Providing accuracy, adjustability, energy efficiency and styling to our
quality line of hot water equipment
• Digitalthermostatprovidesconsistentandaccuratetemperaturesof
60º-212ºF(15.6º-100ºC).
• Newcontemporary,space-savingdesign.
• LEDdisplayprovidessimpletemperatureadjustment.
• Programmable“EnergySaverMode”reducesoperatingcostduringidle
periods.
• Thinsulate®tankinsulationprovidesincreasedenergyefciency.
• Theperfecttoolforaddedcontroloverqualitycoffeeandtea.
H5E/H5X Element - Custom Colors
Dimensions:28.5”Hx7.1”Wx17.5”D
(72.4cm H x 18.03cm W x 44.5cm D)
Model Agency Listing
H5EElement
H5XElement
ULLISTED
5 Gallon Element
Hot Water Dispenser - Custom Colors
Easy Clear®EQHP-10
ProductNo.:39000.0004
Easy Clear®EQHP-10L
ProductNo.:39000.0001
1. Wall Mount Bracket (side)
ProductNo.:12542.0000
 Dimensions:30"Hx131⁄2"Wx41⁄2"D
 76.2cmHx34.29cmWx11.43cmD
2. Wall Mount Bracket (front)
ProductNo.:13125.0001
 Dimensions:301⁄2"Hx81⁄2"Wx151⁄4"D
 77.47cmHx21.59cmWx38.74cmD
3. Container Holding Shelf
ProductNo.:12599.0000
 Dimensions:63⁄4"Wx21"D
 17.15cmWx53.34cmD
4. Drip Tray
ProductNo.:02497.0000
ULLISTED

BUNN®practicescontinuousproductresearchandimprovement.Wereservetherighttochangespecicationsandproductdesignwithoutnotice.Such
revisionsdonotentitlethebuyertocorrespondingchanges,improvements,additionsorreplacementsforpreviouslypurchasedequipment.
Alldimensionsshownininches.
Dimensions & Specifications
Bunn-O-Matic®Corporation-1400StevensonDriveSpringeld,Illinois62703•800-637-8606•217-529-6601•Fax217-529-6644•www.bunn.com
Model Product # Volts Amps Total ˚F Gal./Hr. Gal./Hr. Cu. Shipping Cord
Watts Settings
cold water hot water Ft. Weight Attached
input 35˚ input 140˚
H5E-40-208White 43600.0007 208 19.5 4050 200  4.1 ft3  32lbs. No
H5X-40-208White 43600.0011 208 19.5 4050 212 7.3 14.7 4.1
ft3  32lbs. No
H5E-40-208Red 43600.0004 208 19.5 4050 200   4.1
ft3  32lbs. No
H5X-40-208Red 43600.0008 208 19.5 4050 212 7.3 14.7 4.1
ft3  32lbs. No
H5E-40-208Copper 43600.0005 208 19.5 4050 200   4.1
ft3  32lbs. No
H5X-40-208Copper 43600.0009 208 19.5 4050 212 7.3 14.7 4.1
ft3  32lbs. No
H5E-40-208 Black 43600.0006 208 19.5 4050 200   4.1
ft3  32lbs. No
H5X-40-208Black 43600.0010 208 19.5 4050 212 7.3 14.7 4.1
ft3  32lbs. No
Electrical:Allmodelsrequire2-wiresplusgroundservice,208V,single-phase,60Hz.
Suppliedstrainreliefonrearsideofmachine.
Plumbing:20-90psi(138-621kPa).Machinesuppliedwith1⁄4"ODmalearetting.
