Sportsman GEN85KIDF User manual

ITEM # GEN85KIDF
8750 Surge Watts / 7000 Running Watts
DUAL FUEL INVERTOR GENERATOR INSTRUCTION MANUAL
READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT.
This manual provides important information on proper operation & maintenance. Every effort has been made to ensure
the accuracy of this manual. These instructions are not meant to cover every possible condition and situation that may
occur. We reserve the right to change this product at any time without prior notice.
HAVE QUESTIONS OR PROBLEMS? CONTACT CUSTOMER SERVICE
If you experience a problem or need parts for this product, visit our website http://www.buffalotools.com or call
customer service at 1-866-460-9436, Monday-Friday, 8 AM - 4 PM Central Time. A copy of the sales receipt is
required. IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE, DO NOT OPERATE
THIS PRODUCT!
FOR CONSUMER USE ONLY – NOT FOR PROFESSIONAL USE.
KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE WARRANTY FOR FUTURE
REFERENCE.
Q
ATTENTION: OIL AND GASOLINE IS NOT INCLUDED WITH
THE GENERATOR AND MUST BE ADDED BEFORE FIRST USE.
ATTENTION: THIS GENERATOR IS NOT INTENDED TO
POWER MEDICAL DEVICES OR LIFE SUPPORT APPLIANCES.
ATTENTION: FOLLOW ENGINE BREAK-IN PROCEDURE FOR
FIRST 20 HOURS OF USE.
ATTENTION: DO NOT EXCEED MAX WATTAGE CAPACITY,
OTHERWISE DAMAGE CAN OCCUR TO GENERATOR AND/OR
APPLIANCES. FOLLOW WATTAGE GUIDE TO DETERMINE
PROPER STARTING & RUNNING WATTS.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
2
GEN85KIDF Portable Dual Fuel Invertor Generator
FEATURES:
•8750 Surge Watts / 7000 Running Watts*
•4-Stroke OHV Engine 420cc
•Recoil / Electric Start
•15 HP Dual Fuel Engine
•(Propane Tank Not Included)
• 1 - 12V D/C Outlet
• 4 - 120V A/C Outlets
• 1 - 120V/240V RV Outlet
•Engine Run Time: 10 Hours @ 50% Load Gasoline Fuel
•Engine Run Time: 6 Hours @ 50% Load on 20 lbs of LPG Fuel
•Low Oil Shutdown
•EPA Approved
•Noise Level: 70dB @ 0% Load at 23 ft
•Oil Capacity: 33.8 ounces
•Fuel Capacity: 7 gallon
•Fuel type - Liquid Propane Gas (commonly referred to as LP, LPG and Propane) Or Unleaded Gasoline with octane rating 87 or higher
•This portable generator is not for use with gasoline/ ethanol blends with over 15% ethanol. Do not use E85 fuel.
•3,600 RPM
•USB Port
•Battery Cable Included (Used for Electric Start) (Battery Power Pack sold separately)
•Mobility Kit Not Available
•High Altitude Use: This generator is not recommended for high altitude use above 3,000 feet.
•If you are using a generator above sea level, the generator may not function properly because of air flow getting through the mixer.
* SURGE WATTS / RUNNING WATTS MAY BE REDUCED BY 10% WHEN USING PROPANE FUEL VS USING GASOLINE.
AC Output
Rated Voltage (V)
120/240
Rated Watts (W)
7000
Rated Frequency (Hz)
60
Phase
Single
DC Output
Voltage (V)
12
Circuit Breaker Amperage (A)
8
Engine
Engine Type
4-stroke single cylinder with forced air cooling system
Ignition System
Non-contact transistor (T.C.I.)
