LG DL 385 Series User manual

OWNER’S MANUAL
DRYER
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
DL*;385** / DL*X420** / DL*X450** / DL*360** / DL*340** / DL*347**
0)/
Rev.0_1222
www.lg.com
Copyright © 2022 LG Electronics Inc. All Rights Reserved.
Scan to see the online manual.
Read this owner’s manual thoroughly before operating the appliance
and keep it handy for reference at all times. This abridged owner's
manual addresses user safety, precautions, and installation
information.
To view the complete owner's manual, you may:
1. Online manual: Visit the LG website at: http://gscs-manual.lge.com/
Total/HQ/GatewayPage/main.html or scan the QR code above; or
2. Printable PDF manual: Visit lg.com and search for your model
number; or
3. Call or write to customer service as provided in your Limited
Warranty.
TUUGGwGXGGmSGkG`SGYWYYGGXaY^Gwt

TABLE OF CONTENTS
2
3 IMPORTANT SAFETY
INSTRUCTIONS
3 READ ALL INSTRUCTIONS BEFORE USE
4 WARNING STATEMENTS
7 CAUTION STATEMENTS
9 PRODUCT OVERVIEW
9 Product Features
12 INSTALLATION
12 Before Installing
13 Choosing the Proper Location
17 Leveling the Appliance
17 Reversing the Door
20 Installing the Vent Kit
21 Stacking the Appliance
21 Venting the Dryer
23 Connecting Gas Dryers
24 Connecting Electric Dryers
25 Connecting the Water Inlet Hose (Steam
models)
26 Final Installation Check
30 OPERATION
30 Before Use
31 Loading the Dryer
32 Options and Extra Functions
33 SMART FUNCTIONS
33 LG ThinQ Application
35 Smart DiagnosisTM Function
37 MAINTENANCE
37 Regular Cleaning
39 TROUBLESHOOTING
39 FAQs
40 Before Calling for Service
46 LIMITED WARRANTY
46 CANADA
TUUGGwGYGGtSGkGX`SGYWYYGG`aX^Ght

3IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Safety for a Dryer
WARNING
Fire Hazard
Failure to follow safety warnings exactly could result in serious injury,
death or property damage.
•Do not install a booster fan in the exhaust duct.
•Install all clothes dryers in accordance with the installation instructions
of the manufacturer of the dryer.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury,
death or property damage.
•Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
•WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any phone in your
building.
- Clear the room, building or area of all occupants.
- Immediately call your gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the fire department.
•Installation and service must be performed by a qualified installer,
service agency or your gas supplier.
TUUGGwGZGGtSGkGX`SGYWYYGG`aX^Ght

4IMPORTANT SAFETY INSTRUCTIONS
Safety Messages
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
follow all safety messages.
WARNING STATEMENTS
WARNING
• To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this
product, follow basic precautions, including the following:
Installation
• Adhere to all industry recommended safety procedures including the use of long-sleeved gloves and
safety glasses.
• Before use, the appliance must be properly installed as described in this manual.
• Connect to a properly rated, protected, and sized power circuit to avoid electrical overload.
WARNING
Risk of Fire
Install the clothes dryer according to the manufacturer’s instructions
and local codes.
•Clothes dryer installation must be performed by a qualified installer.
•Do not install a clothes dryer with flexible plastic venting materials. If
flexible metal (foil type) duct is installed, it must be of a specific type
identified by the appliance manufacturer as suitable for use with
clothes dryers. Flexible venting materials are known to collapse, be
easily crushed, and trap lint. These conditions will obstruct clothes
dryer airflow and increase the risk of fire.
•To reduce the risk of severe injury or death, follow all installation
instructions.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages
will follow the safety alert symbol and either the word WARNING or CAUTION.
WARNING
You may be killed or seriously injured if you do not follow instructions.
CAUTION
You may be injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and
tell you what may happen if the instructions are not followed.
TUUGGwG[GGtSGkGX`SGYWYYGG`aX^Ght

5IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
• The appliance must be installed and electrically grounded by qualified service personnel in accordance
with local codes.
• Disconnect the power cord, house fuse or circuit breaker before installing or servicing the appliance.
• When moving or installing the appliance in a different location, call qualified service personnel for
installation and service.
• Keep packing materials out of the reach of children. Packaging material can be dangerous for children.
There is a risk of suffocation.
• Moving or installation of the appliance requires two or more people.
• This appliance is not designed for maritime use or for mobile installations such as in RVs, trailers, or
aircraft.
• This appliance must be positioned near to an electrical power supply.
• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
• When installing or moving the appliance, be careful not to pinch, crush, or damage the power cord.
• Do not install the appliance in humid spaces.
• Destroy the carton, plastic bag, and other packing materials after the appliance is unpacked. Children
might use them for play. Cartons covered with rugs, bedspreads, or plastic sheets can become airtight
chambers.
• Place the appliance at least 18 inches above the floor for a garage installation.
• Do not use sheet metal screws or other fasteners which extend into the duct that could catch lint and
reduce the efficiency of the exhaust system. Secure all joints with duct tape.
• Use only rigid, semi-rigid or flexible metal 4-inch diameter duct inside the dryer cabinet or for exhausting
to the outside. Use of plastic or other combustible ductwork may cause a fire. Punctured ductwork may
cause a fire if it collapses or becomes otherwise restricted in use or during installation.
• The exhaust duct must be 4 inches (10.2 cm) in diameter with no obstructions. The exhaust duct should
be kept as short as possible. Make sure to clean any old ducts before installing your new dryer.
• Rigid, semi-rigid or flexible metal ducting is recommended for use between the dryer and the wall. All
non-rigid metal transition duct must be UL-listed. Use of other materials for the transition duct could
affect the drying time.
• Ductwork is not provided with the dryer, and you should obtain the necessary ductwork locally. The end
cap should have hinged dampers to prevent backdraft when the dryer is not in use.
• Gas dryers MUST be exhausted to the outside.
• The dryer exhaust system must be exhausted to the outside of the dwelling. If the dryer is not exhausted
outdoors, some fine lint and large amounts of moisture will be expelled into the laundry area. An
accumulation of lint in any area of the home may create a health and fire hazard.
• Do not install near another heat source such as a stove, oven or heater.
• Keep the area around the exhaust opening and adjacent surrounding areas free from the accumulation
of lint, dust, and dirt.
• The appliance must not be supplied through an external switching device, such as a timer, or connected
to a circuit that is regularly switched on and off by a utility.
• Certain internal parts are intentionally not grounded and may present a risk of electronic shock only
during servicing. Service personnel - do not contact the following parts while the appliance is energized:
CONTROL BOARD
Operation
• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has
missing or broken parts, including a damaged cord or plug.
• Repair or immediately replace all power cords that have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage along its length or at either end.
TUUGGwG\GGtSGkGX`SGYWYYGG`aX^Ght

