Spartan 727 User manual

PRODUCT MANUAL
Model 727
© 2018 Spartan Tool LLC
Part #72700000
Spartan Tool LLC |1506 West Division Street |Mendota, IL 61342
order by phone [phone] order online SpartanTool.com

2
WARNINGS ............................................................................................................4
TECHNICAL INFORMATION .............................................................................................5
TECHNICAL INFORMATION .............................................................................................6
DESCRIPTIONCOMPONENTS .........................................................................................7
NEW UNIT STARTUP ...................................................................................................8
Before Running Unit ............................................................................................................8
DAILY OPERATION .....................................................................................................9
Pre-Check ......................................................................................................................9
JETTING OPERATION & PROCEDURES ..................................................................................10
Starting ...................................................................................................................... 10
Stopping ..................................................................................................................... 10
General Procedures........................................................................................................... 10
Pulse Control ................................................................................................................. 11
Residue ...................................................................................................................... 11
Septic Tanks and Manhole Entrances .......................................................................................... 12
PRESSURE WASHING INSTRUCTIONS...................................................................................13
JETTING NOZZLES ....................................................................................................14
CARE & MAINTENANCE................................................................................................15
Engine ....................................................................................................................... 15
Pump ........................................................................................................................ 15
Battery ....................................................................................................................... 15
Freeze Protection ............................................................................................................. 15
Contents

3
TROUBLESHOOTING ..................................................................................................16
PARTS & ACCESSORIES ................................................................................................18
How to Use the Parts & Accessories Section.................................................................................... 18
Final Assembly (72700000).................................................................................................... 19
Frame Assembly (72704100) .................................................................................................. 22
Reel Assembly (72727700) .................................................................................................... 24
Pump Assembly (72726200)................................................................................................... 26
Pump—Exploded View ....................................................................................................... 28
Pump Torque Specifications................................................................................................... 30
Pump Repair Kits ............................................................................................................. 30
Plunger Packaging Kits (72726050) ............................................................................................ 30
Valve Assembly Kit (72726051) ................................................................................................ 30
Oil Seal Kit (72726052) ........................................................................................................ 30
Unloader (72726053)—Exploded View ........................................................................................ 31
Unloader Repair Kit (72726092) ............................................................................................... 33
Adapter Assembly, 3/8 to 1/4.................................................................................................. 33
Handgun Lance Nozzle Assembly (77799800).................................................................................. 33
Optional Accessories.......................................................................................................... 34
WARRANTY INFORMATION ............................................................................................35

4
Warnings
• Read the safety and operating instructions before using any Spartan Tool product. Drain and sewer cleaning can be dangerous if
proper procedures are not followed and appropriate safety gear is not utilized. Read the engine owners’manual for instructions and
safety precautions on engine operation.
• Gasoline is extremely flammable and is explosive under certain conditions.
• Refuel in a well ventilated area with the engine stopped. Do not smoke or allow flames or sparks in the area where the engine is
refueled or where gasoline is stored.
• Do not overfill the fuel tank (there should be no fuel in the filler neck). After refueling, make sure the tank cap is closed properly
and securely.
• Explosive fuel can cause fires and severe burns. Fuel is flammable and its vapors can ignite. Store fuel only in approved containers, in
well ventilated, unoccupied buildings. Do not fill the fuel tank while the engine is hot or running, since spilled fuel could ignite if it
comes in contact with hot parts or sparks from ignition. Do not start the engine near spilled fuel. Never use fuel as a cleaning agent.
• Before starting unit, be sure to wear personal protective equipment such as safety goggles or face shield and protective clothing
such as gloves, coveralls or raincoat, rubber boots with metatarsal guards, and hearing protection.
• Carbon monoxide exhaust and/or gasoline fumes from this equipment can create a hazardous atmosphere in confined spaces (which
may include, but are not limited to, manholes and septic tanks), closed garages or other areas which may not be properly ventilated.
In particular, excess gasoline fumes can create an explosion hazard. Such hazardous atmospheres can cause death or severe injury.
Do not operate this equipment with its cart (used to house the engine and gasoline tank) located in any confined space or area with
inadequate ventilation. Operate this equipment only when the cart is located outdoors or in an open, well-ventilated area.
• Ensure the jet hose has been placed in the pipe a minimum of 3 feet before engaging the water pressure to prevent the hose from
coming out of the pipe prematurely and causing injury.
• Always shut off the water pressure before pulling the hose out of the pipe. Mark the hose a minimum of 6 feet from the end to help
ensure the hose is not accidentally pulled out of the pipe while still under pressure. Shut off the water pressure when the hose mark
is encountered.
CAUTION: Portions of the system can still be under pressure even if the unit is not operating.
• Never point the wash gun at anyone while operating the unit. Injury may result.
• Drains and sewer can carry bacteria and other infectious micro-organisms or materials which can cause death or severe illness. Avoid
exposing eyes, nose, mouth, ears, hands, and cuts and abrasions to waste water or other potentially infectious materials during drain
and sewer cleaning operations. To further help protect against exposure to infectious materials, wash hands, arms and other areas
of the body, as needed, with hot, soapy water and, if necessary, flush mucous membranes with water. Also, disinfect potentially
contaminated equipment by washing such surfaces with a hot soapy wash using a strong detergent.
• For any questions, contact Spartan Tool at the address shown below.
CALIFORNIA PROP. 65
This product may contain an
extremely small amount of lead in the
coating. Lead is a material known to
the State of California to cause cancer
or reproductive toxicity.
CONTACT US
Spartan Tool LLC
1506 West Division Street
Mendota, IL 61342
800.435.3866
SpartanTool.com

5
Technical Information
GENERAL
Pipe Sizes Up to 6" diameter
Max water delivery 4.8 GPM
Max pressure delivery 3,000 PSI
Weight—power unit 166 lbs
Weight—reel with hose 54 lbs
Unit size 23"W x 35"L x 47"H
ENGINE
Horsepower 14 HP
Electric start Standard
Low oil alert system Standard
Cylinders 1
Bore & stroke 3.5 x 2.7
Full throttle RPM 3,200
Fuel Gasoline (1.85 gal capacity)
Oil SAE 10W30 (1.16 qt capacity)
Sparkplug Champion RC12YC
Cooling Air
Battery 12 VDC, 17.5 Amp hour, 310 CCA
Back-up starter Recoil
Choke Manual
PUMP
Pump Triplex plunger
Max pressure 3,000 PSI
Max water output 4.8 GPM
Max temperature 160°F
Max RPM 3,400
Plungers 3

