User Manual
SD322B
BLUETOOTH®ENABLED
SINGLE DIN MOUNTING
DVD/MP3/CD AM/FM RECEIVER
3.2” DETACHABLE WIDESCREEN TFT MONITOR
USB and SD CARD PORTS and AUX INPUT
SD322B
BLUETOOTH®ENABLED
SINGLE DIN MOUNTING
DVD/MP3/CD AM/FM RECEIVER
3.2” DETACHABLE WIDESCREEN TFT MONITOR
USB and SD CARD PORTS and AUX INPUT

SAFETY INFORMATION
This Digital Video Player Is A Class I
Laser Product. However This Digital
Video Player Uses A Visible/invisible
Laser Beam Which Could Cause .
Hazardous Radiation Exposure If
Directed.
Be Sure To Operate The Dvd Player
Correctly As Instructed.
Use Of Controls Or Adjustments Or
Performance Of Procedures Other Than
Those Specified Herein May Result In
Hazardous Radiation Exposure. do Not
Open Covers And Do Not Repair Your-
self. Refer Servicing To Qualified
Personnel.
CAUTION:
This Digital Video Player is designed
and manufactured to respond to the
Region Management Information that is
recorded on a Digital Video disc. If the
Region number described on the Digital
Video disc does not correspond to the
Region number of this Digital Video
Player, this Digital Video Player cannot
play this disc.
REGION MANAGEMENT
INFORMATION:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR
MOISTURE.
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE ONLY THE
RECOMMENDED ACCESSORIES.
THIS DEVICE IS INTENDED FOR
CONTINUOUS OPERATION.
WARNING:
This product incorporates copyright
protection technology that is protected
by method claims of certain U.S. Patents
and other intellectual property rights
owned by Macrovision Corporation and
other rights owners.
Use of this copyright protection
technology must be authorized by Macro
vision Corporation, and is intended for
home and other limited viewing uses
only unless otherwise authorized by
Macrovision Corporation.
Reverse engineering or disassembly is
prohibited.

DISC NOTE
Preparing New Discs with Rough
Spots
A new disc may have rough edges on
its inside and outside edges.If a disc
with rough edges is used, the proper
setting will not be performed and the
player will not play the disc.Therefore,
remove the rough edges in advance
by using a ball point pen or pencil as
shown on the right.To remove the
rough edges, press the side of the pen
or pencil against the inside and outside
edges of the disc.
Rough spots
on
outside edge
Ball point pen
or pencil
Rough spots
on inside
edge
Label side
up
Do not touch
the
underside
of the disc
Do not
bend
Wipe the disc from
center
toward the outside
edge
Disc Cleaning
Use a dry soft cloth to wipe the surface.
If the disc is quite dirty, use a soft cloth
slightly moistured with isopropyl
(rubbing) alcohol. Never use solvents
such as benzine, thinner or conventional
record cleaners as they may mar the
surface of the disc.
Handling and Cleaning
Dirt, dust, scratches and warping disc
will cause misoperation.
Do not place stickers or make
scratches on discs.
Do not warp discs.
A disc should always be kept in its
case when not in use to prevent from
damaging.
Do not place discs in the following
places:
1.Direct sunlight
2.Dirty, dusty and damp areas
3.Near car heaters
4.On the seats or dashboard
Discs which cannot be played
with this player
Digital Video-RAM
CDV
CD-G
Note:
A disc may become somewhat scratched
(although not enough to make it unus-
able) depending on your handling it and
conditions in the usage environment.
Note these scratches are not an indica-
tion of any problem with the player.
Disc formats supported by this
player
Digital
Video
VCD
CD
MP3
Audio and Video
Disc size 12 cm
Audio and Video
Disc size 12 cm
Audio
Disc size 12 cm
Audio
Disc size 12 cm
Digital
Video
VCD
CD
MP3