6IMPORTANT SAFETY INSTRUCTIONS
• If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance, unplug
it immediately, and contact an LG Electronics customer information center.
• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight
out from the outlet.
• Do not use an extension cord or adapter with this appliance.
• Do not grasp the power cord or touch the appliance controls with wet hands.
• Do not modify or extend the power cord.
• If the appliance has been submerged, contact an LG Electronics customer information center for
instructions before resuming use.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
• Keep the area underneath and around your appliances free of combustible materials (lint, paper, rags,
etc.), gasoline, chemicals and other flammable vapors and liquids.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety.
• Use this appliance only for its intended purpose.
• Do not abuse, sit on, or stand on the door of the appliance.
• Do not allow children to play on, in or with the appliance. Close supervision of children is necessary when
the appliance is used near children.
• Do not tamper with controls.
• In the event of a gas leak (propane gas, LP gas, etc.) do not operate this or any other appliance. Open a
window or door to ventilate the area immediately.
• Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used
for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not been used for
such a period, before using the appliance turn on all hot water faucets and let the water flow from each
for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
• Fix the drain hose securely in place.
• Do not put oily or greasy clothing, candles or flammable materials on top of the appliance.
• Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of
the fabric softener or product.
• Do not reach into the appliance if the drum is moving.
• Do not dry articles that have been previously cleaned in, washed in, soaked in, soiled with or spotted
with gasoline, dry cleaning solvents, vegetable oil, cooking oil or other flammable or explosive
substances, as they give off vapors that could ignite or explode.
• Do not use heat to dry articles containing foam rubber or similarly textured rubber-like materials.
• Do not store plastic, paper, or clothing that may burn or melt on top of the dryer during operation.
• Gas appliances can cause minor exposure to four potentially hazardous substances, namely benzene,
carbon monoxide, formaldehyde, and soot, caused primarily by the incomplete combustion of natural
gas or LP fuels.
• Properly adjusted dryers will minimize incomplete combustion. Exposure to these substances can be
minimized further by properly venting the dryer to the outdoors.
• Always check the inside of the appliance for foreign objects before operating.
• Do not place items exposed to cooking oils in your appliance. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a load to catch fire. To reduce the risk of fire due to
contaminated loads, the final part of a tumble dryer cycle occurs without heat (cool down period). Avoid
stopping a tumble dryer before the end of the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated.
• Do not let children or pets climb inside the dryer drum.
TUUGGwG]GGtSGkGX`SGYWYYGG`aX^Ght

7IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
• Do not put living animals such as pets inside the appliance.
• Do not put any part of your body, such as your hands or feet, or metal objects under the appliance.
• Do not let your hand get pinched when opening or closing the dryer door.
Maintenance
• Do not repair or replace any part of the appliance. All repairs and servicing must be performed by
qualified service personnel unless specifically recommended in this Owner’s Manual. Use only
authorized factory parts
• Do not disassemble or repair the appliance by yourself.
• Remove any dust or foreign matter from the power plug pins.
• Disconnect this appliance from the power supply before cleaning and attempting any user maintenance.
Turning the controls to the OFF position does not disconnect this appliance from the power supply.
• Remove the door before the appliance is removed from service or discarded to avoid the danger of
children or small animals getting trapped inside.
• Unplug the appliance before cleaning to avoid the risk of electric shock.
• The interior of the appliance and exhaust duct should be cleaned periodically by qualified service
personnel.
• Certain internal parts are intentionally not grounded and may present a risk of electronic shock only
during servicing. Service personnel - do not contact the following parts while the appliance is energized:
CONTROL BOARD
Steam (Steam models)
• Do not open the dryer door during a STEAM CYCLE.
• Do not touch the steam nozzle in the drum during or after a STEAM CYCLE.
• On models with a steam feeder tank, do not fill the steam feeder with hot water (over 86 ૢ/ 30 ૟),
gasoline, dry cleaning solvents, or other flammable or explosive substances.
Grounding Instructions
• Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check
with a qualified electrician or service personnel if you are in doubt whether the appliance is properly
grounded. Do not modify the plug provided with the appliance; if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
• The appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least resistance for electric current. The appliance is
equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must
be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes
and ordinances.
• The appliance must be plugged into a properly grounded outlet. Electrical shock may result if the
appliance is not properly grounded. Have the wall outlet and circuit checked by a qualified electrician to
make sure the outlet is properly grounded. Failure to follow these instructions may create an electric
shock hazard and/or a fire hazard.
CAUTION STATEMENTS
CAUTION
• To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or
property when using this product, follow basic precautions, including the following:
TUUGGwG^GGtSGkGX`SGYWYYGG`aX^Ght

8IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Installation
• Install the appliance on a firm and level floor.
• Store and install the appliance where it will not be exposed to temperatures below freezing or exposed
to outdoor weather conditions.
Operation
• Clean the lint filter before or after each load.
• Do not use fabric softeners or products to eliminate static unless recommended by the manufacturer of
the fabric softener or product.
• If the drain hose is frozen in winter, thaw it out before use.
TUUGGwG_GGtSGkGX`SGYWYYGG`aX^Ght

9PRODUCT OVERVIEW
ENGLISH
PRODUCT OVERVIEW
Product Features
The images in this guide may be different from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
Front View
aControl Panel
bLint filters
cLeveling feet
dReversible door
Rear View
aPower Cord
bGas Connection (for Gas Models)
cExhaust Duct Oulet
dWater Inlet Hose Connection (for Steam Models)
TUUGGwG`GGtSGkGX`SGYWYYGG`aX^Ght

10 PRODUCT OVERVIEW
Product Specifications
Model DL*X385** / DL*X420** DL*X450**
Description Steam Dryer
Electrical Requirements Please refer to the rating label for detailed information.
Min. / Max. Water Pressure 20 - 120 psi (138 - 827 kPa)
Dimensions (Width X Depth X
Height)
27'' X 30 1/8'' X 39'' (68.6 cm X 76.5
cm X 99 cm)
27" X 30" X 39" (68.6 cm X 76.1 cm
X 99 cm)
Maximum Depth with Door
Open
51 3/8'' (130.5 cm) 51" (129.7 cm)
Net Weight
Gas : 136.03 lb (61.7 kg) - 139.34 lb
(63.2 kg)
Electric : 121.9 lb (55.3 kg) - 125.3
lb (56.8 kg)
Gas : 140.4 lb ( 63.7 kg)
Electric : 133.4 lb (60.5 kg)
Capacity Steam Cycle 7.4 cu.ft. (8 lb / 3.6 kg)
Normal Cycle 7.4 cu.ft. (22.5 lb / 10.2 kg)
Gas Requirements NG: 4 - 10.5-inch (10.2 - 26.7 cm) WC
LP: 8 - 13-inch (20.4 - 33.1 cm) WC
Model DL*360** DL*340** / DL*347**
Description Non-Steam Dryer
Electrical Requirements Please refer to the rating label for detailed information.
Dimensions (Width X Depth X
Height)
27'' X 30 1/8'' X 39'' (68.6 cm X 76.5 cm X 99 cm)
Maximum Depth with Door
Open
51 3/8'' (130.5 cm)
Net Weight
Gas : 136.03 lb (61.7 kg) - 139.34 lb
(63.2 kg)
Electric : 121.9 lb (55.3 kg) - 125.3
lb (56.8 kg)
Gas : 123.02 lb ( 55.8 kg)
Electric : 120.15 lb (54.5 kg)
Capacity Normal Cycle 7.4 cu.ft. (22.5 lb / 10.2 kg)
Gas Requirements NG: 4 - 10.5-inch (10.2 - 26.7 cm) WC
LP: 8 - 13-inch (20.4 - 33.1 cm) WC
TUUGGwGXWGGtSGkGX`SGYWYYGG`aX^Ght

11PRODUCT OVERVIEW
ENGLISH
Accessories
Included Accessories
aY Connector (on some models)
bDrying Rack (on some models)
cInlet Hose-Short (on some models)
dInlet Hose-Long (on some models)
Optional Accessories (sold separately)
aPedestal
bStacking kit
cSide vent kit (Kit No. 383EEL9001B)
dHoses
NOTE
• For your safety and extended product life, use only authorized components. The manufacturer is not
responsible for product malfunction or accidents caused by the use of unauthorized components or
parts.
TUUGGwGXXGGtSGkGX`SGYWYYGG`aX^Ght

