Sovereign SQS 2500 User manual

SQS 2500; EX; UK
Electric Silent Shredder Artikel-Nr.: 3430523 Ident-Nr.: 01035

Komponenten / Ersatzteile
Position Artikel-Nr. Beschreibung
2 343052002003 screw für Einfülltrichter
3 343052002004 feeding barrel
4 343052002005 feeding funnel
6 343052002007 plug
8 343052002009 fan
19 343052002020 1st inner gear
31 343052002032 gasket
32 343052002033 2nd planetary gear
38 343052002039 blade frame
42 343052002043 shaft sleeve
46 343052002047 blade
47 343052002048 blade cover für Messerwalze
49 343052002050 screw
50 343052002051 nut M10
51 343052002052 the pole for adjusting M10 x 24
52 343052002053 left support
54 343052002055 screw
55 343052002056 capacitor
58 343052002059 seal of switch cover
59 343052002060 overload protector
62 343052002063 pressure ring
64 343052002065 electromagnetic switch
65 343052002066 switch
71 343052002072 transverse shaft
73 343052002074 right support
75 343052002076 support foot
901 343052002901 wheel complete

Operating Instructions
Silent shredder

Art.-Nr.: 921258
EH-Art.-No.: 34.305.23 I.-No.:01035 SQS 2500
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 1

2

For your own safety, please read these
instructions before trying to use your new
equipment. Mistakes in following these
instructions may lead to serious injury. Before
every use, take the time to familiarise yourself
with your silent shredder.
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 2

3
1
A
2
4
6
3
8
7
5
1
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 3

4
2
3
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 4

5
GB
1. Important information
Please read the directions for use carefully and
observe the information provided. It is important to
consult these instructions in order to acquaint your-
self with the machine, its proper use and safety pre-
cautions.
Keep these instructions in a safe place.
Improper operation of the electric garden shredder
can lead to serious injuries.
This electric garden refuse shredder is designed only
for shredding organic garden waste.
Important!
For safety reasons, the electric garden shredder
may not be operated by individuals under 16
years of age.
Safety information
Caution! The ON/OFF switch must be set to OFF
and the power plug removed from the socket-outlet
before cleaning or doing any other work on the
shredder and whenever the cable becomes tangled.
The shredder will continue to run briefly after it is
switched off.
앬The shredder is not to be used by individuals
under 16 years of age or any other persons who
are not acquainted with these directions for use.
앬The operator is responsible for the safety of third
parties within the working radius of the shredder.
앬The shredder must be placed on a flat and firm
surface where it can stand securely.
앬Always wear gloves and safety goggles when
working with the shredder.
앬Each time before you leave the shredder, switch
it off and or remove the plug.
앬Maintenance and cleaning work on the shredder
as well as the removal or adjustment of any safety
devices may only be performed when the motor is
at a standstill and the power plug has been re-
moved from the socket outlet.
앬The safety devices supplied with the shredder
must be used.
앬Before starting or switching on the motor, the
funnel inlet must be fully mounted and secure.
앬Ear protection is recommended.
앬Do not reach with your hands into the funnel inlet
or discharge opening.
Additional Safety information
앬The shredder must be assembled correctly before
it is put into operation.
앬Examine the shredder each time before you use it.
Do not use the shredder if any safety devices are
damaged or worn. Never put safety devices out of
operation.
앬Use the shredder only for the purpose specified in
these instructions.
앬Work only in good visibility.
앬Always make sure of your footing while working.
앬Never leave the shredder unattended at your work
place. Store the shredder in a safe place during
interruptions.
앬If you interrupt your work to move to a different
position it is imperative to switch off the shredder
whilst you are moving there.
앬Never use the shredder in the rain or in moist or
wet conditions.
앬Protect the shredder from the damp and rain.
앬Always wear suitable clothing to protect your head,
hands and feet from injury. Wear a helmet,
goggles or visor, high boots or strong shoes, long
trousers made of tough material, and work gloves.
앬Keep the shredder away from other persons,
particularly children and pets.
CAUTION! The guard is vital for your safety
and for the safety of others, and it is also
essential for the shredder to work correctly.
Failure to observe this instruction will not
only create a potential hazard, it will also
result in the loss of your rights under the war-
ranty.
앬After use, unplug the machine and check it for
damage.
앬When you are not using the shredder, keep it in a
dry place out of the reach of children.
앬Check the screws regularly to see that they are
properly tightened.
앬The mains voltage must be the same as the
voltage specified on the rating plate.
앬Power cables used with the shredder must not be
of a lighter duty class than HO7RN-F rubber-
insulated flexible cables according to DIN 57282 /
VDE 0282 with a minimum diameter of 1.5 mm2.
Plug connectors must be equipped with earthing
contacts and the coupling must be rain-water-
protected.
앬Use only original replacement parts for repair and
maintenance purposes.
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 5

