Thank you for selecting our
BURAN 1300 ,
you already own the high-tech, professional
DMX snow machine! Better read the manual
thoroughly before operation, follow
instruction will help you have a smooth
handling with BURAN 1300 to achieve the
most satisfactory snow effect, it will also
assist unit to further prolong life time as a
whole.
Warning!Like all electronic products,
BURAN 1300 must be used with safety
precautions in mind.

2
•Withoutuser-serviceablepartsinthepackage,
please contact your local agent or qualified
technician for servicing.
•Withoutchangeablestructurebynon-qualied
user, please do not open the cover or have any
changeatwill,otherwise,itmaycauseaccident!
•Snowmachineisforadultuse.Keepoutof
reach of children. Never leave the unit running
unattended.
•Keepcaseclosedwhileoperating.Putsnow
machine in drafty place, do not insert objects
intoairvents.Allow20cmspaceorabove
around the machine for proper ventilation.
•Keepsnowmachineawayfromamesand
ammableitems.Useonlyhigh-qualitysnow
uid.Neverputammablesubstancesintothe
tank.
•Neverputanyammablematerial(lipid,gas,
perfumeetc.)intothetank,readtheuser
manual thoroughly before operation.
•Betteruseourhigh-qualitysnowuid,random
usewithothersnowuidmaymakebadeffect,
or causing damage to the machine.
•Keepsufcientsnowuidintank.Inthestart
ofsnowuiddetectionstate,ifsnowuidis
insufcient,themachinewillautomaticallystop
working.
•Ifanyabnormalrunningoccurs,stopit
immediately,emptytheuid,andbringthe
doneupunit(recommendoriginalbox)to
youragentordealerforservicing.Makesure
alluidisemptyfromthetankbeforemoving
or shipping.

3
• Neverdrinksnowuid.Ifingested,calladoctor
immediately.Ifuidcontactseyesorskin,rinse
skinthoroughlywithwater.
• Readusermanualinstructionsthoroughly
beforeoperating.Followtheinstruction.Never
removewarningorinformativelabelsfromthe
unit.
!Caution!
There are no user serviceable parts inside this
unit. Do not attempt any repairs yourself, doing
sowillvoidyourmanufactureswarranty.Inthe
unlikelyeventyourunitmayrequireservice
please contact your local dealer.
Particular Warning :
Whenthesnowmachineisidleanddoesnot
work,itisrecommendedtoemptythetank
andmakeacleaningprocedures:putthewater
intothetank,inaccordancewithspraysnow
operationtocleantheinteriorofthesnow
machineuntilthewaterisalmostnofoamsofar.
Pleasenotethatthesnowuidlongtimeplaced
inthesnowmachine,thesnowuidbecomes
stickyandthesnowmachinecomponentsare
stuck,thiscouldmakethesnowmachinedoes
notproperlyblowoutofthesnow.Incaseof
thisproblem,pleasepouroutthesnowuidand
followthecleaningprocedurestocleanitandll
thenewsnowuidagain,ifitstillfails,please
contact the local dealer for processing.

4
Please note:
Specifications and improvements in the design of
this unit and this manual are subject to change
withoutanypriorwrittennotice.
Important
The wires in this mains lead are colored in
accordance with the following code.
EU
GreenandYellow–Earthed(E)
Blue–Neutral(N)
Brown–Live(L)
Warning:Thisappliancemustbeearthed.
USA
GreenandYellow–Earthed(E)
White–Neutral(N)
Black–Live(L)
Warning:Thisappliancemustbeearthed.

