Ssl ML43B User manual

Installation Installation
Installation Procedures
First complete the electrical connections and then check for correctness.
Adjust Menu Options (SEL)
• Press SEL button repeatedly to cycle through the following adjustable
audio functions:
- ILL MID/HI/LOW: This receiver is equipped with 3 brightness settings.
- BASS/TREBLE:-7, -6, ~, 1, 0, +1,~, +6, +7
Note: BASS and TREBLE settings are only enabled when EQ setting is turned OFF.
- BALANCE:L7, L6,~, L1, 0, R1,~,R6, R7
- FADER:R7, R6, ~, R1, 0, F1, ~ ,F6, F7
- EQ(Equalizer) Setting: OFF, CLASS, ROCK, POP, FLAT
- Loudness: LOUD ON/OFF
- DX/LOCAL: Enables or disables the local broadcast mode (LOCAL).
- Stereo/Mono: Switches between MONO and STEREO reception mode
for radio frequencies.
- CLOCK 12/24: Select between 12 hours and 24 hours display.
Note: If 12 hour display is selected , AM= Morning; PM= Afternoon
- AREA US/EU: This car radio is equipped the USA / Europe frequency.
Rotate the volume knob to switch between USA and Europe frequency.
The system will change the frequency setting in about 3 seconds.
• Rotate the VOL knob to adjust the selected item.
Setting the Clock
Press and hold the CLK button to display time. Press the CLK button, the
hours digits start flashing on the display. Set hours by pressing the and
button. Then briefly press the CLK button. The minute digits start flashing.
Set minutes by pressing the and .
Finally press the CLK button to confirm your settings.
LCD Display
Mute On/Off
In power on mode, briefly press the MUTE button to toggle mute on or off.
USB Port
Hands-free Microphone
Auxiliary Input Jack
Reset
Push the RESET button with a thin object with a pointed end to reset all
parameters to factory default settings.This function may be used when the
LCD does not display normally or sound is distorted, or when any of controls
are disabled.
Insert mounting collar into the dashboard and bend the mounting
tabs out with a screwdriver.
Make sure that lock lever is flush with the mounting collar( not
projecting outward).
Connect all wiring harness and slide the head unit into the mounting
collar until it clicks into place.
Turn Unit on/off, Change the Source
• Press the /MODE button to turun on the unit. Press and hold the /
MODE button to turn off the unit.
• Press the /MODE button to select the different modes: Radio, USB(with
USB device inserted), SD(with SD card inserted), AUX-IN(auxiliary input)
and BT(Bluetooth) modes.
Adjust the volume (VOL)
Rotate the VOL knob to increase or decrease the volume level.
Installation Opening
This unit can be installed in any dashboard Having an opening as shown
below.
53 mm
182 mm
- Only use speakers with 4 ohms impedance.
- +12V DC Negative Ground.
- The maximum current of the Amp remote trigger is 200mA.
!
Wiring Connections
Overview of the Components
General Operation
General Operation Radio Operation
Switch Between USA area and Europe area Frequency
In radio mode, press the SEL button to enter the switch state of the US
(USA) and EU(europe)frequency, then rotate it to switch between US(USA)
and EU(europe) frequency. The system will change the frequency setting in
about 3 seconds.
Change Bands
In radio mode, shortly press the BND/AMS button to switch between the
FM1(F1), FM2(F2), FM3(F3) and AM1(A1), AM2(A2) bands.
To Store / Recall Preset Stations
The radio can be stored 6 preset stations for each band (FM1, FM2, FM3,
AM1 and AM2) for atotal of 30 preset stations.
- To memorize a station:
Press and hold the desired preset buttons (1-6) to save a radio station.
- To recall a preset station:
Briefly press the respective station button (1-6) to recall the corresponding
preset station.
Manual Tuning
In the radio mode:
Press and hold the or button to enter the manual tuning mode.
In manual tuning mode, briefly press the or button to search the next
or previous frequency step by step.
Seek Tuning
In radio mode, press the or button, the automatic search will start, it
will search upward or downward for the strong signal radio station within the
cuttent band. The auto searching will stop until find a station.
Automatic Store Preset station (AMS)
Press and hold the BND/AMS button to store 18 FM stations and 12 AM
stations automatically.
(power) / MODE (source) button
SEL (select/menu) button and VOL (volume) knob
BND(BAND) / AMS(automatic store station, automatic music search)
and (answer call) button
(pause/play), Preset station 1 button
RPT (repeat), Preset station 3 button
-10(previous 10 tracks), previous folder, Preset station 5 button
1.
2.
3.
4.
INT (intro), Preset station 2 button5.
6.
RDM (random), Preset station 4 button7.
8.
9. +10(next 10 tracks), next folder, Preset station 6 button
10. MUTE button 11. CLK (clock setting), (end call) button
12. (tune/seek down, previous track, fast reverse) button
13. (tune/ seek up, next track, fast forward) button
14. Hands-free Microphone 15. LCD Display 16. USB Port
17. IR remote sensor 18. SD Card Slot
19. AUX IN (auxiliary input) jack 20. Reset button
ANT F-R R-R
F-L R-L
10
Radio Antenna
White
Front Left
Speaker
Rear Left
Speaker
Front Right
Speaker
Rear Right
Speaker
White/Black
ACC + (Red)
GND - (Black)
ANT + (Blue)
Power B+ (Yellow)
Gray/Black
Purple
Purple/Black
Green
Green/Black
Gray
Red: Front Right PRE-AMP Output
White: Front Left PRE-AMP Output
White: Rear Left PRE-AMP Output
Red: Rear Right PRE-AMP Output
