Stairville INTIMIDATOR User manual

Technical Specifications
Power AC 120V 60HzAC 230V 50/60Hz
Fuse 20mm Glass 6.3A Fast Blow 20mm Glass 5A Fast Blow
Lamps 1 x 24V 250W
Part No. ELC3 24V 250W(300 Hrs)
Dimension 500mm x 200mm x 155mm / 19.69in x 7.87in x 6.1in
Weight 10 kg / 22 lbs
User Information (Please complete for your records)
Data Purchased : //Serial No. :
Dealer Stamp : Model : CH-605 INTIMIDATOR
CH-610 INSIGNIA
INTIMIDATOR
CH-605
INSIGNIA
CH-610
User Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29th Ct., Hollywood, Florida, USA, FL 33020
Tel:[phone] Fax:[phone]
www.ChauvetLighting.com

E. FIXTURE CLEANING
The cleaning ofinternal and external optical lenses and/or mirrors must be carried
out periodicallyto optimizelight output. Cleaning frequencydepends on the
environment in which the fixture operates: damp, smokyor particularlydirty
surroundings can cause greater accumulation ofdirt on the unit s optics.
· Clean with a soft cloth using normal glass cleaning products.
· Always drythe parts carefully.
· Clean the external optics at least once every20 days. Clean the internal optics
at least every30/60 days.
For further requirements, contact the nearest CHAUVEToffice. .
INDEX
A. GENERAL INSTRUCTIONS
B. MAIN FEATURES
C. LAMP
D. HOW TO CONTROL THE UNIT
-----(1) Byuniversal DMXcontroller
-----(2) Preprogrammed function
-----(3) Byeasycontroller
E. FIXTURE CLEANING

(2) Preprogram functions
The unit can be linked together as master/slave in daisychain in linkage as many
units as required and run bybuilt in preprogrammed chase sequences automatically
or bysound activation.
When linking the INSIGNIA (CH-610) and the INTIMIDATOR (CH-605) in stand
alone mode, the INSIGNIA must be used as the master head.
Not need to set the dipswitches in master/slave mode.
2-light show
Dipswitch 10 “off”means the unit worksnormallyand “on”means inversion. In
order to creating a great light show, you can set dip switch 10 “on”on anyunit that is
linking to the master unit to get contrast movement to each other, even ifyou have
twounits only.Dipswitch 10 on the first unit is no use in the DMX linking, as it is
the master unit that operates the light show.
(3) By easy controller
The easyremote control is used onlyin master/slave mode. Byconnecting to the
1/4”microphone jack ofthe first unit, you will find that the remote control on the first
unit will control all the other units for Stand by, Strobe/Next and Fast/Slowfunction.
1) STAND BY : To blackout all the unit.
2) STROBE/NEXT : Under FASTmode, the light will strobe in
three different ways:
a.) Strobe in different gobos and colors.
b.) Synchronous strobe in white color.
c.) Two-light strobe in white color.
If the unit in slowmode, press NEXT button to choose desired
color and gobo. It will change ten colors and then change one
gobo.
3) FAST/SLOW : When the LED is off,it is in FASTmode. The unit smovement-
Pan/Tilt &Gobo/Color is sound activated. Ifthe LED on, it is in SLOWmode,
Pan/Tilt is sound activated but Gobo/Color wheel are static, controlled byNext
button.

