Springtree HD200RGBW User manual

USER MANUAL AND
INSTALLATION GUIDE
Springtree
HD200RGBW LED
Ellipsoidal

2(615) 599-1505 www.springtree.net
Table of Contents
1. Before You Begin
What is included.......................................................................................................................3
Safety precautions....................................................................................................................3
2. Product Information
Description................................................................................................................................4
Features....................................................................................................................................4
3. Installation
Power supply.............................................................................................................................5
Mounting....................................................................................................................................5
Adjusting the shutters................................................................................................................6
Using a gobo.............................................................................................................................6
 Usingagelorlter.....................................................................................................................6
DMX linking...............................................................................................................................7
4. Operation
Touch buttons...........................................................................................................................7
Operating modes......................................................................................................................7
LED display menu.....................................................................................................................8
DMX Modes..............................................................................................................................9
5. Maintenance
Cleaning your ellipsoidal..........................................................................................................10
6. Technical Specications
Troubleshooting.......................................................................................................................10
Dimensions..............................................................................................................................11
Warranty...................................................................................................................................12
Contact us...............................................................................................................................12

3
[phone] www.springtree.net
Before You Begin
What is included
When you open your package, there should
be four items inside of the box:
1. One LED Ellipsoidal light with
a 19°, 26° or 36° lens
2. One gobo holder
3. One gel frame
4. One Powercon power cord
*If any of these items is damaged or missing,
please contact Springtree Media Group.
Safety Precautions
•Toreducetheriskofelectricalshockorre,donotexposethisunittomoisture.
• Be sure that the local power outlet matches that of the required voltage for your unit
• Do not attempt to operate this unit if the power cord has been frayed or broken. Do not attempt
 toremoveorbreako󰀨thegroundprongfromtheelectricalcord.Thisprongisusedto
 reducetheriskofelectricalshockandreincaseofaninternalshort.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user serviceable parts inside.
• Never plug this unit into a dimmer pack.
• Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6”
between this device and a wall.
•ThisxtureisintendedforindooruseONLY.
• During long periods of non-use disconnect the units main power.
• Always mount this unit in a safe and stable manner.
• Keep this manual for as long as you own this product!
3.
4.
2.
1.
2.

4(615) 599-1505 www.springtree.net
• 200W RGBW LED
• Digital Display
• Interchangeable 19°, 26° or 36° lenses
• Lightweight 13lb body
• Three pin XLR jacks
• 5 DMX Modes (4 chan, 6 chan, 7 chan, 8
chan and 10 chan)
• Gobo holder
• Gel frame
• 4 shutters for controlled spotlighting
• Linking Powercon IN/OUT
Features
Description
The Springtree HD200RGBW LED
Ellipsoidalisapowerfulxturesuitable
for theatrical performance halls, schools
and houses of worship. With this versatile
instrument,youcangetmanydi󰀨erentuses
fromonesinglexture.Youcancontrolthe
size, shape, edge and intensity of the beam
of light.
Product Information

5
[phone] www.springtree.net
Power Supply
Before plugging your unit in, be sure the source voltage in your area matches the voltage
required for your lighting setup. Every unit has a power supply capable of 120V. Because line volt-
age may vary from venue to venue, you should be sure your unit voltage matches the wall outlet
voltage before attempting to operate your unit.
* Always connect this product to a protected circuit with an appropriate electrical ground to
avoidtheriskofelectrocutionorre.
Mounting
When mounting your ellipsoidal, make sure there is adequate room for ventilation. Operating
inaninsu󰀩cientlyventilatedroomcanleadtoanoverheatingofthedeviceandmaycauseserious
accidents. Keep a minimum distance of 6 inches around and above the device. Before
deciding on a location, mount in a way that it will be easy to access the unit for maintenance and
addressing.
Installation

6(615) 599-1505 www.springtree.net
Adjusting the shutters
To adjust the width and shape of the beam, simply push or pull any of the four shutters
located around the body of the ellipsoidal.
Gel frame
Framing shutter
(top)
Framing shutter
(left)
Framing shutter
(bottom)
Using a gobo
If you want to shape your light with a gobo,
insert it into the included gobo holder so that it is
visible through the circular hole. In order for your
gobo to be projected correctly, it should be inserted
upsidedownandipped.Afteryou’veinserted
your gobo into the holder, screw the holder shut
so that the gobo is secure and does not move. Slide the holder into the slot located in front of the
top shutter. When removing the gobo, make sure to let it cool before handling.
Using a gel or lter
To alter the color of your light
beam insert a gel into the included
gel frame. Screw the frame closed
so that the gel is secure and does
not move. Slide the holder into
the slots located in front of the lens.
When removing the gel and
holder, make sure to let it
cool before handling.
To look like this Insert like this
Gobo holder

7
[phone] www.springtree.net
DMX linking
An LED Ellipsoidal can be connected to a DMX controller by a 3-pin DMX cable, allowing
total control over one or more lights. To do this, connect an DMX cable from the DMX-input (labeled
DMX IN) on your lighting unit to the DMX-output of the controller. Connect a second light via its
DMX-inputtotherstunit’sDMX-output(labeledDMXOUT)tocontrolandsynchronizemultiple
lighting units at once. DMX IN
DMX IN DMX IN
DMX OUT DMX OUT
Operation
Touch buttons
There are four touch buttons on the back of this unit: MENU, UP, DOWN and ENTER. Normally
theLEDwilldisplaythecurrentDMXaddresscodeofthexture.PressMENUtochoosethede-
siredfunctionandpressENTERtoconrm.
Operating modes
This light can operate in 3 modes:
• DMX control mode- this function will allow you to control each individual unit with a standard
DMX 512 controller
• Master-slave mode- one unit will work as the master and other units in the chain will work in
synchronization towards the master.
• Stand Alone- each ellipsoidal will operate in a manual stand alone mode. No DMX wire nec-
essary.

