Sovereign D030I-18V User guide

612321
D030I-18V
June 21
18V CORDLESS HAMMER DRILL KIT

2
CONTENTS
CONTENTS 2
GENERAL SAFETY WARNINGS 3
WARNING SYMBOLS 14
IN THE BOX 16
OPERATION 20
MAINTENANCE AND STORAGE 25
TECHNICAL DATA 26
RECYCLING AND DISPOSAL 28
GETTING HELP 28
WARRANTY 29

3
GENERAL SAFETY WARNINGS
WARNING! Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool. Failure to
follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for
future reference. The term "power tool" in
the warnings refers to your mains-operated
(corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adaptor plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and

4
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment (PPE).
Always wear eye protection. Protective
equipment, such as a dust mask, non-skid safety
shoes, hard hat, or hearing protection used for

5
appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure the
switch is in the 'off' position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising power
tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
these devices can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action
can cause severe injury within a fraction of a
second.
4) Power tool use and care
a) Do not force the power tool. Use the correct

6
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and

7
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
h) Keep handles and gripping surfaces dry, clean
and free from oil and grease. Slippery handles
and gripping surfaces do not allow for safe
handling and control of the tool in unexpected
situations.
5)
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause
irritation or burns.
e) Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
Battery tool use and care

8
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 130°C may cause explosion.
g) Follow all charging instructions and do not
charge the battery pack or tool outside
the temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of fire.
6)
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
b) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorised service providers.
Drill safety warnings
1)
a) Hold the power tool by insulated gripping
surfaces, when performing an operation
where the cutting accessory may contact
hidden wiring or its own cord. Cutting accessory
contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the
operator an electric shock.
Service
Safety instructions for all operations

9
2)
a) Never operate at higher speed than the
maximum speed rating of the drill bit. At higher
speeds, the bit is likely to bend if allowed to rotate
freely without contacting the workpiece, resulting
in personal injury.
b) Always start drilling at low speed and with the
bit tip in contact with the workpiece. At higher
speeds, the bit is likely to bend if allowed to rotate
freely without contacting the workpiece, resulting
in personal injury.
c) Apply pressure only in direct line with the bit
and do not apply excessive pressure. Bits can
bend causing breakage or loss of control, resulting
in personal injury.
Safety notes for battery/charger
Safety Warnings for battery pack
a) Do not dismantle, open or shred cells or
battery pack.
b) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box or
drawer where they may short-circuit each
other or be short circuited by conductive
materials. When battery pack is not in use, keep
it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
Safety instructions when using long drill bits

10
c) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
d) Do not subject the battery pack to mechanical
shock.
e) In the event of battery leakage, do not allow
the liquid to come into contact with the skin
or eyes. If contact has been made, wash the
affected area with copious amounts of water and
seek medical advice.
f) Seek medical advice immediately if a cell or
battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean
dry cloth if they become dirty.
i) Battery pack needs to be charged before
use. Always refer to this instruction and use the
correct charging procedure.
j) Do not maintain battery pack on charge when
not in use.
k) After extended periods of storage, it may be
necessary to charge and discharge the battery
pack several times to obtain maximum
performance.
l) Battery pack gives its best performance when
it is operated at normal room temperature (20
°C ± 5 °C).
m) When disposing of battery packs, keep battery
packs of different electrochemical systems
separate from each other.
n) Recharge only with the charger specified. Do
not use any charger other than that specifically

11
provided for use with the equipment. A charger
that is suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
o) Do not use any battery pack which is not
designed for use with the equipment.
p) Keep the battery pack out of the reach of
children.
q) Retain the original product literature for
future reference.
r) Remove the batteryfrom the equipment when
not in use.
s) Dispose of properly.
t) Do not mix cells of different manufacture,
capacity, size or type within a device.
u) Do not remove battery pack from its original
packaging until required for use.
v) Observe the plus (+) and minus (–) marks on
the battery and ensure correct use.
General Safety Warnings for battery charger
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
-This appliance can be used by children aged from
8 years and above and persons with reduced

12
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
-Children shall notplay with the appliance. Cleaning
and user maintenance shall not be made by
children without supervision.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Additional safety instructions for your Battery
Charger
1. Before charging, read the instructions.
2. For charging a Li-ion battery pack only.
3. Do not charge a leaking battery.
4. Do not use chargers for works other than those for
which they are designed.
5. Before charging, ensure your charger is matching
the local AC supply.
6. The charging device must be protected from
moisture.
7. Do not use the charging device in the open.
8. Do not short out the contacts of the battery or
charger.
9. Respect the polarity “+/-“ when charging.