Starting System
Recoil
SEEK THE ADVISE OF A LICENSED
ELECTRICIAN FOR 120V / 240V
WIRING

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
3
TABLE OF CONTENTS
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS...............................................................................................4
PACKAGE CONTENTS
PACKAGE CONTENTS ...........................................................................................................................................9
COMPONENTS .....................................................................................................................................................10
PREPARING THE GENERATOR FOR USE ....................................................................................................................11
Using This Generator For The First Time...............................................................................................................11
Step 1 – Add Oil ............................................................................................................................................11
Step 2 – Add Gasoline / Propane..................................................................................................................12
Step 3 – Ground The Generator....................................................................................................................13
Subsequent Use Of This Generator.......................................................................................................................13
Step 1 – Verify Oil Level................................................................................................................................13
Step 2 – Verify Gas Level..............................................................................................................................13
Step 3 – Ground The Generator....................................................................................................................14
STARTING THE GENERATOR ........................................................................................................................................15
USING THE GENERATOR...............................................................................................................................................16
AC Usage...............................................................................................................................................................16
DC Usage...............................................................................................................................................................17
USB Usage ............................................................................................................................................................17
INVERTER GENERATOR ................................................................................................................................................18
BREAK-IN PERIOD ..........................................................................................................................................................18
STOPPING THE GENERATOR........................................................................................................................................20
MAINTENANCE/CARE .....................................................................................................................................................20
Recommended Maintenance Schedule .................................................................................................................20
Cleaning The Generator.........................................................................................................................................20
Checking The Oil Level ..........................................................................................................................................21
Changing/Adding Oil ..............................................................................................................................................21
Air Filter Maintenance ............................................................................................................................................22
Spark Plug Maintenance ........................................................................................................................................22
Changing Fuel Line ................................................................................................................................................22
Emptying The Fuel Tank ........................................................................................................................................22
STORAGE/TRANSPORT PROCEDURES .......................................................................................................................23
TROUBLESHOOTING ......................................................................................................................................................24
PARTS DIAGRAM ............................................................................................................................................................26
WIRING DIAGRAM ...........................................................................................................................................................30
EMISSION CONTROL SYSTEM WARRANTY.................................................................................................................31

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
4
RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS
What You Need to Know About Safety Instructions
Warning and Important Safety Instructions appearing in this manual are not meant to cover all possible conditions and situations
that may occur. Common sense, caution and care must be exercised when operating or cleaning tools and equipment.
Always contact your dealer, distributor, service agent or manufacturer about problems or conditions you do not understand.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate injury.
CAUTION used without the safety alert symbol indicates a
potentially hazardous situation which, if not avoided, may
result in property damage.
2 YEAR LIMITED EMISSION-RELATED WARRANTY
THIS ENGINE MEETS U.S. EPA EMISSION STANDARDS UNDER 40 CFR 1054.625 .The emission-related limited warranty is valid for two (2)
years. Keep the purchase receipt and mail in the product registration card for proof of purchase. Buffalo Corp limits emission-related warranty
repairs to authorized service centers for owners located within 100 miles of an authorized service center. For owners located more than 100
miles from an authorized service center, Buffalo Corp will, in its sole discretion, either pay for shipping costs to and from an authorized service
center, provide for a service technician to come to the owner to make the warranty repair, or pay for the repair to be made at a local non-
authorized service center. The provisions of this paragraph apply only for the contiguous states, excluding the states with high-altitude areas
identified in 40 CFR part 1068, Appendix III.
To exercise this warranty, DO NOT RETURN TO RETAILER. Instead, call Customer Service toll free at 1-866-460-9436 (email address
[e-mail]) and you will be instructed on where to take the engine for warranty service. Take the generator and proof of purchase
(your receipt) to the repair facility recommended by the Customer Service Representative. The warranty does not extend to generators damaged
or affected by fuel contamination, accidents, neglect, misuse, unauthorized alterations, use in an application for which the product was not
designed and any other modifications or abuse.
1 YEAR LIMITED WARRANTY (30 Day Limited Warranty for Commercial and Rental Purpose)
Generators are warranted to be free from defects in materials and workmanship for a period of 1 YEAR from date of original purchase. Buffalo
Corp. is not liable for any indirect, incidental or consequential damages from the sale or use of this product. Any implied warranties are limited to
1 YEAR as stated, or as otherwise stated, in this written limited warranty. Some states do not allow the exclusion or limitation of incidental or
consequential damages. Some states do not allow limitation on the length of an implied warranty. Buffalo Corp will repair or replace, at its
discretion, any part that is proven to be defective in materials or workmanship under normal use during the 1 YEAR warranty period. Warranty
repairs or replacements will be made without charge for parts or labor. Parts replaced during warranty repairs will be considered as part of the
original product and will have the same warranty period as the original product. This warranty gives you specific legal rights, and you may have
other rights that vary state to state.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
5
Notice Regarding Emissions:
Engines certified to comply with U.S. EPA emission regulations for SORE (Small Off Road Equipment) are certified to operate on
regular unleaded gasoline and may include the following emission control systems: Three-Way Catalyst (TWC) (if equipped), and Engine
Modifications (EM).
Legal Requirements:
Federal and/or State Occupational Safety and Health Administration (OSHA) regulations, local codes, and/or ordinances may apply to the
intended use of this generator. Consult a qualified electrician, electrical inspector, and/or the local agency having jurisdiction. Some areas require
generators to be registered with local utility companies. Additional regulations may apply if this generator will be used at a construction site.
IMPORTANT SAFETY INSTRUCTIONS
STOP!
Before using this generator and if you have any questions regarding the hazard and safety notices listed in this manual and/or on this
generator, call 1-866-460-9436, Monday - Friday, 8 AM - 4 PM Central Time.