6
Technical Information
FEATURES
2 wheel cart with 10" pneumatic tires and swivel—locking front casters
200 feet of high pressure ⁄" I.D. working hose
75 feet of high pressure ⁄" I.D. working hose
Nozzles: (¼ NPT) for ⁄" I.D. hose
• 72705100 thruster for distance
• 72705200 cleaning for penetration
• JH-SPNR1 nozzle - spinner (⁄ NPT) for ⁄" I.D. hose
• 72705400 thruster for distance (⁄ NPT)
• 72705500 cleaning for penetration (⁄ NPT)
Pulsation feature for improved hose feeding and retrieval
Thermal dump feature controls heat buil-up during extended periods of
operation with no high pressure flow
Detachable dual-action hose reel
0 to 5,000 PSI pressure gauge provided
Wash wand with detachable trigger gun
Tip cleaner
Gloves

7
BEFORE RUNNING UNIT
Locate the small cardboard box packed with the following materials:
• (1) Spartan 727 Product Manual
• (1) Engine Owners Manual
• (1) ⁄" to ¼" quick disconnect adapter
• (1) Sparkplug wrench
• (1) Nozzle cleaner
Packaged separately:
• (1) Trigger wash wand
• (1) 75' x ⁄" I.D. jetting hose with nozzle
New Unit Start-Up
Locate the battery. There are two battery terminals. One is connected. One is not. Loosen the nut on the disconnected terminal with a
wrench. Connect the loose cable to the terminal between the nut and the "U" shaped bracket on the battery. Tighten securely (20 to 40
in-lbs).
NOTE If any of the above items are missing, contact Spartan Tool Customer Service at
800.435.3866 or by email at [e-mail].

8
Daily Operation
PRE-CHECK
1. Check engine oil (SAE 10W30) by reading the dipstick. (Refer to engine owners manual.)
2. Check pump oil (use only Giant Synthetic or a 15W-50 synthetic motor oil).
3. Check engine fuel. Fill as necessary. Remove the rear hose reel retaining pins to allow the hose reel to be tilted forward for access to
the engine fuel tank.
4. Check pump inlet line strainer for cleanliness before each use. Never run a unit without a strainer.
5. Check the jetting nozzle for possible plugged jet holes using visual inspection and the nozzle cleaning tool. If plugged, use the
nozzle cleaner to carefully clear the obstruction (and then rinse).
• CAUTION: DO NOT ENLARGE THE JET HOLES OF THE NOZZLE. Operating the jetter with jetting nozzle holes plugged OR
enlarged will interfere with the performance of the machine.
6. Use a good-quality ⁄" or larger garden hose connected to an adequate water supply. Connect hose to hot or cold water faucet.
• To check for a required minimum 4 GPM water supply, open water spigot valve and time water flow through the garden hose
and into a one-gallon container. If the container fills in 15 seconds or less, the water supply has adequate flow to supply the
jetter.
• Insufficient water supply will cause pump to cavitate.
PRE-CHECK
1. Attach the garden hose from a water supply to the jetter.
• If a hot water supply is used, do not allow water temperature to exceed 140°F, that is thermo-dump valve setting.
2. Attach jetter hose to the unit (do not attach the jetting nozzle at this time).
3. Prime the system by turning the supply hose valve on, turning the pump inlet valve on, and turning the jetter hose reel control
valve on. Allow the water to flow until the air is purged from the system.
4. Turn jetter hose reel control valve o.
5. Attach selected jetting nozzle to the hose finger tight.
6. Mark a location on hose 3 feet from the jetting nozzle end with a band of tape. Use that mark to determine when jetting nozzle is
near access hole.
• Avoid injury from unconfined jetting nozzles. Place the hose and nozzle at least 3 feet into the line to be cleaned before starting
the engine.
• Turn the hose reel valve on (valve must be on for engine to start).
7. Turn the engine fuel valve on. Start the engine at a reduced (about ¼) throttle setting. Allow 1 to 2 minutes for the engine to warm
up, then fully open the throttle.
• NOTE: Only operate the Model 727 in the upright position. Never allow the unit to be laid on its back or on its side. Damage to
the engine will result.
8. You are now ready to start jetting.

9
STARTING
Before starting unit, be sure to wear personal protective equipment, such as safety goggles or face shield, and protective clothing such
as gloves, coveralls or raincoat, rubber boots with metatarsal guards, and hearing protection.
1. Keep jetting hose at least 3 feet into pipe line access hole. Do not remove hose from line at any time while under power.
2. Adjust regulator control knob to 3,000 PSI.
• WARNING: Do not exceed 3,00 PSI. Injury or machine damage may result. Control hose water pressure and flow at the hose
reel valve. Open and close the valve slowly for smooth engine response.
• Never run the machine with the hose reel valve in the closed position for more than 1 to 2 minutes. Extended shut-off causes the
water recycled in the pump to overheat, which will cause the thermal valve to open and vent hot water.
3. Begin jetting.
STOPPING
1. Shut down the engine by reducing to ¼ throttle before turning the ignition o.
2. Shut o the water supply. Disconnect hoses.
GENERAL PROCEDURES
• Jetting hose selection is determined by the size of the line to be cleaned.
• Use the ⁄" I.D. hose directly from the hose reel for large lines and distances.
• Use the smaller ⁄" I.D. hose (provided separately) for smaller jobs requiring jetting through traps.
• Use of the smaller ⁄" jetting hose should be made directly from the pump quick disconnect fitting (using the provided ⁄" to ¼"
adapter) for the best results. For jobs located at distance from the jetting machine, use the trigger wash wand at the end of the ⁄"
I.D. hose for flow control and attach the ⁄" I.D. hose to the wash wand.
• Jetting nozzle selection is made according to the size of the hose used and the type of jetting to be done. See the jetting nozzle
descriptions for best applications.
• If possible, jetting to the approximate far end of the build-up. Pull the jetter hose back at a slow rate (down to about 1 ft/min for
heavy drainline accumulation), allowing enough time for the jetting nozzle to wash the pipe clean.
• For best results, jet from the lower end of the line to be cleaned. Provision may hae to be made to catch accumulation of water during
jetting operation.
• Hold the jetter hose, release the locking "L" pin on the reel and allow the hose to feed itself into the line to be cleaned. Pushing on the
hose to aid in feeding may be required through traps, blockages, and long distances.
• When jetting a drain line through a trap, you may have to help the jetter hose feed through the trap by grasping it near the entrance
of the drain and jabbing the jetting nozzle through the trap with a quick thrusting motion.
• When jetting from the high end of the line, turn the jetter jose reel valve off occasionally to allow water accumulation to drain past
the jetting nozzle.
Jetting Operation & Procedures

