions carefully. This equipment can throw small objects
at high speed causing personal injury.
Inspect area where used and remove
all foreign objects.
Always wear eye protection that meets or
exceeds the requirements of ANSI Z87.1.
Wear hearing protection.
Wear breathing protection.
Keep all parts of your body away from
the rotating trimmer lines.
Wear safety footwear. Explosive material.
Wear safety gloves. Extremely hot surface. Do not touch
a hot muffler, gear box or cylinder,
you may get burned. These parts get
extremely hot from operation and
remain hot for a short time after the unit
is turned off.
Do not use rigid blades.
Safety Definitions
• Save all instructions
Safety Warning Symbols:
Control and Operating Symbols:
Choke Control:
Run/Warm Start
Cold Start
Fuel Mixture:
40:1
(Unleaded Gas : 2 Cycle Oil)
Fuel Primer:
Press 6 times.
Ignition Switch:
ON
OFF
Fuel Mixture
40:1
Unleaded Gas: 2 Cycle Oil
Caution: Do Not Use Gas
Mix with More Than 10%
Methanol or Ethanol
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
DANGER
CAUTION
WARNING
The information listed below should be read and understood by the operator. We utilize the symbols below to allow the
reader to recognize important information about their safety.
Questions? Call Toll Free at 1-800-737-2112 1 Copyright © 2009 MAT Engine Technologies, LLC

Questions? Call Toll Free at 1-800-737-2112 2 Copyright © 2009 MAT Engine Technologies, LLC
Before Operating Trimmer
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE OPERATING TRIMMER.
Read and follow all warnings and safety instructions. Failure to do so can result in serious injury to you or bystanders.
WARNING
1. Avoid Dangerous Environments
a. Do not operate Trimmer while under the influence of alcohol, medications, or drugs.
b. Do not operate Trimmer when you are tired.
c. Do not use this Trimmer if you are mentally or physically unable to operate safely.
2. Inspect Trimmer for damaged parts, and make sure all fasteners and guards are in place and secure. Replace any
damaged parts.
3. Use only 0.080 inch (2 mm) diameter flexible, nonmetallic line with this Trimmer.
This Trimmer is not designed for use with a rigid blade. Never use this Trimmer with a rigid blade or other accessories not
specifically approved for use in this manual. Never use alternative cutting members such as wire or wire-rope, which can
break off and become a dangerous projectile.
4. Dress properly when operating Trimmer.
a. Always wear heavy long pants, boots, gloves, and a long-sleeve shirt.
b. Do not wear loose clothing or jewelry that can get caught in the moving parts of the Trimmer.
c. Always wear gloves and substantial foot wear when working outside.
d. Always wear protective hair covering to contain long hair.
5. Always wear a face or dust mask if operation is dusty.
6. Always wear eye protection that meets or exceeds the requirements of ANSI Z87.1.
7. Always wear hearing protection which meets or exceeds ANSI standards.
8. Thoroughly inspect the area where the Trimmer is to be used and remove all foreign objects.
Your equipment can throw small objects at high speed causing personal injury or property damage.
WARNING
DANGER
Important Safety Information
• Save all instructions
While Operating Trimmer
1. Stay alert. Use common sense. Watch what you are doing.
2. Do not operate Trimmer if it is damaged or not securely and fully assembled.
3. Only well instructed adults should operate Trimmer. Never allow children to operate Trimmer.
4. Keep children away. Keep all bystanders at least 50 ft (15 m) away.
5. This Trimmer is only intended for trimming, scalping, and mowing. Do not use Trimmer for any job except that for which
it is intended. Do not use for edging, pruning or hedge trimming.
6. The Trimmer line may be spinning during carburetor adjustments. Make carburetor adjustments with lower end
supported to prevent Trimmer line from contacting any object.
7. Maintain your balance and proper footing at all times. Do not overreach.
8. Keep rotating trimmer head below waist level. Keep all parts of your body away from cutting area, the rotating trimmer
lines and hot surfaces.
9. Hold the unit firmly with both hands.
10. Always keep engine on the right hand side of your body.