5
Figure1 BURAN 1300 Functions
F
A
D
DN
V
O P Q R S T U
C
B
W
E
G
I
J
K
H
L
M
A. HangingBracketwithhandle
screw(couldbedoneasatripod)
B. UniqueAnti-SpillTank
C. QuickConnector
D. InletwithMagneticairlter
E. SnowNozzlewithcloth
F. LCDdisplay
G. MENU
H. UP
I. DOWN
J. ManualON/OFFLEDIndicator
K. Manual ON/OFF
L. TimerON/OFFLEDIndicator
M.Timer ON/OFF
N. ControlSocketConnection
O. DMX3PINXLROutput
P. DMX3PINXLRInput
Q. DMX5PINXLROutput
R. DMX5PINXLRInput
S. PowerInput
T. NFB(NoFuseBreaker)
U. PowerSwitch
V. Suspension/Safety Ring
W. Pad

6
Description
• Realisticsnowfunction,underthisfunctionthesnowvolumeverifies
inrandom,andthesnowingeffectlookslikerealandverynatural.
•Uniquedesignof5.6literliquidtankletBURAN 1300havenoworry
of liquidleakingwhenbeingoperatedupsprayorsidespray.Quick
connectormakesreplacementdirectandeasierwhenperformance is
ongoing.
•Built-inautomaticdetectionofliquid,iftheliquidistoolow,
theLCDdisplaywillshowawarningprompt;andthemachinewill
stopworking.
•Whenupspray,thehangingbracketcouldbedoneasatripod, and
be adjusted elevation angle from 50 to 70 degree to do special
parabolicsnowoutput,thesnowoutputlooksmorenaturaland
beautiful.
•Powerfulandstablesnowoutputcontrolfrom0-100%.Could
flexiblewiththespeedofthefan.Suitableforoperationinany
locations.
•50%and100%airvolumeadjustment.Quietandsmoothair
volumeadjustmentletthespreadofsnowsofter.100%highfan
speedletthesnowbeevenandexpandmorequicklythroughout
the location.
•Specialsoundinsulationdesigntoachievetheeffectofultra-quiet.
•Multi-functionoperationcontrol.Built-Intimercontrol,manual
control, remote control and DMX control.
•DMXonboard,3DMXmodesforchoice;1CH,3CH,5CH,operate
by any additional DMX controller.
•Built-infunctionoftimingcontrolallowseasytimingcontrolinterval
and duration.
•CouldbeusedwiththeVT-1controller(optional)control.Simpleand
user-friendlydesignmakesBURAN 1300easiertouse.
•Ruggedhigh-qualityshapedesignedwithstrongbracket.Liquidtank
designedforquickfixingandwithprotectionagainstgettingloosen
during transportation. All details are required.

7
Getting Ready
All products are thoroughly tested at the factory and shipped in
perfect condition. If damage has occurred during shipping, or if
components are missing, please contact your local dealer immediately.
Your package should include:
1. OneBURAN 1300SnowMachine
2. OnepowerCONcable
3. One product user manual
Mounting
BURAN 1300isshippedcomplete,readytouse.Thebracketis
installedbefore shipping, the unit can be hung in any position. Fasten
the snowmachineontofirmtrussing(Usea20-kgratedorstronger
C-clampboltedontothebracket,enhancingsafetynecessarilywith
safetycables).Allowenoughspace(around20cm)onallsidesfor
proper cooling.
C-clamp
safety cable

8
Set Up
1. Opentheshippingcartonandcarefullyremovethesnowmachine
unit from the shipping carton.
2. Besuretoremovepackingmaterialfromaroundthesnowmachine,
especiallynearthesnowoutlet.
3. Setthesnowmachineonadry,atsurface.
4. Fillthesnowliquidtothetank.Placethefeedertubewithlter
deepinsidethefulluidtank(Figure1-B).Pleaseusedealer
recommendedhighqualitysnowliquidonly.
5. Connectthequickconnectorwiththeliquidtankcap(Figure1-C).
Besureofwellconnection.
6. Plugmainspowercordfromthesnowmachineintoappropriate
powersupplysocket.
7. UseLCDdisplay&Functionbuttonsforoperatingcontrol,
or connect DMX controller for setting.
8. Orrmlyattachtheremotecontrolmechanismtosocket(Figure1-N)
onthebackoftheunitforsimpleoperating.