10
Jetting Operation & Procedures
• When obstruction or corners are encountered, it may be
necessary to manually rotate the hose (Fig. 1) to enable the
hose to feed through the area. This will cause the jetting
nozzle to jump over or around those areas. If it becomes
necessary to manually rotate the hose to clear obstructions,
any rotations in one direction must be followed by an equal
number in the opposite direction to prevent kinks from
building in the hose.
• It may also be necessary to move the hose slightly in and
out of the drain line to assist the jetting nozzle in cleaning
stubborn clogs, obstructions, or tight corners (Fig. 2).
PULSE CONTROL
• The Model 727 comes equipped with a pulsator. The purpose of the pulsation is to assist in moving the water jet hose through
the pipe. The pulsator unit operates by creating a vibrating or pulsing action on the hose using pressurized water. The pulsing or
vibration action reduces hose drag in a pipe by reducing surface contact of the hose on the pipe and with the assistance of the water
jet nozzle, causes the hose to propel itself into a pipe much farther and faster.
• To engage the pulsator, turn the control knob clockwise (right) all the way to the built-in stop. The vibrating or pulsing action
will start instantly and the hose will move into the pipe. A slight drop in pressure will be noted on the pressure gauge when the
pulsation is engaged. When retrieving the hose from the pipe, pulsating action is not required and by turning the control knob
counterclockwise (left) all the way to the stop, the unit is returned to standard jetting.
• NOTE: Pulsation control knob must be completely turned in or out to avoid excessive wear on pump and pulsation unit.
Excessive use of the pulsator will lead to quicker wear of the jetting hose.
RESIDUE
• Most drain line residue is precipitated (a solid is formed when it falls out of water suspension and collects on drain pipe walls). A
3,000 PSI water blast from the jetter can very quickly wash these drain lines clean.
• Many lines have a deep layer of hard soap and lime residue bonded to the drain pipe wall. In some of these cases you will encounter
a very slow jetting speed because you are cutting through this hard soap. As an aid to gauging the travel of the jetting hose, mark the
hose at intervals with tape or other markers.
• To clear soap residue, use the cleaning jet nozzles with hot tap water (140°F max). Jet to the far end of the soap residue (jetting can
be very slow, down to 6" per minute). Pull the jet hose out very slowly to allow time for water jets to cut through the soap cake. At
times, you will wash large tubular sections of soap downstream.
• WARNING: Hot water can cause severe burns. Wear a face shield, gloves, and a raincoat when using water at high
temperatures.
FIG. 1 FIG. 2

11
Jetting Operation & Procedures
FIG. 3
SEPTIC TANKS AND MANHOLE
ENTRANCES
• Use a section of 1½" or 2" PVC pipe with a 45° fitting attached
to the end to aid in feeding the jetter hose into a drain line in a
septic tank or manhole (Fig. 3).
• Use caution when entering a confined space! Follow
OSHA guidelines. Dangerous gases in these areas may
be lethal!
• Attach the handgun and lance with quick disconnect fitting to the ⁄" jetting hose for pressure washing applications. Refer to jetting
start-up procedures.
• Adjust the Vari-Nozzle at the end of the lance to achieve the best spray pattern for the pressure wash job being done.
WARNING: Avoid running the machine with the handgun in the closed position for more than 1 minute.
Extended shut-off causes the water recycled in the pump to overheat, which will cause the thermal valve to
open and vent hot water.
Pressure Washing Instructions

12
Jetting Nozzles
The following nozzles are provided in sizes to fit both the ⁄" I.D. (¼ NPT) hose and ⁄" I.D. (⁄ NPT) hose, except for the rotating nozzle,
which is only provided to fit the ⁄" I.D. hose.
THRUSTER JETTING NOZZLES—FOR DISTANCE
These nozzles have four jets in reverse at a low angle
for maximum thrust
OPEN JETTING NOZZLES—FOR PENETRATION
These nozzles have four jets in reverse at a low angle,
plus one forward penetrating jet. These penetrating
jetting nozzles are used to jet through grease, ice, or
other residue.
ROTATING JETTING NOZZLE
This nozzle is used to clean the wall of the sewer line
after the line has been unclogged.

13
Care & Maintenance
ENGINE
• Oil—SAE 10W30 (1.16 qt capacity)
• Check engine oil with every usage. Make the first engine oil change after (1) month or 20 hours of operation and every (6)
months or 100 hours of operation thereafter.
• Air Cleaner—Dual element type
• Check air cleaner with every usage. Clean every (3) months or 50 hours of operation.
• Sediment Cup
• Check every (6) months or 100 hours of operation.
• Spark Plug—Champion RC12YC
• Check every (6) months or 100 hours of operation.
• Replace every year or 300 hours of operation.
PUMP
• Oil—Giant synthetic or a 15W-50 synthetic motor oil (Capacity: 21 fl oz)
• Change oil after the first 50 hours of operation, then at regular intervals of 500 hours or less, depending on operating conditions.
• Inlet strainer
• Check inlet strainer before every usage to ensure that it is not blocked. Take care to ensure that no dirt or particles are allowed to
enter the pump system.
BATTERY
• 12V DC, 17.5 Amp Hour—310 CCA
• Maintenance-free battery. See battery for warnings.
FREEZE PROTECTION
Cold Weather Protection: To avoid damage to the pump and water jet hose, keep the Model 727 from freezing temperatures. If the
Model 727 must be stored in freezing temperatures, you must use one of the following methods:
• Method 1: Use pressurized air to blow out any remaining water left inside pump and hose by using the air blow-out feature
(located next to the pressure gauge).
• Method 2: Attach a short garden hose (not to exceed 4 feet) to the pump inlet valve and put the other end of the garden hose
into a mixture of 50% antifreeze and 50% water. Cycle antifreeze mixture through the system. When antifreeze flows from the
outlet, the system is protected.
WARNING: Do not exceed 3,000 PSI. Injury or machine damage may result.
WARNING: The battery contains sulfuric acid (electrolyte). Contact with skin or eyes may cause severe burns. Wear
protective clothing and a face shield.

