Springtree HD200WW LED User manual

USER MANUAL AND
INSTALLATION GUIDE
Springtree
Prole HD200 WW
LED Ellipsoidal

2(615) 599-1505 www.springtree.net
Table of Contents
1. Before You Begin
What is included.......................................................................................................................3
Safety precautions....................................................................................................................3
2. Product Information
Description................................................................................................................................4
Features....................................................................................................................................4
3. Installation
Power supply.............................................................................................................................5
Mounting....................................................................................................................................5
4. Operation
Touch buttons...........................................................................................................................6
LED display menu.................................................................................................................6-8
DMX linking...............................................................................................................................8
Adjusting the shutters................................................................................................................9
Using a gobo.............................................................................................................................9
 Usingagelorlter.....................................................................................................................9
5. Maintenance
Cleaning your ellipsoidal..........................................................................................................10
Troubleshooting.......................................................................................................................10
6. Technical Specications
Beam angles............................................................................................................................11
Dimensions..............................................................................................................................11
Warranty...................................................................................................................................12
Contact us...............................................................................................................................12

3
[phone] www.springtree.net
Before You Begin
What is included
When you open your package, there should
be four items inside of the box:
1. One LED Ellipsoidal light with
a 19°, 26°, or 36° lens
2. One gobo holder
3. One gel frame
4. One Powercon power cord
*If any of these items is damaged or missing,
please contact Springtree Media Group.
Safety precautions
•Toreducetheriskofelectricalshockorre,donotexposethisunittomoisture.
• Be sure that the local power outlet matches that of the required voltage for your unit
• Do not attempt to operate this unit if the power cord has been frayed or broken. Do not attempt
 toremoveorbreako󰀨thegroundprongfromtheelectricalcord.Thisprongisusedto
 reducetheriskofelectricalshockandreincaseofaninternalshort.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user serviceable parts inside.
• Never plug this unit into a dimmer pack.
• Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6”
between this device and a wall.
•ThisxtureisintendedforindooruseONLY.
• During long periods of non-use disconnect the unit main power.
• Always mount this unit in a safe and stable matter.
• Keep this manual for as long as you own this product!
1.
3.
4.
2.

4(615) 599-1505 www.springtree.net
• 200W Warm White LED COB
• Digital Display
• Interchangeable 19°, 26°, or 36° lenses
• Lightweight 13 lb body
• Three pin XLR jacks
• 3 DMX Modes (1 chan, 2 chan and 4 chan)
• Gobo holder
• Gel frame
• 4 shutters for controlled spotlighting
• Linking Powercon IN/OUT
Product Information
Features
Description
 TheSpringtreeProleHD200WW
LED Ellipsoidal is a powerful, versatile
xturewithalloftheprofessionalfeatures
found on higher priced units.

5
[phone] www.springtree.net
Power Supply
Before plugging your unit in, be sure the source voltage in your area matches the voltage
required for your lighting setup. Every unit has a power supply capable of 120V. Because line volt-
age may vary from venue to venue, you should be sure your unit voltage matches the wall outlet
voltage before attempting to operate your unit.
* Always connect this product to a protected circuit with an appropriate electrical ground to
avoidtheriskofelectrocutionorre.
Mounting
When mounting your ellipsoidal, make sure there is adequate room for ventilation. Operating
inaninsu󰀩cientlyventilatedroomcanleadtoanoverheatingofthedeviceandmaycauseserious
accidents. Keep a minimum distance of 6 inches around and above the device. Before
deciding on a location, mount in a way that it will be easy to access the unit for maintenance and
addressing.
Installation

6(615) 599-1505 www.springtree.net
LED display menu
Operation
Touch buttons
There are four touch buttons on the back of this unit: MENU, ENTER, UP and DOWN.. Normally
theLEDwilldisplaythecurrentDMXaddresscodeofthexture.PressMENUtochoosethede-
siredfunctionandpressENTERtoconrm.
Menu
Up and Down will also scroll thru Menu Options
System Info
(Enter)
Firmware (Enter)- Firmware Version Displayed
Hours (Enter) – Hours of use displayed
DMX Address
(Enter)
Up/Down Select (Enter)
Options: 1-512
DMX Mode
(Enter)
Select 1 Ch, 2 Ch, 4 Ch (Enter)
1 Ch. 1- Dimmer
2 Ch. 1- Dimmer
2- Strobe
4Ch 1- Dimmer
2- Strobe
3- Dimmer Mode 0-126 LED
127-255 Halogen
4- Dimmer Curves 0-005 No Function
006-063 Linear
064-127 Exponential
128-191 Logarithmic
192-255 S-Curve
Slave
(Enter)
Up/Down Select (Enter)
Options: Yes
No
Stand Alone
(Enter)
Static (Enter)
Dimmer 1-255 (Enter)
Dimmer Fine 1-255 (Enter)
Strobe 1-255 (Enter)

