Sovereign ASYEHT01450 User manual

18V CORDLESS HEDGE TRIMMER
Item No. 555375
Model No. ASYEHT01450
INSTRUCTION MANUAL
Please read these instructions fully before starting assembly.
HHGL Limited, MK9 1BA HHGL (ROI) Limited, D02 X576 Oct 19
www.gardenservicecentre.co.uk
Technical Support & Parts
01904 727509
Mon-Fri 9am-5pm Sat-Sun 11am-4pm

2 3
CONTENTS
General safety warning 3
Intended use 12
Warning symbols 12
In the box 15
Assemble the hedge trimmer 16
Operating the hedge trimmer 20
Maintenance and storage 22
Troubleshooting 24
Technical data 25
Recycling and disposal 27
Getting help 27
Warranty 28
GENERAL SAFETY WARNINGS
SAFETY WARNINGS
WARNING! Read all safety warnings and
instructions.
Failure to follow the warnings and instructions
may result in electric shock, re and/or serious
injury.
WARNING! Read all safety warnings and
instructions designated by the symbol.
Save all warnings and instructions for future
reference.
• Always ensure anyone intending to operate this
hedge trimmer is fully conversant with the contents
of this assembly manual prior to assembling,
maintaining or operating the hedge trimmer.
• Perform assembly operations as described in this
manual. Failure to observe this warning may lead
to serious injury, death, or damage to the hedge
trimmer.
• Always take care when removing the packaging, to
prevent damage to you or to the hedge trimmer.
IMPORTANT! Before assembling the hedge trimmer,
check all the parts indicated in the manual are in the
box. Inspect all the parts for signs of damage. Do
not assemble the hedge trimmer if you observe any
damaged components.

4 5
GENERAL POWER TOOL SAFETY WARNINGS
• Read the instructions carefully. Be familiar with
the controls and the correct use of the appliance.
Read and understand the operator’s manual and
observe the warnings and instruction labels axed
to the appliance.
• Users. Never allow children or people unfamiliar
with these instructions to use the appliance. Local
regulations may restrict the age of the operator.
Never operate the tool under the inuence of
alcohol, medication or drugs.
• Use the appropriate tool. This device is only
intended for trimming hedges outdoors and only
designated for use on private property. Do not force
small tools or attachments to do the job of a heavy-
duty tool.
• Keep work areas clean. Cluttered areas can cause
accidents.
• Consider work area environment. Do not expose
the tool to high humidity or rain. Do not use the tool
in damp and wet conditions. Keep the work area
well lit. Do not use the tool where there is a risk of
causing re or explosion, e.g. in the presence of
ammable liquids and gases.
• Keep all bystanders, children and pets away.
The operator or user is responsible for accidents or
hazards occurring to other people or their property.
• Dress appropriately. Do not wear loose clothing,
hair or jewellery, as these can be caught in moving
parts. Wear non-slip footwear when working
outdoors. Wear protective hair covering to keep long
hair out of the way.
• Personal Protective Equipment (PPE). Always use
safety glasses and gloves. Use a face or dust mask
whenever the operations may produce dust or ying
particles. Wear ear protection whenever the sound
level seems uncomfortable.
• Do not overreach. Keep proper footing and balance
at all times.
• Stay alert, watch what you are doing. Use
common sense when operating the appliance. Do
not operate the tool when you are tired.
• Grip the tool securely. The operator should have
one hand on the main handle, the other on the front
handle. Ensure you keep your nger o the trigger
until you are ready to use the product.
• Remove adjusting keys and wrenches. Always
check that adjusting keys and wrenches are removed
from the tool before operating.
• Risk of cut. Do not try to grasp or remove trimmings
when the product is running. Only remove
trimmings when the product is switched o and
disconnected from the power supply.
• Disconnect the battery. Disconnect the battery
from the tool when not in use, or when servicing or
cleaning.