Important Safety Information (Continued)
• Save all instructions
Questions? Call Toll Free at 1-800-737-2112 3 Copyright © 2009 MAT Engine Technologies, LLC
While Operating Trimmer
11. Always use the Trimmer in a sweeping motion from your right to your left. Cutting on left side and front of the trimmer
guard will throw debris away from you.
12. Do not force Trimmer. It will do the job better and with less likelihood of a risk of injury at the rate for which it was
designed.
13. Never start or run the unit inside a closed room or building; breathing exhaust fumes can kill.
14. After turning the Trimmer off, make sure the Trimmer line has stopped before the unit is set down.
Prolonged exposure to vibrations through use of gasoline powered hand tools could cause blood vessel or nerve damage
in fingers, hands, and joints of people prone to circulation disorders or abnormal swellings. Extensive use in cold weather
has been linked to blood vessel damage in otherwise healthy people. If symptoms occur such as numbness, pain, loss of
strength, change in skin color or texture, or loss of feeling in the fingers, hands, or joints, discontinue the use of this tool
and seek medical attention.
CAUTION
DANGER
Fuel Safety
1. Mix and pour fuel outdoors WHERE THERE ARE NO SPARKS OR FLAMES.
2. Use a container approved for gasoline.
3. Do not smoke or allow smoking near fuel or the Trimmer.
4. Avoid spilling fuel or oil. Wipe up all fuel spills.
5. Move at least 10 feet (3 meters) away from fueling site before starting engine.
6. Stop engine and allow to cool before removing fuel cap. Remove fuel cap slowly.
Maintenance & Storage of Trimmer
1. Disconnect the spark plug before performing maintenance.
2. Maintain Trimmer with care. Inspect Trimmer periodically. If Trimmer is not working properly or damaged, have it repaired
by a qualified service center.
3. Check for misalignment of moving parts, binding of moving parts, broken parts, mounting, and any other condition that
may affect its operation.
4. Keep guards in place and in working order.
5. A guard or other part that is damaged should be properly repaired or replaced by a qualified service center.
6. Use only genuine Southland™ replacement parts and accessories. Use of any non-Southland™ parts or accessories
could lead to injury, damage to the unit, and will void your warranty.
7. Do not remove or modify any parts. Removing or modifying parts could lead to injury, damage the Trimmer and will
void the warranty.
8. Keep handles dry, clean, and free from oil and grease.
9. Allow engine to cool and empty the fuel tank before storing or transporting in vehicle. Use up remaining fuel in the
carburetor by starting the engine and letting it run until it stops.
10. When not in use, store Trimmer indoors in a dry location. Store Trimmer above the reach of children or in a locked
area out of the reach of children.
11. Store unit and fuel in area where fuel vapors cannot reach sparks or open flames from water heaters, electric motors
or switches, furnaces, etc.
WARNING

Assembly
Parts Included With The Packaged Trimmer
Engine ..............................30 cc, 2 cycle
Speed ........................... 7,000-8,500 RPM
Cutting Diameter .................... 17 in. (432 mm)
Line Diameter ...................... 0.080 in. (2 mm)
Spool Type . . . . . . . . . . . . . . . . . . . Bump-Feed, Twin-Line
Fuel Tank Capacity.................... 20 oz (600 ml)
Fuel Type ....... Unleaded Gasoline – 87 Octane or higher
2-Cycle Oil Type ........ 2-Cycle Oil that meets or exceeds
. . . . . . . . . . . . . . . . . . . . . . . . . . . JASO – FC Specifications
Fuel Mixture ................ 40:1 (Gasoline: 2-Cycle Oil)
Spark Plug ......................... NGK - BPMR7A
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CHAMPION - CJ7Y
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . or equivalent
Net Weight .........................12.8 lbs (5.8 kg)
Product Specifications
• Save all instructions
Parts & Features
• Front Handle with Bolt and Nut
• Trimmer Guard with 3 screws
• Spanner Wrench
• Spark Plug Wrench
• Star Drive Key
• 40:1 2-Cycle Engine Oil (3.2 fl. oz.)
• Operator’s Manual
Do not operate Trimmer if it is damaged or not securely and fully assembled.
If you need assistance or find any parts
missing, CALL TOLL FREE: 1-800–737-2112
Questions? Call Toll Free at 1-800-737-2112 4 Copyright © 2009 MAT Engine Technologies, LLC
2
3
4
5
6
7
15
8
11
14
10 12
13
1
16
1. Trimmer Head Assembly 7. On/Off Ignition Switch 13. Fuel Tank
2. Bump Knob 8. Recoil Starter Handle 14. Air Filter Cover
3. Trimmer Guard 9. Choke 15. Safety Lever
4. Trimmer Line Knife 10. Fuel Primer Bulb 16. Spool Housing
5. Front Handle 11. Spark Plug 17. Shaft
6. Throttle Lever 12. Muffler 18. Gear Head
Tools Needed For Assembly
• 10 mm wrench or adjustable wrench.
9
WARNING
17
18

1. Insert the Star Drive Key through the slot in the Flanged
Spacer and Gear Head, and use the Spark Plug Wrench
provided to remove the Blade Nut by turning clockwise.
(see Fig. 1) Remove the Blade Nut, Cupped Washer, And
Flanged Spacer.
2. Remove the Flanged Spacer, and then use the Star Drive
Key provided to remove the 3 screws from Gear Head at the
end of Shaft (see Fig. 2).
3. Install the 3 screws through the Trimmer Guard into the
Gear Head (see Fig. 3). Tighten the screws securely.
4. Put on the Flanged Spacer, and align the slot in the
Flanged Spacer with the slot in the Gear Head (see Fig. 4).
5. Insert the Star Drive Key through the slot in the Flanged
Spacer and Gear Head (see Fig. 5).
6. Hand tighten the Trimmer Head Assembly onto the
shaft of the Gear Head by turning counter-clockwise (see
Fig. 6).
7. Tighten the Trimmer Head Assembly securely by rotating
the provided Spanner Wrench counter-clockwise (see Fig. 7).
8. Remove the protective cover from the trimmer line knife
(see Fig. 8).
The Trimmer Line Knife is sharp and can cut you (see Fig. 8).
CAUTION
Assembly (Continued)
• Save all instructions
To Assemble Trimmer Guard:
A
To Adjust Front Handle:
B
The Front Handle on your Trimmer is adjustable for
your comfort, and requires adjustment from its shipping
orientation before your first use of the Trimmer. To adjust
the Front Handle:
1. Loosen wing nut on the Front Handle.
2. Adjust Front Handle to desired position and re-tighten
wingnut until the handle is secure (see Fig. 9).
Questions? Call Toll Free at 1-800-737-2112 5 Copyright © 2009 MAT Engine Technologies, LLC
Fig. 2
ALIGN HOLES
Fig. 3
Fig. 5
Fig. 4
TIGHTENING
Fig. 9
Fig. 6
TIGHTENING
Fig. 7 Fig. 8
ALIGN SLOTS
TIGHTENING
FLANGED SPACER
SLOTS
Fig. 1
LOOSENING
FLANGED
SPACER
CUPPED
WASHER

