Speed Limit RC Sky Sprite Pro User manual

speed limit rc reserves the right to modify the specification or
printing
errors without prior notice.
A R/C model airplane is not a toy and is not suitable for flyer
under 14 years old.Read the instructions carefully before any use.
If you are a beginner, it is necessary to let an experienced airplane
pilot assist you.
Instruction Manual
www.speedlimitrc.com
speed limit rc
speedlimitrc.com

1
PROHIBITED: this symbol points out actions that you should not do
to avoid possible damage or accidents.
1.Do not fly in thunderstorm,
strong winds or bad weather.
5 . Make sure that the model as well as
the control system is in the good state
before the plane takes off.
3 .Never fly the Model where are crowds of
people. Give yourself plenty of room flying ,
as the plane can travel at a high rate of speed .
Remember you are responsible for the safety
of others.
2 .Never fly the Model where are crowds of
power lines overhead , automobiles or near
highways , subways.
Meaning of the icons.
WARNING!: this symbol indicates where caution is essential to
avoid injury to yourself or others .
Safety instructions
4. Do not fly in where the same frequency
model plane is flying nearby.
www.speedlimitrc.com

2
If you have any questions in regarding to the safe operation, or possible
please call your local hobby shop for professional advice.
precautions
Radio-controlled models are very demanding and potentially dangerous
They call for a high level of technical knowledge and skill from the operator.
Please always keep this instruction manual ready at hand for quick reference,
even after completing the assembly.
machines.
Sky sprite pro is a propeller plane which suits for beginners .
In order to fly the Sky sprite pro, please make sure you read through the
carefully before attempting to operate the model for the first time.
instructions
7.Do not attempt to catch the
model while flying.
8.Not recommended for children under 14years old,
Children under years old should only operate this
model under the guidance of a responsible adult.
14
9.Do not store this model in a high-temperature
or humidity area or in direct sunlight.
6. use genuine accessories as
replacmente for damaged parts.
Only
Thank you for purchasing Sky sprite pro .
3
www.speedlimitrc.com

5
Wing Installation.(2-13)
2
3
Wing Lock Installation.(2)
General View Schedule. (1)
1
1
Aileron Plug Installation L/R.(3)
2
Length:1087mm
Wingspan:1600mm
Propeller diameter:8×6 in
Flying weight:1170g
Radio:8CH RC
Brushless ESC:35A
6×17g Digital metal servo
Brushless motor:1300KV
Battery :4s 25C 2200mAh
4
www.speedlimitrc.com

14
6 7
45
6
8 9
10 11
Aileron Installation.(4)horn Aileron Servo Installation.(5)
Aileron Push Rod Installation.(6)
Flap Installation.(8)horn Flap Servo Installation.(9)
Flap Push Rod Installation.(10)
Flap Plug Installation L1/R1.(7)
Servo Plug Installation.(11)
7
16
13
3
Wing Plug Cover Installation (L/R).(12) Servo Cover Installation.(13)
Fuselage Installation.(14-41)
12
Antenna Pipe Installation.(17)
17
The Installation of Permanent Seat in
Horizontal tail.(16)
15
Servo Plug Connector Installation.(14-15)
Please note the positive and negtive direction.
www.speedlimitrc.com

8 9
25
19
Motor Permanent Seat Installation.(19)
Motor Installation.(21)
21
Propeller Installation.(25)
23
18
The combination of left and right fuselage.(18)
22
50A ESC Installation.(22-24)
Heat Filter Installation.(20)
20
Bundling the ESC output lines (3 pcs) with tape ,
then through from wire casing , connecting the
bundled 3 pcs output lines with motor in
respectively colors .(23)
24
Fixing the motor line with tapes to prevent
friction between motor and motor line.(24)
3332
28
26 27
Rudder horn installation.(27)
Rudder Push Rod Installation.(29)
29
Rudder Pipe Installation.(28)
31
Rudder Servo Cover Installation.(31)
Horizontal tail Pipe Installation.(33)
30
Rudder Servo Installation.(30)
Motor Bin Cover Installation.(26)
Fixed the ruddder push rod.(32)
www.speedlimitrc.com

