MachineryHouse K8735 User manual

INSTRUCTION MANUAL
QLD Schools / TAFE - SG-416A
Manual Treadle Guillotine
1300 x 1.6mm
K8735
Page 1
Instruction Manual for SG-416A (K8735)
11/27/2015

S534A
1300 X 1.6
SHEETMETAL GUILLOTINE
INSTRUCTION & PARTS MANUAL
31-7-12
Page 2
Instruction Manual for SG-416A (K8735)
11/27/2015

Page 3
Instruction Manual for SG-416A (K8735)
11/27/2015

Page 4
Instruction Manual for SG-416A (K8735)
11/27/2015

Page 5
Instruction Manual for SG-416A (K8735)
11/27/2015

Page 6
Instruction Manual for SG-416A (K8735)
11/27/2015

Page 7
Instruction Manual for SG-416A (K8735)
11/27/2015

General Machinery Safety Instructions
1. Read the entire Manual before starting
machinery. Machinery may cause serious injury if
not correctly used.
2. Always use correct hearing protection when
operating machinery. Machinery noise may cause
permanent hearing damage.
3. Machinery must never be used when tired, or
under the influence of drugs or alcohol. When
running machinery you must be alert at all times.
4. Wear correct Clothing. At all times remove all loose
clothing, necklaces, rings, jewelry, etc. Long hair
must be contained in a hair net. Non-slip protective
footwear must be worn.
5. Always wear correct respirators around fumes
or dust when operating machinery. Machinery
fumes & dust can cause serious respiratory illness.
Dust extractors must be used where applicable.
6. Always wear correct safety glasses. When
machining you must use the correct eye protection
to prevent injuring your eyes.
7. Keep work clean and make sure you have good
lighting. Cluttered and dark shadows may cause
accidents.
8. Personnel must be properly trained or well
supervised when operating machinery. Make
sure you have clear and safe understanding of the
machine you are operating.
9. Keep children and visitors away. Make sure
children and visitors are at a safe distance for you
work area.
10. Keep your workshop childproof. Use padlocks,
Turn off master power switches and remove start
switch keys.
11. Never leave machine unattended. Turn power off
and wait till machine has come to a complete stop
before leaving the machine unattended.
12. Make a safe working environment. Do not use
machine in a damp, wet area, or where flammable
or noxious fumes may exist.
13. Disconnect main power before service
machine. Make sure power switch is in the off
position before re-connecting.
14. Use correct amperage extension cords.
Undersized extension cords overheat and lose
power. Replace extension cords if they become
damaged.
15. Keep machine well maintained. Keep blades
sharp and clean for best and safest performance.
Follow instructions when lubricating and changing
accessories.
16. Keep machine well guarded. Make sure guards
on machine are in place and are all working
correctly.
17. Do not overreach. Keep proper footing and
balance at all times.
18. Secure workpiece. Use clamps or a vice to
hold the workpiece where practical. Keeping the
workpiece secure will free up your hand to operate
the machine and will protect hand from injury.
19. Check machine over before operating. Check
machine for damaged parts, loose bolts, Keys and
wrenches left on machine and any other conditions
that may effect the machines operation. Repair and
replace damaged parts.
20. Use recommended accessories. Refer to
instruction manual or ask correct service officer
when using accessories. The use of improper
accessories may cause the risk of injury.
21. Do not force machinery. Work at the speed and
capacity at which the machine or accessory was
designed.
22. Use correct lifting practice. Always use the
correct lifting methods when using machinery.
Incorrect lifting methods can cause serious injury.
23. Lock mobile bases. Make sure any mobile bases
are locked before using machine.
24. Allergic reactions. Certain metal shavings and
cutting fluids may cause an ellergic reaction in
people and animals, especially when cutting as the
fumes can be inhaled. Make sure you know what
type of metal and cutting fluid you will be exposed
to and how to avoid contamination.
25. Call for help. If at any time you experience
difficulties, stop the machine and call you nearest
branch service department for help.
Machinery House
requires you to read this entire Manual before using this machine.
Page 8
Instruction Manual for SG-416A (K8735)
11/27/2015

Manual Guillotine Safety Instructions
1. Maintenance. Make sure all moving parts are
locked down before any inspection, adjustment or
maintenance is carried out. Place a block of timber
between the blades to save blades from shearing
hands or fingers.
2. Guillotine Condition. Guillotine must be maintained
for a proper working condition. Never operate
a Guillotine that has damaged or worn parts.
Scheduled routine maintenance should performed on
a scheduled basis.
3. Blade Condition. Never operate a Guillotine with a
damaged or badly worn blades. Replace if required.
4. Hand Hazard. Keep hands and fingers clear from
moving parts. Serious injury can occur if hand or
finger tips come between blades.
5. Personal Protection. Gloves are recommended
when handling the workpieces.
6. Authorized and trained personnel. The machine
must be operated by authorized and trained
personnel. The shear is designed to be operated be
a single user. Using the machine with more than one
operator is forbidden, except for certain maintenance
situations.
7. Work area hazards. Keep the area around the
Guillotine clean from oil, tools, objects & chips. Pay
attention to other persons in the area and know what
is going on around the area to ensure unintended
accidents.
8. Guards. Do not operate Guillotine without the
correct guards in place. Necessary guards protect
you from injuries by the shear blades.
9. Material. Material must NOT be hardened ceramic
or glass-originated, non flat metals (at origin) e.g.
rods, bars, tubes & pipes.
10. Blade gap adjustment. Do NOT operate the
machine without proper blade gap adjustment
according to sheet thickness.
11. Warning Labels. Take note of any warning labels
on the machine and do not remove them.
12. Backgauge Area. Do not access the backgauge
area, while the machine is working.
13. Squaring arm. Do not use side squaring arm and
front support arms for intermediate storage of
workpieces.
14. Operation. During the shearing process, the
workpiece may slide or move unexpectedly.
Therefore, the material must be handled carefully.
15. Level machine. Level the machine on a flat
concrete surface by using a spirit level.
16. Hearing protection and hazards. Always wear
hearing protection as noise generated from
machine and workpiece can cause permanent
hearing loss over time.
17. Call for help. If at any time you experience
difficulties, stop the machine and call you nearest
branch service department for help.
Machinery House
requires you to read this entire Manual before using this machine.
Page 9
Instruction Manual for SG-416A (K8735)
11/27/2015

Manager:
Wear hearing protection as required.
Revised Date:
www.machineryhouse.com.au
www.machineryhouse.co.nz
Aug-08
Plant Safety Program to be read in conjunction with manufactures instructions
Ensure guards are secured properly.
F
STRIKING
MEDIUM
Wear safety glasses.
LOW
Risk Control Strategies
(Recommended for Purchase / Buyer / User)
Wear gloves to prevent cuts from sharp material offcuts.
Secure & support work material on table.
Stand clear of falling offcuts.
Ensure front blade guard is fitted securely.
Hands should be kept clear of moving parts and blades.
LOW
SHEARING
B
OTHER HAZARDS, NOISE.
CRUSHING
PUNCTURING
O
Assessment
MEDIUM
PLANT SAFETY PROGRAM
No.
Hazard
Identification
Safety officer:
Ensure material hold downs are correctly adjusted.
Developed in Co-operation Between A.W.I.S.A and Australia Chamber of Manufactures
This program is based upon the Australian Worksafe Standard for Plant(NOHSC:1010-1994)
NEW MACHINERY HAZARD IDENTIFICATION, ASSESSMENT & CONTROL
Do not adjust or clean machine while operating.
Item
C
Authorised and signed by:
Hazard
Manual Guillotine
D
MEDIUM
CUTTING, STABBING,