6
GB
앬Have repairs carried out only by a qualified
electrician.
앬Examine the shredder for signs of wear or
damage each time before you use it. Have essen-
tial repairs carried out without delay.
앬Never use replacement parts or accessories which
are not recommended by the manufacturer.
앬Pull out the power plug before carrying out any
inspection, cleaning or other work on the shredder
and whenever it is not being used.
앬Before you begin your work, examine the material
you want to shred. Remove any foreign bodies.
Continue to watch out for foreign bodies while you
are working. If you come across any foreign
bodies while shredding, shut down the machine
and remove the items in question.
앬Keep the machine away from other persons,
particularly children and pets.
앬Use the machine only in the way described in
these operating instructions.
앬The electric circuit must be protected at least by a
10A fuse.
앬The efficiency of the machine will be greatly
reduced if a connecting cable with too small a
cross section is used. A conductor cross section of
at least 3x1.5 mm2is required for cables up to 25
m long, and one of at least 3x2.5 mm2for cables
longer than 25 m.
앬If the machine has to be lifted for transporting, be
sure to switch off the motor first and wait for the
cutter to come to a standstill. Each time before you
leave the machine, switch off the motor and pull
out the power plug. Before you connect the
machine to the power supply, make sure that the
funnel inlet is properly connected to the motor
housing.
앬If the garden refuse shredder vibrates excessively,
turn off the motor, pull out the power plug, and find
out immediately what is causing the vibrations.
Intensive vibration is usually a sign that something
is wrong.
앬If the connection lead for this machine is
damaged, it must be replaced by the manufacturer
or its after-sales service or similarly trained
personnel to avoid danger.
Caution! The cutters continue to run for a few
seconds after the motor is switched off.
Plug replacement
Your shredder has a fitted plug, however, if you need
to replace the fitted plug then follow the instructions
below.
IMPORTANT
The wires in the mains lead are coloured in accor-
dance with the following code.
Blue - Neutral Brown Live
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured mar-
kings identifying the terminals in your plug, proceed
as follows.
The wire which is coloured blue must be connected
to the terminal which is marked with N. The wire
which is coloured brown must be connected to the
terminal which is marked with the letter L.
Warning: Never connect live or neutral wires to the
earth terminal of the plug. Only fit an approved 13
Amp BS1363/A plug and a 13 Amp fuse.
Note: If a moulded plug is fitted and has to be remo-
ved take great care in disposing of the plug and
severed cable. It must be destroyed to prevent enga-
ging into a socket. If the supply cord is damaged it
must be replaced by a service agent or a similarly
qualified person in order to avoid hazard.
Caution! The cutters continue to run for
a few seconds after the motor is swit-
ched off.
2. Description of the warning sign (see
Fig. A) on the machine
1. Important! Read the operating instructions
and follow the warnings and safety instructi-
ons
2. Important! Always wear safety goggles, ear
protection, protective gloves and heavy-duty
work clothes. We recommend that you wear a
helmet with a face guard.
3. Important! Protect the machine from the
damp and never expose it to rain.
4. Always set the ON/OFF switch to OFF and
pull the power plug out of the socket-outlet
Brown L
(live)
13 Amp fuse
approved to
BS 1362
Cable grip
Blue N
(neutral)
Earth terminal
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 6