NOTES:
Choose the mounting location where the
unit will not interfere with the normal
driving function of the driver.
Before finally installing the unit, connect
the wiring temporarily and make sure it
is all connected up properly and the unit
and the system work properly.
Use only the parts included with the unit
to ensure proper installation. The use of
unauthorized parts can cause
malfunctions.
Consult with your nearest dealer if insta-
llation requires the drilling of holes or
other modifications of the vehicle.
Install the unit where it does not get in
the driver s way and cannot injure the
passenger if there is a sudden stop,
like an emergency stop.
'
30
INSTALLATION
If installation angle exceeds 30 from
horizontal, the unit might not give its
optimum performance.
Avoid installing the unit where it would
be subject to high temperature, such
as from direct sunlight, or from hot air,
from the heater, or where it would be
subject to dust, dirt or excessive
vibration.
DIN FRONT/REAR-MOUNT
This unit can be properly installed either
from "Front"(conventional DIN Front-
mount) or "Rear"(DIN Rear-mount
installation, utilizing threaded screw
holes at the sides of the unit chassis).
For details, refer to the following
illustrated installation methods.
DASH BOARD
METAL MOUNTING
STRAP
HEX NUT
SPRING WASHER
PLAIN WASHER
TAPPING SCREW
CONSOLE
SLIDE BRACKET
HOUSING
HEX BOLT

INSTALLATION
DETACHING CONTROL PANEL
1. Press the OPEN button to flip down the
front panel .
2. First slide the front panel a little to
the right, and pull it off towards you .
OPEN button
3. put it in the protective case for safe
keeping.
PROTECTIVE CASE
FRONT PANEL
KEY PLATE
PLASTIC FRAME
KEY PLATE
If you want to take CHASSIS out of the SLIDE BRACKET HOUSING , first remove
the PLASTIC FRAME of the both sides away, then insert the two KEY PLATES into
left and right sides of chassis as above illustration.

INSTALLATION
How to clean the connectors
Frequent detachment will deteriorate
the connectors.
To minimize this possibility, periodically
wipe the connectors with a clean, soft,
dry cloth only, being careful not to
damage the connectors.
Connector
ATTACHING CONTROL PANEL
1. First, insert the right side of the front
panel into the main unit.
Bulge
Hollow
Bulge
Hollow
3. Push it back to the position for playing
2. Push the right side of the front panel
until it locks firmly into the main unit, at
one time, insert the left side of the
front panel into the main unit .

ELECTRIC CONNECTION
Note:
the earth connection cable (parking brake B-) must be connected in order for
pictures to be played back to the monitor. If the cable has not been correctly
connected, the message “PARKING BRAKE” appears on the monitor.
IGNITION SWITCH
RED
WHITE
WHITE/BLACK
GREY
GREY/BLACK
GREEN
GREEN/BLACK
VIOLET
VIOLET/BLACK
YELLOW
CONSTANT 12 VOLTS
BLACK
GROUND(B-)
BLUE
AUTO ANTENNA
FRONT
Lch SPK.
REAR
Lch SPK.
FRONT
Rch SPK.
REAR
Rch SPK.
BROWN
(B-) PARKING BRAKE
PINK
RADIO ANTENNA JACK
(B+) 12V
REAR CAMERA SWITCH
REAR CAMERA INPUT
YELLOW
GREY
SUB WOOFER
VIDEO IN (yellow)
AUDIO R OUT (red)
AUDIO L OUT (white)
VIDEO OUTPUT (brown)
WIRE CONNECTION
FUSE
ISO CONNECTOR

REMOTE CONTROL
1. CLK Press it briefly to show the clock
time .
2. PAIR/ Press it to use the BT
function,refer to the BT operation
3. STOP Press once to pause playback,
press PLAY/PAUSE to resume playback .
4. SETUP Press it to open the SETUP
menu.
5.MO/ST(AUDIO) In radio mode, press it
to select STEREO or MONO mode (when
a station is weak, sometimes switching
to Mono will improve sound quality ) .
In Disc playback mode, pressing it button
opens the AUDIO setup menu for making
changes to the way te soundtrack is
reproduced .
6. LO/DX(SUBTITLE) Changing of the
SUBTITLE language on multi-subtitle
language Digital Video disc. In radio mode,
Press this button for distance reception
when you are located at weak signal
location, depress it for stronger signal.
7. REDIAL/ Press this button to use
the BT function, refer to BT operation.
8.GOTO/ Press this button to begin
playback at a moment in the program you
designate. Use the number buttons to
enter the data that is needed.
In BT phone menu, it serves as the
button on your mobile handset.
15
17
19
13
14
7
2
6
22
11
18
3
16
5
20
1
21
24
9
12
10
48
26
23
25

