Stackrack SR200 User manual

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
SR200
MIL-STD Rugged Computer
User’s Manual

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
Safety information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before
relocating the system.
When adding or removing devices to or from the system, ensure that the power cables for the
devices are unplugged before the signal cables are connected. If possible, disconnect all power cables
from the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power cables are
unplugged.
Seek professional assistance before using an adapter or extension cord. These devices could interrupt
the grounding circuit.
Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using, contact your local power
company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or
your local distributor.
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals that came
with the package.
Before using the product, make sure all cables are correctly connected and the power cables are not
damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and
circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may
become wet.
Place the product on a stable surface.
If you encounter any technical problems with the product, contact your local distributor
Statement
All rights reserved. No part of this publication may be reproduced in any form or by any means,
without prior written permission from the publisher.
All trademarks are the properties of the respective owners.
All product specifications are subject to change without prior notice
1

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
Revision History
Revision
Date (yyyy/mm/dd)
Changes
V1.0
2015/01/20
Initial release
V1.1
2016/03/18
Details update
V1.2
2016/10/20
Change document format
Add setting of COM1
Update BIOS setting
Packing list
□SR200 MIL-STD Rugged Computer
□XR-DIMM up to 8 GB RAM optional
Accessories Kit
□Terminal block 4 PIN x 1pcs
□CD (Driver + User’s Manual)
If any of the above items is damaged or missing, please contact your local distributor.
Ordering information
Model Number
Description
SR200-ET
Intel® QM87 MIL-STD Fanless Rugged System with Intel® Core i7-4700EQ
Haswell Processor, NVIDIA GT730M GPU, 4 Independent DP, 9V to 36V DC-in,
Wide Temp -20 to 60°C
SR200-UT
Intel® QM87 MIL-STD Fanless Rugged System with Intel® Core i7-4700EQ
Haswell Processor, NVIDIA GT730M GPU, 4 Independent DP, 9V to 36V DC-in,
Wide Temp -40 to 70°C
2

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
Table of contents
SAFETY INFORMATION ........................................................................................................................................ 1
ELECTRICAL SAFETY.....................................................................................................................................................1
OPERATION SAFETY ....................................................................................................................................................1
STATEMENT......................................................................................................................................................... 1
REVISION HISTORY .............................................................................................................................................. 2
PACKING LIST ...................................................................................................................................................... 2
ACCESSORIES KIT................................................................................................................................................. 2
ORDERING INFORMATION................................................................................................................................... 2
TABLE OF CONTENTS........................................................................................................................................... 3
CHAPTER 1: PRODUCT INTRODUCTION............................................................................................................... 6
1.1 KEY FEATURES .....................................................................................................................................................6
1.2 FRONT PANEL COMPONENTS.................................................................................................................................8
1.3 REAR PANEL COMPONENTS ...................................................................................................................................8
1.4 MECHANICAL DIMENSIONS....................................................................................................................................9
CHAPTER 2: JUMPERS AND CONNECTORS......................................................................................................... 10
2.1 FRONT PANEL CONNECTOR PIN DEFINITIONS .........................................................................................................10
Status Indicators .............................................................................................................................................10
LED1: LAN1 LED STATUS............................................................................................................................ 10
LED2: LAN2 LED STATUS............................................................................................................................ 10
LED3: POWER/HDD LED............................................................................................................................ 10
USB3.0 CN19: USB*2......................................................................................................................................10
DP1,2,3,4: DISPLAY PORT ...............................................................................................................................11
POWER BUTTON........................................................................................................................................ 11
DC IN: DC Adapter Power Input.....................................................................................................................11
2.2 REAR PANEL CONNECTOR PIN DEFINITIONS ...........................................................................................................12
LAN1: Intel i217LM.........................................................................................................................................12
LAN2: Intel I210IT...........................................................................................................................................12
COM1: RS232/422/485 with 5V/12V selectable...........................................................................................12
DP5,6: DISPLAY PORT .....................................................................................................................................12
DVI: DVI-I.........................................................................................................................................................13
USB3.0.............................................................................................................................................................13
MIC 1: Audio Jacks Connector .......................................................................................................................13
LOUT 1: Audio Jacks Connector.....................................................................................................................13
2.3 INTERNAL CONNECTOR AND JUMPER SETTING ........................................................................................................14
MCARD1: Mini PCIE Card Slot<COLAY M SATA>............................................................................................14
JV2,3: COM1 RS232/422/485 jumper setting...............................................................................................14
JV4: COM1 RS422/485 receiver termination ................................................................................................15
JP12: COM1P9SEL pin function select...........................................................................................................15
CHAPTER 3: AMI BIOS UTILITY........................................................................................................................... 16
3