The 2-cycle engine on your Trimmer requires that fuel and
2-cycle engine oil be pre-mixed before adding to the
trimmer’s fuel tank. To mix the fuel/ 2-cycle oil:
1. Use fresh unleaded gasoline with an octane rating of
87 or higher. Do not use gasoline containing ethanol or
methanol.
Use of gasoline containing ethanol or methanol can damage
Trimmer.
2. Always use 2-cycle oil that meets or exceeds JASO – FC
specifications and is intended for mixing at a fuel/oil ratio of 40:1.
3. Do not use automotive or 2-cycle marine outboard oil.
These will damage your trimmer’s engine and void the warranty.
4. Always mix the gasoline and 2-cycle oil in a container
approved for gasoline. Never mix fuel directly in the
trimmer’s fuel tank.
5. Follow instructions on 2-cycle oil container for mixing fuel.
Mix gasoline and 2-cycle oil at a ratio of 40:1. A mixture
with a 40:1 ratio is obtained by mixing 1 gallon (4 liters)
of gasoline with 3.2 ounces of oil (95 ml). After adding oil to
gasoline, shake container momentarily to ensure proper mixing.
6. Mix only enough fuel for your immediate needs. Do not
store pre-mixed fuel.
7. Stop engine and allow to cool before refueling.
8. To fill the trimmer’s fuel tank with the gasoline/ oil mixture,
place the Trimmer upright on the ground or on a sturdy
bench and wipe and any debris from around the fuel cap.
9. Remove fuel cap slowly and use a funnel to pour the
mixture into the tank, and replace the fuel cap.
10. Avoid spilling fuel or oil. Wipe up all fuel spills.
11. Move at least 10 feet (3 meters) away from fueling site
before starting engine.
CAUTION
Operation
• Save all instructions
Before Starting Engine:
A
Mixing Fuel / 2-Cycle Oil
Do not smoke or allow smoking near fuel or the Trimmer. Mix and pour fuel outdoors WHERE THERE ARE NO SPARKS
OR FLAMES.
WARNING
Starting Engine:
B
Keep all parts of your body away from cutting area, the rotating trimmer lines and hot surfaces.
WARNING
Questions? Call Toll Free at 1-800-737-2112 6 Copyright © 2009 MAT Engine Technologies, LLC
Cold Starting The Engine
DO NOT squeeze the throttle lever until engine starts and runs.
1. Place the Trimmer on a flat surface.
2. Move the Ignition Switch to the “ON” position (see Fig. 10).
3. Move the Choke Lever downwards to the “COLD START”
position (see Fig. 11).
4. Press the Primer Bulb slowly 6 times (see Fig. 12).
5. Pull the Recoil Starter Handle sharply until the engine
starts and runs (see Fig. 13).
6. After engine starts and runs for 10-15 seconds, squeeze
the throttle lever to engage to the RUN position (choke lever
released to RUN/WARM START position).
Note: when the weather gets cold, please allow the
engine to warm up at idle for longer period of time,
before engaging to RUN/WARM START position.
Warm Starting The Engine
1. Place the Trimmer on a flat surface.
2. Move the Ignition Switch to the “ON” position (see Fig. 10).
3. Squeeze and hold the throttle lever, pull the Recoil Starter
Handle sharply until the engine starts and runs.
ON
Fig. 10 Fig. 13
Fig. 11
COLD START
RUN/WARM START
Fig. 12
PRIMER BULB