12 INSTALLATION
INSTALLATION
Before Installing
Installation Overview
Please read the following installation instructions first after purchasing this dryer or transporting it to
another location.
aChoose the proper location.
bLevel the appliance.
cVent the appliance.
dConnect the inlet hose (for steam models)
eConnect the Gas dryer.
fPlug in the power cord.
gInstallation test and test run.
• Refer to the Test Exhaust System section in INSTALLATION.
TUUGGwGXYGGtSGkGX`SGYWYYGG`aX^Ght

13INSTALLATION
ENGLISH
Choosing the Proper
Location
WARNING
• Read all installation instructions completely
before installing and operating the appliance. It
is important that you review this entire manual
before installing and using the appliance.
Detailed instructions concerning electrical
connections and additional requirements are
provided on the following pages.
Exhaust
• The location must allow for proper exhaust
installation. A gas dryer must be exhausted to
the outdoors.
Electricity
Use an individual, grounded electrical outlet
located within 2 ft. (61 cm) of either side of the
appliance.
WARNING
• Do not install or store the appliance in an area
where it will be exposed to water and/or
weather.
NOTE
• Check code requirements that limit, or do not
permit, installation of the dryer in garages,
mobile homes or sleeping quarters. If you have
questions, contact your local building inspector.
Flooring
To avoid noise and vibration, the appliance must
be installed and leveled on a solidly constructed
floor with a maximum slope of 1 inch (2.5 cm). If
required, adjust the leveling legs to compensate
for the unevenness of the floor.
NOTE
• A sturdy floor is needed to support the total
appliance weight when loaded. The combined
weight of additional appliances should also be
considered.
• Clothes may not tumble properly, and automatic
sensor cycles may not operate correctly if the
appliance is not level.
• For garage installation, you will need to place the
appliance at least 18 inches (45.7 cm) above the
floor. The standard pedestal height is 15 inches
(38 cm). You will need 18 inches (45.7 cm) from
the garage floor to the bottom of the appliance.
Ambient Temperature
Install the appliance in an area where the
temperature is over 45 ૢ(7 ૟).
If the temperature around the appliance is too low,
the appliance might not shut off at the end of an
automatic cycle. This can result in longer drying
times.
TUUGGwGXZGGtSGkGX`SGYWYYGG`aX^Ght

14 INSTALLATION
Dimensions and Clearances
The following clearances are recommended for the appliance.
• Additional clearances should be considered for ease of installation and servicing.
• Additional clearances should be considered on all sides of the dryer to reduce noise transfer.
Installation Spacing for Recessed Area or Closet Installation
- Description Dimension/Clearance
A Upper Ventilation Opening 248 sq. in. (310 cm2)
B Lower Ventilation Opening 224 sq. in. (155 cm2)
C Distance to Ventilation Opening 23Ȓ(76 mm)
D Overhead Cabinet Depth 114Ȓ(356 mm)
E Distance to the Overhead Cabinet/Shelf 218Ȓ(457 mm)
F Front Clearance 1Ȓ(25 mm)
G Depth 30 1/8Ȓ(765 mm)
H Back Clearance 25Ȓ(127 mm)
I Side Clearance 21Ȓ(25 mm)
J Width 27Ȓ(686 mm)
K Height of Cabinet Opening 39Ȓ(990 mm)
TUUGGwGX[GGtSGkGX`SGYWYYGG`aX^Ght

