Stackrack SR700 User manual

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
SR700
MIL-STD Rugged Computer
User’s Manual

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
Safety information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before
relocating the system.
When adding or removing devices to or from the system, ensure that the power cables for the
devices are unplugged before the signal cables are connected. If possible, disconnect all power cables
from the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power cables are
unplugged.
Seek professional assistance before using an adapter or extension cord. These devices could interrupt
the grounding circuit.
Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using, contact your local power
company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or
your local distributor.
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals that came
with the package.
Before using the product, make sure all cables are correctly connected and the power cables are not
damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and
circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may
become wet.
Place the product on a stable surface.
If you encounter any technical problems with the product, contact your local distributor
Statement
All rights reserved. No part of this publication may be reproduced in any form or by any means,
without prior written permission from the publisher.
All trademarks are the properties of the respective owners.
All product specifications are subject to change without prior notice
1

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
Revision History
Revision
Date (yyyy/mm/dd)
Changes
V0.1
2016/11/01
Draft Version
V1.0
2016/11/23
Initial release
Packing list
□SR700 MIL-STD Rugged Computer
□XR-DIMM up to 8 GB RAM optional
□NVIDIA GTX950M MXM Graphic Card
Accessories Kit
□M12 4 PIN DC Connector x 1pcs
□CD (Driver + User’s Manual)
□Cable kits
□Mounting Bracket
If any of the above items is damaged or missing, please contact your local distributor.
Ordering information
Model Number
Description
SR700
Intel® QM87 MIL-STD IP65 Rugged System with Intel® Core i7-4700EQ Processor, NVIDIA
GT950M GPU, M12 Rugged Connectors, 9V to 36V DC-in, Wide Temp -40 to 70°C
2

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
Table of contents
SAFETY INFORMATION ........................................................................................................................................ 1
ELECTRICAL SAFETY.....................................................................................................................................................1
OPERATION SAFETY ....................................................................................................................................................1
STATEMENT......................................................................................................................................................... 1
REVISION HISTORY .............................................................................................................................................. 2
PACKING LIST ...................................................................................................................................................... 2
ACCESSORIES KIT................................................................................................................................................. 2
ORDERING INFORMATION................................................................................................................................... 2
TABLE OF CONTENTS........................................................................................................................................... 3
CHAPTER 1: PRODUCT INTRODUCTION............................................................................................................... 5
1.1 KEY FEATURES .....................................................................................................................................................5
1.2 FRONT PANEL COMPONENTS.................................................................................................................................6
1.3 MECHANICAL DIMENSIONS....................................................................................................................................7
CHAPTER 2: JUMPERS AND CONNECTORS........................................................................................................... 8
2.1 FRONT PANEL CONNECTOR PIN DEFINITIONS ...........................................................................................................8
DC IN .................................................................................................................................................................8
X1: USB.............................................................................................................................................................. 8
X2: GbE LAN......................................................................................................................................................8
X3: GbE LAN......................................................................................................................................................8
X4: VGA ............................................................................................................................................................. 9
X5: COM............................................................................................................................................................9
2.2 INTERNAL CONNECTOR AND JUMPER SETTING ........................................................................................................10
MCARD1: Mini PCIE Card Slot<COLAY M SATA>............................................................................................10
CHAPTER 3: AMI BIOS UTILITY........................................................................................................................... 11
3.1 STARTING .........................................................................................................................................................11
3.2 NAVIGATION KEYS ..............................................................................................................................................11
3.3 MAIN MENU ....................................................................................................................................................12
3.4 ADVANCED MENU .............................................................................................................................................13
3.4.1 PCI Subsystem Settings .........................................................................................................................14
PCI Express Settings .................................................................................................................................. 14
3.4.2 ACPI Settings .........................................................................................................................................15
3.4.3 CPU configuration .................................................................................................................................16
3.4.4 SATA Configuration................................................................................................................................21
Software Feature Mask Configuration ..................................................................................................... 23
3.4.5 Intel Rapid Start Technology.................................................................................................................25
3.4.6 PCH-FW Configuration..........................................................................................................................25
Firmware Update Configuration............................................................................................................... 26
3.4.7 Intel Anti-Theft Technology Configuration...........................................................................................26
3.4.8 AMT Configuration................................................................................................................................27
3