Starting A Flooded Engine
1. Place the Trimmer on a flat surface.
2. Move the Ignition Switch to the “ON” position.
3. Squeeze and hold the Throttle Lever fully depressed and
pull the starter handle repeatedly until engine starts and
runs. This could require pulling the starter handle many
times, depending on how badly the unit is flooded.
4. If the engine still does not start, allow the unit to sit for
about 30 minutes, and repeat step 1-3.
Operation (Continued)
• Save all instructions
Starting Engine:
B
If the unit still doesn’t start, refer to the
TROUBLESHOOTING section of this manual or:
Stopping The Trimmer:
C
The Trimmer head and line will continue to rotate for a few seconds after the engine has stopped.
CAUTION
During the first ten (10) hours of use, use the slowest engine speed which allows for effective cutting and avoid operation
at high engine speeds for extended periods of time.
This will maximize the life and performance of your Trimmer’s engine. Maximum power will be achieved after the first ten
(10) hours of engine operation.
The Trimmer is most effective when the Trimmer line is
advanced to full cutting width. To advance the Trimmer line:
1. Hold bottom of Trimmer Head parallel to grassy surface
(see Figure 14).
2. With the engine at full throttle, firmly tap or bump the
Trimmer Head on the ground.
3. Trimmer line will be advanced with each tap or bump.
4. Continue to advance Trimmer line until you reach full
cutting width (i.e. when the Trimmer line is cut by the
Trimmer Line Knife).
Engine Break-in Period:
D
Advancing Trimmer Line:
E
Questions? Call Toll Free at 1-800-737-2112 7 Copyright © 2009 MAT Engine Technologies, LLC
If you need assistance or have any questions,
CALL TOLL FREE: 1-800–737-2112
Fig. 14
1. Release the Throttle Lever and allow the engine to idle for a few moments.
2. Move the Ignition Switch to the “OFF” position.

To avoid damaging trees, shrubs and fences:
1. Maintain Trimmer line to the full cutting width by advancing
trimmer line as necessary.
2. Move the tips of the Trimmer line slowly into the grass or
vegetation to be trimmed.
3. Use the slowest engine speed that will permit effective
cutting. This will provide the greatest control of the trimming
line, reduce engine noise and vibration, and extend Trimmer
line life.
Operation (Continued)
• Save all instructions
Techniques / Applications:
F
Your Trimmer is most effective when using the tips of the Trimmer line for trimming grass and other vegetation. Do not force
the Trimmer line into grass or vegetation faster than Trimmer’s cutting speed permits.
Forcing the Trimmer will cause your Trimmer to be less effective, and will cause excessive wear on the Trimmer line.
Thoroughly inspect the area where the Trimmer is to be used and remove all foreign objects. Your equipment can throw
small objects at high speed causing personal injury or property damage.
WARNING
Use a sweeping motion from right to left (see Fig. 15a) to
move the Trimmer line into the grass or vegetation to be cut.
By using the trimming line on the left side and front of the
Trimmer Guard, debris will be thrown away from you
(see Fig. 15b).
Trimming
Holding the Trimmer Head approximately 3 inches (76
mm) above the ground – with the trimmer line angled down
towards the grass or vegetation to be trimmed, move the
Trimmer Head in a sweeping motion from right to left into
the grass or vegetation (see Fig. 16).
Scalping
Scalping is a technique similar to Trimming, but clears
all vegetation to the ground. Holding the Trimmer Head
approximately 3 inches (76 mm) above the ground –
with the Trimmer line angled down towards the grass or
vegetation to be trimmed. Allow the Trimmer line to strike
the ground where scalping is desired (see Fig. 17).
Mowing
The Trimmer is effective in mowing areas your lawn mower cannot easily reach. Holding the Trimmer Head parallel to the
ground, move the Trimmer Head in sweeping motions from right to left. Avoid the Trimmer Head contacting the ground,
this may scalp the grass and damage the unit.
Questions? Call Toll Free at 1-800-737-2112 8 Copyright © 2009 MAT Engine Technologies, LLC
3” (76 mm)
Fig. 16
3” (76 mm)
Fig. 17
Fig. 15a
SWEEP RIGHT
TO LEFT
SAFE CUTTING
ZONE
Fig. 15b

Operation (Continued)
• Save all instructions
Replacing Trimmer Line:
G
Use only 0.080 inch (2 mm) diameter flexible, nonmetallic line with this Trimmer. Other line sizes will not function properly
and can cause serious injury. Never use alternative cutting members such as wire or wire-rope, which can break off and
become a dangerous projectile.
WARNING
1. Stop the engine.
Disconnect the Spark Plug before performing maintenance
except for carburetor adjustments.
2. Position the Trimmer on the ground so that the Trimmer
Head Assembly is facing up.
3. Use the spanner wrench provided to loosen and remove
the Bump Knob (see Fig. 18).
4. Remove spool and spool spring from the Trimmer Head
Assembly, and clear any remaining Trimmer line from the
spool.
5. When replacing Trimmer line only use 0.080 in. (2 mm)
diameter line.
6. Cut a length of new Trimmer line 15 ft. (4.6 m) long.
7. Bend the line in the middle to form a loop of two equal
lengths (see Fig. 19).
8. Hook the bend of the loop onto one of the slots in the
center of the spool (see Fig. 20).
9. With your finger between the Trimmer lines of the loop,
wrap the lines – keeping the lines taut with firm, constant
tension - around the spool in a clockwise direction.
Make sure to keep each of the Trimmer lines on the proper
side of the center divider on the spool (see Fig. 21).
10. Confirm spool spring is secured in proper position on
spool (see Fig. 22).
11. While securing the Trimmer line around the spool, insert
spool into the Spool Housing and insert the end of each
of the Trimmer lines into opposing eyelets in the Spool
Housing. Pull the Trimmer line through eyelets removing
any slack in the line. The Trimmer line should extend
through each eyelet approximately 4 inches (102 mm).
12. Hand tighten the Bump Knob onto the Spool by turning
counter-clockwise (see Fig. 23).
13. Insert the Star Drive Key through the slot in the
Flanged Spacer and Gear Head, and put the Trimmer
Head Assembly onto the drive shaft of the Gear Head, and
secure it by turning the Spanner Wrench counter-clockwise
(see Fig. 24).
14. After installing new Trimmer line, start Trimmer engine
and advance Trimmer line with Bump Knob until Trimmer
line is trimmed at its full cutting width by the Trimmer line
knife (see E. Advancing Trimmer Line).
WARNING
Questions? Call Toll Free at 1-800-737-2112 9 Copyright © 2009 MAT Engine Technologies, LLC
Fig. 18
Fig. 20
Fig. 22
SPOOL SPRING
Fig. 21
WIND LINE IN THIS DIRECTION
Fig. 24
Fig. 23
TIGHTENING
TIGHTENING
Fig. 19
LOOSENING

