Spruce 28098 User manual

Page 1 of 4 IN019-1 Rev B
( RB110 )

Page 2 of 4 IN019-1 Rev B
Dryer Boost Kit
Installation Instructions
IN019-1 Rev B
1.0 Auxiliary Fan Location
The auxiliary fan should be mounted with a minimum of 15 feet of ductwork from the outlet of the dryer to the inlet of the fan.
Failure to observe this distance may result in excessive lint build-up in the fan unit!
2.0 Auxiliary Fan Mounting
2.1). Install Mounting Bracket as shown. Attach the fan to the mounting bracket with (2) self-tapping
screws, provided, Avoid over tightening screws.
2.2) Attach bracket to mounting structure with the 1 1/4” screws provided. Connect the ductwork
between the outlet of the dryer and the inlet of the fan. Connect the outlet of the fan to the
termination ductwork. Seal the connections with duct tape or similar means.
3.0 Automatic Pressure Switch Installation
The pressure switch must be mounted vertically on a wall surface as near the outlet
of the dryer as possible. Mount the duct probe through the duct and connect with
tubing provided to the pressure switch.
Insure the arrow on the duct probe points toward the dryer and away from the
auxiliary fan to prevent lint from closing the probe.
4.0 Electrical Wiring
Electrical connection should be performed by a qualified person in accordance with all local, state and national electrical codes.
Make electrical connections to the pressure switch and auxiliary fan as shown in the following schematic:

Page 3 of 4 IN019-1 Rev B
5.0 Installation Troubleshooting
If the auxiliary fan fails to start when the dryer cycle begins check the following:
Verify the AC voltage at the pressure switch . The pressure switch-point is approximately 0.1” WC. The dryer must generate
this positive pressure to close the switch and start the auxiliary fan. If not, check the probe and connecting tubing for blockage.
You may blow gently into the tubing to check the switch operation.
If the auxiliary fan cycles on and off after the dryer cycle begins check the following:
The auxiliary fan may be generating sufficient negative pressure to overcome the positive pressure generated by the dryer. This
can be verified with a sensitive pressure measuring device or with an AC voltmeter at the pressure switch. Relocate the
auxiliary fan further away from the dryer and recheck.
6.0 Maintenance
Lint may accumulate inside the fan impeller and housing or on the automatic pressure switch probe. Periodic inspection and
cleaning should be performed every (6) months or as required based upon dryer usage.
Disconnect electrical power to the unit prior to inspection or cleaning.
NOTE: Excessive noise or vibration from the auxiliary fan may be an indication of lint buildup inside the fan impeller.

Page 4 of 4 IN019-1 Rev B
IMPORTANT INSTRUCTIONS TO INSTALLER
Inspect the Dryer Boost Kit for shipping damage within 15 days of receipt. Notify Spuce of any damages
immediately. Spruce is not responsible for damages incurred during shipping. However, for your benefit, Spruce
does insure shipments.
Install the Fan and Dryer Boost Kit in accordance with all state and local building codes and state regulations.
Rev. 07/07 B
WARRANTY
Subject to any applicable consumer protection legislation, Spruce Environmental Technologies, Inc. (“Spruce”) warrants that
the Dryer Boost Kit (the “Kit”) will be free from defects in materials and workmanship for a period of one (1) year from the date
of manufacture (the “Warranty Term”).
Warranty claims made during the first thirty days after installation:
Spruce will replace any Kit which fails due to defects in materials or workmanship. The Kit may be returned (at owner’s cost)
to either the point of purchase or the Spruce factory. The point of purchase may require proof of purchase or a bill of sales for
replacement.
Warranty claims made after the first thirty days after installation through the end of the Warranty Term:
Spruce will (at its option) either recondition or replace any Kit which fails due to defects in materials or workmanship. The Kit
must be returned (at owner’s cost) to the Spruce factory.
This Warranty is contingent on installation of the Kit in accordance with the instructions provided. This Warranty does not
apply where any repairs or alterations have been made or attempted by others, or if the unit has been abused or misused.
Warranty does not include damage in shipment unless the damage is due to the negligence of Spruce.
Spruce is not responsible for installation, removal or delivery costs associated with this Warranty.
EXCEPT AS STATED ABOVE, THE KITS ARE PROVIDED WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SPRUCE BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES ARISING OUT OF, OR RELATING TO, THE KIT OR THE PERFORMANCE
THEREOF. SPRUCE’S AGGREGATE LIABILITY HEREUNDER SHALL NOT IN ANY EVENT EXCEED
THE AMOUNT OF THE PURCHASE PRICE OF SAID PRODUCT. THE SOLE AND EXCLUSIVE REMEDY
UNDER THIS WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF THE PRODUCT, TO THE
EXTENT THE SAME DOES NOT MEET WITH SPRUCE’S WARRANTY AS PROVIDED ABOVE.
For service under this Warranty, contact Spruce for a Return Material Authorization (RMA) number and shipping
information. No returns can be accepted without an RMA. If factory return is required, the customer assumes all
shipping cost to and from factory.
Spruce Environmental Technologies, Inc.
3 Saber Way
Ward Hill, MA 01835
TEL. [phone]
FAX [phone]
Record the following information for your records:
Serial No.
Purchase Date
