Spartan 718 User manual

PRODUCT MANUAL
Model 718
© 2020 Spartan Tool LLC
Part #71800150
Spartan Tool LLC |1618 Terminal Road |Niles, MI 49120
order by phone [phone] order online SpartanTool.com

2
WARNINGS ............................................................................................................ 3
TECHNICAL INFORMATION .............................................................................................4
ASSEMBLY INSTRUCTIONS .............................................................................................5
Operating Instructions ..........................................................................................................6
OPERATING INSTRUCTIONS ............................................................................................6
Operating a Power-Driven Cleaning Tool ........................................................................................7
How to Repair Kinked or Broken ¼" and 5⁄16" Open Hook Cables ..................................................................7
Care of Machine ................................................................................................................7
How to Order Parts for Your Model 718 ..........................................................................................8
MODEL 718 CABLE & PARTS ............................................................................................8
Model 718 Cable................................................................................................................8
MODEL 718 FINAL ASSEMBLY........................................................................................... 9
How to Use the Parts & Accessories Section......................................................................................9
Final Assembly (71800000)......................................................................................................9
WARRANTY INFORMATION ............................................................................................11
Contents

3
Warnings
• Read the safety and operating instructions before using any Spartan Tool product. Drain and sewer cleaning can be dangerous if
proper procedures are not followed and appropriate safety gear is not utilized.
• Before starting unit, be sure to wear personal protective equipment such as safety goggles or face shield and protective clothing
such as gloves, coveralls or raincoat, rubber boots with metatarsal guards, and hearing protection.
• Drains and sewer can carry bacteria and other infectious micro-organisms or materials which can cause death or severe illness. Avoid
exposing eyes, nose, mouth, ears, hands, and cuts and abrasions to waste water or other potentially infectious materials during drain
and sewer cleaning operations. To further help protect against exposure to infectious materials, wash hands, arms and other areas
of the body, as needed, with hot, soapy water and, if necessary, flush mucous membranes with water. Also, disinfect potentially
contaminated equipment by washing such surfaces with appropriate chemicals or soaps.
• For any questions, contact Spartan Tool at the address shown below.
CALIFORNIA PROP. 65
This product may contain an
extremely small amount of lead in the
coating. Lead is a material known to
the State of California to cause cancer
or reproductive toxicity.
CONTACT US
Spartan Tool LLC
1618 Terminal Road
Niles, MI 49120
800.435.3866
SpartanTool.com
USE OF ANY ELECTRIC EQUIPMENT IN A WET OR DAMP ENVIRONMENT CAN CAUSE FATAL SHOCK IF NOT PROPERLY
GUARDED AGAINST BY THE OPERATOR.
1. Before using your Spartan equipment, make sure that a properly grounded, 3-hole electrical outlet is available. If not, as in older
homes, use a 3-prong adapter and connect the green pigtail or grounding lug to a known ground such as a cold water pipe.
2. Don't assume all 3-hole outlets are properly installed. Check the outlet and also the adapter, if used, with an outlet testing device
which quickly indicates if a ground is connected. Correct a faulty test indication before proceeding.
3. Plug the three-wire cord furnished with your machine into the inspected outlet. If an extension cord must be used, it must be of an
approved three-wire type in good condition, equipped with a three-prong plug. Never cut off the grounding prong for use in a two-
hole outlet receptacle. By doing so, you have cut off your protection from shock.
4. Use rubber boots and rubber gloves inside your Spartan riveted gloves to further insulate yourself. Respect electricity: you may not
get a second chance.
5. Read this manual carefully for further safety precautions and operating instructions.
Your Spartan equipment has been built with the utmost safety in mind and thoroughly inspected for electrical and mechanical defects.
However, through abuse and misuse on the job, a breakdown in the electrical insulation could conceivably develop and if this happens,
you need a ground circuit to protect you.