14
PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION
Low pressure or ow.
Clogged inlet filter or improper size. Clean. Use adequate size.
Check more frequently.
Inadequate water supply. Check flow available to pump.
Worn nozzle. Replace nozzle of proper size.
Leaky discharge hose. Repair or replace.
Pressure gauge inoperative or not
registering accurately.
Check with new gauge. Replace worn or
damaged gauge.
Air leak in inlet plumbing. Disassemble, reseal, and reassemble.
Worn packing seals. Replace packing seals.
Fouled or dirty inlet or discharge valves. Clean inlet and discharge valve
assemblies.
Worn or plugged relief valve on pump. Clean, reset, and replace.
Cavitation. Check suction lines on inlet of pump for
restrictions.
Unloader. Check for proper operation.
Pump not fully primed.
Remove jetter hose at outlet. Turn pump
inlet valve on. Run pump until fully
primed.
Low engine RPM. Check full throttle speed (adjust to 3,200
RPM).
Rough/pulsating operation with
pressure drop.
Pump not fully primed.
Remove jetter hose at outlet. Turn pump
inlet valve on. Run pump until fully
primed.
Worn packing. Replace packing.
Inlet restriction. Check system for stoppage, air leaks, and
correctly sized inlet plumbing.
Cavitation. Check inlet lines for restrictions and/or
proper size.
Water in crankcase.
High humidity. Reduce oil change interval.
Leakage of crankcase or seals installed
backwards. Replace packing.
Worn seals. Replace seals.
Noisy operation.
Pump not fully primed.
Remove jetter hose at outlet. Turn pump
inlet valve on. Run pump until fully
primed.
Worn bearings. Replace bearings. Refill crankcase with
recommended lubricant.
Cavitation. Check inlet lines for restrictions and/or
proper size.
Coupler loose on crankshaft. Check and tighten set screws.
Troubleshooting

15
PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION
Frequent or premature failure of the
packing.
Damaged or worn plungers. Replace plungers.
Abrasive material in fluid being pumped. Install proper filtration on pump inlet
plumbing.
Excessive pressure and/or temperature of
fluid being pumped.
Check pressures and fluid inlet
temperature. Be sure they are within the
specified range.
Over pressure of pumps. Reduce pressure.
Running pump dry. Do not run with inadequate water supply.
Excessive leakage.
Worn or cracked plungers. Replace plungers.
Worn packing/seals. Adjust or replace packing seals.
Excessive vacuum. Reduce suction vacuum.
Inlet pressure too high. Reduce inlet pressure.
Troubleshooting

16
HOW TO USE THE PARTS & ACCESSORIES SECTION
Spartan Tool will supply all parts or accessories you require as quickly as possible. In order to do so, we must have information from you,
including machine serial number and part numbers.
Please record the serial number of your machine in the space provided below:
Parts & Accessories
SPARTAN MODEL 727
Unit Serial Number
To order parts, look through the pictures until you find the part you require or an
indication of where the part should be. Using the item number from the picture, go to
that number on the adjacent page and check the description to determine if it is the part
you desire.
Using the part numbers, please contact your Spartan Territory Manager or Spartan Tool
directly at www.SpartanTool.com.
CONTACT US
Spartan Tool LLC
1506 West Division Street
Mendota, IL 61342
800.435.3866
SpartanTool.com
Part Number Description Qty.
JH-SPNR1 Revolving Nozzle 1
72705500 ⁄" Cleaning Nozzle 1
72705400 ⁄" Thruster Nozzle 1
72705200 ⁄" Cleaning Nozzle 1
72705100 ⁄" Thruster Nozzle 1
H3/16-75 ⁄" I.D. x 75' Hose Assembly (orange) 1
72711300 ⁄" x ¼" Adapter Assembly 1
71109900 Tip Cleaner 1
5G243631 Safety Gloves—full length 1
77799800 Handgun Lance w/Nozzle Assembly 1
77721400 Coupler, Quick Gun Male 1
542104-03 Bushing Red ⁄m x ¼f St. 1
77721400 Coupler, Quick Gun—Male 1

17
Model 727 Final Assembly
FINAL ASSEMBLY (72700000)
NOZZLE, ROTATING 1/4"
JH-SPNR1136
CLAMP, DRUM CABLE64050080
1
35
WASHER, FLAT 3/16 SAE
01588200134
HEX HEAD S.S. SCREW, M8-1.25X25MM79873400
133
NUT, NYLON LOCKING 1/4-2073821200232
ENGINE, 14 HP KOHLER72708400131
STRAP, 310 CCA BATTERY72708520
1
30
BATTERY, 310 CCA72708500129
BOX, 310 CCA BATTERY72708510
1
28
CARTON, MODEL 72772710100
1
27
NOZZLE ORIFICE CLEANER71109900126
GLOVES, 12" FULL LENGTH (PAIR)5G243631
1
25
CARTON, MAGNUM CABLE 50'
44042300124
SCREW, HX HD CAP - 1/4-20 X 2''79920154223
NEGATIVE BATTERY CABLE72706600122
POSITIVE BATTERY CABLE72706500121
NUT, STOVER LOCK 3/8-16 UNC77748000
4
20
COUPLER, 1/4" QUICK MALE FNPT
77721400119
ASSY, ADAPTER 3/8 TO 1/472711300
1
18
DECAL, HOT EXHAUST PIPE72709500117
NOZZLE, OPEN FOR 3/16" HOSE
72705500116
NOZZLE, CLOSED FOR 3/16" HOSE72705400
115
NOZZLE, OPEN FOR 9/16" HOSE
72705200
114
NOZZLE, CLOSED FOR 9/16" HOSE72705100
1
13
BUSHING RED 3/8M X 1/4F STL
542104-03112
WASHER,FLAT 1/4 USS
00763301411
WASHER, LOCK SPLIT 3/800165800
4
10
SCREW CAP HEX HD 3/8-16X1-3/4
0011690089
WASHER, FLAT 5/16 USS00162600128
HOSE, 9/16" X 200' RED
727067001
7
HOSE, 1/4" X 75' GREEN
7112900316
ASSY, PUMP72726200
15
PIN, SAFETY SNAP (SQUARED)
7271110024
ASSY, HP REEL72727700
1
3
SPRAYGUN ASSEMBLY7779980012
ASSY, FRAME 7277270410011
DESCRIPTION
PART NUMBER
QTY
ITEM
SPARTAN TOOL
MENDOTA, IL 61342
DATE
SIZE SCALE
DRAWN BY ECO
DRAWING NUMBER
SHEET NUMBER
REV
TITLE
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES
WARNING: THIS DRAWING IS
GENERATED FROM 3D BODY DATA
AND ANY GEOMETRY CHANGES
SHOULD BE CARRIED OUT
IN 3D ONLY.
THIS DOCUMENT CONTANINS
PROPRIETARY INFORMATION AND
SUCH INFORMATION MAY NOT BE
DISCLOSED TO OTHERS FOR ANY
PURPOSE NOR USED FOR
MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION
FROM SPARTAN TOOL L.L.C.
727 MINI-JET
5-13-13 RW 7988 2 OF 2
H
72700000
1=4
D
.XX = .03 .XXX = .005
FRACTIONS = 1/64
ANGLES = 1~



