Spear & Jackson S1232ER User manual

IN THE BOX QUICK START
GUIDE
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your mower, ensuring it is assembled correctly
and safely. If you need help or have damaged or missing parts,
call the Customer Helpline on 0345 605 2067
AFTER SALES SUPPORT
0345 605 2067
32cm 1200W
Rotary Electric
Lawnmower
S1232ER
7
4
8
5
6
10
9
11
13
12
1
2
3
14
Switch box
Switch bar
Upper handle
Lower handle
Wing nut
Full grass indicator
Grass bag
Deck
Cable clip
Screws x2
Height adjusting handle
Wheel
Power cable
1
2
7
3
4
5
6
8
9
10
11
12
13
Roller
Grass bag handle
14
15
15

ASSEMBLE PREPARE MOW
1 2
4
3
Locate the lower handle into deck,
and fix it with 2 screws.
Fit the upper handle, lower handle
together using the wing nuts.
Ensure that the cables clips supplied are
used to fix the cable to the handle.
Insert the grass bag handle in the upper
cover of grass bag which is with full indicator.
78
Connect the plug to the main socket. i. Push the adjusting lever out of the
toothed area.
ii. Push the lever up or down into
the required height position (1 to 5)
5
Place the metal frame inside the grass
collection bag. Make sure that these
clips are fully secured to the metal
frame.
9 10
Press the button (1). Pull the switch
bar (2) towards the handle and hold in
position.
When you begin to mow please follow
the arrow, avoiding twisting the power
cord or the risk of cutting the cord.
1
2
1
2
2
60 mm 20 mm
10
6
Lift up the rear flap before assemble the
grass bag. Hang the collection bag on
the mower.
11
Release the switch bar to switch
the mower off.
O
