Spring Well SS+ User manual

1
SALT-BASED WATER SOFTENER
MODELS: SS1, SS4, SS+
Installation Instructions
CUSTOMER SERVICE IS AVAILABLE MON-FRI 9AM-6PM EST
800-589-5592
WWW.SPRINGWELLWATER.COM
Our traditional salt-based whole house water softeners
are the most reliable ion exchange softeners on the
market today. Use 40% less detergent, extend the life of
your appliances see less spotting on hard surfaces. All
with an industry-leading warranty!

"
2
Additional Parts Included
1. Electronic Head
2. 50’ Drain Line
3. Brine Tank
4. Hose Clamp




1
2
3
4
8
PLEASE READ INSTRUCTIONS FULLY BEFORE INSTALLATION.
Be sure to follow all applicable plumbing codes. The system must be
installed on main water supply line.
CAUTION: Do not install on well water unless you have spoken to a
customer service representative first.
NOTE: This system does require electricity.
If the tank is not perfectly straight, carefully lift the tank straight up a few
inches and tap it on the ground until the tank stands vertical and fits
snuggly into the tank boot.

3
Product Specs
SS1
Tank Width
9”
Tank Height
48” (57” with head)
Flow Rate
11 GPM Service
Connection Size
3/4”
Backwash Rate
2 GPM
Operating Pressure
25-80 PSI
Operating Temperatures
36 - 120 F
pH Range
6.5 - 10
Grain
32K
Brine Tank
18”(w) x 33” (h)
SS4
Tank Width
10”
Tank Height
54” (63” with head)
Flow Rate
13 GPM Service
Connection Size
3/4”
Backwash Rate
2.4 GPM
Operating Pressure
25-80 PSI
Operating Temperatures
36 - 120 F
pH Range
6.5 - 10
Grain
48K
Brine Tank
18”(w) x 33” (h)
SS+
Tank Width
13”
Tank Height
54” (63” with head)
Flow Rate
20 GPM Service
Connection Size
3/4”
Backwash Rate
4 GPM
Operating Pressure
25-80 PSI
Operating Temperatures
36 - 150 F
pH Range
6.5 - 10
Grain
80K
Brine Tank
18”(w) x 33” (h)
For replacement filters, please visit: www.springwellwater.com/replacements

#



4
Installation Instructions
Locate main tank box and unpack the tank. Next find the brine tank box and
unpack the brine tank. Inside the brine tank you will find the parts and the
electronic head.
Remove the gray cap on top of the main tank. Remove the blue cap from the
distributor tube. Place the electronic head on top of distributor tube and press
down, then screw down hand tight.

#
#
5
Determine the area where you want to install your system. Be sure there is an
electrical outlet for the electronic head. Set the brine tank next to the main tank.
At this point you are ready to plumb the system into the main plumbing supply.
Follow the arrows on top of the bypass valve to determine the flow of the water.
Adapt your plumbing in and through the head.
Now finish by plumbing back into your main water supply.
(Example using SharkBite Fittings)




6
Brine Tank Setup
Take the lid off of the brine tank and set it aside. Now remove the white cap on
top of the brine tank float assembly and set aside. Locate the black brine draw
line coming off the side of the electronic head and insert into the opening on the
float assembly. Push it in until it stops. (If you need to remove it hold the gray
tab with a flat head screwdriver then pull the black line out.) Now put the white
cap back on the float assembly. Now you can add salt pellets to the brine tank.
5-6 50lb bags is sufficient. The tank will hold up to 375 lbs if you wish to fill it up.
Do not add water. Now you can put the lid back on the brine tank.

#


7
Connect Drain Line
Locate the drain line. Connect the drain line to the white barb fitting on the
electronic head. Slip the drain line over the barb then secure it with the hose
clamp provided. Run the drain line to a drain or to the outside. Cut the
excess off.
Now take the excess drain line and use it on the brine tank drain. Push it up the
barb. There is no need for a clamp here as it is not under pressure, it will only be
for overflow if the float fails in the brine tank.

8
1. Hold up or down button until you get to 12:01 PM.
2. Hit the regen button once to set time.
3. Hold the up and down arrows at the same time until it reads DF GAL.
4. Hit regen button should read VT df 1b.
5. Hit regen button should read CT Fd.
6. Hit regen button should read NT ——— 1.
7. Hit regen button should read C then a number. Hit up or down button
until you get to your number. Model# SWSS0948 you put 32. Model#
SWSS1054 you put 48. Model# SWSS1354 you put 80.
8. Hit regen button should read H 20. Hit up or down arrow to whatever
the hardness of your water is.
9. Hit regen button should read RS rc. Hit up or down button to get to SF.
10. Hit regen button should say SF 10.
11. Hit regen button should say DO 14.
12. Hit regen button should say RT 2:00.
13. Hit regen button should say BW 10.
14. Hit regen button should say BD 60.
15. Hit regen button should say RR 10.
16. Hit regen button should say BF then a number. Hit up or down button
until you get to your number. Model# SWSS0948 you put 8. Model#
SWSS1054 you put 10. Model# SWSS1354 you put 16.
17. Hit regen button should read FM t0.7.
18. Hit regen again should go back to time of day.
Setting The Electronic Head
Plug the electronic head into the outlet and it will automatically come on. To set
the head the time must always be on 12:01 PM.
At this point you can now set the correct time of day, then hit regen button and it
will all be set.

#
9
Turning Main Water Back On
Before you turn the water back on be sure metal tabs are fastened to the
edges and screws are tightened all the way down.

(on position)


10
Finish The Install:
Now that the water is back on check for leaks and make sure there are none.
Check drain hose and make sure it’s in the drain or run to the outside. It’s time
now to do a manual regeneration of the system. At this time you can’t use water
as the system will be using the water. On the head simply hold down the regen
button until you hear it start then release the button. This will take about one and
a half hours.
Install is Complete!

11
Warranty Information
For more information on our warranty, please visit www.springwellwater.com/warranty/