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
3.1 STARTING .........................................................................................................................................................16
3.2 NAVIGATION KEYS ..............................................................................................................................................16
3.3 MAIN MENU ....................................................................................................................................................17
3.4 ADVANCED MENU .............................................................................................................................................18
3.4.1 PCI Subsystem Settings .........................................................................................................................19
PCI Express Settings .................................................................................................................................. 19
3.4.2 ACPI Settings .........................................................................................................................................20
3.4.3 CPU configuration .................................................................................................................................21
3.4.4 SATA Configuration................................................................................................................................26
Software Feature Mask Configuration ..................................................................................................... 28
3.4.5 Intel Rapid Start Technology.................................................................................................................30
3.4.6 PCH-FW Configuration..........................................................................................................................30
Firmware Update Configuration............................................................................................................... 31
3.4.7 Intel Anti-Theft Technology Configuration...........................................................................................31
3.4.8 AMT Configuration................................................................................................................................32
3.4.9 USB Configuration.................................................................................................................................34
3.4.10 IT8786 Super IO Configuration...........................................................................................................35
Serial Port 1 Configuration........................................................................................................................ 35
Serial Port 2 Configuration........................................................................................................................ 35
Serial Port 3 Configuration........................................................................................................................ 36
Serial Port 4 Configuration........................................................................................................................ 36
Serial Port 5 Configuration........................................................................................................................ 36
Serial Port 6 Configuration........................................................................................................................ 36
3.4.11 IT8786 HW Monitor............................................................................................................................37
3.4.12 Serial Port Console Redirection..........................................................................................................37
Console Redirection Setting...................................................................................................................... 38
3.4.13 Network Stack .....................................................................................................................................38
3.4.14 Intel I210 Gigabit Network Connection .............................................................................................39
3.5 CHIPSET ...........................................................................................................................................................40
3.5.1 PCH IO configuration.............................................................................................................................40
PCI Express Configuration......................................................................................................................... 41
PCI Express Root Port1.......................................................................................................................... 41
PCI Express Root Port2.......................................................................................................................... 42
PCI Express Root Port3.......................................................................................................................... 43
PCI Port 4 is assigned to LAN................................................................................................................ 44
PCI Express Root Port5:......................................................................................................................... 44
PCI Express Root Port6.......................................................................................................................... 45
PCI Express Root Port7.......................................................................................................................... 46
PCI Express Root Port8.......................................................................................................................... 47
USB Configuration..................................................................................................................................... 47
PCH Azalia Configuration. ......................................................................................................................... 47
Watch Dog Function select....................................................................................................................... 49
3.5.2 System AGENT SA..................................................................................................................................50
Graphics Configuration ............................................................................................................................. 51
LCD Control............................................................................................................................................ 51
Memory Configuration.............................................................................................................................. 51
GT- Power Management Control ............................................................................................................. 51
4

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
3.6 BOOT...............................................................................................................................................................52
CSM16 Parameters.................................................................................................................................... 53
3.7 SECURITY..........................................................................................................................................................53
3.8 SAVE AND EXIT ..................................................................................................................................................54
5