6 7
• Check for damaged parts. Before further use,
carefully check the tool for damage. Check for
alignment of moving parts, binding of moving
parts, breakage of parts, mounting, and any other
condition that may aect its operation. Do not use
the tool if any parts are damaged or defective. Have
any damaged or defective parts repaired or replaced
by an authorised service centre. Never attempt any
repairs yourself.
• Store idle tools. When not in use, tools should be
stored in a dry, secure place, out of the reach of
children.
• Maintain tools with care. Keep tools clean and in
good condition for better and safer performance.
Follow the instructions for maintenance and
changing accessories. Keep handles and switches
dry, clean and free from oil and grease.
• Have your tool repaired by an authorised service
centre. This tool is manufactured in accordance with
the relevant safety regulations. To avoid danger,
electrical appliances must only be repaired by
qualied technicians.
WARNING!
The use of attachments or accessories not
recommended by the manufacturer of this tool,
can result in serious personal injury.
ADDITIONAL SAFETY INSTRUCTIONS FOR
BATTERIES AND CHARGERS
Batteries
• Never attempt to open the unit for any reason.
• Do not expose it to water.
• Do not incinerate the battery pack, even if it is
severely damaged or is completely worn out; the
battery pack can explode in a re.
• Do not store in locations where the temperature
may exceed 40oC.
• Do not leave the battery pack in the charger when
the charging is nished, otherwise battery leakage
may occur.
• Charge only at room temperature.
• Charge only by using the charger provided with the
tool (see technical data).
• Before charging, make sure that the battery is dry
and clean.
• Use only the correct type of battery for the tool (see
technical data).
• Only dispose of electrical or battery items in
separate collection schemes.
• Under extreme conditions, battery leakage may
occur. When you notice liquid on the battery,
proceed as follows:
- Carefully wipe the liquid o using a cloth.
- Avoid skin contact.

8 9
- Dispose of the battery in an environmentally-
friendly manner.
• In case of skin or eye contact, follow the instructions
below:
- The battery uid, a 25-30% solution of potassium
hydroxide, can be harmful. In case of skin contact,
immediately rinse with water. Neutralise with a mild
acid, such as lemon juice or vinegar. In case of eye
contact, rinse thoroughly with clean water for at
least 10 minutes. Consult a physician.
• Don’t let any metal objects contact the electrode
plate on the battery pack.
WARNING!
The batteries in your battery pack are the
lithium-ion type. Do not dispose of battery
packs/batteries into household waste, re
or water. Battery packs/batteries should
be collected, recycled or disposed of in an
environmentally-friendly manner.
Chargers
• The charger’s plug must match the outlet. Never
modify the plug in any way. Modied plugs and non-
matching outlets will increase the risk of electric
shocks.
• Use your charger only to charge batteries of the type
supplied with your tool. Other batteries could burst,
causing personal injury and damage.
• Only 2 battery packs are allowed to be charged
continuously, in order to prevent over heating of the
charger. Necessary rest time is required to let the
charger cool down before further charging.
• When charging is nished, unplug the charger from
the mains socket outlet and remove the battery pack
from the charger. Do not leave the battery pack in
the charger.
• Never carry the charger by its cord or pull it to
disconnect it from the socket. Keep the cord away
from heat, oil and sharp edges.
• Never attempt to charge non-rechargeable batteries.
• The cord of the charger is not changeable; do not
continue to use if the cord is damaged.
• Do not expose to water or rain, and never use in wet
conditions.
• Do not open the charger.
• Do not probe the charger.
• Intended for indoor use only.
ADDITIONAL SAFETY INSTRUCTIONS FOR
HEDGE TRIMMERS
• THIS TOOL CAN CAUSE SERIOUS INJURIES. Read
instructions carefully for the correct handling,
preparation, maintenance, starting and stopping of
the tool. Be familiar with all controls and proper use
of the tool.
• Only use the tool in daylight or good articial light.

10 11
• Always be aware of your surroundings and stay alert
for possible hazards that you may not hear due to
the noise of the tool.
• Do not carry the tool with your hands on the switch
unless the battery has been removed.
• If you have not used a hedge trimmer before,
preferably seek practical instruction by an
experienced user in addition to studying this
manual.
• Never touch the blades while the tool is running.
• Never attempt to force the blades to come to a
standstill.
• Do not put the tool down until the blade has come
to a complete standstill.
• Regularly check the blades for damage and wear. Do
not use the machine when the blades are damaged.
• Take care to avoid hard objects (e.g. metal wire,
railings) when trimming. Should you accidentally hit
any such object, immediately switch the tool o and
check for any damage.
• Should the tool start to vibrate abnormally,
immediately switch it o and check for any damage.
• Always be aware of falling debris when cutting the
higher sides of a hedge.
• Be aware of the cutting blade; always wear gloves to
protect your hands from being potentially injured.
• NOTE: Do not switch the hedge trimmer on and
o frequently over a short period of time, and in
particular do not play with the ON/OFF switch.
• Never allow children to use the tool.
• Beware of overhead power lines.
• Avoid operating while people, especially children are
nearby.
• Dress properly! Do not wear loose clothing or
jewellery which can be caught in moving parts. Use
of sturdy gloves, non-skid footwear, and safety
glasses is recommended.
• If the tool stalls, immediately switch it o. Remove
the battery before attempting to remove any
obstructions.
• Remove the battery before checking, maintenance
or working on the tool.
• While operating the tool always be sure of a safe
and secure operating position especially when using
steps or a ladder.
• Do not attempt to repair the tool.
• Do not operate the tool with a damaged or
excessively worn cutting device.
• Always wear ear protection, goggles and a helmet
whilst operating.
• Always ensure that all guards are tted when using
the tool. Never attempt to use an incomplete tool or
a tool with unauthorized modications.
• Always use two hands to operate the tool.
• When transporting or storing the tool, always t the
blade sheath.

