Speco O2BFRM User manual

Quick Start Guide
O2BFRM

1Warning and Caution
Package
2

Overview
3 Overview
3
Camera Quick start guide
CD Plastic plug ×4
Drill template
CVBS&DC
IN cables
Screwdriver Junction box
4 tapping screws
1 machine screw
1
3
4
5
6
7
2
8
9
10
11
12
1 Ethernet Connector *
2 MIC Audio Input
3 HP Audio Output
4 CVBS Video Output
5 Alarm Input/Output
6 RS485
7 Power Connector *
8 Micro SD Card Slot
9 Zoom +
10 Zoom -
11 DC IN & CVBS Interface
12 Reset
* 1
* 2 If the PoE switch is used to power the camera, DC12V/AC24 power supply is not required.
It is recommended to install the security cap for outdoor installation.

* 1 It is recommended to install the security cap for outdoor installations.
* 2 DC 12V power supply is not required if a PoE switch or injector is used to power
the camera.
► Connecting Network Cable
① Loosen the nut from the main element.
② Run the network cable (without RJ 45 connector) through both elements.
Then crimp the cable with RJ 45 connector.
③ Connect the cable to the hermetic connector. Then tighten the nut and the
main cover.
2
13
ALM-COM
ALM-OPEN
ALM-INA
ALM-GND
RS485T+
RS485T-
DC12V/AC24V
Security cap

Installation
4
ɑ
H
D
1. The camera shall be installed right in front of the passage to take snapshots
of full-frontal faces.
2. The installation height ranges from 2.0m(6.6ft) to 3.5m(11.5ft), adjustable
according to the focal-length of different lenses and object distances).
3. The depression angle (ɑ) of the camera shall be less than or equal to 15°.
4.The object distance (D) depends on the focal-length of the lens mounted in
the camera.
Surveillance
Width Focal-length Optimal Object
Distance
Installation
Height
Camera’s
Depression Angle
2.4m(7.9ft) 6.0m(19.7ft) 2.6m(8.5ft)
2.4m(7.9ft) 7-22mm (W)
7-22mm (T)
3.6m(11.8ft) 2.1m(6.9ft) 10°
10°
► Requirements of Camera Installation & Surrounding Areas
5.To ensure the accuracy of face detection, the captured faces are only allowed
to deviate less than 30° leftward or rightward or 20° upward or downward.
6. Make sure the detected face is clear and with adequate and even light. Otherwise,
the white light mode of the camera must be enabled for light compensation
(especially, low brightness and too much darkness on the detected face).
7. The following scenes are not applicable, like crowded scenes (airport,
railway station, square, etc.), backlight scenes, crossroads and so on.

* Before you start, please make sure that the wall or ceiling is strong enough
to withstand three times the weight of the camera and junction box.
① Open the mounting base and the upper cover of the junction box.
SD Card Installation
Camera Installation with a Junction Box
Insert a micro
SD card
Cover
Open the cover of the camera as shown in the following figure and then insert
a micro SD card. After that, install the cover back to the camera (Note that the
cover shouldn’t be installed unevenly).
Mounting base
Upper cover
② Install the mounting base of the junction box onto the wall by using the
screws provided.

③ Fix the mounting base of the camera to the upper cover of the junction
box.
④ Route the cables through the cable hole and connect the camera. Then install
the camera onto the mounting base of the junction box.
Three-axis Adjustment-Before adjustment, preview the image of the camera
on a monitor and then loosen the fixed screws to adjust the camera according to
the figure below to get an optimum angle.
⑤

Tilt 90°
Pan 360°
Rotate
360°
Web Operation and Login
5
● Operation
IP Scanner can search for the device on the local network.
① Make sure that the camera and the PC are connected to the same local network.
The camera is set to DHCP by default.
② Install IP Scanner from the CD and run it after installation.
Fixed screws
O2BFRM

The login interface is shown above. Default user name is admin and password
is 1234. After logging in, follow directions to install applicable plugins.
③ In the device list, you can view the IP address, model number, and MAC
address of each device. Select the applicable device and double click to open
up the web viewer. You can also manually enter the IP address in the address
bar of the web browser.