WARNING: If this generator will be connected to a building electrical system, you must consult your local utility company or a qualified
electrician. Connections must isolate generator power from utility power and must comply with all applicable laws and codes. You are
responsible for ensuring that your generator’s electricity does not feed back into the electric utility power lines. Do not plug the
generator into any electric outlet in your home.
WARNING: Do not use this generator to provide power for emergency medical equipment or life support devices.
Carbon Monoxide Gas: When in operation, the exhaust from this generator contains poisonous carbon monoxide gas. Carbon monoxide
gas is both odorless and colorless AND may be present even if you do not see or smell gas. Breathing this poison gas can lead to
headaches, dizziness, drowsiness, loss of consciousness and eventually death.
Propane (LPG): This generator may emit highly flammable and explosive vapors, which can cause severe burns or even death. A nearby
open flame can lead to an explosion even if not directly in contact the fuel.
• Do not operate this generator near open flame.
• Always operate this generator on a firm, level surface.
This fuel is highly flammable and explosive. Handling fuel can result in serious injury or burns.
• Before starting the generator, inspect your LPG tank valve for damage or leaks, attach only approved tanks that have been properly filled by an
approved station. DO NOT light or smoke cigarettes.
Replace the hose at the first sign of a leak or if age-cracking becomes apparent.
• Always handle propane fuel and generator outdoors.
• Before transporting, turn the fuel valve to the "off" position and disconnect the spark plug.
WARNING: ONLY USE THIS GENERATOR OUTDOORS IN NON-CONFINED AREAS. DO NOT SECURE THE GENERATOR WITH A CHAIN
OR ROPE, AS THIS WILL MAKE IT DIFFICULT TO MOVE IN AN EMERGENCY.
• Keep at least several feet of clearance on all sides to allow proper ventilation for this generator.
Usage: Avoid the use of extension cords if possible. If you choose to use them, be sure they are sized adequately to handle the flow of
electricity. An undersized cord can overheat, short out and cause a fire.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
6
Powerful Voltage: This generator produces powerful voltage, which can result in electrocution.
• ALWAYS ground this generator before using it. (See “Ground the Generator” section in this manual).
• Only electrical devices should be plugged into this generator, either directly or with an extension cord. NEVER connect a building electrical
system to this generator without a qualified electrician. Doing so voids your warranty.Such connections must isolate generator power from utility
power and comply with local electrical laws and codes. Failure to comply can create a back feed into utility lines creating an electrocution hazard,
which may result in serious injury or death to utility workers. Such a back feed may cause this generator to explode, burn and create fires when
utility power is restored.
• Use a ground fault circuit interrupter (GFCI) in highly conductive areas such as metal decking or steel work. GFCIs are available in-line with some
extension cords.
• Keep generator dry and operate with dry hands. Do not use this generator in wet conditions (rain, snow, active sprinkler system, wet hands, etc.).
• Do not touch bare wires or outlets (receptacles).
• Do not allow children or non-qualified persons to operate this generator.
Flammable Gasoline: This generator may emit highly flammable and explosive gasoline vapors, which can cause severe burns or even
death. A nearby open flame can lead to an explosion even if not directly in contact with gasoline.
• Do not operate this generator near open flame.
• Do not smoke near this generator.
• Always operate this generator on a firm, level surface.
Gasoline is highly flammable and explosive. Handling fuel can result in serious injury or burns.
• Always shut down this generator before refueling. Refuel in a well-ventilated area. Keep heat, sparks and flame away while refueling and away
from the location where gasoline is stored. Never refuel indoors where gasoline fumes may reach flames and/or sparks.
• Allow this generator to cool for at least 2 minutes before removing the fuel tank cap. Loosen the cap slowly to relieve pressure in the fuel tank.
Avoid spilling fuel.
• Do not fill the fuel tank above the upper limit line. Gasoline may expand during operation. Do not fill to the top of the tank.
• Always check for spilled gasoline and immediately wipe it up before starting this generator.
• Empty the fuel tank before storing or transporting this generator.
• Always handle fuel outdoors.
• Before transporting, turn the fuel valve to the “OFF” position and disconnect the spark plug.
High Temperatures: This generator produces heat when in operation. Temperatures near the exhaust can exceed 150 Degrees
Fahrenheit (65 Degrees Celsius).
• Do not touch hot surfaces. Observe all warning placards on this generator denoting hot surfaces.
• Allow this generator to cool for several minutes after use before touching the engine, muffler or other areas that are hot during operation and
before storing indoors.
• Hot exhaust may ignite some materials. Keep flammable materials away from this generator.
• Keep at least several feet of clearance on all sides of this generator during operation. Do not enclose this generator in any structure.