4
Technical Information
SPECS
Pipe Sizes 1¼" to 2" diameter
Weight 9 lbs
Unit size 9.5"W x 17"L x 14"H
Cable Capacity 35' of ¼" or ⁄"
Motor 18 volt
Battery Lithium Ion 4.0 ah

5
Assembly Instructions
1. Mount Model 718 in vise or have it held in secure position.
2. Lay entire length of cable on floor with non-working end of cable pointing toward chuck.
3. Push cable into drum, using short bites, one foot at a time, to prevent kinking (Fig. 1).
4. Feed entire length or cable into drum, leaving only the bulb or enlarged head exposed.
5. Slide the battery box into place.
Now you are ready to operate.
Fig. 1 Bend cable end
Fig. 2 Feed entire cable into drum

6
Operating Instructions
WARNING Do not use your ¼" cable in lines larger than 1¼" in diameter
OPERATING INSTRUCTIONS
1. Insert proper size of cable in machine, using ¼" cable for 1¼" lines: ⁄" cable for 1½" to 2" lines.
2. Hold unit close—within 6" to 8" of pipe opening.
3. Pull out enough cable to enter waste line or approach cross bar.
4. Position Reverse Switch, causing cable and drum to rotate in a clockwise direction. Don't reverse motor or use Reverse Action
Switch until machine comes to a dead stop.
5. Press Off-On Trigger Switch causing cable to rotate through cross bar or into pipe opening.
6. To tighten chuck, grip it with your hand while motor turns clockwise and chuck will close easily.
7. Take 6" to 8" bite on cable, and feed same into line by advancing machine toward cleanout slowly, giving cable time to round fitting
or remove stoppage.
8. When motor slows up, indicating a load on same, pull back a bit and start moving your unit forwards and backwards. This
reciprocating action keeps the cable rotating—keeps the cable from getting "hung up"—the sole cause of cable kinkage or
breakage.
9. If cable gets "hung up," stop your machine and reverse the direction of same through Reverse Switch, pulling back as you do so to
free working end of cable.
WARNING Do not use Reverse Switch until your motor unit comes to a dead stop!
10. When chuck approaches cleanout, stop your machine; open the chuck and pull out another short length of cable.
11. Tighten your chuck and advance your machine toward pipe opening.
12. Repeat this action as often as necessary to clean the line.
13. When the job is completed, feed all cable back into drum 6" to 8" at a time—DON'T take long bites

7
OPERATING A POWER-DRIVEN CLEANING TOOL
1. Stay close to pipe opening, having no more than 6" to 8" of cable exposed between machine and cleanout—especially when
rounding fittings or removing stoppage.
2. Move your machine backwards and forwards constantly when you get into stoppage, thereby preventing your cable from getting
"hung up" causing unnecessary kinkage. Remember, a rotating sewer cable cannot kink or break. Kinkage of cable takes place only
when the working end of the cable gets "hung up" and you keep on twisting the other end.
3. Don't attempt to go around fittings or remove stoppage until your drum reaches full speed. It is the rotation of the cable that
enables it to either (a) round fittings, (b) remove stoppage—NOT push power.
Operating Instructions
HOW TO REPAIR KINKED OR BROKEN ¼" AND 5∕16" OPEN HOOK CABLES
Repair bulbs for ¼" and ⁄" cables are available. If you kink your cable, cut the cable off at the kinked portion. Grind the end to provide
a leader thread. Now, thread your repair bulb on the regular cable, as you would a nut on a bolt, turning about three turns—which will
fasten it to the cable securely.
CARE OF MACHINE
Dry or wipe your cables as you put them in the drum. When through with a job, place your machine back in the bucket. DON'T drop it—
lay it down in its proper position in the bucket.