REMOTE CONTROL
9. / Press to skip to the next
track & press to skip back one track.
BT
LOUD,
11. VOL+/VOL- Press it to adjust
volume level .
12. / / / Use these buttons to
navigate the various menus present in the
product.
13. MENU/SUB WOOFER Press it to
display the root menu of the Digital Video
disc. Press and hold this button to turn
ON or OFF the SUBWOOFER output.
14. BAND(OSD) In Radio mode, press
this button repeatedly to switch between
the five radio bands .
In Disc Playback modes, Press this
button to see information about the disc
currently in play.
15. /MOD Press this button to turn the
unit ON , press and hold to turn the unit
OFF. Press it briefly to select
16. PLAY/PAUSE ( ) In DISC mode,
starting playback, stopping picture/track.
17. MUTE Press this button to turn off the
audio. Press again to restore the sound
to its prior volume level.
18. TITLE/PBC (A/PS) Display the
TITLE menu which is recorded on the
. changing between PBC
ON and PBC OFF on the VCD disc.
In radio mode, press shortly to scan the
preset station, press longer to enter into
automatic memory storing function .
10. Briefly press to switch between
BASS, TREBLE, BALANCE, FADE,
COLOR, BRIGHTNESS, CONTRAST,
TINT and VOLUME; Long press to display
, then briefly press to switch between
SUBWOOFER, EQ, LOCAL/DX
(in radio mode), STEREO/MONO(in
radio mode), CLK FMT, SET CLK, FRE-
QUENCY AREA, ANIMATION and WALL-
PAPER. After selecting a item above,
use VOL+/VOL- button to adjust.
a desired
work source.
Digital Video
SEL
19. ZOOM Press this button to active
the ZOOM function . Each press of the
zoom button changes the screen in the
sequence : 2x 3x 4x ½ 1/3 1/4 .
Use the / / / buttons to move
through the zoomed picture .
Note : during the JPEG playback, press
the ZOOM button, the “ZOOM 100%” will
appear on screen, then press the /
button to increase/decrease in size,
use the / / / buttons to move
through the zoomed picture .
20. ANGLE Changing of the view angle
on multi-angle Digital Video disc.
21. EQ/LOUD Press it briefly to turn to
equalization function. Press it longer to
switch the LOUDNESS function ON and
OFF .
22.
In DISC mode, Press to start forward
rapidly.press to reverse rapidly.
23. ENTER Confirm the Track/Chapter
selected with the number key or selected
with the cursor buttons on TV screen.
24. 0 - 9 These buttons are used for
numeric entry in many different menus.
In radio mode.
25. +10/ Tens digit select button,
cooperatively used with numeric buttons.
In BT menu, it serves as the
button on your mobile handset.
26. RADIO PRESET Six preset memory
buttons.

1. First push to inside as the direction
indicated by the arrow (See )and then
Remove the battery holder as the
direction indicated by the arrow (See ).
2. Replace the battery Set a new battery
property with (+)side up as illustrated
(See ).
3. Insert the battery holder. Push in the
holder to the original position(See ).
1
2
3
4
INSERTING THE BATTERIES
REMOTE CONTROL
PREPARING THE REMOTE
CONTROL
USING THE REMOTE CONTROL
1. Face the remote control towards the
player front face IR mark (remote control
signal receiver).
2. Operation angle: About 30 degree
in each the direction of the front of the
IR mark.
3. The distance between remote control
and sensor should not exceed 5M .
NOTE:
The lithium cell in the battery comp-
artment of remote control has been
secured for transport with a foil .
Before initial use please remove this
foil so that the remote control is ready
for operation .
WARNING :
Do not expose the batteries to high
temperatures or direct sunlight .
Never throw batteries into the fire, there
is a danger of explosion !