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
3.4.9 USB Configuration.................................................................................................................................29
3.4.10 IT8786 Super IO Configuration...........................................................................................................30
Serial Port 1 Configuration........................................................................................................................ 30
Serial Port 2 Configuration........................................................................................................................ 30
Serial Port 3 Configuration........................................................................................................................ 31
Serial Port 4 Configuration........................................................................................................................ 31
Serial Port 5 Configuration........................................................................................................................ 31
Serial Port 6 Configuration........................................................................................................................ 31
3.4.11 IT8786 HW Monitor............................................................................................................................32
3.4.12 Serial Port Console Redirection..........................................................................................................32
Console Redirection Setting...................................................................................................................... 33
3.4.13 Network Stack .....................................................................................................................................33
3.4.14 Intel I210 Gigabit Network Connection .............................................................................................34
3.5 CHIPSET ...........................................................................................................................................................35
3.5.1 PCH IO configuration.............................................................................................................................35
PCI Express Configuration......................................................................................................................... 36
PCI Express Root Port1.......................................................................................................................... 36
PCI Express Root Port2.......................................................................................................................... 37
PCI Express Root Port3.......................................................................................................................... 38
PCI Port 4 is assigned to LAN................................................................................................................ 39
PCI Express Root Port5:......................................................................................................................... 39
PCI Express Root Port6.......................................................................................................................... 40
PCI Express Root Port7.......................................................................................................................... 41
PCI Express Root Port8.......................................................................................................................... 42
USB Configuration..................................................................................................................................... 42
PCH Azalia Configuration. ......................................................................................................................... 42
3.5.2 System AGENT SA..................................................................................................................................43
Graphics Configuration ............................................................................................................................. 44
LCD Control............................................................................................................................................ 44
Memory Configuration.............................................................................................................................. 44
GT- Power Management Control ............................................................................................................. 44
3.6 BOOT...............................................................................................................................................................45
CSM16 Parameters.................................................................................................................................... 46
3.7 SECURITY..........................................................................................................................................................46
3.8 SAVE AND EXIT ..................................................................................................................................................47
4

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
Chapter 1: Product Introduction
1.1 Key Features
System
CPU
Intel® Core™ i7 Haswell , BGA type Core i7-4700EQ (4C x 2.4/1.7 GHz), 6M
Cache (47W)
Chipset
Intel® QM87 PCH
Ethernet Chipset
Intel® i210-IT & i217-LM GbE
Memory
1 x DDR3 1600 XR-DIMM 8 GB with ECC
Expansion Slot
1 x mPCIe
Storage Device
Onboard uSSD SATAIII 64 GB
Front I/O
Power Button
Power Button with LED backlight
DC IN
1 x DC input
X1
2 x USB2.0
X2
1 x GbE LAN
X3
1 x GbE LAN
X4
1 x VGA
X5
1 x RS232, 1 x RS485
Display
Display Interface
VGA, Resolution Up to 1920 x 1080
GPU
NVIDIA GTX950M (MXM Module)
Mechanical & Environment
Power Requirements
9V to 36V DC-in, AT/ATX mode supports with power delay on/off
Power consumption : Under 120 Watt while system fully loading
Dimension
308 x 230 x 76 mm (12.13" x 9.06" x 2.99")
Operating Temp.
-40 to 70°C (ambient with air flow)
Storage Temp.
-40 to 85°C
Relative Humidity
5% to 95%, non-condensing
Serial Interface & Signals
RS-232
TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-485-2w
Data+, Data-, GND
Standards and Certifications
MIL-STD-810G Test
Method 507.5, Procedure II (Temperature & Humidity)
Method 514.6, Procedure I (Category 20 & 24, Vibration)
Method 516.6, Procedure I (Mechanical Shock)
Method 501.5, Procedure I (Storage/High Temperature)
Method 501.5, Procedure II (Operation/High Temperature)
Method 502.5, Procedure I (Storage/Low Temperature)
Method 502.5, Procedure II (Operation/Low Temperature)
Method 503.5, Procedure I (Temperature shock)
EMC
CE and FCC compliance
Green Product
RoHS, WEEE compliance
*Specifications are subject to change without notice*
5

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
1.2 Front Panel Components
DC IN
1 x DC input
X1
2 x USB2.0
X2
1 x GbE LAN
X3
1 x GbE LAN
X4
1 x VGA
X5
1 x RS232, 1 x RS485
PWR
Power Button with LED backlight
6

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
1.3 Mechanical Dimensions
7