7
GB
before doing any work on the shredder, e.g.
cleaning the shredder and making adjust-
ments, or if the power cable becomes dama-
ged.
5. Important! If the mains lead is damaged or
cut, pull out the power plug immediately.
6. Caution! Pieces of shredded material may be
thrown out of the shredder during operation.
Keep a safe distance between yourself and
the machine.
7. Caution! The cutters continue to run after the
motor is switched off. Wait for the cutters to
come to a standstill. Risk of injury!
3. Technical data
Voltage: 230 V ~ 50 Hz
Power rating: 2500 W (S6-40%)
2000 W (S1)
Cutting unit idling speed 40 min-1
Branch diameter: max. 40 mm
LPA sound pressure level: 81 dB (A)
LWA sound power level: 91 dB (A)
Weight: 26 kg
S6 (40%) stands for a duty cycle based on 4 minutes
on-load and 6 minutes off-load operation. Maximum
power consumption depends on the consistency of
the material being shredded.
4. Layout of the (Figure 1)
1 Funnel inlet
2 Motor protection switch
3 ON/OFF switch
4 Switch for selecting the direction of rotation
5 Integral mains plug
6 Knob for setting the cutter blade
7 Chassis
8 Discharge opening
5. Proper use
This electric garden shredder is designed only for
shredding organic garden waste. Place biologi-cally
degradable material, e.g. leaves, branches, dead flo-
wers etc., into the loading funnel inlet.
Collecting the shredded material
A container can be placed underneath the ejector
opening to catch the shredded material.
6. Before starting up
6.1 Assembly (Fig. 2)
앬Take all the parts out of the packaging.
앬Fit the chassis to the housing using the two lock
nuts (item 2). Use the assembly tool provided for
this purpose.
앬Fit the axle (item 3) to the chassis using the two
M6 x 50 screws (item 4) and nuts (item 2). Use the
assembly tool provided for this purpose.
앬Push the wheels (item 5) on to the axle.
앬Secure the wheel cover (item 6) on the axle using
a hammer.
7. Starting up
7.1 ON/OFF switch (Fig. 1 / item 3)
앬Press the green knob to switch on the shredder.
앬Press the red knob to switch it off.
Important: The machine has a zero voltage switch.
This prevents the machine restarting unintentionally
after a power failure.
7.2 Switch for selecting the direction of rotation
(Fig. 1 / Item 4)
Important! The switch for selecting the direction
of rotation can only be moved when the shredder
is switched off.
Position “1”
The material is automatically drawn in by the blade
and shredded.
Position “0”
The blade rotates in the opposite direction to release
jammed material. After moving the selector switch to
the “0” position, press and hold the green knob of the
ON/OFF switch. The blade will start to rotate in the
opposite direction. As soon as you release the
ON/OFF switch, the shredder will stop automatically.
Important! Always wait until the shredder has
reached a standstill before you switch it on again.
Large items or pieces of wood will be discharged
both in the cutting and in the release direction after
the blade has been started and reversed several
times.
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 7

8
GB
7.3 Motor protection (Fig. 1 / Item 2)
An overload (for example if the blade is jammed) will
cause the machine to cut out after a few seconds. To
protect the motor from damage the motor protection
switch stops the power supply automatically. Wait for
at least one minute before you press the reset knob
so that you can restart the machine.
Then press the ON/OFF switch.
If the blade becomes jammed, turn the switch for
selecting the direction of rotation to the left to position
“1” before you switch on the shredder again.
7.4 Practical tips
앬Read the special and general safety instructions
(section 1).
앬Wear work gloves, goggles and ear protection.
앬Place the material you wish to shred into the
opening on the right-hand side (the blade rotates
anti-clockwise).
앬The material is drawn into the shredder automatic-
ally. CAUTION! Long pieces of material projecting
out of the funnel inlet may spring back when it is
drawn in – keep a safe distance between yourself
and the machine.
앬Judge the quantity of material which you put into
the funnel inlet so that the funnel does not clog.
앬If you want to shred withered, damp material that
has been lying in the garden for several days,
alternate between putting in this material and
branches. This will help to prevent the loading
funnel becoming clogged with material.
앬Do not shred soft waste (e.g. kitchen waste) – put
it straight in the compost box.
앬Entangled branches and leaves should be
thoroughly shredded before loading any more
material.
앬Do not allow the discharge opening to become
clogged with shredded material.
앬Do not cover the ventilation slits.
앬Do not place heavy material or thick branches into
the machine continuously. This may cause the
blade to jam.
앬Use a plunger or hook to remove jammed objects
from the funnel or discharge openings.
Important: The material will be crushed, mashed
and shredded by the cutting unit, thus accelerating
the decomposition process for composting.
7.5 Adjusting the cutter blade (Fig. 3)
The cutter blade and cutting unit are perfectly adjus-
ted at the factory. Only if it suffers wear does the cut-
ter blade require adjustment (switch the machine on
for this purpose). To ensure the best possible results
from your shredder, the gap between the cutter blade
(item B) and the shredding blade (item A) should be
approx. 0.50 mm.
There is an adjustment device on the right-hand side
of the plastic housing for this purpose. Turn the knob
clockwise so that the screw (item C) moves towards
the shredding blade. After a half-turn the counter
blade will have moved 0.50 mm closer to the shred-
ding blade. After completing this adjustment check
whether the blade produces the desired results.
IMPORTANT: If the shredding blade is touching the
cutter blade, it may cause damage. So if metal frage-
ments fall out of the discharge opening then you
must check the cutter blade adjustment.
8. Troubleshooting
Motor does not run
앬The motor protection switch has tripped. Move the
switch for selecting the direction of rotation to
position “0” and press the reset knob. Press and
hold the ON/OFF switch to switch on the shredder
after a brief delay. Once the blockage has been
cleared, return the switch for selecting the
direction of rotation to position “1”.
앬Power failure
Check the mains lead, plug and fuse.
Material is not drawn in by the shredder
앬The shredding blade rotates backwards
Check the direction of rotation
앬Material blockage in the funnel
Move the switch for selecting the direction of
rotation to position “0” and switch on the shredder.
Pull the material out of the funnel. Feed in thick
branches again so that the blade does not
immediately engage again in the notches it
previously cut.
앬The shredding blade is jammed
Move the switch for selecting the direction of
rotation to position “0” and switch on the shredder.
The blade will now rotate in the opposite direction
and release the jammed material.
Important! Do not change the direction of rotation
until the shredder has reached a complete stand-
still.
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 8