1110
36
Horizontal tail Servo Cover Installation. (36)
Horizontal Tail Installation.(38)
38 39
35
Horizontal tail Servo Installation.(35)
Canopy Lock Installation.(41)
41
34
Horizontal Tail Push Rod Installation.(34)
40
Wear block.(40)
37
Horizontal tail horn installation.(37)
Fixed lock and push rod in Horizontal tail.(39)
43
41
42
45 46
47 48
4Magnet Installation in Nose Cone (42-44)
5Battery Bandage
Installation (45-48)
44
Installing the nose cone and using the nose
cone to put the battery inside until the nose
cone is in right position.(46-47)
After the glue drying,put the battery out.Then
finish the battery bandage installation.(48)
Bundling the bandage on battery and glue
the bandage,(Note can't glue in battery)(45)
www.speedlimitrc.com

1312
49 50
6
7
Canopy Installation.(49-50)
The connection of Wing and Fuselage.(51-52)
Canopy Lock and plastic canopy
Installation.(49) Canopy Installation.(50)
51
√
×
53 54
52
8 Receiver Installation.(53-58)
55 56
www.speedlimitrc.com

14 15
59
9
10
Battery Installation.(59-60)
Performance Testing.(61-71)
57 58
60
61 62
Switch on Transmitter.(61)
63 64
Connecting Battery.(62-63)
Aileron Testing.(64-65)
65 66
67 68
69 70
71 71
Flap Testing.(66)
Rudder Testing.(67-68)
Elevator Testing.(69-70)
Throttle Testing .
www.speedlimitrc.com

16 17
11 Beautify.(72-79)
72
73
75
74
80
15
12 CG debugging.(80)
70mm
10mm
www.speedlimitrc.com

18 19
004 005
007 008
010 011 012009
006
003
001 002
13 Parts List .
NO Name Quantity RTF ARF KIT
S-S001
S-S003
S-S004
S-S005
S-S006
S-S007
S-S008
S-S009
S-S010
S-S011
S-S012
S-S013
S-S014
S-S015
S-S016
S-S017
S-S018
S-S019
S-S020
S-S021
S-S022
S-S023
S-S024
S-S025
S-S026
S-S027
S-S028
S-S002
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
√ √
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
Left Wing
Right Wing
Left wing plug cover
Right wing plug cover
Left fuselage
Right fuselage
Servo cover in left fuselage
Servo cover in right fuselage
Nose Cone
Cockpit
Horizontal Tail
Wing Lock parts
Aileron parts
Flap parts
Wing Plug Connector parts
Wing Plug parts
Fuselage Plug Connector parts
Horizontal tail Permanent seat parts
Antenna Pipe
Motor Permanent seat parts
Propeller parts
Motor bin cover parts
Vertical fin parts
Horizontal tail parts
Wear block
Fixed battery parts
Canopy lock parts
Canopy
S-S029
S-S030
S-S031
S-S032
S-S033
S-S034
S-S035
S-S036
S-S037
S-S038
S-S039
S-S040
S-S041
S-S042
1
1
1
1
1
1
1
1
1
1
1
1
1
1
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
××
×
×
×
×
×
×
×
××
×
×
×
Magnet
Hinges
20ml Glue
Allen wrench
Sticker
RC adaptor
Recharger
2850 Motor
35A ESC
17g Metal digital servo
4S 2200mAh Li-po
8ch transmitter
8 ch receiver
5A UBEC
www.speedlimitrc.com

20 21
rotary.
Sky sprite pro pre-flight check
014 015 016
018 019 020
022 023 024
026 027 028025
021
017
013
030 031 032
034 035 036033
029
Problem solving
038 039 040
041
037
042
