ENGLISH (Original instructions)
Intended use
Your STANLEY FAT MAX SFMEE500 wall sander has been
designed for sanding walsl and ceilings. This appliance is
intended for professional and private, non professional users.
Safety instructions
General power tool safety warnings
@Warning! Read all safety warnings,
instructions, illustrations and
specications provided with this power
tool. Failure to follow the warnings and
instructions listed below may result in electric
shock,reand/orseriousinjury..
Save all warnings and instructions for future reference.
The term "power tool" in all of the warnings listed below
refers to your mains operated (corded) power tool or battery
operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b. Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
c. Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify
the plug in any way.
Do not use any adapter plugs with earthed (grounded)
power tools.
 Unmodiedplugsandmatchingoutletswillreduceriskof
electric shock.
b. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
e. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common
sense when operating a power tool.
Do not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
resultinseriouspersonalinjury.
b. Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
c. Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carryingpowertoolswithyourngerontheswitchor
energising power tools that have the switch on invites
accidents.
d. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotatingpartofthepowertoolmayresultinpersonalinjury.
e. Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts.Looseclothes,jewelleryorlonghair
can be caught in moving parts.
g. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
 severeinjurywithinafractionofasecond.
4. Power tool use and care
a. Do not force the power tool. Use the correct power
tool for your application.
 Thecorrectpowertoolwilldothejobbetterandsaferat
the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.

7
ENGLISH
(Original instructions)
c. Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d. Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e. Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the
power tools operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into
account the working conditions and the work to be
performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations.
6. Service
a. Have your power tool serviced by a qualied repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
Additional power tool safety warnings
@Warning! Additional safety warnings for wall
sanders.
uThis power tool is intended to function as a sander.
Read all safety warnings, instructions,illustrations
and specications provided with this power tool.
Failure to follow all instructions listed below may result
 inelectricshock,reand/orseriousinjury.
uOperations such as grinding, wire brushing,
polishing or cutting-off are not recommended to
be performed with this power tool. Operations for
which the power tool was not designed may create a
 hazardandcausepersonalinjury.
uDo not use accessories which are not specically
designed and recommended by the tool
manufacturer.
Just because the accessory can be attached to your
power tool, it does not assure safe operation.
uThe rated speed of the accessory must be at least
equal to the maximum speed marked on the power
tool. Accessories running faster than their rated speed
 canbreakandyapart.
uThe outside diameter and the thickness of your
accessory must be within the capacity rating
of your power tool. Incorrectly sized accessories
cannot be adequately guarded or controlled.
uThreaded mounting of accessories must match the
grinder spindle thread. For accessories mounted
by anges, the arbour hole of the accessory must
t the locating diameter of the ange. Accessories
that do not match the mounting hardware of the power
tool will run out of balance, vibrate excessively and
may cause loss of control.
uDo not use a damaged accessory.
Before each use inspect the accessory such as
abrasive wheels for chips and cracks, backing pad
for cracks, tear or excess wear, wire brush for loose
or cracked wires. If the power tool or accessory is
dropped, inspect for damage or install an undamaged
accessory. After inspecting and installing an
accessory, position yourself and bystanders away
from the plane of the rotating accessory and run
the power tool at maximum no load speed for one
minute.Damaged accessories will normally break
apart during this test time.
uWear personal protective equipment .Depending
on application, use face shield, safety goggles
or safety glasses. As appropriate, wear dust
mask, hearing protectors, gloves and shop
apron capable of stopping small abrasive or
workpiece fragments. The eye protection must
 becapableofstoppingyingdebrisgeneratedby
various operations. The dust mask or respirator must
 becapableofltratingparticlesgeneratedbyyour
operation. Prolonged exposure to high intensity noise
may cause hearing loss.
uKeep bystanders a safe distance away from work
area. Anyone entering the work area must wear
personal protective equipment. Fragments of the
 workpieceorofabrokenaccessorymayyawayand
 causeinjurybeyondtheimmediateareaofoperation.
uHold the power tool by insulated gripping surfaces
only, when performing an operation where the
cutting accessory may contact hidden wiring or
its own cord. Cutting accessory contacting a “live”
wire may make exposed metal parts of the power tool
“live” and could give the operator an electric shock.

8
ENGLISH (Original instructions)
uPosition the cord clear of the spinning accessory.
If you lose control, the cord may be cut or snagged
and your hand or arm may be pulled into the spinning
accessory.
uNever lay the power tool down until the accessory
has come to a complete stop. The spinning
accessory may grab the surface and pull the power
tool out of your control.
uDo not run the power tool while carrying it at your
side. Accidental contact with the spinning accessory
could snag your clothing, pulling the accessory into
your body.
uRegularly clean the power tool’s air vents. The
motor’s fan will draw the dust inside the housing and
excessive accumulation of powdered metal may cause
electrical hazards.
uDo not operate the power tool near ammable
materials. Sparks could ignite these materials.
uDo not use accessories that require liquid
coolants. Using water or other liquid coolants may
result in electrocution or shock.