8(615) 599-1505 www.springtree.net
Operation - Menu/DMXTraits
DMX Address
001-512
4CH
6CH
7CH
8CH
10CH
Program 1
Dim
000-255
Program 2
Speed
000-255
Program 3
Program 4
Program 5
Color Off
000-005
Color1~46
006-255
Dimmer
000-255
Strobe
0~30Hz
Red
000-255
Green
000-255
Blue
000-255
WarmWhite
000-255
On
Display reverse display
Off
normal display
On
The display stays on
Off Turn off automatically after one minute
Hold
Keep the last state
Blackout
Black out
ManualMode
Standard
Stage
TV
Architectural
Theatre
Stage2
Dimmer Speed 0.1-0.9s ~ 1-10S
On
The display automatically locks the screen
after one minute. The lock screen can
also be manually locked: press
simultaneously Hold "up" "down" 5
seconds.
After the screen is locked, the middle of
the display is displayed: Locked.
Off
Turn off screen lock
900Hz
1000Hz
1100Hz
1200Hz
1300Hz
1400Hz
1500Hz
2500Hz
4000Hz
5000Hz
6000Hz
10000Hz
Reset Reset to all factory setting Passcode = 11
Code: down, down,
down, up, down,
down,down, up
Calibration Passcode = 50
Code: down, up,
down, up, down,
down, down, down.
Firmware
V1.0
Software version number
Operation Hours xxxHrs How many hours the lamp has been
running
Temperature
xxx°C
MENU Functions
System Info
DMX Mode
Stand Alone
Auto
Manual
Settings
ColorMacro
Service
Display Reverse
Display Backlight
DMX Fail
Dimmer Curve
AutoLock
PWM Rate

9
[phone] www.springtree.net
4 CH 6 CH 7 CH 8 CH 10 CH VALUES FUNCTIONS
11111
000-255 RED
0%-100%
22222
000-255 GREEN
0%-100%
33333
000-255 BLUE
0%-100%
44444
000-255 WHITE
0%-100%
COLOR MACROS
000-007 No Effect
008~255 Color 1 ~46
SHUTTER & STROBING
000-031 LED Off
032-063 LED On
064-095 Strobing Slow - Fast
096-127 LED On
128-159 Pulse Strobing
160-191 LED On
192-223 Random Strobing Slow - Fast
224-255 LED On
5667
000-255 MASTER DIMMER
0%-100%
6778
000-255 DIMMER FINE
0%-100%
DIMMER MODES
000-020 Standard
021-040 Stage
041-060 TV
061-080 Architectural
081-100 Theatre
101-120 Stage 2
DIMMER DELAY TIME
121 0.1Sec.
122 0.2Sec.
123 0.3Sec.
124 0.4Sec.
125 0.5Sec.
126 0.6Sec.
127 0.7Sec.
128 0.8Sec.
129 0.9Sec.
130 1.0Sec.
131 1.5Sec.
132 2.0Sec.
133 3.0Sec.
134 4.0Sec.
135 5.0Sec.
136 6.0Sec.
137 7.0Sec.
138 8.0Sec.
139 9.0Sec.
140 10Sec.
141-255 Default to Unit Setting
REFRESH RATE
000-015 Default to Unit Setting
016-035 900HZ
036-055 1000HZ
056-075 1100HZ
076-095 1200HZ
096-115 1300HZ
116-135 1400HZ
136-155 1500HZ
156-175 2500HZ
176-195 4000HZ
196-215 5000HZ
216-235 6000HZ
236-255 10000HZ
5
6
9
10
5
8
5

10 [phone] www.springtree.net
Maintenance
Cleaning your ellipsoidal
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses must be
carried out periodically to optimize light output.
  1.Usenormalglasscleanerandasoftclothtowipeo󰀨theoutsidecasing.
2. Clean the external optics with glass cleaner and a soft cloth every 20 days.
3. Always be sure to dry all parts completely before plugging the unit back in.
*Cleaning frequency depends on the environment in which
the unit operates (i.e. smoke, fog residue, dust, dew).
Troubleshooting
Listed below are a few common problems that you may encounter
when using this product:
Unit not responding to DMX:
1. Check that the DMX cables are
connected properly and are
wired correctly. DMX output DMX input
2. Check that all cables are connected to the right connectors; it does matter
which way the inputs and outputs are connected.

11
[phone] www.springtree.net
 TechnicalSpecications
• Power Supply: AC120V, 50/60Hz
• Power Consumption: Max. 200W
• LED: RGBW COB
• Flicker Free
• ElectronicStrobe:1-20ash/s
• Display: 4-digit LED
• Data In/Out: XLR 3Pin
• Switch Power Supply: Built-in and auto switching
• Cooling: Entire casing heat sink plus 2 fans
• Housing: Plastic
• Housing Color: Black
• IP Rating: IP20
• Environment Temp: -30°C-50°C
• Dimensions(mm): L25in x W6.5in
• Net Weight: 13lbs
Dimensions:

12 [phone] www.springtree.net
 Ocehours:
Monday-Friday, 8:30
AM to 5:00 PM CT
Telephone:
[phone]
E-mail:
[email protected]
Website:
www.springtree.net
Contact us
Springtree Media Group would like to thank you for choosing our company for
your lighting needs! If you have any questions or concerns, please contact us.
WARRANTY
1st YEAR - Parts and labor. Advanced replacement - First 90 days with shipping
covered by Springtree Media.
2nd YEAR - Repair/ Replace Springtree discretion. Return shipping covered by
customer.