13
10. Do not open the unit and keep out of the reach of
children.
11. Do not charge the batteries of other
manufacturers or ill-suited models.
12. Ensure that the connection between the battery
charger and battery is correctly positioned and is
not obstructed by foreign bodies.
13. Keep battery chargers slots are free of foreign
objects and protect against dirt and humidity.
Store in a dry and frost-free place.
14. When charging batteries, ensure that the battery
charger is in a well-ventilated area and away from
inflammable materials. Batteries can get hot
during charging. Do not overcharge any batteries.
Ensure that batteries and chargers are not left
unsupervised during charging.
15. Do not recharge non-rechargeable batteries, as
they can overheat and break.
16. Longer life and better performance can be
obtained if the battery pack is charged when the
air temperature is between 18°C and 24°C. Do
not charge the battery pack in air temperatures
below 0°C, or above 40°C. This is important as it
can prevent serious damage to the battery pack.
17. Charge only battery pack/s of the same model
provided by SOVEREIGN, and of models
recommended by SOVEREIGN.
18. After charging, disconnect the battery charger
from the supply mains. Then remove the chassis
connection and then the battery connection.

14
WARNING SYMBOLS
Warning!
Read the instructions
Wear ear protection
Wear eye protection
Wear a dust mask
Class II tool
The product complies with the applicable European
directives, and an evaluation method of conformity
for these directives was done.
Recycle unwanted materials instead of disposing
of them as household waste. All tools, hoses
and packaging should be sorted, taken to the
local recycling centre and disposed of in an
environmentally safe way.
The product complies with the applicable UK
directives, and an evaluation method of conformity
for these directives was followed.

15
Batteries contain Li-ion. Do not dispose of waste
batteries in domestic waste. Contact your local
authority to find out how to dispose of batteries.
Do not subject the battery to strong sunlight over
long periods of time. Do not leave on a heater (max.
45°C).
Do not throw into water
Do not throw on fire
Pole orientation
Li-Ion
max. 45oC
For indoor use only

16
IN THE BOX
Description
1. Keyless chuck
Accessories
71 piece accessory kit
2. Torque adjustment ring
3. ON/OFF Switch
4. Forward/reverse control
5. Gear selection
6. Soft grip
7. Battery pack
8. Release button
9. LED light
10. Power indicator
11. Charger
1
24
6
7
8
10
5
3
9
11

17
OPERATION
NOTE: Before using the tool, read the instruction book
carefully.
INTENDED USE
This tool is intended for driving in and loosening screws as
well as for drilling in wood, metal and plastic.
BEFORE PUTTING INTO OPERATION
1. CHARGING PROCEDURE ( SEE FIG. A)
NOTE:
a) Do not use any charger other than that specifically
provided for use with the tool.
b) If the battery pack is very hot, you must remove your
battery pack from the charger and allow time for your
battery pack to cool down before recharging.
c) The battery in your new tool is not charged when it leaves
the plant. Therefore, it must be fully charged before using
the first time.
d) Please charge the battery to reach full or no less than half
charge before storage. If the tool will not be used for long
periods of time, charge the battery every 3-6 months.

18
Check the battery capacity via battery capacity indicator
(5).
Press the button and check the LEDs:
• Red: battery too low
• Red + yellow: battery half charged
• Red + yellow + green: battery fully charged.
CHARGING
1) Plug charger plug into a suitable power outlet, and the
charger indicator will be green.
2) Plug the output plug of the charger into the socket of the
battery, the charger indicator will be red to indicate the
charging process has started.
3) On completion of charge, the charger indicator is green.
The pack is now fully charged, unplug the charger and
remove the battery pack.
IMPORTANT:
When charging, the charger and battery may become warm to
the touch, this is normal and does not indicate a problem.
A

19
WARNING! When the battery charge runs out after
continuous use or exposure to direct sunlight or heat,
allow time for the tool to cool down before re-charging
to achieve the full charge.
2. INSTALLING AND REMOVING THE BATTERY PACK
(SEE FIG. B)
a) TO REMOVE THE BATTERY PACK
First, press the battery pack release button firmly and then
pull the battery pack out from your tool.
b) TO INSTALL THE BATTERY PACK
Position the fully charged battery pack into the tool with
sufficient force until it clicks into position.
B

ba
C
3
3
4