1
2
3
4
5
6
31
30
28
29
19
18
12

18
Model 727 Final Assembly
NOZZLE, ROTATING 1/4"
JH-SPNR1136
CLAMP, DRUM CABLE64050080
1
35
WASHER, FLAT 3/16 SAE
01588200134
HEX HEAD S.S. SCREW, M8-1.25X25MM79873400
1
33
NUT, NYLON LOCKING 1/4-20
73821200232
ENGINE, 14 HP KOHLER72708400131
STRAP, 310 CCA BATTERY72708520
1
30
BATTERY, 310 CCA72708500129
BOX, 310 CCA BATTERY72708510
1
28
CARTON, MODEL 72772710100127
NOZZLE ORIFICE CLEANER71109900126
GLOVES, 12" FULL LENGTH (PAIR)5G243631
1
25
CARTON, MAGNUM CABLE 50'
44042300124
SCREW, HX HD CAP - 1/4-20 X 2''79920154223
SPRAYGUN ASSEMBLY7779980012
NUT, STOVER LOCK 3/8-16 UNC
77748000420
COUPLER, 1/4" QUICK MALE FNPT77721400
1
19
ASSY, HP REEL7272770013
ASSY, PUMP72726200
15
ASSY, ADAPTER 3/8 TO 1/4
72711300118
PIN, SAFETY SNAP (SQUARED)
7271110024
DECAL, HOT EXHAUST PIPE72709500
117
HOSE, 9/16" X 200' RED
7270670017
NEGATIVE BATTERY CABLE72706600
1
22
POSITIVE BATTERY CABLE72706500121
NOZZLE, OPEN FOR 3/16" HOSE
72705500116
NOZZLE, CLOSED FOR 3/16" HOSE72705400
115
NOZZLE, OPEN FOR 9/16" HOSE
72705200114
NOZZLE, CLOSED FOR 9/16" HOSE72705100
1
13
ASSY, FRAME 7277270410011
HOSE, 1/4" X 75' GREEN
7112900316
BUSHING RED 3/8M X 1/4F STL542104-03
1
12
WASHER,FLAT 1/4 USS
00763301411
WASHER, LOCK SPLIT 3/800165800
4
10
WASHER, FLAT 5/16 USS
00162600128
SCREW CAP HEX HD 3/8-16X1-3/4
0011690089
DESCRIPTION
PART NUMBER
QTY
ITEM
SPARTAN TOOL
MENDOTA, IL 61342
DATE
SIZE SCALE
DRAWN BY ECO
DRAWING NUMBER
SHEET NUMBER
REV
TITLE
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES
WARNING: THIS DRAWING IS
GENERATED FROM 3D BODY DATA
AND ANY GEOMETRY CHANGES
SHOULD BE CARRIED OUT
IN 3D ONLY.
THIS DOCUMENT CONTANINS
PROPRIETARY INFORMATION AND
SUCH INFORMATION MAY NOT BE
DISCLOSED TO OTHERS FOR ANY
PURPOSE NOR USED FOR
MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION
FROM SPARTAN TOOL L.L.C.
727 MINI-JET
5-13-13 RW 7988 1 OF 2
H
72700000
1=4
D
.XX = .03 .XXX = .005
FRACTIONS = 1/64
ANGLES = 1~