Routine Maintenance
• Save all instructions
Air Filter:
A
Accumulated debris and dust in the air filter will reduce engine performance, increase fuel consumption and increases the
risk of engine damage. Clean the air filter every 5 hours of operation.
1. Before removing Air Filter Cover, brush away any loose
dirt or debris on and around the filter cover.
2. To remove Air Filter Cover, press on the top tab and pull
cover down (see Fig. 25).
3. Remove and clean foam filter.
• Light surface dust can readily be removed by tapping the
filter.
• Heavy deposits should be washed out in soap and
water. Squeeze out any remaining water and allow the
filter to completely dry.
Never clean filter in gasoline or other flammable solvents.
4. Add a drop of thin oil to the filter and replace it.
WARNING
Spark Plug:
B
Inspect the spark plug after every 10-15 hours of use; adjust spark plug gap and replace spark plug as necessary. Replace
spark plug every year to maintain engine performance and easy starting.
To inspect or replace the Spark Plug:
1. Remove the insulated spark plug boot.
2. Use the spark plug wrench to remove the Spark Plug, by
turning counter-clockwise.
3. Clean and adjust the spark plug gap to 0.024 – 0.028 in.
(0.6 - 0.7mm).
4. Replace any worn plug with a recommended replacement
(see PRODUCT SPECIFICATIONS. Clean and adjust the
spark plug gap to 0.024 – 0.028 in. (0.6 - 0.7mm).
5. Install the Spark Plug finger tight in the cylinder head,
then tighten firmly with the spark plug wrench.
6. Replace the insulated spark plug boot.
Questions? Call Toll Free at 1-800-737-2112 10 Copyright © 2009 MAT Engine Technologies, LLC
Storage
1. Allow engine to cool and empty the fuel tank before storing or
transporting in vehicle. Use up remaining fuel in the carburetor
by starting the engine and letting it run until it stops.
2. When not in use, store Trimmer indoors in a dry location.
Store Trimmer above the reach of children or in a locked
area out of the reach of children.
3. Store unit and fuel in area where fuel vapors cannot
reach sparks or open flames from water heaters, electric
motors or switches, furnaces, etc.
4. When preparing the Trimmer for storage or when Trimmer
will not be used for 30 days or more:
a. Inspect and clean the Trimmer thoroughly.
b. Lightly oil all external metal surfaces.
c. Remove the spark plug, place a few drops of
2-cycle engine oil into the cylinder. Pull the recoil
starter several times to distribute the oil. Replace
the spark plug.
d. Inspect and clean air filter as required.
NOTE: To prevent fuel gum deposits in the Trimmers carburetor and fuel system, it is acceptable to use fuel stabilizer.
Follow the stabilizer manufacturer’s instructions. Run the engine at least 5 minutes after adding stabilizer.
Fig. 25
Disconnect the spark plug before performing maintenance.
WARNING
PULL DOWN