Usage: Consult a physician(s) before using this generator if using a pacemaker. Electromagnetic fields in close proximity to a heart
pacemaker could cause a pacemaker to malfunction or fail. Caution is necessary when near the engine’s recoil starter.
Usage: Prolonged exposure to high noise levels can be hazardous to hearing. Always wear ANSI-approved hearing protection when
operating or working around the generator when it is running.
Usage: Misuse of this generator can damage it or shorten its life. Use this generator only for its intended purpose.
• Operate this generator only on a dry, level surface. Do not secure the generator with a chain or rope, which would prevent it from being moved in
an emergency.
• Allow this generator to run for several minutes before connecting any electrical devices.
• Promptly turn off any malfunctioning devices and disconnect them.
• Do not operate an excessive number of electrical devices in excess of the wattage capacity of this generator.
• Do not turn on electrical devices until after they are connected to this generator.
• Turn off all connected electrical devices before stopping this generator.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
7

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
8
In addition to the previously described safety information, familiarize yourself with all safety and hazard placards on this generator.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
9
PACKAGE CONTENTS
The following items are supplied with this Generator. Verify that all items are included.
STOP!
If there are missing items, call 1-866-460-9436, Monday - Friday, 8 AM - 4 PM Central Time for customer service.
Item List:
DC connector wires for charging 12 Volt automotive-type batteries
Spark plug wrench
5 ft 9 inch Regulator Hose Kit
(YOU MUST USE THE SUPPLIED REGULATOR FOR SAFE OPERATION)
Cable for Portable Jump Starter Battery Power Pack

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
10
1) Fuel Tank Cap
2) Control Panel
3) Recoil Starter
4) Fuel Cock (not shown)
5) Oil Access
6) Spark Plug
7) Fuel Selector
8) Air Filter Cover
9) AC Circuit Protector
10) 12 Volt DC Outlet
11) DC Circuit Protector
12) USB Port
13) Alert Indicator
14) Engine Power Switch
15) Economy Switch
16) LP gas inlet
17) Carburetor Choke Lever
18) Power Supply Port
19) 120/240 Volt RV Outlet
20) 120 Volt AC GFCI Outlet
21) Grounding Terminal
GENERATOR COMPONENTS
Observe the locations and functions of the various components and controls of this generator.
15
1
2
14
16
11
7
20
12
9
10
17
2
3
18
19
13
5
4
8
6
9
20
21
1

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
11
PREPARING THE GENERATOR FOR USE
Using this Generator for the First-Time
STOP!
The following section describes the required steps for preparing this generator for the first use. Failure to correctly perform these
steps can damage this generator and/or shorten its life. If still unsure about how to perform any of these steps after reading this
section, call 1-866-460-9436 Monday - Friday, 8 AM - 4 PM Central Time for customer service.
If this generator is being used for the first time, the following few steps are required to prepare it for operation:
Step 1 - Add Oil
THIS GENERATOR REQUIRES AT LEAST 33.8 OUNCES OF OIL (SAE10W-30) TO RUN.
ADD OIL UNTIL IT IS ALMOST OVERFLOWING. THE LOW-OIL SENSOR IS VERY SENSITIVE AND THE ENGINE
WILL NOT RUN IF THE OIL IS LOW. START WITH 33.8 OUNCES, THEN ADD MORE UNTIL ALMOST
OVERFLOWING.
TROUBLESHOOTING: IF THE GENERATOR WILL NOT START, DOUBLE CHECK THAT THE OIL LEVEL IS
COMPLETELY FULL AND ALMOST OVERFLOWING.
This generator requires engine oil to function. Engine oil is a major factor affecting engine performance and service life. When new
from the package, this generator contains no oil in the engine crankcase. Add oil before operating this generator for the first time. When
replenishing oil for subsequent use of this generator, always determine that this generator has the correct quantity of oil.
To add oil to the engine crankcase:
1. Confirm that this generator is on a level surface.
2. Unscrew the oil filler/dipstick cap from the (Figure 1).
3. Using a funnel, add high detergent motor oil to fill the engine crankcase to the correct quantity. SAE10W-30 oil is recommended for general
use. When the engine crankcase is full and almost overflowing, the oil level should reach the lower lip of the oil filling opening as shown in
Figure 2.
4. Replace the oil filler/dipstick cap.
Figure 2 - Add Oil
Figure 1 – Figure 1
Oil Dipstick Cap

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
12
Step 2 - Add Gasoline or Connect Propane Tank
Gasoline and gasoline fumes are highly flammable and explosive. Handling fuel can result in serious injury or burns.
• Do not fill the fuel tank near a heat, sparks or an open flame. Keep gasoline away from appliance pilot lights, barbecues, electric appliances, power
tools, etc.