REVISION HISTORY
REV DATE ECO DESCRIPTION APPROVED
A4/23/1996 7014 ADD ITEM 46 (72709500)
B8/25/1997 7118 REMOVE ITEM 39 (72750000) NOZZLE REVOLVING BF
C5/7/1998 7179 ADD ITEM 47 (72720000) AT
D5/15/2001 7356
REPLACE ITEMS 6 (72704300) & 13 (72707200) CHG QTY OF
ITEMS 17 (WAS 4) & 23 (WAS 8); REMOVE 71110400 &
72720000; ADD 00165800
JEK
E6/25/2002 7470 REMOVE 71136800, 72705300 & 72705600; ADD 538002-01 JEK
F12/04/2006 7670 REPLACE 72706600 WITH 77799800;ADD 542104-03; DELETE:
ITEMS 19-22 NRV
G5/15/2013 7988 REDRAWN; RENUMBERED; REPLACE 72704200 WITH
72727700 RW
H1/31/2019 8451 ENGINE AND BATTERY CHANGE JPB
TEST INSTRUCTIONS:
1. CHECK THAT ALL FASTENERS ARE TIGHTEND, ENGINE OIL & PUMP OIL ARE FILLED
2. CHECK THAT BATTERY IS FILLED & CHARGED, CONNECT ENGINE LEADS.
3. SET-UP -CONNECT PORTABLE FUEL SUPPLY TO ENGINE,
-CONNECT WATER SUPPLY TO INLET & TEST GAGE WITH
50 FT LENGTH OF 5/16 ID 4000 PSI HOSE WITH OPEN
NOZZLE FROM JETTER TO OUTLET. TURN INLET WATER ON
PURGE AIR FROM PUMP AND HOSE.
-START ENGINE AND ALLOW TO WARM TO OPERATING
TEMPERATURE (3-5 MINUTES)
4. ADJUST -AT FULL THROTTLE ADJUST REGULATOR FOR A PUMP GAGE
INDICATION OF 3000 +50/ -0 PSI
-ADJUST THROTTLE STOP FOR AN ENGINE RPM OF 3200 +/- 50.
5. TEST -RUN IN SYSTEM AT PRESSURE AND FLOW FOR 300 MINUTES.
-TURN PULSATOR ON (10 MINUTES)
-CHECK ENGINE RPM FOR 3200 +/- 50
-CHECK PUMP GAGE PRESSURE FOR 3000 +50/ -0 PSI
-CHECK TESTER GAGE PRESSURE FOR 3000 +/- 50 PSI
-CHECK FOR LEAKS IN SYSTEM
-TURN OUTLET FLOW OFF
PUMP GAGE PRESSURE <200 PSI
3200 < ENGINE RPM < 3500
(TURN OUTLET FLOW ON WHEN FINISHED)
-TURN ENGINE RUN SWITCH TO OFF, ENGINE STOPS
-RESTART ENGINE, ENGINE STARTS OK
-TURN CHOKE ON, CHECK FOR CHOKING ACTION
6. WINTERIZE UNIT VY CIRCULATING 50/50 SOLUTION OF WATER AND GLYCOL
THROUGH PUMP, OPEN PULSATOR VALVE WHEN WINTERIZING.
NOTES: 1) STAMP S/N ON ITEM 26. DRILL (2) 1/8 DIA HOLES & MOUNT APPROX AS SHOWN USING (2) 44038500\
2) REMOVE (1) WHEEL & MOUNT ENGINE AS SHOWN, REASSEMBLE WHEEL IN PLACE
3) LUBRICATE ENGINE SHAFT WITH ANTISEIZE (71122800) PLACE 1/4 X 1/4 X 2-5/32 KEY INTO
ENGINE SHAFT. SLIDE COUPLER ONTO SHAFT & TIGHTEN SET-SCDREW. ATTACHE PUMP BY SLIDING PUMP
CRANKSHAFT INSIDE COUPLER.
4) ASSEMBLE PUMP TO ENGINE USING (4) 00116900.
5) TIGHTEN SET-SCREW ON PUMP SHAFT BY ACCESSING THRU HOLE IN PUMP FLANGE.
6) FILL & CHARGE PER INCLUDED BATTERY INSTRUCTIONS.
7) ADD OIL (72710200) TO PROPER LEVEL IN ENGINE
8) CHECK OIL IN PUMP AND ADD IF NECESSARY. USE GIANT SYNTHETIC CRANKCASE OIL.
9) DO NOT ADD FUEL TO ENGINE FUEL TANK.
10) SLIDE CLEAR TUBE OF REEL ASSY OVER FEMALE END OF HOSE (72706700). CONNECT FEMALE
FITTING OF HOSE TO SWIVEL ASSEMBLY IN REEL. SLIDE CLEAR TUBE BACK TOWARDS SWIVEL
TO COVER HOSE CONNECTION. TIGHTLY WRAP HOSE TO REEL & SECURE WITH NYLON TIE (72711500)
11) ASSEMBLE THRUSTER NOZZLE (72705400) TO END OF 3/16 ID HOSE (71129103)
12) TEST PER INSTRUCTIONS. AFTER TESTING, REMOVE POSITIVE BATTERY LEAD FROM BATTERY.
REPLACE TERMINAL SCREW TO BATTERY. WRAP ON LAYER OF PLASTIC ELECTRICAL TAPE OVER
CONTACT AREA OF POSITIVE LEAD.
13) PACKAGING INSTRUCTIONS:
A. SECURE JETTER UNIT TO PALLET THROUGH CARTON (72710100) END USING SPACER BLOCK.
B. SHRINK WRAP UNIT.
C. INCLUDE FOLLOWING ITEM IN CARTON (44042300). PLACE CARTON IN MAIN CARTON.
GLOVES 5G243631; 75 FT HOSE 71129103; OWNERS MANUAL; TIP CLEANER 71109900;
ADAPTER ASSEMBLY 72711300; ENGINE EXHAUST DEFLECTOR; SPARKPLUG WRENCH &
ENGINE OWNERS MANUAL- (INCLUDED IN 72703200)
D. BUBBLE WRAP SPRAYGUN ASSEMBY 77799800 & PLACE IN UNIT CARTON
E. STAPLE CARTON ENDS & BAND TO PALLET.
14. SPRAY GUN 77799800 TO BE ASSEMBLED WITH BUSHING 542104-03 USING TEFLON TAPE BEFORE PACKAGING FOR SHIPMENT.
11
23 32
9
10
8
NOZZLE, ROTATING 1/4"
JH-SPNR1136
CLAMP, DRUM CABLE64050080
1
35
WASHER, FLAT 3/16 SAE
01588200134
HEX HEAD S.S. SCREW, M8-1.25X25MM79873400
1
33
NUT, NYLON LOCKING 1/4-20
73821200232
ENGINE, 14 HP KOHLER72708400131
STRAP, 310 CCA BATTERY72708520
1
30
BATTERY, 310 CCA72708500129
BOX, 310 CCA BATTERY72708510
1
28
CARTON, MODEL 72772710100127
NOZZLE ORIFICE CLEANER71109900126
GLOVES, 12" FULL LENGTH (PAIR)5G243631
1
25
CARTON, MAGNUM CABLE 50'
44042300124
SCREW, HX HD CAP - 1/4-20 X 2''79920154223
SPRAYGUN ASSEMBLY7779980012
NUT, STOVER LOCK 3/8-16 UNC
77748000420
COUPLER, 1/4" QUICK MALE FNPT77721400
1
19
ASSY, HP REEL7272770013
ASSY, PUMP72726200
15
ASSY, ADAPTER 3/8 TO 1/4
72711300118
PIN, SAFETY SNAP (SQUARED)
7271110024
DECAL, HOT EXHAUST PIPE72709500
117
HOSE, 9/16" X 200' RED
7270670017
NEGATIVE BATTERY CABLE72706600
1
22
POSITIVE BATTERY CABLE72706500121
NOZZLE, OPEN FOR 3/16" HOSE
72705500116
NOZZLE, CLOSED FOR 3/16" HOSE72705400
115
NOZZLE, OPEN FOR 9/16" HOSE
72705200114
NOZZLE, CLOSED FOR 9/16" HOSE72705100
1
13
ASSY, FRAME 7277270410011
HOSE, 1/4" X 75' GREEN
7112900316
BUSHING RED 3/8M X 1/4F STL542104-03
1
12
WASHER,FLAT 1/4 USS
00763301411
WASHER, LOCK SPLIT 3/800165800
4
10
WASHER, FLAT 5/16 USS
00162600128
SCREW CAP HEX HD 3/8-16X1-3/4
0011690089
DESCRIPTION
PART NUMBER
QTY
ITEM
SPARTAN TOOL
MENDOTA, IL 61342
DATE
SIZE SCALE
DRAWN BY ECO
DRAWING NUMBER
SHEET NUMBER
REV
TITLE
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES
WARNING: THIS DRAWING IS
GENERATED FROM 3D BODY DATA
AND ANY GEOMETRY CHANGES
SHOULD BE CARRIED OUT
IN 3D ONLY.
THIS DOCUMENT CONTANINS
PROPRIETARY INFORMATION AND
SUCH INFORMATION MAY NOT BE
DISCLOSED TO OTHERS FOR ANY
PURPOSE NOR USED FOR
MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION
FROM SPARTAN TOOL L.L.C.
727 MINI-JET
5-13-13 RW 7988 1 OF 2
H
72700000
1=4
D
.XX = .03 .XXX = .005
FRACTIONS = 1/64
ANGLES = 1~



