ON-PREMISES LAUNDRY
Push-to-Start Washers and Dryers
SWNMN2P Washer SDE807 Dryer SSE807 Stack Dryer
SWNMN2S Washer SDG809 Dryer SSG809 Stack Dryer

THE BEST IN CLASS JUST GOTBETTER.
100 years. It’s a long time for any company to be at the forefront of an industry. And you’d think that
a company that’s been able to lead for that long must have a finely honed craft — a premier product.
Well, you’d be right. For more than a century, Speed Queen has built a legacy on providing equipment
that stands up to any commercial laundry challenge. We make no compromises in performance. We
refuse to be outdone in reliability and efficiency. Our commitment to quality is only matched by our
commitment to your success. The result? The most profitable machines in the industry — bar none.
Some of our competitors may think that a residential machine wrapped in a rugged exterior passes
for commercial grade. We believe that strength comes from within. Speed Queen machines are built
specifically for the commercial environment. We use metal where others use plastic. Our world-
class Test Lab rigorously pushes our products far beyond the conditions they’ll face in the field. We
believe in being there when our customers need us most. And we go the extra mile at every point of
our manufacturing process to ensure that our machines reflect that belief.
For commercial laundry equipment designed for use in fire departments, health care facilities, hotels,
correctional facilities, spas, salons, athletics organizations or another industry application, you can
rely on the proven performance of Speed Queen to make your life simpler and more productive.
Made in America and refined for more than a century, Speed Queen Laundry equipment represents
a secure investment for your on-premises laundry facility.

• Water level selectors give managers
the flexibility to choose wash and
rinse levels
• Extra-large capacity wash tub in
stainless steel or porcelain
• Commercial quality transmission
offers highest quality and durability
• Advanced suspension system
eliminates the possibility of an
unbalanced load issue
• Extra-large capacity with
the largest door opening
in the industry
• Front access for easy
serviceability
• Stack unit offers two dryers
in floor space of one
DEDICATED TO A HIGHER STANDARD
E MECH CONTROL
The E Mech control for washers and dryers offers customers a straight-forward design with simple temperature and fabric selections and includes indicator lights
to keep customers aware of what cycle the machines are in.
Speed Queen E-Mech washers and dryers are designed for durability and ease of use with push to
start switch and reinforced control knobs and they come with a 3-year warranty on any part of the
entire machine.
TOPLOAD WASHER DRYER AND STACK DRYER

ON PREMISES PUSH-TO-START WASHERS AND DRYERS
Washer and dryer models are made to suit a variety of electrical service characteristics. See your Speed Queen distributor for specifications. For further details on installation, refer to Installation,
Operation and Maintenance instructions supplied with the washer or dryer. Amperage ratings available in Installation Manual. For the most accurate information, the installation guide should be used
for all design and construction purposes. Due to continuous product improvements, design and specifications subject to change without notice. The quality management system of Alliance Laundry
Systems’ Ripon facility has been registered to ISO 9001:2000.
Printed in the U.S.A.
speedqueen.com
© 2014 Alliance Laundry Systems LLC AO14-0002
Model SWNMN2S SWNMN2P SDE807 SDG809 SSE807 SSG809
Width (inches) 25-5/8 25-5/8 26-7/8 26-7/8 26-7/8 26-7/8
Depth (inches) 28 28 28 28 28 28
Height (inches) 43 43 43 43 76-5/8 76-5/8
Work surface height
(inches)
36 36 36 36 N/A N/A
Basket Volume (cu. ft.) 3.26 3.26 N/A N/A N/A N/A
Cylinder Volume (cu. ft.) N/A N/A 7 7 7 7
Tub Finish Stainless Steel Porcelain N/A N/A N/A N/A
Cycles/Temperature Hot
Warm
Cold
Hot
Warm
Cold
Normal
Perm Press
Delicate
No Heat
Normal Perm
Press Delicate
No Heat
Normal
Perm Press
Delicate
No Heat
Normal
Perm Press
Delicate
No Heat
Motor HP 1/2 HP 1/2 HP 1/3 HP,
5.5 Amps
1/3 HP,
5.5 Amps
1/3 HP,
5.5 Amps
1/3 HP,
5.5 Amps
Motor RPM N/A N/A 60Hz,
1725 RPM
60Hz,
1725 RPM
60Hz,
1725 RPM
60Hz,
1725 RPM
Electrical Specs
Voltage/Hz/Phase/Amps
Heating Element
120/60/1 - 15
N/A
120/60/1 - 15
N/A
120/240/60/1 - 30
5350W - 240V
120/60/1 - 15
N/A
120/240/60/1 - 30
5350W - 240V
120/60/1 - 15
N/A
Spin Speeds (RPM)
High Speed
Low Speed
710
473
710
N/A N/A N/A N/A
Water Consumption 27.3 gal/cycle 27.3 gal/cycle N/A N/A N/A N/A
Water Factor 8.4 gal/cu ft 8.4 gal/cu ft N/A N/A N/A N/A
Modified Energy Factor 1.65 1.65 N/A N/A N/A N/A
Energy Data N/A N/A 5350W 25000 Btu/hr 5350W 25000 Btu/hr
Type of Gas N/A N/A N/A Natural N/A Natural
Connections
Utility Connections
Air outlet
Exhaust Airflow
Maximum Exhaust
Static Back Pressure
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
4”
220 cfm
0.6”W.C.
3/8” NPT
4”
220 cfm
0.6”W.C.
N/A
4”
220 cfm
0.6”W.C.
3/8” NPT
4”
220 cfm
0.6”W.C.
Net Weight (lbs) 190 190 135 140 265 275
Shipping Weight (lbs) 210 210 145 150 280 290
Agency Approvals cULus cULus cULus CSA Star cULus CSA Star