9
DMX Connector Pin Assignment
Themachineprovidesa3-or5-pinXLRconnectorforDMX
connection.Thediagrambelowindicatespinassignmentinformation.
5 pin XLR 3 pin XLR
1. Ground
1. Ground
1. Ground
1. Ground
2. Cold
2. Cold
2. Cold
2. Cold
3. Hot
3. Hot
3. Hot
3. Hot
4. N/A
4. N/A
5. N/A
5. N/A
XLR Pin Configuration
Pin 1= Ground
Pin 2= Data Compliment
(negative)
Pin 3= Data True (positive)
Pin 4= No use
Pin 5= No use
XLR Pin Configuration
Pin 1= Ground
Pin 2= Data Compliment
(negative)
Pin 3= Data True (positive)

10
Functions of the buttons
1. MENU: Functionswitchingbutton;thenhavethenumericalvalue
changedbyusingUP( )andDOWN( ) buttons.
A. DMX Mode: DMX mode selection. Single channel, 3 channels
and 5 channels mode can be selected.
B. DMX Set: SettingofDMXaddress.Rangeofaddressvalue:
address=001~512.
PressUP/Down1.5secondscanchangevalue
continuously and fast, pressed UP/DOWN at the
sametime,valuebackto1.
C. SNOW V/A: Settingofsnowmodes,therearetwomodes;
Fixedvolume(=V)andrandomvolume(=Auto).
1. V001-V100:Fixedsnowvolume.Thenumber
after V is the concrete value. For example, V30
means30%.
2. A001~100:Interchangeofsnowvolumeevery
5-15 seconds automatically, do not need to
setting.ThenumberafterAiscurrentsnow
volume. It changes at random.

11
D. WIND H/F/A: SettingofAirvolume,therearethreechanges;
Half=50%,Full=100%,andAuto.Autois
randomeffect,interchangeof50%and100%of
air volume every 2-5 minutes.
E. Duration: Settingdurationoftimingsprayingsnow
(Duration=10~200s).
F. Interval: Settingintervaloftimingsprayingsnow 
(Interval=20~2000s).
G.FLUID SCAN ON/OFF: Settingofautomaticinspectionofuid.
1. When this function is OFF, the machine cannot
inspectvolumeoftheuid.Thismeansthatthe
machinewillkeepworkingeventhere’snouid.
2. When this function is ON, the machine starts
this inspection function automatically. Some
pointsneedtobepaidattentionto:
• Themachinecannotdrawuidinthecaseof
20to35secondswillautomaticallyshutdown.
• Whenthemachinedetectsthatnouidwill
stop,theLCDdisplaywillshow“NOFLUID”.
• Ifthemachinedetectsnouidduring
operation,themachinestopsworking.Atthis
moment,itisallowedtosupplementuidin
thetankandthenpressbuttonofManual
ON/OFF or button of Timer ON/OFF to let the
machineenterworkingstatusagain.
H.Display Backlight Setting: Therearetwomodes.Longpressing
oftheMENUcaninterchangethesetwobacklight
modes.
1. Lighted mode: displayappears“ — — FN20 — — ”.
2. Power saving mode: displayappears“ — FN20 — “.
Backlightlightsuponlywhenpressed.
Fewminuteslaterlightoffautomatically.

12
2. :Buttonforincreasingnumericalvalue.
3. :Buttonfordecreasingnumericalvalue.
4. MANUAL ON/OF: Shortpressing:startorstopsprayingsnow.
Longpressing:switchairvolume50%/100%/AUTO.
5.TIMER ON/OFF: Shortpressing:startorstoptimingofsprayingsnow.
Longpressing:switchairvolume50%/100%/AUTO.
Set values are automatically saved.
Control priority order:
When both DMX console and VT-1 are connected to the machine,
appears problem of priority among the panel control, DMX console and
VT-1controller.There’snoapparentpriorityamongthethreecontrols.
Theonewhichhaschangeactiongetsthepriorityofcontrol.
1. If DMX values changes of each DMX channel by DMX console, the
control priority is DMX console.
2. IfwantingVT-1tohavethecontrolpriority,turntheknobtoOFF
then to ON.
3. Pressing Manual ON/OFF button or Timer ON/OFF button of the
control panel to let it get the control priority.
Important: Theonewhichcontrolsthelastactionhasthecontrolpriority.