Start the address
Howto address your DMX512 system:
1. Select the channels ofDMX controller
2. Dipswitches
Dip #1 #2 #3 #4 #5 #6 #7 #8 #9 #10
Value 124816 32 64 128 256 option
Examples:
Channel 01：dip / on : #1（=1）
Channel 06：dip / on : #2, #3（2+4=6）
Channel 11：dip / on : #1, #2,#4（1+2+8=11）
Channel 16：dip / on : #5（=16）
A.GENERAL INSTRUCTIONS
Please read the enclosed instructions carefully as they include important points about
safety for the installation, usage and maintenance of the unit.
Please keep this booklet with the unit for future consultation. Ifyou sell the unit to
another user, be sure that the newuser also receives this instruction booklet thus
giving themthe necessaryinformation about the use and general warnings
regarding the unit.
Before the initial start-up, please unpackand carefullycheckall components in
case anydamage mayhave occurred during shipping.
Locate asuitable spot for your device where there is good ventilation. Also, make
sure that no ventilating fans or slots are blocked.
Protect our environment!Please dispose ofthe packing boxes properly.
The electrical workthat is necessaryfor installation must done byqualified
personnel.
Alwaysremember to unplug the unit fromthe main power before anyservice is
done. Do not open the unit. There are no serviceable parts inside.
It is veryimportant to ground the yellow/green conductor to earth in order to meet
regulations for safety.
Checkthe surrounding area and makesure there are no flammable liquids, water
or metal objects that could enter the fixture. Ifaforeign object enters the unit,
immediatelydisconnect the main power. Also, place the fixture in awell-ventilated
roomat about 15 cmfromthe walls.
Do not touch anywires during operation, as high voltage is hazardous.
In the event ofserious operating problems, stop using the unit immediately.Never
tryto repair the unit yourself.Repairs carried out byunqualified personnel can lead
to damage or malfunction. Please contact the nearest authorized Technical
Assistance Center. Always use genuine spare parts.

B. MAIN FEATURES
Voltage：AC 120V~60Hzor 230V~50/60 Hz
Bulb：ELC3 24V 250W
The unit is aDMX512 scanner. It features full DMX512 control, 14 gobos plus
open and 11 colors plus white, accurate focusable optics systemand stepper
motor with blackout feature. Fan cooled.
It can be operated byDMX512 control or can be used as an individual unit without
a control.
It can be linked together in master/slave combination units, as manyas required in
4channels and run bybuilt-in preprogrammed chase sequences automaticallyor
bysound activation through an internal microphone to create an intelligent effect.
Please use a 3 pin XLR cable/plug when connecting themtogether.
It features different preprogrammed chase patterns.
Dimensions：500mm x 200mm x 155 mm / 19.69 in x 7.87 in x 6.1 in
Weight：10 kg / 22 lbs
C. LAMP
ELC3 24V 250W (300 Hrs)
Alwaysswitch off the mains supplyand never handle the lampor luminaire when
it is hot.
Do not touch the bulb with bare hands. Ifthis does happen, clean the lampwith
denatured alcohol and wipe with a lint free cloth before installing.
D. HOW TO CONTROL THE UNIT
(1) By universal DMX controller
The DMX512 is widelyused in intelligent lighting control, with amaximumof512
channels.
120 ohm 1/4W
Termination reduces signal errors and to avoid signal
(Resistance 120 ohm 1/4W) between pin2 (DMX-) and
transmission problems and interference. It is always
3
pin3 (DMX+) of the lastfixture.
advisable to connect a DMX terminal.
2
DMX -
1
COMMON
DMX +
3
1
DMX512
2
1234
DMX INPUTDMX OUTPUT
2
3
1
Ÿ ADMX512 systemrequires acontroller, lighting equipment and cable. These are
connected together in a “daisychain”with the terminator at the end. The cable
cannot be branched or split to a “Y”cable.
Ÿ The terminator requires a90-120 Ohm1/4 Watt resistor soldered between two
signal cables.
Ÿ The DMX512 uses a veryhigh-speed signal. Inadequate or damaged cables, bad
solder joints or corroded connectors can easilydistort the signal and shut down
the system. A reliable DMX512 systemstarts with good qualitycables.
Ÿ Each lighting unit needs to have an address set to receive the data sent bythe
controller. The address number is between 0-511. The end ofthe DMX512
systemshould be terminated reducing signal errors.
Ÿ 3 pin XLR connectors are more popular than 5 pin XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