BASIC OPERATION
1. OPEN Button
Press it to flip down the front panel , then
you can insert the CD disc into the CD
compartment. You can also press the
Eject button(13) to eject the disc.
1318 12
2. (POWER On/Off)/SRC Button
Press it to switch the device ON, press
and hold (approximately 2 seconds) to
switch the device OFF . During the
playback mode, you can press it to select
an input mode by pressing repeatedly
until proper one is found:
>RADIO >DISC >USB > CARD >AUX IN
>BT MUSIC >
Control Panel
Control Panel
Base of Control Panel
3. VOL Multifunction Button
In normal mode, this button is used to
increase or decrease the volume.
If the SEL button is pressed beforehand,
changes can be made in the menus,
e.g. Sound mode .
4. utton
Briefly press to switch between BASS,
TREBLE, BALANCE, FADE, COLOR,
BRIGHTNESS, CONTRAST, TINT and
VOLUME; Long press to display BT, then
briefly press to switch between LOUD,
SEL B
14
2
1
15 17
816
3
7
611
4
10
95
1920

BASIC OPERATION
8. CH 1-6 (RADIO PRESET) or
A). In Disc Playback Mode
Press this button to pause playback,
press it again to resume playback.
7.MUTE Button
Press this button to turn off the audio.
Press again to restore the volume to the
prior level. You can also disable the
MUTE function by turning the VOL +/-
knob.
6. EQ Button
Press the EQ button briefly to turn to
equalization function and to select
desired audio mode.
There are five kinds of mode as below:
Press it longer to switch the LOUDNESS
function ON and OFF .
JAZZ CLAS POP ROCK USER
5. BAND/ Button
In Radio mode, press this button repeat-
edly (or the BAND button on the remote
control) to cycle through and select the
desired radio band, the designation of
the corresponding level- FM1, FM2,
FM3, AM1(MW1), AM2(MW2)- is shown
in the TFT.
B) In Radio Mode
you can store 30 stations in memory:
18 FM stations and 12 AM(MW) stations,
each band stores up to six preset
stations .
The operation as below :
-Store in Memory
> Select the frequency band
> Press repeatedly the button to select
the desired memory key .
> Select the station
> Keep the desired memory key pressed
in until the station is heard again after
a brief interruption .
-Retrieve a preset station
press the button repeatedly to retrieve
a station which had been stored in the
memory in advance the chose number
is shown on display .
9/10 . / Buttons
(tune, Seek, Track, Skip Up/down)
a) In DISC, USB mode:
if you wish to jump forwards or back-
wards press briefly the or button.
Press and hold up for more than two
seconds to begin Fast Forward (or down
for Fast Reverse) mode. Press the
button again as needed, to cycle thru the
range of available speeds.
Digital Video/VCD/CD/MP3:
Normal Playback 2x 4x 8x 20x
b) In Radio Mode:
Press the or button
to start the
search for a radio station
briefly to manu-
ally tune the radio in single steps. Press
and hold for two seconds
automatically.
SUBWOOFER, EQ, LOCAL/DX(in radio
mode), STEREO/MONO(in radio mode),
CLK FMT, SET CLK, FREQUENCY AREA,
ANIMATION and WALLPAPER. After
selecting a item above, use VOL knob to
adjust.

BASIC OPERATION
12. (EJECT) Button
In DISC playing ,Press the Open button
(1) to flip down the front panel, then you
can press the this button to eject the disc .
14. IR (Infrared)
Sensor for the remote control .
13. RESET Button
RESET button is placed on the housing
and must be activated with either a
ballpoint pen or thin metal object. The
RESET button is to be activated for the
following reasons:
A. Initial installation of the unit when all
wiring is completed.
B. All the function buttons do not operate.
C. Error symbol on the display.
11. PAIR/ Button
In BT menu, press this button to
use the BT function, how to use
it , please refer to BT operation
19. MIC (Microphone position )
15. AUX INPUT JACK
For information about using an AUX IN
audio source, refer to AUX operation.
16. TFT Display (liquid crystal display)
The operation of the TFT, refer to TFT
Monitor Adjustment
17. USB PORT
For information about connecting a
USB device, refer to USB operation.
18. SD/MMC CARD SLOT
For information about connecting a
SD card device, refer to SD/MMC Card
operation.
20. APS Button
For the function of the APS button,
please refer to the part of the Radio
Operation.