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
Chapter 1: Product Introduction
1.1 Key Features
System
CPU
Intel® Core™ i7 Haswell , BGA type Core i7-4700EQ (4C x 2.4/1.7 GHz), 6M
Cache (47W)
Chipset
Intel® QM87 PCH
Ethernet Chipset
Intel® I210IT & i217-LM GbE
Memory
1 x DDR3 1600 XR-DIMM up to 8 GB with ECC
Expansion Slot
2 x mPCIe (1 x colay with mSATA)
Storage Device
Onboard uSSD SATAIII up to 64 GB
Front I/O
Power Button
Power Button with dual color LED backlight
Power LED
1 x Green LED
HDD LED
1 x Red LED
LAN LED
2 x Red LED, 2 Green LED
USB
2 x USB 3.0
DisplayPort
4 (From Graphic Module)
Power
1 x Terminal Block
Rear I/O
Ethernet
2 xRJ45
COM
1 x RS232/422/485 with 5V/12V selectable
USB
2 x USB 3.0
DVI-I
1 (Default CLOSED)
DisplayPort
2 (Default CLOSED)
Audio
1 x MIC, 1 x Line out
Display
Display Interface
DP x 4 - Resolution Up to 3840 x 2160
GPU
NVIDIA GT730M
(embedded on PCIe/104 form factor)
Mechanical & Environment
Power Requirements
9V to 36V DC-in, AT/ATX mode supports with power delay on/off
Dimension
(W xHxD)
308 x 149 x 76 mm
(12.13" x 5.87" x 2.99")
Operating Temp.
-40 to 70°C (ambient with air flow)
Storage Temp.
-40 to 85°C
Relative Humidity
5% to 95%, non-condensing
Serial Interface & Signals
Serial Standards
1x RS-232/422/485 port, Jumper-selectable (DB9 male)
RS-232
TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422
TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w
TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w
Data+, Data-, GND
Standards and Certifications
6

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
MIL-STD-810G Test
Method 507.5, Procedure II (Temperature & Humidity)
Method 514.6, Procedure I (Category 20 & 24, Vibration)
Method 516.6, Procedure I (Mechanical Shock)
Method 501.5, Procedure I (Storage/High Temperature)
Method 501.5, Procedure II (Operation/High Temperature)
Method 502.5, Procedure I (Storage/Low Temperature)
Method 502.5, Procedure II (Operation/Low Temperature)
Method 503.5, Procedure I (Temperature shock)
EMC
CE and FCC compliance
Green Product
RoHS, WEEE compliance
*Specifications are subject to change without notice*
7

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
1.2 Front Panel Components
1
2 x DisplayPort
2
Grounding Screw
3
2 x USB 3.0 (Type A)
4
System/ LAN LED
5
Power Button
6
Power Input (9~36V DC in)
7
2 x DisplayPort
1.3 Rear Panel Components
1
Audio jack (1 x MIC, 1 x Line out)
2
LAN port, 2 x RJ45
3
2 x DisplayPort
4
1 x DVI-I
5
1 x RS232/422/485 with 5V/12V selectable
6
2 x USB 3.0
8

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
1.4 Mechanical Dimensions
9

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
Chapter 2: Jumpers and Connectors
This chapter describes the jumpers and connectors on the systems’ motherboard.
2.1 Front Panel Connector Pin Definitions
Status Indicators
LED1: LAN1 LED STATUS
LED1
Light
Dark
Flash
GREEN
Link
Un-link
Activity
RED
1000M
100M
NA
LED2: LAN2 LED STATUS
LED2
Light
Dark
Flash
GREEN
Link
Un-link
Activity
RED
1000M
100M
NA
LED3: POWER/HDD LED
LED2
Light
Dark
Flash
GREEN
Power On
Power Off
NA
RED
NA
HDD un-access
HDD access
USB3.0 CN19: USB*2
LOWER USB
UPPER USB
PIN
DEFINITION
PIN
DEFINITION
1
USB_VCC2
10
USB_VCC3
2
USBD0-
11
USBD1-
3
USBD0+
12
USBD1+
4
GND
13
GND
5
USB_SSRX3N_C
14
USB_SSRX4N_C
6
USB_SSRX3P_C
15
USB_SSRX4P_C
7
GND
16
GND
8
USB3TN3
17
USB3TN4
9
USB3TP3
18
USB3TP4
10

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
DP1,2,3,4: DISPLAY PORT
PIN
DEFINITION
PIN
DEFINITION
1
DPC_LANEP0
2
GND
3
DPC_LANEN0
4
DPC_LANEP1
5
GND
6
DPC_LANEN1
7
DPC_LANEP2
8
GND
9
DPC_LANEN2
10
DPC_LANEP3
11
GND
12
DPC_LANEN3
13
DDIC_DDC_AUX_SEL
14
GND
15
DPC_AUXP
16
GND
17
DPC_AUXN
18
DPC_DET
19
GND
20
DPC_PWR
POWER BUTTON
Orange Backlight
Blue Backlight
Power Off
Power On
DC IN: DC Adapter Power Input
PIN
DEFINITION
1 4
1
GND
2
GND
3
+VIN
4
+VIN
11