PROBLEM POSSIBLE CAUSE(S) SOLLUTION(S)
Engine will not start. 1. Ignition Switch in the “OFF” position.
2. Engine flooded.
3. Fuel Tank empty.
4. Spark Plug not firing.
5. Fuel not reaching carburetor.
6. Carburetor requires adjustment.
1. Move ignition switch to the ON position.
2. See Starting a Flooded Engine in
OPERATION section.
3. Fill tank with correct fuel mixture.
4. Replace Spark Plug.
5. Check for kinked or split fuel line; repair
or replace.
6. Contact a qualified service center.
Engine will not accelerate, lacks
power or stalls.
1. Grass wrapped around Trimmer Head.
2. Air filter dirty.
3. Spark plug fouled.
4. Carburetor requires adjustment.
5. Carbon build-up on muffler outlet
screen.
6. Compression low.
1. Clear debris and grass from Trimmer Head.
2. Clean air filter.
3. Clean or replace plug
4. Contact a qualified service center.
5. Contact a qualified service center.
6. Contact a qualified service center.
Engine smokes excessively. 1. Fuel mixture incorrect.
2. Air filter dirty.
3. Carburetor requires adjustment.
1. Empty Fuel Tank and refill with correct fuel
mixture.
2. Clean or replace air filter.
3. Contact a qualified service center.
Engine runs hot. 1. Fuel mixture incorrect.
2. Spark Plug incorrect.
3. Carburetor requires adjustment.
4. Carbon build-up on muffler outlet
screen.
1. See Mixing Fuel / 2-Cycle Oil in
OPERATION section.
2. Replace with correct Spark Plug.
3. Contact a qualified service center.
4. Contact a qualified service center.
Engine will not idle properly. 1. Carburetor requires adjustment.
2. Crankshaft seals worn.
3. Compression low.
1. Contact a qualified service center.
2. Contact a qualified service center.
3. Contact a qualified service center.
Troubleshooting
• Save all instructions
You may have further questions about assembling, operating, or maintaining this Trimmer. If so, you can contact our
Technical Service Department at 1-800-737-2112 (English only).
You may also write to:
METL Corporate Office - CORRESPONDENCE ONLY
ATTN: Technical Service – METL
6700 Wildlife Way
Long Grove, IL 60047
Technical Service
Questions? Call Toll Free at 1-800-737-2112 11 Copyright © 2009 MAT Engine Technologies, LLC
When contacting the Technical Service Department, have
ready:
• Your Name
• Your Address
• Your Phone Number
• Model Number of Product
• Date of Purchase (include copy of receipt for written requests)
If you need assistance or have any questions,
CALL TOLL FREE: 1-800–737-2112

Warranty
• Save all instructions
Always specify model number when contacting the factory.
We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard
written warranty. We make no other warranty, expressed or implied. MAT Engine Technologies, LLC warrants this Trimmer
and any parts thereof, to be free from defects in material and workmanship for two years (90 days for reconditioned unit) from
the date of first purchase from an authorized dealer, provided that the product has been properly maintained and operated in
accordance with all applicable instructions. This warranty is extended only to the original retail purchaser. The bill of sales or
proof of purchase must be presented at the time a claim is made under this warranty. This warranty does not cover commercial,
industrial, or rental usage, nor does it apply to parts that are not in original condition because of normal wear and tear, or parts
that fail or become damaged as a result of misuse, accident, lack of proper maintenance, tampering, or alteration. Travel,
handling, transportation, and incidental costs associated with warranty repairs are not reimbursable under this warranty and
are the responsibility of the owner. To the full extent allowed by the law of the jurisdiction that governs the sale of the product,
this express warranty excludes any and all other expressed warranties and limits the duration of any and all implied warranties,
including warranties of merchantability and fitness for a particular purpose to two years from the date of first purchase, and MAT
Engine Technologies, LLC’s liability is hereby limited to the purchase price of the product and MAT Engine Technologies,
LLC shall not be liable for any other damages whatsoever including indirect, incidental, or consequential damages. Some states
do not allow limitation of how long an implied warranty lasts or an exclusion or limitation of incidental or consequential damages,
so the above limitation of damages may not apply to you. This warranty provides the original purchaser with specific rights.
For information regarding those rights, please consult the applicable state laws.
METL Corporate Office - CORRESPONDENCE ONLY
ATTN: Technical Service – METL
6700 Wildlife Way
Long Grove, IL 60047
This MAT Engine Technologies, LLC ( METL )outdoor power equipment engine complies with the emissions regulations of:
Southland™ Model No. Regulatory Agency
S-HLT-3017-SBEZ-E United States Environmental Protection Agency (“U.S. EPA”)
S-HLT-3017-SBEZ State of California
To the extent there is any conflict between this Emissions Control Warranty and the METL Limited Warranty, this Emissions Control
Warranty shall apply except where the METL Limited Warranty may provide a longer warranty period.
Please read your warranty rights and obligations carefully. Some sections of the warranty may not apply to the specific
model you purchased. Unless specifically noted otherwise, the terms below shall apply to all Southland™ products
covered within this manual.
YOUR WARRANTY RIGHTS AND OBLIGATIONS
State of California (Applies only to Model No. S-HLT-3017-SBEZ):
The California Air Resources Board and MAT Engine Technologies, LLC (METL) are pleased to explain the emissions
control system warranty on your 2009 small off-road engine (SORE). In California, new SOREs must be designed, built
and equipped to meet the State’s stringent anti-smog standards. METL must warrant the emissions control system on
your SOREs for the periods of time listed below provided there has been no abuse, neglect or improper maintenance of
your SOREs.
Questions? Call Toll Free at 1-800-737-2112 12 Copyright © 2009 MAT Engine Technologies, LLC
Southland™ TRIMMER Limited Warranty
A
Federal and California Emissions Control Warranty Statement
B