• Do not overfill the fuel tank. Always check for fuel spills and immediately wipe them up. Spilled fuel is a fire hazard and causes environmental
damage.
To add gasoline:
To ensure that this generator runs smoothly, use only FRESH, UNLEADED GASOLINE WITH AN OCTANE RATING OF 87 OR HIGHER.
Unleaded gasoline produces fewer engine and spark plug deposits and extends the life of the exhaust system.
1. Confirm that this generator is on a level surface.
2. Unscrew fuel tank cap and set aside. (NOTE: The fuel tank cap may be tight and difficult to unscrew.)
3. Slowly add fresh, unleaded gasoline (with an octane rating 87 or higher) to the fuel tank. Be careful not to fill the fuel tank above the upper limit
line. NOTE: Because gasoline can expand, do not fill the fuel tank to the very top.
4. Securely tighten the fuel tank cap and immediately wipe up any spilled gasoline with a dry cloth.
Fuel Tank Capacity (gallons)
7
Fuel Type
Fresh, Unleaded Gasoline Octane Rating 87 or Higher
IMPORTANT:
• Use only UNLEADED gasoline with an octane rating of 87 or higher.
• Never use a mixture of oil and gasoline.
• Never use old and/or contaminated gasoline.
• Avoid getting dirt and/or water in the fuel tank.
• Gasoline can age in the fuel tank and make it difficult to start this generator. Never store this generator for extended time with gasoline in the
fuel tank.
To connect propane:
If using LPG, first connect the regulator that was included with the generator to
the Propane Fuel Tank, then connect the other end to the Gas Inlet. Make sure
the LPG cylinder is vertical and securely positioned.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
13
Step 3 - Ground the Generator
Failure to properly ground this generator can result in electrocution.
Ground this generator by tightening the grounding nut against a grounding wire as illustrated in Figure 3. A No. 12 AWG (American Wire Gauge)
stranded copper wire is generally an acceptable grounding wire. The other end of this grounding wire should be connected to a copper or brass
grounding rod that is driven into the earth.
Grounding codes can vary by location. Contact a local electrician for information on grounding regulations for your area.
Subsequent Use of this Generator
For subsequent uses of this generator after the first use, certain steps still must be completed to prepare it for operation.
IMPORTANT: Be familiar with the procedures described in the previous section titled “Using the Generator for the First Time” of this
manual. If not, review this section now.
Step 1 - Verify Oil Level
It is important to check the oil level in the engine crankcase before each use to ensure that there is sufficient quantity.
1. Verify that this generator is on a level surface.
2. Unscrew the oil filler/dipstick cap from the engine.
3. With a dry cloth, wipe the oil off of the dipstick that is located on the inside of the cap.
4. Fully insert the dipstick without screwing the filler/dipstick cap and then remove again. There should be oil on the dipstick. If there is no oil on
the dipstick, or oil is visible only at the very end of the dipstick, add oil until the engine crankcase is filled. (See “Changing/Adding Oil” in the
“Maintenance/Care” section of this manual).
5. Confirm that the oil filler/dipstick cap is properly screwed in place when finished verifying the oil level.
Step 2 - Verify Gas Level If Using Gasoline Fuel
Before starting this generator, verify that there is sufficient gasoline in the fuel tank. If necessary, add fresh unleaded gasoline with an octane
rating of 87 or higher according to “Step 2 - Add Gasoline” of the “Using this Generator for the First Time” section of this manual.
Fuel Tank Capacity (gallons)
7
Fuel Type
Fresh, Unleaded Gasoline Octane Rating 87 or Higher
Figure 3
The Grounding Terminal is
located on the base of the
generator frame.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
14
Gasoline and gasoline fumes are highly flammable and explosive. Handling fuel can result in serious injury or burns.
• Do not fill the fuel tank near a heat, sparks or an open flame. Keep gasoline away from appliance pilot lights, barbecues, electric appliances, power
tools, etc.
• Always allow several minutes for the engine to cool before refueling.
• Do not overfill the fuel tank. Always check for fuel spills and immediately wipe them up. Spilled fuel is a fire hazard and causes environmental
damage.
IMPORTANT:
• Use only fresh UNLEADED gasoline with an octane rating of 87 or higher.
• Never use old and/or contaminated gasoline.
• Never use a mixture of oil and gasoline.
• Avoid getting dirt and/or water in the fuel tank.
• Never store generator for extended time with gasoline in the fuel tank.
Step 3 - Ground the Generator
Failure to properly ground this generator can result in electrocution.
Ground this generator by tightening the grounding nut against a grounding wire as previously illustrated in Figure 3. A generally acceptable
grounding wire is a No. 12 AWG (American Wire Gauge) stranded copper wire. The other end of this grounding wire should be connected to a
copper or brass grounding rod that is driven into the earth.