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
2.2 Rear Panel Connector Pin Definitions
LAN1: Intel i217LM
LAN2: Intel I210IT
LAN1
LAN2
PIN
DEFINITION
PIN
DEFINITION
1
D0+
1
D0+
2
D0-
2
D0-
3
D1+
3
D1+
4
D2+
4
D2+
7
D2-
7
D2-
8
D1-
8
D1-
9
D3+
9
D3+
10
D3-
10
D3-
COM1: RS232/422/485 with 5V/12V selectable
Pin
RS-232
RS-422
Half Duplex RS-485
1
DCD#
TX-
D-
2
RXD
TX+
D+
3
TXD
RX+
NA
4
DTR#
RX-
NA
5
GND
GND
GND
6
DSR#
NA
NA
7
RTS#
NA
NA
8
CTS#
NA
NA
9
RI# (Define by JP12)
RI# (Define by JP12)
RI# (Define by JP12)
DP5,6: DISPLAY PORT
PIN
DEFINITION
PIN
DEFINITION
1
DPC_LANEP0
2
GND
3
DPC_LANEN0
4
DPC_LANEP1
5
GND
6
DPC_LANEN1
7
DPC_LANEP2
8
GND
9
DPC_LANEN2
10
DPC_LANEP3
11
GND
12
DPC_LANEN3
13
DDIC_DDC_AUX_SEL
14
GND
15
DPC_AUXP
16
GND
17
DPC_AUXN
18
DPC_DET
19
GND
20
DPC_PWR
12

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
DVI: DVI-I
PIN
DEFINITION
PIN
DEFINITION
1
TMDS Data2-
13
NC
2
TMDS Data2+
14
+5V Power
3
GND
15
GND
4
NC
16
Hot Plug Detect
5
NC
17
TMDS Data0-
6
DDC Clock
18
TMDS Data0+
7
DDC Data
19
GND
8
Analog VSYNC
20
NC
9
TMDS Data1-
21
NC
10
TMDS Data1+
22
GND
11
GND
23
TMDS Clock+
12
NC
24
TMDS Clock-
C1
Analog Red
C2
Analog Green
C3
Analog Blue
C4
Analog HYNC
C5
Analog GND0
C6
Analog GND1
USB3.0
LOWER USB
UPPER USB
PIN
DEFINITION
PIN
DEFINITION
1
USB_VCC0
10
USB_VCC1
2
USBD2-
11
USBD3-
3
USBD2+
12
USBD3+
4
GND
13
GND
5
USB_SSRX1N_C
14
USB_SSRX2N_C
6
USB_SSRX1P_C
15
USB_SSRX2P_C
7
GND
16
GND
8
USB3TN1
17
USB3TN2
9
USB3TP1
18
USB3TP2
MIC 1: Audio Jacks Connector
PIN
DEFINITION
5
MIC_L
4
GND
3
NC
2
MIC1_R
1
GND
LOUT 1: Audio Jacks Connector
PIN
DEFINITION
5
FRONT_L
4
GND
3
NC
2
FRONT_R
1
GND
13

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
2.3 Internal Connector and Jumper Setting
MCARD1: Mini PCIE Card Slot<COLAY M SATA>
PIN
DEFINITION
PIN
DEFINITION
1
WAKE#
2
3.3VAUX
3
COEX1
4
GND
5
COEX2
6
1.5V
7
CLKREQ#
8
UIM_PWR
9
GND
10
UIM_DATA
11
REFCLK-
12
UIM_CLK
13
REFCLK+
14
UIM_RESET
15
GND
16
UIM_VPP
17
Reserved
18
GND
19
Reserved
20
W_Disable#
21
GND
22
PERST#
23
PERn0
24
+3.3Vaux
25
PERp0
26
GND
27
GND
28
1.5V
29
GND
30
SMB_CLK
31
PETn0
32
SMB_DATA
33
PETp0
34
GND
35
GND
36
USB_D-
37
GND
38
USB_D+
39
+3.3VAUX
40
GND
41
+3.3VAUX
42
LED_WWAN#
43
GND
44
LED_WLAN#
45
Reserved
46
LED_WPAN#
47
Reserved
48
1.5V
49
Reserved
50
GND
51
Reserved
52
3.3VAUX
JV2,3: COM1 RS232/422/485 jumper setting
No.
Function Description
JV3
JV2
Location
1
Loopback
2
RS232
(Default)
3
RS485 Half-Duplex
4
RS485/422 Full Duplex
14