Further safety instructions
Kickback and related warnings
Kickback is a sudden reaction to a pinched or snagged
rotating wheel, backing pad, brush or any other accessory.
Pinching or snagging causes rapid stalling of the rotating
accessory which in turn causes the uncontrolled power tool
to be forced in the direction opposite of the accessory’s
rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched
by the workpiece, the edge of the wheel that is entering
into the pinch point can dig into the surface of the material
causing the wheel to climb out or kick out. The wheel may
eitherjumptowardorawayfromtheoperator,depending
on direction of the wheel’s movement at the point of
pinching. Abrasive wheels may also break under these
conditions.
Kickbackistheresultofpowertoolmisuseand/orincorrect
operating procedures or conditions and can be avoided by
taking proper precautions as given below.
uMaintain a rm grip on the power tool and
position your body and arm to allow you to resist
kickback forces. Always use auxiliary handle, if
provided, for maximum control over kickback or
torque reaction during start-up. The operator can
control torque reactions or kickback forces, if proper
precautions are taken.
uNever place your hand near the rotating accessory.
Accessory may kickback over your hand.
uDo not position your body in the area where power
tool will move if kickback occurs.
Kickback will propel the tool in direction opposite to the
wheel’s movement at the point of snagging.
uUse special care when working corners, sharp
edges etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing have
a tendency to snag the rotating accessory and cause
loss of control.
uDo not attach a saw chain woodcarving blade or
toothed saw blade. Such blades create frequent
kickback and loss of control.
Additional safety instructions for sanding
operations
Safety Warnings Specic for Sanding Operations:
uDo not use excessively oversized sanding disc
paper. Follow manufacturers recommendations,
when selecting sanding paper. Larger sanding paper
extending beyond the sanding pad presents a laceration
hazard and may cause snagging, tearing of the disc or
kickback.
Safety of others
uThis tool is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
uChildren should be supervised to ensure that they do not
play with the appliance.
Residual risks
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
u Injuriescausedbytouchinganyrotating/movingparts.
u Injuriescausedwhenchanginganyparts,bladesor
accessories.
u Injuriescausedbyprolongeduseofatool.Whenusing
any tool for prolonged periods ensure you take regular
breaks.
uImpairment of hearing.
uHealth hazards caused by breathing dust developed when
using your tool (example:- working with wood, especially
oak, beech and MDF.)

9
ENGLISH
(Original instructions)
Vibration
The declared vibration emission values stated in the technical
data and the declaration of conformity have been measured in
accordance with a standard test method provided by EN60745
and may be used for comparing one tool with another.
The declared vibration emission value may also be used in a
preliminary assessment of exposure.
Warning! The vibration emission value during actual use of
the power tool can differ from the declared value depending
on the ways in which the tool is used. The vibration level may
increase above the level stated.
When assessing vibration exposure to determine safety
measuresrequiredby2002/44/ECtoprotectpersonsregularly
using power tools in employment, an estimation of vibration
exposure should consider, the actual conditions of use and the
way the tool is used, including taking account of all parts of the
operating cycle such as the times when the tool is switched off
and when it is running idle in addition to the trigger time.
Labels on tool
The following pictograms along with the date code are shown
on the tool:
:Warning!Toreducetheriskofinjury,theuser
must read the instruction manual.
Wear ear protectors with impact drills. Exposure
to noise can cause hearing loss.
Wear safety glasses or goggles.
Wear a dust mask.
Electrical safety
#This tool is double insulated; therefore no
earth wire is required. Always check that the
power supply corresponds to the voltage on
the rating plate.
uIf the supply cord is damaged, it must be replaced by
the manufacturer or an authorised STANLEY FAT MAX
Service Centre in order to avoid a hazard.
Features
This appliance includes some or all of the following features.
1. Round sanding head
2. Round sanding pad (hook & loop system)
3. Motor housing
4. Folding lock
5. Main handle
6. Shaft
 7. On/Offswitch
8. Electronic speed control wheel
9. Dust extration outlet (with locking sleeve)
10. Extension shaft
10a. Rear handle
10b. Dust extraction outlet (with locking sleeve)
10c. Sleeve
11. Vacuum hose
11a. Support adaptor
11b. Connector (pre-assembled) (38mm)
11c. Suctionpoweradjustmentring
11d. Vacuum adaptor (pre-assembled) (47mm)
12. Vacuum adaptor (pre-assembled) (35mm)
13. Hex wrench
14. Round sanding disc
Use
Warning! Let the tool work at its own pace.