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
Chapter 2: Jumpers and Connectors
This chapter describes the jumpers and connectors on the systems’ motherboard.
2.1 Front Panel Connector Pin Definitions
DC IN
Phoenix Contact [1424132]
PIN
DEFINITION
1
+
2
+
3
-
4
-
X1: USB
Phoenix Contact [1441817]
USB2.0
PIN
DEFINITION
1
USB1
VCC
2
D-
3
D+
4
Gound
5
USB2
VCC
6
D-
7
D+
8
Gound
X2: GbE LAN
X3: GbE LAN
Phoenix Contact [1441817]
LAN
PIN
DEFINITION
1
D1+
2
D1-
3
D2+
4
D2-
5
D3+
6
D3-
7
D4+
8
D4-
8

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
X4: VGA
Phoenix Contact [1441833]
LAN
PIN
DEFINITION
1
RED
2
R Ground
3
GREEN
4
G Ground
5
BLUE
6
B Ground
7
H-Sync
8
9
V-Sync
10
11
DDC DATA
12
DDC LOCK
X5: COM
Phoenix Contact [1441833]
LAN
PIN
DEFINITION
1
COM1
RS232
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
10
COM2
RS485
RXD(D+)
11
GND
12
DCD(D-)
9

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
2.2 Internal Connector and Jumper Setting
MCARD1: Mini PCIE Card Slot<COLAY M SATA>
PIN
DEFINITION
PIN
DEFINITION
1
WAKE#
2
3.3VAUX
3
COEX1
4
GND
5
COEX2
6
1.5V
7
CLKREQ#
8
UIM_PWR
9
GND
10
UIM_DATA
11
REFCLK-
12
UIM_CLK
13
REFCLK+
14
UIM_RESET
15
GND
16
UIM_VPP
17
Reserved
18
GND
19
Reserved
20
W_Disable#
21
GND
22
PERST#
23
PERn0
24
+3.3Vaux
25
PERp0
26
GND
27
GND
28
1.5V
29
GND
30
SMB_CLK
31
PETn0
32
SMB_DATA
33
PETp0
34
GND
35
GND
36
USB_D-
37
GND
38
USB_D+
39
+3.3VAUX
40
GND
41
+3.3VAUX
42
LED_WWAN#
43
GND
44
LED_WLAN#
45
Reserved
46
LED_WPAN#
47
Reserved
48
1.5V
49
Reserved
50
GND
51
Reserved
52
3.3VAUX
10

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
Chapter 3: AMI BIOS UTILITY
This chapter provides users with detailed descriptions on how to set up a basic system configuration
through the AMI BIOS setup utility.
3.1 Starting
To enter the setup screens, perform the following steps:
•Turn on the computer and press the <Del> key immediately.
•After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be
accessed from the main BIOS setup menu, such as the Chipset and Power menus.
3.2 Navigation Keys
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot
keys can be used at any time during the setup navigation process.
Some of the hot keys are <F1>, <F10>, <Enter>, <ESC>, and <Arrow> keys.
Some of the navigation keys may differ from one screen to another.
Left/Right
The Left and Right <Arrow> keys moves the cursor to select a
menu.
Up/Down
The Up and Down <Arrow> keys moves the cursor to select a setup
screen or sub-screen.
+− Plus/Minus
The Plus and Minus <Arrow> keys changes the field value of a
particular setup setting.
Tab
The <Tab> key selects the setup fields.
F1
The <F1> key displays the General Help screen.
F10
The <F10> key saves any changes made and exits the BIOS setup
utility.
Esc
The <Esc> key discards any changes made and exits the BIOS setup
utility.
Enter
The <Enter> key displays a sub-screen or changes a selected or
highlighted option in each menu.
11

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
3.3 Main Menu
The Main menu is the screen that first displays when BIOS Setup is entered, unless an error has occurred.
You could setup these items on the Main menu:
System Language: Choose the system default language.
System Date: Set the date. Use Tab to switch between date elements.
System Time: Set the time. Use Tab to switch between time elements.
Access Level
Displays the access level of the current user in the BIOS.
12

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
3.4 Advanced Menu
This section allows you to configure and improve your system and allows you to set up some system
features according to your preference.
13