BASIC OPERATION
TFT MONITOR ADJUSTMENT
In disc playing , press the “SEL” knob
on the front panel to adjust the Audio/
Video item, using the VOL+/- knob to
adjust, the message will display on the
screen like following below:
REAR VIEW CAMERA
When connecting the rear view camera.
the mirror image of the rear view through
the rear view camera is automatically
displayed on the monitor when you
change the gear to the back position.
(Note : additional the monitor can not
display image .)
CONTRAST: 0 to 32
Adjust the contrast of the bright and dark
portion.
TINT: 0 to 32
Adjust the tint if the human skin color is
unnatural.
-Adjustable when “NTSC “ is selected for
“NTSC/PAL “ .
ADJUSTABLE ITEMS:
COLOR: 0 to 32
Adjust the color for the picture-lighter or
darker.
BRIGHT: 0 to 32
Adjust if the picture is too bright or
too dark.
FADE: F 0-10 to R 0-10
Adjust sound balance between front and
rear speakers .
TREBLE: -7 to +7
Adjust treble level .
BALANCE: R 0-10 to L 0-10 .
Adjust sound balance between left
and right speakers .
BASS: -7 to +7
Adjust bass level .
VOLUME: 0 to 40
Adjust volume level .
SETTING AUDIO MODE
In any mode , longer press “SEL” button
on the front panel, the “LOUDNESS ON”
will display, then repeatedly press
shortly to select the other items, using
the VOL+/- knob to adjust, then press
the SEL to confirm the setting.
the message will display on the screen
like following below:
ADJUSTABLE ITEMS:
LOUDNESS ON/OFF
SUBWOOFER ON/OFF
DX/LOCAL:in radio mode
STEREO/MONO: in radio mode
ROCK
use the VOL+/- to choose the equalizer
mode: USER, JAZZ, CLASSIC, POP,
ROCK.

BASIC OPERATION
Note:
Please set the playing time of the ani-
mation to “ 10S ” for the first, when you
turn the unit on .
Only in the RADIO mode, Longer (more
than 2’s) press the SEL button and then
shortly press it to select the Animation
item, then you can use the VOL+/- knob
to change the playing time of animation
among “OFF, 10S, 30S, 1M, 1.5M,2M,
3M and 4M ”.
ANIMATION
In any modes, longer (more than 2’s)
press “SEL” button and then repeatedly
press shortly it to select the Background
Color item, use the VOL+/- to change
until choose your desired Background
Color . E.X: In RADIO mode :
SETTING BACKGROUND
in wallpaper mode, you can select the
among of “Pink, Blue, Light Blue, Red,
Yellow, Green, Auto ” .
When you select the “AUTO” item, the
player will change the background color
automatically .
24H CLOCK FORMAT
use the VOL+/- to choose clock display
in 12 or 24 hour.
SET CLOCK 06:36
Rotate VOL+/- knob clockwise to adjust
the hour and anticlockwise to adjust the
minute and confirm the setting by press-
ing the SEL knob.
USA/EUR FREQUENCY
use the VOL+/- to choose the USA or
EUROPEAN frequency.
ANIMATION 10 SECONDS
use the VOL+/- to choose the animation
playing time.
WALLPAPER PINK
use the VOL+/- to choose the back-
ground color.
The RESET button is to be activated for
the following reasons:
A. Initial installation of the unit when
all wiring is completed.
B. All the function buttons do not operate.
C. Error symbol on the display.
Reset Factory Settings
RESET button is placed on the housing
and must be activated with either a
ballpoint pen or thin metal object.
RESET
BT ON/OFF
To switch the BT function on/off.
LOC ST USER
101.60
FM2 MH2
187.50
290.10
398.10
4105.30
5106.20
688.20
WALLPAPER PINK
LOC ST USER
101.60
FM2 MH2
187.50
290.10
398.10
4105.30
5106.20
688.20
ANIMATION 10SEC