Grounding codes can vary by location. Contact a local electrician for information on grounding regulations for your area.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
15
STARTING THE GENERATOR
STOP!
Before starting this generator, confirm all the steps in the section titled, “Preparing the Generator for Use,” of this manual have been correctly
completed. If unsure about how to perform these steps, call 1-866-460-9436, Monday - Friday, 8 AM - 4 PM Central Time for customer service.
Disconnect all electrical loads from this generator before attempting to start.
A Power Pack Cable Is Included. Portable Jump Starter Battery Power Pack Is Not Included
Use a multi-function Portable Jump Starter Battery Power Pack with a capacity of at least 6,000 mAh.
(Sold separately. Call 1-866-460-9436 for additional information.)
This generator includes one Power Pack Cable. Insert one end of Red (Positive) cable into the Positive
receptacle of Battery Power Pack, then insert one end of Black (Negative) cable into the Negative receptacle of
Battery Power Pack. Then insert the Red (Positive) end into Positive receptacle of generator and Black
(Negative) into the Negative receptacle of generator.
Press the POWER switch on the Battery Power Pack, then press the generator POWER switch to the START
position, until the generator has started. DO NOT CONNECT electrical devices until AFTER the generator is
started.
To start this generator:
1. Confirm that there are no electrical devices connected to this generator. Connected devices may increase the difficulty in starting the engine.
2. Confirm that this generator is properly grounded. (See “Ground the Generator”
section of this manual.)
3A. If using gasoline, select GAS/LP switch to GAS, then turn the fuel switch to
the “on” position.
3B. If using propane, select GAS/LP switch to LPG, then turn the fuel switch to
the “off” position.
4. Pull the choke lever towards you.
5. Set the engine switch to the “on” position.
6A. For recoil start: Slowly pull on the recoil starter handle, shown in Figure 4, until a slight resistance is felt. Then pull briskly to start the engine.
Gently return the cord into the generator to avoid damage to the starter or housing. Never allow the cord to snap back.
6B. For electric start: Push the Power Switch rocker to START position and hold until engine starts. If the engine fails to start within five seconds,
release and wait at least 5 seconds before attempting to start the engine again.
7. If the engine fails to start, repeat step 6.
NOTE: After repeated attempts to start the engine, consult the troubleshooting guide before attempting again. If problems persist,
call 1-866-460-9436, Monday - Friday, 8 AM - 4 PM Central Time.
8. Once the engine has started, GRADUALLY push the choke lever until the engine levels off. Then let the engine run
approximately 5 minutes BEFORE adding appliances or tools. DO NOT CONNECT electrical devices until AFTER the generator is started.
Choke Rod
The choke is used to provide an enriched fuel mixture when starting a cold engine.
It can be opened and closed by operating the choke rod manually.
Figure 4
The Recoil Start is located on
the right side of the generator.
Choke OUT/OFF To Start
Choke IN/ON To Run
Choke Rod

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
16
USING THE GENERATOR
• USE THIS GENERATOR ONLY OUTDOORS IN NON-CONFINED AREAS. DO NOT SECURE THE GENERATOR WITH A CHAIN OR ROPE, AS
THIS WILL MAKE IT DIFFICULT TO MOVE IN AN EMERGENCY.
• Keep at least several feet of clearance on all sides to allow proper ventilation for this generator.
After the engine has been running for several minutes, electrical devices may be connected to this generator.
AC Usage
Electrical devices running on AC current may be connected according to their wattage requirements.
Rated (Running) Wattage
7000
Surge Wattage
8750
* SURGE WATTS / RUNNING WATTS MAY BE REDUCED BY 10%
WHEN USING PROPANE FUEL VS USING GASOLINE.
The rated (running) wattage corresponds to the maximum wattage a generator can output on a continuous basis.
The surge wattage corresponds to the maximum amount of power a generator can output for a short time. Many electrical devices, such as a
refrigerator, require short bursts of extra power for starting and stopping fan motors, etc., in addition to their listed rated wattage. Motorized
devices typically require more than their rated wattage for startup. The surge wattage ability of a generator allows for this extra power
requirement.
The total running wattage requirement of the electrical devices connected to a generator should not exceed the rated wattage of the generator
itself. To calculate the total wattage requirement of the electrical devices to be connected, look up the rated (running) wattage of each device and
add these numbers together to find the total wattage that all of the devices together will draw from the generator. If the total wattage of the
selected devices exceeds the rated wattage of the generator, DO NOT connect all of the devices. Select a combination of the electrical devices
that will have a total wattage less than or equal to the rated wattage for the generator.
This generator can run at its surge wattage capacity for only a short time. Connect electrical devices requiring a rated (running) wattage
equal to or less than the rated wattage of this generator. Never connect devices requiring a rated wattage equal to the surge wattage of a
generator.