REVISION HISTORY
REV DATE ECO DESCRIPTION APPROVED
A4/23/1996 7014 ADD ITEM 46 (72709500)
B8/25/1997 7118 REMOVE ITEM 39 (72750000) NOZZLE REVOLVING BF
C5/7/1998 7179 ADD ITEM 47 (72720000) AT
D5/15/2001 7356
REPLACE ITEMS 6 (72704300) & 13 (72707200) CHG QTY OF
ITEMS 17 (WAS 4) & 23 (WAS 8); REMOVE 71110400 &
72720000; ADD 00165800
JEK
E6/25/2002 7470 REMOVE 71136800, 72705300 & 72705600; ADD 538002-01 JEK
F12/04/2006 7670 REPLACE 72706600 WITH 77799800;ADD 542104-03; DELETE:
ITEMS 19-22 NRV
G5/15/2013 7988 REDRAWN; RENUMBERED; REPLACE 72704200 WITH
72727700 RW
H1/31/2019 8451 ENGINE AND BATTERY CHANGE JPB
TEST INSTRUCTIONS:
1. CHECK THAT ALL FASTENERS ARE TIGHTEND, ENGINE OIL & PUMP OIL ARE FILLED
2. CHECK THAT BATTERY IS FILLED & CHARGED, CONNECT ENGINE LEADS.
3. SET-UP -CONNECT PORTABLE FUEL SUPPLY TO ENGINE,
-CONNECT WATER SUPPLY TO INLET & TEST GAGE WITH
50 FT LENGTH OF 5/16 ID 4000 PSI HOSE WITH OPEN
NOZZLE FROM JETTER TO OUTLET. TURN INLET WATER ON
PURGE AIR FROM PUMP AND HOSE.
-START ENGINE AND ALLOW TO WARM TO OPERATING
TEMPERATURE (3-5 MINUTES)
4. ADJUST -AT FULL THROTTLE ADJUST REGULATOR FOR A PUMP GAGE
INDICATION OF 3000 +50/ -0 PSI
-ADJUST THROTTLE STOP FOR AN ENGINE RPM OF 3200 +/- 50.
5. TEST -RUN IN SYSTEM AT PRESSURE AND FLOW FOR 300 MINUTES.
-TURN PULSATOR ON (10 MINUTES)
-CHECK ENGINE RPM FOR 3200 +/- 50
-CHECK PUMP GAGE PRESSURE FOR 3000 +50/ -0 PSI
-CHECK TESTER GAGE PRESSURE FOR 3000 +/- 50 PSI
-CHECK FOR LEAKS IN SYSTEM
-TURN OUTLET FLOW OFF
PUMP GAGE PRESSURE <200 PSI
3200 < ENGINE RPM < 3500
(TURN OUTLET FLOW ON WHEN FINISHED)
-TURN ENGINE RUN SWITCH TO OFF, ENGINE STOPS
-RESTART ENGINE, ENGINE STARTS OK
-TURN CHOKE ON, CHECK FOR CHOKING ACTION
6. WINTERIZE UNIT VY CIRCULATING 50/50 SOLUTION OF WATER AND GLYCOL
THROUGH PUMP, OPEN PULSATOR VALVE WHEN WINTERIZING.
NOTES: 1) STAMP S/N ON ITEM 26. DRILL (2) 1/8 DIA HOLES & MOUNT APPROX AS SHOWN USING (2) 44038500\
2) REMOVE (1) WHEEL & MOUNT ENGINE AS SHOWN, REASSEMBLE WHEEL IN PLACE
3) LUBRICATE ENGINE SHAFT WITH ANTISEIZE (71122800) PLACE 1/4 X 1/4 X 2-5/32 KEY INTO
ENGINE SHAFT. SLIDE COUPLER ONTO SHAFT & TIGHTEN SET-SCDREW. ATTACHE PUMP BY SLIDING PUMP
CRANKSHAFT INSIDE COUPLER.
4) ASSEMBLE PUMP TO ENGINE USING (4) 00116900.
5) TIGHTEN SET-SCREW ON PUMP SHAFT BY ACCESSING THRU HOLE IN PUMP FLANGE.
6) FILL & CHARGE PER INCLUDED BATTERY INSTRUCTIONS.
7) ADD OIL (72710200) TO PROPER LEVEL IN ENGINE
8) CHECK OIL IN PUMP AND ADD IF NECESSARY. USE GIANT SYNTHETIC CRANKCASE OIL.
9) DO NOT ADD FUEL TO ENGINE FUEL TANK.
10) SLIDE CLEAR TUBE OF REEL ASSY OVER FEMALE END OF HOSE (72706700). CONNECT FEMALE
FITTING OF HOSE TO SWIVEL ASSEMBLY IN REEL. SLIDE CLEAR TUBE BACK TOWARDS SWIVEL
TO COVER HOSE CONNECTION. TIGHTLY WRAP HOSE TO REEL & SECURE WITH NYLON TIE (72711500)
11) ASSEMBLE THRUSTER NOZZLE (72705400) TO END OF 3/16 ID HOSE (71129103)
12) TEST PER INSTRUCTIONS. AFTER TESTING, REMOVE POSITIVE BATTERY LEAD FROM BATTERY.
REPLACE TERMINAL SCREW TO BATTERY. WRAP ON LAYER OF PLASTIC ELECTRICAL TAPE OVER
CONTACT AREA OF POSITIVE LEAD.
13) PACKAGING INSTRUCTIONS:
A. SECURE JETTER UNIT TO PALLET THROUGH CARTON (72710100) END USING SPACER BLOCK.
B. SHRINK WRAP UNIT.
C. INCLUDE FOLLOWING ITEM IN CARTON (44042300). PLACE CARTON IN MAIN CARTON.
GLOVES 5G243631; 75 FT HOSE 71129103; OWNERS MANUAL; TIP CLEANER 71109900;
ADAPTER ASSEMBLY 72711300; ENGINE EXHAUST DEFLECTOR; SPARKPLUG WRENCH &
ENGINE OWNERS MANUAL- (INCLUDED IN 72703200)
D. BUBBLE WRAP SPRAYGUN ASSEMBY 77799800 & PLACE IN UNIT CARTON
E. STAPLE CARTON ENDS & BAND TO PALLET.
14. SPRAY GUN 77799800 TO BE ASSEMBLED WITH BUSHING 542104-03 USING TEFLON TAPE BEFORE PACKAGING FOR SHIPMENT.
11
23 32
9
10
8

