SPACEMAKER DSSCBW Instructions for use

Storage
Area
Exterior Dimensions
(Lid Edge to Lid Edge)
Interior Dimensions
(Wall to Wall)
Width Depth Height Width Depth Height
10 Sq. Ft. 22 Cu. Ft. 52” 27 3/16” 26 3/16” 50 1/2” 25” 24 11/16”
0,9 m20,6 m3132,1 cm 69,1 cm 66,5 cm 128,3 cm 63,5 cm 62,7 cm
UNIT DIMENSIONS
Gloves must be worn
at all times to reduce
risk of injury!
* See Inside for Detailed Safety Information.
Owner’s Manual
& Assembly Guide
719181214
Customer Service:
1-800-851-1085 or
[email protected]
www.arrowsheds.com
01V
Series Storage Chest
Model No. DSSCBW
DSSCBWDI
DSSCANBW
DSSCANBWDI
PATENT PENDING

2
BEFORE YOU BEGIN...
Safety precautions MUST be followed at all times throughout the construction of your Storage Unit!
•Care must be taken when handling various pieces of your Storage Unit since
many contain sharp edges. Please wear work gloves, eye protection and long
sleeves when assembling or performing any maintenance on your Storage
Unit.
•Practice caution with the tools being used in the assembly of your Storage
Unit. Be especially familiar with the operation of all power tools.
•Keep children and pets away from the worksite during construction. Do not
allow children to help with assembly.
•Do NOT attempt to assemble your Storage Unit on a windy day. The large
panels can catch the wind like a “sail”, causing them to be whipped around
making construction diffi cult and unsafe.
•We recommend two people work together to assemble your Storage Unit.
This will make assembly faster and easier.
02L
• Work Gloves
• Safety Glasses
• No. 2 Phillips Screwdriver (Magnetic Tip Preferred)
• Pliers
• Power Drill (Cordless, Variable Speed)
• Nut Driver or Wrench
• Awl (to help align holes)
WHAT YOU NEED
RECOMMENDED TIME SAVERS
Reading and following all steps carefully will help make assembly quicker and easier. Before you begin
assembly, be sure to confi rm that all the parts for your Storage Unit are present using the checklist on
pages 3 and 4. If parts are missing or damaged, include the model number of your Storage Unit and
contact Customer Service at 1-800-851-1085 or online at [email protected].
Below is a list of things you will need to assemble your Storage Unit.
NOT RECOMMENDED FOR STORAGE OF CORROSIVE CHEMICALS OR PRODUCTS

3
03V
AA
Confi rm that all hardware and parts are present before attempting to assemble
your Storage Unit.
Customer Service:
1-800-851-1085 or [email protected]
For missing or damaged parts contact Customer Service. Do not return to store.
HARDWARE LIST...
BB CC DD EE
FF GG HH II
JJ
Part
No. Part Description Qty.
List
AA M4*16 Cross recessed pan head screw 8
BB M4*12 Cross recessed pan head self-tapping screw 56
CC M4*12 Cross recessed countersunk head screw 9
DD M4*12 Cross recessed countersunk head screw (Black) 4
EE M4 Hex Nut 21
FF M4*8 Cross recessed pan head screw 8
GG Top Air Spring Pedestal 2
HH Bottom Air Spring Pedestal 2
II Feet M6 x 15 6
JJ Air Spring 2

6
PARTS LIST...
4
04V
ALid Panel 1
BFront Panel 1
CBack Panel 1
DLeft/Right Panel 2
EBottom Panel 1
FStrength Rib 5
GPlastic Handle 1
HCorner Support 8
Part
No.
Part
Description
Qty.
List
A B C
DE
F
G H

ASSEMBLY BY KEY NO.
5
05V
A
D
H
C
D
B
G
H
H
H
H
E
FF
FFF

6
Step 1
6
06V
You will need for this page:
Attach the Bottom Air Spring Pedestal to the Back Panel by using Screws
provided with Bottom Air Spring Pedestal.Push Bottom Air Spring Pedestal
downward and tighten Screws as shown in Figure A.
1
Put three (3) Hardware II on the bottom of Back Panel as shown in Figure C.
3
Attach four (4) Corner Supports to Back Panel using eight (8) Hardware BB as
shown in Figure B. DO NOT TIGHTEN SCREWS.
2
• Back Panel - C
(QTY:1)
• Bottom Air Spring Pedestal - HH
(QTY: 2)
• Corner Support - H
(QTY: 4)
(QTY: 3)
II
C
Fig. A
HH
Fig. C
II
(QTY: 8)
BB
Fig. B
H
BB
HH