8
MODEL 718 CABLE
Model 718 Cable & Parts
SPARTAN MODEL 718
Unit Serial Number
CONTACT US
Spartan Tool LLC
1618 Terminal Road
Niles, MI 49120
800.435.3866
SpartanTool.com
For rodding 1¼" to 1½" lavatory, bathtub, shower stall wastes, etc. Each sewer rod comes equipped with all parts illustrated, including
Allen head screws and wrenches for changing heads. Use cutters for removing grease and extraction hook for rags. Drop-head designed
to assure downward direction on vents—imperative in rodding waste lines where fixtures are back-to-back.
HOW TO ORDER PARTS FOR YOUR MODEL 718
Spartan Tool will supply all parts or accessories you require as quickly as possible. In order to do so, we must have information from you,
including machine serial number and part numbers.
Please record the serial number of your machine in the space provided below:
To order parts, look through the pictures until you find the part you
require or an indication of where the part should be. Using the item
number from the picture, go to that number on the adjacent page and
check the description to determine if it is the part you desire.
Using the part numbers, please contact your Spartan Territory Manager
or Spartan Tool directly at www.SpartanTool.com.
5/16” Multi-Purpose Inner-Core Cable
1/4” X 25’ Sewer Cable with open hook end for rodding 11/4”waste lines only
5/16” X 25’ Sewer Cable with open hook end for rodding 11/4”to 11/2”waste lines only
Model 718 Cables
03449002 ⁄" x 25' IC No. 8
03449003 ⁄" x 30' IC No. 8
03449004 ⁄" x 35' IC No. 8
04212402 ⁄" x 25' OH
04212403 ⁄" x 30' OH
04212404 ⁄" x 35' OH
04224701 ¼" x 25' NCNT
04212102 ¼" x 25' OH
04212103 ¼" x 30' OH
04212104 ¼" x 35' OH
44104301 ¼" x 35' DH
44104302 ¼" x 35' DH

9
Model 718 Final Assembly
FINAL ASSEMBLY (71800000)
PARTS LIST
DESCRIPTIONPART NUMBERQTYITEM
WASHER, 2" OD x 13/16 ID x 5/32 THICK00163300
11
NOZZLE COLLAR-MODEL 7000275340012
HAND GUARD MOD 7000275440013
CHUCK ASSY C/W STL COLLET02773700
14
NUT, HEX JAM 3/4-16NF
0282090015
RETAINING RING02822700
1
6
INTERNAL TOOTH LOCKWASHER 3/4
0282470017
DECAL, SPARTAN WARNING4416440018
BAND, RUBBER MODEL 70044229300
1
9
DRUM, BACK MOD 700 W/MILW 0299-20
44301300110
NOZZLE-MODEL 70044301800
111
SCREW, TRUSS HD #8-32X 3/8
44301900412
WASHER-EXT TOOTH #844301910413
DRUM, FRONT 700 W/ PEM NUTS44302300
114
SCREW, 8-32 X 1/2 BHCS
64050083215
SET, MODEL 718 DRIVER71800200
1
16
ADAPTER, MODEL 718 SPINDLE71800300117
PLATE, MODEL 718 DRIVE71800310118
SCREW, M6-1.0X20 LH BHCS71800320
1
19
SPARTAN TOOL
MENDOTA, IL 61342
DATE
SIZE SCALE
DRAWN BY ECO
DRAWING NUMBER
SHEET NUMBER
REV
TITLE
THIRD ANGLE PROJECTION
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES
WARNING: THIS DRAWING IS
GENERATED FROM 3D BODY DATA
AND ANY GEOMETRY CHANGES
SHOULD BE CARRIED OUT
IN 3D ONLY.
THIS DOCUMENT CONTAINS
PROPRIETARY INFORMATION AND
SUCH INFORMATION MAY NOT BE
DISCLOSED TO OTHERS FOR ANY
PURPOSE NOR USED FOR
MANUFACTURING PURPOSES
WITHOUT WRITTEN PERMISSION
FROM SPARTAN TOOL L.L.C.
MODEL 718
11/21/2019 8495 1 of 2
71800000
2/3
D
.XX = ±.01 .XXX = ±.005
FRACTIONS = ±1/64
ANGLES = ±1°
CRITICAL DIMENSION
REV ECO DESIGNER DATE DESCRIPTION APPROVED
8495 SMO 9/9/2019 RELEASE DRAWING JPB
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