12 13
INTENDED USE
This Li-ion hedge trimmer ASYEHT01450 is intended for
trimming hedges, bushes and shrubs. Observe the technical data
for the maximum cutting capacity. Do not cut non-plant material
or branches exceeding the stated maximum capacity.
For safety reasons it is essential to read the entire instruction
manual before rst operation and to observe all the instructions
therein.
This product is intended for private domestic use only, not for
any commercial trade use. It must not be used for any purposes
other than those described.
WARNING SYMBOLS
Warning!
Conforms to all relevant safety standards.
Read the instruction manual before use.
Wear ear protection.
Wear eye protection.
Wear dust mask.
Keep ngers away from moving cutting device!
Keep bystanders away.
Disconnect the battery pack before any repair or
maintenance.
Do not expose to rain.
Guaranteed sound power level data (96dB), in
accordance with Directive 2000/14/EC.
WARNING SYMBOLS ON THE CHARGER
Before use, carefully read through the user manual.
The charger is for indoor use only.
Protection class II.
Pole orientation.
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling
advice.
xx

14 15
IN THE BOX
Parts
1. Blade
2. Guard
3. Safety Switch
4. Trigger
5. Battery Pack
6. Charger
WARNING SYMBOLS ON THE BATTERY
Do not dispose of batteries in rivers or immerse in water.
Do not subject the battery to strong sunlight over long
periods and do not leave it on a heater (max. 45oC).
Do not dispose of batteries in a re. They will explode
and cause injury.
Contains Li-ion battery. All batteries must be recycled or
disposed of properly.
Do not dispose of batteries in household waste. Return
exhausted batteries to your local collection or recycling
point.
max. 45
o
C
Li-Ion
7. Charging plug
8. Front Handle
9. Blade Sheath
6
7
5
2
13
4
8
9

16 17
ASSEMBLE THE HEDGE TRIMMER
WARNING!
Before using the tool, read all instructions carefully.
CHARGING THE BATTERY
WARNING!
The charger and battery pack are specically designed
to work together so do not attempt to use any other
devices. Never insert or allow metallic objects into your
charger or battery pack connections because an electri-
cal failure and hazard will occur.
The battery needs to be charged before rst use and whenever
it fails to produce sucient power on jobs that were easily done
before.
WARNING! NEVER LEAVE THE BATTERY AND CHARGER
UNATTENDED WHEN CHARGING THE BATTERY.
This product comes with a lithium-ion battery pack. Lithium-
ion batteries don’t lose charge when not in use, and don’t lose
charging capacity overtime. Nevertheless, it is best practice to
charge the battery when empty or insucient to do the job.
CHARGING PROCEDURE
WARNING!
The battery cannot be charged immediately after use, it
should cool o for a period of time.
1. Plug the charger into an appropriate AC power outlet.
2. Insert the charger plug (7) into the charging hole (A1) in
battery pack (5), make sure the plug is fully in position. The
LED (A2) lights on battery pack ashes to tell you that the
battery pack is on charge.
3. The battery pack will be fully charged in 4-5 hours. And the
three LED (A2) lights turn green to tell you that the battery
pack is fully charged.
Important charging notes
Longest life and best performance can be obtained if the battery
pack is charged when the air temperature is between 18-24oC.
Do not charge the battery pack in a very low or very high air
temperature. This is important and will prevent serious damage
to the battery pack.
1. When using your tool continuously, the batteries in your
battery pack will become hot. You should let a hot battery
pack cool down for approximately 30 minutes before
attempting to recharge.
2. The charger and battery pack may become warm to touch
while charging. This is a normal condition and does not
indicate a problem.
3. Use the charger in normal room temperatures whenever
possible. To prevent overheating, do not cover the charger
and do not charge battery packs in direct sunlight or near
heat sources.
7
5
A1
A2