7
07V
You will need for this page:
Step 2
• Front Panel - B
(QTY: 1)
• Plastic Handle - G
(QTY: 1)
• Corner Support - H
(QTY: 4)
(QTY: 4)
DD
(QTY: 4)
EE
Install the Plastic Handle on the Front Panel using four (4) Hardware DD and
four (4) Hardware EE as shown in Figure D.
1
B
Fig. D
G
EE
DD
Put three (3) Hardware II on the bottom of Front Panel as shown in Figure F.
3
Attach four (4) Corner Supports to Front Panel using eight (8) Hardware BB
as shown in Figure E. DO NOT TIGHTEN SCREWS.
2
Fig. E
H
BB
Fig. F
II
(QTY: 3)
II
(QTY: 8)
BB

8
08V
You will need for this page:
Step 3
Attach Top Air Spring Pedestal to Lid Panel using Screws provided
with Top Air Spring Pedestal as shown in Figure G.
• Lid Panel - A
(QTY: 1)
• Top Air Spring Pedestal - GG
(QTY: 2)
1
A
Fig. G
GG
GG

9
09V
You will need for this page:
Step 4
Assemble Front Panel Assembly,Back Panel Assembly, and fi ve (5) Strength Ribs together
using twenty (20) Hardware BB as shown in Figure H.
• Back Panel Assembly (Step 1)
• Front Panel Assembly (Step 2)
• Strength Ribs - F
(QTY: 5)
Fig. H
1
BC
F
F
F
F
F
FBB
(QTY: 20)
BB

10
10V
You will need for this page:
Step 5
• Bottom Panel - E
(QTY: 1)
Attach the Bottom Panel using twelve (12) Hardware BB as shown in Figure I.
1
C
B
E
Fig. I
BB
E
(QTY: 12)
BB

11
11V
You will need for this page:
Step 6
• Left/Right Panel - D
(QTY: 2)
Fig. J
Fig. K
Fig. L
(QTY: 8)
AA
1
Attach one (1) Left/Right Panel using four (4) Hardware FF and four (4) Hardware EE as
shown in Figure J.
Attach Left/Right Panel at Corner Support using four (4) Hardware AA as shown in Figure K.
2
Attach Left/Right Panels to Bottom Panel using four (4) Hardware BB as shown in Figure L.
Repeat for other Left/Right Panel.
3
EE
D
FF
AA
D
D
BB
C
B
E
D
D
(QTY: 8)
FF
(QTY: 8)
EE
(QTY: 8)
BB

12V
You will need for this page:
Step 7
Connect the Lid Panel Assembly to assembled box using nine (9) Hardware CC and nine (9)
Hardware EE as shown in Figure M.
• Lid Panel Assembly (Step 3)
• Air Spring - JJ
(QTY: 2)
Insert both ends of Air Spring into Top Air Spring Pedestal and Bottom Air Spring Pedestal.
Fig. M
12
(QTY: 9)
CC
1
2
JJ
CC
EE
C
B
A
D
D
(QTY: 9)
EE

CARE &MAINTENANCE...
Rust protection precautions may help to stop rust from developing, or stop it quickly as soon as it appears.
• Do not stand on lid.
• Avoid nicking or scraping the coating surface, inside and out.
• Keep storage unit free of debris and leaves which may accumulate and retain moisture. These can do
double damage since they give off acid as they decay.
• Touch up scrapes or nicks and any area of visible rust as soon as possible. Make sure the surface is
free of moisture, oils, dirt or grime and then apply an even fi lm of high quality touch-up paint.
• Various paint manufacturers provide products for rust treatment and coverage. If surface rust does
appear on your storage unit we recommend treating those areas as soon as possible, following the paint
supplier of your choice instructions.
• Exercise caution when moving fully loaded product. This is not intended for transporting heavy objects.
This product is recommended for stationary storage.
• Not intended for usage by children. This is not a toy box. To avoid risk of suffocation, do not allow
children to play inside container.
Fasteners:
Regularly check screws, bolts, nuts, etc., and retighten as necessary.
General:
• Silicone caulking may be used for watertight seals throughout the storage unit.
Keep these assembly instructions and owner’s manual for future reference.
Please note, Manufacturer cannot be held responsible for any consequences due to storage units that
are not installed per these instructions, or for damage due to weather conditions or acts of God.