9
GB
9. Care and maintenance
Caution! Interrupt the power supply by pulling the
plug out of the socket-outlet before you carry out any
checks or maintenance work on the machine.
앬Clean the machine regularly. This will help to keep
the machine in good working order and is the
basis for a long working life.
앬Keep the vent slots clean while you work.
앬Clean the plastic body and other plastic parts with
a mild household cleaning agent and a damp
cloth. Do not use any aggressive agents or
solvents for cleaning purposes.
앬Never clean the shredder by spraying with water.
앬Prevent water getting inside the machine at all
cost.
앬Check the chassis securing screws from time to
time to ensure that they are tight.
앬If you do not intend to use the shredder for a
lengthy period, protect it from corrosion using
environmentally friendly oil.
10. Ordering replacement parts
Please quote the following data when ordering repla-
cement parts:
앬Type of machine
앬Article number of the machine
앬Identification number of the machine
앬Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
11. Waste disposal
Accessories and packaging should be disposed of in
an environment-friendly fashion, i.e. by taking them
to a recycling depot. Plastic parts are coded for pur-
poses of separation when recycling.
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 9

10
Derklärt folgende Konformität gemäß EU-Richtlinie
und Normen für Artikel
declares conformity with the EU Directive
and standards marked below for the article
Fdéclare la conformité suivante selon la
directive CE et les normes concernant l’article
verklaart de volgende conformiteit in overeen-
stemming met de EU-richtlijn en normen voor
het artikel
Edeclara la siguiente conformidad a tenor de la
directiva y normas de la UE para el artículo
Pdeclara a seguinte conformidade de acordo
com a directiva CE e normas para o artigo
Sförklarar följande överensstämmelse enl. EU-
direktiv och standarder för artikeln
ilmoittaa seuraavaa Euroopan unionin direkti-
ivien ja normien mukaista yhdenmukaisuutta
tuotteelle
erklærer herved følgende samsvar med EU-
direktiv og standarder for artikkel
заявляет о соответствии товара
следующим директивам и нормам EC
izjavljuje sljedeću uskladjenost s odredbama i
normama EU za artikl.
declarå urmåtoarea conformitate cu linia direc-
toare CE μi normele valabile pentru articolul.
ürün ile ilgili olarak AB Yönetmelikleri ve
Normlar∂ gere©ince aμa©∂daki uygunluk aç∂kla
mas∂n∂ sunar.
‰ËÏÒÓÂÈ ÙËÓ ·ÎfiÏÔ˘ıË Û˘Ìʈӛ· Û‡Ìʈӷ ÌÂ
ÙËÓ √‰ËÁ›· ∂∂ Î·È Ù· ÚfiÙ˘Ô ÁÈ· ÙÔ ÚÔ˚fiÓ
Idichiara la seguente conformità secondo la
direttiva UE e le norme per l’articolo
attesterer følgende overensstemmelse i
henhold til EU-direktiv og standarder for
produkt
prohlašuje následující shodu podle směrnice
EU a norem pro výrobek.
Ha következő konformitást jelenti ki a termékek-
re vonatkozó EU-irányvonalak és normák
szerint
pojasnjuje sledečo skladnost po smernici EU
in normah za artikel.
deklaruje zgodność wymienionego poniżej
artykułu z następującymi normami na
podstawie dyrektywy WE.
vydáva nasledujúce prehlásenie o zhode podľa
smernice EÚ a noriem pre výrobok.
деклаpиpа следното съответствие съгласно
диpективите и ноpмите на ЕС за пpодукта.
заявляє про відповідність згідно з Директивою
ЄС та стандартами, чинними для даного товару
deklareerib vastavuse järgnevatele EL direktiivi
dele ja normidele
deklaruoja atitikti pagal ES direktyvas ir normas
straipsniui
izjavljuje sledeçi konformitet u skladu s odred
bom EZ i normama za artikl
Landau/Isar, den 12.01.2006
Ensing
Leiter Technik EC
Shredder SQS 2500
Weichselgartner
Leiter QS Konzern
ISC GmbH
Eschenstraße 6
D-94405 Landau/Isar Konformitätserklärung
98/37/EG
73/23/EWG_93/68/EEC
97/23/EG
89/336/EWG_93/68/EEC
90/396/EWG
89/686/EWG
87/404/EWG
R&TTED 1999/5/EG
2000/14/EG:
95/54/EG:
97/68/EG:
x
x
x
x
Art.-Nr.: 34.305.23 I.-Nr.: 01035 Archivierung: 3430520-04-4155050-E
Subject to change without notice
EN 13683; EN 60335--1+A11+A1+A12+A16:; EN 55014-1;
EN 55014-2; EN 61000-3-2; EN 61000-3-11; KBV V
LWM = 88 dB LWA = 91 dB
P = 2,5 kW S6 40%
EE
SCG
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 10