13
Operation
Plugmainspowercordfromthesnowmachineintoappropriate
powersupplysocket;
Regardlessofthemachineinwhichmode,themain
displayinformationasshownontheleft:
--FN20--: showslightedmodeofthedisplay.
H:showsthestateofairvolume,asshowninFigureH
thatairvolumeis50%.
Vx: showsthecurrentsetofsnowvolume,asshownin
FigureV1thatsnowvolumeof1%.Pleasedofollowthe
requiredoperatingmodes;
Panel Continuous Snow Mode Operation ....................................
“ManualON/OFF”control,whentheexternalcontrollerorDMXsignal
is not connected.
— — FN2.0 — —
H>>>V1
PressMENUtoselecttheSNOWstatus;useUp/
Downbuttontoswitchxedvolume(=V1~100)
andrandomvolume(=Auto).ThelefticonisSNOW
inAutovolume;
Thedisplayinformationasshownontheleft:
--FN20--: showslightedmodeofthedisplay.
H: showsthestateofairvolume,asshownin
FigureHthatairvolumeis50%.
Vx: showsthecurrentsetofsnowvolume,as
showninFigureV100thatsnowvolumeof100%;
PressMENUtoselecttheWINDstatus;useUp/
Downbuttontoswitchairvolume.Thereare
threechanges:Half=50%,Full=100%,andAuto=
randomvolume.ThelefticonisWIND(airvolume)
inAutovolume;
SNOW
AUTO
WIND
AUTO
1.
2.
3. PressManualON/OFFbuttontostartsnowspray;LEDupperthebuttonashes;
— — FN2.0 — —
H>>>V100
4.

14
Panel Timing Snow Mode Operation .............................................
5. PressManualON/OFFbuttonagaintostopsnowspray;LEDupper
the button off.
• WhenturnontheManualON/OFFbuttonoperation,stillcoulduseUp/Down
buttontocontrolsnowincreaseanddecrease.
• WhenturnontheManualON/OFFbuttonoperation,longpressingthe
Manual ON/OFF button to change air volume.
“TimerON/OFF”control,whentheexternalcontrollerorDMXsignal
is not connected.
PressMENUtoselecttheSNOWstatus;useUp/
Downbuttontoswitchxedvolume(=V1~100)
andrandomvolume(=Auto).ThelefticonisSNOW
inAutovolume;
PressMENUtoselecttheWINDstatus;useUp/Down
buttontoswitchairvolume.Therearethreechanges:
Half=50%,Full=100%,andAuto=randomvolume.
ThelefticonisWINDinAutovolume;
PressMENUtoselecttheIntervalstatus;useUp/
Downbuttontoswitchthevalueofinterval,the
rangeis20~2000seconds;
PressMENUtoselecttheDurationstatus;useUp/
Downbuttontoswitchthevalueofduration,the
rangeis10~200seconds;
SNOW
AUTO
WIND
AUTO
1.
2.
Interval
20
Duration
10
3.
4.
5. PressTimerON/OFFbuttontostarttimingsnowspray;LEDupperthebutton
ashes;

15
Remote Control Operation..............................................................
•WhenturnontheTimerON/OFFbuttonoperation,stillcoulduseUp/Down
buttontocontrolsnowincreaseanddecrease.
•When turn on the Timer ON/OFF button operation, long pressing the Manual
ON/OFF or Timer ON/OFF button to change air volume.
Forbestresult,useVT-1wiredcontroller.
Theappearanceofthedisplay,thesnowvolume
andairvolumecontrolledbyVT-1;
Thedisplayinformationasshownontheleft:
TheupperleftfortheDURATION,shownas6
seconds;theupperrightfortheINTERVAL,as
showninFigure20seconds
Theleftlowerforairvolume,asshowninthegure
AUTO;thelowerrightforsnowvolume,asshown
inFigureV100%;
7. PressTimerON/OFFbuttonagaintostoptimingsnowspray;LEDupperthe
button off.
6 20
A> V100
6.
4. Refertoyourcontrollermanualforoperationdetails.(AppendixA)
3.
— — FN2.0 — —
H>>>V1
1. Firmlyattachtheremotecontrolmechanismtosocket(Figure1-N)onthe
backoftheunit;
2. Plugmainspowercordfromthemachineintoappropriatepowersupply
socket;