A device's rated (running) wattage should be listed somewhere on the device itself and/or in its manual. If the wattage specification for a device is
not available, the wattage can be calculated by multiplying the Voltage requirement (120) by the Amperage drawn.
Watts = Volts x Amperes
Or, the wattage required by a device can be estimated by using the following chart. The chart provides only estimates and it is better to know the
exact wattage of each electrical device to be powered by this generator.
NOTE: Plug appliances into the correct outlet.
Connect standard 120 Volt, single phase, 60 Hz
loads to the 120 Volt outlet. Connect 12 Volt, DC
loads to the 12 Volt outlet.
Electrical Device
Rated (Running) Watts
Additional Surge Watts
air compressor (1 - 1/2 HP)
2500
2500
airless sprayer (1/3 HP)
600
1200
coffee maker
1500
0
computer w/17 inch monitor
800
0
deep freezer
500
500
electric drill (1/2 HP)
1000
1000
furnace fan blower (1/2 HP)
800
1300
hot plate
2500
0
microwave oven (1000 watt)
1000
0
quartz halogen work light
1000
0
refrigerator/freezer (18 Cu. Ft.)
800
1600
saw - circular (7 1/4 inch)
1500
1500
stereo receiver
450
0
electric stove - single element
1500
0
sump pump
800
1200
television (27 inch color)
500
0
well water pump (1/3 HP)
1000
2000
window air conditioner (10000 BTU)
1200
1800
window fan
300
600
Connect only electrical devices that are in good
working order. Faulty devices or power cords
present the risk of electrical shock. Immediately
turn off and disconnect any device that
commences to operate abnormally, sluggish or
abruptly stops. Determine if the problem was the
device or the rated load capacity of this generator
has been exceeded.
Figure 5 - Estimated wattage requirements for
common electrical devices

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
17
Even though this generator has an overall rated wattage of 8750, do not attempt to draw more than 7000 Watts from the 120 Volt outlet.
Draws higher than 7000 Watts will damage this generator and void the warranty.
NOTE: While this generator is running, power is available from either the standard 120 Volt outlet or the 12 Volt DC outlet. Both 120 Volts and 12
Volts can be simultaneously drawn from this generator.
Turn on the connected electrical devices beginning with the device with the highest rated wattage requirement and then each additional device
with the next lower rated wattage requirement.
Do not connect 50Hz or 3-phase loads to this generator.
DC Usage
•The DC outlet is for charging 12 Volt battery, up to 8 Amps.
•NEVER attempt to jumpstart a car with this generator.
Do not secure the generator with a chain or rope, which would prevent it from being moved in an emergency.
To Plug Items Into the Generator
1. Allow the engine to run for several minutes after it has been started.
2. Confirm that the electrical device is switched off prior to plugging it into this generator.
3. Turn on the connected electrical devices beginning with the device with the highest rated wattage requirement and then each additional device
with the next lower rated wattage requirement.
To Plug Items Into the USB
The generator offers convenient (5V DC 2.0 A) USB outlet to allow charging of USB devices like tablets, MP3 players, GPS, digital cameras and
other USB chargeable devices. Allow the engine to run for several minutes after it has been started before plugging in a USB cable for charging.
Engine Overload Indicator Light
If the engine overload indicator light comes on, the generator s wattage / amperage capacity has been exceeded by connected electrical devices
or by a power surge. When this occurs, the green AC Pilot Indicator Light will go off. The engine will continue to run, (but the red Engine
Overload Indicator Light will stay on and power will no longer be supplied to connected electronic devices.
AC Pilot Indicator Light
The green AC Pilot Indicator Light comes on when the engine starts and generates power.
DC Circuit Breaker
When the DC Circuit Breaker is in the “ON” position, the generator is able to supply power to connected electronic devices. When the DC Circuit
Breaker is in the “OFF” position, the generator will no longer supply power. The DC Circuit Breaker automatically turns “OFF” when connecting
electronic devices to the generator that exceed the generator’s rated output. If the DC Circuit Breaker turns off, reduce the load of connected
electronic devices until the load is within the specified rated output. To re-establish power, return the DC Circuit Breaker back to the “ON” position
Smart Throttle Control Switch
When the Smart Throttle Control switch is turned to the “ON” position, the economy control unit automatically determines the generator’s proper
engine speed based on the connected electronic load. This results in superior fuel economy and reduces noise. When the Smart Throttle switch
is turned to the “OFF” position, the engine runs at the rated speed of 3,600 r/min. Note: The Smart Throttle switch must be turned to the “OFF”
position when using electronic devices that require a large starting current, such as a compressor.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
18
INVERTER GENERATOR WITH SINE WAVE
This inverter generator eliminates power fluctuations like the ones you see in standard generators. It offers stable, consistent power.
