Splendide WD2100 User manual
Select A Wash Program
Turn the program selector knob
(1) clockwise until the program
you want aligns with the mark on
the knob.
IMPORTANT: Should you wish
to interrupt a program in
progress, advance the Program
Selector knob (1) to a "Reset"
position and wait 5 seconds.
Select A Wash Temp.
Turn the Wash Temp. knob (3)
to the temperature you want.
The 7 selections range from
HOT to COLD. Note: Rinse
temperatures are always COLD.
Special Programs
Use buttons A, B, C, or D to run
a Special program. If you don't
wish to use these buttons, leave
them in their OFF (OUT)
position.
Choose a Dry Time
To start drying automatically after
washing select a dry time using
the Dry Time knob (2). (Cool-
Down not included).
IMPORTANT: Once set, this knob
will not move during the dry cycle.
Add Laundry Aids
Pull the dispenser drawer (4)
open and add your favorite
laundry aids to the appropriately
labeled compartments. When
finished, close the drawer.
IMPORTANT: Use no more
than 1-2 tbsp. of a High
Efficiency (HE) powder
detergent and 1-2 tbsp. of fabric
softener per wash load.
Press ON
Press the ON button (5) in.
The Auto Dry LED will light if a
dry time has been set. The
Status/Door Lock LED will flash
then light steady, indicating that
the door is locked and the
program will begin.
IMPORTANT: For your
protection, the door will stay
locked for the duration of the
wash and dry cycles.
Go From Wash To Dry Automatically!*
11
1
2233445
Before you begin, check that the: -Door is closed -On/Off button (5) is in the OFF (OUT) position -Program Selector knob (1) is in a "Reset" position
Quick Reference Guide
*See Opposite page for Wash ONLY and Dry ONLY Instructions
ATTENTION! Before operating your washer-dryer, read your owners manual. It contains important safety, operation, and maintenance information.
WD2100, WDC6200CEE, WD2000S, WDC5200
Choose A
Dry Time
Select A Wash
Temp.
Add Laundry
Aids
Select A Wash
Program
Rinse
Anti-crease
Anti-crease
Spin
Rinse
Spin
DRY TIME
0'
with cool down
50'
90'
110'
100'
120' 30'
70'
WASH TEMP
WARM
cold rinse only
Auto
Dry
Status /
Door Lock
Extra
Rinse
Low
Spin
Easy
Iron
Pre
Wash
COTTON
HEAVY DUTY
EXPRESS
GENTLE
EXPRESS
WOOL
Delay Start
DELICATES
SUPER
REGULAR
REGULAR
SILK
REGULAR
DRY
DRY
DRY
HOTCOLD
PERMANENT
PRESS
Reset
Reset
Reset
Reset
Rinse
Spin
Drain
Automatic Washer & Vented Dryer
9 Wash Programs - 7 Water Temperatures - 3 Dry Programs - Automatic Balance System - 1200 RPM High Spin
Splendide
12h 9h3h 1h
On/Off 1
3
2
45ABCD
12 3 45
Dry Cycles
(0 min. - 120 min.)
Cotton Heavy Duty Dry
Permanent Press Dry
Delicates Dry
No Dry
Water Temp.
Selections
7
Ranging from HOT
to COLD
Note: Rinse water
temperatures are
always COLD
High Spin
1200 RPM
850 RPM
600 RPM
Time*
(Minutes)
80
70
40
75
65
40
65
60
45
Special Options
(Buttons)
Pre-wash
Low Spin
Extra Rinse
Pre-Wash
Easy Iron
Low Spin
Extra Rinse
Pre-wash
Pre-wash, Easy Iron
No Options
Wash Cycles
Cotton Heavy Duty
Super
Regular
Express
Permanent Press
Regular
Gentle
Express
Delicates
Regular
Silk
Wool/Hand Wash
*Cycle times vary according to water pressure, load size and fabric type.
Is doing laundry different in a
Splendide? Yes. Your Splendide will
save you space, water, electricity, and
detergent while treating your fabrics gentler
and washing them better. Instead of
washing several, bulky loads of laundry one
day a week, you'll learn to wash smaller,
more convenient loads every day or two.
Simply program your washer-dryer to wash
and dry automatically - and let the machine
do the rest!
Why can't I see the water through
the door? Your Splendide uses the latest
in washing technology and needs less than
half the water to get wash results that are
twice as good! In fact, Spendide washer-
dryers are rated top of their class* in terms
of wash performance and energy efficiency.
*Class A Norm EN 60456 Washing Machine
Label Directive 95/72/EC & Energy Star
labeled for energy/resource efficiency.
Any tips for loading the drum?
Remember, in separate w/d's, dryer drums
are 2x larger than washer drums. In your
Splendide, you wash and dry in the same
drum. If you wash full loads, you'll need to
remove some items (up to 50%) before
starting a dry program. When you program
your machine to wash then dry automatically,
load the drum according to the
recommended load sizes for drying and your
desired dry time. (For more information
about loading your washer-dryer's drum, see
"Choosing a Load," pg. 12, in your owners
manual.)
How can I optimize my dry times?
Never overload the drum. Also, using 1-2
tbsp. of a liquid fabric softener (or a detergent
w/ built-in softener) during the wash cycle will
not only shorten dry times, but reduce fabric
wrinkling. (If you own one of Splendide's
Comb-o-matic models, see "A Special Note
About Condenser Drying," -pg.15 in your
owners manual for more info.)
When can I open the door?
At the end of a cycle (or if you "Reset" a dry
cycle), the Status/Door Lock LED flashes
quickly indicating that the program is finished
(or canceled) but the door is still locked.
When it flashes slowly, the door can safely
be opened. Note: Door may remain locked
for up to 1-2 minutes.
Quick Reference Guide
Program Chart and Frequently Asked Questions (See Your Owners Manual For More Information)
WD2100, WDC6200CEE, WD2000S, WDC5200
4
How Do I Dry ONLY?
1. With the machine OFF, Select a Dry
Cycle (See Right)
2. Set the Dry Time knob to desired time
3. Press "ON"
How Do I Wash ONLY?
1. With the machine OFF, Select a Wash
Cycle
2. Set the Dry Time knob to "0" min.
3. Press "ON"
Splendide®
Where's the load size selector?
Your Splendide has a built-in Automatic
Consumption Control feature that
automatically adjusts the water used for the
size and fabric type of your load. No
guesswork, perfect every time.
Rinse
Anti-crease
Anti-crease
Spin
Rinse
Spin
50'
COTTON
HEAVY DUTY
EXPRESS
GENTLE
EXPRESS
WOOL
Delay Start
DELICATES
SUPER
REGULAR
REGULAR
SILK
REGULAR
DRY
DRY
DRY
PERMANENT
PRESS
Reset
Reset
Reset
Reset
Rinse
Spin
Drain
12h 9h 3h 1h