15INSTALLATION
ENGLISH
Closet Ventilation Requirements
Closets with doors must have both an upper and lower vent to prevent heat and moisture buildup in the
closet. One upper vent opening with a minimum opening of 48 sq. in. (310 cm2) must be installed no lower
than 6 feet above the floor. One lower vent opening with a minimum opening of 24 sq. in. (155 cm2) must
be installed no more than one foot above the floor. Install vent grilles in the door or cut down the door at
the top and bottom to form openings. Louvered doors with equivalent ventilation openings are also
acceptable.
NOTE
• There should be at least a little space around the dryer (or any other appliance) to eliminate the transfer
of vibration from one appliance to another. If there is enough vibration, it could cause appliances to
make noise or come into contact, causing paint damage and further increasing noise.
• No other fuel-burning appliance can be installed in the same closet as a dryer.
Installation Spacing for Recessed Area or Closet, with Stacked Washer and Dryer
† Differs depending on the washer dimensions.
- Description Dimension/Clearance
A Upper Ventilation Opening 248 sq. in. (310 cm2)
B Lower Ventilation Opening 224 sq. in. (155 cm2)
C Distance to Ventilation Opening 23Ȓ(76 mm)
D Front Clearance 21Ȓ(25 mm)
E Back Clearance 25 1/2Ȓ(140 mm)
F Top Clearance to the Ceiling 26Ȓ(152 mm)
GHeight to the Top of Stacked Appliances†77 1/2Ȓ(1968 mm)
H Side Clearance 21Ȓ(25 mm)
IWidth†27Ȓ(686 mm)
TUUGGwGX\GGtSGkGX`SGYWYYGG`aX^Ght

16 INSTALLATION
Installation Spacing for Cabinet
For cabinet installation with a door, minimum ventilation openings in the top of the cabinet are required.
- Description Dimension/Clearance
A Depth of Ventilation Opening 27Ȓ(178 mm)
B Back Clearance 25Ȓ(127 mm)
C Depth 30 1/8Ȓ(765 mm)
D Front Clearance 21Ȓ(25mm)
E Side Clearance 21Ȓ(25 mm)
F Width 27Ȓ(686 mm)
G Clearance to Top of Cabinet 29Ȓ(229 mm)
TUUGGwGX]GGtSGkGX`SGYWYYGG`aX^Ght

17INSTALLATION
ENGLISH
Leveling the Appliance
WARNING
• Use long-sleeved gloves and safety glasses.
• The appliance is heavy. Two or more people are
required when installing the appliance.
Checking the Level
Position the appliance in the final location and
place a level across the top of the appliance.
aLevel
bLeveling Feet
NOTE
• All four leveling feet must rest solidly on the
floor. Gently push on the top corners of the
appliance to make sure that the appliance does
not rock from corner to corner.
• Adjust the leveling feet only as far as necessary
to level the appliance. Extending the leveling feet
more than necessary may cause the appliance to
vibrate.
• To ensure that the appliance provides optimal
drying performance, it must be level. To
minimize vibration, noise, and unwanted
movement, the floor must be a perfectly level,
solid surface.
Adjusting the Leveling Feet
Use an adjustable wrench to turn the leveling feet.
Unscrew the legs to raise the appliance or screw in
the legs to lower it. Raise or lower with the leveling
feet until the appliance is level from side to side
and front to back. Make sure that all four leveling
feet are in firm contact with the floor.
NOTE
• If you are installing the appliance on the optional
pedestal, you must use the leveling feet on the
pedestal to level the appliance. The appliance
leveling feet should be fully retracted.
Reversing the Door
WARNING
• Support the door with a stool or box that fits
under the door, or have an assistant support the
weight of the door.
• Avoid dropping the door.
• Unplug the appliance or turn off power at the
main circuit breaker before beginning door
reversal.
• Always reverse the door BEFORE stacking the
appliance on top of the washer.
Tools Required
• Phillips screwdriver
• Large flat blade screwdriver (recommended for
hinge screws if they are tight or your Phillips
screwdriver is worn)
• Small flat blade screwdriver (for lifting out parts)
Door Reversal Instructions
The instructions here are for changing the door
swing from a right to a left side hinge. If the door
has been reversed, and it is necessary to change it
back, use care when following these instructions.
Some of the illustrations and the left/right
references will be reversed, and you will need to
read the instructions carefully.
1 Open the door and remove the 2 decorative
screws, 2 latch screws, and the latch on the
catch side with a screwdriver. Save these for
step 4.
WARNING
• Be sure to support the weight of the door before
removing the hinge screws.
a
b
TUUGGwGX^GGtSGkGX`SGYWYYGG`aX^Ght