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
JV4: COM1 RS422/485 receiver termination
Jumper
Function description
Setting
1-2
Disable RS422/485 receiver termination
(default)
2-3
Enable RS422/485receiver termination
Default setting: 1-2
JP12: COM1P9SEL pin function select
Jumper
Function description
Setting
1-2
COM_RI(Default)
3-4
5VS
5-6
12V
15

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
Chapter 3: AMI BIOS UTILITY
This chapter provides users with detailed descriptions on how to set up a basic system configuration
through the AMI BIOS setup utility.
3.1 Starting
To enter the setup screens, perform the following steps:
•Turn on the computer and press the <Del> key immediately.
•After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be
accessed from the main BIOS setup menu, such as the Chipset and Power menus.
3.2 Navigation Keys
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot
keys can be used at any time during the setup navigation process.
Some of the hot keys are <F1>, <F10>, <Enter>, <ESC>, and <Arrow> keys.
Some of the navigation keys may differ from one screen to another.
Left/Right
The Left and Right <Arrow> keys moves the cursor to select a
menu.
Up/Down
The Up and Down <Arrow> keys moves the cursor to select a setup
screen or sub-screen.
+− Plus/Minus
The Plus and Minus <Arrow> keys changes the field value of a
particular setup setting.
Tab
The <Tab> key selects the setup fields.
F1
The <F1> key displays the General Help screen.
F10
The <F10> key saves any changes made and exits the BIOS setup
utility.
Esc
The <Esc> key discards any changes made and exits the BIOS setup
utility.
Enter
The <Enter> key displays a sub-screen or changes a selected or
highlighted option in each menu.
16

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
3.3 Main Menu
The Main menu is the screen that first displays when BIOS Setup is entered, unless an error has occurred.
You could setup these items on the Main menu:
System Language: Choose the system default language.
System Date: Set the date. Use Tab to switch between date elements.
System Time: Set the time. Use Tab to switch between time elements.
Access Level
Displays the access level of the current user in the BIOS.
17

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
3.4 Advanced Menu
This section allows you to configure and improve your system and allows you to set up some system
features according to your preference.
18

WWW.STACKRACK.COM
Version 1.2
Revision Date: Oct. 20, 2016
MIL-STD Rugged Computer
User’s Manual
3.4.1 PCI Subsystem Settings
PCI, PCI-X and PCI Express settings.
PCI Common Settings
PCI Latency Timer: Value to be programed into PCI Latency Timer Register.
VGA Palette Snoop: Enable or disable VGA Palette Registers Snooping.
PERR# Generation: Enables or Disables PCI Device to Generate PERR#.
SERR# Generation: Enables or Disables PCI Device to Generate SERR#.
PCI Express Settings
Change PCI Express Devices Settings.
PCI Express Device Register Settings
Relaxed Ordering: Enables or Disables PCI Express Device Relaxed Ordering.
Extended Tag: If ENABLED allows Device to use 8-bit Tag field as a requester.
No Snoop: Enabled or Disables PCI Express Device No Snoop option.
Maximum Payload: Set Maximum Payload of PCI Express Device or allow System BIOS to select the
value.
Maximum Read Request: Set Maximum Read Request Size of PCI Express Device or allow System
BIOS to select value.
PCI Express Link Register Settings
ASPM Support: Set the ASPM level: Force L0s - Force all links to L0s state: AUTO - BIOS auto
configure: DISABLE- Disables ASPM. WARNING: Enabling ASPM may cause some PCI-E devices to
fail.
Extended Synch: If ENBLED allows generation of extended synchronization patterns.
19