16
DMX Control Operation ..................................................................
DMX MODE
1 CH
DMX ADDR
5
3.
4.
1. ConnecttheDMX512controllercabletotheinputsocket(Figure1-PorR)
ofthesnowmachineunit.Makesurethesignalcablepolarityiscorrect.
WhenDMXsocketreceiveseffectiveDMXsignals,themachineenterDMX
controlmodeautomatically;
2. Thereare3DMXmodesforchoice;1CH,3CH,&5CH,pleasechoosethe
DMXmodebyMENU
5. Ifdesired,connectanothersnowmachine:Plugoneendofanothersignal
cableintotheoutputsocket(Figure1-OorQ)onthebackofthefirst
BURAN 1300;plugtheotherendofthesignalcabletotheinputsocket
(Figure1-P orR)onthebackofthesecondBURAN 1300.Followthesame
proceduretolinkmoresnowmachines,ifdesired;wholelinkisdaisychain;
6. Down.RefertoDMXchannelchartinFigure2makerelatedsettings. Now
startoperatingBURAN 1300withDMXconsole.
PressMENUtoselecttheDMXModestatus;
useUp/Downbuttontoswitch1CH,3CHand5CH.
Saveautomaticallyaftertheset;
PressMENUtoselecttheDMXADDRstatus;
pressUp/DownbuttontosettheDMXaddress.
Saveautomaticallyaftertheset;
Set values are automatically saved.
link more
snow machines
MT-4

17
CH1
DMX Value Snow Volume
250-255 AUTO
RandomSnow
0-249
*** The air volume setting needs to be set in the panel.
**Interval=0meansconstantsprayingsnow.
**S=seconds
100%
0%
3 CH
1 CH
5 CH
CH1 CH2 CH3
DMX Value Snow Volume DMX Value Air Volume DMX Value ON/OFF
250-255 AUTO
RandomSnow 250-255
AUTO
50%or100%
random change
128-255 SnowON
0-249 0-100% 125-249 100% 0-127 SnowOFF
0-124 50%
CH1 CH2 CH3 CH4 CH5
DMX Value Snow Volume DMX Value Air Volume DMX Value ON/OFF DMX Value Duration DMX Value Interval
250-255 AUTO,
RandomSnow 250-255
AUTO,
50%or100%
random change
128-255 SnowON 0-255 0-255s 0-255 0-2550 s
0-249 0-100% 125-249 100% 0-127 SnowOFF
0-124 50%
Figure 2 DMX Chart

18
Troubleshooting
This troubleshooting guide is meant to help solve simple problems.
Ifaproblemoccurs,carryoutthestepsbelowinsequenceuntila
solution is found. Once the unit operates properly, do not carry out
followingsteps.Iftheproblempersists,referservicingtoaqualied
technician.
Power Connected but No Snow is Emitted:
1. Checkthepowersupply.Plugtheunitintogroundedelectricpower
supplysocketwithpropervoltage;
2. LCDdisplayislitandcheckifitcanoperate;
3. Thecontrolpaneloperationiscorrect;
4. Makesurethesignalcablepolarityiscorrectandgoodconnection;
5. Checkyourcontrollerifincorrectconnection,testthebatteryif
powerenoughforwirelesscontroller;
6. CheckyourDMXaddresssetting;
7. Ifthepipeconnectedtothetankisinwellcondition;
8. ChecktheNFB(nofusebreaker)ifjumpoff,ifany,pleasere-press
thebreakertodotheresetaction;
9. Keepsufcientuidintank.