18 19
4. If the battery pack does not charge properly:
(1). Check the main socket by plugging in a lamp or other
appliance.
(2). Move the charger and battery pack to a location where
the surrounding air temperature is approximately 18-24oC.
(3). If charging problems persist, take or send the tool, battery
pack and charger to your local service centre.
5. The battery pack should be recharged when it fails to
produce sucient power on jobs which were easily
done previously. DO NOT CONTINUE to use under these
conditions. Follow the charging procedure. You may also
charge a partially used pack whenever you desire with no
adverse eect on the battery pack.
6. Under certain conditions, with the charger plugged in to
the power supply, the exposed charging contacts inside the
charger can be shorted by foreign material. Foreign materials
of a conductive nature, such as, but not limited to, steel wool,
aluminium foil, or any build-up of metallic particles, should be
kept away from charger cavities. Always unplug the charger
from the power supply when there is no battery pack in the
cavity. Unplug the charger before attempting to clean it.
7. Do not immerse the charger in water or any other liquid.
WARNING!
Don’t allow any liquid to get inside the charger; electric
shocks may result. To facilitate the cooling of the battery
pack after use, avoid placing the charger or battery pack
in a warm environment, such as in a metal shed, or an
un-insulated trailer.
WARNING!
Never attempt to open the battery pack for any reason. If
the plastic housing of the battery pack breaks or cracks,
return it to a service centre for recycling; do not put it
into further use.
TAKE OFF THE BLADE SHEATH
1. Take o the blade sheath.
Note! Make sure the battary pack is taken from the trimmer.
REMOVE OR INSTALL THE BATTERY PACK
WARNING!
Always release the on/o trigger before insertion or re-
moval of the battery pack.
Remove the battery pack. Depress the button (D) on the two
sides of the battery pack, and then remove the pack (E) from the
tool.
Install the battery pack. Align the ribs on both sides of the
battery pack with the slots in the housing, and slip it into place.
Always insert it all the way until it locks in place with a click
sound. If not, it may accidentally fall out of the tool, causing
injury to you or someone around you.
D
DE

20 21
OPERATING THE HEDGE TRIMMER
Starting
WARNING!
If any parts are missing, damaged or broken, do not
operate your hedge trimmer until all damaged parts
have been replaced or repaired. Failure to do so could
result in serious personal injury.
For your safety, this tool is equipped with a dual safety-switch
system. This system prevents starting the tool inadvertently, and
will only allow operation while holding the tool with both hands.
SWITCHING ON
Hold the product with one hand at the rear handle and the other
at the front handle.
Press the trigger (F) and the front handle safety switch (G) at the
same time, to switch the product on.
SWITCHING OFF
Release the front handle safety switch (G) or the trigger (F).
NOTE! Never attempt to lock the dual safety-switch system in
the on position.
CUTTING GUIDE
WARNING!
Before using this hedge trimmer, make sure that you
have read all of the safety instructions.
When operating the unit, check for the following:
- Wear eye protection and appropriate clothing.
- Hold the front handle with one hand and the rear handle with
the other hand.
1. When trimming, the blade should be tilted towards the
hedge. Always trim from the bottom upwards.
2. Trim the sides of the hedge rst and then trim the top.
3. If the branches are very long, they should be cut back in
several stages.
4. Make sure that there are no hard objects in the hedge, such
as railings, that could damage the blade.
5. If the blade becomes jammed, switch it o and remove the
battery pack before clearing the obstruction.
6. Do not force the hedge trimmer to cut oversized branches.
These should be cut by hand using secateurs or shears.
Note: Evergreen hedges and shrubs that retain their leaves in
the winter, should be trimmed in April and August.
Conifers and other fast-growing shrubs can be trimmed every six
weeks throughout the growing season.
G
F