Do not overload.
uBeforeusingthetoolforthersttime,itisrecommended
to receive practical information.
uAlways check that the supply voltage is the same as the
voltage indicated on the nameplate of the tool.
uUsesuitabledetectorstondhiddenutilitylinesor
call the local utility company for assistance(contact with
 electriclinescanleadtoreorelectricalshock;damaging
a gas line can result in an explosion; penetrating a water
pipe will cause property damage or an electrical shock).
uDo not work materials containing asbestos (asbestos is
considered carcinogenic).
uDust from material such as paint containing lead, some
wood species, minerals and metal may be harmful
(contact with or inhalation of the dust may cause allergic
reactionsand/orrespiratorydiseasestotheoperator
or bystanders); wear a dust mask and work with a dust
extraction device when connectable.
uCertainkindsofdustareclassiedascarcinogenic(such
 asoakandbeechdust)especiallyinconjunctionwith
additives for wood conditioning; wear a dust mask and
work with a dust extraction device when connectable.
uFollow the dust-related national requirements for the
materials you want to work with.
uDo not clamp the tool in a vice.
uUse completely unrolled and safe extension cords with a
capacity of 16 Amps.
After use
uAfter switching off the tool, never stop the rotation of the
accessory by a lateral force applied against it.

10
ENGLISH (Original instructions)
Assembly and adjustment
Warning!Toreducetheriskofseriouspersonalinjury,turn
tool off and disconnect tool from power source before making
anyadjustmentsorremoving/installingattachmentsor
accessories. Before reconnecting the tool, depress and
release the trigger switch to ensure that the tool is off. An
accidentalstart-upcancauseinjury.
Assemble foldable shaft (Fig. A1, A2, A3)
uFully unfold the upper shaft and lower shaft (Fig. A1).
uPush the folding lock (4) to the right position and keep
 thetipadjacenttothehandle(Fig.A2).
uPress down the folding lock (4) to lock the shaft (Fig. A3).
uRelease the folding lock to fold the shaft.
Replace sanding pad (Fig. B1)
uInsert the hex wrench (13) (size 5) into the hexagonal
screw bolt on the sanding block.
uHoldthesandingpadrmly,andthenturnthewrench
counter clockwise to dismount the pad.
uInstall new sanding pad by tightening the bolt.
Attaching and changing sanding disc (Fig. B2)
uPlace the sanding disc (14) in the center of the sanding
pad (2) and press on. The holes in the sanding disc must
be in alignment with the extraction holes in the sanding
pad.
uFor round sanding pad only: conduct a test run to
check that the sanding disc is clamped in the centre.
The LED light
u10W LED lights surrounding the pad lighten the
cupped and raised spots on the wall or ceiling, enable you
toworkefcientlyanddeliverabettersandingresultas
showninguresEandF.
Extension shaft (optional) (Fig. C)
uUse the extension shaft (10) according to the intended
operation for higher work surface.
uLoosen the sleeve on the dust extraction outlet (9) of the
shaft. Do not remove the sleeve from the outlet.
uAlign the rear handle (10a) with the main handle (5)
and insert the sleeve (10c) on the extension shaft (10)
into the outlet (9) with a twist motion all the way to the
top.
uAdjustthelengthoftheextensionshaft(10)if
necessary. Pay attention to the marking “max 1.8m”
on the extension shaft. Tighten the sleeve (9) after
 assembling/adjustingtheextensionshaft.
Dust suction (Fig. D)
uLoosen the sleeve on the dust extraction outlet (9)
or (10b) by turning it in the direction of the unlocking
symbol on the tool handle.
uInsert vacuum hose (11) into the end of the tool handle
as illustrated.
uTightenlockingknobforlengthadjustment(9)by
turning it in the direction of the locking symbol on the
tool handle.
uConnect the vacuum hose with the Ø 47 mm adapter
(11d) or with the Ø35mm adapter (12) directly to an
industrial vacuum cleaner (remove vacuum cleaner
 hoserst).
uYou can also connect vacuum hose with one adapter
to an industrial Vacuum cleaner without removing the
vacuum cleaner hose.
Support adaptor/airow control (Fig. G, H)
uSupport adaptor (11a) protects the hose from damage
when putting the tool aside during work breaks (Fig. G).
uControltheairowbyslidingsuctionpoweradjustment
ring (11c) over the airvent in tool connector (11b).
uThe vacuuming power is at its lowest level when the
air vent is fully visible (Fig. H).
Switching the machine on and off (Fig. I, J, K)
uTurnthewallsanderon/offusingtheswitch(7).
Electronic speed control
uAdjustthespeedbyturningthespeedwheel(8),user
can choose different speed for different sanding
surface.
uKeep the machine running at the same speed as
selected. Do not overload by excessive pressure.
Sanding operations
uOnce the machine and vacuum cleaner are set up
and all safety measures and equipment are in place,
begin by turning on the vacuum cleaner and then the
machine. (If you are using a vacuum cleaner with
integrated switching, then simply turn the machine on.)
Round sanding head
uBegin sanding and carefully contact the work surface
 aslightlyaspossible-justenoughtokeepthesanding
 headatagainstthesurface.
uThe best technique is to use overlapping sweeps and
keep the head in constant motion with appropriate
lasting time. Never keep sanding too long in any one
place or there will be swirl marks.
uTake the machine from the work surface before turning
off.
Warning! Ensure that the sanding disc you are using is suited
to the task, Overly coarse grit paper may remove material too
quicklytocontrol.Whileoverlynegritpapermaynotsand
the surface quickly.
Warning!Takecaretoavoidsharpprojectionsandnails,etc.