BASIC OPERATION
When an FM stereo broadcast is
hard to receive
Press ST/MO button on the remote
control to select the MONO or STEREO
mode . (When Stereo mode is activated,
the ST symbol will appear . )
Selecting The Frequency Band
Repeatedly press the BAND button on
the front panel to select the band, the
message will show in turn :
FM1 FM2 FM3
AM2(MW2) AM1(MW1)
RADIO OPERATION
Press the MODE button to select the
RADIO mode, the message will like
following below :
Start Searching For a Station
During Radio mode, briefly press the
button on the front panel to increase
frequency by one step of channel
spacing . (Or you can press button
on the remote control)
Manual Search
During Radio mode, briefly press the
button on the front panel to decrease
frequency by one step of channel
spacing . (Or you can press button
on the remote control)
Automatic Search
During Radio mode, press and hold
(for more than 2’s ) the “ / ” button
to start search for a radio station
automatically .
You can use the “ / ” buttons on the
remote control to start search for a radio
station automatically .
To tune in strong-singnal FM
Station only (LO/DX function)
Press the LOC/DX button on the remote
control to choose between the LOC and
DX mode of Local and Long-distance
traffic news . The word “LOC” or “DX”
will display in the screen .
Storing Stations In Memory
Setting Memory
With this system, a total of 30 stations
can be stored in the memory of six
buttons. Each band stores up to six
preset stations. The stations might be
FM1, FM2, FM3, AM1(MW1), and
AM2(MW2) band.
The operation is as below :
- Store in Memory
>Select the frequency band
>Select the station
>Keep the desired memory key pressed
in until the station is heard again after
a brief interruption .
LISTENING TO RADIO
LOC ST USER
101.60
FM2 MH2
187.50
290.10
398.10
4105.30
5106.20
688.20
WELCOME TO ......
LOC ST USER
101.60
FM2 MH2
187.50
290.10
398.10
4105.30
5106.20
688.20
WELCOME TO ......

BASIC OPERATION
In Radio Mode, press and keep (for more
than 2 ’ S) the remote of “ APS ” button
to active automatic station storage.
The radio searches within the current
frequency band, e.g. FM1, for the stron-
ger signal level until the search cycle
has finished . The six strongest stations
are then allocated to the corresponding
storage locations .
Then the station of the first storage
location is set .
Automatic Memory Storing &
Program Scanning
Automatic Preset Setup
Scan Function
In Radio mode, briefly press the “APS”
button on the remote control , the radio
briefly plays all the preset stations of the
frequency band .
- Retrieve a preset station
press the 1-6 buttons briefly on the
remote control to retrieve a station
which had been stored in the memory
in advance the chose number is shown
on display .

SELECTING PLAY MODE
During the Disc playback, press the
“2, RDM, INT ” button on the remote
control to select the different playing
mode .
2). REPEAT FUNCTION
REPEAT OFF
REPEAT ONE REPEAT ALL
FOR VCD/CD :
Longer press 2 button on the remote
control to select REPEAT mode as
follows :
FOR Digital Video :
Longer press 2 button on the remote
control to select REPEAT mode as
follows :
REPEAT ALL
CHAPTER REPEAT ON TITLE REPEAT ON
REPEAT OFF
MEDIA OPERATION
123
45 6
789
SELSEL
VOLVOL
TOP INT
RDM
1). TOP FUNCTION
ForDigital Video/ VCD/CD/MP3:
In the state of Digital Video/VCD/CD/
MP3 disc playing, press the button to
select the first track/chapter to play.
(depend on the disc used for VCD)
3). INTRO FUNCTION
FOR CD :
longer press the 3/INT button on the
remote control to play the previous 10
seconds part of each track/chapter on
disc.
(Longer press again to cancel this mode)
FOR VCD :
longer press the 3/INT button on
the remote control, It display will
following menu as below :
SEQ PLAY INTRO 1
Note: when select INTRO 1 Mode, this
player to start to play the previous 10
seconds part of each track/chapter on
disc. (Longer press it again to cancel
this mode .)
FOR Digital Video/MP3 :
For Digital Video/MP3 , longer press the
INT button is not available .
4). RDM (RANDOM) FUNCTION
During DISC playback, longer press the
4/RDM button on the remote control to
play in random. Each playing, the order
is different .
(Depend on the disc used for VCD).
Longer press it again to cancel
this function .
REPEAT ALL
REPEAT ONE REPEAT FOLD ER
REPEAT OFF
FOR MP3 :
Longer press 2 button on the remote
control to select REPEAT mode as
follows :