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
3.4.1 PCI Subsystem Settings
PCI, PCI-X and PCI Express settings.
PCI Common Settings
PCI Latency Timer: Value to be programed into PCI Latency Timer Register.
VGA Palette Snoop: Enable or disable VGA Palette Registers Snooping.
PERR# Generation: Enables or Disables PCI Device to Generate PERR#.
SERR# Generation: Enables or Disables PCI Device to Generate SERR#.
PCI Express Settings
Change PCI Express Devices Settings.
PCI Express Device Register Settings
Relaxed Ordering: Enables or Disables PCI Express Device Relaxed Ordering.
Extended Tag: If ENABLED allows Device to use 8-bit Tag field as a requester.
No Snoop: Enabled or Disables PCI Express Device No Snoop option.
Maximum Payload: Set Maximum Payload of PCI Express Device or allow System BIOS to select the
value.
Maximum Read Request: Set Maximum Read Request Size of PCI Express Device or allow System
BIOS to select value.
PCI Express Link Register Settings
ASPM Support: Set the ASPM level: Force L0s - Force all links to L0s state: AUTO - BIOS auto
configure: DISABLE- Disables ASPM. WARNING: Enabling ASPM may cause some PCI-E devices to
fail.
Extended Synch: If ENBLED allows generation of extended synchronization patterns.
14

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
Link Training Retry
Defines number of retry attempts software will take to retrain the link if previous training attempt was
unsuccessful.
Link Training Time out (uS)
Defines number of Microseconds software will wait before polling “Link training” bit in link status register.
Value range from 10 to 10000 uS.
Unpopulated Links
In order to save power, software will disable unpopulated PCI Express Links. If this option save to “Disable
Link”.
Restore PCIE Registers
On non-PCI Express aware OS’s some device may not be correctly reinitial after S3. Enableling this restore
PCI Express device configurations on S3 resume.
Warning: Enabling this may cause issues with other hardware after S3 resume.
3.4.2 ACPI Settings
System ACPI Parameters.
Enable ACPI Auto Configuration
Enable/disable BIOS ACPI Auto Configuration.
Enable Hibernation
Enables or Disables system ability to hibernate (OS/S4 sleep state). This option may be not effective with
some OS.
15

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
ACPI Sleep State
Select ACPI sleep state the system will enter when the suspend button is pressed.
Lock Legacy Resources
Enable or disable lock of legacy resource.
S3 Video Repost
Enable or disable S3 Video Repost.
3.4.3 CPU configuration
CPU Configuration Parameters.
16

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
17

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
Hyper-threading
Enable for windows XP and Linux(OS optimized for Hyper-Threading Technology) and Disabled for other OS
(OS not optimized for Hyper-Threading Technology). When Disabled only one thread per enabled core is
enabled.
Active Processor Cores
Number of cores to enable in each processor package.
Overclocking lock
FLEX_RATIO(194) MSR.
Limit CPUID Maximum
Disable for Windows XP.
Execute Disable Bit
XD can prevent certain classes of malicious buffer overflow attecks when combined with a supporting OS.
Intel Virtualization Technology
When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology.
Hardware Prefetcher
Enable the mid level cache(L2) streamer prefetcher.
Adjacent Cache Line Prefetcher
Enable the mid level cache(L2) prefetching of adjacent cache lines.
18

WWW.STACKRACK.COM
Version 1.0
Revision Date: NOV. 23, 2016
MIL-STD Rugged Computer
User’s Manual
CPU AES
Enable/disable CPU advanced encryption standard instruction.
Boot performance mode
Select the performance state that the BIOS will set before OS handoff.
EIST
Enable/Disable Intel speed step.
Turbo Mode
Enable/Disable CPU turbo mode
Energy performance
Optimize between performance and power savings.
Package power limit lock: When enabled PACKAGE_POWER_LIMIT MSR will be locked and a reset will
be required to unlock the register.
CPU Power limit1: CPU power limit1 value
CPU Power limit1 time: Time window which the power limit1 is maintained
CPU Power limit2: CPU power limit2 value
Platform power limit lock: When enable, PLATFORM_POWER_LIMIT MSD will be locked and a reset will
be required to unlock the register.
CPU Power Limit3: CPU Power Limit3 value
CPU Power Limit3 Time: Time window which the power limit3 is maintained
CPU Power Limit3 Duty Cycle: Specify the duty cycle in percentage that the CPU is required to maintain
over the configured Power Limit3 time windows.
DDR Power Limit1: DDR Power limit1 value
DDR Power Limit1 Time: Time window which the DDR Power Limit1 is maintained.
DDR Power Limit2: DDR Power limit2 value
1-Core Ratio Limit: This limit is for 1 core active. 0 means using the factory-configured value.
2-Core Ratio Limit: This limit is for 2 cores active. 0 means using the factory-configured value.
3-Core Ratio Limit: This limit is for 3 cores active. 0 means using the factory-configured value.
4-Core Ratio Limit: This limit is for 4 cores active. 0 means using the factory-configured value.
VR Current value lock
Locks VR Current value from further writes until a reset.
VR Current value
Voltage regulator current limit. 0 means AUTO.
19