Warranty (Continued)
• Save all instructions
Other U.S States / Territories:
In other areas of the Unites States, your outdoor power equipment engine must be designed, built and equipped so as
to conform at the time of sale to U.S. EPA emissions standards for small off-road spark ignition engines at or below 19
kilowatts.
All of the United States:
Your emission control system may include parts such as the carburetor or fuel-injection system, fuel lines, the ignition
system, and catalytic converter. Also included may be hoses, belts, clamps, connectors and other emission-related
assemblies.
Where a warrantable condition exists, METL will repair your small off-road engine at no cost to you including diagnosis,
parts and labor.
Manufacturer’s Warranty Coverage:
The emissions control system is warranted for two years. If any emissions-related part on your engine is defective, the part
will be repaired or replaced by METL.
Owner’s Warranty Responsibilities:
• As the SORE owner, you are responsible for the performance of the required maintenance listed in your owner’s manual.
METL recommends that you retain all receipts covering maintenance on your SORE, but METL can not deny warranty
solely for the lack of receipts or for your failure to ensure the performance of all scheduled maintenance.
• As the SORE owner, you should however be aware that METL may deny your warranty coverage if your SORE or a part
has failed due to abuse, neglect, improper maintenance or unapproved modifications.
• You are responsible for presenting your SORE to a distribution center or service center authorized by METL as soon as
the problem exists. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty
coverage, you should contact METL customer service:
Questions? Call Toll Free at 1-800-737-2112 13 Copyright © 2009 MAT Engine Technologies, LLC
If you need assistance or have any questions,
CALL TOLL FREE: 1-800–737-2112

Warranty (Continued)
• Save all instructions
Defects Warranty Coverage:
METL warrants to the original purchaser and each subsequent purchaser that the small off-road engine (SORE) (1) has
been designed, built and equipped so as to conform with all applicable regulations; and (2) is free from defects in materials
and workmanship that cause the failure of a warranted part to conform with those regulations as may be applicable to the
terms and conditions stated below.
(a) The warranty period begins on the date the engine is first purchased. The warranty period is two years.
(b) Subject to certain conditions and exclusions as stated below, the warranty on emissions related parts is as follows:
(1) Any warranted part that is not scheduled for replacement as required maintenance in your Operator’s Manual is
warranted for the warranty period stated above. If the part fails during the period of warranty coverage, the part will
be repaired or replaced by METL according to Subsection (4) below. Any such part repaired or replaced under
warranty will be warranted for the remainder of the period.
(2) Any warranted part that is scheduled only for regular inspection in your Operator’s Manual is warranted for the
warranty period stated above. Any such part repaired or replaced under warranty will be warranted for the remaining
warranty period.
(3) Any warranted part that is scheduled for replacement as required maintenance in your Operator’s Manual is
warranted for the period of time before the first scheduled replacement date for that part. If the part fails before the
first scheduled replacement, the part will be repaired or replaced by METL according to Subsection (4) below.
Any such part repaired or replaced under warranty will be warranted for the remainder of the period prior to the first
scheduled replacement point for the part.
(4) Repair or replacement of any warranted part under the warranty provisions herein must be performed at a
warranty station at no charge to the owner.
(5) Notwithstanding the provisions herein, warranty services or repair will be provided at all of our distribution centers
that are franchised to service the subject engines.
(6) The engine owner must not be charged for diagnostic labor that leads to the determination that a warranted part is
in fact defective, provided that such diagnostic work is performed at a warranty station.
(7) METL is liable for damages to other engine components proximately caused by a failure under warranty of any
warranted part.
(8) Throughout the engine warranty period stated above, METL will maintain a supply of warranted parts sufficient to
meet the expected demand for such parts.
(9) Any replacement part may be used in the performance of any warranty maintenance or repairs and must be
provided without charge to the owner. Such use will not reduce the warranty obligations of METL.
(10) Add-on or modified parts that are not exempted by the Air Resources Board may not be used. The use of
any non-exempted add-on or modified parts by the original or subsequent purchaser will be grounds for disallowing
a warranty claims. METL will not be liable to warrant failures of warranted parts caused by the use of a non-
exempted add-on or modified part.
(11) The manufacturer issuing the warranty shall provide any documents that describe that warranty procedures or
policies within five working days or requested by the Air Resources Board.
Questions? Call Toll Free at 1-800-737-2112 14 Copyright © 2009 MAT Engine Technologies, LLC

Warranty (Continued)
• Save all instructions
Emission Warranty Parts List:
The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such
warranty coverage if METL demonstrates that the engine has been abused, neglected, or improperly maintained, and that
such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part. That
notwithstanding, any adjustment of a component that has a factory installed, and properly operating, adjustment limiting
device is still eligible for warranty coverage. The following emissions warranty parts list is covered.
(1) Fuel Metering System:
(a) Gasoline carburetor assembly and its internal
components (if so equipped)
(b) Fuel filter (if so equipped)
(c) Carburetor gaskets
(d) Fuel pump (if so equipped)
(2) Air Induction System including:
(a) Intake pipe/manifold
(b) Air cleaner
(3) Ignition System including:
(a) Spark plug
(b) Ignition module/coil
(4) Catalytic Muffler Assembly (if so equipped) including:
(a) Muffler gasket
(b) Exhaust manifold
(5) Crankcase Breather Assembly including:
(a) Breather connection tube.
(6) Miscellaneous items Used in Above Systems including:
(a) Switches
(b) Hoses, belts, connectors, and assemblies.
Questions? Call Toll Free at 1-800-737-2112 15 Copyright © 2009 MAT Engine Technologies, LLC