19
Model 727 Final Assembly
Item Part Number Description Qty.
1 72704100 Assembly, Frame—727 1
2 77799800 Spraygun Assembly 1
3 72727700 Assembly, HP Reel 1
4 72711100 Pin, Safety Snap 2
5 72726200 Assembly, Pump 1
6 H ⁄-75 ⁄" I.D. x 75' Hose Assembly (orange) 1
7 72706700 Hose, ⁄" O.D. x 200' (red) 1
8 00162600 Washer, Flat ⁄" USS 12
9 00116900 Screw, Hex Head ⁄-16 x 1¾ 8
10 00165800 Washer, Lock-Split ⁄" 4
11 00763301 Washer, Flat ¼" 4
12 542104-03 Bushing, Red ⁄" M x ¼" F STL 1
13 72705100 Nozzle, Closed for ⁄" Hose 1
14 72705200 Nozzle, Open for ⁄" Hose 1
15 72705400 Nozzle, Closed for ⁄" Hose 1
16 72705500 Nozzle, Open for ⁄" Hose 1
17 72709500 Decal, Hot Exhaust Pipe 1
18 72711300 Assembly, Adapter ⁄" to ¼" 1
19 77721400 Plug, Female ¼" NPT 1
20 77748000 Nut, Stover ⁄-16 4
21 72706500 Cable, Positive Battery 1
22 72706600 Cable, Negative Battery 1
23 79920154 Screw, Hex Head Cap ¼-20 x 2" 2
25 5G243631 Gloves 1
26 71109900 Nozzle Orifice Cleaner 1
28 72708510 Battery Box 1
29 72708500 Battery 1
30 72708520 Battery Strap 1
31 72708400 Engine, 14 HP 1
32 73821200 Nut, Nylon Locking ¼-20 2
33 79873400 Hex Head Screw, M8-1.25x25 1
34 01588200 Washer, Flat #10 1
35 64050080 Clamp, Drum Cable 1
36 JH-SPNR1 Nozzle, Rotating ¼" 1

20
Frame Assembly
FRAME ASSEMBLY (72704100)
PARTS LIST
DESCRIPTION
PART NUMBER
QTY
ITEM
WELDMENT, FRAME 7277270010011
TIRE, 10" PNUEMATIC7110070022
HANDLE4424500013
SCREW CAP HEX HD 3/8-16X1-3/4001169002
4
HEX NUT 1/4-20 ZINC PLATED
001373002
5
WASHER, LOCK SPLIT #100016530026
WASHER, LOCK SPLIT 3/8001658002
7
NUT, HEX 3/8-16
0293410028
SCREW, SELF TAPPING 10-24 X 1/244119500
1
9
WASHER, FLAT 1/2" USS
5OHW12FO210
ASSY, LOWER WAND SUPPORT72726800111
NUT, 1/2-13 STOVER LOCK77744800212
S HOOK77813100113
1/8 PUSH ON RUBBER TRIM79907600
114
2 X 4-1/4 X 1/8 BLACK MAT
02865500415
HANDLE GRIP5PP60500216
PIN, SAFETY SNAP 72772714700
117
CASTER, SWIVEL TOP LOCKING72703702218
Cable Assembly, 7" Eye To Eye75853820
1
19
TUBE, PLASTIC 7/8" I.D. X 13"
72703900120
SPACER, WHEEL- 72772700800221
COLLAR, LOCKING SET 5/8"5PP55120222
SPARTAN TOOL
MENDOTA, IL 61342
DATE
SIZE SCALE
DRAWN BY ECO
DRAWING NUMBER
SHEET NUMBER
REV
TITLE
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES
WARNING: THIS DRAWING IS
GENERATED FROM 3D BODY DATA
AND ANY GEOMETRY CHANGES
SHOULD BE CARRIED OUT
IN 3D ONLY.
THIS DOCUMENT CONTAINS
PROPRIETARY INFORMATION AND
SUCH INFORMATION MAY NOT BE
DISCLOSED TO OTHERS FOR ANY
PURPOSE NOR USED FOR
MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION
FROM SPARTAN TOOL L.L.C.
ASSY, FRAME 727
5/17/2018 DL 1 of 1
H
72704100
1 / 4
D
.XX = ±.01 .XXX = ±.005
FRACTIONS = ±1/64
ANGLES = ±1°
CRITICAL DIMENSION
REV ECO DATE DESCRIPTION APPROVED
G 5/18/18 REPLACES DWG DATED 9/18/95 DL
H 1/31/2019 UPDATE VIEW TO MATCH PRODUCTION JPB
20
16
16
15
15
15
15
2.50
14 1
2
11
18
10
12
3
21
4
7
8
8
7
4
6
5
22 21
17
13
19
9