Power from inverter generators is ultra-clean, and comes in a form that is useful for sensitive electronic equipment. It is clean enough to run
even the most sensitive electronic equipment.
Inverter generators can reduce fuel consumption, and they are often quieter than a traditional generator.
ENGINE BREAK-IN PROCEDURE
You can avoid small engine problems if you follow the break-in procedure below. Because the pistons and rings wear into the engine’s walls,
small pieces of metal can flake off into the oil. It’s important to flush these pieces out of your generator by frequently changing the oil. Maintain at
least a 50-75 percent load on your generator for the first 20 hours (Do not operate the engine at full load during the first 20 hours of operation.)
Varying the load will help seat the rings.
1. Allow the engine to run for 5 minutes before adding any load.
2. Change the break-in oil within the first 5 hours of use
3. Do not operate the engine at full load during the first 20 hours of operation.
4. Read and follow the Maintenance/Care section of this Generator manual.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
19
SOME NOTES ABOUT POWER CORDS
Long or thin cords can require more wattage from a generator to power an electrical device. Figure 6 shows the recommended cords according
to the power requirement of the electrical device. When using cords that exceed these specifications, allow for the electrical
device to have a slightly higher rated wattage requirement.
Device Requirements
Max. Cord Length (ft) by Wire Gauge
Amps
Watts (120V)
Watts (240V)
#8 wire
#10 wire
#12 wire
#14 wire
#16 wire
2.5
300
600
NR
1000
600
375
250
5
600
1200
NR
500
300
200
125
7.5
900
1800
NR
350
200
125
100
10
1200
2400
NR
250
150
100
50
15
1800
3600
NR
150
100
65
NR
20
2400
4800
175
125
75
50
NR
25
3000
6000
150
100
60
NR
NR
30
3600
7200
125
65
NR
NR
NR
40
4800
9600
90
NR
NR
NR
NR
Figure 6 - Maximum Extension Cord Lengths by Power Requirement
SWITCHING BETWEEN GASOLINE & PROPANE FUEL
In order to switch between gasoline and propane fuel, you must turn off the current fuel.
For example, if using gasoline and you want to switch to propane, turn the gasoline Fuel Switch to OFF position and turn the propane tank to ON.
Then select the FUEL SELECTOR SWITCH to LPG. If using propane and you want to switch to gasoline, turn the gas Fuel Switch to ON and
select the FUEL SELECTOR SWITCH to GAS. Then turn the propane tank OFF.

Item # GEN85KIDF Portable Dual Fuel Invertor Generator
20
STOPPING THE GENERATOR
To stop this generator:
1. Turn off all connected electrical devices and then unplug them.
2. Allow this generator to run for several more minutes with no electrical devices connected to help stabilize the temperature of this generator.
3. If using gasoline, turn the fuel valve to the “OFF” position.
4. Set the engine power switch to the “OFF” position.
5. If using Propane, turn the propane tank fuel valve to the “off” position, then turn off the engine power switch.
Allow this generator to cool down before touching areas that become hot during operation.
Allowing gasoline to sit in this generator's fuel tank for extended time without use can increase the difficulty in starting this generator in
the future. Never store this generator for extended time with gasoline in the fuel tank.
MAINTENANCE/CARE
Proper routine maintenance of this generator is essential for safe, economical, and trouble-free operation. It will help prolong the life of this
generator as well as help reduce air pollution. Perform maintenance checks and procedures according to the schedule in Figure 7.
Never perform maintenance procedures while this generator is running. Allow this generator to cool before commencing any maintenance
procedures. Keep heat, sparks and flame away.
Improper maintenance and/or failure to correct any problems prior to operating this generator can cause a malfunction which could cause
death or serious injury. Always follow the inspection and maintenance recommendations and schedules in this manual.
Recommended Maintenance Schedule
Each Use
Every Month or
Each 20 Hrs
Every 3 Months or
Each 50 Hrs
Every 6 Months or
Each 100 Hrs
Every Year or
Each 300 Hrs
Engine Oil
Check Level
X
Replace
X (first use)
X
Air Filter
Check
X
Clean
X
Spark Plug
Check/Clean
X
Fuel Tank
Verify Gas Level
X
Clean
X
Figure 7 - Recommended maintenance schedule
Cleaning the Generator
Always try to use this generator in a cool dry place. If this generator becomes dirty, the exterior can be cleaned with a damp cloth, soft brush,
vacuum and/or pressurized air.
Never clean this generator with a bucket of water and/or a hose as water can get inside and cause a short circuit or corrosion.
Never use gasoline to clean parts of this generator.