Warranty (Continued)
• Save all instructions
YOUR WARRANTY RIGHTS AND OBLIGATIONS
Applies only to Model No. S-HLT-3017-SBEZ:
The California Air Resources Board and METL are pleased to explain the evaporative emission control system’s warranty
on your 2009 model year small off-road engine (SORE). In California, new SOREs must be designed, built and equipped
to meet the State’s stringent anti-smog standards. METL must warrant the evaporative emission control system on your
SOREs for the period of time listed below provided there has been no abuse, neglect or improper maintenance of your
SOREs.
Your evaporative emission control system may include parts such as: carburetors, fuel tanks, fuel lines, fuel caps, valves,
canisters, filters, vapor hoses, clamps, connectors, and other associated components.
Manufacturer’s Warranty Coverage:
This evaporative emission control system is warranted for two years. If any evaporative emission-related part on your
equipment is defective, the part will be repaired or replaced by METL.
Owner’s Warranty Responsibilities:
• As the SORE owner, you are responsible for performance of the required maintenance listed in your owner’s manual.
METL recommends that you retain all receipts covering maintenance on your SOREs, but METL can not deny warranty
solely for the lack of receipts.
• As the SORE owner, you should however be aware that METL may deny you warranty coverage if your SOREs or a part
have failed due to abuse, neglect, or improper maintenance or unapproved modifications.
• You are responsible for presenting your SOREs to distribution center or service center authorized by METL as soon as
the problem exists. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty
coverage, you should contact METL customer service:
Questions? Call Toll Free at 1-800-737-2112 16 Copyright © 2009 MAT Engine Technologies, LLC
California Evaporative Emission Control Warranty Statement
C
If you need assistance or have any questions,
CALL TOLL FREE: 1-800–737-2112

Warranty (Continued)
• Save all instructions
Defects Warranty Coverage:
(a) The warranty period begins on the date the engine is purchased.
(b) General Evaporative Emissions Warranty Coverage. The engine must be warranted to the ultimate purchaser and
any subsequent owner that the evaporative emission control system when installed was:
(1) Designed, built, and equipped so as to conform with all applicable regulations; and
(2) Free from defects in materials and workmanship that causes the failure of a warranted part for a period of two years.
(c) The warranty on evaporative emissions-related parts will be interpreted as follows:
(1) Any warranted part that is not scheduled for replacement as required maintenance in the written instructions must
be warranted for the warranty period defined in subsection (b) (2).
If any such part fails during the period of warrantycoverage, it must be repaired or replaced by METL issuing
the warranty. Any such part repaired or replaced under the warranty must be warranted for a time not less than the
remaining warranty period.
(2) Any warranted part that is scheduled only for regular inspection in the written instructions must be warranted
for the warranty period defined in subsection (b) (2). A statement in such written instructions to the effect of “repair
or replace as necessary” will not reduce the period of warranty coverage. Any such part repaired or replaced under
warranty must be warranted for a time not less than the remaining warranty period.
(3) Any warranted part that is scheduled for replacement as required maintenance in the written instructions must be
warranted for the period of time prior to the first scheduled replacement point for that part. If the part fails prior to the
first scheduled replacement, the part must be repaired or replaced by METL Any such part repaired or replaced under
warranty must be warranted for a time not less than the remainder of the period prior to the first scheduled
replacement point for the part.
(4) Repair or replacement of any warranted part under the warranty provisions of this article must be performed at no
charge to the owner at a warranty station.
(5) Notwithstanding the provisions of subsection (4) above, warranty services or repairs must be provided at
distribution centers that are franchised to service the subject engines or equipment.
(6) The owner must not be charged for diagnostic labor that leads to the determination that a warranted part is in fact
defective, provided that such diagnostic work is performed at a warranty station.
(7) Throughout the evaporative emission control system’s warranty period set out in subsection (b) (2), METL issuing
the warranty must maintain a supply of warranted parts sufficient to meet the expected demand for such parts.
(8) Manufacturer approved replacement parts must be used in the performance of any warranty maintenance or
repairs and must be provided without charge to the owner. Such use will not reduce the warranty obligations of the
manufacturer issuing the warranty.
(9) The use of any add-on or modified parts will be grounds for disallowing a warranty claim made in accordance with
this article. The manufacturer issuing the warranty will not be liable under this Article to warrant failures of warranted
parts caused by the use of an add-on or modified part.
(10) METL issuing the warranty shall provide any documents that describe the warranty procedures or policies within
five working days of request by the Executive Officer.
(1) Fuel Tank.
Evaporative Emission Warranty Parts List:
Questions? Call Toll Free at 1-800-737-2112 17 Copyright © 2009 MAT Engine Technologies, LLC