7
[phone] www.springtree.net
LED display menu cont.
Menu
Up and Down will also scroll thru Menu Options
System Info
(Enter)
Firmware (Enter)- Firmware Version Displayed
Hours (Enter) – Hours of use displayed
DMX Address
(Enter)
Up/Down Select (Enter)
Options: 1-512
DMX Mode
(Enter)
Select 1 Ch, 2 Ch, 4 Ch (Enter)
1 Ch. 1- Dimmer
2 Ch. 1- Dimmer
2- Strobe
4Ch 1- Dimmer
2- Strobe
3- Dimmer Mode 0-126 LED
127-255 Halogen
4- Dimmer Curves 0-005 No Function
006-063 Linear
064-127 Exponential
128-191 Logarithmic
192-255 S-Curve
Slave
(Enter)
Up/Down Select (Enter)
Options: Yes
No
Stand Alone
(Enter)
Static (Enter)
Dimmer 1-255 (Enter)
Dimmer Fine 1-255 (Enter)
Strobe 1-255 (Enter)
Settings
(Enter)
Display Reverse
Up/Down Select (Enter)
On/Off (Enter)
Frequency (Enter) (LED PWM frequency for video)
Up/Down Select (Enter)
Options: 3 KHz
6 KHz
12 KHz
24 KHz
Gamma Correction (Enter) (color dimming ratio for video)
Up/Down Select (Enter)
Options: No
2
2.2
2.4
Factory Reset (Enter)
Reset (Enter)
Auto Lock (Enter)
Up/Down Select (Enter) To Lock/ Unlock hold
Up and Down for 5 sec.
Options: On
Off
Dimmer Response (Enter)
Up/Down Select (Enter)
Options: LED
Halogen
Dimmer Curve (Enter)
Up/Down Select (Enter)
Options: S-Curve
Logarithmic
Exponential
Linear
DMX Fail (Enter)
Up/Down Select (Enter)
Options: Blackout
Hold
Emergency Light
Display Blackout (Enter)
Up/Down Select (Enter)
Options: On
Off

8(615) 599-1505 www.springtree.net
LED display menu cont.
DMX linking
An LED Ellipsoidal can be connected to a DMX controller by a 3-pin XLR cable, allowing total
control over one or more lights. To do this, connect an XLR cable from the DMX-input (labeled DMX
IN) on your lighting unit to the DMX-output of the controller. Connect a second light via its DMX-in-
puttotherstunit’sDMX-output(labeledDMX OUT) to control and synchronize muiltiple lighting
units at once. DMX IN
DMX IN DMX IN
DMX OUT DMX OUT
Settings
(Enter)
Display Reverse
Up/Down Select (Enter)
On/Off (Enter)
Frequency (Enter) (LED PWM frequency for video)
Up/Down Select (Enter)
Options: 3 KHz
6 KHz
12 KHz
24 KHz
Gamma Correction (Enter) (color dimming ratio for video)
Up/Down Select (Enter)
Options: No
2
2.2
2.4
Factory Reset (Enter)
Reset (Enter)
Auto Lock (Enter)
Up/Down Select (Enter) To Lock/ Unlock hold
Up and Down for 5 sec.
Options: On
Off
Dimmer Response (Enter)
Up/Down Select (Enter)
Options: LED
Halogen
Dimmer Curve (Enter)
Up/Down Select (Enter)
Options: S-Curve
Logarithmic
Exponential
Linear
DMX Fail (Enter)
Up/Down Select (Enter)
Options: Blackout
Hold
Emergency Light
Display Blackout (Enter)
Up/Down Select (Enter)
Options: On
Off

9
[phone] www.springtree.net
Adjusting the shutters
To adjust the width and shape of the beam, simply push or pull any of the four shutters
located around the body of the ellipsoidal.
Gobo holder
Gel frame
Framing shutter
Using a gobo
If you want to shape your light with a gobo,
insert it into the included gobo holder so that it is
visible through the circular hole. Slide the holder
into the slot located in front of the top shutter.
In order for your gobo to be projected correctly,
itshouldbeinsertedupsidedownandipped.
Afteryou’veinsertedyourgobointotheholder,screwtheholdershutsothatthegoboissecure
and does not move. When removing the gobo, make sure to let it cool before handling.
To look like this Insert like this
Using a gel or lter
To alter the color of your light beam
insert a gel into the included gel frame.
Screw the frame closed so that the
gel is secure and does not move.
Slide the holder into the slots
located in front of the lens.
When removing the gel and
holder, make sure to let it
cool before handling.

10 [phone] www.springtree.net
Maintenance
Cleaning your ellipsoidal
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses must be
carried out periodically to optimize light output.
  1.Usenormalglasscleanerandasoftclothtowipeo󰀨theoutsidecasing.
2. Clean the external optics with glass cleaner and a soft cloth every 20 days.
3. Always be sure to dry all parts completely before plugging the unit back in.
*Cleaning frequency depends on the environment in which
the unit operates (i.e. smoke, fog residue, dust, dew).
Troubleshooting
Listed below are a few common problems that you may encounter
when using this product:
Unit not responding to DMX:
1. Check that the DMX cables are
connected properly and are
wired correctly. DMX output DMX input
2. Check that all cables are connected to the right connectors; it does matter
which way the inputs and outputs are connected.

11
[phone] www.springtree.net
Technical Specications
• PowerSupply:AC120V,50/60Hz
• Power Consumption: Max. 200W
• LED: WW COB
• Display: LED
• Data In/Out: XLR 3Pin
• Switch Power Supply: Built-in and auto switching
• Cooling: Entire casing heat sink plus 2 fans
• Housing:Plastic
• HousingColor:Black
• IP Rating: IP20
• Environment Temp: -30°C-50°C with single yolk
• Dimensions(mm):L24.25xW8.25xH6.5
• Net Weight: 13 lbs
Dimensions:
Beam Angles:
24.25 in
23.75 in
8.25 in
10.5 in
18 in
6.5 in

12 [phone] www.springtree.net
 Ocehours:
Monday-Friday, 8:30
AM to 5:00 PM CT
Telephone:
[phone]
E-mail:
[email protected]
Website:
www.springtree.net
Contact us
Springtree Media Group would like to thank you for choosing our company for
your lighting needs! If you have any questions or concerns, please contact us.
WARRANTY
1st YEAR - Parts and labor. Advanced replacement including shipping covered by
Springtree Media.
2nd YEAR - Repair/ Replace Springtree discretion. Return shipping covered by
customer.