18 INSTALLATION
2 While supporting the door, remove the 2
screws on the door hinge. Remove the door.
3 Turn the door upside down and line up the
holes in the hinge with the holes on the
opposite side of the cabinet. Reinstall the
door with the screws removed in step 2.
WARNING
• Be sure to support the weight of the door before
inserting the hinge screws.
4 Install the 2 decorative screws, the latch, and
2 latch screws removed in step 1 on the
opposite side from which they were removed.
5 Check that the door closes properly.
Door Reversal Instructions
(DL*X450**)
The instructions here are for changing the door
swing from a right to a left side hinge. If the door
has been reversed, and it is necessary to change it
back, use care when following these instructions.
Some of the illustrations and the left/right
references will be reversed, and you will need to
read the instructions carefully.
1 Open the appliance door.
2 You will be removing the screws shown below
(6 on left, 4 on right).
3 Remove the four decorative screws on the left
using a screwdriver.
4 Remove the two latch screws and the latch.
TUUGGwGX_GGtSGkGX`SGYWYYGG`aX^Ght

19INSTALLATION
ENGLISH
CAUTION
• Be sure to support the weight of the door before
removing the hinge screws.
5 Hold the hinge in place while removing the
four hinge screws (to prevent the door from
dropping).
6 Remove the door from the cabinet cover.
7 Move the door to the left side and line up the
holes in the hinge with the holes in the
cabinet.
WARNING
• Be sure to support the weight of the door before
inserting the hinge screws.
8 Hold the hinge in place while inserting the
two hinge screws (to prevent the door from
dropping).
9 Insert the latch on the right side and install
the latch screws.
10 Insert the four decorative screws on the right
side.
11 Check that the door closes and latches
properly.
TUUGGwGX`GGtSGkGX`SGYWYYGG`aX^Ght

20 INSTALLATION
Installing the Vent Kit
WARNING
• Use long-sleeved gloves and safety glasses.
• Use a heavy metal vent.
• Do not use plastic or thin foil ducts.
• Clean old ducts before installing the appliance.
The appliance is configured to vent to the rear. It
can also vent to the bottom or side.
NOTE
• An adapter kit, part number 383EEL9001B, may
be purchased from your LG retailer. This kit
contains duct components necessary to change
the appliance vent location.
• Right-side venting is not available on gas
models.
Side Venting
1 Remove the rear exhaust duct retaining screw
aand pull out the exhaust duct b.
2 Press the tabs on the knockout cand
carefully remove the knockout for the desired
vent opening. (Right-side venting is not
available on gas models.) Press the adapter
duct donto the blower housing and secure
to the base of the dryer as shown.
3 Preassemble a 4" (10.2 cm) elbow eto the
next 4" (10.2 cm) duct section, and secure all
joints with duct tape. Be sure that the male
end of the elbow faces AWAY from the dryer.
Insert the elbow/duct assembly through the
side opening and press it onto the adapter
duct. Secure it in place with duct tape. Be sure
that the male end of the duct protrudes 1.5"
(3.8 cm) to connect the remaining ductwork.
Attach the cover plate fto the back of the
dryer with the included screw.
Bottom Venting
1 Remove the rear exhaust duct retaining screw
a. Pull out the exhaust duct b.
2 Press the adapter duct conto the blower
housing and secure it to the base of the dryer
as shown.
3 Insert the 4" (10.2 cm) elbow dthrough the
rear opening and press it onto the adapter
duct. Be sure that the male end of the elbow
faces down through the hole in the bottom of
the dryer. Secure it in place with duct tape.
Attach the cover plate eto the back of the
dryer with the included screw.
a
b
c
d
f
e
a
b
c
d
e
TUUGGwGYWGGtSGkGX`SGYWYYGG`aX^Ght