22 23
STORAGE AND TRANSPORT
1. After cleaning the unit thoroughly. Store the unit in a safe, dry
room, allowing the motor to cool down beforehand.
2. Store the machine out the reach of children.
3. Use the original packaging whenever possible.
MAINTENANCE AND STORAGE
WARNING!
Before performing any repair work, always remove
the battery pack.
CLEANING THE PRODUCT
- Use a soft brush to remove any accumulated dust.
- Wear safety glasses to protect your eyes whilst cleaning.
- Wipe down the product enclosure with a slightly damp cloth.
- Do not spray the unit with water. Ingress of water may
destroy the switch and the electric motor.
MAINTENANCE
1. Keep all nuts, bolts and screws tight to be sure that the
machine is in safe working condition.
2. Examine the machine and replace worn or damaged parts for
safety.
3. Check that the guards are undamaged and correctly tted.
Carry out necessary maintenance or repairs before using.
4. Do not use the unit if the blades are blunt or worn. This will
overstress the motor and gearbox of the machine.
BLADE MAINTENANCE
1. Wear gloves when handling or cleaning the cutting blade.
2. Always clean the cutting blade after operation and lubricate
with protective spray. During longer cutting jobs, we
recommend periodically lubricating the cutting blade with
protective spray.
3. Visually check the condition of the cutting edges of the
cutting blade. Check tightness of blade bolts. Ensure that the
blade is covered with the blade protection supplied.

24 25
TROUBLESHOOTING
Although your new cordless hedge trimmer is really easy to
operate, if you do experience problems, check the following:
Problem Possible cause Solution
Product does
not start 1. Not connected to battery pack 1. Connect to battery pack
2. Low battery
capacity 2. Charge the battery pack
3. Other defect to
the product 3. Check with a specialist
Product does
not reach full
power
1. Low battery
capacity 1. Charge the battery pack
2. Air vents are
blocked 2. Clean the air vents
Does not cut Cutting device
worn Have a specialist replace it
If a fault is suspected, return the trimmer to an authorised
service centre for repair.
TECHNICAL DATA
Model no. ASYEHT01450
Voltage 18V DC
Battery type Lithium-ion
No load speed 1400/min
Cutting length/tooth gap 405cm/14cm
Battery pack
Model ZDBP18012001
Battery type Lithium-ion
Battery capacity 2.0Ah
Charging time Approx. 4 hours
Charger
Model XH2200-0500wE
Rated voltage 100-240VAC 50-60Hz
Input voltage of charger 0.5A
Output voltage of charger 22V DC
Output current of charger 500mA
Protection category IP20
Noise and vibration data
A weighted sound pressure 78dB(A) KPA: 3dB(A)
A weighted sound power 90.3dB(A) KWA: 3dB(A)
The guaranteed sound power level: 96dB(A)
Wear ear protection (PPE).
Typical weighted vibration 1.9m/s2 K=1.5m/s2

26 27
WARNING!
The sound values have been determined according to
the noise test code given in EN50636-2-91, using the
basic standards EN ISO 11201 and EN ISO 3744.
The sound intensity level for the operator may exceed
80dB(A) and ear protection measures are necessary.
The declared vibration value (according to EN 786) has
been measured in accordance with a standard test
method, and may be used for comparing one product
with another. The declared vibration value may also be
used in a preliminary assessment of exposure.
Depending on the actual use of the product, the
vibration values can dier from the declared total!
Adopt proper measures to protect yourself against
vibration exposures! Take the whole work process into
consideration, including times the product is running
under no load or switched o!
Proper measures include, among others, regular
maintenance and care of the product and cutting
attachments, keeping hands warm, periodical breaks and
proper planning of work processes!
RECYCLING AND DISPOSAL
Waste electrical products should not be disposed with
household waste. Please recycle where facilities exist.
Check with your local authority or retailer for recycling advices.
GETTING HELP
Our dedicated UK-based customer helpline is open 7 days a
week to assist you with assembly, parts queries and technical
support. We are open during oce hours but you can always
send an email via [email protected]. Our
experts are here to get you back enjoying your garden in no
time.
For useful assembly, starting and maintenance videos, and for
ordering spares, please visit www.gardenservicecentre.co.uk
Calling our service does not aect your statutory rights.

28
WARRANTY
Any claim under this warranty must be made within 12 months
of the date of purchase. To make a claim under the warranty,
take the product (with proof of purchase) to your local store.
HHGL Limited bears reasonable, direct expenses of claiming
under the warranty.
You may submit details and proof to our store for consideration.
The warranty covers manufacturer defects in materials,
workmanship and nish under normal use.
This warranty is provided in addition to other rights and
remedies you may have under law: our goods come with
guarantees which cannot be excluded under the UK Consumer
Rights Act 2015.
You are entitled to a replacement or refund for a major failure,
and to compensation for other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
The warranty excludes damage resulting from product misuse
or product neglect. The warranty covers domestic use only and
does not apply to commercial applications.
This warranty is given by:
HHGL Limited, MK9 1BA
HHGL (ROI) Limited, D02 X576