NOTE:
For CD(audio) Disc, press OSD button
is not available .
E. Press OSD for the fifth time:
The message on the screen will be
cleared for SVCD and VCD.
2.Example for VCD/SVCD/CD:
F. Press OSD for sixth time:
The message on the screen will be
cleared.
ON-SCREEN DISPLAY FUNCTION
Digital Video TT 01/01CH 04/31 C -0:01:32
C. Press OSD for third time:
SCREEN DISPLAY
During playback, press the
OSD button on the remote
control . It will display the
following as bellow :
1. Digital Video:
A. Press OSD for first time:
Title Number, Tot al Title Number,
Chapter Number, Tot al Chapter Number
of this Title of the disc currently being
played will be shown on the screen,
along with the elapsed time.
Digital Video TT 01/01CH 04/31 C 0:02:06
D. Press OSD for fourth time:
Digital Video TT 01/01CH 04/31 T 0:16:00
E. Press OSD for fifth time:
Digital Video TT 01/01CH 04/31 T -1:36:55
B. Press OSD for second time:
A. Press OSD for first time:
VCD TRK 1/19 PBC C 0:01:36
A
B. Press OSD for second time:
VCD TRK 1/19 PBC C -0:06:06
A
C. Press OSD for third time:
VCD TRK 1/19 PBC T 0:02:12
A
D. Press OSD for fourth time:
VCD TRK 1/19 PBC T -1:23:06
A
3. Example for MP3
A. Press OSD for first time:
CDrom TRK 2/76 C 0:00:36
A
B. Press OSD for second time:
CDrom TRK 2/76 C -0:03:38
A
C. Press OSD for third time:
The message on the screen will be
cleared.
½ ENG 2CH OFF AN OFF
The underlined part is different from
the used discs.

Digital Video Special Function
Notes:
- The angle number is different
according to the disc.
- The function only work for disc having
scenes recorded at different angles.
- When no different angle are recorded,
will be displayed at
screen left top corner.
“ INVALID KEY ”
During Digital Video playback,
press the ANGLE ( ) button
on the remote control
3. Multi-Angle Function
(for Digital Video Only)
Each time the button is pressed , the
number of the angle changes in sequen-
tial order.
4. Title Menu Function
For Digital Video:
If the Digital Video has multiple titles
recorded on the disc. It can select
preferred title from the title menu to start
playback.
- During Digital Video playback, press
TITLE button on the remote .The title
menu is display.
- Select preferred title by the cursor
button and confirmed by press the
ENTER button .
For VCD:
Press TITLE/PBC button on the remote
control while the disc is playing, you can
switch between "PBC ON"and "PBC off"
mode.
MONO LEFT MONO RIGHT
STEREO
MIX-MONO
For VCD/CD:
during playback, Press AUDIO on the
remote control . It is possible to switch
the sound between monaural and
stereo sound.
Notes:
- The language number is different
according to the disc.
- Some disc only contain one language
soundtrack
- When no different language soundtra-
ck are recorded will be
display at screen left top corner.
“ INVALID KEY ”
2. Multi-Audio Language Function
For Digital Video:
During Digital Video playback,
press the AUDIO on the remote
Each time the button is pressed number
changes on sequential order.
Notes:
- The language number is different
according to the disc.
- Some discs only contain one subtitle
language.
- When no different subtitle language
are recorded, “ INVALID KEY ” will be
displayed at screen left top corner.
During Digital Video playback.
press the SUBTITLE on the
remote control .
1. Multi-subtitle Language
Function (for Digital Video Only)
Each time the button is pressed number
of the subtitle language changes
in sequential order.
DIGITAL VIDEO SPECIAL FUNCTION