11
 WARRANTY CERTIFICATE
The product described in these instructions comes with a 2 year warranty cove-
ring defects. This 2-year warranty period begins with the passing of risk or when
the customer receives the product. Please retain receipt as proof of purchase.
For warranty claims to be accepted, the product has to receive the correct main-
tenance and be put to the proper use as described in the operating instructions.
Your statutory rights of warranty are naturally unaffected during these 2
years.
This warranty applies in Germany, or in the respective country of the manufactu-
rer’s main regional sales partner, as a supplement to local regulations. Please
note the details for contacting the customer service center responsible for your
region or the service address listed below.
GARANTIEURKUNDE
Auf das in der Anleitung bezeichnete Gerät geben wir 2 Jahre
Garantie, für den Fall, dass unser Produkt mangelhaft sein sollte.
Die 2-Jahres-Frist beginnt mit dem Gefahrenübergang oder der
Übernahme des Gerätes durch den Kunden. Voraussetzung für
die Geltendmachung der Garantie ist eine ordnungsgemäße
Wartung entsprechend der Bedienungsanleitung sowie die be-
stimmungsgemäße Benutzung unseres Gerätes.
Selbstverständlich bleiben Ihnen die gesetzlichen Gewähr-
leistungsrechte innerhalb dieser 2 Jahre erhalten. Die Garan-
tie gilt für den Bereich der Bundesrepublik Deutschland oder der
jeweiligen Länder des regionalen Hauptvertriebspartners als Er-
gänzung der lokal gültigen gesetzlichen Vorschriften. Bitte be-
achten Sie Ihren Ansprechpartner des regional zuständigen Kun-
dendienstes oder die unten aufgeführte Serviceadresse.
ISC GmbH · International Service Center
Eschenstraße 6 · D-94405 Landau/Isar (Germany)
Info-Tel. [phone] • Telefax 0180-5 835 830
Service- und Infoserver: http://www.isc-gmbh.info
Sovereign Customer Helpline 0044 (0) 151 649 1500
 Technical specifications subject to change
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 11

EH 01/2006

The reprinting or reproduction by any other means, in whole or in
part, of documentation and papers accompanying products is
permitted only with the express consent of ISC GmbH.
For EU countries only
Never place any electric tools in your household refuse.
To comply with European Directive 2002/96/EC concerning old electric and electronic equipment and its
implementation in national laws, old electric tools have to be separated from other waste and disposed of
in an environment-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to the demand to return electrical devices:
As an alternative to returning the electrical device, the owner is obliged to cooperate in ensuring that the
device is properly recycled if ownership is relinquished. This can also be done by handing over the used
device to a returns center, which will dispose of it in accordance with national commercial and industrial
waste management legislation. This does not apply to the accessories and auxiliary equipment without
any electrical components which are included with the used device.
Anleitung SQS 2500 GB 19.01.2006 10:12 Uhr Seite 12
